Janser 135SH User manual

MOD.135SH
112 455 000 - 230 Volt
112 455 600 - 120 Volt
MOD.145SH
112 560 000 - 230 Volt
112 560 600 - 120 Volt
MOD.155 S
112 750 000 - 230 Volt
112 750 600 - 120 Volt
Manual Columbus - JD - Date: 09/2019 Konf
Janser GmbH
Böblinger traße 91
71139 Ehningen
GERMANY
Phone +49 / 7034 / 127-0
Fax +49 / 7034 / 8838
E-mail: [e-mail]
Internet:www.janser.com
OPERATING MANUAL
PROFESSIONAL
FLOORING
TECHNOLOGY
GRINDING MACHINE
Columbus

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
INDEX
OPERATING INSTRUCTIONS 3
Chapter Page
1 Rules for save operation
1.1 Elektric Connection 4
1.2 Staff 5
1.3 Usage 5
2 Product Information
2.1 Technical Description 6
2.2 Technical Data and Range of application 6
2.3 Accessory units 7
2.4 Accessories driving discs/brushes/plates 8-12
3 Security Instructions
3.1 Determined Application 13
3.2 Electric Supply 13
3.3 Measures of Precaution 13
3.4 Accident control Measures 13
3.5 Emissions 13
4 User Instructions
4.1 Assembly of guide bar 14
4.2 nstalling and changeing accessories 14
4.3 Starting the machine 15
4.4 Operation 15
4.5 Transport 15
5 Maintenance Instructions 16
6 Spare Parts 17
Declaration of conformity

G r i n d i n g m c h i n e s n d c c e s s o r i e s
K e t t e l m s c h i n e
BEDIENUNGSANLEITUNG
4
1 RULES FOR SAVE OPERATION
1.1 Electric Connection
Commandment Warning /
Caution
Hint /
Clue
Forbiddance /
Prohibition
Always disconnect power plug before servicing.
Maintenance, replacement or adjustment of hydraulic fluid or other parts can cause serious injury or
death to the user or other persons, if the machine is connected to the power supply system.
Keep the cable away from the blade to avoid damage of the cable.
Das Run over or damage of the cable can cause an electric shock.
The machine is constructed for inside-usage only.
Danger of electric shock. Do not expose the machine to water or rain.
Connection: power supply system – machine
Only to the given ranges on the type plate.
Check before usage.
Connection: cable – machine only with authorized cable.
Europe, Cable – Type: HAR HO5VV-3x2,5 mm² , Connector / Plug – Type: 2P+T16A-250v
Using cables with to little average or excessive length can cause damage to persons and objects.
Electrical equipments like cables or plugs must be controlled / renewed by an authorized electrici-
an. Risk of injuries or fatalities by wrong electrical connection
Never operate with a damaged cable or connector.
Replacement of worn or damaged cables or connectors has to be effected by a specialist or a similar qua-
lified person.
Improperly connecting the grounding wire can result in risk of electric shock.
Check with a qualified electrician if your in doubt as to whether the outlet is properly grounded. Do not
modify the plug provided with the tool. Never remove the grounding prong from the plug. Do not use
the tool if the cord or plug is damaged. f the plug will not fit the outlet, have a proper outlet installed
by a qualified electrician.
Do not use machine when cable is damage. Don't move the machine by dragging the cable. Utilization
with a damaged cable can cause an electric shock.
Non observance of the symbols, which you can see in the instruction manual or on the machine, may
result in serious injury or death for the user and other persons. Read, understand and follow all the clues
/ hints, which are situated in the machine or in the instruction manual.

