OPERATING INSTRUCTIONS

FOR MODEL F6-DP

Certified to CSA

STD C22�2 No� 120

TABLE OF CONTENTS

SAFETY FIRST �� 3

EPA CERTIFICATION�� 3

PRODUCT SAFETY �� 3

RESPONSIBILITY �� 3

COPYRIGHT AND DECLARATION OF CONFORMITY�� 4

SAFETY PRECAUTIONS�� 5

SPECIFICATIONS, FEATURES AND WARRANTY �� 6

F6-DP SPECIFICATIONS�� 6

WARRANTY �� 6

ANATOMY OF THE F6 �� 7

SETUP AND OPERATION �� 8

GETTING STARTED�� 8

STANDARD RECOVERY OPERATION �� 9

PURGING F6-DP �� 10

PUSH-PULL OPERATION �� 11

COOLING THE RECOVERY TANK�� 11

SPECIAL OPERATING NOTES�� 12

MAINTENANCE��13

TROUBLESHOOTING ��13

SERVICE��14

EPA REQUIREMENTS��14

TM2

JB INDUSTRIES F6-DP OPERATING MANUAL

Thank you for buying the JB Industries F6-DP Refrigerant Recovery Machine�

For optimal F6-DP performance, read this manual carefully before use�

For additional questions or assistance, contact JB Industries� USA: +1.800.323.0811

or sales@jbind.com

SAFETY FIRST

This symbol is intended to alert the presence of critical items regarding operating,

safety and maintenance (servicing) instructions in this manual�

EPA CERTIFICATION

JB Industries F6-DP is an EPA Certiﬁed machine in accordance with Section 608 of the Clean

Air Act� It has been independently tested and certiﬁed to conform with AHRI standard 740�

PRODUCT SAFETY

F6-DP is a recovery machine for a broad range of refrigerants� Recovering refrigerants into

separate storage tanks involves a process of gas compression, resulting in high pressures

within the machine, the connecting hoses, and the storage tank�

High pressure systems can cause accident or injury if not handled properly,

and with care�

Refrigerant hoses must have shut-off devices within 30�5 cm (12 in�) of the ends, to reduce the

likelihood of refrigerant leakage to the atmosphere when changing tanks or setups�

RESPONSIBILITY

Do not use F6-DP unless properly trained in the recovery process� Operation of this machine

by unqualiﬁed personnel is potentially dangerous�

3

JB INDUSTRIES

F6-DP OPERATING MANUAL

COPYRIGHT AND DECLARATION OF CONFORMITY

Reproduction or adaptation of any part of this manual without permission is unlawful�

This is to certify that this equipment, designed and manufactured by JB Industries Inc�,

601 N Farnsworth Ave; Aurora, IL 60505 meets the essential safety requirements and is

placed on the market accordingly� It has been constructed in accordance with good

engineering practice in safety matters in force in the community and does not endanger

the safety of persons, domestic animals or property when properly installed and maintained

and used in applications for which it was made�

5005404

Equipment Description F6-DP Refrigerant Recovery Machine

Certications The F6-DP was tested and is certied to

CSA STD C22.2 No. 120 by an independant

testing laboratory

UL Veried

Authorized Representative Dave Madden

Product Manager

Any questions relative to this declaration or to the safety of JB Industries products

should be directed, in writing, to the quality assurance department at JB Industries, Inc�,

601 North Farnsworth, Aurora, IL 60505�

TM4

JB INDUSTRIES F6-DP OPERATING MANUAL

SAFETY PRECAUTIONS

Read this manual before using F6-DP to become familiar with its speciﬁcations and operation�

Review the Safety Data Sheets (SDS) and the Temperature/Vapor Pressure information for the

proper safety and handling requirements regarding the refrigerants being recovered�

Wear gloves, eye protection and foot protection when working on refrigeration systems�

Refrigerant vapor can be hazardous and its by-products can be lethal�

Motors and switches can generate sparks and can be especially dangerous in

ﬂammable environments� Work only in well-ventilated areas, with mechanical ventilation

that provides at least four air change rates per hour� Do not work in an enclosed

area without appropriate safety equipment� It may be necessary to install a separate

circulation fan�

Never use oxygen for leak detection� Oxygen can become an explosive mixture in the

presence of oil and pressure� Perform leak detection in accordance with recommended

practice only� For best results, use a refrigerant leak detector, such as JB Industries

