LOVATO ELECTRIC DME D305T2MID User manual

I509 GB CS 09 17 31100345
G
B
1
DME D305T2MID
THREE-PHASE ENERGY METER
WITH CT INSERTION WITH 2 STATIC OUTPUTS
Instructions manual
GB
LOVATO ELECTRIC S.P.A.
24020 GORLE (BERGAMO) ITALIA
VIA DON E. MAZZA, 12
TEL. [phone]
FAX (Nazionale): 035 4282200
FAX (International): [phone]
E-mail [e-mail]
We www.LovatoElectric.com
WARNING!
– Carefully read the manual efore the installation or use.
– This equipment is to e installed y qualified personnel, complying to current standards, to avoid
damages or safety hazards.
– Before any maintenance operation on the device, remove all the voltages from measuring and supply inputs and short-
circuit the CT input terminals.
– The manufacturer cannot e held responsi le for electrical safety in case of improper use of the equipment.
– Products illustrated herein are su ject to alteration and changes without prior notice. Technical data and descriptions
in the documentation are accurate, to the est of our knowledge, ut no lia ilities for errors, omissions or
contingencies arising there from are accepted.
– A circuit reaker must e included in the electrical installation of the uilding. It must e installed close y the
equipment and within easy reach of the operator. It must e marked as the disconnecting device of the equipment:
IEC /EN 61010-1 § 6.11.2.
– Clean the device with a soft dry cloth; do not use a rasives, liquid detergents or solvents.
ATTENZIONE!
– Leggere attentamente il manuale prima dell’utilizzo e l’installazione.
– Questi apparecchi devono essere installati da personale qualificato, nel rispetto delle vigenti normative
impiantistiche, allo scopo di evitare danni a persone o cose.
– Prima di qualsiasi intervento sullo strumento, togliere tensione dagli ingressi di misura e di alimentazione e
cortocircuitare i trasformatori di corrente.
– Il costruttore non si assume responsa ilità in merito alla sicurezza elettrica in caso di utilizzo improprio del dispositivo.
– I prodotti descritti in questo documento sono suscetti ili in qualsiasi momento di evoluzioni o di modifiche. Le
descrizioni ed i dati a catalogo non possono pertanto avere alcun valore contrattuale.
– Un interruttore o disgiuntore va compreso nell’impianto elettrico dell’edificio. Esso deve trovarsi in stretta vicinanza
dell’apparecchio ed essere facilmente raggiungi ile da parte dell’operatore. Deve essere marchiato come il dispositivo
di interruzione dell’apparecchio: IEC/ EN 61010-1 § 6.11.2.
– Pulire l’apparecchio con panno mor ido, non usare prodotti a rasivi, detergenti liquidi o solventi.
ATTENTION !
– Lire attentivement le manuel avant toute utilisation et installation.
– Ces appareils doivent être installés par un personnel qualifié, conformément aux normes en vigueur en
matière d'installations, afin d'éviter de causer des dommages à des personnes ou choses.
– Avant toute intervention sur l'instrument, mettre les entrées de mesure et d'alimentation hors tension et court-circuiter
les transformateurs de courant.
– Le constructeur n'assume aucune responsa ilité quant à la sécurité électrique en cas d'utilisation impropre du
dispositif.
– Les produits décrits dans ce document sont suscepti les d'évoluer ou de su ir des modifications à n'importe quel
moment. Les descriptions et caractéristiques techniques du catalogue ne peuvent donc avoir aucune valeur
contractuelle.
– Un interrupteur ou disjoncteur doit être inclus dans l'installation électrique du âtiment. Celui-ci doit se trouver tout
près de l'appareil et l'opérateur doit pouvoir y accéder facilement. Il doit être marqué comme le dispositif d'interruption
de l'appareil : IEC/ EN 61010-1 § 6.11.2.
– Nettoyer l’appareil avec un chiffon doux, ne pas utiliser de produits a rasifs, détergents liquides ou solvants.
UWAGA!
– Prze użyciem i instalacją urzą zenia należy uważnie przeczytać niniejszą instrukcję.
– W celu uniknięcia obrażeń osób lub uszko zenia mienia tego typu urzą zenia muszą być instalowane przez
wykwalifikowany personel, zgo nie z obowiązującymi przepisami.
– Prze rozpoczęciem jakichkolwiek prac na urzą zeniu należy o łączyć napięcie o wejść pomiarowych i zasilania oraz zewrzeć
zaciski przekła nika prą owego.
– Pro ucent nie przyjmuje na siebie o powie zialności za bezpieczeństwo elektryczne w przypa ku niewłaściwego użytkowania
urzą zenia.
– Pro ukty opisane w niniejszym okumencie mogą być w każ ej chwili u oskonalone lub zmo yfikowane. Opisy oraz ane
katalogowe nie mogą mieć w związku z tym ża nej wartości umownej.
– W instalacji elektrycznej bu ynku należy uwzglę nić przełącznik lub wyłącznik automatyczny. Powinien on znaj ować się w
bliskim sąsie ztwie urzą zenia i być łatwo osiągalny przez operatora. Musi być oznaczony jako urzą zenie służące o
wyłączania urzą zenia: IEC/ EN 61010-1 § 6.11.2.
– Urzą zenie należy czyścić miękką szmatką, nie stosować śro kow ściernych, płynnych etergentow lub rozpuszczalnikow.
ACHTUNG!
– Dieses Hand uch vor Ge rauch und Installation aufmerksam lesen.
– Zur Vermeidung von Personen- und Sachschäden dürfen diese Geräte nur von qualifiziertem
Fachpersonal und unter Befolgung der einschlägigen Vorschriften installiert werden.
– Vor jedem Eingriff am Instrument die Spannungszufuhr zu den Messeingängen trennen und die Stromwandler
kurzschlieβen.
– Bei zweckwidrigem Ge rauch der Vorrichtung ü ernimmt der Hersteller keine Haftung für die elektrische Sicherheit.
– Die in dieser Broschüre eschrie enen Produkte können jederzeit weiterentwickelt und geändert werden. Die im
Katalog enthaltenen Beschrei ungen und Daten sind daher unver indlich und ohne Gewähr.
– In die elektrische Anlage des Ge äudes ist ein Ausschalter oder Trennschalter einzu auen. Dieser muss sich in
unmittel arer Nähe des Geräts efinden und vom Bediener leicht zugänglich sein. Er muss als Trennvorrichtung für das
Gerät gekennzeichnet sein: IEC/ EN 61010-1 § 6.11.2.
– Das Gerät mit einem weichen Tuch reinigen, keine Scheuermittel, Flüssigreiniger oder Lösungsmittel verwenden.
ADVERTENCIA
– Leer atentamente el manual antes de instalar y utilizar el regulador.
– Este dispositivo de e ser instalado por personal cualificado conforme a la normativa de instalación
vigente a fin de evitar daños personales o materiales.
– Antes de realizar cualquier operación en el dispositivo, desconectar la corriente de las entradas de alimentación y
medida, y cortocircuitar los transformadores de corriente.
– El fa ricante no se responsa ilizará de la seguridad eléctrica en caso de que el dispositivo no se utilice de forma
adecuada.
– Los productos descritos en este documento se pueden actualizar o modificar en cualquier momento. Por consiguiente,
las descripciones y los datos técnicos aquí contenidos no tienen valor contractual.
– La instalación eléctrica del edificio de e disponer de un interruptor o disyuntor. Éste de e encontrarse cerca del
dispositivo, en un lugar al que el usuario pueda acceder con facilidad. Además, de e llevar el mismo marcado que el
interruptor del dispositivo (IEC/ EN 61010-1 § 6.11.2).
– Limpiar el dispositivo con un trapo suave; no utilizar productos a rasivos, detergentes líquidos ni disolventes.
ПРЕДУПРЕЖДЕНИЕ!
– Прежде чем приступать к монтажу или эксплуатации устройства, внимательно ознакомьтесь с одержанием
настоящего руководства.
– Во избежание травм или материального ущерба монтаж должен существляться только квалифицированным персоналом
в соответствии с действующими нормативами.
– Перед проведением любых работ по техническому обслуживанию устройства необходимо обесточить все
измерительные и питающие входные контакты, а также замкнуть накоротко входные контакты трансформатора тока (ТТ).
– Производитель не несет ответственность за обеспечение электробезопасности в случае ненадлежащего использования
устройства.
– Изделия, описанные в настоящем документе, в любой момент могут подвергнуться изменениям или
усовершенствованиям. Поэтому каталожные данные и описания не могут рассматриваться как действительные с точки
зрения контрактов
– Электрическая сеть здания должна быть оснащена автоматическим выключателем, который должен быть расположен
вблизи оборудования в пределах доступа оператора. Автоматический выключатель должен быть промаркирован как
отключающее устройство оборудования: IEC /EN 61010-1 § 6.11.2.
– Очистку устройства производить с помощью мягкой сухой ткани, без применения абразивных материалов, жидких
моющих средств или растворителей.
UPOZORNĚNÍ
– Návo se pozorně pročtěte, než začnete přístroj instalovat a používat.
– Tato zařízení smí instalovat kvalifikovaní pracovníci v soula u s platnými pře pisy a normami pro pře cházení
úrazů osob či poškození věcí.
– Pře jakýmkoli zásahem o přístroje o pojte měřicí a napájecí vstupy o napětí a zkratujte transformátory prou u.
– Výrobce nenese o pově nost za elektrickou bezpečnost v přípa ě nevho ného používání přístroje.
– Výrobky popsané v tomto okumentu mohou k ykoli projít úpravami či alším vývojem. Popisy a ú aje uve ené v katalogu
nemají proto žá nou smluvní ho notu.
– Spínač či o pojovač je nutno zabu ovat o elektrického rozvo u v bu ově. Musejí být nainstalované v těsné blízkosti přístroje a
sna no ostupné pracovníku obsluhy. Je nutno ho označit jako vypínací zařízení přístroje: IEC/ EN 61010-1 § 6.11.2.
– Přístroj čistěte měkkou utěrkou, nepoužívejte abrazivní pro ukty, tekutá čisti la či rozpouště la.
DİKKAT!
– Montaj ve kullanım an önce bu el kitabını ikkatlice okuyunuz.
– Bu aparatlar kişilere veya nesnelere zarar verme ihtimaline karşı yürürlükte olan sistem kurma normlarına göre
kalifiye personel tarafın an monte e ilmeli irler
– Aparata (cihaz) herhangi bir mü ahale e bulunma an önce ölçüm girişlerin eki gerilimi kesip akım transformatörlerine e kısa
evre yaptırınız.
– Üretici aparatın hatalı kullanımın an kaynaklanan elektriksel güvenliğe ait sorumluluk kabul etmez.
– Bu oküman a tarif e ilen ürünler her an evrimlere veya eğişimlere açıktır. Bu sebeple katalog aki tarif ve eğerler herhangi bir
bağlayıcı eğeri haiz eğil ir.
– Binanın elektrik sistemin e bir anahtar veya şalter bulunmalı ır. Bu anahtar veya şalter operatörün kolaylıkla ulaşabileceği yakın
bir yer e olmalı ır. Aparatı (cihaz) evre en çıkartma görevi yapan bu anahtar veya şalterin markası: IEC/ EN 61010-1 § 6.11.2.
– Aparatı (cihaz) sıvı eterjan veya solvent kullanarak yumuşak bir bez ile siliniz aşın ırıcı temizlik ürünleri kullanmayınız.
AVERTIZARE!
– Citiţi cu atenţie manualul înainte e instalare sau utilizare.
– Acest echipament va fi instalat e personal calificat, în conformitate cu stan ar ele actuale, pentru a evita
eteriorări sau pericolele.
– Înainte e efectuarea oricărei operaţiuni e întreţinere asupra ispozitivului, în epărtaţi toate tensiunile e la intrările e
măsurare şi e alimentare şi scurtcircuitaţi bornele e intrare CT.
– Pro ucătorul nu poate fi consi erat responsabil pentru siguranţa electrică în caz e utilizare incorectă a echipamentului.
– Pro usele ilustrate în prezentul sunt supuse mo ificărilor şi schimbărilor fără notificare anterioară. Datele tehnice şi escrierile
in ocumentaţie sunt precise, în măsura cunoştinţelor noastre, ar nu se acceptă nicio răspun ere pentru erorile, omiterile sau
evenimentele neprevăzute care apar ca urmare a acestora.
– Trebuie inclus un isjunctor în instalaţia electrică a clă irii. Acesta trebuie instalat aproape e echipament şi într-o zonă uşor
accesibilă operatorului. Acesta trebuie marcat ca fiin ispozitivul e econectare al echipamentului: IEC/EN 61010-1 § 6.11.2.
– Curăţaţi instrumentul cu un material textil moale şi uscat; nu utilizaţi substanţe abrazive, etergenţi lichizi sau solvenţi.
UE declaration: http://www.lovatoelectric.com/DMED305T2MID/DMED305T2MID/snp

