Jacuzzi Signa D578 User manual

signa® 5 whirlpool bath and soaking bath (with 3 tile flange)
the signa®whirlpool bath takes its name from the medieval central italian walled city, lastra a signa.
Like the walled city for which it is named,
Signa®5 was specially developed and
designed for walled surround spaces.
whirlpool bath features:
• Contoured backrest.
• 4 Fully adjustable TheraPro™ jets
• 2 AccuPro™ foot jets.
• Exclusive Tru-Level™ self-leveling base system
• Slip-resistant bottom.
• Patented Fixed Air Flow System
• Drain included on whirlpool baths
signa®5 with 3 tile flange
soaking bath
model number: D578 (w/3-tile flange)
exterior dimensions:
60" long x 42" wide x 22" high
interior dimensions:
41" long x 25" wide
signa®5 with 3 tile flange
whirlpool bath
model number: D560 – RH pump,
D569 – LH pump
exterior dimensions:
60" long x 42" wide x 22" high
interior dimensions:
41" long x 25" wide
# of Jets/type of Jets:
4 TheraPro™ Jets
2 AccuPro™ Back Jets
operating gallons:
42 gallons

Signa™ 5 Whirlpool Bath with 3 Tile Flange
Model: D560, D569
Signa™ 5 Bath with 3 Tile Flange
Model: D578
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Electrical Components and Electrical Specifications do not apply to non-jetted baths.
Ordering Information
Product Code:
D560 Signa™ 5 Whirlpool Bath with
3 Tile Flange Right Hand
D569 Signa™ 5 Whirlpool Bath with
3 Tile Flange Left Hand
D578 Signa™ 5 Bath with 3 Tile
Flange
• Center Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
TheraPro™ Jet Rings Kit: #D095
AccuPro™ Jet Rings Kit: #P556
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Technical Specifications
Dimensions
60” L x 42” W x 22” H
(1524 mm) L x (1067 mm) W x (559 mm) H
Drain/Overflow
A: 17-1/2” (445 mm) B: 12-1/2” (318 mm)
Cutout
Not Applicable
Total Weight
D560, D569: 708 lb (321 kg) / 40 lb/sq. ft. (197 kg/m2)
D578: 667 lb (303 kg) / 38 lb/sq. ft. (186 kg/m2)
Operating Gallonage
42 U.S. Gal. (159 Liters)
Max. 82 U.S. Gal. (310 Liters)
Product Weight
D560, D569:108 lb (49 kg)
D578: 67 lb (30 kg)
Skirt Mounting
Optional, U-Frame
Electrical Specifications Models D560, D569 only
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Optional) Models D560, D569 only
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
12"
30"
5"
42"
*60"
13" x 5"
4-1/4"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
© Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino • CA • 91710 • www.jacuzzi.com
BATHS WITH 3-SIDED TILE FLANGE
L
1"
(25 mm)
H
W
SIDE VIEW END VIEW
#FS13 06/07
DRAIN/OVERFLOW
A
B
Product Shown: Signa™ 5 Whirlpool Bath with 3 Tile Flange Right Hand Model: D560
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
