JCM GLOBAL DT-300 Series Quick setup guide

© 2013, Japan CashMachine Co., Limited
Support: http://www.jcmglobal.com/en/contact/default.aspx Web-Site: http://www.jcmglobal.com
Issue #4033-IGE-01-01
DT-300™Series
Download Tool
Operator Integration Guide
Revision 1, April 1, 2013
P/N 960-000167R_Rev. 1 {EDP #214645}

Copyright © 2013 By Japan CashMachine Co., Limited
DT-300™ Series Download Tool Operator Integration Guide
This product document (hereinafter referred to as “Manual”) is fully covered by legal Copyrights owned by the Japan
Cash Machine, Co., Ltd., (hereinafter referred to as “JCM”) under Japanese laws and foreign countries. This Manual
contains many copyrighted, patented or properly registered equipment items manufactured by JCM, that are prohibited
and illegal to duplicate, replicate, or copy in whole, or in part, without the express authorization by JCM with the following
exceptions:
1. When an authorized JCM agency or distributor duplicates the Manual for sales promotion and/or service 
maintenance of the product, or technical service personnel education as required; and
2. When an end user duplicates the Manual to maintain operation of the product or operate the product in general. 
JCM retains all rights to amend, alter, change or delete any portion of this Manual in whole, or in part, or add items 
thereto without notice regarding the product or its related products.
JCM is a registered trademark of Japan CashMachine Co, Limited. All other product names mentioned herein may be
registered trademarks or trademarks of their respective companies. Furthermore, ™, ®and © are not always mentioned
in each case throughout this publication.
International Compliance
• RoHS Directives
• CE Mark
• FCC Directives See below.
REVISION HISTORY
Rev №.Date Reason for Update Comment
A 10/09/12 Initial Document
1 4/1/13 Display change
or or or or
CE Warning
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
FCC NOTICE
This equipment complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
IC NOTICE
This class A digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la classe A est conforme a la norme NMB-003 du Canada.
Issue #4033-IGE-01-01

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
i
DT-300™ Series
Operator Integration Guide
Table of Contents Page
TOC
1 GENERAL INFORMATION......................................................................................1
Description.......................................................................................................................... 1
DT-300 Device .................................................................................................................... 1
2 COMPONENT NAMES ............................................................................................2
3 PRIMARY FEATURES.............................................................................................2
4 PRECAUTIONS........................................................................................................3
User Cautions ................................................................................................................................. 3
5 SPECIFICATIONS....................................................................................................4
Technical Specifications...................................................................................................... 4
Environmental Specifications.............................................................................................. 4
Electrical Specifications ...................................................................................................... 4
Structural Specifications...................................................................................................... 4
6 INSTALLATION .......................................................................................................5
Battery Installation .............................................................................................................. 5
SD Card Installation ............................................................................................................5
Installation to a PC or a Card Reader ............................................................................................. 5
SD Card Installation Into a DT-300 ................................................................................................. 5
DIP Switch Setting ..............................................................................................................6
Functions ............................................................................................................................ 6
Bootloader....................................................................................................................................... 6
MainApplication (Normal Mode)...................................................................................................... 6
Boot Mode........................................................................................................................... 6
Authentication ..................................................................................................................... 6
USB Cable Connection ....................................................................................................... 6
Operation Procedures 
(MainApplication) ................................................................................................................ 6
Firmware Update Function.............................................................................................................. 6
Statistics Function ........................................................................................................................... 7
Reviewing an Acceptance Log (Total)........................................................................................... 7
Display the Acceptance Log ......................................................................................................... 8
Enabling a Denomination Function............................................................................................... 8
Error Message Function ............................................................................................................... 9
Version Check Function................................................................................................................ 9
Maintenance Function .................................................................................................................. 9
Acceptance Log Function (Limited) ............................................................................................ 10
Display the Number of the Banknote Acceptance Log ............................................................... 10
Language Function ..................................................................................................................... 11
Operation Procedures 
(Bootloader) .......................................................................................................................11
DT-300 Firmware Update.............................................................................................................. 11
DT-300 EEPROM Update ............................................................................................................. 11
Power Management.......................................................................................................... 12
Monitoring Battery Charge Level .................................................................................................. 12
Battery Condition Display.............................................................................................................. 12
Sleep Mode................................................................................................................................... 12
Backlight Control........................................................................................................................... 13
Software Data File ........................................................................................................................ 13
Received Log File ......................................................................................................................... 13
Firmware File ................................................................................................................................ 13