I509 GB CS 09 17 31100345
G
B
2
CONTENTS PAGE
Introduction ........................................................................................................................................................................................................................................................................................................................ 2
Description ......................................................................................................................................................................................................................................................................................................................... 2
Front utton functions ........................................................................................................................................................................................................................................................................................................ 2
Display indications .............................................................................................................................................................................................................................................................................................................. 2
Displaying measurements ................................................................................................................................................................................................................................................................................................. 3
Main page ........................................................................................................................................................................................................................................................................................................................... 3
Front metrology LED ........................................................................................................................................................................................................................................................................................................... 3
Ta le of display pages ........................................................................................................................................................................................................................................................................................................ 4
Navigating etween the display pages ................................................................................................................................................................................................................................................................................ 6
Energy meter indication ...................................................................................................................................................................................................................................................................................................... 7
Tariffs .................................................................................................................................................................................................................................................................................................................................. 7
Hour counter indication ...................................................................................................................................................................................................................................................................................................... 7
Limit threshold status indication (LIMx) ............................................................................................................................................................................................................................................................................. 8
Alarm indication .................................................................................................................................................................................................................................................................................................................. 8
Main menu .......................................................................................................................................................................................................................................................................................................................... 8
Parameters setting (setup) ................................................................................................................................................................................................................................................................................................. 8
Parameter ta le ................................................................................................................................................................................................................................................................................................................... 9
Commands menu ............................................................................................................................................................................................................................................................................................................... 12
Wiring test .......................................................................................................................................................................................................................................................................................................................... 12
Wiring diagram ................................................................................................................................................................................................................................................................................................................... 12
Terminals arrangement and mechanical dimensions (mm) ................................................................................................................................................................................................................................................ 13
Technical specifications ...................................................................................................................................................................................................................................................................................................... 14
INTRODUCTION
The three-phase energy meter with CT insertion, model DME D305T2MID, has een designed to com ine the utmost ease of use with a wide range of advanced functions. Despite the extremely limited dimensions of
the modular housing (just 4 modules), the energy meter features the same performance as a high-level device. The acklit LCD display permits a clear and intuitive user interface. The DME D305T2MID also features
2 static outputs for pulse generation and a tariff input.
DESCRIPTION
– Three-phase energy meter
– CT insertion
– 4U (72 mm) modular construction for DIN rail
– Backlit LCD display
– 2 static outputs
– AC tariff input
– 3 navigation uttons for functions and settings
– Metrology LED for energy flow indication
– High-accuracy true root mean square (TRMS) measurement
– Active energy measurement according to EN50470-3 class B
– Active and reactive energy meters, total and y individual phase
– Total and partial energy meters (only partial meter can e reset)
– 1 total hour counter and 4 partial hour counters
– Programma le input (e.g. for tariff selection)
– 2-level password protection for settings
– Backup copy of original settings
– Fitting does not require tools
– Terminal covers that can e lead sealed
– Texts in 6 languages (English, Italian, French, Spanish, Portuguese, German).
KEYBOARD FUNCTIONS
s and t buttons – Used to scroll etween screens, select from availa le options on the display and change (increase/decrease) settings.
When pressed simultaneously (
s + t ), they are used to enter or exit the various display and setup menus.
button – Used to scroll su -pages, confirm selected options and switch etween display modes.
DISPLAY INDICATIONS
Main measurements
display
Alarm icon
Sub-page
(measurement
type) indication
Main
measurements
display
Measurement page
indication
Bar graph
Communication
active
Selected
phase(s)
indication
Bar graph full
scale
indication

I509 GB CS 09 17 31100345
G
B
3
MAIN PAGE
Active power
measured on the
system
Active power
percentage with
respect to the rated
value for the system
Total active
energy meter
RS485
communication
active (flashing)
– The main page displays the active power currently used in the system, the active power percentage with respect to the rated value for the system and the total active energy meter for the system.
– The user can choose the page and su -page that the DME D305T2MID display returns to automatically after a certain time has elapsed without the uttons eing pressed.
– It is also possi le to program the energy meter so that the display always remains that which was last selected.
– For the setup of these functions, see the P02 – Utility menu.
FRONT METROLOGY LED
– The red front LED pulses 10,000 times for each kWh of energy consumption, referred to the CT secondary.
– The flashing frequency of the LED provides an immediate indication of the amount of power required in a given moment.
– The duration of the flashing, the colour and the intensity of the LED comply with the standards that prescri e its use for metrological checking of the energy counter’s accuracy.
VIEWING OF MEASUREMENTS
– The
s and t uttons allow the measurement display pages to e scrolled one at a time. The current page can e recognized through the unit of measurement shown in the top part of the display.
– Some measurements may not e displayed, depending on the programming and the connection for the device (for example, if programmed for a system without neutral, the measurements relating to neutral are
not displayed).
– For every page, the utton permits access to su -pages (for example, to display the maximum and minimum values recorded for the selected measurement).
– The su -page displayed currently is indicated at the ottom right y one of the following icons:
– IN = Instantaneous value – Current instantaneous value of the measurement, displayed y default every time the page is changed.
– HI = Highest peak – Highest value measured y the energy meter for the corresponding measurement. HIGH values are stored and preserved even in the a sence of a power supply. They can e reset through a
dedicated command (see command menu).
– LO = Lowest peak – Lowest value measured y the energy meter from the moment voltage is applied. It is reset with the same command used for the HI values.
– AV = Average value – Time-integrated (average) value of measurement. Permits display of a measurement with slow variations. See Integration menu.
– MD = Maximum Demand – Peak integrated value (max demand). Remains stored in non-volatile memory and can e reset with a dedicated command.

