Jado Iq 832 144 series User manual

JADO

10˚

7TEST INSTALLED FITTING AND

CONNECTIONS FOR LEAKS

With FAUCET HANDLES in OFF position, turn on

WATER SUPPLIES (1) and check all connections

for leaks.

Operate both handles to flush water lines thoroughly.

Turn diverter to rim wash and bidet spray.

Operate LIFT ROD (2) and fill bidet with water. DRAIN

STOPPER (3) should make a good seal and retain water

in bidet. Adjust stopper height if required by repositioning

LIFT ROD (2) and tightening SET SCREW (4).

Release DRAIN STOPPER (3) and check all drain

connections and "P" trap for leaks. Tighten if

necessary.

SMALL

END

LARGE

END

LARGE

END

VALVE

OUTLET

VALVE

OUTLET

PUTTY

8HELPFUL HINTS FOR CLEANING AND MAINTENANCE

The solid brass product you have just purchased has been designed to give you years of beauty and service. It is

important to bring to your attention proper care and maintenance procedures, which will ensure its lasting beauty.

First and foremost, it is important (as it is with any fine piece of jewelry or furniture) that the product be wiped clean and

dry with a soft damp cloth after every use.

Second, under no circumstances should an abrasive cleaner or combination cleaner/polish be used on JADO products.

The abrasive nature of such products will eventually destroy the finish and void the warranty.

In the event of stubborn blemishes shown on the finish, we recommend use of Windex window cleaner with a soft cloth,

but we do not recommend it be used on an everyday basis.

It is important to note that it is normal to expect signs of usage over time.

Thank you for selecting JADO for your home.

M965581 M965581 M965581 M965581

4INSTALL SUPPLY HOSES

INSTALL SPRAY BODY

Connect small end of SUPPLY HOSES (1) TO "Y" ADAPTER (2)

and larger end to each VALVE OUTLET.

Important: Loop SUPPLY HOSES (1) as illustrated

so they do not kink.

Connect one end of SPRAY HOSE (7) to HOSE ADAPTER (8)

and the other end to shank of SPRAY BODY (3). Tighten hose

connections to make a water tight seal.

JADO

Apply putty to the underside of SPRAY BODY

FLANGE (3) and install SPRAY BODY (3) into

spray hole of Bidet.

From underside of Bidet install RUBBER WASHER (4),

FIBER WASHER (5) and LOCKNUT (6) onto shank of SPRAY

BODY (3). Tighten LOCKNUT (6) to make water tight seal.

Connect water supplies to FAUCET (1) with

1/2" IPS FLEXIBLE SUPPLIES (2) or 3/8"

O.D. BULL-NOSE RISERS (3). Use adjustable

wrench to tighten connections. Do not over

tighten. Be careful not to kink copper supply

when bending. Use tubing cutter to cut to

proper length.

Supply connections are made after bidet

has been installed.

HOT

COLD

FRONT

COLD

FERRULE

COUPLING

NUT

NOTE: FLEXIBLE SUPPLIES OR BULL-NOSE RISERS

MUST BE PURCHASED SEPARATELY.

JADO

WATER SUPPLY CONNECTIONS

TO THE PURCHASER OF JADO BRASS PRODUCTS

Attention installer:

Please leave This Pamphlet for The Owner

POLISHED BRASS AND CUSTOM FINISH WARRANTY: A 1 YEAR LIMITED FINISH WARRANTY from date of purchase is provided to the

first residential owner against defects in materials and workmanship. Due to the ever-changing finish of Patina products, the finish warranty

is excluded. Warranty shall not include problems related to the installation of the product.

MECHANICS

MECHANICAL WARRANTY: A LIFETIME LIMITED WARRANTY is provided to the first residential owner on parts to be free from failure

related to defects in materials and workmanship but not installation.

CONDITIONS TO WARRANTIES

JADO Bathroom & Hardware Manufacturing Corp.places the following conditions on its finish and mechanical warranties to the first residential owner only.

JADO finish and mechanical warranties are limited to products correctly installed and used in a residential environment.

JADO warranties will not assume liability for damage due to abuse, mishandling, incorrect installation, improper maintenance, or deterioration

due to normal use.

JADO will not be liable for labor or other costs relating to the sale, installation, or replacement of their products.

In the event of a defect in any JADO product covered by this warranty, the product must be returned to the dealer where originally purchased

along with proof of purchase.

JADO's obligation under the warranty shall be limited to the repair or exchange of any product which has been determined by JADO to be

defective after appropriate examination.

