Jenn-Air DOUBLE REFRIGERATOR DRAWERS W10310149A User manual

DOUBLE REFRIGERATOR DRAWERS
REFRIGERATOR/FREEZER DRAWERS
DOUBLE FREEZER DRAWERS
Installation Instruction and Use & Care Guide
For questions about features, operation/performance, parts, accessories, or service, call: 1-800-688-1100 or visit our website at...
www.jennair.com
In Canada, call: 1-800-807-6777, or visit our website at...
www.jennair.ca
CAJÓN REFRIGERADOR DOBLE
CAJÓN REFRIGERADOR/CONGELADOR
CAJÓN CONGELADOR DOBLE
Instrucciones de instalación y Manual de uso y cuidado
Para consultas respecto a características, operación/desempeño, partes, accesorios o servicio, llame al: 1-800-688-1100
o visite nuestra página de internet...
www.jennair.com
En Canadá, llame al: 1-800-807-6777 o visite nuestra página de internet...
www.jennair.ca
DOUBLE TIROIR RÉFRIGÉRÉ
TIROIRS DE RÉFRIGÉRATION/CONGÉLATION
DOUBLE TIROIR DE CONGÉLATION
Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site web à...
www.jennair.ca
Table of Contents/Índice/Table des matières ..................................................................2
W10310149A / 8336411963000B

2
TABLE OF CONTENTS
REFRIGERATOR DRAWERS SAFETY....................................................... 3
Proper Disposal of Your Old Refrigerated Appliance .............................. 3
DESIGN SPECIFICATIONS......................................................................... 4
24" Drawer Models ................................................................................... 4
INSTALLATION REQUIREMENTS ............................................................. 5
Tools and Parts......................................................................................... 5
Location Requirements............................................................................. 5
Electrical Requirements............................................................................ 5
Water Supply Requirements..................................................................... 6
Product Dimensions ................................................................................. 6
Custom Overlay Drawer Panels................................................................7
INSTALLATION INSTRUCTIONS ............................................................... 7
Unpack the Refrigerator Drawers............................................................. 7
Connect Water Supply..............................................................................8
Move the Refrigerator Drawers to Final Location .................................... 8
Level the Refrigerator Drawers.................................................................9
Install Custom Overlay Panel.................................................................... 9
Complete Installation ................................................................................ 9
REFRIGERATOR DRAWERS USE ........................................................... 10
Normal Sounds....................................................................................... 10
Ensuring Proper Air Circulation .............................................................. 10
Using the Controls.................................................................................. 10
Ice Maker and Water Filtration System................................................. 11
REFRIGERATOR DRAWERS CARE ........................................................ 12
Cleaning.................................................................................................. 12
Power Interruptions ................................................................................ 13
Vacation Care ......................................................................................... 13
TROUBLESHOOTING ............................................................................... 13
ASSISTANCE OR SERVICE...................................................................... 14
In the U.S.A............................................................................................. 14
In Canada................................................................................................ 15
Accessories............................................................................................. 15
WATER FILTER CERTIFICATIONS.......................................................... 15
PRODUCT DATA SHEETS........................................................................ 16
WARRANTY ............................................................................................... 17
ÍNDICE
SEGURIDAD DE LOS CAJONES REFRIGERADOS ...............................18
Cómo deshacerse adecuadamente de su aparato refrigerado viejo ....18
ESPECIFICACIONES DE DISEÑO ...........................................................19
Modelos de cajón de 24"........................................................................19
REQUISITOS DE INSTALACIÓN..............................................................20
Piezas y herramientas.............................................................................20
Requisitos de ubicación .........................................................................20
Requisitos eléctricos...............................................................................20
Requisitos del suministro de agua .........................................................21
Medidas del producto.............................................................................21