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
1 RULES FOR SAVE OPERATION
OPERATING INSTRUCTIONS 5
1.2 Staff
The operator has to be instructed to the use of the machine before operating.
Non observance of the instruction manual before commissioning, adjustment or maintenance could
cause serious injury to personal or objects.
Read unexceptionally all security statements. Be sure that type plate, security symbols as com-
mandments, warnings, precautions and the directives are mounted / fixe to the machine. Non
observance of the directives inside this manual may cause serious injury or damage.
Always wear eye-protection, protective suit, dust-mouthguard / dust respirator and ear-protection
during the usage of the machine. The noise that appears while removing flooring can be so intense
that at long term use it may cause injury of the auditory tube. Working without appropriate security
equipment, as for instance a protective suit, can injure eyes and body. Arising airborne dust may be inha-
led when wearing no mouthguard.
Keep arms, feet and clothes away from the operating machine parts.
Moving parts of the machine can cause serious injury or damage.
1.3 Usage
Use only the recommended accessories ensure its function before starting.
Spare parts and accessories are manufactured especially for the COLUMBUS.
We explicitly point out that other parts must not be used. Thereby the safety of the machine can be
negatively affected, especially the blade. Janser GmbH cannot be held responsible for the performance of
any damage arising from the use of machines in which genuine spare parts have not been used.
Work Safety
The grinding machine COLUMBUS is designed to the highest technical standards. Nevertheless the
usage may cause dangers for life, body and objects. Use this machine only as instructed in this operation
manual and with the machine in perfect working order. Disturbances that could impair safety, have to be
eliminated immediately.
Restrictions of Use
The grinding machine COLUMBUS is exclusively for use in dry rooms for grinding, cleaning and
sanding of subfloors. It should not be used for any other materials. Janser GmbH cannot be held
responsible for any damage or loss caused by incorrect use. Correct use also includes to take care of all
directions from the operation manual and the execution of maintenance and service.

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
2 PRODUCT INFORMATION
OPERATING INSTRUCTIONS
6
2.1 Technical Description
Columbus
Removes decisively all that unwanted material adhered to your subfloor !
This machine will mill, grind and sand your floor surface while creating a minimum of
dust - thus helping to maintain a healthier working environment.
All types of plaster, screed, asphalt and adhesive along with small surface irregulari-
ties can be removed from the subfloor with ease.
On parquet floors the Columbus is ideal for sanding immediately before and bet-
ween sealing and varnishing coats. t can then be used for surface cleaning, polishing
and the applying of sealing wax.
With a wide range of working plate options to suit all types of floor surfaces, the
machine is unsurpassed in saving you time and effort.
The robust design and construction of the Columbus ensures a long life and good
reliability. The 3-gear planetary transmission designed to cope with the toughest
tasks.
With the appropriate accessories the machine is also used for shampooing carpets.
Working plates can be changed in seconds.
2.2 Restrictions of Use - Range of Application
Finish sanding of parquet
Intermediate grinding
Grinding of cork floors
Waxing
Incorporating of flooring materials
Shampooing of carpets
Grinding of wassh floors and fillers
Removing all residues
MOD.145
MOD.155
MODEL 135 SH 145SH 155S
Power supply 230V or 110 V 230V or 110 V 230V or 110 V
Motor power 1200 Watt (1,5 HP) 1500 Watt (2 HP) 2000 Watt (2,5HP)
Working Width Ø 375 mm (14 3/4’’) Ø 375 mm (14 3/4’’) Ø 375 mm (14 3/4’’)
Speed 140 rpm 140 rpm 140 rpm
Weight 42 kg (93 lbs) 42 kg (93 lbs) 50 kg (110lbs)
Order-No. 110 V 112 455 600 112 560 600 112 750 600
Order-No. 230 V 112 455 000 112 560 000 112 750 000
2.3 Technical Data
MOD.135
MOD.155

