Jacuzzi J-200 Series User manual

•J-285™
•J-275™
•J-245™
•J-235™
• J-225™
• J-215™
J-200™ COLLECTION
OWNER’S MANUAL
2530-277K Rev A

Attention New Spa Owner!
Congratulations on the purchase of your new Jacuzzi®spa! The following is a
list of automated functions performed by your spa. These functions are listed
below in an attempt to alleviate any operational concerns you may have during
the rst 24 hours of ownership! Also listed below are important maintenance
recommendations you should observe on a regular basis to protect your new
investment.
Automated Operations
Blow out cycle: Before each lter cycle, pump 2 will activate to clear out the
plumbing lines.
Clean up cycle: Begins 30 minutes after a pump is turned off or it has timed out.
Pump 1 (low speed) and the CLEARRAY® unit turn on and run for 30 minutes.
Maintain Healthy Spa Water
Always maintain your spa’s water chemistry within the following parameters:
With CLEARRAY® Without CLEARRAY®
pH 7.4-7.6 7.4-7.6
Free Chlorine no less than 1.0 ppm 3.0-4.0 ppm
Free Bromine no less than 2.0 ppm 2.0-4.0 ppm
Total Alkalinity 100-150 ppm 100-150 ppm
Calcium Hardness 150-250 ppm 150-250 ppm
IMPORTANT: The CLEARRAY® system is factory installed. If the CLEARRAY®
system is altered or is not operating efciently then follow the “without
CLEARRAY®” water chemistry parameters as dened by the Pool & Hot Tub
Alliance. CLEARRAY® Unit requires an annual bulb replacement to operate
properly.
!TO DECREASE RISK OF INFECTION OR DISEASE! Always maintain
your spas lter as outlined below to ensure healthy spa water. Refer page 45
“Water Quality Maintenance” for additional information.
Required Filter Maintenance
Your new spa is equipped with an advanced water ltration system that provides
unsurpassed water quality! To ensure maximum water quality at all times, you should
clean the lter cartridge once a month, or earlier as necessary. See page 40 for
detailed lter cartridge cleaning/replacement instructions.
Required Water Replacement
!TO DECREASE RISK OF INFECTION OR DISEASE!
You should replace
the spa’s water every 3 months. The frequency depends on a number of variables
including frequency of use, number of users, and attention paid to water quality
maintenance. You will know it is time for a change when you cannot control
sudsing and/or you can no longer get
the normal feel or sparkle to the water, even
though the key water balance measurements are all within the proper
parameters. See page 45 for additional information.
****** Spa operation/features subject to change without notice ******

Table of Contents
1.0 Important Spa Owner Information.............................................. 1
2.0 FCC Notice ................................................................................... 1
3.0 Important Safety Instructions for all Spa Owners .................... 2
3.1 Entrapment Risk ............................................................................ 7
3.2 Hyperthermia ................................................................................. 8
3.3 Important Safety Instructions......................................................... 9
3.4 PRECAUTIONS-Important Chemical Safety ................................. 9
3.5 PRECAUTIONS FOR USE OF PRODUCTS
CONTAINING SODIUM BROMIDE ............................................... 9
4.0 Choosing A Location................................................................. 10
4.1 Outdoor Location ......................................................................... 11
4.2 Indoor Location............................................................................ 11
5.0 General Electrical Safety Instructions..................................... 13
6.0 Power Requirements................................................................. 14
7.0 Electrical Wiring Instructions................................................... 15
8.0 Spa Fill Up Procedure ............................................................... 20
9.0 Control Functions...................................................................... 25
9.1 Control Panel Buttons.................................................................. 25
9.2 Control Panel Display Icons......................................................... 25
9.3 General Spa Features and Controls............................................ 27
10.0 Operating Instructions .............................................................. 28
10.1 Setting Water Temperature.......................................................... 28
10.2 Activate Jets Pump...................................................................... 29
10.3 Multi-Colored LED Light System Operation................................. 29
10.4 Adjusting Individual Jet Flow ....................................................... 29
10.5 Air Controls.................................................................................. 30
10.6 Blow-Out Cycle............................................................................ 30
10.7 Cleanup Cycle ............................................................................. 30
10.8 Optional SmartTub® System ....................................................... 30
11.0 Menu Features and Programming Instructions...................... 32
11.1 Adjusting the Temperature........................................................... 32
11.2 Programming the Mode Setting................................................... 33
11.3 Adjusting and Setting the Time.................................................... 34
11.4 Invert the display.......................................................................... 34
11.5 Locking the Spa........................................................................... 34
11.6 Hold (Standby)............................................................................. 35
11.7 Programming the Filtration Cycles............................................... 36
11.8 Preferences ................................................................................. 38
11.9 Utilities ......................................................................................... 39
© Jacuzzi Hot Tubs, Inc. All Rights Reserved