Paneles de los cajones recubiertos a la medida....................................22
INSTRUCCIONES DE INSTALACIÓN......................................................23
Cómo desempacar los cajones refrigerados .........................................23
Conexión del suministro de agua...........................................................23
Mueva los cajones refrigerados a su posición final ...............................24
Nivelación de los cajones refrigerados................................................... 24
Cómo instalar el panel recubierto a la medida....................................... 25
Complete la instalación .......................................................................... 25
USO DE LOS CAJONES REFRIGERADOS ............................................. 25
Sonidos normales................................................................................... 25
Cómo asegurar la debida circulación de aire ........................................ 26
Uso de los controles............................................................................... 26
Fábrica de hielo y sistema de filtración de agua.................................... 27
CUIDADO DE LOS CAJONES REFRIGERADOS.................................... 28
Limpieza.................................................................................................. 28
Cortes de corriente................................................................................. 29
Cuidado durante las vacaciones............................................................ 29
SOLUCIÓN DE PROBLEMAS................................................................... 29
AYUDA O SERVICIO TÉCNICO................................................................ 31
En los EE.UU........................................................................................... 31
En Canadá .............................................................................................. 31
Accesorios .............................................................................................. 31
HOJA DE DATOS DEL PRODUCTO........................................................ 32
GARANTÍA ................................................................................................. 33
TABLE DES MATIÈRES
SÉCURITÉ DES TIROIRS RÉFRIGÉRÉS .................................................35
Mise au rebut correcte de votre vieil appareil réfrigéré..........................35
SPÉCIFICATIONS DE DESIGN.................................................................36
Modèles de tiroirs de 24''.......................................................................36
EXIGENCES D’INSTALLATION................................................................37
Outillage et pièces ..................................................................................37
Exigences d’emplacement .....................................................................37
Spécifications électriques....................................................................... 37
Spécifications de l’alimentation en eau..................................................38
Dimensions du produit............................................................................38
Panneaux décoratifs de tiroirs personnalisés ........................................39
INSTRUCTIONS D’INSTALLATION .........................................................40
Déballage des tiroirs réfrigérés...............................................................40
Raccordement de l'alimentation en eau.................................................40
Déplacement des tiroirs réfrigérés à leur emplacement final.................41
Réglage de l'aplomb des tiroirs réfrigérés .............................................41
Installation du panneau décoratif personnalisé......................................42
Achever l'installation............................................................................... 42
UTILISATION DES TIROIRS RÉFRIGÉRÉS............................................. 42
Sons normaux......................................................................................... 42
Pour assurer une circulation d'air correcte............................................ 43
Utilisation des commandes.................................................................... 43
Machine à glaçons et système de filtration de l'eau.............................. 44
ENTRETIEN DES TIROIRS RÉFRIGÉRÉS............................................... 45
Nettoyage ............................................................................................... 45
Pannes de courant.................................................................................. 46
Entretien avant les vacances.................................................................. 46
DÉPANNAGE ............................................................................................. 47
ASSISTANCE OU SERVICE...................................................................... 48
Aux États-Unis........................................................................................ 48
Au Canada .............................................................................................. 48
Accessoires............................................................................................. 48
FEUILLES DE DONNÉES SUR LE PRODUIT.......................................... 49
GARANTIE.................................................................................................. 50

