Jamfox Earbits WS-T2 User manual

Jamfox® Earbits WS-T2
True Wireless Bluetooth Earbuds + charging Pod
SIMULATION THEORY LLC
JAMFOX

2
USER MANUAL
JAMFOX
Jamfox®
Congratulations, and thank you for choosing Jamfox Earbits.
This manual will help you operate your wireless stereo earbuds. We recommend that you
familiarize yourself with Bluetooth functionality of your mobile phone or other devices before
using the earbuds.
Enjoy your time with your product.
Safety rules:
1. Please follow the rules described in this manual closely to ensure your safety. Before
using these earbuds, we strongly encourage you to read through this user manual.
2. Do not modify, repair or dismantle these earbuds or charging case. Doing so many result
in fires, electric shocks, complete breakdown of the product and void the warranty.
3. Do not use any diluents or volatile liquid to clean the product.
4. Do not use the product in a hazardous Location.

JAMFOX
USER MANUAL
3
Jamfox®
Accessories

4
USER MANUAL
JAMFOX
Jamfox®
Graphical Representation
1. Touch control button
2. Microphone and LED
indicator
3. Ear Tips
4. Charging case
5. Charging case LED
indicator
6. Micro-USB Charging
Port
7. Earbuds charging status
LED indicator
Fit
In order to get best audio performance, try every ear tips (Small, medium and large) to achieve
the correct seal for your ear. This will give optimal fit and stability.

JAMFOX
USER MANUAL
5
Jamfox®
Charging
The earbuds and charging capsule must be fully charged before first time to use.
Note:
1. The LED indicator of the earbuds will flash blue slowly during normal operation.
2. The LED indicator of the earbuds will flash red quickly to remind you the battery is low.

6
USER MANUAL
JAMFOX
Jamfox®
Single headset operation
Power on / Power off
Manual Power on: Press the touch control button for 2 seconds, the LED light will flash
blue, you will hear “power on” prompt.
Auto Power on: Open the charging capsule. The LED indicator of the earbuds will flash,
you will hear “power on” prompt.
Manual Power off: Press and hold the touch control button for 6 seconds, the LED
indicator will first flash red and you will hear “power off” prompt.
Auto Power off: Cover the earbud with the charging capsule, the LED indicator of the earbud will
turn red and begin charging.
Pairing: first time to use
Mono pairing
Manual Pairing: Master earbuds (L) pair as single/Slave earbuds (R) pair as single:
1) Press the touch control button around 2 seconds, the earbud will power on
with LED indicator flash blue
2) Double tap the touch control button, the LED indicator will turn to flash red
and blue alternately and ready for connecting.
2
2
1

JAMFOX
USER MANUAL
7
Jamfox®
Turn on the Bluetooth of the device and find the pairing ID “Jamfox-L/Jamfox-R”, click it
to connect, the LED indicator of the Master/Slave will flash once/twice every 5 seconds,
the earbud is connected with the Bluetooth device successfully.
Automatic Pairing:
Master earbuds (L) pair as single/Slave earbuds (R) pair as single:
1) Put one earbud into the charging capsule, cover the cap for two seconds and
open it, the earbud will power on automatically.
2) After 10 seconds, the LED on earbud will change to flash red and blue
alternately, entering into the pairing mode. Turn on the Bluetooth of the phone
and find the pairing ID “Jamfox-L/Jamfox-R”, click it to connect, the LED
indicator of the earbud will flash once/twice every 5 seconds, the earbud is
connected with the Bluetooth device successfully.
3) Second time or later use: Press the touch control button around 2 seconds to
power on the earbud. It will automatically reconnect with the Bluetooth device.
3

8
USER MANUAL
JAMFOX
Jamfox®
Once the headset is successfully paired and connected with your mobile phone, you can
use it to make a call and listen to music.
Answer a call/End a call: Tap the touch control button once to answer the incoming
call. Tap the touch control button once to end a call.
Reject a call: Double-tap the touch control button to reject the incoming call.
Music: When the earbud is connected with the Bluetooth device, single click the touch
control button to play music, single click it again to pause the music.
4
2
5
2
6
6
2