12.0 Spa Maintenance ....................................................................... 40
12.1 Cleaning The Filters..................................................................... 40
12.2 DrainingandRelling................................................................... 42
12.3 Pillow Care................................................................................... 43
12.4 Cleaning The Spa Interior............................................................ 43
12.5 Cover Care and Maintenance...................................................... 43
12.6 Maintaining The Synthetic Cabinet.............................................. 44
12.7 Winterizing ................................................................................... 44
12.8 Restarting Your Spa in Cold Weather.......................................... 45
13.0 Water Quality Maintenance....................................................... 45
13.1 pH Control.................................................................................... 46
13.2 Sanitizing ..................................................................................... 46
13.3 CLEARRAY® System.................................................................. 47
13.4 CLEARRAY® Lamp Replacement and Quartz
Tube Maintenance ....................................................................... 48
14.0 Error Conditions and Messages............................................... 51
15.0 Troubleshooting Procedures.................................................... 54
15.1 None of the Components Operate (e.g., Pump, Light) ................ 54
15.2 Pump Does Not Operate ............................................................. 54
15.3 Poor Jet Action ............................................................................ 54
15.4 Water is Too Hot .......................................................................... 54
15.5 No Heat........................................................................................ 55
16.0 Circuit Board Diagrams............................................................. 56
16.1 2-Pump Models............................................................................ 56
16.2 J-215 and J-225 Convertible Power Models (For a
3-wire 120V 60 Hz connection).................................................... 58
16.3 North American J-215 and J-225 Convertible Power
Models (For a 4-wire 240V 60 Hz connection) ............................ 59
17.0 Dip Switch Settings and Wiring................................................ 61
17.1 Switch settings for Domestic 60Hz Models.................................. 61

J-200
1.0 Important Spa Owner Information
Your Jacuzzi J-200 Collection spa is constructed to the highest standards
and is capable of providing many years of trouble-free use. However,
because heat retentive materials are utilized to insulate the spa for
efcient operation, an uncovered spa surface and wall ttings directly
exposed to sunlight and high temperatures for an extended period are
subject to permanent damage. Damage caused by exposing the spa
to this abuse is not covered under warranty. We recommend that you
always keep the spa full of water when it is exposed to direct sunlight
and that you keep the Jacuzzi premium insulating cover in place at
all times when the spa is not in use. Read and carefully follow the
requirements for your spa’s support base found in Section 4.0 titled,
“Choosing A Location” (page 56).
Jacuzzi constantly strives to offer the nest spas available,
therefore modications and enhancements may be made which
affect the specications, illustrations and/or instructions contained
herein.
2.0 FCC Notice
This equipment has been tested and found to comply with the limits for
a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
1. Rearrange or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from the
circuit connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party
responsible for FCC compliance could void the user’s authority to
operate this equipment.
1

