Jenn-Air JDR8880RDB10 User manual

COOKTOP PARTS
1
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
11−11 Litho in U.S.A. (amd) (eeb) Part No. W10141329 Rev. B
30" FREE STANDING
DUAL FUEL
CONVECTION RANGE
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8113P622−60 Manual, Owners
8119P367−60 Wiring Diagram
2 Grate, Double
74009143 Black
74009145 Gray
3 Cap, Burner
74007414 Black, (LF)
74007416 Black,(LR)
74007925 Black,Medium (3)
74007420 Gray,(RF)
74007422 Gray,(LR)
74007752 Gray,Medium (3)
4 Base, Burner
74007411 5K, Center (1)
74007413 16K, RF
74007698 12K,9.2K (3)
5 Panel, Manifold
74009138 Black
74009139 White
74009146 Stainless
6 74009147 Knob, Valve
7 Cooktop
74009086 Black
74009087 White

CONTROL PANEL PARTS
2
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329
Illus. Part
No. No. DESCRIPTION
1 End Cap
74009022 Black (Right)
74009023 Black (Left)
2
8507P333−60 Control
3 Backgaurd Assy.
74011912 Black
74011913 Stainless
74011914 White
4 Sheild, Heat Visor
74009202 Black
74009203 White
5 74010983 Cover, Rear Wire
6 74001530 Screw
7 74009444 Shield, Vent
8 74011982 Bracket, Control

OVEN PARTS
3
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329

OVEN PARTS
4
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Panel, Side
74008709 White
74009710 Black
2 74008701 Retainer, Side
3 74011910 Element, Broil
4 12001656 Oven Sensor
5 74001530 Screw
6 74011177 Fan Assy. Convect
7 74005401 Screw
8 47005783 Cover, Convection
9 74008695 Support, Oven
10
7406P456−60 Element, Bake
11
740086960 Gasket
12 74008763 Rack, Oven
13 74009651 Cover, Main Wire
14
8026P090−60 Smoke Eliminator
15 74008798 Screw, Shoulder #8
16 74008690 Spacer, Side Panel
17 74011896 Latch, Door Lock
18 74011278 Light, Oven
19
7407P103−60 Bulb, Oven Light
20 74008687 Runner, Drawer
21 74004078 Roller, Drawer
22 74005231 Shaft, Drawer
23 74008762 Bottom, Wire Cover
24 74008699 Back, Main
25 74010551 Receiver, Hinge
26 74003976 Screw, Shoulder
27 74008694 Support, Oven
28 74008741 Bottom, Oven
29 74005564 Anti−Tip Bracket
30 74002373 Leg, Leveling
31 74008688 Stop, Drawer
32 74006398 Cord, Power
33 74008715 Switch, Limit
34 74008340 Panel, Access
35 74008760 Cover, Wire Lower
36
3605F146−51 Plate, Conduit
37
7103P027−60 Nut,Terminal Block
38
7401P039−60 Block, Terminal
Following Parts Not Illustrated
5171P790−60 Harness, Main
5171P839−60 Harness, Ignition
7509P115−60 Kit,
LP Conversion
12500100 Kit, Broiler Pan

MANIFOLD PARTS
5
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329
Illus. Part
No. No. DESCRIPTION
1 74009098 Module, Spark
2 74008815 Pipe, Manifold
3 Valve, Burner
74010629 5K Copreci (1)
74010751 16K Copreci (1)
74010752 12K Copreci (3)
4 74010753 Harness, Switch
5 Orifice Holder
74009099 RF
74009100 RR
7527P097−60 Center
7527P100−60 LR
7527P101−60 LF
6 74009958 Ignitor,Top Burner
7
7506P519−60 Tubing, Supply
8 74005560 Regulator

DRAWER PARTS
6
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329
Illus. Part
No. No. DESCRIPTION
1 74005546 Spacer, Rubber
2 74008877 Drawer, Service
3 74009105 Sheild, Heat
4 74009268 Screw
5 74008908 Handle, Drawer
6
7103P082−60 Nut
7 74005231 Shaft, Roller
8 74004078 Roller, Drawer
9
7101P072−60 Screw
10 Panel, Drawer
74008856 White
74009035 Black
11 74009518 Panel, Drawer
(Stainless Models)

DOOR PARTS
7
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329

DOOR PARTS
8
For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10
(Black) (White) (Stainless)
W10141329
Illus. Part
No. No. DESCRIPTION
1 7902P805−60 Glass, Outer
2 311426 Nut
3 74008914 Spacer, Handle
4
7760P218−60 Panel, (Stainless)
5 74008920 Handle, Door
6 Trim, Side
74010560 Black
74010561 White
7 Glass, Door
74008684 White
74008686 Black
8 Trim, Bottom
74008757 White
74008889 Black
9 Tape,Double Sided
74009014 White
74009025 Black
10
3801F918−51 Bracket, Glass
(Stainless Models)
11
7002P482−60 Insulation, Foil
12 74008916 Gasket, Window
13 74008926 Liner, Door
14 74003645 Glass, Inner
15
3601F380−51 Baffle, Door
(Stainless Models)
16 Trim, Top
74008747 White
74008890 Black
17
7002P484−60 Insulation, Door
18 Bracket, Handle
74009412 Left
74009413S Right
19 74004224 Tape
20
8270P090−60 Tape, Foil 3"
21
7101P282−60 Screw
22 74010546 Hinge, Door
23 74011458 Bracket, Glass
24 74003647 Insulation, Door
