jcm-tech HONOADOOR User manual

HONOADOOR
User Manual

Table of contents
Important safety instructions 3
Use of the equipment 3
Introduction 4
General description 4
Features 5
Installation 7
Connection 7
Configuration 8
Connect to the Internet 8
Configuration with cloudAssistant 9
Registering the equipment 9
Registering groups and users 12
Configure relays and assign traffic schedules 16
Set group schedules 17
Administration: Honoa 18
Events 19
Operational mode 20
Remote control from cloudAssistant 20
Anti-Passback 21
Verification 23
LED behaviour 23
Solving problems 24
Connect to a WiFi network 24
Resolve reception issues 25
Notes 26
Technical data 28
Regulatory Data 28
EU Declaration of conformity 28
jcmtechnologies
2

Important safety instructions
Disconnect the power supply whenever you proceed to the installation or repair of
the equipment.
In compliance with the European Low Voltage Directive, we inform you of the following requirements:
•When the devices remain permanently connected, an easily accessible connecting device must be incorporated into the wir-
ing.
•This system must only be installed by qualified professionals that have with automated garage doors and knowledge of the
relevant European standards.
•The user instructions for this device must always be in the user’s possession.
•The operating frequency of the receiver does not interfere in any way with the 868 MHz remote control systems.
Use of the equipment
This deviceisdesigned for applicationswith an automated garage door. It isnot guaranteed for thedirect activation of devices
other than those specified. The manufacturer reservesthe right to change the device specifications without warning. No liab-
ility can be accepted for errors and misprints.
jcmtechnologies
3

Introduction
General description
HONOADOOR is a Motion and Bluetooth receiver connected with information on the state of the door and with remote
activation in real time.
Save on commutes and secure your installation. Open the door with the phone thanksto the HONOA APP or with the fob.
Along with cloudAssistant, you can use HONOADOOR to instantly check the door's operation from your office, avoiding unne-
cessarytrips to check that installations are working properly and to detect and manage suspiciousfobs.
The device can work without an Internet connection, but it doesrequire a connection for certain functions.
An Internet connection isrequired for:
•Setting up the device in cloudAssistant:
•Setting and assigning time slots with the annual holiday calendar
•Checking the entry status in cloudAssistant
•Reading events in cloudAssistant
•Remote activation of the device with the HONOA APP
•Registering and cancelling fobs
•Alerts and notifications
NoInternet connection isrequired for:
•Setting up the device in cloudAssistant:
•Name of the device that appears on the HONOA APP
•Name of the relay that appears on the HONOA APP
•Activating entrances and their settings
•Granting and revoking access permission on cloudAssistant
•Deactivating remote opening in HONOA through cloudAssistant
•Deactivating Bluetooth hands-free activation in HONOA through cloudAssistant
All changes to authorizations or settings in cloudAssistant shall be automatically updated in the HONOA APP.
For the HONOA APPto work properly on your phone, in addition to other requirements, you must authorize the use of phone
data or WIFI, access to your location, and to work in the background.
The application does not require an Internet connection to activate the door.
Settings are adjusted through the cloudAssistant (v4 or later) with a WIFI connection.
Settings with cloudAssistant Use with Honoa
jcmtechnologies
4

Features
Power supply: The equipment is powered with a 110Vac to 230Vac voltage. 500mA protective fuse.
Relay Output: The equipment has 2 adjustable open or closed contact relayoutputs. These outputs can be programmed to be
activated with different fob channels through cloudAssistant. Moreover, these relays can be remotely activated in real time
with the cloudAssistant.
Inputs: The equipment has2 inputs to connect 2 limit switches to monitor the door'sstatus (Open/Closed).
868MHz MOTION receiver module: The equipment has an 868MHz MOTION receiver module to receive from fobs.
Bluetooth receiver module: The equipment has a Bluetooth receiver module to open the door in hands-free mode with a
phone with the HONOA APP. Hands-free activation may be disabled for the entire device in cloudAssistant.
WIFI / GSM Module: The equipment has a WIFI / GSM communication module for connection to the Internet and for remote
opening with a phone with the HONOA APP. Remote opening may be disabled for the entire device in cloudAssistant.
Users: Up to2000 usersmanaged with cloudAssistant.
Events: Up to 2000 events may be viewed through cloudAssistant.
Statistics and information on use: You may use cloudAssistant to view a daily graph of thenumber of relayactivations,
accepted and rejected users, open-door and closed-door events, data consumption, and more.
Light-up signals: The equipment has three LED indicators: "ST", "NW", and "IN" to indicate the cloudAssistant connection
status.
More information
jcmtechnologies
5

jcmtechnologies
6

Installation
Attach the back of the box to the wall with the plugs and screws supplied.
Connect the equipment. Attach the front of the receiver to the back part with the screwssupplied for this purpose.
Connection
POWER INPUT: Power supply at 230Vac.
R1:RELAYChannel 1. Potential-free contact.
R2: RELAYChannel 2. Potential-free contact
•Characteristics of output relays (for resistive load):
•Maximum current: 2A.
•Maximum power: 60W / 62.5VA.
•Maximum voltage: 24V ac/dc.
IN1: Monitoring input for NCcontact.
IN2: Monitoring input for NCcontact.
jcmtechnologies
7