J-200
3.0 Important Safety Instructions for all Spa Owners
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!
This spa was manufactured to meet the standards and specications
outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB
Safety Act). When installing and using this spa, basic safety precautions
should always be followed, including:
1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
• Extreme caution must be exercised to prevent unauthorized access
by children.
• To avoid accidents, ensure that children do not use this spa unless
supervised at all times. Adult supervision is a critical safety factor in
preventing children from drowning.
• Use the straps and clip tie downs to secure the spa cover when not
in use. This will help discourage unsupervised children from entering
the spa. Keep the spa cover secure in high-wind conditions.
• There is no representation that the cover, clip tie-downs, or actual
locks will prevent access to the spa.
2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
• Keep hair, loose articles of clothing or hanging jewelry away from
suction ttings, rotating jets or other moving components to avoid
entrapment that could lead to drowning or severe injury.
• Never use the spa unless all suction guards, lter, lter lid, or
skimmer assembly are installed to prevent body and/or hair
entrapment.
• Never operate or use the spa if the lter, lter lid, or skimmer
assembly are broken or any part of the skimmer assembly is missing.
Please contact your dealer or nearest service center for service.
• The suction ttings and suction covers in this spa are sized to match
the specic water ow created by the pump(s). If it is necessary to
replace the suction ttings, suction covers or pump(s), be sure that
the ow rates are compatible and are in compliance with the VGB
Safety Act.
• Never replace a suction tting or suction cover with one rated less
than the ow rate marked on the original suction tting. Using improper
suction ttings or suction covers can create a body or hair suction
entrapment hazard that may lead to drowning or severe injury.
3. !DANGER: RISK OF SEVERE INJURY FROM ELECTRIC
SHOCK OR DEATH FROM ELECTROCUTION!
• Install the spa at least 5 feet (1.5m), from all metal surfaces. As an
alternative, a spa may be installed within 5 feet of metal surfaces
if each metal surface is permanently connected (bonded) by a
minimum No. 8 AWG (8.4 mm²) solid copper conductor attached
to the wire connector on the grounding lug, inside the equipment
compartment on the equipment box.
2

J-200
• A grounding wire connector is provided on this unit to connect a
minimum No. 8 AWG (8.4 mm²) solid copper conductor between
this unit and any metal equipment, metal enclosures of electrical
equipment, metal water pipe, or conduit within 5 feet (1.5m) of the
unit.
• Never permit any electrical appliance, such as a light, telephone,
radio, television, etc. within 5 feet (1.5m) of a spa unless such
appliances are built-in by the manufacturer.
• Never bring any electrical appliances into or near the spa.
• Never operate any electrical appliances from inside the spa or when
you are wet.
• The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with Article 422.20 of the National Electrical Code/USA,
ANSI/NFPA 70. The disconnecting means must be readily accessible
and visible to the spa occupant but installed at least 5 feet (1.5m),
from the spa.
• The electrical circuit supplied for the hot tub must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC Article
680.42.
4. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Extreme caution must be exercised to prevent diving or jumping
into the spa or slipping and falling, which could result in
unconsciousness, drowning, or serious injury. Remember that wet
surfaces can be very slippery.
• Never stand, walk or sit on the top railing of the spa.
5. !WARNING: RISK OF HYPERTHERMIA (OVER-HEATING)
CAUSING SEVERE INJURY, BURNS, WELTS OR DEATH!
• Water temperature in excess of 104°F (40°C) may be injurious to
your health.
• Refer to Section 3.2 Hyperthermia for specic causes and symptoms
of this condition.
• The water in the spa should never exceed 104°F (40°C). Water
temperatures between 100°F (38°C) and 104°F (40°C) are
considered safe for a healthy adult.
• Lower water temperatures are recommended for young children
(children are especially sensitive to hot water) and when spa use
may exceed 10 minutes.
• The Consumer Products Safety Commission/USA has stated that the
water temperature in a spa should not exceed 104°F (40°C).
• Always test the spa water temperature before entering the spa.
The user should measure the water temperature with an accurate
thermometer since the tolerance of water temperature-regulating
devices may vary as much as +/- 5°F (2°C).
3

