Jasco 28170 Operating and safety instructions

Plug-in
Wirelessly control and schedule
lights from anywhere
Smart Dimmer
Z-Wave Plug-In Dual
Outlet Smart Dimmer,
White
SKU#: 28170
Features
• Dual outlets – Dual-outlet smart dimmer features two polarized Z-Wave-controlled
outlets allowing remote operation of two devices at the same time (cannot be controlled
individually).
• Full-range dimmability – The dimmer adjusts brightness levels from 0-100 percent,
which reduces energy costs and improves bulb life.
• Easy installation – No wiring required. Simply plug in the device and connect to your hub
for dimming capabilities.
• LED, CFL, incandescent and halogen – To retain the full benefit of LED, CFL, incandes-
cent and halogen lights, the smart dimmer supports all types of dimmable light sources.
• Full-home coverage – Z-Wave Plus works with all previous Z-Wave generations to allow
continued expansion of your smart-home network. The dimmer is capable of controlling
indoor fixtures for whole-home automation and repeats your Z-Wave signal from your hub
or other devices to extend your range by up to 150ft.
Wirelessly schedule and control two lamps or
small appliances separately or together from
anywhere, at any time with any mobile device -
space-saving design does not block second outlet
or obstruct furniture placement.
28170 PRODUCT OVERVIEW

1
PRODUCT OVERVIEW
ULTIMATE FLEXIBILITY
Dim and control your lights, small fans and other appliances,
schedule a timed event, create a custom scene from
anywhere in the world, at any time of the day, and charge
your mobile devices from your smartphones, tablets, PCs and
Z-Wave enabled remotes
TWO POLARIZED OUTLETS & MANUAL
ON/OFF DIMMING BUTTON
Smart Dimmer Plug features two (2) polarized outlets that are
controlled together (not individually controlled).
Manual On/O/Dimming physical button is located on the top
of the plug in module.
FULL DIMMING - DIMMABLE BULBS REQUIRED
Smart Dimmer is ideal for lamps and small appliances such as
fans, heaters, coee makers, etc. Works with dimmable LED,
CFL, halogen, and incandescent bulbs. Dimmable Bulbs are
Required for Dimming.
If used with non dimming bulbs you may experience
flickering, buzzing, and limited functionality.
SPACE-SAVING DESIGN
When plugged in to the top outlet of your standard wall
outlet this smart dimmer will not block access to the bottom
outlet. Outlets are located on the left and right side of the
plug-in allowing for ease of use behind furniture like tables,
couches, and beds.
28170

Power:120VAC, 60Hz Signal Frequency: 908.4/916
Maximum load for the Z-Wave controlled outlets:
2.5A,300W Incandescent / 100W dimmable CFL/LED
Z-Wave controlled outlet isfused @ 5A.This fuse is not
user serviceable
Range:Up to 150 feet from controller or closest Z-Wave device
Operating Temperature: 32-104° F (0-40° C)
Warranty:2-year limited product warranty
For Indoor Use Only
Z-Wave Plug-In Dual
Outlet Smart Dimmer
Design Features
· Turn the connected device
On/Off/Dim manually via
Z-Wave remote control
·Remotely monitor with any
mobile device*
· Can beIncluded in multiple
Groups andScenes
· One Z-wave controlled AC
outlet for dimmable LED,
CFL and incandescent lights
· One outlet is Z-Wave controlled
the other is a pass through
·Remote ON/OFF and
Brightness control via the
Z-Wave controller
· Manual ON/OFF and
Brightness control with the
top push-button
·Does not block thelower
outlet when plugged in to
the upper outlet of a duplex
wall receptacle. (This assumes
that the duplex receptacle
is mounted withthe ground
pin down.)
·Plugs and cords for connected
devices route to the side
allowing close placement
of furniture
·Utilizes the Z-Wave Firmware
Update Meta Data command
updates Over theAir
· Two Toned coloring
· Visit http://www.ezzwave.com/
hubs/for hub compatibility
· Trilingual Instruction manual –
(English, French, Spanish)
Z-Wave Plus Features
·Works with Z-Wave Classic
and Z-Wave Plus Products
·50% more wireless range
·250% faster processor
·400% more memory
·Supports wireless upgrades
to future-proof your home
* Requires Z-Wave hub or controller,
functions may vary depending on brand.
2
PRODUCT SPECIFICATIONS28170

Two-Outlet Smart Dimmer
Wirelessly control both outlets simultaneously
Adjust brightness level from 0-100%.
Dimming lights cuts energy cost andextends bulb life.
Dimsin 1% increments.
Adding your device to a Z-Wave network
Once the hub is ready to add your smart dimmer, press and
release the top buttononthe smart dimmer to addit in
the network.
To remove and reset the device
Once the controller is ready to remove your device, press and
release the top buttononthe smart dimmer to removeit from
the network.
To return to factorydefaults
If plugged in, unplug from the receptacle.Press and hold the
top button for at least 3 seconds whileyou plugthe dimmer into
the receptacle.
subject to change without notice
Distributed by Jasco Products Company LLC
10 E. Memorial Rd., Oklahoma City, OK
©Jasco 2018
Polarized outlet
3
PRODUCT SPECIFICATIONS28170