I509 GB CS 09 17 31100345
G
B
TABLE OF DISPLAY PAGES
Selection with
s and t Selection with
N° PAGES
SUB-PAGES
1 ACTIVE ENERGY– ACTIVE POWER
kWh(TOT) – kW (TOT) – %kW with respect to the rated value
2 IMP. ACTIVE ENERGY METERS
kWh+(SYS) PAR SYS TAR-1 TAR-2
kWh+(SYS) TOT
3 EXP. ACTIVE ENERGY METERS
kWh-(SYS) PAR SYS TAR-1 TAR-2
kWh-(SYS) TOT
4 IMP. REACTIVE ENERGY METERS
kvarh+(SYS) PAR SYS TAR-1 TAR-2
kvarh+(SYS) TOT
5 EXP. REACTIVE ENERGY METERS
Kvarh-(SYS) PAR SYS TAR-1 TAR-2
Kvarh-(SYS) TOT
6 APPARENT ENERGY METERS
kVAh(SYS) PAR SYS TAR-1 TAR-2
kVAh(SYS) TOT
7 ENERGY METERS (L1)
kWh+(L1) PAR SYS TAR-1 TAR-2
kWh+(L1) TOT
8 ENERGY METERS (L2)
kWh+(L2) PAR SYS TAR-1 TAR-2
kWh+(L2) TOT
9 ENERGY METERS (L3)
kWh+(L3) PAR SYS TAR-1 TAR-2
kWh+(L3) TOT
10 ENERGY METERS (L1)
kWh-(L1) PAR SYS TAR-1 TAR-2
kWh-(L1) TOT
11 ENERGY METERS (L2)
kWh-(L2) PAR SYS TAR-1 TAR-2
kWh-(L2) TOT
12 ENERGY METERS (L3)
kWh-(L3) PAR SYS TAR-1 TAR-2
kWh-(L3) TOT
13 ENERGY METERS (L1)
kvarh+(L1) PAR SYS TAR-1 TAR-2
kvarh+(L1) TOT
14 ENERGY METERS (L2)
kvarh+(L2) PAR SYS TAR-1 TAR-2
kvarh+(L2) TOT
15 ENERGY METERS (L3)
kvarh+(L3) PAR SYS TAR-1 TAR-2
kvarh+(L3) TOT
16 ENERGY METERS (L1)
kvarh-(L1) PAR SYS TAR-1 TAR-2
kvarh-(L1) TOT
17 ENERGY METERS (L2)
kvarh-(L2) PAR SYS TAR-1 TAR-2
kvarh-(L2) TOT
18 ENERGY METERS (L3)
kvarh-(L3) PAR SYS TAR-1 TAR-2
kvarh-(L3) TOT
19 ENERGY METERS (L1)
kVAh(L1) PAR SYS TAR-1 TAR-2
kVAh(L1) TOT
20 ENERGY METERS (L2)
kVAh(L2) PAR SYS TAR-1 TAR-2
kVAh(L2) TOT
21 ENERGY METERS (L3)
kVAh(L3) PAR SYS TAR-1 TAR-2
kVAh(L3) TOT
22 PHASE-TO-PHASE VOLTAGES
V(L1-L2), V(L2-L3), V(L3-L1), V(LL)EQV HI LO AV
23 PHASE-TO-NEUTRAL VOLTAGES
V(L1-N), V(L2-N), V(L3-N), V(L-N)EQV HI LO AV
24 PHASE AND NEUTRAL CURRENTS
I(L1), I(L2), I(L3), I(N) HI LO AV MD
25 ACTIVE POWER
P(L1), P(L2), P(L3), P(TOT) HI LO AV MD
26 REACTIVE POWER
Q(L1), Q(L2), Q(L3), Q(TOT) HI LO AV MD
27 APPARENT POWER
S(L1), S(L2), S(L3), S(TOT) HI LO AV MD
28 POWER FACTOR
PF(L1), PF(L2), PF(L3), PF(EQ) HI LO AV
4

I509 GB CS 09 17 31100345
G
B
5
TABLE OF DISPLAY PAGES
Selection with
s and t Selection with
N° PAGES
SUB-PAGES
29 ACTIVE POWER UNBALANCE
L1-L2, L2-L3, L3-L1 HI LO AV
30 FREQUENCY
Hz HI LO AV
31 ASYMMETRY ASY(VLL) HI LO AV
32 ASYMMETRY ASY(VLN) HI LO AV
33 ASYMMETRY ASY(I) HI LO AV
34 PH-PH VOLTAGE HARM. DISTORTION
THD-V(L1-L2), THD-V(L2-L3), THD-V(L3-L1) HI LO AV
35 PH-N VOLTAGE HARMONIC DISTORTION
THD-V(L1),THD-V(L2),THD-V(L3) HI LO AV
36 CURRENT HARMONIC DISTORTIONE
THD-I(L1), THD-I(L2) THD-I(L3) HI LO AV
37 HOUR COUNTER
hhhhhh-mm-ss TOT PAR-1 PAR-2 PAR-3 PAR-4
38 LIMIT THRESHOLD
LIM1–LIM2–LIM3–LIM4
39 ALARMS
ALA1–ALA2–ALA3–ALA4
40 SELECTED TARIFF (tAr-1 and tAr-2)
41 INFO-REVISION-SERIAL NO.
MODEL, REV SW, SER. No.
NOTE: The pages highlighted in grey in the a ove ta le may not e displayed if the function or parameter that controls them is not ena led. For example, if no alarm is programmed, the corresponding page is not
displayed.

I509 GB CS 09 17 31100345
G
B
NAVIGATING BETWEEN THE DISPLAY PAGES
Phase-to-phase voltages
6
= Instantaneous value = Maximum value = Minimum value = Average value
= Instantaneous value = Maximum value = Minimum value = Average value
= Instantaneous value = Maximum value = Minimum value = Average value
= Instantaneous value
= Max Demand value
= Maximum value = Minimum value = Average value
Phase-to-neutral voltages
Phase and neutral currents
Active power phase and total

I509 GB CS 09 17 31100345
G
B
7
ENERGY METER INDICATION
– There are five dedicated pages for energy meters.
• Imported and exported active energy
• Inductive or capacitive reactive energy
• Apparent energy.
– Each page displays the total and partial value (can e reset from commands menu).
– If the unit of measurement is displayed continuously, it means that the meter is for imported energy (positive). Display of exported (negative) energies can e ena led as well y setting parameter P02.09 to ON.
These energies are highlighted y the flashing of the unit of measurement and y the “-” sign, and are displayed after the imported energies y pressing
t .
– If display of energy y individual phase is ena led (P02.10=ON), three independent additional pages, one per phase, will e displayed, including total and partial energy.
– If programma le input P13.01 is set to TAR-A, all the energy meters indicated are also present divided y Tariff 1 and Tariff 2. These meters are displayed in the system meter su -pages (see Tariffs paragraph).
TARIFFS
– For energy metering, the DME D305T2MID can manage 2 independent tariffs in addition to total and partial.
– The tariff is normally selected through the digital input, or optionally through messages sent through the communication protocol.
– To select the 2 tariffs, the TAR-A input function is availa le. Activating this makes the selection illustrated in the ta le:
– The device features a VAC programma le input.
– The default function setting is TAR-A, which therefore permits selection etween the two tariffs 1 and 2.
– The text tAr-1 or tAr-2 flashes to indicate the selected tariff and consequently the meter reading that is increasing.
– The meter readings for the tariffs are displayed as a su -page of the system meters (total and phase if ena led).
– The active tariff can e selected through a dedicated command on the Mod us protocol (see Mod us protocol technical instruction).
HOUR COUNTER INDICATION
– If the hour counter is ena led (see menu P05), the DME D305T2MID displays the hour counter page, with the format indicated in the figure:
– There is a total hour counter and 4 partial hour counters that can e reset and activated with different sources (see the parameters of the P05 group).
Imported active energy Exported active energy
Imported active energy tariff 1 Imported active energy tariff 2
TAR-A TARIFF
OFF 1
ON 2

I509 GB CS 09 17 31100345
G
B
8
LIMIT THRESHOLD STATUS INDICATION (LIMx)
– If the limit thresholds are ena led (see menu P08), the DME D305T2MID displays the page, with the corresponding status and the format indicated in the figure:
– With limit threshold activated, the word ON flashes, while if it is deactivated the word OFF is constant. If no limit threshold is programmed, dashes are displayed.
ALARM INDICATION
– If alarms are ena led (see menu P09), the DME D305T2MID displays the page, with the corresponding status and the format indicated in the figure:
– With alarm activated, the word ON flashes with the triangle sym ol, while if it is not activated the word OFF is constant.
– If no alarm is programmed, dashes are displayed. After a out 3s, the scrolling text of the alarm programmed in parameter P09.n.05 appears.
– With several alarms active, the texts are displayed in succession.
– Dedicated parameter P02.14 for the utility menu can e used to make the display acklighting flash in the event of an alarm to highlight the presence of the fault.
– The alarm reset method depends on parameter P09.n.03. This determines whether it can e automatic, on the disappearance of the alarm conditions, or requires manual intervention through the commands menu
(C.07).
MAIN MENU
To access the main menu:
– Press s and t simultaneously. The main menu is displayed (see figure), with the availa le options:
• SET – Access to the setup menu
• CMD – Access to the commands menu
• PAS – Password entry
– The selected option flashes. Descriptive text for the selection scrolls in the alphanumeric display.
– If the password needs to e set, the menu opens with the PAS option already selected.
– Press
st to select the desired option, then to confirm.
– To return to the measurement display, press
s and t simultaneously again.
PARAMETER SETTING (SETUP)
– From the standard measurement display, press
s and t simultaneously to call up the main menu, then select SET and press to access the settings menu.
– The display indicates the first menu level P.01 at the top left of the display, with selection 01 flashing.
– Select the desired menu (P.01, P.02, P.03) using the st uttons. During selection, the alphanumeric display scrolls a rief description of the currently selected menu.
– To exit and return to the measurement display, press
s and t simultaneously.
Setup: menu selection