J-200
6. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Since excessive water temperatures have a high potential for
causing fetal damage during the early months of pregnancy, if
pregnant or possibly pregnant, consult your physician before using a
spa.
• Pregnant or possibly pregnant women should limit spa water
temperatures to 100°F (38°C).
• Persons suffering from obesity or a medical history of heart disease,
low or high blood pressure, circulatory system problems, diabetes,
infectious diseases or immune deciency syndromes should consult
a physician before using a spa.
• If you experience breathing difculties in association with using or
operating your spa, discontinue use and consult your physician.
• Persons using medication should consult a physician before using
a spa since some medication may induce drowsiness, while other
medication may affect heart rate, blood pressure, and circulation.
• Persons suffering from any condition requiring medical treatment, the
elderly, or infants should consult with a physician before using a spa.
• The use of alcohol, drugs, or medication before or during spa use
may lead to unconsciousness with the possibility of drowning.
7. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Prolonged immersion in a spa may be injurious to your health.
• Observe a reasonable time limit when using the spa. Exposures
at higher temperatures can cause high body temperature (over-
heating). Symptoms may include dizziness, nausea, fainting,
drowsiness, and reduced awareness. These effects could possibly
result in drowning or serious injury.
• Never use a spa immediately following strenuous exercise. Enter
and exit the spa slowly. Wet surfaces can be slippery.
8. !WARNING: TO DECREASE RISK OF INFECTION OR DIS-
EASE!
• To reduce the risk of contracting a waterborne illness (e.g., an infec-
tion, bacteria or virus) and/or respiratory ailments , maintain water
chemistry within the parameters listed on the inside cover of this
manual and consult with a licensed engineer regarding proper venti-
lation if installed indoors or in an enclosed area.
• People with infectious diseases should not use a spa to avoid water
contamination, which could result in spreading infections to others.
• Always shower before and after using your spa. Maintain water
chemistry in accordance with manufacturer’s instructions. Failure to
do so may result in contracting a waterborne illness (e.g., an infec-
tion, bacteria or virus).
4

J-200
9. !WARNING: In addition to maintenance of lters and water
chemistry, proper ventilation is recommended to reduce the risk of
contracting a waterborne illness (e.g., an infection, bacteria or virus)
and/or respiratory ailments that could be present in the air or water.
Consult a licensed architect or building contractor to determine your
specic needs if installing your hot tub indoors.
10. CAUTION: TO DECREASE RISK OF PRODUCT DAMAGE.
• Maintain water chemistry in accordance with manufacturer’s
instructions.
• Proper chemical maintenance of spa water is necessary to maintain
safe water and prevent possible damage to spa components.
11. !WARNING: RISK OF SEVERE INJURY OR DEATH! The
appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
12. NOTE: This spa is not intended nor designed to be used in a com-
mercial or public application. The spa buyer shall determine whether
there are any code restrictions on the use or installation of this spa
since local code requirements vary from one locality to another.
Hot Tub Safety Literature
To ensure you have a safe and enjoyable hot tub experience, learn
all you can about hot tub safety and emergency procedures.
The Pool & Hot Tub Alliance has a great source of safety literature.
• Go to http://phta.org
• Conduct your own search on the internet
• Write to the following address:
Pool & Hot Tub Alliance
2111 Eisenhower Avenue
Alexandria VA 22314
703.838.0083
5

J-200
6530-460 Rev A (12/18)
FOR CALIFORNIA RESIDENTS ONLY
NUR FÜR EINWOHNER KALIFORNIENS
POUR LES RÉSIDENTS DE LA CALIFORNIE SEULEMENT
PARA RESIDENTES DE CALIFORNIA ÚNICAMENTE
WARNING: Drilling, sawing, sanding or machining wood products
can expose you to wood dust, a substance known to the State of
California to cause cancer. Avoid inhaling wood dust or use a dust
mask or other safeguards for personal protection. For more infor-
mation go to www.p65Warnings.ca.gov/wood
ACHTUNG: Das Bohren, Sägen, Schleifen oder Zerspanen von
Holzprodukten kann Stäube freisetzen. Diese Substanz gilt im
US-Bundesstaat Kalifornien als krebserregend. Möglichst keinen
Holzstaub einatmen bzw. eine Staubmaske oder anderweitige
persönliche Schutzmaßnahmen einsetzen. Weitere Informationen
finden Sie auf www.P65Warnings.ca.gov/wood
ADVERTENCIA: Perforar, cortar, lijar o usar máquinas con pro-
ductos de madera le puede exponer a polvo de madera, una sub-
stancia reconocida por el Estado de California como causante de
cáncer. Evite inhalar polvo de madera o utilice una máscara antipol-
vo u otros resguardos para protección personal. Para más infor-
mación, visite www.P65Warnings.ca.gov/wood
AVERTISSEMENT: Le forage, le sciage, le ponçage ou l'usinage
des produits du bois peuvent vous exposer à la poussière de bois,
une substance connue dans l'État de Californie pour causer le
cancer. Éviter d'inhaler la poussière de bois ou utiliser un masque
antipoussières ou d'autres mesures de protection personnelle. Pour
de plus amples renseignements, consulter le site www.P65Warn-
ings.ca.gov/wood
FOR CALIFORNIA RESIDENTS ONLY
NUR FÜR EINWOHNER KALIFORNIENS
POUR LES RÉSIDENTS DE LA CALIFORNIE SEULEMENT
PARA RESIDENTES DE CALIFORNIA ÚNICAMENTE
WARNING: Cancer and Reproductive Harm
www.p65Warnings.ca.gov
ACHTUNG: Krebserregend und mit fortpflanzungsschä-
digender Wirkung-www.p65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo
www.p65Warnings.ca.gov
AVERTISSEMENT: Cancer et danger pour la reproduction
www.p65Warnings.ca.gov
6530-464 Rev A (12/18)
6