The state of California has mandated under Proposition #65 that

manufactures of products, including faucets which come into

contact with potable water, must warn the consumer if the product

contains materials listed by the state as a carcinogen or

reproductive toxin. Lead, which is contained in all brass faucets in

limited amounts appears on the State's list.

Preliminary industry tests have indicated that users of faucets

made from brass face no significant danger, however,

California Proposition #65 requires that we provide you with the

following notice:

NOTICE: JADO products conform to industry

requirements of water conservation under the

ASTM / ANSI A112.18.1M-1994 plumbing code.

Lavatory, bidet, wet bar and kitchen faucet sets

have a maximum flow rate of 2.2GPM. Shower

heads, hand showers and body sprays have a

maximum flow rate of 2.5GPM.

Warning: This product contains an element

known to the State of California to cause cancer

of reproductive harm.

JADO BATHROOM AND HARDWARE MFG. CORP.

6615 West Boston

Chandler, AZ 85226

JADO warrants this product to be free from defects in materials or workmanship for as long as the original consumer purchaser

owns their home.

JADO will provide, free of charge, at it’s sole option, replacement part(s) or product (or if no longer available, a comparable

product) to replace those which have proven defective in materials or workmanship.

Proof of purchase (original sales receipt) from the original consumer purchaser must be made available to JADO for all limited

warranty claims. This limited warranty is non transferable. It does not apply in the event of product damage due to the use of other than

genuine JADO replacement parts, installation error, abuse, misuse, or improper care and maintenance (whether performed by

a plumber, contractor, service provider or member of the purchaser’s household). The limited warranty excludes damage due to aggressive

air or water conditions, or harsh or abrasive cleaners and/or materials. This limited warranty excludes all industrial, commercial and business

usage, whose purchasers are hereby extended a two year limited warranty (with the exception of solenoid valves and other electronic

components which carry a one year limited warranty) applying to all other terms of this limited warranty except duration. This limited warranty

does not cover labor charges incurred and/or damages sustained in installation, repair or replacement, nor incidental or consequential

damages, all of which are expressly disclaimed. This limited warranty is applicable only to JADO faucets manufactured after June 1, 1996

and installed in the United States and/or Canada.

This limited warranty gives the original consumer purchaser of an JADO faucet specific legal rights which may vary from state to

state or from province to province. This limited warranty does not cover any liability for consequential or incidental damages, all of which

are hereby expressly disclaimed, or the extension beyond the duration of this limited warranty of any implied limited warranties, including

those of merchantability or fitness for an intended purpose. In some states or provinces the exclusion or limitation of incidental or consequential

damages is not allowed, so those exclusions may not apply to you.

JADO Bathroom & Hardware Manufacturing Corp. provides the following warranties only to the first residential owner of our products.

FINISHES

FAUCET LIFETIME FUNCTION AND FINISH LIMITED WARRANTY

NOTE: Diverter valve is not a positive shut-off to rim wash.

Installation Instructions

To ensure that your installation proceeds smoothly--please

read these instructions carefully before you begin.

©JADO USA 2005

Products Luxury Faucets and Accessories

JADO USA

6615 West Boston

Chandler, AZ 85226

Phone:(8OO) 227-2734

Fax: (8OO) 552-JADO(5236)

www.jadousa.com

Three Hole Bidet Set

with Vacuum Breaker

1Turn off hot and cold water

supplies before beginning.

CAUTION

ROUGHING-IN

DIMENSIONS

FRONT

INSTALL VALVE BODIES AND TRANSFER VALVE

INSTALL TRANSFER VALVE

Apply sealant or Teflon tape to threads of SPRAY ELL (12) and install

into TRANSFER VALVE (13). Note: Arrow on SPRAY ELL (1) points

down, see illustration.

Install "Y" HOSE ADAPTER (14) with SEAL (15) to bottom nipple of

TRANSFER VALVE (13) and tighten to make a water tight seal.

Install LOWER CONE SEAL (16) onto TRANSFER VALVE (13) and insert

TRANSFER VALVE (13) from under side of Bidet into the proper diverter hole.

Install UPPER CONE SEAL (17), FRICTION WASHER (18) and

MOUNTING NUT (19) onto TRANSFER VALVE (13).

Tighten MOUNTING NUT (19) to secure the TRANSFER VALVE (13)

and make a water tight seal.

Thread TRANSFER VALVE ESCUTCHEON (20) onto MOUNTING

NUT (19) until snug against bidet ledge.

COLD

HOT

BIDET

LEDGE

MAX 7"

MAX 2"

11"

2-1/8" DIA.