I509 GB CS 09 17 31100345
G
B
9
– The following ta le lists the availa le menus:
CODE MENU DESCRIPTION
P01 GENERAL Specifications of the system
P02 UTILITY Language, rightness, display, etc.
P03 PASSWORD Ena lement of protected access
P04 INTEGRATION Readings integration times
P05 HOUR COUNTER Ena lement of hour counter
P08 LIMIT THRESHOLDS (LIMn) Measurement thresholds
P09 ALARMS (ALAn) Alarm messages
P11 ENERGY PULSES (PULn) Energy pulse configuration
P13 INPUTS Programma le input
P14 OUTPUTS Programma le outputs
– Press to access the selected menu.
– At this point the su -menu (if applica le) and sequential parameter num er can e selected, again using the uttons as follows:
•
s and t simultaneously: ack
•
t decrease
•
s increase
• next
– Once the desired parameter num er is set, switches to parameter value edit mode, with the parameter shown in the alphanumeric display.
– Pressing
s or t changes the parameter within the permitted range.
– Pressing
t and simultaneously sets the minimum possi le value, while pressing s and sets the maximum.
– Pressing
s and t simultaneously restores the factory default value.
– After selecting the desired value, pressing stores the parameter and returns to the previous level, i.e. parameter selection.
– Press s and t simultaneously several times to exit and save the parameters. The device will re oot.
– If no uttons are pressed for two minutes, the setup menu is a andoned automatically and the system returns to the standard display without saving the parameters.
– Remem er that, solely for the data that can e edited using the uttons, a ackup copy can e made in the DME D305T2MID’s EEPROM. If required, this data can e restored to the working memory. The ackup
and data restore commands are in the commands menu.
PARAMETER TABLE
– All availa le programming parameters are indicated in the following ta le. For each parameter the range of possi le settings and factory default are shown, in addition to an explanation of the parameter’s function.
The description of the parameter visi le on the display may in some cases vary from that indicated in the ta le due to the limited num er of characters availa le. The parameter code is a valid reference in any case.
M01 - GENERAL UoM Default Range
P01.01 CT primary A 5 1-10000
P01.02 CT secondary A 5 1-5
P01.03 Nominal voltage V AUT AUT / 220-415
P01.04 Nominal power kW AUT AUT / 1-10000
P01.05 Connection type L1-L2-L3-N L1-L2-L3-N
L1-L2-L3
L1-L2-L3-N BIL
L1-L2-L3 BIL
L1-N-L2
L1-N
P01.01 – Rated current of CT primary winding.
P01.02 – Current of CT secondary winding.
P01.03 – Rated voltage of system.
P01.04 – Rated power of system.
P01.05 – Set in accordance with the connection scheme adopted. See Wiring Diagram at the end of the manual.
Setup: selecting the parameter num er

I509 GB CS 09 17 31100345
G
B
10
M02 – UTILITY UoM Default Range
P02.01 Language English English
Italiano
Francais
Espanol
Portuguese
Deutsch
P02.02 High acklight level % 100 0-100
P02.03 Low acklight level % 30 0-50
P02.04 Low acklight delay s 30 5-600
P02.05 Default page return s 60 OFF / 10-600
P02.06 Default pag W + kWh VL-L / VL-N …
P02.07 Default su -page INST INST / HI / LO /
AVG / MD
P02.08 Display update time s 0.5 0.1 – 5.0
P02.09 Exported energy measure OFF OFF-ON
P02.10 Phase energy measure OFF OFF-ON
P02.11 Asymmetry measure OFF OFF-ON
P02.12 THD measure OFF OFF-THD
P02.13 Power un alance measurement OFF OFF-ON
P02.14 Backlight flash when in alarm OFF OFF-ON
P02.15 Reactive power calculation TOT TOT-FUND
P02.05 – If set to OFF, the display always remains on the page where the user left it. If set to a value, after this time the display returns to the page set with P02.06.
P02.06 – Num er of the page that the display returns to automatically once the time P02.05 since a utton was last pressed has elapsed.
P02.07 – Type of su -page that the display returns to after P02.05 has elapsed.
P02.09 – Ena les the measurement and display of exported energies (generated towards the mains).
P02.10 – Ena les the measurement and display of energies y individual phase.
P02.11 – Ena les the measurement and display of voltage and current asymmetry.
P02.12 – Ena les the measurement and display of voltage and current THDs (% Harmonic Distortion).
P02.13 – Ena les the calculation and display of phase power un alance.
P02.14 – When there is an alarm, the display’s acklight flashes to highlight the fault.
P02.15 – Selection of reactive power calculation method.
TOT: the reactive power includes the harmonic contri utions. In this case: Preactive2= Papparent2–Pactive2
FUND: the reactive power includes the fundamental contri ution only. In this case: Preactive2≤ Papparent2–Pactive 2. Papparent still includes the harmonic contri ution (same value as TOT case).
In a sence of voltage and current harmonics, oth the calculation methods come to the same result and PF = cosj.
M03 – PASSWORD UoM Default Range
P03.01 Ena le passwords OFF OFF-ON
P03.02 User level password 1000 0-9999
P03.03 Advanced level password 2000 0-9999
M04 – INTEGRATION UoM Default Range
P04.01 Integration mode Shift Fixed
Shift
Bus
P04.02 Power integration time min 15 1-60
P04.03 Current integration time min 15 1-60
P04.04 Voltage integration time min 1 1-60
P04.05 Frequency integration time min 1 1-60
M05 – HOUR COUNTER UoM Default Range
P05.01 Hour counters general ena le ON OFF-ON
P05.02 Partial hour counter 1 ena le ON OFF-ON-LIMx
P05.03 Hour counter 1 channel num er (x) 1 1-4
P05.04 Partial hour counter 2 ena le ON OFF-ON-LIMx
P05.05 Hour counter 2 channel num er (x) 1 1-4
P05.06 Partial hour counter 3 ena le ON OFF-ON-LIMx
P05.07 Hour counter 3 channel num er (x) 1 1-4
P05.08 Partial hour counter 4 ena le ON OFF-ON-LIMx
P05.09 Hour counter 4 channel num er (x) 1 1-4
P03.01 – If set to OFF, password management is disa led and there is free access to settings and the commands menu.
P03.02 – With P03.01 active, value to specify to activate user-level access. See Password Access section.
P03.03 – As P03.02, with reference to advanced-level access.
P04.01 – Integrated measurement calculation mode selection.
Fixed = The instantaneous measurements are integrated for the time set. Each time that the time set elapses, the integrated measurement is updated with the result of the latest integration.
Shift = The instantaneous measurements are integrated for a time = 1/15 of the time set. Each time this interval elapses, the oldest value is replaced with the new value calculated. The integrated
measurement is updated every 1/15 of the time set, considering a time-shift window that includes the last 15 values calculated, equivalent in length to the time set.
Bus = As fixed mode, ut the integration intervals are dictated y synchronisation messages sent on the serial us. (110)
P04.01 – Average (AVG) measurement integration time for active, reactive and apparent power.
P04.03, P04.04, P04.05 – Average (AVG) measurement integration time for the corresponding values.
P05.01 – If OFF, the hour counters are disa led and the hour counter measurement page is not displayed.
P05.02, P05.04, P05.06, P05.08 – If OFF, the partial hour counter (1, 2, 3 or 4) is not incremented. If ON, it is incremented when the energy meter is supplied. If linked to one of the internal varia les (LIMn), it is
incremented only when this condition is true.
P05.03, P05.05, P05.07, P05.09 – Channel num er (x) of any internal varia le used in the previous parameter. Example: If the partial hour counter needs to count the time that a measurement is a ove a certain
threshold, defined y LIM3, program LIMx in the previous parameter and specify 3 in this parameter.

