Jema Autolifte DWC User manual

- 2 - Jema Autolifte A/S wheel balancer DWC
WHEEL BALANCER INSTRUCTION MANUAL
DWC
ATTENTION
This manual is an integral part of the product.
The warnings and instructions in this manual provide important information about SAFETY IN USE and MAINTENANCE and
should be read very carefully.
KEEP THIS MANUAL IN A SAFE PLACE SO THAT IT IS ON HAND FOR REFERENCE.
Product destination
The wheel balancing machine is designed exclusively for balancing the tires of wheels with maximum dimensions defined in the
general section of this manual.
During ordinary maintenance of the apparatus, it is the responsibility of the maintenance operator (who should be suitably
trained and professionally qualified) to turn the main switch to OFF, ensuring that it cannot be accidentally switched on,
unplugging the connection to the power supply if necessary.
This machine should only be used for the purpose for which it was designed. Any other use is to be considered improper and
unreasonable.
The manufacturer (Balance) may not be considered responsible for any damage caused by improper, incorrect and
unreasonable use.
Training and information for the machine operators
The machine should only be used by specially trained and authorized personnel.
The training and informing of the operating staff should be done so as to enable them to operate the machine as described in
the instructions provided by the manufacturer, so that the machine performs in the best possible way and the operations are
carried out efficiently and safely.
For any doubts relating to the use, installation and maintenance of the machine, please refer to the instructions manual or if
necessary contact the authorized service centers or the technical services office of Balance.
Transport and unpacking
For transport of the packaged product, refer to Fig.1.
Once the product has been unpacked, check that the instructions
manual is there, that the material is complete and there are no parts
which have been visibly damaged.
Remove the contents of the packages and place them in a storage
area inaccessible to children or animals.
Environmental requirements for installation
The site of installation should have the following features:
Level horizontal floor, rigid, preferably concrete or tiled. Fig. 1
Sufficient lighting (but without dazzling or very bright lights).
Protected from atmospheric conditions.
Pollution-free area.
Noise level lower than provided for by current regulations.
The work place must not be exposed to dangerous movements from other machines in operation.
Explosive, corrosive and/or toxic materials should not be stored in the same place.

–3 –Jema Autolifte A/S wheel balancer DWC
From the control position the operator must be able to see the entire apparatus and the surrounding area. Within the area
you must prevent access to unauthorized persons and objects that may constitute a source of danger.
All the installation operations involving connections with outside main supplies (especially electricity) must be done by
professionally qualified people.
Installation must be done by authorized personnel following the special instructions contained in the manual where necessary.
In case of doubt, consult authorized service centre or the technical services office of Balance.
Safety
Any tampering or alteration of the apparatus which is not previously authorized by the manufacturer will release the latter from
any liability for damages deriving from or referring to the above-mentioned actions.
Removal or tampering with the safety devices constitutes violation of the safety regulations.
The operator must also observe the following safety procedures:
Check that dangerous conditions do not arise during the operation maneuvers. Stop the machine immediately in case of
irregular functioning and contact the customer service office of the authorized retailer.
Check that the working area around the machine is free of potentially dangerous objects and that there is no oil (or other
sticky materials) on the flooring since this is a potential danger for the operator.
The operator must wear suitable work clothing, protective goggles, gloves and mask to prevent harm from dust or
impurities being blown out. Dangling objects such as bracelets should not be worn, long hair should be protected in a
suitable manner, shoes should be suitable for the type of operation to be performed.
Technical service, repairs and replacement of parts
All repair and extraordinary maintenance operations should be carried out by authorized and professionally qualified personnel.
Disconnect the machine from the mains supplies (electricity, compressed air, etc.) before any maintenance operation.
Use original spare parts supplied by the manufacturer.
Consult the technical services office of Balance for any doubt regarding the suitability and conformity to safety regulations of the
accessories and spare parts to be used on the machine.
Storing
Should the machine have to placed in storage for a long period, disconnect the main supplies, empty the tanks containing the
operating liquids and make sure that those parts which could be damaged by the deposit of dust are adequately protected.
Grease those parts which could be damaged due to drying out and, when the machine is used again, replace the gaskets
indicated in the spare parts section.
Scrapping
If the machine is not to be used again, it should be made inoperative.
Those parts which could cause danger should be rendered harmless.
Consult disposal classification lists for the disposal category of the product.
Scrap as iron scrap and send to the appropriate refuse collection centre.
If it is considered special waste, dismantle and divide into similar parts before disposing in accordance with the regulations in
force. 1.
2.GENERAL PRECAUTIONS
Before operating the balancing machine, read carefully the use and maintenance manual. The noncompliance with these
standards frees the constructor from any responsibility.
1.1 Warnings and cautions
-The machine is to be operated only by authorized personnel.
-Check that the use of the balancing machine does not trigger off hazardous situations to people or things.
-When irregularities or malfunctions occur, stop immediately and require the intervention of the specialized technical