JAMFOX
USER MANUAL
9
Jamfox®
Stereo Headset Operation
Power on
Manual power on: press the touch control button for about 2 seconds, the LED
indicator will flash blue and you will hear “power on” prompt.
Auto power on: open the charging capsule, both earbuds will power on automatically
and both LED indicators of the earbuds will flash blue.
Power off
1. Manual power off
Press and hold the touch control button around 6 seconds, the LED indicator will first
flash red and you will hear a “power off” prompt and the earbud was turned off.
Power off one earbud and the other one will power off automatically.
2. Auto power off
Put both earbuds into the charging capsule and cover the cap, the earbuds will power
off and begin charging.
Pairing: first time to use
Manual Pairing:
Long press the touch control buttons of both earbuds around 8 seconds until the LED
indicator of the earbuds flash blue and red alternately, release the buttons and put
the earbuds together to pairing each other, LED indicators of both earbuds will flash
blue once and the Master will turn to flash red and blue alternately again, the Slave
will turn to flash blue twice every 5 seconds, now both earbuds are paired together
successfully and they are ready to connect with the Bluetooth devices.
1
2
3

10
USER MANUAL
JAMFOX
Jamfox®
Turn on the Bluetooth of the device and find the pairing ID “Jamfox-L”, click to
connect, the LED indicator of the Master will turn to flash blue once every 5 seconds
and the Slave will keep flashing blue twice every 5 seconds, the earbuds are now
connected with the Bluetooth device successfully.
Auto Pairing:
1) Put both earbuds into the charging capsule, cover the cap and open it later, both
earbuds will power on automatically and try to connect the Bluetooth phone / device.
2) The LED indicators of the Master will turn to flash red and blue alternately again,
the Slave will turn to flash blue twice every 5 seconds, now both earbuds are paired
together successfully, and they are ready for connecting with the Bluetooth devices.

JAMFOX
USER MANUAL
11
Jamfox®
Turn on the Bluetooth of the device and find the pairing ID “Jamfox-L”, click it to
connect, the LED indicator of the Master will flash blue once every 5 seconds and the
Slave will flash blue twice every 5 seconds, the earbuds is connected with the
Bluetooth device successfully.
Second time or later use: put both earbuds into the charging capsule, cover the cap
and open it later, both earbuds will power on automatically and connect with each
other, and they will auto connect with the Bluetooth device which has previous
connect record. In pairing mode, stereo earbuds will power off automatically if it can't
connect with Bluetooth device in 10 minutes.
Calling
Both earbuds can hear the voice when calling and both button can works.
Answer a call /End a call: Tap the touch control button once to answer the incoming
call. Tap the touch control button once to end a call.
Reject a call: Double-tap the touch control button to reject the incoming call.
Play music
When the earbuds is connected with the Bluetooth device, tap the touch control
button once to play music, tap it again to pause the music.
5
4

12
USER MANUAL
JAMFOX
Jamfox®
Volume+/Volume-
When the earbuds are playing music, double tap the touch control button of the
Master to increase the volume and double tap the touch control button of the Slave
to decrease the volume.
Next song
When the earbuds is playing with music, press the touch control button of the Master
2 seconds to the Next song, please release the touch control button once you heard
the “Beep” sound, or press another 4 seconds will power it off.
Previous song
When the earbuds is playing with music, press the touch control button of the Slave 2
seconds to the Previous song, please release the touch control button once you heard
the “Beep” sound, or press another 4 seconds will power it off.
Active Siri
1. Double press the touch control button and hold press 1 second to active Siri
function. In TWS mode only Left channel can active Siri function.
2. Siri function can also be activated in single earbuds.
Low power alarm
The LED indicator of the earbud will flash red quickly and a prompt of “Low battery, please
charge” will remind you to recharge the earbud in a short time, or the earbud will shut down
automatically after several minutes if you ignored the prompt.
Clear the pairing list (reset factory setting)
1) In Power off status, press and hold the touch control button of the earphone for
around 8 seconds until the LED indicator flashing red and blue alternately (or take the
earphone out of the charging capsule and wait for the LED indicator of the earphone
flashing red and blue alternately.)
8
9
6
7

