Jefferson JEFWLT60W-230 User manual
User Manual
v.1.1
JEFWLT60W-230
S
2. EQUIPMENT OVERVIEW
3. OPERATION GUIDE
3.1. CHARGING
Connect the charger into charging socket, which
is located on the rear of work light. Connect the
charger to a power supply. The charging indicator
will illuminate to show the charging has started.
NOTE: The charging indicator will turn stable
green when the lamp is fully charged.
Disconnect the charger from the work light when
it has been charged for a sufcient time.
3.2. OPERATION
Choose the desired working mode with switch:
(1) Single Mode (2200lm) (2) Dual Mode (4400lm) (3) OFF
The lamp can be mounted to a metal surface
with the magnets on the stand foot.
3.3. GENERAL SAFETY
This device utilizes rechargeable Lithium ion
battery that can rupture, ignite and cause series
injury if missued or disposed of incorrectly.
Observe the following safety rules:
• DO NOT place battery and device
in re or high temperature
• DO NOT tamper with the battery wiring
• DO NOT puncture or damage the battery
• DO NOT use a battery that appears to be damaged
• DO NOT immerse or expose the battery to water
• DO NOT alter or modify the battery
• DO NOT attempt changing the battery in any manner
other than that prescribed in this manual.
• DO NOT dispose of the battery in re or water.
• Failure to heed these warning may result in
personal injury and/or property damage.
www.jeffersontools.com
Rechargeable, High Performance Site Work Light
60W (2x 30W) 4400 Lumens COB LED
120° Lighting Angle
Die-Cast Aluminium, Heavy-duty Frame & Stand
Powerful Magnetic Base
IP54 Housing Protection
14.8V 4400mAh Lithium Battery / AC Charger
Max. Charging Time: 4-5 hours
Max. Run Time: 2 hours (Dual Mode)
4 hours (Single Mode)
1. 60W COB LED
2. Protective Glass Cover
3. Rubber ring
4. Front plate
5. Lens cap
6. Stand
7. Switch
8. Charger indicator
9. Charger socket
10. AC Charger
11. Back housing
12. Magnetic Stand Base
1. FEATURES & SPECIFICATION
CAUTION: Never shine the LED light directly into
eyes as the LED is extremely bright and may cause
injury if used incorrectly or inappropriately.
User Manual
v.1.1
JEFWLT60W-230
LIMITED WARRANTY STATEMENT
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that
its products will be free of defects in workmanship or material. Jefferson shall, upon suitable
notication, correct any defects, by repair or replacement, of any parts or components of this
product that are determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage,
alteration, abnormal operations, improper care, service or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the
stated warranty periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If
proof of purchase is unavailable from the end user, then the date of purchase will be deemed to
be 3 months after the initial sale to the distributor.
1 Year
• Jefferson 4400 Lumens Rechargeable COB LED Site Work Light (JEFWLT60W-230)
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be
subject to a minimum of 90 days cover or the remaining duration of the warranty period from
the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the
following address: www.jeffersontools.com/warranty and completing the online form.
Online warranty registration is recommended as it eliminates the need to provide proof of
purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will
be corrected by repair or replacement at an authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for
collection. Jefferson will arrange collection and transportation of any equipment returned under
warranty. Upon inspection of the equipment, if no defect can be found or the equipment is not
covered under the terms of the Jefferson warranty, the customer will be liable for any labour
and return transportation costs incurred. These costs will be agreed with the customer before
the machine is returned.
NOTE: * Jefferson reserve the right to void any warranty for damages identified as being
caused through misuse *
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians
or engineers. Jefferson's liability under this warranty will not exceed the cost of correcting the
defect of the Jefferson products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business
or hire of substitute equipment etc.) caused by the defect or the time involved to correct the
defect. This written warranty is the only express warranty provided by Jefferson with respect to
its products.
Any warranties of merchantability are limited to the duration of this limited warranty for the
equipment involved.
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment:
(Tel: +44 (0) 1244 646 048) or their nearest authorised Jefferson dealer where final
determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form.
You can complete the form online and submit it to us directly or download the form to print out
and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together
with details of your nearest authorised Jefferson repair centre. On receipt of this form Jefferson
will arrange to collect the equipment from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer’s responsibility to ensure that the equipment is appropriately and securely
packaged for collection, together with a copy of the original proof of purchase. Please note
that Jefferson cannot assume any responsibility for any damage incurred to equipment during
transit. Any claims against a third party courier will be dealt with under the terms & conditions
of their road haulage association directives.
NOTE: Jefferson will be unable to collect or process any warranty requests without a copy of
the original proof of purchase.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will
be determined if the equipment is defective and in need of repair and any repairs needed are
covered by the warranty policy. In order to qualify for warranty cover all equipment presented
must have been used, serviced and maintained as instructed in the user manual.
Where repair is not covered by the warranty a quotation for repair, labour costs and return
delivery will be sent to the customer (normally within 7 working days). Note: If the repair
quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour labour
time at £30 per hour plus return carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the
equipment is identified as the cause of the problem, a minimum of 1 hour labour at £30 per
hour plus carriage costs will be required before the equipment will be despatched back to the
customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to
the customer within 7 working days upon receipt of the equipment at an authorised Jefferson
Repair centre (subject to part availability). Where parts are not immediately available Jefferson
will contact you with a revised date for completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call:
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all
recommendations or suggestions are made without guarantee. Since the conditions of use are
beyond their control, Jefferson Tools® disclaim any liability for loss or damage suffered from
the use of this data or suggestions. Furthermore, no liability is accepted if use of any product
in accordance with this data or suggestions infringes any patent. Jefferson Tools® reserve the
right to change product specifications and warranty statements without further notification. All
images are for illustration purposes only.
EC Declaration of Conformity
Name and address of manufacturer or
authorised representative:
Jefferson Tools,
Herons Way,
Chester Business Park,
Chester,
United Kingdom,
CH4 9QR
We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of the manufacturer,
declare that this equipment conforms to the requirements of the following Directives:
• 2011/65/EU – RoHS Directive (as amended)
• 2014/30/EU – Electromagnetic Compatibility (EMC)
Signed by: Stephen McIntyre (Operations Director)
www.jeffersontools.com