Table of Contents
P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
ii
Page
DT-300™ Series Operator Integration Guide
EEPROM Data File........................................................................................................................13
7 CONNECTOR PIN ASSIGNMENTS...................................................................... 13
8 UNIT DIMENSIONS ............................................................................................... 14
DT-300 Entire Unit Outside Dimensions........................................................................................14
9 COMPATIBILITY ................................................................................................... 14
10 ERROR CODES .................................................................................................... 15
Bootloader Error Codes.................................................................................................................15
MainApplication Error Codes.........................................................................................................15
11 INTERNATIONAL COMPLIANCE......................................................................... 18
12 TECHNICAL CONTACT INFORMATION ............................................................. 19
America .........................................................................................................................................19
JCM American.............................................................................................................................19
Europe, Africa, Russia & Middle East ...........................................................................................19
JCM Europe GmbH.....................................................................................................................19
UK & Ireland ..................................................................................................................................19
JCM Europe (UK Office)..............................................................................................................19
Asia & Oceania..............................................................................................................................19
JCM Gold (HK) Ltd. .....................................................................................................................19
Japan Cash Machine Co, Limited (HQ).......................................................................................19
13 INDEX .................................................................................................................... 21

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
iii
DT-300™ Series
Operator Integration Guide
List of Figures Page
LOF
Figure 1 DT-300 BlueWaveDX Device........................................................................1
Figure 2 DT-300 Component Names..........................................................................2
Figure 3 Precautionary Symbols.................................................................................3
Figure 4 Type AAA Battery Installation .......................................................................5
Figure 5 SD Card Insertion (PC or Card Reader) .......................................................5
Figure 6 Model Name Creation...................................................................................5
Figure 7 Model Folder Creation ..................................................................................5
Figure 8 SD Card Insertion (DT-300) ..........................................................................5
Figure 9 Cable Connection .........................................................................................6
Figure 10 SD Card Confirmation Screen 1 ...................................................................6
Figure 11 Function Selection Screen 1 .........................................................................6
Figure 12 Select the Download File ..............................................................................7
Figure 13 Download Waiting Screen.............................................................................7
Figure 14 Flash ROM Erase Standby Screen...............................................................7
Figure 15 Software Downloading Screen......................................................................7
Figure 16 Software Download Verifying Screen ...........................................................7
Figure 17 Software Download Complete Screen ..........................................................7
Figure 18 SD Card Confirmation Screen 2 ...................................................................7
Figure 19 Function Selection Screen 2 .........................................................................7
Figure 20 Acceptance Log Standby Screen 1...............................................................7
Figure 21 Acceptance Log Reading Screen .................................................................8
Figure 22 Log Read Complete Screen..........................................................................8
Figure 23 SD Card Confirmation Screen 3 ...................................................................8
Figure 24 Function Selection Screen 3 .........................................................................8
Figure 25 Standby Screen 1 .........................................................................................8
Figure 26 Denomination Table Screen .........................................................................8
Figure 27 SD Card Confirmation Screen 4 ...................................................................9
Figure 28 Function Selection Screen 4 .........................................................................9
Figure 29 Standby Screen 2 .........................................................................................9
Figure 30 Active Error Code Indication Screen.............................................................9
Figure 31 SD Card Confirmation Screen 5 ...................................................................9
Figure 32 Function Selection Screen 5.........................................................................9
Figure 33 Standby Screen 3 .........................................................................................9
Figure 34 Version, CRC & Serial Number Screen ........................................................9
Figure 35 SD Card Confirmation Screen 6 ...................................................................9

List of Figures
P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
iv
Page
DT-300™ Series Operator Integration Guide
Figure 36 Function Selection Screen 6 ........................................................................ 9
Figure 37 Standby Screen 4......................................................................................... 9
Figure 38 Maintenance Request Screen.................................................................... 10
Figure 39 Maintenance Non-Request Screen ............................................................ 10
Figure 40 SD Card Confirmation Screen 7................................................................. 10
Figure 41 Function Selection Screen 7 ...................................................................... 10
Figure 42 Standby Screen 5....................................................................................... 10
Figure 43 Acceptance Log Reading Screen............................................................... 10
Figure 44 Log Read Complete Screen ....................................................................... 10
Figure 45 SD Card Confirmation Screen 8................................................................. 11
Figure 46 Function Selection Screen 8 ...................................................................... 11
Figure 47 Language Selection Screen ....................................................................... 11
Figure 48 Firmware Update Confirmation Screen ...................................................... 11
Figure 49 Firmware Update Progress Bar.................................................................. 11
Figure 50 Firmware Update Success Screen............................................................. 11
Figure 51 EEPROM Update Confirmation Screen ..................................................... 11
Figure 52 EEPROM Update Progress Bar ................................................................. 12
Figure 53 EEPROM Update Success Screen ............................................................ 12
Figure 54 Sleep Mode Screen.................................................................................... 12
Figure 55 DT-300 Download Tool Outside Dimensions ............................................. 14

