Jacuzzi JPV200 User manual

Jacuzzi
JPV200
PROFESSIONAL GRADE POOL AND SPA VACUUM
Operating Instructions
®

2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNINGS AND USAGE INFORMATION
WARNINGS
1. Read carefully and understand all safety warnings before using this appliance.
2. Do not attempt to operate if the cleaner or charger appear to be damaged in any way.
3. All cautions and warnings on the equipment should be noted.
4. Never allow children to operate this product. This is NOT a toy. Children should be
supervised to ensure they do not play with this product.
5. Keep the cleaner and its accessories out of reach of children.
6. This cleaner is not intended for use by persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance by a person responsible
for their safety.
7. Charge indoor only. Do not use or store the charger outdoors. Charge your
cleaner in a clean, dry place and only with the charger provided. Do not use a charger
supplied with any other appliance.
8. The warnings, cautions, and instruction discussed in this instruction manual cannot
cover all possible conditions or situations that could occur. It must be understood,
the operator should always exercise intensive caution and common sense when
utilizing the cleaner.
9. Risk of electric shock. Do not expose to liquid, vapor or rain. Store cleaner in a clean
dry place. Do not store in direct sunlight or expose to extreme temperatures.
10. Do not plug or unplug charger into a power source or the appliance with wet hands.
11. Do not operate this cleaner in the presence of ammable or combustible liquids.
12. Never service the cleaner while the unit is on or connected to the charger.
13. Installation work and electrical wiring must be done by qualied person(s) in
accordance with all applicable codes and standards, including re-rated construction.
14. Use only the charger supplied with the cleaner. Never carry the charger by its cord
or disconnect it from an outlet by pulling on the cord.
15. For pluggable equipment, the socket-outlet shall be installed near the equipment and
shall be easily accessible.
16. Keep proper footing and balance at all times when using the cleaner. Do not overreach.
17. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or
sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning.
18. This cleaner contains rechargeable batteries. Do not incinerate the battery as it will
explode at high temperatures. Always dispose of batteries in accordance with local law.
19. Leaks from a battery may occur under extreme conditions. If battery liquid gets on
the skin, wash immediately with water. If it gets in your eyes, immediately ush your
eyes with a mild solution of baking soda and water, and seek medical attention.
20. Keep hair, loose tting clothing and all body parts away from openings and moving
parts of this cleaner.
DANGER!
DANGER!
WARNING!
WARNING!
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW
THESE INSTRUCTIONS. When using electrical
products, read, understand and follow all the
instructions stated in this manual.
DO NOT ALLOW WATER OR OTHER
HIGHLY CONDUCTIVE FLUIDS TO
CONTACT THE CHARGER OR CHARGING
JACK PRIOR TO OR WHILE CHARGING
THE APPLIANCE. Pool water is highly corrosive
and will cause damage to the charger or charging jack
and can cause short-circuit resulting in smoke, re
and/or serious personal injury. Make sure all surfaces
of the charger and charging jack are dry and no water
is present before charging the appliance.
RECHARGE ONLY WITH A CHARGER
MANUFACTURED BY WATER TECH
CERTIFIED FOR USE WITH THIS
PRODUCT. A charger suitable for one type of
battery pack may create a risk of re when used with
another battery pack. DO NOT use an extension
cord or power strip. Use only charger certied by
Water Tech: LC099-2SK.
DROWNING HAZARD. This device produces
suction. Risk of entrapment present. DO NOT use
when bathers are present. Never permit children to
use this product. Never permit persons who cannot
swim to use this product to prevent the chance
of drowning.
WARNING!
This appliance contains batteries that are only
replaceable by skilled persons.

