Jacuzzi era EU70 User manual

era™ freestanding slipper tub
Gentle curves and romantic lines, deep
bathing wells and the beauty of acrylic
combine to create the Era collection of
freestanding baths.
era™ freestanding slipper tub
model number: EU70
exterior dimensions:
60" long x 32" wide x 26" high
( height includes feet )
operating gallons:
43 gallons
era™ freestanding faucet with
stops
model number: EV16
era™ freestanding wall mounted
faucet
model number: EV19
era™ drain assembly
model number: EV23
era™ freestanding slipper tub
model number: EU75
exterior dimensions:
69" long x 34" wide x 26" high
( height includes feet )
operating gallons:
56 gallons
features:
• Slipper and double-ended versions available
• Edwardian claw on slipper tub
• Durable acrylic construction
• Matching drain and faucets available
• Coordinating suite includes toilet and lavatories
faucet accessory for era:
• Ceramic disk cartridge
• Solid brass construction
• Vacuum breaker in hand held shower
• 60” hose lenght
• Available in chrome, brushed nickel and polished
brass
Shown with optional faucet (EV19) and supply line/stops (EV16)
Models EV16
and EV19 shown
Faucet & drain assembly sold separately

Product Shown: Era Freestanding Slipper Soaker Model: EU75
EraTM Freestanding Slipper Tub
Model: EU70 / EU75
Installation Notes
Refer to installation instructions included with xture before beginning installation.
Please conrm product availability and specications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Ordering Information
Product Code:
EU70 Era Slipper 6032 Soaker
EU75 Era Slipper 6934 Soaker
• End Drain Location
• Accessories / Hardware:
Era Wallmount Faucetry: # EV19
Era Floormount: # EV16
Plated Drain: # EV23
Edwardian Feet: #EV06/EV07*
• Hardware Finishes Available:
(827) – Chrome
(829) – Bright Brass
(826) – Brushed Nickel
(959) – White*
* Edwardian claw only hardware available in (959) white
*Repair part reference numbers Technical Specications
Dimensions
60” L x 32”W x 26” H (EU70)
(1524 mm) L x (813 mm) W x (660 mm) H
69” L x 34”W x 24” H (EU75)
(1753 mm) L x (864 mm) W x (610 mm) H
Drain/Overow
A: 17.00” (432 mm) B: 13-7/8” (352 mm)
Total Weight
467 lb. (212 kg) / 33 lb/ft2(15 kg/m2) (EU70)
580 lb. (263 kg) / 36 lb/ft2(16 kg/m2) (EU75)
Operating Gallonage
43 U.S. Gal. (20 Liters) (EU70)
56 U.S. Gal. (25 Liters) (EU75)
Product Weight
110 lb. (50 kg) (EU70)
116 lb. (53 kg) (EU75)
© Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino • California • 91710 • www.jacuzzi.com
#GB48 07/01
W
L
H
A
B
Drain/Overow
EU70: 32.00”
EU75: 30.00” EU70: 28.00”
EU75: 26.00”

Era Freestanding Faucet Specs
Used on EU70, EU75, EU95, & EV00
EV16 & EV19 SPECIFICATIONS
EV19 Era Wall Mount Faucet
EV19 Era Faucet & EV16 Era Supply Lines
25-1/2”
4”
3”
27-1/2”
NOTE: Install through
1-1/4” Hole. Plumber to supply
3/4”NPT x Sweat Adaptor
(Straight or Elbow)