4
28170 QUICKSTART GUIDE
DA
B C
In-Wall Plug-in In-Wall
In-Wall Plug-in In-Wall
Enbright- In-Wall Hinge Pin
Direct Porta- In-Wall
Tam-
Plug-in
Outdoor
Fr
Cet appareil est conforme au paragraphe 15 des normes FCC et au CNR pour les appareils
exempts de licence d’Industrie Canada. Son utilisation est sujette aux deux conditions suivantes :
(1) cet appareil ne doit pas occasionner de brouillage préjudiciable et (2) cet appareil doit
accepter toutes les interférences reçues, notamment les interférences qui peuvent provoquer un
fonctionnement non désiré.
NOTE DE LAFCC : Le fabricant n’est pas responsable des interférences sur les fréquences
radioélectriques ou télévisuelles pouvant être causées par des
l’utilisateur à utiliser cet appareil.
REMARQUE : ves aux appareils
15 des normes FCC. Ces limites ont
brouillage préjudiciable en milieu
résidentiel. Cet appareil produit, utilise et peut émettre des ondes de fréquence radio et, s’il n’est
pas installé et utilisé conformément aux instructions, il peut provoquer un brouillage préjudiciable
aux communications radio. Il n’existe toutefois aucune garantie que des interférences ne se
produiront pas au sein d’une installation donnée. Si cet appareil occasionne un brouillage
préjudiciable à la réception radiophonique ou télévisuelle, il
pour déterminer sa responsabilité. Nous encourageons l’utilisateur à essayer de corriger ces
interférences en appliquant une ou plusieurs des mesures suivantes :
— Réorienter ou déplacer l’antenne de réception.
— Augmenter la distance entre l’appareil et le récepteur.
—Brancher l’appareil à une prise secteur différente de celle du récepteur.
— Consulter le revendeur ou un technicien spécialisé en postes radio ou téléviseurs.
Remarqueimportante : Pour se conformer aux exigences de conformité de la FCC concernant
dépasse les exigences d’exposition aux RF et pourrait annuler le droit de l’utilisateur à utiliser ce
dispositif.
En
This device complies with Part 15 of the FCC and Industry Canada license-exempt RSS
standards. Operation is subject tothe following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC NOTE:The manufacturer is not responsible for any radio or TV interference caused by
could void the user’s authority
to operate the equipment.
NOTE:This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant toPart 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged totry to correct the interference by one or more of
the following measures:
— Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from which the receiver is
connected.
— Consult the dealer or an experienced radio/TV technician for help.
Important note:To comply with the FCC RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any change tothe antenna or the device could result
in the device exceeding the RF exposure requirements and void user’s authority to operate the
device.
Es
de las normas de la FCC y con
isterio de Industria de Canadá
aplicables a aparatos exentos de licencia. Elfuncionamiento está sujeto a las siguientes dos
condiciones: (1) este dispositivo no debe provocar interferencia perjudicial, y (2) este dispositivo
debe aceptar toda interferencia que reciba, incluso la que pudiera causar un funcionamiento no
deseado.
NOTA DE LAFCC: El fabricante no se hace responsable de ninguna interferencia de radio o TV
podrían anular la autoridad del usuario para utilizar el equipo.
NOTA: Este equipo ha sido probado y cumple con los límites para aparatos digitales de Clase B,
de conformidad con el apartado 15 de las normas de la FCC. Estos límites están diseñados para
proveer protección razonable contra interferencias perjudiciales en una instalación residencial.
Este equipo genera, usa y puede irradiar energía de radiofrecuencias y, si no se instala y usa
según las instrucciones, puede provocar interferencia perjudicial a las radiocomunicaciones. No
obstante, no hay garantías de que no ocurrirá interferencia en una instalación en particular. Si
este equipo provoca interferencia perjudicial a la recepción de radio o televisión, lo que puede
determinarse encendiendo y apagando el equipo, se recomienda que el usuario intente corregir
la interferencia por medio de la implementación de una o más de las siguientes medidas:
— Reorientar o reubicar la antena receptora.
—Incrementar la separación entre el equipo y el receptor.
— Conectar el equipo a un tomacorriente de un circuito diferente del circuito al que está
conectado el receptor.
— Consultar al distribuidor o a un técnico con experiencia en radio/televisión para
solicitar asistencia.
Nota importante: Para cumplir con los requisitos de cumplimiento de exposición de
radiofrecuencia de la FCC, no se permiten cambios a la antena o el dispositivo. Cualquier
cambio a la antena o dispositivo podría hacer que el dispositivo supere los requerimientos de
exposición de radiofrecuencia y anular la autoridad del usuario para operar el dispositivo.
ResponsibleParty - US Contact Information | Parte responsable-Informaór Estados
Unidos| Partie responsable - Coordonnées des États-Unis
FCC — U2ZZW3105 | IC: 6924A-ZW3105
Jasco Products Company | Model: ZW3105/28170
CAN ICES-3(B)/NMB-3(B)
FCC/IC

QUICKSTART GUIDE
5