I509 GB CS 09 17 31100345
G
B
11
M08 – LIMIT THRESHOLDS (LIMn, n=1..4) UoM Default Range
P08.n.01 Reference measure OFF OFF- (measures)
P08.n.02 Function Max Max - Min - Min+Max
P08.n.03 Upper threshold 0 -9999 - +9999
P08.n.04 Multiplier x1 /100 – x10k
P08.n.05 Delay s 0 0.0 – 1000.0
P08.n.06 Lower threshold 0 -9999 - +9999
P08.n.07 Multiplier x1 /100 – x10k
P08.n.08 Delay s 0 0.0 – 1000.0
P08.n.09 Normal status OFF OFF-ON
P08.n.10 Latch OFF OFF-ON
M13 – INPUT UoM Default Range
P13.01 Input function TAR-A (n=1) OFF– LOCK –
TAR-A –
C01 - C02 - C03 -
C04 - C06 - C07-C08
P13.02 Rest status OFF OFF – ON
P13.03 ON delay s 0.05 0.00 – 600.00
P13.04 OFF delay s 0.05 0.00 – 600.00
M09 – ALARMS (ALAn, n=1..4) Default Range
P09.n.01 Alarm source OFF OFF-LIMx
P09.n.02 Channel num er (x) 1 1-4
P09.n.03 Latch OFF OFF-ON
P09.n.04 Priority Low Low – High
P09.n.05 Text ALAn (text: 16 characters)
Note: this menu is divided into 4 sections, for limit thresholds LIM1..4
P08.n.01 – Defines which energy meter measurement the limit threshold is applied to.
P08.n.02 – Defines the function of the limit threshold. It can e:
Max = LIMn active when measurement exceeds P08.n.03. P08.n.06 is the reset threshold.
Min = LIMn active when measurement is elow P08.n.06. P08.n.03 is the reset threshold.
Min+Max = LIMn active when measurement is a ove P08.n.03 or elow P08.n.06.
P08.n.03 and P08.n.04 – Define the upper threshold, which results from multiplying value P08.n.03 y P08.n.04.
P08.n.05 – Trip delay on upper threshold.
P08.n.06, P08.n.07, P08.n.08 – as a ove, with reference to the lower threshold.
P08.n.09 – Permits inversion of the status of limit threshold LIMn.
P08.n.10 – Defines whether the threshold is stored and must e reset manually (ON) or is reset automatically (OFF).
Note: this menu is divided into 4 sections, for alarms ALA1..4
P09.n.01 – Signal that causes the alarm. It can e when a threshold (LIMx) is exceeded.
P09.n.02 – Channel num er (x), with reference to the previous parameter.
P09.n.03 – Defines whether the alarm is stored and must e reset manually (ON) or is reset automatically (OFF).
P09.n.04 – If the alarm has a priority of high, its activation switches the display to the alarm page automatically and it shows the alarm icon. If instead it is set to low priority, the page does not change and it is
displayed with the ‘information’ icon.
P09.n.05 – Free text for alarm. 16 characters max.
M11 – ENERGY PULSES (PULn, n=1..2) UoM Default Range
P11.n.01 Source measure OFF OFF
Wh+
Wh-
Varh+
Varh-
VAh
P11.n.02 Count unit pulse/kWh 10 100
10
1
0.1
P11.n.03 Pulse duration s 0.10 0.01-1.00
Note: this menu is divided into 2 sections, for pulses PUL1..2
P11.n.01 – Source measure for pulse generation.
P11.n.02-P11.n.03 – Num er of pulses and pulse duration.
P13.01 – Input function:
OFF – Input disa led
LOCK – Settings lock – prevents access to oth levels.
TAR-A – Energy tariff selection. See tariffing chapter.
C01 C08 – When this input is activated (on the rise time), the corresponding command in the commands menu is carried out.
P13.02 – Input rest status. Permits inversion of the activation logic.
P13.03 – P13.04 – Input activation – deactivation delays. Permits filtering of the status to avoid ounces.

I509 GB CS 09 17 31100345
G
B
12
CODE COMMAND ACCESS LEVEL DESCRIPTION
C.01 RESET HI-LO User / Advanced Resets the HI and LO values of all measurements
C.02 RESET MAX DEMAND User / Advanced Resets Max Demand values for all measurements
C.03 RESET PARTIAL ENERGY METERS User / Advanced Resets partial energy meters
C.04 RESET PARTIAL HOUR COUNTER User / Advanced Resets partial hour counters
C.06 RESET TARIFFS User / Advanced Resets energy meters with tariff 1 and 2
C.07 RESET ALARMS User / Advanced Resets alarms with latch
C.08 RESET LIMITS User / Advanced Resets limit thresholds with latch
C.12 RESET TOTAL HOUR COUNTERS Advanced Resets total hour counters
C.13 PARAMETERS TO DEFAULT Advanced Restores all settings to factory default values
C.14 PARAMETER BACKUP Advanced Saves a ackup copy of all setup parameters
C.15 PARAMETERS RESTORE Advanced Reloads the settings from the ackup copy
C.16 WIRING TEST Advanced Runs the test to check that the DME D305T2MID is connected correctly - See wiring test
COMMANDS MENU
– The commands menu permits the execution of occasional operations such as resetting measurements, meters, counter, etc.
– If the Advanced-level password has een entered, the commands menu can also e used to perform some automatic operations that are useful for configuring the instrument.
– The following ta le lists indicates the functions availa le in the commands menu, divided y access level required.
– Once the required command has een selected, press to execute it. The device will prompt for a confirmation. Pressing again will execute the command.
– To cancel the command execution, press MENU.
– To quit the commands menu, press
s and t simultaneously.
WIRING TEST
– The wiring test permits verification of the correct installation of the energy meter.
– In order to run the test, the energy meter must e connected to an active system with the following conditions:
• Three-phase system with all phases present (V > 187VAC PH-N)
• Minimum current flow in each phase > 1% of the CT full scale set
• Positive flow of energies (i.e. a normal system where the inductive load draws power from the supply).
– To launch the test execution, enter the commands menu and select command C.16, according to the instructions in the Commands Menu section.
– The test allows to verify the following points:
• Reading of the three voltages
• Phase sequence
• Voltage un alance
• Reverse polarity of one or more CTs
• Mismatch etween voltage/current phases
– If the test does not succeeds, the display shows the reason of the failure.
WIRING DIAGRAM
NOTES
1. Recommended fuses: F1A (fast).
2. The S2 terminals are connected to each other internally.
M14 – OUTPUTS (OUTn, n=1..2) UoM Default Range
P14.n.01 Output function OFF OFF – ON – SEQ
LIM – ALA – PUL
P14.n.02 Channel num er (x) 1 1 - 4
P14.n.03 Normal status OFF OFF - ON
P14.n.04 ON delay s 0.0 0.0-6000.0
P14.n.05 OFF delay s 0.0 0.0-6000.0
Note: this menu is divided into 2 sections, for outputs OUT1..2
P14.n.01 – Output function:
OFF – Output disa led.
ON – Output always activated when the meter is powered up.
SEQ – Output activated in case of phase sequence error.
LIM - ALA – Output activated in case of limit overcome or alarm presence.
PUL – Output used as pulse generator as defined in M11.
P14.n.02 – Output normal status. Permits inversion of the activation logic.
P14.n.03 – P14.n.04 – Output activation – deactivation delays.
L1
L3
L2
N
VN S2
I2
O1-
T2T1 O1+
METER
V2
V1 V3 S1
I1
S2 S1
I3
S2
S1
O2-O2+
Static
400V (L-L)
230V (L-N)
Pulse output
30VDC 50mA
L1
L3
L2
VN
O1-
T2T1 O1+
METER
V2
V1 V3
O2-O2+
Static
400V (L-L)
230V (L-N)
Pulse output
30VDC 50mA
L
A
O
D
CURRENT
S1 S2 S1 S2 S1 S2
I1 I2 I3
CT1
CT2
L1
L3
L2
VN
O1-
T2T1 O1+
METER
V2
V1 V3
O2-O2+
Static
400V (L-L)
230V (L-N)
Pulse output
30VDC 50mA
L
A
O
D
CT1
CT3
CURRENT
S1 S2 S1 S2 S1 S2
I1 I2 I3

I509 GB CS 09 17 31100345
G
B
13
TERMINALS ARRANGEMENT AND MECHANICAL DIMENSIONS [ mm]
90
71.6
104.7
58
45
Ø4.2
5 43.7
98.3
S1 S2
I1 I2
S2
S1 S1 S2
I3
T1 T2
SG
B
A
TR
V2V1V3VN

TECHNICAL SPECIFICATIONS
Auxiliary supply
Rated voltage Us 230V
~ L-N / 400V ~ L-L
The device may operate with or without neutral
Voltage range 187-264V
~ L-N / 323-456V ~ L-L
Rated frequency 50Hz
Frequency range 45-66Hz
Power consumption/dissipation 3.5VA / 2.7W
Current
IEC maximum current (Imax) 6A
IEC minimum current (lmin) 0.05A
IEC rated current (Iref - I ) 5A
IEC start current (Ist) 0.010A
IEC transition current (Itr) 0.25A
Burden (per phase) ≤ 0.3W
Tariff control circuit
Rated voltage Uc 100-240V
~
Voltage range 85-264V ~
Rated frequency 50/60Hz
Frequency range 45-66Hz
Power consumption/dissipation 0.25VA / 0.18W
Accuracy
Active energy (EN 50470-3) Class B
LED pulse
Pulse rated 10.000 puls/kWh (referred to CT secondary)
Pulse duration 30ms
Static outputs
Programma le n. of pulses and duration 0.1 - 1 - 10 - 100 p/kWh, 10 - 1000ms
Exetrnal voltage 10 - 30V=
Maximum current 50mA
Insulation
IEC rated insulation voltage Ui 250V
~ (L-N) 415V ~ (L-L)
IEC rated impulse withstand voltage Uimp 6kV
IEC power frequency withstand voltage 4kV
I509 GB CS 09 17 31100345
G
B
Measurement and tariff power supply circuit connection
Type of terminal Screw-type (fixed)
Num er of terminals 4 for supply / measurement
2 for tariff selection input
Ca le cross section (min…max) 0.2…4.0mm² (24...12 AWG)
Tightening torque 0.8Nm (7 l in)
Current input and static output connections
Type of terminal Screw-type (fixed)
Num er of terminals 6 for CT connections
Ca le cross section (min…max) 0.2…2.5mm² (24...12 AWG)
Tightening torque 0.44Nm (4 l in)
Ambient conditions
Mounting For indoor use only
Operating temperature −25 – +55°C
Storage temperature −25 – +70°C
Relative humidity <80% (IEC/EN 60068-2-70)
Maximum pollution degree 2
Overvoltage category 3
Altitude ≤2000m
Climatic sequence Z/ABDM (IEC/EN 60068-2-61)
Shock resistance 15g (IEC/EN 60068-2-27)
Vi ration resistance 0.7g (IEC/EN 60068-2-6)
Housing
Version 4 modules (DIN 43880)
Mounting 35mm rail (IEC/EN 60715) or screw-type y means
of remova le clips
Material Polyamide RAL 7035
Degree of protection IP40 on front∂; IP20 terminals
Weight 332g
Certifications and compliance
Certifications o tained EAC, RCM
Reference standards EN 50470-1, EN 50470-3, TR 50579
To guarantee the required protection, the instrument must e installed in container with minimum protection rating of IP51
(IEC/EN 60529).
GB
14