J-200
3.1 Entrapment Risk
The Consumer Products Safety Commission/USA has reported that
users of pools and spas have become entrapped (stuck) to drain and/or
suction ttings causing death, drowning, or serious injury (see diagram
below). This spa was manufactured to meet the standards and specica-
tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”
(VGB Safety Act). Entrapment risk can be minimized if proper precau-
tions are taken.
DANGER: RISK OF PERSONAL INJURY OR DEATH!
Never operate the spa if a suction tting, suction cover,
lter, lter lid or skimmer assembly are broken, damaged or
missing.
!
Note: Suction covers must be replaced every 7 years.
1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Hair entrapment: May occur if hair is entangled, knotted or snagged
in a drain suction or skimmer assembly. This has been reported in
persons who when submerge themselves underwater, allowing hair
to come close and/or within the reach of the suction fittings, suction
covers or skimmer assembly.
• Keep hair away from suction ttings, suction covers, lter, lter lid or
skimmer assembly.
• Children are at risk for hair entrapment if swimming under water.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Limb entrapment: May occur when a limb becomes entrapped,
inserted or sucked into a suction or outlet opening.
• Always keep suction ttings, suction covers, lter, lter lid or skimmer
assembly in place when operating to avoid limb entrapment.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
Filter, Filter
Lid, Skimmer
Assembly,
Floating Weir,
(location and
style vary by
models)
Suction Fittings,
Suction Covers
(locations vary
by models)
7

J-200
3. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Body entrapment: May occur when part of the torso becomes
entrapped, inserted or sucked into a suction or outlet opening.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
4. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Evisceration (disembowelment) entrapment: May occur when the
buttocks becomes entrapped, inserted or sucked into a suction or
outlet opening.
• Never sit on suction ttings, suction covers, lter, lter lid or skimmer
assembly.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
5. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Mechanical entrapment: May occur when jewelry, swimsuit, or
hair accessories become entangled, knotted or snagged in a drain
suction or skimmer assembly.
• Never allow your jewelry, swimsuit, or hair accessories to come close
to the suction ttings, suction covers or skimmer assembly.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
3.2 Hyperthermia
Prolonged immersion in hot water may induce hyperthermia (over-
heating). The use of alcohol or drugs can greatly increase the risk of fatal
hyperthermia in spas. A description of the causes, symptoms, and effects
of hyperthermia are as follows.
Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above the normal body temperature of 98.6°F
(37°C). The symptoms of hyperthermia include drowsiness, lethargy
(fatigue), and an increase in the internal temperature of the body. The
effects of hyperthermia include:
• Unawareness of impending hazard.
• Failure to perceive heat.
• Failure to recognize the need to exit spa.
• Physical inability to exit spa.
• Fetal damage in pregnant women; and
• Unconsciousness and DANGER of drowning.
A Warning Sign is provided in your warranty packet. Please install at
a location near your spa, where it is visible to users of the spa. For
additional or replacement Warning Signs please contact your local
Jacuzzi dealer and reference item number #6530-082.
8

