Product dimension, cutout and installation specifications are provided for planning purposes only. Before installing
any product, be sure to verify cutout dimensions and electrical/gas connections as actual product dimensions may vary.
JENN-AIR® DETAILED PLANNING DIMENSIONS 1 of 4
JRC120046A 07/2012
48" PRO-STYLE® GAS RANGE
JGRP548WP – 477⁄8" x 383⁄4" x 291⁄4"
PRODUCT DIMENSIONS
FRONT VIEW
TOP VIEW
Floor
Wall
K
L
A
M
N
O
M*
N*
O*
B*
A*
C*
D*
E*
I
H
F
G
J
A
GH
K
I
L
J
BD
C
F
E
O
N
Floor
Wall
K
L
A
M
N
O
M*
N*
O*
B*
A*
C*
D*
E*
I
H
F
G
J
A
GH
K
I
L
J
BD
C
F
E
O
N
MODEL # JGRP548WP
in cm
AOverall width 477⁄8121.6
BWidth of secondary oven door 175⁄844.6
CSpace between doors 3⁄41.8
DWidth of main oven door 295⁄875.2
EHeight of island trim backsplash 3 7.6
FHeight of bullnose 21⁄45.5
GHeight of control panel 53⁄813.5
HSpace between doors
and control panel 7⁄82.0
IHeight of doors 203⁄452.5
JHeight to top of handles 193⁄849.0
KSpace between doors and lower panel 1 2.5
LHeight of lower panel 51⁄214.0
MDepth with control panel overhang 273⁄869.5
NDepth with handles 291⁄474.2
ODepth with doors fully open 453⁄4116.2

Product dimension, cutout and installation specifications are provided for planning purposes only. Before installing
any product, be sure to verify cutout dimensions and electrical/gas connections as actual product dimensions may vary.
JENN-AIR® DETAILED PLANNING DIMENSIONS 2 of 4
JRC120046A 07/2012
DIMENSIONS AS INSTALLED
SIDE VIEW
48" PRO-STYLE® GAS RANGE
JGRP548WP – 477⁄8" x 383⁄4" x 291⁄4"
Floor
Wall
K
L
A
M
N
O
M*
N*
O*
B*
A*
C*
D*
E*
I
H
F
G
J
A
GH
K
I
L
J
BD
C
F
E
O
N
MODEL # JGRP548WP
in cm
A* Height to top of grates (min.) 363⁄493.3
B* Height to top of cooking surface (min.) 353⁄490.8
C* Height to top of doors (min.) 273⁄869.5
D* Height to top of handles (min.) 257⁄865.7
E* Height to top of lower panel (min.) 57⁄814.9
FDepth with doors fully open 453⁄4116.2
GDepth with handles 291⁄474.2
HDepth with control panel overhang 273⁄869.5
IDepth without control panel 231⁄259.5
JDepth of island trim backsplash 21⁄45.7
KDepth without doors 245⁄862.5
LDepth with doors 263⁄468.0
M* Height to top of island trim
backsplash (min.) 383⁄498.4
OPTIONAL ACCESSORIES
N* Height to top of adjustable
stainless steel backsplash (min.) 551⁄2141.0
O* Height to top of adjustable
stainless steel backsplash (max.) 743⁄4189.9
*Add 13⁄4" (4.4 cm) to the height dimension when leveling legs
are fully extended.

Product dimension, cutout and installation specifications are provided for planning purposes only. Before installing
any product, be sure to verify cutout dimensions and electrical/gas connections as actual product dimensions may vary.
JENN-AIR® DETAILED PLANNING DIMENSIONS 3 of 4
JRC120046A 07/2012
OPENING/CLEARANCE DIMENSIONS
48" PRO-STYLE® GAS RANGE
JGRP548WP – 477⁄8" x 383⁄4" x 291⁄4"
G*
L
H
A
BB
J
M**
Side
Cabinet
D
Ie
g
C
K
E
F
SIDE VIEW
FRONT VIEW
Floor
Wall
K
L
A
M
N
O
M*
N*
O*
B*
A*
C*
D*
E*
I
H
F
G
J
A
GH
K
I
L
J
BD
C
F
E
O
N
BACK VIEW
G*
L
H
A
BB
J
M**
Side
Cabinet
D
Ie
g
C
K
E
F
MODEL # JGRP548WP
in cm
AWidth of combustible area above
cooking surface (min.) 48 121.9
BWidth from range to fixed wall
or other combustible material (min.) 6 15.2
CWidth of opening (min.) 481⁄4122.6
DWidth of electrical installation area 40 101.6
EWidth of gas installation area 24 61.0
FWidth from side cabinet to gas
installation area 6 15.2
G* Height to bottom of uncovered wood or
metal cabinet above cooking surface (min.) 42 106.7
HHeight to bottom of uncovered wood
or metal cabinet (min.) 18 45.7
IHeight of electrical installation area 15 38.1
JDepth of electrical and gas installation area 5 12.7
KHeight of gas installation area 3 7.6
LDepth of upper cabinet (max.) 13 33.0
M** Depth to wall (min.) 6 15.2
NWidth to electrical conduit 91⁄823.0
OWidth to gas inlet 143⁄836.5
eRecommended electrical access location
gRecommended gas supply line location
*Dimension can be reduced by 6" (15.2 cm) when bottom of wood or metal cabinet
is covered by not less than 1⁄4" (0.6 cm) flame retardant millboard covered with not
less than No. 28 MSG sheet metal, 0.015" (0.4 mm) stainless steel, 0.024" (0.6 mm)
aluminum or 0.020" (0.5 mm) copper.
If installing a hood or hood liner above the range, follow the hood or hood liner
instructions for dimensional clearances above the cooking surface.
**If back wall is constructed of a combustible material and a backsplash is not installed,
a 6" (15.2 cm) minimum clearance is required.
ELECTRICAL REQUIREMENTS
120 volt, 60 Hz, AC only, 15-amp fused, grounded circuit is required. A dedicated
circuit is recommended.