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
v
DT-300™ Series
Operator Integration Guide
List of Tables Page
LOT
Table 1 DT-300 Technical Specifications....................................................................4
Table 2 DT-300 Environmental Specifications ............................................................4
Table 3 DT-300 Electrical Specifications.....................................................................4
Table 4 DT-300 Structural Specifications....................................................................4
Table 5 Boot Mode Selection ......................................................................................6
Table 6 Acceptance Log..............................................................................................8
Table 7 Reading Denomination Table.........................................................................8
Table 8 Log Storage Limit .........................................................................................10
Table 9 Acceptance Logs Available ..........................................................................10
Table 10 Performance and Battery Condition .............................................................12
Table 11 Battery Condition Indication .........................................................................12
Table 12 Various Sleep Mode Screens.......................................................................12
Table 13 Software Data File Information.....................................................................13
Table 14 Received Log Files.......................................................................................13
Table 15 Existing Firmware File ..................................................................................13
Table 16 EEPROM Data File Information ...................................................................13
Table 17 DT-300 USB Type “A” Pin Assignments ......................................................13
Table 18 DT-300 Compatible Validators .....................................................................14
Table 19 Bootloader Error Codes................................................................................15
Table 20 MainApplication Error Codes........................................................................15

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
vi
DT-300™ Series Operator Integration Guide
THIS PAGE INTENTIONALLY LEFT BLANK

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
1
DT-300™ Series
Download Tool
Operator Integration Guide
Revision 1
Description
This section provides a general overview of the 
DT-300™ “BlueWaveDX” Download Tool Device
pictured in Figure 1. This first section is designed
to help the user navigate through this guide with
ease and provides the following information:
• DT-300™ Device
• Component Names
• Primary Features
• Precautions
• Specifications
• Installation
• Connector Pin Assignments
• Functions
• Unit Dimensions
• Compatibility
• Technical Contact Information.
In order to make operation of this device easier and
make navigation within this manual simpler, the
following illustrations were used within the text:
• Safety Instructions,which need to be
observed in order to protect the operators and
equipment, have been written in bold text and
have been given the pictographs:
• Special Notes, which affect the use of the DT-
300™ Device, have been written in italic text
and have been given the pictograph:
• Steps, requiring the operator to perform
specific actions are given sequential numbers
(1., 2., 3., etc.).
1 GENERAL INFORMATION
DT-300 Device
Figure 1 DT-300 BlueWaveDX Device

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
2
DT-300™ Series Download Tool Operator Integration Guide
2 COMPONENT NAMES
Figure 2 illustrates the DT-300™ Functional Component Part Names and Locations.
3 PRIMARY FEATURES
The DT-300™ “BlueWave” Series Download Tool contains the following primary features:
• The DT-300™ is a battery-driven device. The DT-300 transfers the software data to the power-
supplied Validator.
• The DT-300™ features an LCD Display. The Bootloader update and the MainApplication function
selection are available by using the LCD Display. The Acceptance Log, Error Messages, Version/CRC/
Serial Number, Maintenance Condition, Enabled Denomination and Language Selection are also
confirmed by the LCD Display.
• Refer to “Operation Procedures (MainApplication)” on page 6 of this Guide for more details.
Figure 2 DT-300 Component Names
A. USB Connector Type A (Host)
B. LCD (Monochrome)
C. OK Button
D. CLR Button
E. Power LED (Red)
F. Direction Key Button
G. Power Switch
H. SD Card Slot
I. Battery Compartment Cover
J. Power Plug (Option)
K. Magnet
L. Magnet
A
B
C
D
E
F
G
H
I
K
J
L

