Jenn-Air JES9750BA Series User guide

Electric Downdraft Range
PRODUCT MODEL NUMBERS
CLEARANCE DIMENSIONS
JES9750BA
JES9800BA
JES9860BA
Electrical: This range requires a single-phase
three-wire 120/240- or a 120/208-volt, 60-Hz,
AC-circuit. Wiring codes require a separate circuit
be run from the main entrance panel to the range
and that it be equipped with separate disconnect
switch and fuses, either in the main entrance
panel or in a separate switch and fuse box.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 8101P700-60
10-28-08
Page 1 of 2
Combustible
Building Walls
Combustible
Wall Cabinets
13" (33 cm) Max.
Depth of cabinets
above cooktop
30”
30”
(76.2 cm)
(76.2 cm)
30”
(76.2 cm)
30”
30”
(76.2 cm)
(76.2 cm)
18”
(45.7 cm)
13”
(33 cm)
3”
(7.6 cm)
25”
(63.5cm)
18”
(45.7 cm)
3”
(7.6 cm)
Range may be installed with 0"
(0 cm) clearance adjacent to
(against) combustible construction
at the rear and on the sides below
the cooktop.
NOTE: 30" (76.2 cm) dimension
between cooking top and wall
cabinet shown on illustration does
not apply to ranges with an elevated
oven or microwave. The installation
instructions of the elevated oven will
specify the minimum acceptable
dimension between the cooktop and
elevated oven. The 30" (76.2 cm)
dimension may be reduced to not
less than 24" (61 cm) when the wall
cabinets in a domestic home are
protected with fireproof materials in
accordance with American National
Standards - National Fuel Gas Code
or in mobile homes when they are
protected with fireproof materials in
accordance with the Federal
Standard for Mobile Home
Construction and Safety.
To eliminate the risk of burns or fire
by reaching over heated surface
units, cabinet storage space located
above the surface units should be
avoided. If cabinet storage is to be
provided, the risk can be reduced by
installing a range hood that projects
horizontally a minimum of 5" (13 cm)
beyond the bottom of the cabinets.

Electric Downdraft Range
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 8101P700-60
10-28-08
CABINET OPENING DIMENSIONS
Page 2 of 2
5.5”
(14 cm)
10”
(25.4cm)
19”
(48.3cm)
9 1/2”
(24.13 cm)
24”
(61cm)
2 1/4”
(5.71 cm)
23.25”
(
59.1cm)
36”
(91.4cm)
30”
(76.2cm)
25”
(63.5cm)
30”
(76.2cm)
1-1/2"min
(3.8 cm)
1-1/2"min
(3.8 cm)
NOTE: For countertops with formed front edge, shave
raised section to clear top.
CAUTION: Some white European style cabinets are
equipped with delicate white vinyl drawer and door fronts.
The vinyl may not be designed to withstand the heat
produced by the normal safe operation of a self-clean
range. Discoloration or delamination may occur. To avoid
possible damage, we recommend increasing the 30"
(76.2 cm) cabinet opening to 31-1/4" (79.3 cm) minimum
and using heat shield (CABKIT V). The countertop cut-out
must remain 30" (76.2 cm).
When replacing an existing unit, a maximum of 23-1/2"
(59.7 cm) is acceptable. If the cut depth exceeds 23-1/2"
(59.7 cm), use filler kit K71FILL.
120/240 V or 120/208 V grounded electrical outlet in the
hatched area. Outlet MUST be flush. Nothing located in
hatched area can extend more than 2" (5.1 cm) from wall
or range will not slide all the way back.