3
REFRIGERATOR DRAWERS SAFETY
Proper Disposal of Your Old
Refrigerated Appliance
IMPORTANT: Child entrapment and suffocation are not problems
of the past. A junked or abandoned refrigerated appliance is still
dangerous – even if it will sit for “just a few days.” If you are
getting rid of your old refrigerated appliance, please follow these
instructions to help prevent accidents.
Before You Throw Away Your Old Refrigerated Appliance:
Remove the door or drawer(s).
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
To reduce the risk of fire, electric shock, or injury when using your refrigerator drawer(s), follow these basic
SAVE THESE INSTRUCTIONS
■ Plug into a grounded 3 prong outlet.
■ Do not remove ground prong.
■ Do not use an adapter.
■ Do not use an extension cord.
■ Disconnect power before servicing.
■ Replace all parts and panels before operating.
■ Remove door or drawer(s) from your old refrigerated
appliance.
■ Use nonflammable cleaner.
■ Keep flammable materials and vapors, such as gasoline,
away from refrigerator drawer(s).
■ Use two or more people to move and install refrigerator
drawer(s).
precautions:
WARNING
Suffocation Hazard
Remove door or drawer(s) from your old refrigerated
appliance.
Failure to do so can result in death or brain damage.

4
DESIGN SPECIFICATIONS
24" Drawer Models
Double Refrigerator Drawers
Two refrigerator drawers provide additional storage options in the kitchen or other areas of the home.
Euro Series
JUD248R*R* Overlay - Custom Panels and Handles Required JUD248R*C*
Refrigerator/Freezer Drawers (with ice maker and water filter)
Upper refrigerator drawer and lower freezer drawer provide additional storage options in the kitchen or other areas of the home.
Factory-installed ice maker in lower drawer ensures a constant supply of ice on hand at all times.
Euro Series
JUD248C*R* Overlay - Custom Panels and Handles Required JUD248C*C*
Double Freezer Drawers (with ice maker and water filter)
Two freezer drawers provide additional storage options in the kitchen or other areas of the home. Factory-installed ice maker in lower
drawer ensures a constant supply of ice on hand at all times.
Euro Series
JUD248F*R* Overlay - Custom Panels and Handles Required JUD248F*C*

5
INSTALLATION REQUIREMENTS
Tools and Parts
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Additional Tools Needed (Style 2 - Overlay only):
PARTS NEEDED (Style 2 - Overlay only):
PARTS SUPPLIED:
Location Requirements
NOTES:
■For the refrigerator drawers to be flush with the front of the
base cabinets remove any baseboards or moldings from the
rear of the opening. See “Product Dimensions” and later in
this section “Opening Dimensions (both styles).”
■It is recommended that you do not install the refrigerator
drawers near an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C).
Opening Dimensions (both styles)
■Height dimensions are shown with the leveling legs extended
to the minimum height of ¹⁄₄" (6.35 mm) below the refrigerator
drawers.
NOTE: When leveling legs are fully extended to 1" (25 mm)
below the refrigerator drawers, add ³⁄₄" (19.05 mm) to the
height dimensions. See “Product Dimensions.”
■If the floor of the opening is not level with the kitchen floor,
shim the opening to make it level with the kitchen floor.
Electrical Requirements
Before you move your refrigerator drawers into the final location, it
is important to make sure you have the proper electrical
connection.
Recommended grounding method
A 115 Volt, 60 Hz., AC only, 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator drawers be provided. Use an
outlet that cannot be turned off by a switch. Do not use an
extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground Fault
Circuit Interrupter) equipped outlet, nuisance tripping of the power
supply may occur, resulting in loss of cooling. Food quality and
flavor may be affected. If nuisance tripping has occurred, and if
the condition of the food appears poor, dispose of it.
■Cordless drill
■¹⁄₈" Drill bit
■Tape measure
■Level
■Phillips screwdriver
■Scissors
■Pencil
■Scribe
■Custom Overlay Drawer Panels —
See “Custom Overlay Drawer Panels.”
■Hardware
■Hooks (8)
■Overlay plates (4)
■Screws (16)
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator drawer(s).
Failure to do so can result in death, explosion, or fire.
Critical Dimensions:
A. 14
³⁄₄ " (37.5 cm) utility opening
B. 24" (60.96 cm) minimum opening width
¹⁄₂"
(1.3 cm)
A
14³⁄₄"
(37.5 cm)
24"
(60.96 cm)
min.
24" (60.96 cm) min.
34³⁄₈" (87.3 cm) min.
35" (88.9 cm) max.
B
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

6
Water Supply Requirements
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
IMPORTANT:
■If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
■All installations must meet local plumbing code requirements.
■Use copper tubing and check for leaks. Install copper tubing
only in areas where the household temperatures will remain
above freezing.
TOOLS NEEDED: Flat-blade screwdriver, ⁷⁄₁₆" and ¹⁄₂" open-end
wrenches or two adjustable wrenches, ¹⁄₄" nut driver and drill bit,
cordless drill.
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper tubing.
Before purchasing, make sure a saddle-type valve complies with
your local plumbing codes. Do not use a piercing-type or ³⁄₁₆"
(4.76 mm) saddle valve which reduces water flow and clogs more
easily.
Water Pressure
A cold water supply with water pressure of between 30 and
120 psi (207 and 827 kPa) is required to operate ice maker. If you
have questions about your water pressure, call a licensed,
qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi
(207 and 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
If you have questions about your water pressure, call a licensed,
qualified plumber.
Product Dimensions
Styles 1 and 2 - Euro Series and Overlay
■Height dimensions are shown with the leveling legs extended
to ¹⁄₄" (6.35 mm) below the refrigerator drawers.
■When leveling legs are fully extended to 1" (25 mm) below the
refrigerator drawers, add ³⁄₄" (19.05 mm) to the height
dimensions.
■The power cord is 60" (152.4 cm) long.
Style 1 - Euro Series
Style 2 - Overlay
Drawer Opening Dimensions
Dimensions vary based on model, as shown.
Style 1 - Euro Series
14⁷⁄₈"
(37.8 cm)
14⁷⁄₈"
(37.8 cm)
34¹⁄₈"
(86.7 cm)
³⁄₈"
(1.0 cm)
14⁷⁄₈"
(37.8 cm)
14⁷⁄₈"
(37.8 cm)
34¹⁄₈"
(86.7 cm)
³⁄₈"
(1.0 cm)
18⁹⁄₁₆"
(47.2 cm)
22¹⁄₂"
(57.2 cm)
21"
(53.3 cm)