- 4 - Jema Autolifte A/S wheel balancer DWC
assistance.
-Any maintenance operation is to be carried out by specialized personnel.
-It is absolutely forbidden to alter equipment and safety devices.
-Any utilization of spare parts whose features do not correspond to the following specifications, any modifications or even
any little alterations, free the constructor from any responsibility related to proper use and safety for people and/or things.
1.2 Technical data
Max. wheel weight 65 kg
Power supply 110 V /220 V /380 V, 50 /60 Hz
Balancing accuracy 1 g
Balancing speed <200rpm
Rim diameter 10” ～24” (254mm ～610mm)
Rim width 1.5” ～20” (40mm ～508mm)
Cycle time <10 s
Noise level <70 dB
Net weight (without accessories) 88 kg
Operating temperature range -5°C ～50°C
Overall dimensions (with guard) (L×W×H) 915 X 760 X1230
3.INTRODUCTION
The electronic balancing machine with a microprocessor, capable of balancing wheels weighing up to 65Kg.
The control elements and signals are all contained on the front panel.
The keyboard calibration system also provides a sufficient adjustment range to cope with unusual wheels (aging motorcycles
and cars).
Some ALU functions are available for specially shaped wheels or for presetting
optional balancing machine functions (see 3.5 using the keyboard).
4.INSTRCUTIONS FOR USE
3.1 Lifting and Installation
Lever the base to lift the balancing machine. In no circumstances should force be
applied to other parts, such as the mandrel, the headstock, the casing or the
accessories tray.
It is advisable but not obligatory to fix the machine to the floor, using the φ12 holes in
the three support feet (access to two is obtained by removing the adapter support).
Check that the balancing machine touches the floor where the three feet rest.
Maximum dimensions including the guard: 1250X1100X1700mm. (See Fig.2)
Fig. 2
3.2 Power supply
Before connecting the machine to the mains with the cable provided, check that the voltage is the same as shown on the plate
mounted on the back of the balancing machine.
Standard voltage is 220-240 V or 110 V single phase. Maximum electrical power input is 0.6KW.

–5 –Jema Autolifte A/S wheel balancer DWC
1. Inner side UNBALANCE POSITION display
2. Outer side UNBALAN-CE POSITION display
3. Outer side UNBALANCE VALUE digital display
4. Displays showing the type of correction chosen
5. Inner side UNBALANCE VALUE digital display
6. DISTANCE calibration key
7. WIDTH calibration key
8. DIAMETER calibration key
9. Key for selecting g/oz and mm/inches; self-calibrating
10. Emergency key
11. Key to start cycle
12. Opt program
13. Threshold key
14. Key for selecting type of correction
15. Recalculation key
N.B.: Only use the fingers to press the push buttons. Never use the pincers for the counterweights or other pointed objects