I509 B CS 09 17 31100345
CS
15
DME D305T2MID
TŘÍFÁZOVÝ ELEKTROMĚR S ŘI OJENÍM ŘES ROUDOVÉ TRANSFORMÁTORY
SE 2 STATICKÝMI VÝSTU Y
Návod k použití
CS
LOVATO ELECTRIC S. .A.
24020 ORLE (BER AMO) ITALIA
VIA DON E. MAZZA, 12
TEL. [phone]
FAX (italský): 035 4282200
FAX (mezinárodní): [phone]
E-mail [e-mail]
Web www.LovatoElectric.com
Prohlášení EU: http://www.lovatoelectric.com/DMED305T2MID/DMED305T2MID/snp
WARNING!
– Carefully read the manual efore the installation or use.
– This equipment is to e installed y qualified personnel, complying to current standards, to avoid
damages or safety hazards.
– Before any maintenance operation on the device, remove all the voltages from measuring and supply inputs and short-
circuit the CT input terminals.
– The manufacturer cannot e held responsi le for electrical safety in case of improper use of the equipment.
– Products illustrated herein are su ject to alteration and changes without prior notice. Technical data and descriptions
in the documentation are accurate, to the est of our knowledge, ut no lia ilities for errors, omissions or
contingencies arising there from are accepted.
– A circuit reaker must e included in the electrical installation of the uilding. It must e installed close y the
equipment and within easy reach of the operator. It must e marked as the disconnecting device of the equipment:
IEC /EN 61010-1 § 6.11.2.
– Clean the device with a soft dry cloth; do not use a rasives, liquid detergents or solvents.
ATTENZIONE!
– Leggere attentamente il manuale prima dell’utilizzo e l’installazione.
– Questi apparecchi devono essere installati da personale qualificato, nel rispetto delle vigenti normative
impiantistiche, allo scopo di evitare danni a persone o cose.
– Prima di qualsiasi intervento sullo strumento, togliere tensione dagli ingressi di misura e di alimentazione e
cortocircuitare i trasformatori di corrente.
– Il costruttore non si assume responsa ilità in merito alla sicurezza elettrica in caso di utilizzo improprio del dispositivo.
– I prodotti descritti in questo documento sono suscetti ili in qualsiasi momento di evoluzioni o di modifiche. Le
descrizioni ed i dati a catalogo non possono pertanto avere alcun valore contrattuale.
– Un interruttore o disgiuntore va compreso nell’impianto elettrico dell’edificio. Esso deve trovarsi in stretta vicinanza
dell’apparecchio ed essere facilmente raggiungi ile da parte dell’operatore. Deve essere marchiato come il dispositivo
di interruzione dell’apparecchio: IEC/ EN 61010-1 § 6.11.2.
– Pulire l’apparecchio con panno mor ido, non usare prodotti a rasivi, detergenti liquidi o solventi.
ATTENTION !
– Lire attentivement le manuel avant toute utilisation et installation.
– Ces appareils doivent être installés par un personnel qualifié, conformément aux normes en vigueur en
matière d'installations, afin d'éviter de causer des dommages à des personnes ou choses.
– Avant toute intervention sur l'instrument, mettre les entrées de mesure et d'alimentation hors tension et court-circuiter
les transformateurs de courant.
– Le constructeur n'assume aucune responsa ilité quant à la sécurité électrique en cas d'utilisation impropre du
dispositif.
– Les produits décrits dans ce document sont suscepti les d'évoluer ou de su ir des modifications à n'importe quel
moment. Les descriptions et caractéristiques techniques du catalogue ne peuvent donc avoir aucune valeur
contractuelle.
– Un interrupteur ou disjoncteur doit être inclus dans l'installation électrique du âtiment. Celui-ci doit se trouver tout
près de l'appareil et l'opérateur doit pouvoir y accéder facilement. Il doit être marqué comme le dispositif d'interruption
de l'appareil : IEC/ EN 61010-1 § 6.11.2.
– Nettoyer l’appareil avec un chiffon doux, ne pas utiliser de produits a rasifs, détergents liquides ou solvants.
UWAGA!
– Prze użyciem i instalacją urzą zenia należy uważnie przeczytać niniejszą instrukcję.
– W celu uniknięcia obrażeń osób lub uszko zenia mienia tego typu urzą zenia muszą być instalowane przez
wykwalifikowany personel, zgo nie z obowiązującymi przepisami.
– Prze rozpoczęciem jakichkolwiek prac na urzą zeniu należy o łączyć napięcie o wejść pomiarowych i zasilania oraz zewrzeć
zaciski przekła nika prą owego.
– Pro ucent nie przyjmuje na siebie o powie zialności za bezpieczeństwo elektryczne w przypa ku niewłaściwego użytkowania
urzą zenia.
– Pro ukty opisane w niniejszym okumencie mogą być w każ ej chwili u oskonalone lub zmo yfikowane. Opisy oraz ane
katalogowe nie mogą mieć w związku z tym ża nej wartości umownej.
– W instalacji elektrycznej bu ynku należy uwzglę nić przełącznik lub wyłącznik automatyczny. Powinien on znaj ować się w
bliskim sąsie ztwie urzą zenia i być łatwo osiągalny przez operatora. Musi być oznaczony jako urzą zenie służące o
wyłączania urzą zenia: IEC/ EN 61010-1 § 6.11.2.
– Urzą zenie należy czyścić miękką szmatką, nie stosować śro kow ściernych, płynnych etergentow lub rozpuszczalnikow.
ACHTUNG!
– Dieses Hand uch vor Ge rauch und Installation aufmerksam lesen.
– Zur Vermeidung von Personen- und Sachschäden dürfen diese Geräte nur von qualifiziertem
Fachpersonal und unter Befolgung der einschlägigen Vorschriften installiert werden.
– Vor jedem Eingriff am Instrument die Spannungszufuhr zu den Messeingängen trennen und die Stromwandler
kurzschlieβen.
– Bei zweckwidrigem Ge rauch der Vorrichtung ü ernimmt der Hersteller keine Haftung für die elektrische Sicherheit.
– Die in dieser Broschüre eschrie enen Produkte können jederzeit weiterentwickelt und geändert werden. Die im
Katalog enthaltenen Beschrei ungen und Daten sind daher unver indlich und ohne Gewähr.
– In die elektrische Anlage des Ge äudes ist ein Ausschalter oder Trennschalter einzu auen. Dieser muss sich in
unmittel arer Nähe des Geräts efinden und vom Bediener leicht zugänglich sein. Er muss als Trennvorrichtung für das
Gerät gekennzeichnet sein: IEC/ EN 61010-1 § 6.11.2.
– Das Gerät mit einem weichen Tuch reinigen, keine Scheuermittel, Flüssigreiniger oder Lösungsmittel verwenden.
ADVERTENCIA
– Leer atentamente el manual antes de instalar y utilizar el regulador.
– Este dispositivo de e ser instalado por personal cualificado conforme a la normativa de instalación
vigente a fin de evitar daños personales o materiales.
– Antes de realizar cualquier operación en el dispositivo, desconectar la corriente de las entradas de alimentación y
medida, y cortocircuitar los transformadores de corriente.
– El fa ricante no se responsa ilizará de la seguridad eléctrica en caso de que el dispositivo no se utilice de forma
adecuada.
– Los productos descritos en este documento se pueden actualizar o modificar en cualquier momento. Por consiguiente,
las descripciones y los datos técnicos aquí contenidos no tienen valor contractual.
– La instalación eléctrica del edificio de e disponer de un interruptor o disyuntor. Éste de e encontrarse cerca del
dispositivo, en un lugar al que el usuario pueda acceder con facilidad. Además, de e llevar el mismo marcado que el
interruptor del dispositivo (IEC/ EN 61010-1 § 6.11.2).
– Limpiar el dispositivo con un trapo suave; no utilizar productos a rasivos, detergentes líquidos ni disolventes.
ПРЕДУПРЕЖДЕНИЕ!
– Прежде чем приступать к монтажу или эксплуатации устройства, внимательно ознакомьтесь с одержанием
настоящего руководства.
– Во избежание травм или материального ущерба монтаж должен существляться только квалифицированным персоналом
в соответствии с действующими нормативами.
– Перед проведением любых работ по техническому обслуживанию устройства необходимо обесточить все
измерительные и питающие входные контакты, а также замкнуть накоротко входные контакты трансформатора тока (ТТ).
– Производитель не несет ответственность за обеспечение электробезопасности в случае ненадлежащего использования
устройства.
– Изделия, описанные в настоящем документе, в любой момент могут подвергнуться изменениям или
усовершенствованиям. Поэтому каталожные данные и описания не могут рассматриваться как действительные с точки
зрения контрактов
– Электрическая сеть здания должна быть оснащена автоматическим выключателем, который должен быть расположен
вблизи оборудования в пределах доступа оператора. Автоматический выключатель должен быть промаркирован как
отключающее устройство оборудования: IEC /EN 61010-1 § 6.11.2.
– Очистку устройства производить с помощью мягкой сухой ткани, без применения абразивных материалов, жидких
моющих средств или растворителей.
UPOZORNĚNÍ
– Návo se pozorně pročtěte, než začnete přístroj instalovat a používat.
– Tato zařízení smí instalovat kvalifikovaní pracovníci v soula u s platnými pře pisy a normami pro pře cházení
úrazů osob či poškození věcí.
– Pře jakýmkoli zásahem o přístroje o pojte měřicí a napájecí vstupy o napětí a zkratujte transformátory prou u.
– Výrobce nenese o pově nost za elektrickou bezpečnost v přípa ě nevho ného používání přístroje.
– Výrobky popsané v tomto okumentu mohou k ykoli projít úpravami či alším vývojem. Popisy a ú aje uve ené v katalogu
nemají proto žá nou smluvní ho notu.
– Spínač či o pojovač je nutno zabu ovat o elektrického rozvo u v bu ově. Musejí být nainstalované v těsné blízkosti přístroje a
sna no ostupné pracovníku obsluhy. Je nutno ho označit jako vypínací zařízení přístroje: IEC/ EN 61010-1 § 6.11.2.
– Přístroj čistěte měkkou utěrkou, nepoužívejte abrazivní pro ukty, tekutá čisti la či rozpouště la.
DİKKAT!
– Montaj ve kullanım an önce bu el kitabını ikkatlice okuyunuz.
– Bu aparatlar kişilere veya nesnelere zarar verme ihtimaline karşı yürürlükte olan sistem kurma normlarına göre
kalifiye personel tarafın an monte e ilmeli irler
– Aparata (cihaz) herhangi bir mü ahale e bulunma an önce ölçüm girişlerin eki gerilimi kesip akım transformatörlerine e kısa
evre yaptırınız.
– Üretici aparatın hatalı kullanımın an kaynaklanan elektriksel güvenliğe ait sorumluluk kabul etmez.
– Bu oküman a tarif e ilen ürünler her an evrimlere veya eğişimlere açıktır. Bu sebeple katalog aki tarif ve eğerler herhangi bir
bağlayıcı eğeri haiz eğil ir.
– Binanın elektrik sistemin e bir anahtar veya şalter bulunmalı ır. Bu anahtar veya şalter operatörün kolaylıkla ulaşabileceği yakın
bir yer e olmalı ır. Aparatı (cihaz) evre en çıkartma görevi yapan bu anahtar veya şalterin markası: IEC/ EN 61010-1 § 6.11.2.
– Aparatı (cihaz) sıvı eterjan veya solvent kullanarak yumuşak bir bez ile siliniz aşın ırıcı temizlik ürünleri kullanmayınız.
AVERTIZARE!
– Citiţi cu atenţie manualul înainte e instalare sau utilizare.
– Acest echipament va fi instalat e personal calificat, în conformitate cu stan ar ele actuale, pentru a evita
eteriorări sau pericolele.
– Înainte e efectuarea oricărei operaţiuni e întreţinere asupra ispozitivului, în epărtaţi toate tensiunile e la intrările e
măsurare şi e alimentare şi scurtcircuitaţi bornele e intrare CT.
– Pro ucătorul nu poate fi consi erat responsabil pentru siguranţa electrică în caz e utilizare incorectă a echipamentului.
– Pro usele ilustrate în prezentul sunt supuse mo ificărilor şi schimbărilor fără notificare anterioară. Datele tehnice şi escrierile
in ocumentaţie sunt precise, în măsura cunoştinţelor noastre, ar nu se acceptă nicio răspun ere pentru erorile, omiterile sau
evenimentele neprevăzute care apar ca urmare a acestora.
– Trebuie inclus un isjunctor în instalaţia electrică a clă irii. Acesta trebuie instalat aproape e echipament şi într-o zonă uşor
accesibilă operatorului. Acesta trebuie marcat ca fiin ispozitivul e econectare al echipamentului: IEC/EN 61010-1 § 6.11.2.
– Curăţaţi instrumentul cu un material textil moale şi uscat; nu utilizaţi substanţe abrazive, etergenţi lichizi sau solvenţi.