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS 7
2 PRODUCT INFORMATION
2.4 Accessory units
For connection to the JANVAC V cuum Cle ner. Fits on Columbus M chines
This vacuum-system was developed with the latest "2-Channel Suction System".
f used in combination with a strong vacuum cleaner like the JANVAC,
grinding or sanding can be done in one dust free process with vacuum
so that hardly any dust will be left.
Dust Extraction Ring MULTI-VAC
Dust Extractors ANVAC
CONTENTS:
Dust Ring with closure-ring,
velco straps, 2 suction hoses and T-
Adapter
Order-No. 113 700 000
Spare Parts
Velcro Strap 113 700 100
Modell 1600-H Power Modell 2400-H Power CT
The Teflon-coated
channel filter has a
self-cleaning effect
because the filter
material is stretched
over springs which
move automatically
when in operation.
- Built for construction materials such as
concrete, plaster, grout and stone.
- Safe when working with insanitary dust.
- Easy to transport.
- Delivered complete with cleaning
equipment.
With a 1200 Watt motor and the Teflon-coated
filter areas, the airflow is so great that vacuu-
ming from hand tools and the removal of other
dust is performed without difficulty.
Power Supply 230V or 120 V
Motor Power 1450 Watt (1,6 HP)
Filter Area 8000 cm² (8,6 ft²)
Weight 15 kg (33 lbs)
TECHNICAL SPECIFICATION TECHNICAL SPECIFICATION
Power Supply 230V or 120 V
Motor Power 1100 Watt (1,5 HP)
Filter Area 14000 cm² (15,1ft²)
Weight 31 kg (68 lbs)
230 V 115 096 700
STANDARD ACCESSOR ES:
- 4 m (13 1/8’) suction hose
Ø 38 mm (1½”)
- Rolling floor nozzle 45 cm (1½”)
- Suction pipe
STANDARD ACCESSOR ES:
- 4 m (13 1/8’) suction hose
Ø 38 mm (1½”)
- Rolling floor nozzle 45 cm (1½”)
- Suction pipe
230 V 115 095 200
for older Columbus-Models
(with small wheels & foot-rest)
Special Equipment
Clutch Adaptor 112 336 100

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS
8
2 PRODUCT INFORMATION
2.6 Accessories driving discs/brushes/plates
for Mod.135/145/155 112 300 001
Grinding Plate
with Felt
For holding sandpaper discs and also suitable for
compressing adhesive on PVC/linoleum type
floor coverings.
Polishing Brush
Scrubbing Brush
For cleaning hard surfaces
Shampooing Brush
For cleaning of rugs and carpets
Tank
Capacity 15 l
Ø 375 mm (14¾”) 112 300 002
Ø 430 mm (17”) 112 801 002
Felt Plate
Order-No.:
Order-No.:
Order-No.:
Order-No.:
Order-No.:
Order-No.:
for Mod.135/145/155 112 334 000
Universal Plate
For accepting sandpaper discs, sanding
gauze discs and abrasive pads.
for Mod.135/145/155 112 320 000
for Mod.135/145/155 783 000 012
for Mod.135/145/155 783 000 011
for Mod.135/145/155 783 000 010
Ø 375 mm (14¾”) 112 334 001
Ø 410 mm (16”) 112 809 001
Rubber-coconut-disc

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS 9
2 PRODUCT INFORMATION
2.4 Accessories driving discs/brushes/plates
Order-No.:
Order-No.:
Grit 12 112 309 000
Grit 16 112 311 000
Grit 24 112 312 000
Grit 30 112 313 000
Ø 375 mm (14¾”)
for Mod.135/145/155
Sandpaper
double sided
pack of 25
Grit 40 112 314 000
Grit 60 112 315 000
Grit 80 112 316 000
Grit 100 112 317 000
Grit 120 112 318 000
Pad Mounting Plate
For mounting of sanding mats and pads to take
grinding gauze.
for Mod.135/145/155 783 000 042
for Mod.135/145/155 783 000 015
Black Pad
for fixing grinding gauze
for Mod.135/145/155 783 000 043
Velcro Top
Grit 60 783 000 045
Grit 80 783 000 047
Grit 100 783 000 050
Grit 120 783 000 055
for Mod.135/145/155
Grit 150 783 000 057
Grit 180 783 000 060
Grinding Gauze
Ø 410 (16”)
pack of 10 pcs
Sandpaper - full plastic -red
double sided
pack of 25
Grit 12 112 324 000
Grit 16 112 310 000
Grit 24 112 325 000
Grit 30 112 326 000
Ø 375 mm (14¾”)
for Mod.135/145/155
Grit 40 112 327 000
Grit 60 112 328 000
Sanding Mats
Gr. 40 coarse for smoothing off wood
Gr. 80 medium for in-between smoothing
Gr.280 fine for cutting sealed floor surfaces
Grit 40 783 000 140
Grit 80 783 000 180
Grit 280 783 000 280
for Mod.135/145/155
Polyester Pads
brown for stubborn dirt
red for normal dirt
white for polishing
brown 783 000 023
red 783 000 025
white 783 000 026
for Mod.135/145/155
Regular Pads
brown 783 000 017
green 783 000 016
for Mod.135/145/155