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
3
DT-300™ Series Download Tool Operator Integration Guide
4 PRECAUTIONS
The Figure 3 symbols are defined as follows:
1. (Type 1) Do not use any other Cables except the
specified USB Type A Cable.
2. (Type 2) Do not expose the Unit to water. The
Unit contains several precision electronic devices
that can be damaged if water or any type of 
liquid is sprayed or spilled into the Unit.
3. (Type 3) Do not expose the Unit in a dusty 
environment.
U SER C AUTIONS
1. Do not use or store the DT-300™ at the fol-
lowing locations:
• In direct Sunlight
• In a dusty environment
• Areas likely to be wet or humid
• Vibrating areas
• Near hazardous materials.
2. Do not insert and/or drop foreign objects
such as metals or flammable substances into
the DT-300™ Unit.
3. Use “AAA” Alkaline size Batteries (LR03)
to Power the Unit. Be sure to turn the DT-
300’s Power OFF before replacing Batteries.
When replacing Batteries, change all four (4)
Batteries and install them in the correct direc-
tion.
4. Be sure to turn the DT-300’s Power OFF
before plugging or unplugging the USB
Cable. Be sure to remove the USB Cable by
firmly gripping on the plug and not on the
USB Cable itself.
5. Do not redesign or disassemble the 
DT-300™ Device. Disassembly and repair
should only be performed by a certified JCM
Service Center or a professional technician. 
Unauthorized repair, use by inadequately
trained personnel, or use outside the manu-
facture’s original intent voids the warranty.
6. Do not strike, drop or throw the DT-300™
Device. Contact the local JCM distributor
immediately when identified damage or
internal repair conditions exist.
7. When a communication error occurs, turn the
Validator’s Power Switch OFF and then turn
it to ON again.
8. Do not touch the SD Card when downloading
data. Be sure to turn the DT-300’s Power
Switch OFF before inserting or removing the
SD Card.
9. Be sure that the Cable length connected to
the V
alidator is less than 3m.
10. Using strong pressure or impact on the Func-
tion Buttons may damage the Buttons.
11. Do not put recording medium such as mag-
netic cards or magnetic tapes close to the DT-
300’s Magnet portion. The data recorded in
the medium may be damaged or erased.
Type 1 Type 2 Type 3
Figure 3 Precautionary Symbols
Caution: DO NOT use a new Battery
along with an old Battery together.
Doing so will decrease the life of
both Batteries, or Battery liquid
content seepage may occur.
Caution: Pulling on the USB Cable
alone may damage the cable and
cause a fire, electrical shock or
both. Also do not damage, break,
or redesign the recommended USB
Cable.
Caution: Do NOT touch or pull on
the connecting Cables with wet
hands; this may cause an electrical
shock, equipment damage or both.

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
4
DT-300™ Series Download Tool Operator Integration Guide
5 SPECIFICATIONS
Technical Specifications
Environmental Specifications
Electrical Specifications
Structural Specifications
Table 1 DT-300 Technical Specifications
Compatibility: UBA, iVIZION, VEGA, TBV, iPRO & RC Series Units
Processing Speed*:
*. Download Time depends on Models and/or files.
Software Download Time (from start to completion):
a) UBA-10 (USB): Approximately 60 seconds (Software Size/1MB)
b) UBA-14 (USB): Approximately 120 seconds (Software Size/2MB)
c) iVIZION (USB): Approximately 70 seconds (Software Size/8MB)
d) VEGA (USB): Approximately 34 seconds (Software Size/2MB)
e) TBV-100 (USB): Approximately 124 seconds (Software Size/8MB)
f) iPRO (USB): Approximately 70 seconds (Software Size/8MB).
Switches: Power Switch, OK Button, CLR Button, 
Direction Key Button (UP/DOWN/RIGHT/LEFT)
Interface: USB†Host Single Channel (USB 2.0, Full Speed)
SD Card (SDHC acceptable)
†. USB is available for only JCM products’ access.
Display: Monochrome LCD (122x32 dots with back light)
LED (Light-emitting Diodes) (Red)
Table 2 DT-300 Environmental Specifications
Operating Temperature: 5ºC to +45ºC (41ºF to 113ºF)
Storage Temperature: -20ºC to +60ºC (-4ºF to 140ºF) (Batteries are exception)
Relative Operating Humidity: 30% to 80% RH (non-condensed)
Relative Storage Humidity: 15% to 95% RH (non-condensed)
Visible Light Sensitivity: Avoid Direct Sunlight
Table 3 DT-300 Electrical Specifications
Supply Voltage: Four (4) AAA/LR03 Size Alkaline Batteries (provided by User)
Current Consumption: Standby = 20mA*
Downloading = 90mA
*. 70mA for less then ten (10) minutes while entering Standby.
Table 4 DT-300 Structural Specifications
Weight Empty: Approximately 165g (5.82oz) without Batteries and SD Card
Outside Dimensions: Refer to “Unit Dimensions” on page 14 of this Guide
Hydrothermal Condition Table
35ºC(86ºF)/80%RH
45ºC(113ºF)/30%RH
Temperature (ºC)
Humidity (%RH)
Allowable Operating Temperature
and Humidity Range