Configuration
Connect to the Internet
The device must be connected to the Internet to change its settings, but it does not require a connection to function.
If the device comes with a SIM card supplied: power on the device and wait about 5 minutes until it connects to the
Internet (LEDssolid green).
If the device does NOT come with a SIM supplied: see "Connect to a WiFi network" in "Solving problems".
jcmtechnologies
8

Configuration with cloudAssistant
Registering the equipment
Once the equipment has an Internet connection, it can be configured:
1. Enter cloudAssistant:https://cloudassistantv4.jcm-tech.com/login and login.
2. Add facility (orange button located in the lower right corner).
3. Fill the fields. Save.
The name of the installation and the city will appear in the HONOA APP:
jcmtechnologies
9

4. Equipments -> Add equipment (orange button located in the lower right corner).
5. Enter a name for the device and select HONOADOOR. Save.
The name of the device will appear in the HONOA APP:
jcmtechnologies
10

6. Enter the Activation Key (found in the device label). Select the pertinent Timezone and assign names and work modes
to the entries. Save.
The names assigned to the entries are the same ones that appear in "Remote state" (see: Operational Mode).
The Activation key and the Timezone are the only mandatory fields to register users.
On this screen, you may enable Allow remote opening and Allow BlueTooth hands-free for HONOA users. By default,
these are enabled.
For remote opening, the device must be connected to the Internet.
jcmtechnologies
11

Registering groups and users
1. Groups -> Add (orange button located in the lower right corner).
2. Enter Name and Description. Save.
jcmtechnologies
12

3. Activate the relays by selecting any of the channels. HONOA activates relays. Back.
If this is a group of devices working with fobs, the selected channels match the function that the
fob will have.
4. On the group screen: Enroll code to add fobs.
jcmtechnologies
13

5. Manual to add one by one, Sequential to add a series of fobs. Fill in the fields correctly, enter the serial number cor-
rectly. Accept.
This equipment does not work with reservation codes and does not allow replacements.
All fobs must be directly managed with the equipment's memory with the button Save con-
figuration.
6. On the group screen: Add user to add HONOA users.
jcmtechnologies
14

7. Complete the fields with the user information. Accept. The different users must provide the email used for their Honoa
account.
When a user is registered with cloudAssistant, they will automatically have access to the install-
ation with the Honoa application.
8. Click "Installation Name" in the upper gray bar to go to installation.
9. Equipments -> Save configuration.
Every time an equipment parameter is modified, you must Save con-
figuration.
It is not necessary to press Save configuration to update HONOA user authorizations.
jcmtechnologies
15

Configure relays and assign traffic schedules
On the equipment's "Relays" screen:
•Relay X: assign name to the relay
•Selector: enable/disable relay
•Relay type X: Normally open/ Normally closed
•Open door schedule: The relay activates automatically, based on the assigned weekly hours. Without assigned hours, the
relay operates normally
•Custom open door time schedule: Activation time goes from 1 second to the time selected in "Door open time", based on
the assigned weekly hours. Without assigned scheludes, the relay operates normally
•Door open time: time in seconds
For the activation times and schedule to work, the device must be connected to the Internet.
Every time an equipment parameter is modified, you must save con-
figuration.
The relay names are displayed in the HONOA APP:
jcmtechnologies
16

Set group schedules
The assignment of a schedule toa group is donein the "Configuration" screen of groups:
Group userscan only activate the relaywhen within the assigned hours. If there is no assigned schedule, it can always be activ-
ated.
For the schedule to work, the device must be connected to the Internet.
Every time an equipment parameter is modified, you must save con-
figuration.
jcmtechnologies
17

Administration: Honoa
HONOA users may view your contact information by clicking on the logo to the bottom left of the device in the HONOA APP.
Contact information can be changed on the "Honoa"screen under "Administration".
jcmtechnologies
18

Events
HONOADOOR is a device with an event record. To see them, in cloudAssistant, go to the device's "Events"screen.
When HONOADOOR does not have an Internet connection, the device keeps working, but without sending the events in real
time. In this case, the events are stored locally on the device. To load the list of events from the device, go to the "Events"
screen →"Load events".
To read the events, the device must be connected to the Internet.
To reset the device's list of events, select "Remove events".
jcmtechnologies
19

Operational mode
Remote control from cloudAssistant
To control the equipment remotely it is necessary to have it connected to the Internet:
•Go to "Facilities" -> "Facility name" -> "Equipments"-> Select "Remote State" (button with the door).
We can view the status of the inputs and remotely activate the equipment's relays. You also have information on the equip-
ment (equipment versions, connection levels, etc.).