- 6 - Jema Autolifte A/S wheel balancer DWC
3.3 Fixing the adapter
Before fixing the adapter on the balancing machine shaft, check that the shaft and the adapter centering area are clean.
Use one of the many adapters produced as per catalogue.
Remember that imperfect centering provokes unbalanced. Use the wrench provided to lock the adapter onto the balancing
machine shaft.
3.4 Mounting the wheel
Mount the wheel with suitable cone and adjustable nut Remember that imperfect centering provokes unbalanced unnecessarily.
3.5 Using the keyboard
The following operations can be carried out using the keyboard:
Varying the distance (dimension “a”)---------------------------------------------------------------
Varying the width (dimension “b”)-------------------------------------------------------------------
Varying the diameter (dimension: “d”)-------------------------------------------------------------
Recalculating the values------------------------------------------------------------------------------
Disp. The values below the threshold-------------------------------------------------------------
Static Dynamic------------------------------------------------------------------------------------------
ALUx Dynamic------------------------------------------------------------------------------------------
Balancer self-calibrating------------------------------------------------------------------------------
Start by closing the guard-----------------------------------------------------------------------------
Unbalance measured in gm or oz------------------------------------------------------------------
Width measured in mm or inches-------------------------------------------------------------------
Diameter measured in mm or inches--------------------------------------------------------------
Start measuring cycle----------------------------------------------------------------------------------
Emergency cycle stop----------------------------------------------------------------------------------
The unit of measurement chosen for the unbalance (grams or
ounces) and the option to start by closing the guard or by pressing
the START key are stored in the machine’s memory when it is
switched off.
If the unit of measurement selected for the width and diameter (mm
or inches) is inches, this selection must be repeated every time the
machine is started up.
3.6 Calibrating the panel
DIAMETER: input the diameter “d “ which is shown on the tire.
WIDTH: input the width "b", which is normally shown on the wheel
rim, or measure the width “b” with the calipers provided.
DISTANCE: find out the measure between the machine and the
weights positioning point on the wheel rim and set by means of “a”
(Fig.4) Fig.4
3.7Note for balancing of motorcycle wheels dynamically
-Slip the extension onto the distance measurer.
-Extract the measurer until the extension touches the inner side of
the wheel rim.
-Read the value “ a ” on the scale, set it manually using the key
9, value “a+5” (scale base 25 cm).
Fig.5
↑a or ↓a
↑b or ↓b
↑d or ↓d
C
FINE
F
ALU
F + C
F + STOP
F + ↑a + ↓a
F + ↑b or F + ↓b
F + ↑d or F + ↓d
START
STOP
+5 cm

–7 –Jema Autolifte A/S wheel balancer DWC
3.8 Wheel balancing
-Close the guard.
-Press the START key.
-The wheel is accelerated automatically to balancing speed and then braked; displays 3 and 5 read the unbalance values.
-Displays 1 and 2 read the correction position with LEDs. If all the LEDs are lit, the correction weight must be put at the top
of the vertical axis.
IMPORTANT: An unbalance value reading below 10-12 grams (0.4-0.5 oz) is normally sufficient for good balancing.
With this balancing machine, it is easy to balance to a tolerance of only 5 grams (0.2 oz) or less.
THRESHOLD KEY: FINE
The correction of residual unbalance below 5 grams (0.2 oz) can be read whenever necessary (wheels for special uses) by
pressing this key with the machine at a standstill.
Display 3 and 5 for unbalances below 5 grams (0.2 oz) in normal conditions.
3.8.1 Alu-S Function - How to use ALU-S program.
Select: ALU S (press ALU key to LED-light is on next to the Alu-S program)
•A ↑ ↓ - keys, A1 = Distance from the edge of the machine to the inner track of the rim where glue-grams must be placed.
•B ↑ ↓ - keys, AE = Distance from the edge of the machine to the outer track on the rim where glue-grams must be placed.
•D ↑ ↓ - keys, d1 = Rim diameter measured at the inner track which adhesive glue-grams to be installed and entered. (Usefully
be measured before mounting the wheel on DWC)
•Aluminum is pressed and hold, and D ↑ ↓ - keys, change rim diameter measured at the outermost track on which glue-grams
must be installed. (Can usefully be measured before mounting the wheel on DWC)
•Glue-grams glued on 12 o´clock, at the time that all LED-light is turned on. (12.00.)
3.9 Self calibration methods
-Fit any wheel to the shaft, even one that is not balanced, although it is advisable to use one with “average” dimensions.
-Set the exact dimensions of the wheel fitted.
ATTENTION: any error in setting the dimensions will mean that the machine is not correctly calibrated, so all the subsequent
measurements will be faulty until the machine is next calibrated with correct measurements.
-Press F + C .
- Until the positioning LED’s change from flashing into steady.
- Press START
- Add a 100 gram weight on the outside in any angular position.
-Press START .