for Mod.145/155 112 332 000
Grinding Plate
Grit 20 with 6 Rectangular Grinding Stones,
replaceable 75 x 90 mm (3 x 3½”)
For grinding of plaster and levelling compound,
removal of residual paint and gypsum, smoothing of
slight unevenness.
Repacement Stone Grit 20
with tapped hole
for Mod.145/155 161 515 003
Grinding Plate
Grit 16 with 5 truncated,conical stones,
For grinding of screed and hard plaster, asphalt and con-
crete. Good grinding rate due to high total edge measu-
rement of hollow conical stones.
Removes unevenness, soft spots, coatings and residual
filling plaster.
for Mod.145+155 112 346 000
Grinding Stone, Grit 16 112 346 001
Replacement Parts
C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS
10
2 PRODUCT INFORMATION
2.4 Accessories driving discs/brushes/plates
Steel Brush
Wire length 45 mm (1¾”)
For removal of foam backing, adhered residual
underlay and carpet backing for industrial floor
cleaning.
for Mod.145+155 112 319 000
Order-No.:
Order-No.:
Order-No.:
Order-No.:
Order-No.:
Ø 375 mm (14¾”)
Abrasive Disc
metal Grit 14
A thin steel disc with randomly scattered hardmetal
fragments welded to the surface.
For roughing the surface of anhydrite and screed.
Also suitable for levelling off surface irregularities.
for Mod.145+155 112 308 000
Plate with 6 Pot Brushes
For removal of the metallic layer that builds up bet-
ween anhydrite and magnesite screed materials.
Also for the removal of residual foam-backing, plaster
splatter, residual paint coatings etc. and
the removal of adhered underlay.
for Mod.145+155 112 322 000
Pot Brushes 112 321 003
Replacement Parts

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS 11
2 PRODUCT INFORMATION
2.4 Accessories driving discs/brushes/plates
Star-Wheel Grinding Plate
with 5 redating Heads of 20 wheels each
For the effective scraping, peeling and removal of
adhesive and various coatings as well as thin set and
mastic.
for Mod.145+155 112 339 000
Grinding Head, complete 112 339 100
Set of 20 Grinding Wheels 112 339 110
Replacement Parts
Grinding Plate with 8 Hardmetal
Titanium - coated Insets
Each inset is useable on 4 sides. For removal of residual
adhesive (also bitumen) or other adhered surface
covering material. The hardmetal inserts can be reda-
ted to make use of all 4 cutting edges in turn.
for Mod.145+155 112 343 000
Hardmetal Inset,
set of 8 112 343 001
Replacement Parts
Hexa-Plate
with 12 Carbide-Hexpins
designed with a replaceable, four-sided, abrasion resi-
stant, carbide insert to be used for scraping and remo-
val of coatings and paints from concrete surfaces.
for Mod.145 SH+155S 112 355 300
Carbide Hexpin 112 355 020
Replacement Parts
Carbide Insert 112 355 050
Order-No.:
Order-No.:
Order-No.:
Hexa-Plate
with 6 Diamond-Segments
Grinding of hard surfaces such as concrete or levelling
compounds seems to be more effective as by using
other diamond plates due to the larger area covered. t
also proves more effective when grinding plaster and
anhydrite screed.
for Mod.145SH+155S 112 353 500
1 pcs 112 353 020
Diamond Segment compl
with input unit
set of 6 pcs 112 353 200
1 pcs 112 353 010
Replacement Diamond Segment
set of 6 pcs 112 353 100
Order-No.:
Abrazor Diamond Plate
with 5 Diamond Cups on Ball Bearings
For superior grinding, sanding and bevelling on hard sur-
faces like concrete and coated levelling compounds. The 5
Diamond Cups are stabilized in a way that they work in
unity. The use of a strong Sander is recommended. (min.
1500 Watt /2 HP + 3-gear planetary) Diamond Cup (1pcs) 112 357 100
Replacement Parts
for Mod.145 SH/155 S 112 357 000
Order-No.:

Grit 40 112 359 110
Grit 60 112 359 111
Grit 80 112 359 112
Grit 100 112 359 113
Grit 120 112 359 114
Grit 80 112 359 120
Grit 100 112 359 121
Grit 120 112 359 122
Grit 150 112 359 123
Order-No. 112 360 900
Order-No. 112 360 100
Satellite MULTI-PAD
for holding velcro sanding discs
Grit 10 112 360 200
Grit 2 112 360 250
MULTI-TITAN
with hard metal fragments for
grinding of hard surfaces
Order-No. 112 360 300
MULTI-DIAMOND
with diamond segments for
sanding and roughening
on hard floors
Order-No. 112 360 600
MULTI-STAR
created to sand and remove
glue, paint and coatings
Order-No. 112 360 400
MULTI-STONE
ideal accessory to sand
cement foundations.
Eleminates brush marks and
surplus materials.
Velcro Sanding Paper
Ø115 mm (4½”) pack of 25
Velcro Screen Pad
Ø105 mm (4 1/8”) pack of 25
Multi-Disc-Satelites®
5 same Satellites per Shuttle needed
Multi-Disc-Shuttle III ®
with 6 Satellites to hold 6 Sanding- or Grinding Plates.
Can be used with 3 or 6 satellites. (Multi-Scraper always has 6 satellites)
Reverse direction of satellites with 500 rpm - 4 times the speed of the shuttle
mproved version: ball bearing, steel satellite discs
C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS
12
2 PRODUCT INFORMATION
2.4 Accessories driving discs/brushes/plates
Columbus DIA-DISC Grinding Plate
with PCD inserts
Grinding of screed, removing sinter surfaces (anhydri-
te), adhesive residues, levelling compounds, thin coa-
tings and painted surfaces.
Order No. 112 381 000
complete with 5 PCD Head Segments
Order No. 112 381 100
Base plate without segments
Order No. 112 381 050
PCD Head Segment
Order No. 112 381 070
Diamond Sanding Segment Grit 30 - grey
Order No. 112 381 080
Diamond Sanding Segment Grit 30 - yellow
Spare Segments for D A-D SC Plate
PCD-Head Plate
with 5 ball-bearing sanding discs
For sanding of cement-bound subfloors,
spackling compound, anhydrite,
layers of sinter, coverings and
irregularities, for example trowel marks.
Very long product life
Order No. 112 391 000
1 pcs 112 391 050
Spare PCD sanding disc

