QUBINO ZMNHDD2 Installation and operation manual

USER MANUAL EN.
QUBINO FLUSH DIMMER
The Qubino Flush Dimmer is a MOSFET-switching light device that also supports control of
low-voltage halogen lamps with electronic transformers, dimmable compact fluorescent
lights, and dimmable LED bulbs.

EN.
2
Table of contents
About Qubino......................................................................................................................................................... 3
Safety Information .................................................................................................................................................5
Flush Dimmer - Available Frequencies..................................................................................................................... 6
Where To Buy......................................................................................................................................................... 7
1. Introduction .......................................................................................................................................................7
2. Use Cases ........................................................................................................................................................... 9
2.1. Installation examples where Flush Dimmer is installed behind a wall switch ................................................ 9
2.2. Additional features of Flush Dimmer which can make your life easier ........................................................ 11
3. Qubino Flush Dimmer Advantages and Highlights ............................................................................................. 13
3.1. Advantages ............................................................................................................................................... 13
3.2. Highlights.................................................................................................................................................. 17
4. Package Contents ............................................................................................................................................. 18
5. Technical Terms for Switches............................................................................................................................ 19
6. Compatibility with Z-Wave Gateways (hubs) ..................................................................................................... 21
7. Installation ....................................................................................................................................................... 22
7.1. Installing the device behind a light switch.................................................................................................. 23
7.2. Installing the Qubino Temperature Sensor................................................................................................. 36
8. Device Information and Support ....................................................................................................................... 42
9. Electrical Diagram (110 - 230VAC, 24VDC)......................................................................................................... 43
10. Adding the device to a Z-Wave network (Inclusion) ......................................................................................... 44
11. Removing the device from a Z-Wave network (Exclusion)................................................................................ 45
12. Associations.................................................................................................................................................... 46
13. Configuration Parameters............................................................................................................................... 48
14. Technical Specifications .................................................................................................................................. 62
15. Z-Wave Command Classes .............................................................................................................................. 64
16. Important Disclaimer ...................................................................................................................................... 69
17. Warning ......................................................................................................................................................... 69
18. Regulations..................................................................................................................................................... 69

EN.
3
About Qubino
Qubino is a family of innovative Z-Wave devices, many of them the smallest of their kind.
Numerous breakthrough innovations, 100% quality control, and responsive customer service
make Qubino the number one choice for making your life more comfortable.
Qubino enables you to transform –inexpensively and invisibly –any traditional electric device
into a smart, connected one that you can control with your smart phone. Qubino devices are
simple to install and use, but also extremely versatile - they offer a wealth of additional features
and parameters for you to play with.
We love helping people who enjoy creating new ideas for their home and then using their hard
work and skill to turn those ideas into reality. We admire their passion and resourcefulness. We
do our best to supply you with products that will enable you to create a unique and special
home for yourself. We innovate so that you can be free to make the smartest home possible.
With just a touch of magic.
"Simple is smart." We believe it is smart to make complex things simple. But only when this
means simple for our customers, not for ourselves. We think a lot so that you won't have to
when it comes to installing or using our devices.
For more information visit: www.qubino.com

EN.
4
About Z-Wave:
The Z-Wave protocol is an interoperable, wireless, RF-based communications technology
designed specifically for control, monitoring, and status reading applications in residential and
light commercial environments. Mature, proven, and broadly deployed (with over 50 million
products sold worldwide), Z-Wave is by far the world market leader in wireless control, bringing
affordable, reliable, and easy-to-use 'smart' products to millions of people in every aspect of
daily life.
Source: www.z-wavealliance.org

EN.
5
Safety Information
For Qubino, safety is first, so we have prepared lots of safety tips and information that can be
found throughout this manual.
To ensure your safety, please read this manual carefully before installing the device; follow
the instructions exactly. The manufacturer (GOAP d.o.o. Nova Gorica) shall not be legally
responsible for any equipment damage or personal injury caused by incorrect installation or
operation other than that covered in this manual.
ⓘPlease check the Technical Specifications and Electrical Diagram chapters, as well as fuse
requirements in the Installation chapter before installing the device.