- 8 - Jema Autolifte A/S wheel balancer DWC
-The machine is calibrated at the end of the cycle. The display reads “END CAL”.
Remove the 100 gram weight from the wheel, which can now be balanced with a further cycle.
The values that the machine records from this self-calibration operation are automatically stored in a special memory which also
maintains them when the machine is switched off, with storage lasting for about 10 years, so the machine will be ready for
correct functioning every time it is switched on.
However, the self-calibration operation can be repeated as often as you like or whenever the correct functioning of the machine
is in doubt.
3.10 STATIC-ALU functions
(For balancing wheels of motorcycle, in light alloy or special construction forms) Ref. Fig.6
NORMAL: for balancing wheel rims in steel or light alloy by applying weights to the edge of
the rim with clips.
ALUS: for balancing special shape wheel rim (Look 3.8.1)
ALU1: for balancing of the light alloy rims with application of adhesive weights on the rim
shoulders
ALU2: for balancing wheel rims in light alloy with application of the inner side adhesive
weight. Position of the inner side weight is the one shown in the figure
ALU3: for combined balancing: clip-on weight on the inside; hidden application of the
adhesive weight on the outside (Mercedes).
St.: STATIC correction is required for motorcycle wheels or when it is not possible to place
the counterweights on both sides of the wheel rim.
-The ALU functions available can be selected at any time to provide a reading of the
correction weights to be applied to different positions from those shown in Figure 4 (normal).
Press key ALU to select the desired function. For each function, the microprocessor
elaborates the real values of the compensating weight corrected on the basis of the position
of the correction weight and memorizes them quickly on the unbalance displays.
3.11 Optimizing the unbalance
The optimizing operation enables you to reduce the amount of weight to add to the wheel in
order to balance it. In many cases, an improvement of the residual eccentricity on the tire
can also be achieved.
-Press key OPT, The display reads “r.S.”
-Press START The machine runs a measuring cycle.
-The display gives an instruction to turn the tire on the wheel rim. Make a reference
mark on the adapter and wheel rim with chalk, so as to be able to refit the wheel rim on
the bead of the tire in the same position.
Fig.6 - Use a tire changer to rotate the tire through 180 on the wheel rim.
-Fit the wheel rim back onto the adapter in the same position as before.
-Press START. The machine runs a second measuring cycle.
-The displays now read as follows: Right hand display: % value (symbol
current condition of the wheel.
Left hand display: Current static unbalance value. This is the value that can be reduced by the figure, read off the right
hand display by turning the tire on the rim.
LEDs: Manually turn the wheel until the outer LED’s light up (display position); mark the top of the tire. Continue the
(manual) rotation and similarly mark the wheel rim where it corresponds to the position indicated by the inner LED’s.
-Unbalance optimizing is achieved by turning the tire on the wheel rim again (using a tire remover) until the two marks
line up. Press the STOP key to end the unbalance reduction operation and return to measuring wheel unbalance.

–9 –Jema Autolifte A/S wheel balancer DWC
3.12 Inconstant unbalance readings
When a wheel has been balanced, is removed from the balancing machine and then fitted to it again, the instruments may read
that the wheel is not balanced.
This does not depend on defective machinery instruments, but is due to the wheel having been fitted badly to the adapter, i.e.
the wheel is in a different position with respect to the balancing machine axis in the first and second fittings.
If the wheel is fitted to the adapter with screws, the screws may not have been tightened correctly, i.e. using the crossover
system, gradually, or (as often happens), the holes in the wheel may have too much tolerance.
Small errors, up to 10 grams (0.4 oz) should be considered normal in wheels fitted on a cone adapter; the error is normally
greater for wheels fitted with screws or bolts. If the wheel is found to be still unbalanced when it is fitted to the vehicle after
balancing, this depends on the unbalances in the vehicle’s brake drums or very often on the holes for the bolts of the wheel rim
and brake drum, which are sometimes made with too much tolerance. In this case, it may be advisable to rebalance with the
wheel on the vehicle.
5.ORDINARY MAINTENANCE
Switch off the machine’s power supply before executing any maintenance operations.
4.1 Adjusting the belt pulley
1. Slightly loosen the four screws that support the motor and move the motor to adjust the belt tension.
2. Block the four motor screws carefully, check that the belt does not play laterally and touch the casing when in movement.
4.2 Computer board replacement
Machine parameters input:
When the computer board is to be replaced by a new one, it is necessary to insert the machine parameters.
To perform this operation, act as follows: press push buttons F + C as to execute the self-calibration; When the position
LEDs stop flashing press the following push buttons within 5 seconds and with the proper sequence: ↓a +↑a + F .
After having pressed ↓a and ↑a, the displays turn off, and after having pressed F the present value of fixed distance “DF”
appears: modify by ↑b and ↓b .
Press ↑a to the modification of the “I” value.
On the right display appears the present value (in %) and on the left one appear the “I” writing and the symbol “-“ if the
correction is negative, or “+” if it is positive. Modify by ↑b and ↓b .
By pressing the push button ↑a on the right display , the “S “ value appears: to modify it, press the push buttons ↑b and ↓b.
To finish, press ↑a .
Configuration basic values: See the sticker beside the power board.
After having modified the machine parameters, execute again the self-calibration.
NOTE: the values with which the machine has been calibrated in the factory are reported on a inner frame based data plate.

