Montwill M2-1f series User manual

Technical features:

• red display of -19999…99999 digits (optional: green, orange or blue display)

• minimal installation depth: 70 mm without plug-in terminal

• min/max memory

• adjustment via factory default or directly on the sensor signal

• 30 adjustable supporting points

• display flashing at threshold undercut or exceedance

• simplified parameterisation U/min with only 3 parameters

• Schmitt-trigger-input

• zero-key for triggering of Hold, Tara

• permanent min/max-value recording

• digital frequency filter for contact bounce suppression and interference suppresion

• frequency filter with varying pulse-duty factor

• volume metering (totaliser) for frequencies up to 1 kHz (accurate to a pulse)

• mathematical function like reciprocal value, square root, rounding

• sliding averaging with an optional dynamic display filter

• setpoint generator

• brightness control

• programming interlock via access code

• protection class IP65 at the front

• plug-in terminal

• sensor supply

• galv. isolated digital input

• option: relay outputs

• option: analog output

• accessories: PC-based configuration-kit PM-TOOL incl. CD & USB-adapter

User manual M2-1F

Frequency input: 0.01 Hz to 999.99 kHz / 0.01 Hz to 9.9999 kHz / 0-2.500 kHz

Connection for Namur, NPN/PNP with HTL- or TTL-output or for

position survey via incremental encoder

96x48M2_1FGB.pdf update: 28.05.2020

Identification

STANDARD-TYPES ORDER NUMBER

Frequency

Housing size: 96x48 mm

M2-1FR5B.0307.570xD

M2-1FR5B.0007.670xD

Please state physical unit by order, e.g. m/min.

Options – breakdown of order code:

M 2- 1 F R 5 B. 0 3 0 7. 5 7 0 x D

Basic type M2 Dimension

D physical unit

Installation depth

89 mm, incl.plug-in terminal 2Version

x internal version

Housing size

B96xH48xT70 mm 1Switching points

0 no switching points

Type of display 2 2 relay outputs

Frequency F

Protection class

Display colour 1 without keypad,

Blue B operation via PM-TOOL

Green G 7 IP65 / plug-in terminal

Red R

Yellow YVoltage supply

4 115 VAC

Number of digits 5 230 VAC

5-digit 5 6 10-30 VDC galv. isolated

8 24 VDC

Digit height

14 mm BMeasuring input

1 0.01 Hz to 999.99 kHz

Digital input

without 0Analog output

one I 0 without

X 0-10 VDC, 0/4-20 mA

Sensor supply

without 0

10 VDC / 20 mA, incl. digital input 2

24 VDC / 50 mA, incl. digital input 3

24 VDC / 50 mA, incl. digital input K

and pulse output max 10 kHz

Contents

1. Brief description 1

2. Assembly 2

3. Electrical connection 3

4. Function description and operation 7

4.1. Programming software PM-TOOL 8

5. Setting up the device 9

5.1. Switching on 9

5.2. Standard parameterisation (flat operation level) 9

Value assignment for the triggering of the signal input

5.3. Programming interlock 15

Activation/Deactivation of the programming interlock or change into professional

or flat operation level

5.4. Extended parameterisation (professional operation level) 16

5.4.1. Signal input parameters „ “ 16

Value assignment for the triggering of the signal input incl. linearisation

5.4.2. General device parameters „ “ 21

Superior device functions like Hold, Tara, min/max permanent, setpoint value function /

nominal value function, averaging, brightness control, as well as the control of the

digital input and keyboard layout

5.4.3. Safety parameters „ “ 26

Assignment of user and master code to lock or to receive access to defined

parameter such as analog output and alarms, etc.

5.4.4. Analog output parameters „ “ 28

Analog output functions

5.4.5. Relay functions „ “ 30

Parameter for setpoint definition

5.4.6. Alarm parameters „ “ 32

Actuator and dependencies of the alarms

5.4.7. Totaliser (Volume metering) „ “ 34

Parameter for calculation of the sum function

6. Reset to factory settings 36

Reset parameters onto the delivery state

7. Alarms / Relays 36

Functional principle of the switching outputs

8. Programmer examples 38

Sample applications like e.g. calculation of the input frequency or the adjustment at unknown

rotation speed

9. Technical data 41

10. Safety advices 43

11. Error elimination 44

1. Brief description

The panel meter M2-1F can evaluate pulses in many different ways and shows the result in the

5-digit LED-display. Available options are: frequency coverage with optional filters, summate of

pulses or display values via the time, detection of a rotational speed or collection of a position

via an incremental encoder. The results can be monitored via alarm conditions and can be

displayed onto the optional switching point. Furthermore the results can be freely scaled on an

optional analog output and relayed to a control system. The device can be operated directly by

Namur sensors, 3-wire sensors, switching/slider contacts, incremental encoders (HTL-/TTL-

output) or TTL-signals.