J-200
3.3 Important Safety Instructions
When using this electrical equipment, basic safety precautions should
always be followed, including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. A green colored terminal or a terminal marked G, Gr, Ground,
Grounding or the symbol* is located inside the supply terminal box
or compartment. To reduce the risk of electric shock, this terminal
must be connected to the grounding means provided in the electric
supply service panel with a continuous copper wire equivalent in size
to the circuit conductors that supply this equipment (*IEC Publication
417, Symbol 5019).
3. At least two lugs marked “Bonding Lugs” are provided on the
external surface or on the inside of the supply terminal box/
compartment. To reduce the risk of electric shock, connect the local
common bonding grid in the area of the spa to these terminals with
an insulated or bare copper conductor not smaller than No. 6 AWG
(10 mm²).
4. All eld installed metal components such as rails, ladders, drains or
other similar hardware within 10 feet (3m) of the spa shall be bonded
to the equipment grounding buss with copper conductors not smaller
than No. 6 AWG (10 mm²).
5. SAVE THESE INSTRUCTIONS.
3.4 PRECAUTIONS-Important Chemical Safety
Do not use this device with bromide products.
3.5 PRECAUTIONS FOR USE OF PRODUCTS CONTAINING
SODIUM BROMIDE
• Do not use any Product containing Sodium Bromide with an
electrolysis device (for example, a chlorine generator).
• Do not use any Product containing Sodium Bromide with ozonation.
• Do not use any Product containing Sodium Bromide with ultraviolet
(UV).
9

J-200
4.0 Choosing A Location
IMPORTANT: Because of the combined weight of the spa, water and
users, it is extremely important that the base upon which the spa rests
be smooth, at, level and capable of uniformly supporting this weight,
without shifting or settling, for the entire time the spa is in place. Visit
www.Jacuzzi.com for weight information. If the spa is placed on a
surface which does not meet these requirements, damage to the skirt
and/or the spa shell may result. Damage caused by improper support
is not covered under warranty. It is the responsibility of the spa owner
to assure the integrity of the support at all times. We recommend a
poured, reinforced concrete slab with a minimum thickness of 4 inches
(10 cm). Wood decking is also acceptable provided it is constructed so
that it meets the requirements outlined above.
WARNING: For spas that are to rest on balconies,
roofs or other platforms not specically tied into main
structural support, consult a professional Structural
Engineer with experience in this type of application.
!
WARNING: Proper drainage is required. The installation
must not allow the spa equipment bay to become ooded
or wetted (by external water). It is your responsibility, and
the responsibility of any installation contractor you hire, to
make sure that all applicable codes and/or local construction
requirements are met. If in doubt, refer to the building authority
responsible for approving the proposed installation site.
!
The spa must be installed in such a manner as to provide drainage away
from it. Placing the spa in a depression without provisions for proper
drainage could allow rain, overow, leaks from spa plumbing, and other
casual water to ood the equipment and create a wet condition in which
it would sit in. For spas which will be installed below grade or recessed
into a oor or deck, install so as to permit access to the equipment, either
from above or below, for servicing. Make certain that there are no
obstructions which would prevent removal of all side cabinet side panels
and access to the jet components, especially on the side with the
equipment bay.
CAUTION: If the spa is indoors or located in an enclosed area,
proper ventilation should be discussed with an Engineer or authority
competent enough to understand the necessary provisions needed
to vent moist or heated air and air associated with chemical odors
outdoors. When the spa is in use considerable amounts of
moisture will escape potentially causing mold and mildew. This
can cause health risk. Over time, this can damage certain surfaces,
surroundings, and equipment.
!
10

J-200
4.1 Outdoor Location
In selecting the ideal outdoor location for your spa, we suggest that you
take into consideration:
• The proximity to changing area and shelter (especially in colder
weather).
• The pathway to and from your spa (this should be free of debris so
that dirt and leaves are not easily tracked into the spa).
• The closeness to trees and shrubbery (remember that leaves and
birds could create extra work in keeping the spa clean).
• A sheltered environment (less wind and weather exposure can result
in lowered operation and maintenance costs).
• The overall enhancement of your environment. It is preferable not to
place the spa under an unguttered roof overhang since run-off water
will shorten the life expectancy of the spa cover.
• For spas that are to rest on balconies, roofs or other platforms not
specically tied into main structural support, consult a professional
Structural Engineer with experience in this type of application.
• In the unlikely event that you should ever need to access or gain
entry to any portion of the spa for servicing, it is highly recommended
that you plan your outdoor installation to provide full access to the
entire spa. Please take this into consideration when placing the spa
in a deck or enclosed by a surrounding.
• Consider locating your spa away from any reective surface or glass
to prevent any damage to the synthetic skirt.
• Do not shim the spa. To ensure proper support the spa must sit at
on the intended foundation.
4.2 Indoor Location
For indoor installations many factors need to be considered before
installing a spa indoors:
WARNING: In addition to maintenance of lters and water
chemistry, proper ventilation is recommended to reduce the
risk of contracting a waterborne illness (e.g., an infection,
bacteria or virus) and/or respiratory ailments that could be
present in the air or water. Consult a licensed architect
or building contractor to determine your specic needs if
installing your hot tub indoors.
!
• Proper Foundation: Consult a Structural Engineer when
considering a foundation that will adequately support the spa
the entire time it is in place. Proper support is critical especially
if the spa is to rest on a second story or higher. For spas that are
to rest on balconies, roofs or other platforms not specically tied
into the main structural support, you should consult a professional
Structural Engineer with experience in this type of application.
11