Product dimension, cutout and installation specifications are provided for planning purposes only. Before installing
any product, be sure to verify cutout dimensions and electrical/gas connections as actual product dimensions may vary.
JENN-AIR® DETAILED PLANNING DIMENSIONS 4 of 4
VENTILATION SELECTION ChART – RANGETOPS AND RANGES
MODEL #
PRO-STYLE™ HOODS
EURO-STYLE
ISLAND-MOUNT HOODS
EURO-STYLE
WALL-MOUNT HOODS
GLASS
COLLECTION
ISLAND-MOUNT
HOOD
GLASS COLLECTION
WALL-MOUNT HOODS
PERIMETRIC
HOOD
OILED BRONzE
WALL-MOUNT HOODS
EURO-STYLE
TELESCOPING
DOWNDRAFT
SYSTEMS CUSTOM HOOD LINERS
OVER-THE-
RANGE
MICROWAVE
OVENS
JXW9048WP
JXW9036WP
JXU9136WP
JXW9030WP
JXU9130WP JXI8042WS JXI8036WS
JXW8036WS
JXW8836WS JXW8030WS JXI5036WS JXW5036WS JXW5030WS JXP5032WS JXW6036WR JXW6030WR
JXD7036YS
JXD7030YS
UXL6048YSS
UXL6036YSS
JMV9186W
JMV8208W
1200 or
600 CFMA600 CFMB
PRO-STYLE®RANGETOPS
48-INCH (more than 60,000 BTU total)
JGCP548WP – 6 Burners & Griddle ★—————— — ————— — ★— —
36-INCH (less than 60,000 BTU total)
JGCP536WP – 4 Burners & Griddle ★ ★ —nnn—n n —n n — — ★ ★ —
36-INCH (more than 60,000 BTU total)
JGCP436WP – 6 Burners ★ ★ — — — — — — — — — — — — ★— —
30-INCH (less than 60,000 BTU total)
JGCP430WP – 4 Burners n★ ★ n n n n n n n n n n —★ ★ —
48-INCH (less than 60,000 BTU total)
JGD8348CDP – 4 Burners & Grill Assembly — — — — — — — — — — — — — — ★— —
PRO-STYLE®DUAL-FUEL AND GAS RANGES
48-INCH (more than 60,000 BTU total)
JDRP548WP – 6 Burners & Griddle ★—— — — — — — — — — — — — ★— —
JGRP548WP – 6 Burners & Griddle ★—————— — ———— — —★— —
36-INCH (less than 60,000 BTU total)
JDRP536WP – 4 Burners & Griddle ★ ★ —nnn—n n —n n — — ★ ★ —
JGRP536WP – 4 Burners & Griddle ★ ★ —nnn—n n —n n — — ★ ★ —
36-INCH (more than 60,000 BTU total)
JDRP436WP – 6 Burners ★ ★ —— — — — — — — — — — — ★— —
JGRP436WP – 6 Burners ★ ★ ————— — ————— —★— —
30-INCH (less than 60,000 BTU total)
JDRP430WP – 4 Burners — ★ ★ —n n n n n n n n n —★ ★ —
JGRP430WP – 4 Burners — ★ ★ —n n n n n n n n n —★ ★ —
SLIDE-IN RANGES
Dual-Fuel and Gas Conventional (less than 60,000 BTU total)
JDS8860BDP – 4 Burners n★ ★ n★★★ ★ ★★★ n n —★ ★ n
JDS8850CD – 4 Burners nnnn★★★ ★ ★★★ n n —★ ★ n
JGS8860BDP – 4 Burners n★ ★ n★★★ ★ ★★★ n n —★ ★ n
JGS8850CD – 4 Burners nnnn★ ★ ★ ★ ★ ★ ★ ★ ★ —★ ★ n
ELECTRIC CONVENTIONAL
JES8850CA – 5 Elements nnnn★★★ ★ ★★★ n n —★ ★ n
A. Custom hood liners can be used with any of the following blower motors: UXB1200DYS, UXB0600DYS, UXI1200DYS or UXI0600DYS.
B. Blower motor UXB0600DYS is rated for up to 65,000 BTUs and can be used with the rangetops and ranges indicated.
KEY
★Style and Performance Pair
nPerformance Pair
— Not Recommended
JRC120046A 07/2012