Via the 4 navigation keys on the front, the device can be adjusted onto different kind of

applications and later on different functions of the device can be controlled. The adjustment is

also possible via the PC-Software PM-TOOL with a special connecting cable. With an individual

code, the created parameterisation can be protected against changes by the user.

Numerous applications can be realised with this device, like e.g. tachometer, revolution

counter, flowmeter, dosing equipment, filling capacity meter, baking time meter of a baking

oven, flying knife, position evaluation, position surveillance, flow rate surveillance, acoustic

discharge measurements and so on. By use of the integrated, configurable functions like

permanent min/max-recording, averaging, frequency filter, setpoint setting, threshold value

recording via alarm system, 30-points-linearisation, mathematic charging and many more, you

receive an universal applicable modern system for your demands in measuring and control

technique.

2. Assembly

Please read the Safety advices on page 43 before installation and keep this user manual for

future reference.

Sealing

48,0

3,0

Installation depth incl. plug-in termnal

Gap for physical unit

89,0

1. After removing the fixing elements, insert the device.

2. Check the seal to make sure it fits securely.

3. Click the fixing elements back into place and tighten the clamping screws by hand. Then use

a screwdriver to tighten them another half a turn.

CAUTION! The torque should not exceed 0.1 Nm!

The dimension symbols can be exchanged before installation via a channel on the side!

3. Electrical connection

Type M2-1FR5B.0307.470xD – supply of 115 VAC

Type M2-1FR5B.0307.570xD – supply of 230 VAC

21 22 23 24 25 26

S1 S2

Options

Relay 1 Relay 2

1 2 3 10 119

4 5 6 7 8

TTL

Namur

Pulse input 1

Sensor

supply

24 VDC

3-wire

sensor

230 VAC

115 VAC

N L

Digital

input

Pulse input 2

TTL

Namur

3-wire

sensor

Pulse output

max. 10 kHz

alternatively to pulse input 2

3. Electrical connection

Advice:

If Namur sensors with a nominal voltage of approx. 8 V are used, then a sensor supply of 12

VDC is needed. For devices with a sensor supply terminals 4 and 8, aswell as terminals 3 and

7 need to be galvanically connected in the device.

Type M2-1FR5B.0007.670xD – supply of 10-30 VDC galv. isolated

1 2 3 10 119

4 5 6 7 8

TTL

Namur

Pulse input 1

3-wire

sensor

10-30 VDC

Pulse input 2

TTL

Namur

3-wire

sensor

21 22 23 24 25 26

S1 S2

alternatively to

pulse input 2

Relais 1 Relais 2

Pulse output

max. 10 kHz

7 8 9

10 V

0 V

0/4-20 mA

Analog output

Options:

3 9

4 5 6 7 8

Sensor

supply

alternatively to analog output

Digital

input

0 V

3. Electrical connection

M3-devices

Below please find some connection examples with practical applications:

10-30 VDC

Namur

123 10 1194 5 6 7 8

N A MUR

230 VAC

Namur

NAMUR

1 2 3 10 1194 5 6 7 8

10-30 VDC

3-wire PNP

3-wire

_ +

123 10 1194 5 6 7 8

230 VAC

_ +

3-wire PNP

3-wire

12 3 10 11

4 5 6 7 8

3. Electrical connection

10-30 VDC

Pull-up

(extern)

3-wire NPN

3-wire

_ +

2,7 k

0,5 W

12 3 10 11

4 5 6 7 8

230 VAC

_ +

3-wire NPN

3-wire

Pull-up

(extern)

2,7 k

0,5 W

12 3 10 11

4 5 6 7 8

10-30 VDC

Incremental encoder with analog output 4-20 mA

123 10 1194 5 6 7 8

Incremental encoder

A B

Incremental encoder (max. 50 mA current consumption)

115VAC

230 VAC

_ +

123 10 1194 5 6 7 8

N L

Incremental encoder

external

reset

4. Function and operation description

Operation

The operation is divided into three different levels.

Menu level (delivery status)

This level is for the standard settings of the device. Only menu items which are sufficent to set

the device into operation are displayed. To get into the professional level, run through the menu

level and parameterise under menu item .

Menu group level (complete function volume)

Suited for complex applications as e.g. linkage of alarms, setpoint treatment, totaliser function

etc. In this level function groups which allow an extended parameterisation of the standard

settings are availabe. To leave the menu group level, run through this level and parameterise

under menu item .