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS 13
3 IMPORTANT SECURITY INSTRUCTIONS
3.1 DETERMINED APPLICATION
3.2 ELECTRIC SUPPLY
All columbus single disc floor cleaning machines may only be used indoors for scrubbing, polishing,
shampooing of floor coverings. Certain models - see range of applications - may also be used indoors for
grinding, roughing and milling all kind of subsoils.
Before usage it has to be taken care that the connected load corresponds to the marking on the rating
plate.
Unplug machine before carrying out maintenance or repair works or changing accessories
The main cable may not be damaged by passing over, pinching, wrenching, chafing or similar. Machines
may only be used with perfect cables.
When replacing cables, plugs, couplings, fuses or sockets take care the same comply with the the specifi-
cations stated by the manufacturer and genuine spare parts are being used.
Only splash-proof couplings may be used for the main cable or extension cords.
3.3 MEASURES OF PRECAUTION
3.4 ACCIDENT CONTROL MEASURES
The machines may never be transported with the guide bar in its upright position
When transporting in elevators the relevant user instructions and safety measures especially the carrying
capacity have to be kept in.
The machine is only suitable to be used on plain areas with a miximum gradient up to 2%
Drive carefully over sills and steps to avoid damages at the edges respectively brushes or pads
After stoppage the machine has immediately to be switched off to avoid damages on floors.
Never switch on machine when in upright position only when tilting back to working position.
Take care not to cross the cable. The working field must be always behind the machine at the guide bar.
N CASE OF EMERGENCY - UNPLUG MACH NE
3.5 Emissions
The equivalent A-weighted continuous sound level of these machines without suction unit lies under 70
dB (A) and with suction unit under 81 dB (A).

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS
14
4 INSTRUCTIONS
4.1 Initial Operation
Assembling the guide bar
a. First of all the guide bar has to be fitted to the body with the four fixing nuts
which have to be tightened with a 13 mm fork wrench.
b. Then plug the cable of the guide bar on to the machine body.
c. Unlock the guide bar by pulling the lower lever on the right, tilt the machine
slightly forward into the upright position until it locks.
d. With a tipping chassis tilt the machine slightly forward and step on the wheel frame
until it locks.
4.2 Installing and changing accessories
Manual
a. Unplug the machine.
b. Tilt the machine back until the guide bar lies on the floor.
c. nstall the accessory with a slight left-hand movement to the fixing device.
d. To remove it turn the same jerkily to the right.
by machine
a. Connect the main cable.
b. Put the accessory on the floor in front of the machine.
c. Tilt the guide bar into the convenient working position by pulling
the lower lever on the right and lock it.
d. Tilt the machine slightly back and move it over the accessory.
e. With a tipping chassis push the pedal of the wheel frame to move it up.
f. Switch on the machine shortly and the accessory locks in.

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
4 INSTRUCTIONS
OPERATING INSTRUCTIONS 15
4.3 Starting the machine
a. Connect main cable.
WHEN PLUGGING THE MACHINE AND WORKING WITH THE SAME HOLD THE GUIDE
BAR WITH BOTH HANDS FIRM AND SAFE AND NOT CLENCHED!
b. By pulling the lower lever on the right tilt the guide bar back into the convenient
working position and lock it. Release lever.
c. Push the key button on the back of the switch box. Manipulate switch lever.
(Security against unintended turn-on)
d. Release key button, machine is turned on.
e. Release of switch levers turns off machine.
f. For switching on and working with the machine it is sufficient to manipulate
one of the two switch levers.
4.4 Operation
a. The grinding machines are self-runners, that is to say by slightly pushing or
pulling the guide bar the machines move to the left or right.
movement to the left -> pushing guide bar slightly !
movement to the right -> pulling guide bar slightly !
TO AVOID CROSSING THE CABLE WHEN WORKING PUT THE SAME
OVER THE SHOULDER !
4.5 Transport
a. For transporting the machine tip the same slightly back and move the guide bar
into the upright position.
b. Then the machine can easily be tilted backwards and being transported without
problems.