Aurora or Prowler�

Never mix refrigerants� Use separate storage cylinders, hoses, and ﬁlters for each type

of refrigerant recovered� Store refrigerants in a cool, dry place�

Never overﬁll a storage container� Overﬁlled tanks can rupture and explode� Use a

refrigerant scale such as JB Industries ATLAS to prevent overﬁll�

When opening service or cylinder valves, open slowly, to ensure all connections are

secure and free of danger�

Disconnect power before moving or servicing F6-DP�

The risk of electric shock and exposure to hot compressor parts is possible if the

F6-DP covers are removed� F6-DP should only be opened by a qualiﬁed technician

who has been trained in basic electronics and refrigeration�

Use only the power cord supplied by JB Industries� If the cord is lost or damaged,

contact JB Industries for information on obtaining a replacement�

When connected to the F6-DP, extension cord wiring can overheat under conditions of

high current draw� If an extension cord is necessary, use the shortest possible length

and only size 14 AWG or larger for 115 V (ac) or 1�00 mm2 or larger

for 230 V (ac)�

Do not use F6-DP near open containers of gasoline or other ﬂammable liquids�

This product is designed for use with refrigerants only� Only approved for use with

A1 (nonﬂammable) and A2L (mildly ﬂammable) refrigerants� Any other uses of this

product are not recommended by JB Industries and could result in personal injury�

Use of this product other than intended is done at the user‘s own risk�

5

JB INDUSTRIES

F6-DP OPERATING MANUAL

SPECIFICATIONS, FEATURES AND WARRANTY

F6-DP SPECIFICATIONS

Refrigerants�� R-12, R-1234yf, R-134a, R-22, R-32, R-401A, R-401B,

R-401C, R-402A, R-402B, R-404A, R-407A, R-407B,

R-407C, R-408A, R-409A, R-410A, R-500, R-502, R-507

Power ��115 V (ac), 60 Hz, 12 A,

Protection �� High pressure switch cutoff at 550 PSI

(3�8 MPa, 38 bar) Compressor motor thermally protected

Pressure�� Low side design pressure 350 PSI (2�4 MPa, 24 bar)

High side design pressure 550 PSI (3�8 MPa, 38 bar)

Temperature ��Operating range 10 to 40°C (50 to 104°F)

Pollution degree ��2

Ingress protection��IP20

EPA Certication

(F6-DP) ��Certiﬁed for all refrigerants listed under categories III,

IV, & V in ARI standard 740

WARRANTY

JB Industries warrants the F6-DP Refrigerant Recovery Machine to be free from defects of

materials or workmanship for three years from the date of purchase� JB Industries does not

warrant any machine that has been subjected to misuse, negligence, or accident, or has been

repaired or altered by anyone other than JB Industries�

The compressor is warranted for a period of three years by the manufacturer� To keep this

warranty in force, a ﬁlter (included) must be used on the inlet port or hose at all times to

prevent particulates from entering the compressor� Failure to use the included ﬁlter will void the

compressor warranty�

JB Industries liability is limited to repairing or replacing, at its option, a defective machine or

part� If a defect arises, a valid claim must be received by JB Industries, with transportation

prepaid, no later than thirty (30) days after the warranty period expires� JB Industries will

determine whether the machine has malfunctioned due to defective materials or workmanship�

This warranty is in lieu of all other warranties, expressed or implied, whether of merchantability,

ﬁtness for a particular purpose, or otherwise� All such other warranties are expressly

disclaimed�

JB Industries shall have no liability in excess of the price paid to JB Industries for F6-DP-250,

plus return transportation charges prepaid� JB Industries shall have no liability for any

incidental or consequential damages� All such liabilities are excluded�

TM6

JB INDUSTRIES F6-DP OPERATING MANUAL

F6 FEATURES

ANATOMY OF THE F6

Heavy-Duty Metal Handle with

Comfortable Rubber Grip

-Micro-Channel Condenser

for Industry Leading

Recovery Rates

-Large Fan for Superior

Heat Dissipation

-1 Full Horsepower Motor

-Powerful Dual Piston Compressor

-Circuit Breaker

-Simple Two-Valve Operation

Carrying Strap with

Shoulder Pad

Rugged Blow Molded

Outer Shell

Recessed Gauges

Sturdy Metal Knobs

Easy-to-Access

Filter

Detachable and

Replaceable Power

Cord for Easy

Maintenance

Self-Purge Without

Changing Hoses

7

JB INDUSTRIES

F6-DP OPERATING MANUAL

SETUP AND OPERATION

GETTING STARTED

Review the full contents of this manual before operating the F6-DP�

Failure to follow proper safety precautions can result in personal injury or death�

Do not use the F6-DP unless properly trained in the recovery process�

1Install the included ﬁlter on the inlet� F6-DP has a female refrigerant ﬂare ﬁtting,

and connects with male ﬂare ﬁttings� Ensure the protective plugs are removed

from the ﬁlter�

2Attach the hoses to the ﬁlter�

Do not use an adapter ﬁtting in place of a ﬁlter� Use of an adapter ﬁtting can

damage the valves and will void the warranty�

3Attach a hose from the discharge valve to the recovery tank� Connect other hoses

between system components as shown in Figure 1 on page 9�

4Connect the AC power cord to a circuit protected by an appropriately sized circuit

breaker� If an extension cord is absolutely necessary, make sure it meets the

following conditions:

• Length is not excessive

• Contains a safety ground wire

• Wire size 14 AWG or larger for 115 V (ac) or 1.0 mm2 or larger for 230 V (ac)

Overﬁlled tanks can rupture and explode� When operating in standard recovery or push-pull

mode, it is possible to overﬁll the tank� Use a refrigerant scale to ensure that the tank does not

exceed 80% of its capacity by weight� Check the tank weight before transporting�

Do not allow the F6-DP to recover large amounts of liquid too quickly�

NOTE: During the refrigerant recovery process, when a signiﬁcant amount of liquid is

present and enters the recovery machine too quickly, it can sometimes be

referred to as a “liquid slug” or “slugging�”

A liquid slug can activate the High Pressure shutoff and prolong the refrigerant recovery

process� If the F6-DP recovers large amounts of liquid too quickly (or a liquid slug is present),

a loud knocking will sound from the compressor�

Compressor damage caused by recovering a large amount of liquid too quickly is not covered

by the compressor warranty�

Monitor the recovery process carefully� If the compressor begins to knock:

• Throttle the INLET valve clockwise, or

• Adjust the MANIFOLD gauge valves until the knocking stops.

TM8

JB INDUSTRIES F6-DP OPERATING MANUAL

STANDARD RECOVERY OPERATION

1 Connect all cables and hoses as described in Setup and Operation on page 8�

NOTE: Make sure all connections are tight, and that the cables and

hoses do not interfere with the recovery process (See Figure 1).

2 Make sure the hose connecting the F6-DP to the recovery tank is attached to

the LIQUID port (LP)�

3 OPEN the LP valve on the tank — Keep the VAPOR port CLOSED�

4 Rotate the INLET valve (V1) to CLOSE�

5 Set the PURGE/RECOVER valve (V2) to the RECOVER position�

6 Slowly rotate the LIQUID valve on the MANIFOLD gauge to OPEN� Make sure there

are no leaks�

7 Turn on F6-DP�

8 Monitor the inlet pressure (LP, Low Pressure Gauge) and slowly rotate the INLET valve

(V1) to OPEN�

The compressor may emit a knocking sound if the F6-DP attempts to recover a

signiﬁcant amount of liquid� To prevent damage to the compressor, throttle the LIQUID

valve on the MANIFOLD gauge set, or the F6-DP INLET valve (V1)�

9 Once the liquid has been recovered, transfer the remaining vapor; rotate the INLET

valve (V1) to OPEN� Make sure the LIQUID and VAPOR valves on the MANIFOLD

gauge are OPEN�

Figure 1 - Setup Procedure for Standard Refrigerant Recovery

9

JB INDUSTRIES

F6-DP OPERATING MANUAL

10 Continue to operate until the LP gauge indicates the required vacuum has been

obtained�

11 Turn off the F6-DP and close the INLET valve (V1) — Wait ﬁve minutes�

If the MANIFOLD gauge indicates pressure has risen above 0 PSIG (0 bar), refrigerant is

still present�

• Open the INLET valve (V1) and turn on F6-DP.

• Run the F6-DP until the required vacuum is reached again.

• Wait ﬁve minutes. Repeat this process until all refrigerant is removed and

pressure is 0 PSIG (0 bar), or less.