EN.
6
Flush Dimmer - Available Frequencies
ORDERING CODE
(MODEL NUMBER)
POWER SUPPLY FREQUENCY
Z-WAVE FREQUENCY*
ZMNHDD1
50 Hz
868,4 MHz
ZMNHDD2
50 Hz
921,4 MHz
ZMNHDD3
60 Hz
908,4 MHz
ZMNHDD4
50 Hz
869,0 MHz
ZMNHDD5
50 Hz
916,0 MHz
ZMNHDD6
50 Hz
868,4 MHz
ZMNHDD7
50 Hz
919,8 MHz
ZMNHDD8
50 Hz
865,2 MHz
ZMNHDD9
60 Hz
922,5 MHz
ZMNHDDA
60 Hz
919,7 –921,7 –923,7 MHz
ZMNHDDB
50 Hz
868,1 MHz
ZMNHDDC
60 Hz
868,1 MHz
ZMNHVDD
60 Hz
919,8 MHz
ZMNHVDE
50 Hz
920,9 MHz
*You can check the Z-Wave frequency in your country here:
http://z-wave.sigmadesigns.com/wp-content/uploads/Z-Wave_Frequency_Coverage.pdf

EN.
7
Where To Buy
To find your nearest Qubino dealer visit: http://qubino.com/where-to-buy/
1. Introduction
Flush Dimmer is a MOSFET-switching light device that also supports control of low-voltage
halogen lamps with electronic transformers, dimmable compact fluorescent lights, and
dimmable LED bulbs. It measures power consumption of the connected device, and can be
paired with a digital temperature sensor (sold separately). It supports push-button/momentary
switches and toggle switches (default).
The connection of a digital temperature sensor means you can create complex scenes and
control any device relative to a set temperature range. The Qubino Flush Dimmer also acts as a
Z-Wave repeater to improve the range and stability of the Z-Wave network.

EN.
8
Flush Dimmer supported functions:
Dim the Lights
Turn on/off
kWh
Measurement
W
Measurement
Temperature Sensor
Automatically turn
ON/OFF
✓
✓
✓
✓
✓
✓
Scene 1
Trigger
Scene 2
Trigger
Associations
Z-Wave Repeater
Auto-inclusion
✓
✓
✓
✓
✓

EN.
9
2. Use Cases
The Flush Dimmer can be used in many different scenes, which can help make your life more
comfortable. We have prepared a few of them for you so you can get an idea for your next
smart home project. Of course, there are countless of other options for how to use Qubino
Flush Dimmer to remotely control devices via your smartphone.
2.1. Installation examples where Flush Dimmer is installed behind a wall switch
•Remotely dim the lights or turn them
ON/OFF
•Remotely trigger different scenes with two
additional inputs (I2, I3) –for example
scene 1: turn on all the lights in the house,
scene 2: turn off all the lights in the house

EN.
10
•Remotely measure room temperature (* The
temperature sensor is sold separately - for
more info, please see Qubino catalogue.
Product ordering code (model number):
ZMNHEA1)

EN.
11
2.2. Additional features of Flush Dimmer which can make your life easier
•Do you often forget to turn off devices
when you leave your home, like lights in
the basement or attic?
•The Flush Dimmer can automatically turn
lights on or off after a set period of time
(when you’re away from home). For
example, the light will automatically turn
off if it’s been on for 8 hours, let’s say.
This function is independent of other
scenes and gateway (hub) commands.
•Do you know how much energy you
consume?
•The Flush Dimmer monitors and reports
energy consumption of connected
devices in real time to your smart home
app (your gateway (hub) needs to
support this feature). Know how much
power your lights are using.

EN.
12
•Want to control other devices in your Z-Wave
network with the Flush Dimmer?
•Connect the Flush Dimmer with other devices in
your network to remotely and automatically
trigger another Z-Wave device. And have other Z-
Wave devices trigger your Qubino Flush Dimmer.