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS
16
5 MAINTENANCE
Machines and appliances have to be kept dry and to be protected against frost and heat.
Motor and gear of the machines are maintenance-free, only the dirt residues under the motor
cover have to be removed regularly thus guaranteeing a good cooling of the motor.
Machines and appliances may only be cleaned with a dry or with a gentle detergent slightly moi-
stured cloth. No wet cleaning otherwise endangering the electrical safety.
When the suction efficiency is decreasing the cloth filter cartridge in the suction unit GK has to be
cleaned. The filter cap has only to be batted. If necessary the filter plate beneath (fleece) has to be
replaced.
When extremely soiled dust bag and motor filter may be washed in lukewarm water with gentle
washing-powder. However both may only be fitted again after complete drying.
Maintenance inspection and repair work (including change of the main cable and carbon brushes
of the motor) may only be carried out by authorized service centers or qualified trained personnel.
After approximately 600 working hours the carbon brushes of the motor have to be replaced.
When using extension cords or replacing main cables it has to be taken care that the same comply
with our specifications PVC sheated cables H05W-F in accordance with DIN 57281/VDE 0281. The
plugs have to be # of rubber or PVC and the outlet direction of the cable has to correspond with
the direction of the plug pins. When changing the main cable the under chapter 4 stated relevant
safety regulations have to be kept to.

C O L U M B U S
G r i n d i n g m c h i n e s n d c c e s s o r i e s
OPERATING INSTRUCTIONS 17
MODELS 135S 145SH 155S
1 grinding machine complete 112 455 000 112 560 000 112 750 000
2 machine body 112 455 001 112 560 001 112 750 001
3 guide bar complete 112 750 100 112 750 100 112 750 100
4 guide tube complete 112 750 150 112 750 150 112 750 150
5 frame with wheels co. 112 750 160 112 750 160 112 750 160
6 switch box complete 112 750 110 112 750 110 112 750 110
6 SPARE PARTS
4.3 Subassembly Survey

Service / Ersatzteile
Maschinen, Geräte, Fachwerkzeuge für
Raumausstatter, Fußbodenleger und
den Fußbodenbelagshandel
Columbus Mod.145
Artikelnr.: 112 560 000
28.01.2020
Seite 1 von 5 / MAI 2006 28.01.2020 Sai
Janser GmbH Böblinger Straße 91 D-71139 Ehningen Telefon [phone] Fax [phone] [email protected] www.janser.com
Maschinenkörper 112 560 001