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
5
DT-300™ Series Download Tool Operator Integration Guide
6 INSTALLATION
Battery Installation
Perform the following steps to install Batteries into
the DT-300™ Device:
1. Push the two (2) Tabs of the Battery Cover in the
direction of the Arrow illustrated in Figure 4aand
lift the Cover off of the Device.
2. Install four (4) AAA Batteries into their correct
polarized position in the direction illustrated in
Figure 4.
3. Place the Battery Cover back into its original
position, and listen for it to “Click” back into
place.
SD Card Installation
I NSTALLATION TO A PC OR A C ARD R EADER
Perform the following steps to install the SD Card
into a PC or an SD Card Reader:
1. Insert the SD Card into an SD Card Reader, or an
SD Card Reader Slot of the PC.
2. Create each model Folder in the first layer of the
SD Card. Each Folder Name needs to include a
“space” before the word “System”.
3. Save the Software Data Files (xxxxxxxxx.COM)
for each Model’s Folder. Refer to the “Software
Data File” on page 13 of this Guide for more
details.
SD C ARD I NSTALLATION I NTO A DT-300
Perform the following steps to install/remove the
SD Card into/from a DT-300™ Device:
1. Ensure the DT-300™ Power is OFF.
2. Slide the SD Card into the Unit in the direction
indicated by the Red Arrow shown in Figure 8
until it “clicks” in place.
Tabs
+
+
a
Figure 4 Type AAA Battery Installation
NOTE: When creating the storage Folder for
each Model, use the SD Card Slot of a PC or an
SD Card Reader.
SD Card
SD Card
SD Card
SD Card
Slot
Reader
Figure 5 SD Card Insertion (PC or Card Reader)
Space
Figure 6 Model Name Creation
NOTE: Up to twenty (20) Folders can be
created on an SD Card.
Figure 7 Model Folder Creation
NOTE: Refer to “Compatibility” on
page 14 for the details regarding each
Model’s setting.
NOTE: Do NOT erase the
“BWDXCARD.INF” Card Information File!
If the Card Information is lost, Card
Reading errors may occur.
NOTE: When removing the SD Card,
follow the User Guide of the PC, or the
SD Card Reader.
SD Card
SD Card Slot
Figure 8 SD Card Insertion (DT-300)

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
6
DT-300™ Series Download Tool Operator Integration Guide
3. When removing the SD Card from the DT-300™,
push in on the SD Card in the insertion direction
once and then pull the SD Card out of the DT-
300™ Device.
DIP Switch Setting
DIP Switch Settings are necessary to communicate
with the DT-300™ and a Validator. Refer to “Com-
patibility” on page 14 of this Guide for proper DIP
Switch Settings related to each Validator Model.
Functions
The following two (2) Functions exist for the DT-
300™ Device:
B OOTLOADER
The Bootloader Function contains the following
two (2) Modes:
• “BlueWaveDX Firmware Update Mode” to
upgrade the Firmware in the DT-300™ Device
• “BlueWaveDX EEPROM Update Mode” to
update the EEPROM data within the DT-300™
Device.
M AIN A PPLICATION (N ORMAL M ODE )
MainApplication (Normal Mode) contains the 
following two (2) Functions:
• “Firmware Update Function” to upgrade the
Firmware within the Validator
• “Acceptance Log Function” to receive and
display the Acceptance Log.
Boot Mode
When the DT-300™ is initialized, three (3) Modes
will be available. Select one Mode by using the
Direction Key Button to move and select to the
desired Operational Mode (See Table 5).
Authentication
When the MainApplication is booting, the DT-
300™ will authenticate itself with the information
on the SD Card.
USB Cable Connection
Perform the following steps to connect a Power-
Supplied Validator to the DT-300™ Device:
1. Connect the USB Cable A Terminal to the DT-
300™ Unit’s Connector “A” Port (See Figure 9
a).
2. Connect the USB Cable B or Mini-B terminal to
the Validator’s USB Port (See Figure 9 b).
Operation Procedures 
(MainApplication)
This portion provides each MainApplication 
procedure of the DT-300™ Device Operation.
F IRMWARE U PDATE F UNCTION
To update the Firmware of the Validator, proceed 
as follows:
1. Make sure that the SD Card contains the required
Software Data File (Refer to “Software Data File”
on page 13 of this Guide for details regarding
selection of the correct Software Data File).
2. Turn the DT-300™ Power Switch ON; an SD
Card check will begin as shown in Figure 10.
3. Select “FIRMWARE UPDATE” Function on the
Function Selection Screen shown in Figure 11,
and press the OK Key to begin the Firmware
Erase process.
4. Connect the USB Port of the Validator to the DT-
300™ Device using a proper USB Cable.
5. Select the download File desired by pressing the
UP Key or the DOWN Key , and then
Table 5 Boot Mode Selection
Mode Direction Key Button
DT-300 Firmware Update Mode UP + DOWN
DT-300 EEPROM Update Mode LEFT + RIGHT
Normal Mode (MainApplication) N/A (except the other
combinations)
NOTE: Do NOT push the SD Card in by
using excessive force!
NOTE: Refer to “Compatibility” on
page 14 of this Guide to select the “B” or
“Mini-B” Connection Terminal.
b
a
NOTE: Validator power must be supplied.
Figure 9 Cable Connection
Figure 10 SD Card Confirmation Screen 1
NOTE: Product specifications (e.g.,
version) may vary from illustrations, and
are subject to change without notice.
Figure 11 Function Selection Screen 1