4
3
SAFETY AND USAGE SYMBOLS
The following symbols and meanings are intended to explain the levels of risk associated with this product:
The following symbols and meanings are intended help you operate the product better and safer. Please study them and learn their meanings.
Indicates a hazardous situation, that, if not avoided, may result in minor or moderate injury.
Indicates a potential personal injury hazard. Basic precautions should always be
followed when seeing this symbol.
Indicates by NO MEANS water should touch the indicated part with this symbol.
If not avoided, may result in minor or moderate injury.
Indicates to charge product for the 4 complete hours.
Recycle batteries in accordance to local law.
Dispose any unwanted product in accordance to local law.
SYMBOL SIGNAL MEANING
SYMBOL NAME EXPLANATION
WARNING!
DANGER!
CAUTION!
SAFETY ALERT
DO NOT GET WET
CHARGE FOR
4 FULL HOURS
BATTERY
RECYCLE
DISPOSAL
USAGE INFORMATION
21. Use this product only for its intended purpose as described in this manual. Use only Water Tech accessories and lters.
22. This product is not intended for commercial use.
23. If the equipment is not in use for long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.
24. Never leave your cleaner in water when it is “OFF” or when it has run out of power.
25. Do not use your cleaner for pool openings; the cleaner is designed for routine maintenance of your pool or spa.
26. The cleaner is designed for underwater use in swimming pools or spas only. It is not an all purpose vacuum cleaner.
27. Submerge the cleaner in water immediately after turning the unit “ON” to prevent damage to the seal on the motor shaft. Failure to do so
will shorten the life of the water seal and / or void the warranty.
28. Avoid picking up sharp objects as they may damage the lter. Keep all openings on the cleaner free of debris which may reduce water ow.
29. Do not place the cleaner or charger on or near hot surfaces.
30. For best results use the charger in locations where temperatures are between 50˚ F / 10˚C and 100˚ F / 37.7˚ C.
31. For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper conguration for the power outlet.
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
Green indicates battery has been fully charged.
Red indicates battery is accepting a charge.
BLINKING LIGHT

4
1. Vacuum Head
2. Nose Cap
3. Filter Bag
4. Cleaner Body
5. Motor Box
6. Charger
P20X006
P30X002
P30X022XF
P20X003LIV2
LC099-2SK
Model: 25150GL
12
4
6
5
3
C
B
A
A.1 A.2 A.3
PRODUCT BREAKDOWN
Charge time: 4 hours

5
E
D
F
Push for ON / OFF
Submerge immediately after pushing ON.
OPTIONAL - POLE NOT INCLUDED
F. 1
E.1 E.2

6
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable
protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation, If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different than that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Industry Canada Regulatory Information
CAN ICES-3 (B)/NMB-3 (B)
Avis d’Industrie Canada
CAN ICES-3 (B)/NMB-3 (B)
TwoYear Limited Pro-Rated Warranty
Water Tech Corp (“WT”) warrants this product, including supplied accessories against defects in material or workmanship to the original purchaser for the time periods as
set forth above and below. Pursuant to this Limited Warranty WT will, at its option (i) repair the product to the original specications or (ii) replace the product with a new
or refurbished product. In the event of a defect, these are your exclusive remedies. For purposes of this Limited Warranty,“refurbished,” means a product or part that has
been return to its original specications.
The Jacuzzi
© JPV200 Professional Grade Pool & Spa Vacuum, for a period of two (2) years from the original date of purchase of the product, WT will, at its option, repair or
replace with new or refurbished product or parts, any product or parts determined to be defective. After the rst year, the claimant shall pay ½ the MSRP or List Price of the
warranted component.
Accessories. Included accessories, lters or vacuum head are covered by this Limited Warranty for a period of (90) days from the original date of purchase of the product.
Instructions. Please retain the original box and internal packaging materials.To obtain warranty service, you must comply with the following requisite instructions:
(1) Visit Water Tech Corp’s Customer Support Department via the web at www.wtrma.com.You will be guided through the correct process on how to obtain the required
RMA# (Return Merchandise Authorization Number.) All customers must obtain an RMA number before any product will be accepted for warranty service. If you need
additional assistance, please contact us by telephone: [phone]) or email: [e-mail].
(2) Package the unit and the WT battery charger only (if the unit requires a WT charger ) properly and securely in the original box.
(3) Attach your RMA number and Bar-Code you received from the website to the outside of the package. If you could not print the RMA number and bar-code from the
website you must write your RMA number in thick black indeligable marker on two sides of the box.
(4) Send the package by USPS or express courier of choice to: Water Tech Corp, 10 Alvin Court, East Brunswick, New Jersey 08816; (WT suggests you insure the contents
of your package.) WT is not responsible for lost, stolen or damaged property in transit to WT.
Repair/Replacement Warranty.This Limited Warranty shall apply to any repair, replacement part or replacement product for the remainder of the original Limited Warranty
period or for ninety (90) days, whichever is longer. Any parts or products replaced shall become the property of WT.
This Limited Warranty covers only product issues caused by defects in material or workmanship during ordinary consumer use; it does not cover product issues caused by
any other reasons, including but not limited to product issues caused by commercial use, acts of God, misuse, abuse, limitations in technology, or modication of or to any
part of the WT product. This Limited Warranty does not cover WT products sold AS IS or WITH ALL FAULTS or consumables (such as batteries). This Limited Warranty is
invalid if the factory-applied serial number has been altered or removed from the product. This Limited Warranty is valid only in the United States and Canada.
EXPRESS LIMITATION: THIS LIMITED WARRANTY ONLY APPLIES IF THE PRODUCTWAS PURCHASED FROM AN AUTHORIZED WATER TECH DEALER. THIS
WARRANTY IS NOT TRANSFERABLE
LIMITATION ON DAMAGES. WT WILL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF EXPRESS OR IMPLIED
WARRANTY ON THIS PRODUCT.
DURATION OF IMPLIED WARRANTIES. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,ANY IMPLIEDWARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION OF THIS WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or allow limitations or how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you. This Limited Warranty gives you specic legal rights and you may have other rights, which vary from state to state.
Two year limited warranty from original date of purchase with one year full.
After the rst year, the claimant shall pay ½ of the MSRP or List Price of the warranted component.