12 Immediately purge the F6-DP� Purging is necessary to remove any residual

refrigerant from inside the F6-DP internal components as well as the hose from

the outlet to the recovery tank� Refer to Purging the F6-DP and Figure 2 below�

PURGING F6-DP

1 While the F6-DP is off, rotate the PURGE/RECOVER valve (V2) to PURGE�

See (See Figure 2).

2 Turn on the F6-DP and slowly rotate the INLET valve (V1) to PURGE�

3 Run the F6-DP and monitor the LP gauge until a vacuum of 20 In/Hg (0�7 bar)

or more is achieved�

4 Turn off the F6-DP and immediately close the valves on the recovery tank�

Rotate the inlet valve (V1) to CLOSE�

The hose and the discharge port will contain a small amount of pressurized refrigerant�

Exercise care when removing this hose�

Figure 2 - Setup Procedure for Purging

TM10

JB INDUSTRIES F6-DP OPERATING MANUAL

COOLING THE RECOVERY TANK

The F6-DP can be used to pre-cool (or sub-cool) the recovery tank, if the head pressure is too

high to complete the recovery process� If the ambient pressure is too high, high head pressure

can occur when working with certain refrigerants that have a high vapor pressure�

NOTE: The recovery tank must contain ﬁve pounds or more of liquid,

to allow the pressure differential to develop�

Sub-cooling the tank before starting the recovery process may provide little or no beneﬁt�

If the recovery process stalls because of high head pressure, turn off the F6-DP, close the

hose valves, and reconﬁgure the setup as shown in (See Figure 4).

PUSH-PULL OPERATION

The push-pull recovery method is used to move large amounts of liquid refrigerant� During

this process, the recovery unit pulls vapor from the recovery cylinder and produces a high

pressure discharge gas that pushes liquid out of the HVAC system and back into the recovery

cylinder� Recovery rates above 15 pounds per minute can be achieved when using this

procedure�

NOTE: Do not attempt the push-pull process unless the system contains

at least 15 pounds (7 Kg) of liquid that can be easily isolated�

To prevent overﬁll, use the scale to make sure the tank does not surpass 80% capacity

by weight� Monitor the tank weight carefully as 80% capacity maybe reached quickly during

push-pull due to its rapid transfer�

Connect the refrigerant hoses (See Figure 3). A sight glass, not included, can help determine

when the liquid has been transferred and vapor remains�

Figure 3 - Setup Procedure For Push-Pull Method

11

JB INDUSTRIES

F6-DP OPERATING MANUAL

1 Rotate V2 on the F6-DP to RECOVER and open the LIQUID and

VAPOR valves on the cylinder�

2 Turn on the F6-DP�

3 Rotate V1 to OPEN�

4 On the cylinder, throttle the ﬂow of liquid by slowly closing the LIQUID

valve to achieve a minimum pressure differential of 100 PSIG (0�7 MPa, 7 bar)

between the LP and the HP gauges�

NOTE: To prevent the HP cutoff switch from actuating, do not allow the

HP gauge to exceed 550 PSIG (3�8 MPa, 38 bar)�

5 Once the recovery tank is cold, turn off the F6-DP and reconﬁgure the

setup for standard recovery� Repeat as needed�

SPECIAL OPERATING NOTES

During standard operation, the High Pressure switch will reset when the head pressure drops

below approximately 425 PSI (2�9 MPa, 29 bar), and the F6-DP will restart automatically�

Figure 4 - Setup Procedure for Sub-Cooling Method

TM12

JB INDUSTRIES F6-DP OPERATING MANUAL

MAINTENANCE

With minimal but important maintenance, the F6-DP can provide many seasons of reliable

service� After each use, clean the F6-DP with a damp cloth to remove dirt and oils�

Do not use gasoline or other hazardous solvents to clean F6-DP; this can damage the

plastic enclosure� Standard household detergent or isopropyl alcohol may be used, but

do not allow liquid to penetrate the outer case�

Make sure the inlet and discharge ports are protected during transit and storage; keep the

inner diameter and the outer threads clear and clean�

NOTE: For best results, leave the ﬁlter connected to the inlet port,

and change the ﬁlter regularly�

TROUBLESHOOTING

PROBLEM CAUSE ACTION

F6-DP will not turn

on; compressor does

not start

1. Power cord is not attached

2. No voltage at receptacle

3. Circuit breaker has opened

4. Discharge pressure is too high;

HP switch has opened

5. Electronics failure in motor

1. Attach power cord

2. Verify voltage at job site

3. Identify cause of breaker

activation, rectify and reset

4. Reduce pressure; rotate V2 to

Purge, then back to Recovery

5. Factory service required

Compressor starts,

but falters within

minutes; pressure

indication on HP

gauge is high

1. Recovery tank valve is not open

2. Discharge hose blocked

3. Air in system/tank

1. Open tank valve

2. Check and clear blockage

3. Bleed air from system/tank

Compressor stops

intermittently

1. Vapor pressure of refrigerant in

tank is close to HP trip point

2. Thermal overload switch in

compressor is activating

1. Reduce tank temperature

2. Reduce amount of liquid being

pumped; let machine cool

before proceeding

13

JB INDUSTRIES

F6-DP OPERATING MANUAL

EPA REQUIREMENTS

Under Section 608 of the Clean Air Act (40 CFR Part 82), the Environmental Protection Agency

(EPA) has established regulations that cover all aspects of the refrigerant recovery process�

These regulations have established service practices that maximize the recycling of ozone-

depleting compounds during the servicing and disposal of air-conditioning and refrigeration

equipment�

Certiﬁcation requirements for recovery equipment and technicians have also been

established� The JB Industries F6-DP has been EPA Certiﬁed for use by an independent

laboratory�

The EPA has also established Evacuation Requirements for HVAC/R equipment used for

service, to ensure that any release of CFCs or HCFCs to the atmosphere is minimized�

SERVICE

The F6-DP uses electrical components recognized by international safety agencies or

components that have been specially designed for this application�

Do not change any of these components, as it could compromise safety� All service

work must be performed at a JB Industries-approved facility to maintain the safety rating

and the warranty�

If defective, do not return F6-DP directly to the factory� For technical assistance or service

information, contact JB Industries or your wholesaler�

PROBLEM CAUSE ACTION

F6-DP overheats Excessive head pressure, due to:

1. High ambient temperature

2. Restricted discharge hose

3. Air in recovery tank

1. Reduce tank temperature

2. Check and clear restriction

3. Bleed air from tank

Recovery process

too slow

1. Head pressure is too high

2. System refrigerant is frozen

3. Compressor seals are worn

1. Reduce tank temperature or

change tanks

2. Interrupt process to allow ice to

dissipate

3. Rebuild compressor with

service kit — contact wholesaler

for assistance

TM14

JB INDUSTRIES F6-DP OPERATING MANUAL

EPA REQUIREMENTS (CONTINUED)

• Technicians repairing small appliances such as household refrigerators, window air

conditioners and water coolers, must recover 80% of the refrigerant when the compressor in

the appliance is not operating.

• Technicians repairing small appliances must recover 90% of the refrigerant when the

compressor in the appliance is operating.

NOTE: These requirements may also be met by evacuating the small appliance

with the recovery machine to four inches of mercury vacuum�

Other requirements are covered in the following table:

TYPE OF APPLIANCE REQUIRED INCHES OF

HG VACUUM

HCFC-22 appliance generally containing less than 200 pounds of

refrigerant

0

HCFC-22 appliance generally containing 200 pounds or more or

refrigerant

10

Other high pressure appliance generally containing less than

200 pounds of refrigerant

10

Other high pressure appliance generally containing 200 pounds

or more of refrigerant

15

Very high pressure appliance (CFC-13, -503) 0

Low Pressure appliance (CFC-11, HCFC-123) 25*

*mm Hg absolute

The EPA requires that service technicians certify the acquired recovery equipment to the

appropriate EPA Regional Ofﬁce, and that it is in compliance with the applicable laws

established by the Clean Air Act� Forms are available from the Regional Ofﬁce of the EPA�

Questions about the EPA requirements can be answered by contacting the Ozone Protection