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
7
DT-300™ Series Download Tool Operator Integration Guide
press the OK Key to select it (See Figure 12).
[“M:” indicates the “Model Name” and “V:” indi-
cates the “Version”.]
6. Press the OK Key to begin the Software
download (See Figure 13). Press the CLR Key
to return to the previous File Selection
Screen.
7. Ensure that the LCD Display shows the Flash
ROM is in Erase Standby after pressing the OK
Key .
The LCD Screen will display a Progress Bar 
during the Software download (See Figure 15).
8. After the Software Download is complete
(See Figure 17), the LCD Screen will display the
Download Complete Screen once the OK Key
or the CLR Key is pressed.
S TATISTICS F UNCTION
Reviewing an Acceptance Log (Total)
To review the total number Acceptance Log from
the a Validator, proceed as follows:
1. Turn the DT-300™ Power Switch ON, and an SD
Card check will begin (See Figure 18).
2. Select “STATISTICS” on the Function Selection
Screen, and then press the OK Key to accept
it (See Figure 19).
3. Connect the USB Port of the Validator to the DT-
300™ Device using a proper USB Cable
(See Figure 20). Once detected, the connection
between the Validator and the DT-300™ will
automatically begin to receive the Validator’s
Acceptance Log.
4. The LCD Screen will display a Progress Bar
while the Acceptance Log is being read
(See Figure 21).
NOTE: The DT-300 screen can display
up to (20) files using the UP or
DOWN key. [The SD card may have
additional storage, but files exceeding
twenty (20) will not display.]
Figure 12 Select the Download File
NOTE: If the connection between the
Validator and the DT-300 fails, or the
Software selected is inappropriate for the
Validator, a Software download will not
begin!
Figure 13 Download Waiting Screen
Figure 14 Flash ROM Erase Standby Screen
NOTE: While downloading Software, NO
Keyboard operations will be accepted!
Figure 15 Software Downloading Screen
Figure 16 Software Download Verifying Screen
Figure 17 Software Download Complete Screen
NOTE: The Acceptance Log File is generated on
the SD Card when it is successfully received
from the Validator. Refer to “Received Log File”
on page 13 of this Guide for details regarding the
Acceptance Log File.
Figure 18 SD Card Confirmation Screen 2
Figure 19 Function Selection Screen 2
Figure 20 Acceptance Log Standby Screen 1
NOTE: While reading the Acceptance
Log, NO Keyboard operations will be
accepted!

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
8
DT-300™ Series Download Tool Operator Integration Guide
5. Once reading of the Acceptance Log is complete,
the LCD will display a “Log Read Complete”
Screen, as shown in Figure 22.
Display the Acceptance Log
To confirm the Acceptance Log, use the UP
Key or the DOWN Key to display the Log.
Press the CLR Key to return to the previous
Function Selection Screen. The Acceptance Log
will be read again when re-connecting the USB
Cable between the Validator and the DT-300™.
Table 6 listed the available Acceptance Log Dis-
plays.
Enabling a Denomination Function
To view/display the Denomination Table, proceed
as follows:
1. Turn the DT-300™ Power Switch ON and an SD
Card check will begin (See Figure 23).
2. Select “ENABLE DENOMI.” on the Function
Selection Screen, and then press the OK Key
to select it (See Figure 24).
3. Ensure that the LCD Display shows the Standby
Screen shown in Figure 25.
4. Press the
OK Key to display the Denomina-
tion Table Screen (See Figure 26). Press the CLR
Key to return to the previous Function Selec-
tion Screen.
5. Confirm that the current denomination selected
from the Denomination Table is correct.
Table 6 Acceptance Log
Screen Description
Model Name
Version
Banknote 
Acceptance Rate
Ticket 
Acceptance Rate
Denomination, 
Country Code, Year
and Acceptance Rate
Figure 21 Acceptance Log Reading Screen
Figure 22 Log Read Complete Screen
NOTE: The maximum number of Folders allowed
in a DT-300 Device is 20. If more than twenty (20)
Folders are saved in the SD Card Folder, their
functions may not work properly.
Table 7 Reading Denomination Table
Code Example
CCountry Code (3-digit) EUR, USA etc.
DBanknote (5-digit) 100, 200, 500 etc.
EDenomination ($ or €) $ or €
YIssued Year (2-digit) 02
Figure 23 SD Card Confirmation Screen 3
Figure 24 Function Selection Screen 3
Figure 25 Standby Screen 1
Figure 26 Denomination Table Screen
NOTE: If the information cannot be
displayed within 3-digits, the rest of the
information can be shown by scrolling
the Display using the UP/DOWN Key.