JAMFOX
USER MANUAL
13
Jamfox®
2) Double tap the touch control button and the LED indicator will flash red and blue
once at the same time, reset the factory setting and the earphone will power off after
the operation. Remark: If the Master and Slave clear the paring list at the same time,
you have to pairing as first time use then both earbuds can pairing as TWS. In order to
operation easier we recommended clear the earbuds pairing list one by one.
Fast Charging
Just 15 minutes in the case gives you 1.5 hours of listening time.
Charging case holds multiple additional charges for more than 9 hours of listening time.
Charging Pod battery status
Charging status: the number of blue LED light indicate battery status; the LED indicator will turn
blue when the charging Pod is fully charged.
Power off status: LED indicator indicate battery status
Power 0%-25%: one blue LED indicator lights on
Power 25%-50%: two blue LED indicator lights on
Power 50%-75%: three blue LED indicator lights on
Power 75%-100%: four blue LED indicator lights on

14
USER MANUAL
JAMFOX
Jamfox®
Specifications
Items
Specifications
Headset
Battery
Earbud Weight
Bluetooth Version
Working voltage
Microphones sensitivity
Bluetooth Frequency band
Bluetooth range
Audio transmission protocols
Button Cell 60mAh
4.7 grams
V5.0
3.2V-4.2V
-40±2db
2.4-2.48GHZ
10M
A2DP/HFP/HSP/AVRCP
Charging Pod
Capacity
Weight
DC output voltage
DC output current(MAX)
DC charging voltage
DC charging current(MAX)
400 mAh
25 grams
DC5V
250mA
DC5V
120mA
Product Certification : FCC/CE/ROHS/BQB
FCC ID : 2AJCZWS-T2

JAMFOX
USER MANUAL
15
Jamfox®
Notice
Please ensure the earbuds are in pairing mode (LED indicator of the earbud flash red and blue
alternately.) or the mobile will not find the relevant pairing ID to connect it.
Warm tips
You must select a qualified adapter to charge this product. You must charge the Bluetooth
headset if it has not been used for more than 3 months.
Warning
1. Do not put the product in the environment of too low or too high temperature extended
periods. This may cause deformation, reduce the battery capacity, even shorten service
lifetime.
2. Do not use the device when the thunderstorm coming, may cause a failure, and Increase
the risk of struck by lightning.
3. Do not remove or modified headset for any reason, otherwise may lead to headset fault
or burned, please send headset to authorized service center for repairs.
4. Place the device and all accessories out of the reach of children and pets, small parts
may be swallowed cause suffocation and serious consequences.
5. Do not put the headset into the water.

16
USER MANUAL
JAMFOX
Jamfox®
Troubleshooting
Problem
Reason
Solution
Starting-up failure
low battery
charge for the headset
No sound after paired
wrong paired
re-pairing
Red light shines during phone
talking
low battery warning
please charge immediately
No indicator during charging
Headset didn’t put into the
charging cable well
check the headset if it’s well
put into
Shut down automatically
low battery
charge for the headset
Echo
volume is too high or
environment is too noisy
adjust volume or change
environment
Noise during phone calls
environment disturbance or
headphone is too far away
from device
change environment or
shorten the distance
between headphone and
device
Low volume of the caller
wrong wear of headphone
adjust headphone position
Signal is not well,
interrupting
environment disturbance or
headphone is too far away
from device
far away from the
interference signal or shorten
the distance between
headphone and device
Warranty and support
For more products and supports, please visit our company website: www.jamfoxaudio.com

JAMFOX
USER MANUAL
17
Jamfox®
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Non-modification Statement
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