Service / Ersatzteile
Maschinen, Geräte, Fachwerkzeuge für
Raumausstatter, Fußbodenleger und
den Fußbodenbelagshandel
Columbus Mod.145
Artikelnr.: 112 560 000
28.01.2020
Seite 2 von 5 / MAI 2006 28.01.2020 Sai
Janser GmbH Böblinger Straße 91 D-71139 Ehningen Telefon [phone] Fax [phone] [email protected] www.janser.com
Pos
Bezeichnung
Description
Version
#
Artikelnr
001
Schutzring
Safety ring
Mod.400,125-165 und S
1
112400001
002
Schutzhaube lang silber
motor cover silver -long
Mod.145SH
1
112560004
003
Linsenschraube
raised-head screw
DIN 7985 M5*10
3
006805010
004
Sicherungsring
retaining ring
DIN472 D=10*1,0
1
017000101
005
Kühlflügel
cooling fan
Mod.400S,145S-165S
1
112550151
006
Zyl.Kopfschraube
cylinder-head screw
DIN 84 M4*16
2
000304016
007
Zahnscheibe
antiturn washer
DIN 6797 J 4,3
2
017410004
008
Toleranzring 12x12
ring
Mod.400S,145S-165S
1
112550062
009
Motorgehäuse mit Stator
motor cover with stator
Mod.145SH
1
112560060
010
Zyl.Kopfschraube
cylinder-head screw
DIN 84 M5*35
4
000305035
011
Ausgleichscheibe K2
washer
Mod.400,145-165 und S
1
112400140
012
Rillenkugellager 6001-2rs
Grooved ball bearing
6001-2RS 12*28*8
1
050204008
013
Fliehkraftschalter 1500W
Centrifugal switch 1500W
Mod.400,145-165 und S
1
112700008
014
Rotor
rotor
Mod.400SH/135SH
1
112550061
015
Planetengetriebe 3 Räder
Planetary gear 3PL
Mod.145SH
1
112560050
016
Kantenschutzprofil
gasket
1
112750017
017
Betriebskondensator 30myF
running capacitor 30myF
Mod.400SH/145SH/155/165+S
1
112700020
018
Anlasskondensator 120myF
Starting condenser 120myF
Mod.400/145/145-S (380 V)
1
112500030
019
Isolierfolie
Terminal Isolation
1
112750016
020
Bolzen für Tragegriff
bolt
2
112400065
021
Tragegriff
handle
2
112400064
022
Gegengewicht
counterweight
1
112400133
023
Scheibe
washer
DIN 125 A 6,4
2
014600061
024
Zyl.Kopfschraube
cylinder-head screw
DIN 912 M6*25
2
004006025
025
Kabelbinder
cable ties
4,8 X 178
1
065900021
026
Spannband
holding strip
1
112750022
027
Linsenschraube
raised-head screw
DIN 7985 M4*8
1
006804008
028
Linsenschraube
raised-head screw
Din 7985 M3*16
2
006803016
029
Klemmleiste (4-polig)
terminal (4 poles)
1
112500013
030
Linsenschraube
raised-head screw
DIN 7985 M5*10
2
006805010
031
Schaltkasten-Oberteil
switch box, upper part
Mod.400S/145S/155S/165S
1
112750005
032
Scheibe
washer
DIN 125 A 4,3
4
014600041
033
Linsenschraube M4*8
raised-head screw
DIN 7985 M4*8
4
006804008
034
Gerätesteckdose
socket
Mod.400S/145S/155S/165S
1
112550004
035
Gerätestecker
plug
Mod.400S/145S/155S/165S
1
112550012
036
Linsenschraube
raised-head screw
DIN 7985 M4*6
1
006804006
037
Zahnscheibe
antiturn washer
DIN 6797 J 4,3
1
017410004
038
Schaltkasten-Unterteil
Switch box, lower part
Mod.400S/145S/155S/165S
1
112750006
039
Schlauchtülle
hose sleeve
1
112400067
040
Sechskantschraube
hexagon-head screw
DIN 933 M8*50
2
004608050
041
Sechskantmutter
hexagon nut
Ripp (ähnl.DIN 6923) M 8
2
013700008
042
Blockergehäuse
housing
Mod.400S/145/145S/155S
1
112400062
043
Mutter Selbstsichernd
hexagon nut, self locking
DIN 985 M 6
4
012300006
044
Sechskantmutter M 12x1
hexagon nut M12x1
1
112400068
045
Stoßring
rubber ring
Mod.400,125-155 und S
1
112400030
046
Zwischenscheibe D122x32,2
Intermediate ring
Mod.400,125-165+S ohne165
1
112400046
047
Anschlagstück
Backstop
3
112300021
048
Mitnehmerbolzen
catch bolt
Mod.400-165S außer 165
3
112400069
050
Segmentscheibe
segment ring
Mod.125-165S außer 165
1
112200014
051
Zentrierring
Centering ring
1
112300022
052
Zahnscheibe
antiturn washer
DIN 6797 J 6,4
3
017410006
053
Zyl.Kopfschraube M6*16
cylinder-head screw
DIN 7984 M6*16
6
006706016
054
Verschlußstopfen
closure
1
112500011

Service / Ersatzteile
Maschinen, Geräte, Fachwerkzeuge für
Raumausstatter, Fußbodenleger und
den Fußbodenbelagshandel
Columbus Mod.145
Artikelnr.: 112 560 000
28.01.2020
Seite 3 von 5 / MAI 2006 28.01.2020 Sai
Janser GmbH Böblinger Straße 91 D-71139 Ehningen Telefon [phone] Fax [phone] [email protected] www.janser.com
Führungsstange 112 750 100