7
1.Vacuum Head
2. Nose Cap
3. Filter Bag
4. Cleaner Body
5. Motor Box
6. Charger
ChargingYour Cleaner
A
BInserting the Filter Bag
CAttaching the Vacuum Head
D
E
Attaching the Pool Pole
F
Turning the Cleaner ON & OFF
Maintenance
P20X006
P30X002
P30X022XF
P20X003LIV2
LC099-2SK
Please respect recycling regulations and help to protect the environment.
Return non-working electrical equipment to a facility appointed by your municipality that properly recycles electrical and electronic equipment.
Do not dispose them in unsorted waste bins. For items containing removable batteries, remove batteries before disposing of the product.
Environmental Recycling Programs USA
Help protect the environment.
Only use the battery charger supplied with the cleaner.
Cleaning the Filter Bag
• You should remove and clean the Filter Bag following each use (Figure F.1).
• Don’t scrub the bag against itself while rinsing it.
Long Term Storage
• Always clean the Nose Cap and Filter Bag before storing.
• Always store and charge your cleaner in a cool, dry indoor shelter.
• Recharge the cleaner indoors for 4 hours after each month of inactivity.
• Never leave your charger connected to the cleaner for more than 24 hours.
Initial Charge 4 Hours
Recharging (After Complete Discharge) 4 Hours
Maximum charging time should not exceed 24 Hours
End of Life Disposal / Recycling Directive
Specications
Battery Charger Input................................................................100-240V-50-60Hz, 400mA Maximum
Battery Charger Output........................................................................................................8.4V, 1.A
Battery Technical Data...............................................................7.4V, 2200mAh, 16.28Wh, 2S1P Li-Ion
Water Temperature Range.............................................Maximum 96°F, (35°C) Minimum 40°F, (5°C)
Operation Depth.....................................................Maximum 9.8 ft. (3.0 m), Minimum 10 in. (0.25 m)
Charge Temperature................................................Maximum 100°F, (37.7°C) Minimum 50°F, (10°C)

1 2 3 4 5
8
The maintenance free, Lithium Ion battery in your pool cleaner must be properly disposed of in accordance to State and local law. To
conrm if recycling is required; contact your local authority for information.
WARNING!
• Never attempt to disassemble a battery pack.
1. Remove all personal items such as rings, bracelets, necklaces and watches when unwiring a pack from the vacuum unit.
2. A battery can produce a short circuit current high enough to weld a ring (or like item) to metal causing a severe burn.
3. Wear complete eye protection, gloves and protective clothing when removing the battery pack.
4. Take care not to touch wires together or allow them to contact any metal items, which would cause sparking and/or short
circuit the battery.
5. Never smoke or allow a spark or ame in the vicinity of the battery or the cleaner. Batteries can generate gases which could
possibly ignite.
6. Do not expose to re or intense heat as this may result in an explosion.
CAUTION!
•If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag.
7. If acid comes in contact with skin and clothing, wash immediately with plenty of soap and water.
8. If acid comes in contact with eyes, immediately ood eye with running cool water for at least 15 minutes. Get medical
attention immediately.
How to remove the battery
• Recommended tools (not included): Philips screwdriver, wire-cutters, electrical tape.
1. Remove battery chamber cap.
2. Using the Philips screw driver, unfasten the 2 screws on top of the motor-box.
3. Pull the battery out shown in image three.
4. Using the wire-cutters, cut the wires as shown in image four. Do not cut both wires at the same time.
5. Wrap the wires with electrical tape. Dispose according to local law.
END OF LIFE BATTERY DISPOSAL

9
This page has been left blank intentionally.

10

11

Rev.: 11162020
www.Jacuzzipool.com