J-200
• Proper Drainage: It is extremely important to have in place
measures to sufciently handle excessive water spillage. Be
sure the ooring in which the spa rests on has adequate drainage
and can handle the entire contents of the spa. Be sure to make
provisions for ceilings and other structures that may be below
the spa’s installation. Areas around your spa can become wet or
moist so all ooring and subsequent furniture, walls and adjacent
structures should be able to withstand or resist water and moisture.
• Proper Ventilation: Proper ventilation should be discussed with
an Engineer or authority competent enough to understand the
necessary provisions needed to vent moist or heated air and air
associated with chemical odors outdoors. When the spa is in use
considerable amounts of moisture will escape, potentially causing
mold and mildew over time which can damage certain surfaces and/
or surroundings.
• Sufcient Access: In the unlikely event that you should ever need
to access or gain entry to any portion of the spa for servicing, it is
highly recommended that you plan your indoor installation to provide
full access to the entire spa.
• Warranty: Damage caused by not following these guidelines or any
improper installation not in accordance to local codes or authorities is
not covered under the spas warranty. Please consult your local state
or city building ordinances.
• Do not shim the spa. To ensure proper support the spa must sit at
on the intended foundation.
12

J-200
5.0 General Electrical Safety Instructions
Your new Jacuzzi spa is equipped with a “state-of-the-art”
equipment system. It contains the most advanced safety
and self-protective equipment in the industry.
Nonetheless, this spa must be installed properly to insure
dependable usage. Please contact your dealer or local
building department should you have any questions regarding your
installation.
Proper grounding is extremely important. Jacuzzi spas are equipped with
a current collector system. A pressure wire connector is provided on the
surface of the control box, located outside the equipment door (page
17) to permit connection of a bonding wire between this point and any
ground metal equipment, metal water pipe or conduit within 5 feet (1.5m)
of the spa, or copper clad grounding rod buried within 5 feet (1.5m) of the
spa. Bonding wire must be at least No. 8 AWG (8.4 mm²) solid copper
wire. This is a most important safety assurance feature. Before installing
this spa, check with the local building department to insure installation
conforms to local building codes.
120/240 Volt Convertible Models
A spa connected to a 120 VAC electrical service must be located close
enough to a grounded, grounding-type electrical outlet so that the
included 10-foot (3m) power cord can be plugged directly into it. DO NOT
USE AN EXTENSION CORD as this could cause damage to the spa’s
equipment due to insufcient voltage. The power supplied to this spa
must be a dedicated circuit with no other appliances or lights sharing the
power provided by the circuit.
13

