JBL CS205E User manual

THANK YOU
for purchasing JBL CS Series®
automotive speakers. We’ve organized this manual
to make your installation as simple and trou le-free as
possi le. Please read it thoroughly efore proceeding.
Remem er to keep your sales receipt and this manual
in a safe place so oth are availa le for future reference.
multielements
owner’s manual
English

INSTALLATION
Figure 1. Mounting the Speaker using the supplied grille.
Figure 2. Mounting the CS265 using the supplied grilles.
Rotate tweeter so it is angled toward the listener using the
UniPivot™(patent no. 6,002,780) feature on the Speaker.
Figure 3. Mounting the CS265 in 165mm speaker locations.
Rotate tweeter so it is angled toward the listener using the UniPivot™
(patent no. 6,002,780) feature on the speaker.
INSTALLATION WARNINGS AND TIPS
ABOUT THESE
INSTRUCTIONS
Installation of automotive stereo
components can require extensive
experience with a variety of
mechanical and electrical proce-
dures. Although these instructions
explain how to install CS Series
multielement speakers in a general
sense, they do not show the exact
installation methods for your
particular vehicle. If you do not feel
you have the experience, do not
attempt the installation yourself,
ut instead ask your authorized JBL
car audio dealer a out professional
installation options.
LOUD MUSIC AND
HEARING
Playing loud music in an automo-
ile can hinder your a ility to hear
traffic as well as permanently dam-
age your hearing. The maximum
volume levels achieva le with
JBL speakers, com ined with high
power amplification, may exceed
safe levels for extended listening.
We recommend using low volume
levels when driving. JBL accepts
no lia ility for hearing loss, odily
injury, or property damage as a
result of use or misuse of this
product.
REAR DECK
RECAUTION
In some cars, fuel tanks may e
located directly eneath the rear
deck. Before installation, make
sure there is adequate speaker
asket clearance efore consider-
ing this location!
INSTALLATION TI S
• Always wear protective eyewear
when using any tools.
• Turn off all audio components
and other electrical devices
efore you start. Disconnect the
(–) negative lead from your
vehicle’s attery.
• Keep speakers in their package
until final installation. When
moving a speaker, always rest it
with the cone or dome facing up.
Never use force to install any
speaker.
• Check clearances on oth sides
of a planned mounting surface
efore drilling any holes or
installing any screws. Remem er
that the screws can extend
ehind the surface.
• At the installation sites, locate
and make a note of all fuel lines,
hydraulic rake lines, vacuum lines
and electrical wiring. Use extreme
caution when cutting or drilling in
and around these areas.
• Before drilling or cutting holes,
use a utility knife to remove
unwanted fa ric or vinyl, to keep
material from snagging in a drill
it or saw.
• For door installations, check the
clearance with the windows
throughout the range of the
window’s travel, and verify that a
mounted speaker will not
interfere with the window crank
or power window mechanism.
• If mounting speakers elsewhere,
check for clearance around rear
deck torsion ars, glove ox or
other structural elements.
• Do not mount speakers where
they will get wet.
English

English
SPECIFICATIONS
Declaration of Conformity
We, Harman Consumer International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products
described in this owner’s manual are in compliance
with technical standards:
EN 50081-1:1992
EN 50082-1:1997
Emmanuel Millot
Harman Consumer International
Chateau-du-Loir, France. 2/03
JBL Consumer Products
250 Crossways Park Drive, Wood ury, NY 11797 USA
1.800.336.4JBL (4525) • FAX [phone] • www.j l.com
© 2003 Harman International Industries, Incorporated
JBL is a registered trademark of
Harman International Industries, Incorporated.
Part No. CSMEOM2/03
CS205 CS265 CS308 CS310 CS396
Type: 130mm two-way 165mm two-way 200mm two-way 250mm three-way 150 x 230mm three-way
Speaker 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Impedance:
Power 90W Peak 120W Peak 210W Peak 270W Peak 210W Peak
Handling: 30W RMS 40W RMS 70W RMS 90W RMS 70W RMS
Sensitivity
(2.83V, 1m): 91dB 91dB 91dB 92dB 91dB
Frequency
Response: 70Hz – 20kHz 55Hz – 20kHz 50Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Mounting
Depth: 58mm 61mm 77mm 107mm 77mm
Cut-Out
Diameter: 120mm 145mm 183mm 234mm 224mm x 153mm
General Care
The loudspeaker grilles may e cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
A valid serial num er is required for warranty coverage.
Features, specifications and appearance are su ject to change without notice.
