BALBOA SERIES
®
OWNER’S GUIDE
MODEL: BALBOA 10
SPEAKER PLACEMENT
Proper placement of the
speakers is an important step
in obtaining the most realistic
soundstage possible. These
recommendations are for the
optimal placement of the loud-
speakers. Use these place-
ment recommendations as a
guide. Slight variations will not
diminish your listening plea-
sure. All of the Balboa Series
As front speakers
MODEL: BALBOA 30
As surround speakers
MODEL: BALBOA CENTER
The Balboa enter loud-
speaker is designed to com-
plement all of the Balboa
Series loudspeakers. It is the
ideal way to re-create the
cinematic experience in your
home.
† Placement for surround back
speakers in 6.1/7.1 systems, or
alternate placement for side
surround speakers in 5.1 sys-
tems.
loudspeakers referred to in
this guide are video-shielded
and can safely be placed near
a television.
All manuals and user guides at all-guides.com
all-guides.com

MODELS:
BALBOA 10 AND
BALBOA CENTER
The supplied self-adhesive
rubber feet may be attached
to the bottom corners of your
speakers to protect your
furniture.
MODEL: BALBOA 30
This model is shipped with
four self-adhesive nonskid
pads that are to be used when
the loudspeaker is intended
to be placed on a smooth-
surfaced floor, such as tile or
hardwood. Gently lay the
speaker on its side (not its
front or back) on a soft, non-
abrasive surface. Attach each
pad to the bottom of its foot in
the widest portion of the
recessed area.
DO NOT attach the pads if
the speaker will be placed
on carpeting.
NEVER drag the speaker to
move it, as this will damage
the pads, the feet and/or the
wood cabinet itself. Always
lift the speaker and carry it to
its new location.
CAUTION: Floorstanding
(tower) loudspeakers have a
high center of gravity and may
become unstable and tip over
during earthquakes, or if
rocked, tipped or improperly
positioned. If this is a concern,
these speakers should be
anchored to the wall behind
them, using the same proce-
dures and hardware custom-
ary for anchoring bookcases
and wall units. The customer
is responsible for proper
installation and proper selec-
tion of hardware.
Without pad With pad
Place pads here
SPEAKER PLACEMENT (CONTINUED)
MODELS:
BALBOA 10 AND
BALBOA 30
MODEL:
BALBOA CENTER
Speakers and electronics ter-
minals have corresponding (+)
and (–) terminals. It is impor-
tant to connect both speakers
identically: (+) on the speaker
to (+) on the amplifier and (–)
on the speaker to (–) on the
amplifier. Wiring “out of
phase” results in thin sound,
weak bass and poor imaging.
With the advent of multichan-
nel surround sound systems,
connecting all of the speakers
in your system with the cor-
rect polarity remains equally
important in order to preserve
the proper ambience and
directionality of the program
material.
To use the binding-post
speaker terminals, unscrew
the colored collar until the
pass-through hole in the cen-
ter post is visible. Insert the
bare end of the wire through
this hole; then screw the col-
lar down until the connection
is tight.
The hole in the center of each
collar is intended for use with
banana-type connectors. To
comply with European E cer-
tification, these holes are
blocked with plastic inserts at
the point of manufacture. Use
of banana-type connectors
requires the removal of the
inserts. Do not remove these
inserts if you are using the
product in an area covered by
the European E certification.
Receiver
Speaker Outputs
– +
CENTER
– +
– +– +
– +
Receiver’s Speaker Outputs
LEFT
LEFT
RIGHT
RIGHT
– +
SPEAKER CONNECTIONS
All manuals and user guides at all-guides.com