I509 B CS 09 17 31100345
CS
16
OBSAH STRANA
Úvod .................................................................................................................................................................................................................................................................................................................................................................................................................................... 2
Popis.................................................................................................................................................................................................................................................................................................................................................................................................................................... 2
Funkce předních tlačítek ...................................................................................................................................................................................................................................................................................................................................................................................................... 2
Indikace na displeji .............................................................................................................................................................................................................................................................................................................................................................................................................. 2
Zobrazení rozměrů............................................................................................................................................................................................................................................................................................................................................................................................................... 3
Hlavní stránka...................................................................................................................................................................................................................................................................................................................................................................................................................... 3
Přední metrologická kontrolka ............................................................................................................................................................................................................................................................................................................................................................................................ 3
Tabulka s přehledem stránek zobrazovaných na displeji ..................................................................................................................................................................................................................................................................................................................................................... 4
Procházení stránkami na displeji ......................................................................................................................................................................................................................................................................................................................................................................................... 6
Indikace poskytovaná počitadly energie.............................................................................................................................................................................................................................................................................................................................................................................. 7
Sazby ................................................................................................................................................................................................................................................................................................................................................................................................................................... 7
Indikace poskytovaná počitadlem hodin.............................................................................................................................................................................................................................................................................................................................................................................. 7
Ukazování mezních stavů (LIMx) ......................................................................................................................................................................................................................................................................................................................................................................................... 8
Indikace alarmů ................................................................................................................................................................................................................................................................................................................................................................................................................... 8
Hlavní menu ........................................................................................................................................................................................................................................................................................................................................................................................................................ 8
Nastavení parametrů z předního panelu.............................................................................................................................................................................................................................................................................................................................................................................. 8
Tabulka parametrů .............................................................................................................................................................................................................................................................................................................................................................................................................. 9
Příkazové menu .................................................................................................................................................................................................................................................................................................................................................................................................................. 12
Test spojení.......................................................................................................................................................................................................................................................................................................................................................................................................................... 12
Schémata zapojení............................................................................................................................................................................................................................................................................................................................................................................................................... 12
Uspořádání svorek a mechanické rozměry (mm) ................................................................................................................................................................................................................................................................................................................................................................. 13
Technické charakteristiky..................................................................................................................................................................................................................................................................................................................................................................................................... 14
ÚVOD
Elektroměr s připojením přes proudové transformátory PT, typ DMED305T2 je navržen pro co nejjednodušší použití s širokým výběrem funkcí. Tento elektroměr poskytuje stejné parametry jako přístroje vyšších řad. Podsvícený displej LCD poskytuje přehledné a intuitivní uživatelské
rozhraní. DME D305T2MID je dále vybaveno dvěma statickými výstupy pro generování impulsů a jedním vstupem pro přepínání sazeb.
POPIS
– Třífázový elektroměr.
– Připojení přes proudové transformátory PT.
– Modulární provedení 4U (72mm) pro lišty DIN.
– Podsvícený displej LCD.
– 2 statické výstupy.
– Vstup pro přepínání sazeb v AC.
– Tři tlačítka pro procházení funkcemi a nastaveními.
– Metrologická kontrolka ukazování energetického toku.
– Vysoká přesnost měření skutečné efektivní hodnoty True RMS (TRMS).
– Měření činné energie dle EN 50470-3 třída B.
– Počitadla celkové činné a jalové energie a podle jednotlivých fází
– Nulovatelná počitadla celkové a dílčí energie.
– Jedno počitadlo celkové energie a čtyři počitadla dílčí energie.
– Programovatelný vstup (např. pro výběr sazeb).
– Ochrana nastavení dvouúrovňovým heslem.
– Záložní kopie původních nastavení.
– Montáž bez nářadí.
– Krytky svorek: krytky lze plombovat.
– Text v šesti jazycích (anglicky, italsky, francouzsky, španělsky, portugalsky, německy).
FUNKCE TLAČÍTEK NA ČELNÍM PANELU
Tlačítka
s a t – Slouží pro procházení stránek na displeji, výběr z voleb zobrazovaných na displeji a úpravu nastavení (zvýšení/snížení).
Současným stiskem (
s + t ) slouží pro vstup do jednotlivých zobrazovacích i nastavovacích menu a pro výstup z nich.
Tlačítko – slouží pro procházení pod-stránek, potvrzení výběru a přechod mezi jednotlivými režimy zobrazení.
INDIKACE NA DISPLEJI
Hlavní displej
naměřených hodnot
Ikona Alarm
Indikace
podstránky
(typ měření)
Hlavní displej
naměřených
hodnot
Indikace stránky
naměřených hodnot
Grafická lišta
Aktivní
komunikace
Indikace
zvolených fází
Indikace
nejvyšší
hodnoty měřítka
grafické lišty