Parameterisation level:

Parameter deposited in the menu item can be parameterised here. Functions, that can be

changed or adjusted, are always signalised by a flashing of the display. Settings that are made

in the parameterisation level are confirmed with [P] and thus saved. By pressing the „zero-key“

it leads to a break-off of the value input and to a change into the menu level. All adjustments

are saved automatically by the device and changes into operating mode, if no further key

operation is done within the next 10 seconds.

Level Key Description

Menu level

Change to parameterisation level and deposited values.

Keys for up and down navigation in the menu level.

Change into operation mode.

Parameterisation

level

To confirm the changes made at the parameterization

level.

Adjustment of the value / the setting.

Change into menu level or break-off in value input.

Menu group level

Change to menu level.

Keys for up and down navigation in the menu group level.

Change into operation mode or back into menu level.

4. Function and operation description

Function chart:

4.1. Parameterisation software PM-TOOL:

Part of the PM-TOOL are the software on CD and an USB-cable with device adapter. The

connection is done via a 4-pole micromatch-plug on the back side of the device, to the PC-side

the connection ist done via an USB plug.

System requirements: PC incl. USB interface

Software: Windows XP, Windows VISTA

With this tool the device configuration can be generated, omitted and saved on the PC. The

parameters can be changed via the easy to handle program surface, whereat the operating

mode and the possible selection options can be preset by the program.

CAUTION!

During parameterisation with connected measuring signal, make sure that the measuring signal

has no mass supply to the programming plug. The programming adapter is galvanic not

isolated and directly connected with the PC. Via polarity of the input signal, a current can

discharge via the adapter and destroy the device as well as other connected components!

Menu level Parameterisation level

Selection of the input signal,

Default:

If the scaling of the device is done via (Sensor calibration), the frequency

range needs to be preset under and is adjusted by application of the final

value / initial value. If (Factory calibration) is preferred, the final value needs

to be entered under and the final frequency needs to be entered under .

Under the initial value needs to be entered and under the initial

frequency. There is no application of the measuring signal. is the rotation in

r.p.m. up to 10 kHz input frequency. is the position recognition per

incremental encoder. Confirm the selection with [P] and the display switches back

to menu level.

Adjustment of pulses per rotation, :

Default:

This parameter is only important if = or = has been selected.

Generally it shows the number of pulses per rotation.

5.1. Switching-on

Once the installation is complete, start the device by applying the voltage supply. Before, check

once again that all electrical connections are correct.

Starting sequence

For 1 second during the switching-on process, the segment test ( ) is displayed, followed

by an indication of the software type and, after that, also for 1 second, the software version.

After the starting sequence, the device switches to operation/display mode.

5.2. Standard parameterisation: (flat operation level)

To parameterize the display, press the [P] key in operating mode for 1 second. The display

then changes to the menu level with the first menu item .

5. Setting up the device

Menu level Parameterisation level

Setting end value of the measuring range, :

Default:

Choose between six different frequency ranges. Confirm the selection with [P] and

the display switches back to menu level.

Setting the final value of the measuring range, :

Default:

Set the final value from the smallest to the highest digit with [▲] [▼] and confirm

each digit with [P]. A minus sign can only be parameterized on the highest value

digit. After the last digit, the display switches back to the menu level. If was

selected as input option, you can only select between and With , only

the previously set display value is taken over, and with , the device takes over

both the display value and the analogue input value.

Setting the start/offset value of the measuring range, :

Default:

Enter the start/offset value from the smallest to the highest digit [▲] [▼] and

confirm each digit with [P]. After the last digit the display switches back to the

menu level. If was selected as the input option, you can only select between

and With , only the previously set display value is taken over, and

with , the device takes over both the display value and the analogue input

value.

5. Setting up the device

9.9999 Hz 99.999 Hz 999.99 Hz 9.9999 kHz

99.999 kHz 999.99 kHz

5. Setting up the device

Menu level Parameterisation level

Setting the decimal point, :

Default:

The decimal point on the display can be moved with [▲] [▼] and confirmed with

[P]. The display then switches back to the menu level again.

Setting up the display time, :

Default:

The display time is set with [▲] [▼]. The display moves up in increments of 0.1

sec up to 1 sec and in increments of 1.0 sec up to 10.0 sec. Confirm the selection

by pressing the [P] button. The display then switches back to the menu level

again.

Rescaling the measuring input values,

Default:

With this function, rescale the input value of e.g. 8.000 Hz (works setting) without

applying a measuring signal. If sensor calibration has been selected, these

parameters are not available.