English
TROUBLESHOOTING
If there is no soun from any
of the speakers:
• heck that receiver/ampli-
fier is on and that a source is
playing.
• Review proper operation of
your receiver/amplifier.
If there is no soun coming
from one speaker:
• heck the “Balance” control
on your receiver/amplifier.
• heck all wires and connec-
tions between receiver/ ampli-
fier and speakers.
• Make sure no wires are
touching other wires or
terminals and creating a short
circuit.
• Make sure all wires are con-
nected. Make sure none of the
speaker wires are frayed, cut
or punctured.
• In Dolby* Digital or DTS®
modes, make sure that the
receiver/processor is config-
ured so that the speaker in
question is enabled.
• Turn off all electronics and
switch the speaker in question
with one of the other speakers
that is working correctly. Turn
everything back on, and deter-
mine whether the problem has
followed the speaker, or has
remained in the same channel.
If the problem is in the same
channel, the source of the
problem is most likely with
your receiver or amplifier, and
you should consult the
owner’s manual for that prod-
uct for further information. If
the problem has followed the
speaker, consult your dealer
for further assistance or, if that
is not possible, visit
www.jbl.com
for further information.
If the system plays at low vol-
umes but shuts off as volume
is increase :
• heck all wires and con-
nections between receiver/
amplifier and speakers.
• Make sure all wires are con-
nected. Make sure none of the
speaker wires are frayed, cut
or punctured.
• If more than one pair of main
speakers is being used, check
the minimum impedance
requirements of your receiver/
amplifier.
If there is no (or low) bass
output:
• Make sure the polarities
(+ and –) of the left and right
“Speaker Inputs” are
connected properly.
• If your system includes a
powered subwoofer, make
sure it is connected correctly,
plugged into an active A out-
let and turned on. See the
owner's guide for your sub-
woofer for more information.
• If your system does not
include a powered subwoofer,
consider adding one for use
with digital “.1” surround for-
mats.
If there is no soun from
the surroun speakers:
• heck all wires and connec-
tions between receiver/ampli-
fier and speakers. Make sure
all wires are connected. Make
sure none of the speaker
wires are frayed, cut or punc-
tured.
• Review proper operation of
your receiver/amplifier and its
surround sound features.
• Make sure the movie or TV
show you are watching is
recorded in a surround sound
mode. If it is not, check to see
whether your receiver/ampli-
fier has other surround modes
you may use.
• In Dolby Digital or DTS
modes, make sure your
receiver/processor is config-
ured so that the surround
speakers are enabled.
• If you are using both side
surround and back surround
speakers, make sure that your
receiver/processor is config-
ured for 6.1/7.1 operation.
• Review the operation of your
DVD player and the jacket of
your DVD to make sure that
the DVD features the desired
Dolby Digital or DTS mode,
and that you have properly
selected that mode using both
the DVD player’s menu and the
DVD disc’s menu.
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products
described in this owner’s manual are in compliance
with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Gary Mardell
Harman Consumer Group International
Chateau-du-Loir, France 1/05
All manuals and user guides at all-guides.com

SPECIFICATIONS
* Trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
** The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
All features and specifications are subject to change without notice.
All dimensions include grilles and feet, but not spikes.
© 2005 Harman International Industries, Incorporated
JBL is a registered trademark, and IsoPower, FreeFlow and Straight-Line Signal
Path are trademarks, of Harman International Industries, Incorporated.
Part No.
406-000-05179
PRO SOUND COMES HOME™
JBL onsumer Products, 250 rossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, A 91329
2, route de Tours, 72500 hateau-du-Loir, France
516.255.4JBL (4525) www.jbl.com
BALBOA 10
Description
2-Way 130mm (5") bookshelf
Maximum Recommen e
Amplifier Power**
125W
Power Han ling
(Continuous/Peak)
60W/240W
Nominal Impe ance
8 Ohms
Sensitivity (2.83V/1m)
86dB
Frequency Response (–3 B)
68Hz – 20kHz
Crossover Frequency
3000Hz
High-Frequency Trans ucer
19mm (3/4") Titanium-laminate dome
Low-Frequency Trans ucer
130mm (5") Pure-cellulose fiber
cone, shielded
Baffle
Low diffraction, IsoPower™
Port
FreeFlow™flared
Network
Straight-Line Signal Path™(SSP)
Terminal
5-Way binding posts
Dimensions (H x W x D)
(With grille)
259mm x 165mm x 210mm
Weight per Speaker
3.9kg
BALBOA 30
Description
3-Way 170mm (6") floorstanding
Maximum Recommen e
Amplifier Power**
150W
Power Han ling
(Continuous/Peak)
80W/320W
Nominal Impe ance
8 Ohms
Sensitivity (2.83V/1m)
90dB
Frequency Response (–3 B)
47Hz – 20kHz
Crossover Frequencies
600Hz, 3500Hz
High-Frequency Trans ucer
19mm (3/4") Titanium-laminate
dome
Mi range Trans ucer
100mm (4") Pure-cellulose-fiber
cone, shielded
Low-Frequency Trans ucer
170mm (6") Pure-cellulose-fiber
cone, shielded
Baffle
Low diffraction, IsoPower™
Port
FreeFlow™flared
Network
Straight-Line Signal Path™(SSP)
Terminals
5-Way binding posts
Dimensions (H x W x D)
(With grille an feet)
889mm x 229mm x 321mm
Weight per Speaker
14.5kg
BALBOA CENTER
Description
2-Way dual 130mm (5") center
Maximum Recommen e
Amplifier Power**
150W
Power Han ling
(Continuous/Peak)
75W/300W
Nominal Impe ance
8 Ohms
Sensitivity (2.83V/1m)
90dB
Frequency Response (–3 B)
80Hz – 20kHz
Crossover Frequency
3500Hz
High-Frequency Trans ucer
19mm (3/4") Titanium-laminate
dome, shielded
Low-Frequency Trans ucer
Dual 130mm (5") Pure-cellulose fiber
cone, shielded
Baffle
Low diffraction, IsoPower™
Port
FreeFlow™flared
Network
Straight-Line Signal Path™(SSP)
Terminals
5-Way binding posts
Dimensions (H x W x D)
(With grille)
170mm x 479mm x 260mm
Weight per Speaker
6.9kg
