Jaypro Sports RDC SERIES Installation guide

JAYPRO SPORTS
RDC-SERIES, ROUND CLUB SOCCER GOALS
LIST OF MATERIALS
RDCSG-409 RDCSG-612 RDCSG-618 RDCSG-721 RDCSG-824
PIECE NO. DESCRIPTION QTY PART NO. PART NO. PART NO. PART NO. PART NO.
1 CROSSBAR 1 RDC9X1 RDC12X1 RDC18X1 RDC21X1 RDC24X1
2 SIDE FRAME 2 RDC4SF1 RD-6SFHP RDC-6SFHP RDC7SF1 RDC8SF1
3 CORNER 4 RDC-CRN RDC-CRN RDC-CRN RDC-CRN RDC-CRN
4 3/8” FLT WASHER 24 HW2151 HW2151 HW2151 HW2151 HW2151
5 3/8”-16 x 2 ¼” CP SCRW 24 HS5157 HS5157 HS5157 HS5157 HS5157
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED: 7/32” HEX WRENCH
1) SLIP CORNER FITTINGS (3) INTO THE ENDS OF EACH CROSSBAR (1). NOTE THAT FLAT SIDES SHOULD
MATCH. ASSEMBLE 3/8” FLAT WASHER (4) AND HEX HD SCREW 3/8”-16 x 2 ¼” (5) LOOSELY INTO THE TWO
ASSEMBLY HOLES. THE SCREWS MUST MATCH WITH THE INTERNAL THREAD OF THE CORNER FITTING.
PUSH THE CORNER FITTINGS AND CROSSBAR FIRMLY TOGETHER AND TIGHTEN THE ASSEMBLY
HARDWARE SECURELY.
2) SLIDE THE CROSSBAR ASSEMBLY INTO EACH SIDE FRAME (2) THEN ASSEMBLE THE HARDWARE AS
DESCRIBED ABOVE.
SAFETY AND USE CONSIDERATIONS
1) ALWAYS USE GOAL ANCHORS OR COUNTERWEIGHT SANDBAGS TO KEEP GOAL FROM FALLING OVER.
ALWAYS STORE UNUSED GOALS IN COMPLIANCE WITH CPSC RECOMMENDATIONS.
2) IF THE PAINT IS SCRATCHED DURING SHIPPING, ASSEMBLY OR USE IT CAN BE TOUCHED UP TO PREVENT
FURTHER DETERIORATION. LIGHTLY SAND THE AFFECTED AREA AND APPLY SEVERAL LIGHT COATS OF
A NON-SOLVENT BASED WHITE SPRAY ENAMEL. ALLOW TO FULLY DRY AND REPEAT IF NECESSARY.