J-200
6.0 Power Requirements
Jacuzzi spas are designed to provide optimum performance and exibility
of use when connected to the maximum electrical service listed below.
Minor circuit board modications can be performed to allow your new spa
to accept an electrical service other than the factory operation setting. The
electrical wiring of this spa must meet the requirements of the National
Electrical Code/USA (NEC) and/or any applicable state or local codes.
Note: Refer to pages 56-59 for circuit board conguration details or
contact your authorized Jacuzzi dealer.
North American J-215/J-225 Convertible Models (60 Hz)
120V/15A* 240V/30A* 240V/40A**
Circuit Breaker: 15A, 1-Pole 30A, 2-Pole 40A, 2-Pole
Number of Wires: 3 (15A GFCI
Cord US
Only*)
4 (Hard Wire
Only) 4 (Hard Wire Only)
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 12A 20A 31A
*In 15A/30A conguration, the heater will not operate while the jets
pump is running in high speed. The factory setting is 120V/15A.
** In 40A conguration, the heater will operate while the jets pump is
running in high speed.
**CAUTION: (For a 4-wire 240 VAC Heater Operation): Make
certain wires are connected exactly as shown in Figure D (page 18)
before applying power. Failure to do so will result in damage to the
circuit board and/or related components and void the manufacturer's
warranty.
North American J-235/J-245/J-275/J-285 Models (60 Hz)
240V/40A* 240V/50A** 240V/60A***
Circuit Breaker (2-Pole): 40A 50A 60A
Number of Wires: 3 3 3
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 26A 36A 45A
*In 40A conguration, the heater will not operate while either jets
pump is running in high speed. Note: pump 2 runs only in high
speed.
** In 50A conguration, the heater will not operate while both jets
pumps are running in high speed. This is the factory setting.
Note: pump 2 runs only in high speed.
*** In 60A conguration the heater will operate while both jets pumps
are running in high speed.
14

J-200
7.0 Electrical Wiring Instructions
IMPORTANT NOTICE: The electrical wiring of this spa must
meet the requirements of the National Electrical Code/USA
(NEC) and/or any applicable state or local codes. The
electrical circuit must be installed by a qualied electrician
and approved by a local building/electrical inspection authority.
1. Convertible 120/240V Power Models:
• !DANGER: TO DECREASE THE RISK OF SHOCK,
PRODUCT DAMAGE OR ELECTRICAL FIRE.
120V “Plug-in” Operation: This spa must operate on the supplied
120V GFCI cord at its original length or must be hard-wired for longer
runs. NEVER USE AN EXTENSION CORD FOR ANY REASON!
• Convertible 120/240V heater Operation: The included 120V
GFCI cord must be discarded for 240V heater operation. This spa
must be hard wired. Supplying power to either conguration above
which is not in accordance with these instructions will void both the
independent testing agency listing and the manufacturer’s warranty.
2. Dedicated 230V-240V models must be permanently connected
(hard-wired) to the power supply. No plug-in connections or
extension cords are to be used in conjunction with the operation
of this spa. Supplying power to the spa which is not in accordance
with these instructions will void both the independent testing agency
listing and the manufacturer’s warranty.
3. The power supplied to this spa must be a dedicated circuit with no
other appliances or lights sharing the power provided by the circuit.
4. To determine the current, voltage and wire size required, refer to
Section 6.0 “Power Requirements” (page 14).
• Wire size must be appropriate per NEC/USA and/or local codes.
• The spa controller’s terminal block will accept a maximum wire size
of 6 AWG (10 mm²).
5. The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with Article 422.20 of the National Electrical Code/USA,
ANSI/NFPA 70. The disconnecting means must be readily accessible
to the spa’s occupant but installed at least 5 feet (1.5m) from spa
water.
6. The electrical circuit supplied for the spa must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC/USA Article
680.42.
7. The electrical supply for this product must include a suitably rated
isolating switch and circuit breaker to comply with local electrical
regulations. This RCD/GFCI circuit breaker must be installed at the
power supply in the house electrical box.
15

J-200
8. To gain access to the spa’s power terminal block (Figure 1):
• Remove the corner panels. Grab the top of the panel and pull
forward to unsnap it from the clips. Then lift the panel up to remove.
• To remove the front panel. Start at one end and pull the panel
forward to unsnap it from the retaining clips, at the top. Work your
way along the entire length of the panel.
• Once the panel it unclipped, tilt it slightly forward and lift the panel up
to remove. Be careful with the exterior light cord. Disconnect it before
fully removing the panel.
• Remove the insulation panel and place it in a safe location.
9. Then remove the control box door screws and door. Feed power
cable to control box (Figure B), then install it through the large
opening provided in the bottom side of the box.
10. Connect wires to the terminal block TB1 (Figure C, page 17).
TIGHTEN SECURELY! All wires must be hooked up securely or
damage could result.
11. Re-install control box door and screws, insulation panel (if equipped),
secure the insulation blanket (if equipped), and reinstall the cabinet
side panels.
Figure 1
16
