JDiag FasCheck BT-200 User manual

Universal Car Battery Analyzer
JDiag ElectronicsTechnology Co.,Ltd.
FasCheck BT-200
R
User Manual
BT-200

FasCheck BT-200
R
BT-200
UP/Down
OK
Back
Red Clip- Positive
Black Clip- Negative
Product Parameters
【Material】LCD screen, backlit LED, 2.4 inch black and
white display
【Voltage Range】8-20V (12V car battery)
【Test Time】5-10 seconds
【RangeCCA】100-1700
【Battery Range】30AH-100AH
【Product Specifications】124*73*22mm
【Test Clip】Double conductor Kelvin Clips
【Shell Material】Anti-acid ABS plastic
【Cable Specifications】PVC material, 20AWG / 4 core
wire, 100cm long cable.

Product Introduction
Advanced conductance test technology can easily, conve-
niently and accurately test the engine cranking with cold
starting current & health of the car battery, which helps the
maintenance staff to quickly and accurately determine the
battery condition, save testing time and improve the work
efficiency.
Features
1) Test accurate, fast, easy to operate, intuitive display
2) Suitable for CCA, DIN, IEC, EN, JIS and unknown specifi-
cations battery type.
3) Test with low-frequency signal, no external large-load
discharge test, well protect battery during testing.
4) Test the battery fit in car and test the battery which has
been discharged.
5) The device is well designed, strong and durable.
Functions
Can test all the cars start-up lead-acid batteries, including
ordinary lead-acid AGM flat battery, AGM winding batteries,
gel batteries etc., can directly detect bad cells.
Main features: car battery testing, car charging system
testing, car starting system testing.
Operations
1) Clamp the testing clips on the car battery, the RED clip on
positive and BLACK clip on negative, the tester display will

Product Tips
For the deep deficit battery (such as the vehicle for a long
time shelved, the battery is not timely charged; lights /doors
forgotten to turn off leading to serious power failure can not
start the vehicle, etc.), the actual test process may also
prompt “Please replace the battery" Please consult the
battery manufacturers to charge the battery before testing.
Manufacturer：JDiag Electronics Technology Co.,Ltd
Address：R502, Building No.1, Binianghua Industrial Park,
Huada road #7, Longhua District, Shenzhen 518109, China
Tel：[phone]
Website：http://www.jdiag.com
show the boot screen, press the “confirm" button to contin-
ue (Note: if the measured battery voltage is below 6.0V
device unable to test normally).
2) Follow the tester prompts for quick test or standard test:
Enter the standard options (refers to the battery factory
standard, you can get the informations on the battery label)
select the standard battery can be marked on, such as CCA,
BCI, DIN and so on.
Rated capacity selection: refers to the battery factory
start-up current standard, just above or in front of the
battery can be seen, such as 300A. Press “Confirm"button
to start the test.
3) Display the test results