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
9
DT-300™ Series Download Tool Operator Integration Guide
Error Message Function
To receive/display the error condition from the 
Validator, proceed as follows:
1. Turn the DT-300™ Power Switch ON, and the
SD Card check will begin (See Figure 27).
2. Select the “ERROR MESSAGE” from the Func-
tion Selection Screen and press the OK Key to
select it (See Figure 28).
3. Make sure that the LCD displays the Standby
Screen shown in Figure 29.
4. Press the
OK Key to display the Active Error
Code Indication Screen shown in Figure 30. Press
the CLR Key to return to the previous Func-
tion Selection Screen.
5. Confirm the Active Error Code. Press the OK
Key or the CLR Key to return to the previ-
ous Standby Screen.
Version Check Function
To obtain the Version, CRC and Serial Number
from the Validator, proceed as follows:
1. Turn the DT-300™ Power Switch ON, and the
SD Card check will begin (See Figure 31).
2. Select “VERSION CHECK” from the Function
Selection Screen and press the OK Key to
select it (See Figure 32).
3. Ensure that the LCD displays the Standby Screen
shown in Figure 33.
4. Press the
OK Key to display the Version,
CRC and Serial Number Indication Screen
(See Figure 34). Press the CLR Key to return
to the previous Function Selection Screen.
5. Confirm the Version, CRC and Serial Number.
Press the OK Key or the CLR Key to
return to the previous Standby Screen.
Maintenance Function
To review/display the Maintenance Condition
information of the Validator, proceed as follows:
1. Turn the DT-300™ Power Switch ON, and the
SD Card check will begin (See Figure 35).
2. Select “MAINTENANCE” from the Function
Selection Screen and press the OK Key to
select it (See Figure 36).
3. Ensure that the LCD displays the Standby Screen
(See Figure 37).
Figure 27 SD Card Confirmation Screen 4
Figure 28 Function Selection Screen 4
Figure 29 Standby Screen 2
Figure 30 Active Error Code Indication Screen
Figure 31 SD Card Confirmation Screen 5
Figure 32 Function Selection Screen 5
Figure 33 Standby Screen 3
Figure 34 Version, CRC & Serial Number Screen
Figure 35 SD Card Confirmation Screen 6
Figure 36 Function Selection Screen 6
Figure 37 Standby Screen 4

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
10
DT-300™ Series Download Tool Operator Integration Guide
4. Press the OK Key to display the Maintenance
Request Indication Screen. Press the CLR Key
to return to the previous Function Selection
Screen.
5. Confirm the Maintenance Request (See Figure 38
& Figure 39). Press the OK Key or the CLR
Key to return to the previous Standby Screen.
Acceptance Log Function (Limited)
The possible storage amount for Banknote Log
Data is limited for each Validator Type. Table 8 lists
each Validator Type’s Log Storage limitation.
To view/display the Banknote Log Data limit of the
Validator being tested, proceed as follows:
1. Turn the DT-300™ Power Switch ON, and the
SD Card check will begin (See Figure 40).
2. Select “ACCEPTANCE LOG” from the Function
Selection Screen and press the OK Key to
select it (See Figure 41).
3. Connect a proper USB Cable between the Valida-
tor and the DT-300™ Device. When the connec-
tion is detected, the reload operation will begin
automatically (See Figure 42).
4. The LCD Screen will display a Progress Bar 
during the Acceptance Log reading process as
shown in Figure 43.
5. Once reading of the Acceptance Log is complete,
the LCD will display the Log Read Complete
Screen shown in Figure 44.
Display the Number of the Banknote
Acceptance Log
To confirm the amount in the Banknote Acceptance
Log, use the UP Key or the DOWN Key to
display the record desired. Press the CLR Key
to return to the previous Function Selection Screen.
The Banknote Acceptance Log value will be read
again when re-connecting a USB Cable between
the Validator and the DT-300™ Device.
Table 9 lists the various Acceptance Log Displays
available.
Table 8 Log Storage Limit
Model Series Storage Limit
UBA Series 50 Notes
iVIZION Series 1000 Notes
VEGA Series N/A
TBV-100 Series N/A
iPRO Series 50 Notes
Figure 38 Maintenance Request Screen
Figure 39 Maintenance Non-Request Screen
Figure 40 SD Card Confirmation Screen 7
Figure 41 Function Selection Screen 7
Table 9 Acceptance Logs Available
Screen Description
Record Start Date
Model Name
Version
Total Number of the
Banknote Insertions
Figure 42 Standby Screen 5
NOTE: While reading the Acceptance
Log, NO Keyboard operations will be
accepted!
Figure 43 Acceptance Log Reading Screen
Figure 44 Log Read Complete Screen