Rescaling the measuring input values,

Default:

With this function, rescale the input value of e.g. 100 Hz (works setting) without

applying a measuring signal. If sensor calibration has been selected, these

parameters are not available.

then

5. Setting up the device

Menu level Parameterisation level

Setting of the pulse delay,

Default:

With the pulse delay of 0–250 seconds (max), frequencies can be collected, which

are even smaller than by the predetermined measuring time of the device. If e.g. a

delay of 250 seconds is set, this means that the device waits up to 250 seconds

for an edge, before it assumes a 0 Hz frequency. Thus frequencies up to 0.004 Hz

can be collected.

Adjustment of the optimum digital frequency filter,

Default:

If the optional filter is not activated by the adjustment , frequencies are ignored

by the adjusted frequency filter. Act on the assumption that the pulse-duty factor is

1:1. Accordingly the minimal pulse duration is derived from the half of the time of

oscillation. Use a filter of 10 Hz or 20 Hz for contact bounce suppression.

Selection of analog output,

Default:

Three output signals are available: 0-10 VDC, 0-20 mA and 4-20 mA, with this

function, the demanded signal is selected.

Setting up the final value of the analog output,

Default:

The final value is adjusted from the smallest digit to the highest digit with [▲] [▼]

and digit by digit confirmed with [P]. A minus sign can only be parameterised on

the highest digit. After the last digit, the device changes back into menu level.

5. Setting up the device

Menu level Parameterisation level

Setting up the initial value of the analog output,

Default:

The final value is adjusted from the smallest digit to the highest digit with [▲] [▼]

and digit by digit confirmed with [P]. A minus sign can only be parameterised on

the highest digit. After the last digit, the device changes back into menu level.

Threshold values / limit values,

Default:

For both limit values, two different values can be parameterized. With this, the

parameters for each limit value are called up one after another.

Hysteresis for limit values,

Default:

For all limit values exists a hysteresis function, that reacts according to the settings

(threshold exceedance / threshold undercut).

Function if display falls below / exceeds limit value,

Default:

The limit value undercut can be selected with (LOW = lower limit value) and

limit value exceedance can be selected with (HIGH = upper limit value). If e.g.

limit value 1 is on a switching threshold of 100 and occupied with function , the

alarm will be activated by reaching the threshold. If the limit value is allocated to

, an alarm will be activated by undercut of the threshold..

Threshold values / limits,

Default:

This value defines the threshold, that activates/deactivates an alarm.

5. Setting up the device

Menu level Parameterisation level

Hysteresis for limit values,

Default:

The delayed reaction of the alarm is the difference to the threshold value, which is

defined by the hysteresis.

Function for threshold value undercut / exceedance,

Default:

A limit value undercut is selected with (for LOW = lower limit value), a limit

value exceedance with (for HIGH = higher limit value). If e.g. limit value 1 is on

a threshold level of 100 and allocated with function , an alarm is activated by

reaching the threshold level. If the threshold value was allocated to an alarm

will be activated by undercutting the threshold value, as long as the hysteresis is

zero.

User code (4-digit number-combination, free available), :

Default:

If this code is set (>0000), all parameters are locked, if has been selected

before under menu item . By pushing [P] during operation mode for approx. 3

seconds, appears in the display. To get access to the unlocked reduced

parameter, the user needs to enter the preset . This code has to be entered

before each parameterisation, until the (Master code) unlocks all

parameters again.

Master code (4-digit number-combination free available), :

Default:

With this code, all parameters can be unlocked, if has been activated before

under menu item . By pushing [P] during operation mode for approx. 3

seconds, appears in the display. The user can now reach all parameters by

entering . Leaving the parameterisation, under menu item , the user can

unlock them permanently by choosing or . So, there is no need for anew

code entering, even by pushing [P] during operation mode again.

5. Setting up the device

Menu level Parameterisation level

5.3. Programming interlock „ “

Activation / deactivation of the programming lock or completion of the

standard parameterization with change into menu group level (complete

function range),

Default:

Choose between the deactivated key lock (works setting) and the activated

key lock , or the menu group level with the navigation keys [▲] [▼].

Confirm the selection with [P]. After this, the display confirms the settings with

", and automatically switches to operating mode. If was selected, the

keyboard is locked. To get back into the menu level, press [P] for 3 seconds in

operating mode. Now enter the (works setting ) that appears using

[▲] [▼] plus [P] to unlock the keyboard. appears if the input was wrong.

To parameterise further functions needs to be set. The device confirms this

setting with „ „ and changes automatically into operation mode. By pressing

[P] for approx. 3 seconds in operation mode, the first menu group is shown in

the display and thus confirms the change into the extended parameterisation. It

stays activated as long as is entered in menu group , thus the display is

set back in standard parameterisation again.

5. Setting up the device

5.4. Extended parameterisation (Professional operation level)

5.4.1. Signal input parameters