I509 B CS 09 17 31100345
CS
17
HLAVNÍ STRÁNKA
činn v kon
měřen v soustavě
Procento činného
v konu vůči
jmenovitému v konu
soustavy
Počitadlo
celkové činné
energie
Aktivní
komunikace
RS485 (blikající)
– Na hlavní stránce se zobrazuje činný výkon, který se právě používá v soustavě, procento činného výkonu ve srovnání se jmenovitým výkonem soustavy a počitadlo celkové činné energie systému.
– Uživatel má možnost určit, na jakou stránku a podstránku se má displej DME D305T2MID automaticky vrátit po uplynutí času bez stisknutí tlačítek.
– Počitadlo energií lze naprogramovat i tak, aby zobrazení zůstalo tam, kde bylo zanecháno.
– Pro nastavení těchto funkcí viz menu P02 – Utility.
ČELNÍ METROLO ICKÁ KONTROLKA
– Přední červená kontrolka vysílá 10 000 impulzů za každou kWh spotřebované energie vztažené na sekundární vinutí PT.
– Četnost blikání kontrolky poskytuje okamžitou indikaci velikosti výkonu požadovaného v daném okamžiku.
– Interval blikání, barva a intenzita svícení kontrolky odpovídají normám předepisujícím použití těchto kontrolek pro metrologickou kontrolu přesnosti počitadla energie.
ZOBRAZENÍ NAMĚŘENÝCH HODNOT
– Tlačítka
s a t umožňují procházet jednotlivými stránkami pro zobrazení naměřených hodnot. Aktuální stránka se pozná podle zobrazené měrné jednotky v horní části displeje.
– Některé hodnoty nemusejí být zobrazeny: to závisí na naprogramování a připojení přístroje (jestliže je například naprogramovaný pro systém bez nulového vodiče, nezobrazí se hodnoty pro tento vodič).
– Na každé stránce umožňuje tlačítko přístup na podstránky (například pro zobrazení maximálních a minimálních hodnot zapsaných pro zvolené měření).
– Běžně zobrazená podstránka je ukázána dole vpravo jednou z následujících ikon:
– IN = Okamžitá hodnota – Okamžitá stávající hodnota se defaultně zobrazí při každé změně stránky.
– HI = Maximální okamžitá hodnota – Nejvyšší hodnota naměřená multimetrem pro příslušné měření. Hodnoty HI H se uloží do paměti, kde zůstanou i bez napájení. Lze je vynulovat příslušným příkazem (viz příkazové menu).
– LO = Minimální okamžitá hodnota – Nejnižší hodnota naměřená multimetrem od připojení napětí. Resetuje se stejným příkazem jako hodnot HI.
– AV = Integrovaná hodnota – Hodnota integrovaného (zprostředkovaného) měření v čase. Umožňuje zobrazit měření s pomalými změnami. Viz menu Integrace
– MD = Maximální integrovaná hodnota – Maximální hodnota integrované hodnoty (max demand). Zůstane v energeticky nezávislé paměti a lze ji resetovat příslušným příkazem.

I509 B CS 09 17 31100345
CS
TABULKA S PŘEHLEDEM STRÁNEK ZOBRAZOVANÝCH NA DISPLEJI
Výběr pomocí
s a t Výběr pomocí
Č. STRÁNKY
STRÁNKY
1 ČINNÁ ENER IE – ČINNÝ VÝKON
kWh(TOT) – kW (TOT) – %kW vůči jmenovité hodnotě
2 POČITADLA ČINNÉ ENER IE IMP
kWh+(SYS) PAR SYS TAR-1 TAR-2
kWh+(SYS) TOT
3 POČITADLA ČINNÉ ENER IE EXP
kWh-(SYS) PAR SYS TAR-1 TAR-2
kWh-(SYS) TOT
4 POČITADLA JALOVÉ ENER IE IMP
kvarh+(SYS) PAR SYS TAR-1 TAR-2
kvarh+(SYS) TOT
5 POČITADLA JALOVÉ ENER IE EXP
Kvarh-(SYS) PAR SYS TAR-1 TAR-2
Kvarh-(SYS) TOT
6 POČITADLA CELKOVÉ ENER IE
kVAh(SYS) PAR SYS TAR-1 TAR-2
kVAh(SYS) TOT
7 POČITADLA ENER IÍ (L1)
kWh+(L1) PAR SYS TAR-1 TAR-2
kWh+(L1) TOT
8 POČITADLA ENER IÍ (L2)
kWh+(L2) PAR SYS TAR-1 TAR-2
kWh+(L2) TOT
9 POČITADLA ENER IÍ (L3)
kWh+(L3) PAR SYS TAR-1 TAR-2
kWh+(L3) TOT
10 POČITADLA ENER IÍ (L1)
kWh-(L1) PAR SYS TAR-1 TAR-2
kWh-(L1) TOT
11 POČITADLA ENER IÍ (L2)
kWh-(L2) PAR SYS TAR-1 TAR-2
kWh-(L2) TOT
12 POČITADLA ENER IÍ (L3)
kWh-(L3) PAR SYS TAR-1 TAR-2
kWh-(L3) TOT
13 POČITADLA ENER IÍ (L1)
kvarh+(L1) PAR SYS TAR-1 TAR-2
kvarh+(L1) TOT
14 POČITADLA ENER IÍ (L2)
kvarh+(L2) PAR SYS TAR-1 TAR-2
kvarh+(L2) TOT
15 POČITADLA ENER IÍ (L3)
kvarh+(L3) PAR SYS TAR-1 TAR-2
kvarh+(L3) TOT
16 POČITADLA ENER IÍ (L1)
kvarh-(L1) PAR SYS TAR-1 TAR-2
kvarh-(L1) TOT
17 POČITADLA ENER IÍ (L2)
kvarh-(L2) PAR SYS TAR-1 TAR-2
kvarh-(L2) TOT
18 POČITADLA ENER IÍ (L3)
kvarh-(L3) PAR SYS TAR-1 TAR-2
kvarh-(L3) TOT
19 POČITADLA ENER IÍ (L1)
kVAh(L1) PAR SYS TAR-1 TAR-2
kVAh(L1) TOT
20 POČITADLA ENER IÍ (L2)
kVAh(L2) PAR SYS TAR-1 TAR-2
kVAh(L2) TOT
21 POČITADLA ENER IÍ (L3)
kVAh(L3) PAR SYS TAR-1 TAR-2
kVAh(L3) TOT
22 SDRUŽENÁ NAPĚTÍ
V(L1-L2), V(L2-L3), V(L3-L1), V(LL)EQV HI LO AV
23 FÁZOVÁ NAPĚTÍ
V(L1-N), V(L2-N), V(L3-N), V(L-N)EQV HI LO AV
24 FÁZOVÉ PROUDY A NULA
I(L1), I(L2), I(L3), I(N) HI LO AV MD
25 ČINNÝ VÝKON
P(L1), P(L2), P(L3), P(TOT) HI LO AV MD
26 JALOVÝ VÝKON
Q(L1), Q(L2), Q(L3), Q(TOT) HI LO AV MD
27 CELKOVÝ VÝKON
S(L1), S(L2), S(L3), S(TOT) HI LO AV MD
28 ÚČINÍK
PF(L1), PF(L2), PF(L3), PF(EQ) HI LO AV
18

I509 B CS 09 17 31100345
CS
19
TABULKA S PŘEHLEDEM STRÁNEK ZOBRAZOVANÝCH NA DISPLEJI
Výběr pomocí
s a t Výběr pomocí
Č. STRÁNKY
STRÁNKY
29 NEVYVÁŽENOST ČINNÉHO VÝKONU
L1-L2, L2-L3, L3-L1 HI LO AV
30 KMITOČET
Hz HI LO AV
31 ASYMETRIE ASY(VLL) HI LO AV
32 ASYMETRIE ASY(VLN) HI LO AV
33 ASYMETRIE ASY(I) HI LO AV
34 HARM. ZKRESLENÍ NAPĚTÍ SDRUŽENÉ L-L
THD-V(L1-L2), THD-V(L2-L3), THD-V(L3-L1) HI LO AV
35 HARM. ZKRESLENÍ NAPĚTÍ L-N
THD-V(L1),THD-V(L2),THD-V(L3) HI LO AV
36 HARM. ZKRESLENÍ PROUDU
THD-I(L1), THD-I(L2) THD-I(L3) HI LO AV
37 POČITADLO HODIN
hhhhhh-mm-ss TOT PAR-1 PAR-2 PAR-3 PAR-4
38 MEZE
LIM1–LIM2–LIM3–LIM4
39 ALARMY
ALA1–ALA2–ALA3–ALA4
40 ZVOLENÁ SAZBA (tAr-1 a tAr-2)
41 INFO-REVIZE-SÉROVÉ ČÍSLO
MODEL, REV SW, SÉROVÉ ČÍS.
POZNÁMKA: Stránky zvýrazněné šedě ve výše uvedené tabulce nemusí být zobrazeny v případě, že funkce nebo je kontrolující parametry nejsou povoleny. Jestliže není například naprogramovaný žádný alarm, příslušná stránka se nezobrazí.

I509 B CS 09 17 31100345
CS
NAVI ACE MEZI STRÁNKAMI DISPLEJE SDRUŽENÁ NAPĚTÍ
20
= Okamžitá hodnota = Nejvyšší hodnota = Nejnižší hodnota = Průměrná hodnota
= Okamžitá hodnota = Nejvyšší hodnota = Nejnižší hodnota = Průměrná hodnota
= Okamžitá hodnota = Nejvyšší hodnota = Nejnižší hodnota = Průměrná hodnota
= Okamžitá hodnota
= Max. hodnota Demand
= Nejvyšší hodnota = Nejnižší hodnota = Průměrná hodnota
Fázová napětí
Fázové proudy a nula
Činný a celkový fázový výkon