- 10 - Jema Autolifte A/S wheel balancer DWC
6.TROUBLESHOOTING
TROUBLE-ERROR CODE
CAUSE
REMEDY
ERR. 1:
Lack of wheel phase signal
a) Faulty position transducer
b) Not started motor
c) Rotation hindrance
d) Loose or broken driving belt
a) Restore the transducer
efficiency
b) Start the motor
c) Remove the hindrance
d) Tighten or replace the belt
ERR.2:
The rotation is lower than 60/min
a) Accidental breaking in rotation
unit
b) Loose driving belt
c) No tire mounted or lower
rotary speed
a) Check and eliminate the
cause of breaking
b) Tighten or replace the belt
c) Mounted adequate tire
ERR.3:
Miscalculation
a) Incorrect self-calibration
b) Too high unbalance
c) Faulty memory card
a) Repeat the self-calibration
b) Check the correct wheel
centering on the spindle
c) Replace the board
ERR.4:
Wrong rotation direction
a) Wrong motor connection
a) Reverse the connection in
the motor terminal board
ERR.5:
Open protection before
beginning launch
a) Open protection
b) Faulty protection switch
a) Close the protection
b) Replace the switch
ERR.7:
Card faulty operation
a) Incorrect self-calibration
b) Faulty computer board
a) Repeat the self-calibration
b) Replace the board
ERR.8:
Self-calibration memory fault
a) Second launch carried out
without adding the reference
weight
b) Broken detectors cable
a) Add the reference weight
during the carrying out of
the second launch
b) Restore the connection

–11 –Jema Autolifte A/S wheel balancer DWC
7.LOGIC TROUBLE SHOOTING SEQUENCE
N.B. Before carrying out any test disconnect braking resistor R on the contactor. Reconnect R only at calibration of testing.
When the power or computer board requires replacement, repeat the self-calibration of the balancing machine.
N.B. When the computer board is replaced , preset the machine parameters indicated on the related nameplate.
6.1 CHECKING AND SETTING OF STATIC VALUE (STI)
N
Y
Y
Carry out self-calibration
Wheel balancing.
Tolerance 1 gram
Select STATIC.
Apply 100 grams on inside.
Perform the spin.
Is the STATIC value on
the inside between 98 and
102 grams?
Select function “SELECTION OF MACHINE
PARAMETERS”.
Increase value “1” if the inside STATIC value is
too high (2 digits of “1” are equivalent to approx. 1
gram).
END

- 12 - Jema Autolifte A/S wheel balancer DWC
6.2 CHECKING AND SETTING OF UNBALANCING POSITION
N N
Y
Carry out self-calibration.
Wheel balancing.
Tolerance 1 gram.
Apply weight of 100
grams on the outside.
Perform the spin.
Is the 100 gram
counterweight in the
six o’clock position?
Select function “SELECTION OF MACHINE
PARAMETERS”.
Modify value “S” by making various attempts
(“S” is expressed in degrees)
END