Hotline, toll free, at +1.800.296.1996�

15

JB INDUSTRIES

F6-DP OPERATING MANUAL

THANK YOU FOR

PURCHASING

THE F6

TO SEE THE FULL LINE

OF JB PRODUCTS

VISIT US AT JBIND.COM

DS-20000S

WIRELESS REFRIGERANT

CHARGING SCALE

PATRIOTTM 2-VALVE

MANIFOLD

KOBRA® CLE

SERIES HOSE

EMPTY REFRIGERANT

TANK CYLINDERS

PATRIOTTM 2-VALVE

MANIFOLD

ÍNDICE

NORMAS DE SEGURIDAD �� 18

CERTIFICACIÓN DE LA EPA�� 18

SEGURIDAD DEL PRODUCTO�� 18

RESPONSABILIDAD�� 18

DERECHOS DE AUTOR Y DECLARACIÓN DE CONFORMIDAD�� 19

PRECAUCIONES DE SEGURIDAD��20

ESPECIFICACIONES, FUNCIONES Y GARANTÍA��21

ESPECIFICACIONES DE F6-DP�� 21

GARANTÍA�� 21

ANATOMÍA DE LA F6 ��22

CONFIGURACIÓN Y FUNCIONAMIENTO ��23

PRIMEROS PASOS�� 23

FUNCIONAMIENTO DE LA RECUPERACIÓN ESTÁNDAR �� 24

PURGA DE F6-DP �� 25

FUNCIONAMIENTO DEL MÉTODO PUSH-PULL �� 26

REFRIGERACIÓN DEL DEPÓSITO DE RECUPERACIÓN �� 26

NOTAS SOBRE EL FUNCIONAMIENTO ESPECIAL �� 27

MANTENIMIENTO��28

RESOLUCIÓN DE PROBLEMAS ��28

REVISIÓN ��29

REQUISITOS DE LA EPA ��29

17

JB INDUSTRIES

F6-DP INSTRUCCIONES DE FUNCIONAMIENTO

Le agradecemos que haya comprado el Equipo de recuperación de refrigerante F6-DP de JB

Industries� Para conseguir un rendimiento óptimo de F6-DP, lea este manual detenidamente

antes de usar el equipo�

Si tiene preguntas adicionales o necesita ayuda, póngase en contacto con JB Industries�

Estados Unidos: +1.800.323.0811 o sales@jbind.com

NORMAS DE SEGURIDAD

El objetivo de este símbolo consiste en advertir al usuario de la existencia de aspectos

importantes relacionados con las instrucciones de mantenimiento (revisión), seguridad

y funcionamiento de este manual�

CERTIFICACIÓN DE LA EPA

JB Industries F6-DP es un equipo certiﬁcado por la EPA de conformidad con la sección 608

de la ley estadounidense de aire limpio (Clean Air Act)� Asimismo, se ha probado y certiﬁcado

de forma independiente para cumplir la norma ARI 740 de Intertek�

SEGURIDAD DEL PRODUCTO

F6-DP es un equipo de recuperación para una amplia gama de refrigerantes� La recuperación

de refrigerantes en depósitos de almacenamiento independientes implica un proceso de

compresión de gas que provoca altas presiones en el equipo, las mangueras de conexión y el

depósito de almacenamiento�

Los sistemas de alta presión pueden provocar accidentes o lesiones si no se

manipulan correctamente y con cuidado�

Las mangueras refrigerantes deben incluir dispositivos de parada a unos 30,5 cm

(12 pulgadas) de los extremos para reducir la probabilidad de fuga de refrigerante a la

atmósfera al cambiar los depósitos o las conﬁguraciones�

RESPONSABILIDAD

No utilice F6-DP a menos que haya recibido la formación adecuada en el proceso de

recuperación� El uso de este equipo por parte de personal que no esté cualiﬁcado

puede ser peligroso�

TM18

JB INDUSTRIES F6-DP INSTRUCCIONES DE FUNCIONAMIENTO

DERECHOS DE AUTOR Y DECLARACIÓN DE CONFORMIDAD

Es ilegal reproducir o adaptar cualquier parte de este manual sin permiso�

Por la presente se certiﬁca que este equipo, diseñado y fabricado por JB Industries Inc�, 601

N Farnsworth Ave; Aurora, IL 60505, EE� UU�, cumple los requisitos de seguridad esenciales y

se comercializa en el mercado de acuerdo con ellos� Se ha fabricado de acuerdo con buenas

prácticas de ingeniería en cuestiones de seguridad vigentes en la Comunidad y no representa

un peligro para la seguridad de las personas, animales domésticos o propiedades siempre

que se instale y se mantenga adecuadamente y se use para las aplicaciones para las que

está destinado�

5005404

Equipment Description Máquina de recuperación de refrigerante F6-DP

Certicaciones/acreditaciones La unidad F6-DP se ha probado y certicado de

acuerdo con la norma CSA STD C22.2 N.º 120 por

un laboratorio de ensayos independiente.

