Jaykal JLS68103-G60-ACTR User manual

LED Driver Replacement Guide for Post Top Acorn Light
Instrucons JLS68103-G60-ACTR
Step 1. Remove the four screws shown in (Figure 1.) Step 2. Remove the top of the xture and locate the four screws in
(Figure 2.)
Step 3. Remove the driver mounng plate and the LED
assembly from the xture. (Figure 3.)
Step 4. Cut the red and white wires connecng the driver to the LED
assembly. (Figure 4.)
Figure 1. Figure 2.
Figure 3. Figure 4.

LED Driver Replacement Guide for Post Top Acorn Light
Step 5. Cut the AC power connecons to the driver. Black,
white and green wires. (Figure 5.)
Step 6. Remove the two screws retaining the driver to the mounng
plate and remove driver. (Figure 6.)
Step 7. Install new driver and reinstall mounng screws
(Figure 7.)
Step 8. Strip the DC power connecon wires (red and white wires)
back approximately 1/2 inch. (Figure 8.)
Figure 5. Figure 6.
Figure 7. Figure 8.

LED Driver Replacement Guide for Post Top Acorn Light
Step 9. Ulizing two wire caps reconnect the AC input wires. Black to black and white to white (Figures 9 and 10.)
Step 10. Pass the red and white wires from the LED assembly through the hole in the driver mounng plate. (Figure 11.)
Figure 9. Figure 10.
Figure 11.

LED Driver Replacement Guide for Post Top Acorn Light
Step 11. Ulizing two wire caps reconnect the DC driver output wires (Red to Red) and (White to Black) (Figure 12.)
Figure 12.
Step 12. Reinstall the driver mounng plate in its
original posion and reinstall the four screws re-
moved in step 2. (Figure 13.)
Step 13. Return the top of the xture to its original posion and reinstall the
four screws removed in step one (Figure 14.)
Figure 13. Figure 14.