SPRAY

1-1/8 D.

2-7/16" D.

MAX 13"

DIVERTER

AND VACUUM

BREAKER

LIFT ROD

BIDET

CONNECTIONS ARE FOR1/2" IPS

FLEXIBLE SUPPLIES or 3/8" O.D.

BULL-NOSE RISERS

Plumbers' Putty or Caulking

Adjustable Wrench

Phillips Screwdriver

Channel Locks

TOOLS REQUIRED

Tubing Cutter Regular Screwdriver

Basin Wrench

APPLY SEALANT

OR TEFLON TAPE

VALVE

STEM

Remove LIFT ROD NUT (1), METAL WASHER (2) and

RUBBER SEAL WASHER (3) from LIFT ROD GUIDE (4).

Drop LIFT ROD GUIDE (4) into pop-up hole of bidet.

From below install RUBBER SEAL WASHER (3), METAL

WASHER (2) and secure guide assembly with LIFT ROD NUT (1).

LIFT ROD GUIDE INSTALLATION

4" - 6" 4" - 6"

1-1/4" O.D.

APPLY SEALANT

OR TEFLON TAPE

A FOAM SEAL (1) is installed on underside of FLANGE (2). (Plumbers

Putty may be used in place of FOAM SEAL (1) if desired.)

Apply sealant or Teflon tape to threads of TAILPIECE (10) and

thread into DRAIN BODY (7) making a water tight seal.

Drop FLANGE (2) into LAVATORY DRAIN (3). From below, assemble

RUBBER GASKET (4), PLASTIC WASHER (5) and LOCK NUT (6) onto

DRAIN FLANGE (2). Do not tighten fully.

INSTALL POP-UP DRAIN

FIG. 3a

FIG. 3b

FIG. 3c

FIG. 3a

FIG. 3b

Adjust STOPPER (13) height by repositioning POP-UP ROD (16) in SWIVEL (15)

and tightening SET SCREW (18).

Assemble POP-UP SWIVEL (15) to PIVOT ROD (11) but do not tighten.

Drop POP-UP ROD (16) through other hole in POP-UP SWIVEL (15) and

tighten SET SCREW (17)

Assemble PIVOT ROD (11), and PIVOT NUT (12) as shown. Install CONCAVE

WASHER (19) into PIVOT ROD OPENING (9) if not preinstalled. Hand tighten

PIVOT NUT (12). Drop STOPPER (13) into drain.

(To vandal proof drain, rotate STOPPER (13) so PIVOT ROD (11) goes

through EYE (14) of STOPPER (13). Make connection to "P" TRAP.

Inspect inside DRAIN BODY (7) that SEAL (8) is installed. Thread

DRAIN BODY (7) tight against FLANGE (2) to make a water tight seal.

1517

The PIVOT ROD OPENING (9) in DRAIN BODY (7) should face the rear

of the lavatory. Tighten LOCK NUT (6) on FLANGE (2) to make a water

tight connection with channel locks. Do not over tighten.

5INSTALL DIVERTER HANDLE

DIVERTER

Install DIVERTER HANDLE ASSEMBLY (1)

onto VALVE STEM (2) of DIVERTER.

Secure with DIVERTER HANDLE

SCREW (3). Thread HANDLE CAP

(4) onto DIVERTER HANDLE (1).

Teflon Tape

Product Numbers

832/144/...

IQ™

Insert VALVE BODY (3) through mounting hole from underside

of bidet or mounting surface.

Note: Maximum mounting thickness is 1-1/4".

Install O-RING (9) into groove in FLANGE (4).

Thread FLANGE (4) onto VALVE BODY (3) until tight against

STOP WASHER (10).

Align VALVE BODY (3) as shown and from below tighten

LOCKNUT (5) to secure the VALVE BODY (3) to the

mounting surface.

Install O-RING (1) into under side of HANDLE BASE (2). Turn

VALVES to off position. Align HANDLES (1) as shown or as

desired. Thread HANDLE BASE (2) until tightly seated against

FLANGE (4).

Unpack valve assemblies and remove HANDLE (1) by unthreading

HANDLE BASE (2) from VALVE BODIES (3). Unthread FLANGES (4)

from VALVE BODIES (3).

Thread LOCKNUT (5) to bottom of VALVE BODY (3). Make sure

SPACER (6), BRASS WASHER (7) and RUBBER WASHER (8) are

installed in that order.

CROSS

HANDLE

1-1/8" D.

(28mm)

2-3/8" D.

(60mm)

JADO 1-1/4" MAX.

(32mm)

JADO
