J&K FD24 User manual

Knee Drawer
Item Code:
FD24, FD27, FD30, FD36
2020 Edition
All manuals and user guides at all-guides.com

WARNING:
1. Please be careful when opening the box with boxcutter and/or blade.
2. J&K Cabinetry is not responsible for any injuries and/or damages incurred during
cabinet assembly.
SERVICE:
During the installation process, if you encounter any problems, please go to our official
website: www.jandkcabinetry.com, check the full version assembly instruction or watch
the assembly video online.
Copyrights © 2020 J&K International Group, LLC. All Rights Reserved.
All manuals and user guides at all-guides.com

Included Items:
Recommended Tools:
Side Panel
Side Panel
Back Panel
Bottom Panel
Front Frame
Drawer Side
Drawer Bottom
Drawer Front
Drawer Side
Drawer Back
Wood Glue Screw Driver Rubber Mallet Compressor
Nail Gun Stapler Senco Fastener
Safety Tools:
Eye Wear
Gloves
19/32”
1/2”
Under Mount
Drawer Glide Kit
X 1
Door Bumpers
X 4
90° Brackets
X 4
Screws
X 16
Screws
X 10
Glide Supports
X 2
Glide Locking Kit
X 1
1-3/16”
Screws
X 3