EN.
13
3. Qubino Flush Dimmer Advantages and Highlights
3.1. Advantages
•The Qubino Flush Dimmer allows the easiest and quickest installation possible. Because
of its small size, it fits smoothly in even the smallest, most shallow and most crowded
flush mounting boxes, which are stuffed with lots of electrical cables and where every
millimetre counts. All this is possible because the Qubino Flush Dimmer is the smallest
Z-Wave dimmer in the world.
•The Qubino Flush Dimmer has the option to connect a temperature sensor*, through
which users can monitor the ambient air or water temperature. It’s the only Z-Wave
dimmer in the world which offers this option. With a connected sensor, the user can
monitor accurate measurements of the room temperature, pool water temperature,
etc., and remotely change conditions as desired. Qubino dimmer, along with the
temperature sensor, is connected directly to the power supply. Install it and forget it –
no need to worry about dying batteries, like with battery-powered sensors.
*The temperature sensor is sold separately - for more info, please see Qubino
catalogue. Product ordering code (model number): ZMNHEA1
ⓘPlease do not put the temperature sensor directly into the water! The temperature
sensor is designed to measure the water temperature by being mounted to the water pipe.

EN.
14
•The Qubino Flush Dimmer is the only Z-Wave dimmer in the world that has two
additional inputs (I2, I3), which enable triggering of different scenes. The user does not
need to buy additional devices for setting various scenes. For example:
oSwitch connected to input I2: Welcome Home –turn on all the lights in the
house
oSwitch connected to input I3: Leaving Home –turn off all the lights in the house
•Qubino Dimmer allows a direct connection of even the smallest bulbs. It’s the only Z-
Wave dimmer on the market that does not require any minimum load power, which
means that the user can connect the bulbs with minimum power loads that are bigger
than 0 W. So there is no need for buying a bypass for connecting for example LED lights
with 3 W, 7 W, 10 W etc

EN.
15
•Qubino guarantees 100% device quality. Such high quality can be delivered because
every Qubino goes through rigorous quality control standards throughout the
production process. Every device has a unique serial number and a part number, which
are assigned to the device only after it goes through a strict testing procedure.
•By scanning the QR code on the back of your Qubino device, the serial and part numbers
will be automatically copied on your mobile phone; they also provide direct access to
Qubino’s technical support team. The serial and part numbers of your device are given
automatically every time you open an inquiry with our support team: this instantly
shares the relevant device information we need to provide the best technical support
possible. For details, please see the Device Information and Support chapter.

EN.
16
•The Qubino Flush Dimmer is engineered and manufactured in the EU, and contains only
the highest quality components.
•The Qubino Flush Dimmer is certified by an independent European Institute and has CE,
FCC, LVD and EMC certificates to ensure the highest safety standards.

EN.
17
3.2. Highlights
•Remote (via smartphone or PC) and local on/off control of ALL dimmable bulbs
•Works with push-button (momentary switch) or toggle switches
•Capable of measuring the power consumption of the connected device in real time via
smartphone, which allows you to save on electricity bills*
•Features one of the easiest and quickest installations of devices of this kind; fits in even
the smallest flush mounting boxes
•Saves and restores the last status after a power failure.
•Supports auto-inclusion mode for quick set up
•Can automatically turn devices on and off after a set period of time (helpful when you’re
away from home, for example)*
•Supports additional parameters for expert users, which allows for advanced
configuration*
•Acts as a signal repeater which improves the range and stability of your Z-Wave network
•Can be used to remotely control and trigger other devices in your Z-Wave network
*Your gateway (hub) needs to support advanced configuration and parameter input if you wish
to use this feature

EN.
18
4. Package Contents
•Flush Dimmer Device
•Installation Manual

EN.
19
5. Technical Terms for Switches
Symbol
Switch example images
Definition
EU
USA
Qubino
Other
names
Single pole,
single throw
(SPST) - One
switch
controlling one
light / circuit of
lights
One-way
switch
Two-way
switch
(regular
switch)
Toggle
switch
Switch;
Bi-stable
switch
Single pole,
double throw
(SPDT) - Two
switches
controlling the
same light /
circuit of lights
Two-way
switch
Three-way
switch
Two-way
switch
Used when you
have three or
more switches
controlling the
same light
Intermedi-
ate switch
Four-way
switch
Intermedi-
ate switch
Crossover
switch;
Cross
connection
After being
released, it goes
back to its
original state
Momentary switch
Momentary
switch
Monostable
switch;
Push button

EN.
20
Qubino devices are installed into flush mounting boxes behind the switches. You can see some
examples below:
For more information on how to install your device, please refer to the Installation chapter.