Vericada por UL

Representante autorizado Dave Madden

Jefe de producto

Todas las preguntas relacionadas con esta declaración o con la seguridad de los productos

de JB Industries se deben dirigir por escrito al departamento de garantía de calidad en la

dirección indicada anteriormente� 601 North Farnsworth, Aurora, IL 60505 (EE� UU)�

19

JB INDUSTRIES

F6-DP INSTRUCCIONES DE FUNCIONAMIENTO

PRECAUCIONES DE SEGURIDAD

Lea este manual antes de utilizar F6-DP para familiarizarse con sus especiﬁcaciones y

su funcionamiento� Revise las hojas de datos sobre la seguridad de materiales (MSDS)

y la información sobre temperatura y presión de vapor para conocer los requisitos de

manipulación y seguridad adecuados con relación a los refrigerantes que se van a recuperar�

Use guantes, gafas protectoras y calzado de seguridad cuando trabaje con sistemas

de refrigeración�

El vapor refrigerante puede ser peligroso y su inhalación a través de los productos

puede ser letal�

Los motores y conmutadores pueden generar chispas y ser especialmente peligrosos

en entornos inﬂamables� Trabaje solo en zonas que estén bien ventiladas, con

ventilación mecánica que proporcione al menos cuatro renovaciones de aire por

hora� No trabaje en un área cerrada sin el equipo de seguridad adecuado� Puede ser

necesario instalar un ventilador de circulación independiente�

No utilice nunca oxígeno para la detección de fugas� El oxígeno se puede convertir en

una mezcla explosiva en presencia de combustible y presión� Realice una detección de

fugas de conformidad únicamente con la práctica recomendada� Para obtener mejores

resultados, utilice un detector de refrigerante como, por ejemplo, JB Industries Aurora o

Prowler�

No mezcle nunca los refrigerantes� Utilice ﬁltros, mangueras y cilindros de

almacenamiento independientes para cada tipo de refrigerante recuperado� Almacene

los refrigerantes en un lugar frío y seco�

No llene nunca el contenedor de almacenamiento en exceso� Los depósitos llenados

en exceso pueden romperse y explotar� Utilice una balanza para refrigerante como, por

ejemplo, JB Industries ATLAS para evitar el llenado�

Al abrir válvulas de cilindro o de mantenimiento, hágalo lentamente para garantizar que

todas las conexiones estén bien sujetas y fuera de peligro�

Desconecte la electricidad antes de mover F6-DP o realizar tareas de mantenimiento en

el equipo�

Si se retiran las cubiertas de F6-DP, puede existir el riesgo de descarga eléctrica y

de exposición a las piezas calientes del compresor� F6-DP solo debe abrirse por un

técnico cualiﬁcado que haya recibido formación en electrónica básica y refrigeración�

Utilice únicamente el cable de alimentación proporcionado por JB Industries� Si el

cable se ha perdido o ha sufrido daños, póngase en contacto con JB Industries para

obtener información sobre cómo solicitar uno de recambio�

Al conectarse a F6-DP, los cables de extensión pueden sobrecalentarse en

condiciones de consumo alto de corriente� Si es necesario utilizar un cable de

extensión, utilice el que tenga la longitud más corta posible y un calibre mínimo de 14

AWG para una corriente de 115 V (CA) o de 1 mm2 para una corriente de 230 V (CA)�

No utilice F6-DP cerca de contenedores abiertos de gasolina u otros líquidos

inﬂamables�

Este producto está diseñado para utilizarlo únicamente con refrigerantes� Solo está

aprobado para utilizarlo con refrigerantes de tipo A1 (no inﬂamables) y A2L (ligeramente

inﬂamables)� JB Industries no recomienda ningún otro uso para este producto, ya que

podría provocar daños personales; el uso del producto en situaciones diferentes a las

previstas queda bajo responsabilidad del usuario�

TM20

JB INDUSTRIES F6-DP INSTRUCCIONES DE FUNCIONAMIENTO

JB INDUSTRIES F6-DP User manual

Popular Heating System manuals by other brands