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
11
DT-300™ Series Download Tool Operator Integration Guide
Language Function
To change a Language from English to another
Language, proceed as follows:
1. Turn the DT-300™ Power Switch ON, and the
SD Card check will begin (See Figure 45).
2. Select “LANGUAGE” from the Function Selection
Screen and press the OK Key to select the
desired Language from the list available
(See Figure 46).
3. Select the preferred language; English or Deutsch
(German) as shown in Figure 47 in this example.
Operation Procedures 
(Bootloader)
This portion provides each Bootloader procedure of
the DT-300™ Device operation.
DT-300 F IRMWARE U PDATE
To update the Firmware of the DT-300™, proceed
as follows:
1. Ensure that the SD Card contains the latest Ver-
sion of Firmware (Refer to “Firmware File” on
page 13 of this Guide for details regarding the
proper Firmware File selection).
2. Turn the DT-300™ Power Switch ON while
pressing the UP Key and the DOWN
Key . The Firmware Update Confirmation
Screen shown in Figure 48 will appear.
3. Press the
OK Key to begin the DT-300™
Firmware update. The LCD Screen will display a
Progress Bar during the Firmware updating pro-
cess as shown in Figure 49.
4. Once the update is complete, the LCD Screen will
display the new “Bootloader X.XX Succeeded.”
Message (See Figure 50).
DT-300 EEPROM U PDATE
To update the EEPROM Data in the DT-300™
Device, proceed as follows:
1. Ensure that the SD Card contains the EEPROM
Data (Refer to “EEPROM Data File” on page 13
of this Guide for details regarding the EEPROM
Data File).
2. Turn the DT-300™ Power Switch ON while
pressing the LEFT Key or the RIGHT Key .
The EEPROM Update Confirmation Screen
shown in Figure 51 will appear.
3. Press the
OK Key to begin the EEPROM
update. The LCD Screen will display a Progress
Bar during the EEPROM updating process as
shown in Figure 52.
Total Ti ck e t 
Acceptance Rate
Limited Number of the
Banknote 
Acceptance Rate 1
Limited Number of the
Banknote 
Acceptance Rate 2
Table 9 Acceptance Logs Available (Continued)
Screen Description
Figure 45 SD Card Confirmation Screen 8
Figure 46 Function Selection Screen 8
Figure 47 Language Selection Screen
NOTE: The Firmware File should be
newer than the current Firmware Version
presently in the DT-300.
Figure 48 Firmware Update Confirmation Screen
Figure 49 Firmware Update Progress Bar
Figure 50 Firmware Update Success Screen
Figure 51 EEPROM Update Confirmation Screen

P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
12
DT-300™ Series Download Tool Operator Integration Guide
4. Once the update is complete, the LCD Screen will
display the “Bootloader X.XX Succeeded.” mes-
sage (See Figure 53).
Power Management
M ONITORING B ATTERY C HARGE L EVEL
Three (3) Levels of a Battery Charge condition
exist: FULL, LOW and EMPTY. The DT-300™
Unit’s performance is limited by the Battery condi-
tion. Table 10 lists the DT-300™ available perfor-
mance for each Battery condition case.
B ATTERY C ONDITION D ISPLAY
The Battery condition is monitored regularly. When
the Battery condition is EMPTY, the existing per-
formance Function will terminate, and all Func-
tions will no longer be available; the Error Display
appears.
Table 11 lists the various Battery Condition Dis-
plays.
S LEEP M ODE
When no operation has been performed for 10 min-
utes, the DT-300™ Device will enter Sleep Mode
automatically in order to extend its battery life
(See Figure 54). Once Power is re-supplied, or any
Function Key is pressed, the DT-300™ will again
be ready to begin operation.
When the DT-300™ Device enters Sleep Mode
while downloading the Software or receiving the
Acceptance Log, the LCD Screen will display the
following messages shown in Table 12.
Table 10 Performance and Battery Condition
Performance Function Battery Condition
FULL LOW EMPTY
LCD Display O O O
LCD Backlight O O X
Key Input O O X
Function Selection O O X
Firmware Update Function O O X
Statistics Function O O X
Enabled Denomination Function O O X
Error Message Function O O X
Version Check Function O O X
Maintenance Function O O X
Acceptance Log Function O O X
Language Function O O X
Bootloader*
*. When booting, check the Battery Charge Level. The Bootloader will be
available only when the Battery is FULL. If the Battery condition is
LOW or EMPTY, an error message will appear.
O X X
Figure 52 EEPROM Update Progress Bar
Figure 53 EEPROM Update Success Screen
Table 11 Battery Condition Indication
Display Condition
Battery FULL
Battery LOW
Battery EMPTY
Table 12 Various Sleep Mode Screens
Screen Description
Download Complete
Download Failed
Acceptance Log
Receipt Complete
Acceptance Log
Receipt Failed
Figure 54 Sleep Mode Screen