–13 –Jema Autolifte A/S wheel balancer DWC
6.3 CHECKING AND CALIBRATION OF FIXED DISTANCE VALUE (DF)
N
Y
Follow the procedure for “CHECKING AND
CALIBRATION DISTANCE VALUE (DF)”
100 g. weight on Inner Side (F.I.),
the indication of dynamic
unbalance is F.I.=100±5 F.E.≤5
Select “MACHINE PARAMETERS”, modify
“DF” value by increasing or decreasing it 5
figures at a time
Make self-calibration
END

- 14 - Jema Autolifte A/S wheel balancer DWC

–15 –Jema Autolifte A/S wheel balancer DWC
8.POWER SUPPLY LAYOUT DIAGRAM
(220 V CONNECTION)

- 16 - Jema Autolifte A/S wheel balancer DWC
9.SPARE PARTS LIST
No
Code
Description
Qt
No
Code
Description
Qt
1
PX-500-010000-0
Body
1
108
B-014-100251-0
Screw
3
2
B-004-050001-1
Nut
3
109
B-004-100001-0
Nut
3
3
B-040-050000-1
Washer
3
110
S-060-000410-0
Micro switch
1
4
B-024-050251-0
Screw
3
111
PX-100-020000-0
Shaft box
1
5
P-000-001001-0
Tools hang
3
112
P-100-330000-0
Spring
1
6
PX-100-120000-0
Electric board support
1
113
PX-100-040000-0
Shaft
1
7
Screw
4
114
Screw
1
8
PZ-000-020822-0
Power board
1
115
B-004-100001-0
Nut
1
9
Nut
12
116
P-100-200000-0
Hood
1
10
B-004-060001-1
Nut
10
117
B-007-060081-0
Screw
3
11
B-004-050001-1
Nut
4
12
D-010-100100-1
Resistor
1
201
B-010-060161-0
Screw
1
13
B-024-050251-0
Screw
2
202
P-100-160000-0
Handle bar
1
14
S-060-000210-0
Power switch
1
203
P-100-900000-0
Rim distance
gauge
1
15
PX-100-010920-0
Motor adjust board
1
204
Pin
1
16
S-063-002000-0
Capacitor
1
205
P-100-170000-0
Plastic bush
2
17
Hoop
1
206
P-100-520000-0
Seeger ring
2
18
S-051-230020-0
Motor
1
207
P-100-210000-0
Spring
1
19
B-040-061412-1
Washer
4
208
Y-004-000070-0
Graduated
strip
1
20
B-014-050351-1
Screw
2
21
PX-100-110000-0
Plate
1
301
S-042-000380-0
Belt
1
22
B-024-050061-0
Screw
2
302
B-040-103030-1
Washer
1
23
B-040-050000-1
Washer
2
303
B-014-100251-0
Screw
3
24
S-025-000135-0
Cable circlip
1
304
B-050-100000-0
Washer
3
25
P-500-190000-0
Head with tools-tray
1
305
B-040-102020-1
Washer
6
26
S-140-001000-0
Computer board
1
306
PZ-000-040100-0
Position
Pick-up
1
27
Screw
4
307
B-024-030061-0
Screw
4
28
Key board support
1
308
Thread
1
29
S-115-008000-0
Key board
1
309
P-100-420000-0
Plastic lid
1
310
P-100-340000-0
Spring
1
101
PX-100-200200-0
Shaft
1
311
S-100-000010-0
Coupling
shaft
1
102
B-024-050061-0
Screw
3
312
P-100-080000-0
Screw
1
103
B-040-050000-1
Washer
3
313
B-048-102330-1
Washer
4
104
PX-100-030000-0
Cover
1
314
B-004-100001-2
Nut
5
105
P-100-180000-0
Sheath
2
315
S-131-000010-0
Sensor
assembly
1
106
PX-100-050000-0
Shaft sheath
1
316
B-040-124030-1
Washer
2
107
B-024-060081-0
Screw
1
317
P-100-070000-0
Screw
1

–17 –Jema Autolifte A/S wheel balancer DWC
10. EXPLODED WHEEL BALANCER
DRAWINGS

- 18 - Jema Autolifte A/S wheel balancer DWC

–19 –Jema Autolifte A/S wheel balancer DWC
207
206
205
203
204
202
201
208

- 20 - Jema Autolifte A/S wheel balancer DWC
