Jefferson Professional Tools & Equipment JEFTRCH19HD User manual

www.jeffersontools.com
User Manual
v.1.1
JEFTRCH19HD
1. IMPORTANT
Recharge the battery pack every 3 months if it is not being used for a long time,
or recharge it after used.
• Charge before use, although the battery pack is delivered in a charged state.
• It is advisable to use the unit from time to time in order to maintain the unit in good condition.
• Do not dispose of the unit by burnimg or dismantle it under any condition.
• Reverse charging is not recommended.
• Do not short circuit the battery as this may cause permanent damage to the battery pack.
• Never insert any foreign metallic objects into the charge jack of the battery pack.
• Never leave the unit in extremely high temperatures while charging.
• Use of the battery in extreme condition such as extreme temperature, deep cycle, and
extreme overcharged or over discharged, may affect the service life.
• Battery should be stored in a cool and dry place.
• Be sure to use manufacturer's replacement parts.
JEFTRCH19HD
RECHARGEABLE
UNI-POWERED
CREE LED
HEADLAMP
IP64 WATER
RESISTANT
2.5 HRS
RUNNING
TIME
USB
RECHARGEABLE
2.5 HRS
CHARGING TIME
2M
IMPACT
RESISTANT
150m
BEAM
RANGE
2. OPERATION
[Twist lens ring for WHITE LED FOCUS CONTROL]
[Press OFF if stays at any mode over 10 seconds]
JEFTRCH19HD
White High 580 Lumens 150m 2.5 hrs
White Med 245 Lumens 100m 4.5 hrs
White Low 25 Lumens 35m 16 hrs
Red On 10 Lumens 5m 15 hrs
Red 2Hz Flashing* NA NA 30 hrs
Battery Type 1 x Li-polymer Rechargeable Battery Pack (Included),
or 3 x 1.5V AAA Alkaline Batteries (Not Included).
1. Open battery case.
2. Insert a charged Li-polymer battery pack according to the arrow
sign on the battery & case, top pin position rst. Then place
the end into battery case. Or; Insert 3pcs new AAA alkaline batteries
according to the polarity marks on the case.
3. Close battery case.
3. BATTERY INSPECTION
When the headlight becomes noticeably dim, switch off the unit and
recharge the battery pack as soon as possible.
Battery Type
3.7V BOOmAh Li-polymer Rechargeable Battery Pack (Included)
Charging Time
2.5hrs
1. Connect the rechargeable battery pack to your PC, or an approved
USB adaptor, a solar panel, a portable power bank or any other
charging devices with an USB outlet, with the
micro USB cable (included).
2. The Red LED indicator will light up to indicate charging has started.
The Green LED indicator will light up when the battery has
been fully charged.
• Recharge the battery pack every 3 months if it is not being used for
a Long time, or recharge it after used.
• The rechargeable battery pack will reach full performance only after
a few complete charging & discharging cycles.
• DO NOT leave the battery pack in charging status
(with power connected) continuously for more than ve days,
as this may cause a reduction in battery efcacy.
• It is recommended to carry a spare charged battery pack,
in the event of unexpected battery power shortage.
4. RECHARGING
1 x 3.7V 800mAh
Li-polymer
Rechargeable
Battery
Insert
OPEN
Battery Case
3 x 1.5V
AAA Alkaline
Batteries
3 x 1.5V
AAA Alkaline
Batteries
OR
Micro USB Cable - To PC,
USB adaptor, solar panel,
portable power bank or
any other charging device.
Charging status indication
RED LED On - Charging
GREEN LED On - Fully Charged
Charge jack
CONNECT
580

Jefferson Professional Tools & Equipment, or hereafter “Jefferson” warrants its customers that
its products will be free of defects in workmanship or material. Jefferson shall, upon suitable
notication, correct any defects, by repair or replacement, of any parts or components of this
product that are determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage,
alteration, abnormal operations, improper care, service or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the
stated warranty periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If
proof of purchase is unavailable from the end user, then the date of purchase will be deemed
to be 3 months after the initial sale to the distributor.
1 Year
• Jefferson Rechargeable Uni-Powered CREE LED Headlamp (JEFTRCH19HD).
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be
subject to a minimum of 90 days cover or the remaining duration of the warranty period from
the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the
following address:
www.jeffersontools.com/warranty and completing the online form.
Online warranty registration is recommended as it eliminates the need to provide proof of
purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will
be corrected by repair or replacement at an authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for
collection. Jefferson will arrange collection and transportation of any equipment returned under
warranty. Upon inspection of the equipment, if no defect can be found or the equipment is not
covered under the terms of the Jefferson warranty, the customer will be liable for any labour
and return transportation costs incurred. These costs will be agreed with the customer before
the machine is returned.
NOTE: * Jefferson reserve the right to void any warranty for damages identified as being
caused through misuse *
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians
or engineers. Jefferson’s liability under this warranty will not exceed the cost of correcting the
defect of the Jefferson products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business
or hire of substitute equipment etc.) caused by the defect or the time involved to correct the
defect. This written warranty is the only express warranty provided by Jefferson with respect to
its products.
Any warranties of merchantability are limited to the duration of this limited warranty for the
equipment involved.
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment:
(Tel: [phone]) or their nearest authorised Jefferson dealer where final
determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form.
You can complete the form online and submit it to us directly or download the form to print out
and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together
with details of your nearest authorised Jefferson repair centre. On receipt of this form Jefferson
will arrange to collect the equipment from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer’s responsibility to ensure that the equipment is appropriately and securely
packaged for collection, together with a copy of the original proof of purchase. Please note
that Jefferson cannot assume any responsibility for any damage incurred to equipment during
transit. Any claims against a third party courier will be dealt with under the terms & conditions
of their road haulage association directives.
NOTE: Jefferson will be unable to collect or process any warranty requests without a copy of
the original proof of purchase.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will
be determined if the equipment is defective and in need of repair and any repairs needed are
covered by the warranty policy. In order to qualify for warranty cover all equipment presented
must have been used, serviced and maintained as instructed in the user manual.
Where repair is not covered by the warranty a quotation for repair, labour costs and return
delivery will be sent to the customer (normally within 7 working days). Note: If the repair
quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour labour
time at £30 per hour plus return carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the
equipment is identified as the cause of the problem, a minimum of 1 hour labour at £30 per
hour plus carriage costs will be required before the equipment will be despatched back to the
customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to
the customer within 7 working days upon receipt of the equipment at an authorised Jefferson
Repair centre (subject to part availability). Where parts are not immediately available Jefferson
will contact you with a revised date for completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call:
[phone] or send your enquiry via email to [email protected]
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all
recommendations or suggestions are made without guarantee. Since the conditions of use are
beyond their control, Jefferson Tools® disclaim any liability for loss or damage suffered from
the use of this data or suggestions. Furthermore, no liability is accepted if use of any product
in accordance with this data or suggestions infringes any patent. Jefferson Tools® reserve the
right to change product specifications and warranty statements without further notification. All
images are for illustration purposes only.
LIMITED WARRANTY STATEMENT
www.jeffersontools.com
User Manual
v.1.1
EC DECLARATION OF CONFORMITY
We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of
the manufacturer, declare that this equipment conforms to the requirements of the following Directives:
Name and address of manufacturer
or authorised representative:
Jefferson Tools, Herons Way, Chester Business Park,
Chester, United Kingdom, CH4 9QR
Telephone: [phone]
Fax: [phone]
Email: [email protected]
www.jeffersontools.com
2014/30/EU - Electromagnetic compatibility
Signed By: Stephen McIntyre Date: 11th June 2018
JEFTRCH19HD