7
Style 2 - Overlay
Drawer Width Dimensions
Style 1- Euro Series
Style 2 - Overlay
Custom Overlay Drawer Panels
If you plan to install custom wood panels, you will need to create
the panels yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for panel specifications.
IMPORTANT:
■The thickness of the overlay panels must be ³⁄₄" (19.05 mm).
■To avoid damage to the drawers, each overlay panel must not
weigh more than 10 lbs (4.5 kg).
■Do not exceed the height dimension for the overlay panels.
Panels that exceed the height dimension may damage the
refrigerator drawers, cabinets or countertop.
■The width of the overlay panels may vary according to the
width of the cabinet opening.
Top and Bottom Overlay Drawer Panel Dimensions
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator Drawers
Remove the Packaging
Remove tape and glue residue from surfaces before turning on
the refrigerator drawers. Rub a small amount of liquid dish soap
over the glue residue with your fingers. Wipe with warm water and
dry. Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator drawers.
Properly dispose of packaging.
17¹⁄₄"
(43.8 cm)
22¹⁄₂"
(57.2 cm)
23⁵⁄₈"
(60.0 cm)
23³⁄₄"
(60.4 cm)
24³⁄₄"
(60.4 cm)
27¹⁄₈"
(68.9 cm)
23⁵⁄₈"
(60.0 cm)
23³⁄₄"
(60.4 cm)
22¹⁄₂"
(57.1 cm)
24¹⁄₈"
(61.2 cm)
A. Overlay hook locations
B. Rout
¹⁄₈ " (3.18 mm) deep.
Reverse Side
23⁵⁄₈"
(60.0 cm)
14⁷⁄₈"
(37.8 cm)
¹⁵⁄₁₆" (2.4 cm)
4¹⁄₈"
(10.5 cm)
¹³⁄₁₆"
(2.1 cm)
2³⁄₁₆"
(5.6 cm)
¹³⁄₁₆"
(2.1 cm)
A
¹⁵⁄₁₆"
(2.4 cm)
1³⁄₄"
(4.4 cm)
R ¹⁄₁₆"
(1.6 mm)
min.
B
Pilot Holes
¹⁄₁₆" (1.6 mm) diameter x
³⁄₈" (9.5 mm) deep
8 places
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator drawer(s).
Failure to do so can result in back or other injury.

8
Clean Before Using
After you remove all of the package materials, clean the inside of
your refrigerator drawers before using them. See “Cleaning.”
Connect Water Supply
(Refrigerator/Freezer Drawers and
Double Freezer Drawers only)
Connect to Water Line
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a ½" to 1¹⁄₄" (1.25 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but drill on the top side of the
pipe, not the bottom. This will help keep water away from
the drill and normal sediment from collecting in the valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the lower left rear of refrigerator to the
water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure both
ends of copper tubing are cut square.
5. Using a cordless drill, drill a ¹⁄₄" hole in the cold water pipe you
have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" drilled hole in
the water pipe and that the washer is under the pipe clamp.
Tighten the packing nut. Tighten the pipe clamp screws slowly
and evenly so washer makes a watertight seal. Do not
overtighten or you may crush the copper tubing.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten.
8. Place the free end of the tubing in a container or sink, and turn
ON the main water supply. Flush the tubing until water is clear.
Turn OFF the shutoff valve on the water pipe. Coil the copper
tubing.
Connect to Refrigerator
1. Attach the copper tube to the valve inlet using a compression
nut and sleeve as shown. Tighten the compression nut. Do not
overtighten. Use the tube clamp on the back of the refrigerator
to secure the tubing to the refrigerator as shown. This will help
avoid damage to the tubing when the refrigerator is pushed
back against the wall.
2. Turn shutoff valve ON.
3. Check for leaks. Tighten any connections (including
connections at the valve) or nuts that leak.
4. The ice maker is equipped with a built-in water strainer. If your
water conditions require a second water strainer, install it in
the ¹⁄₄" (6.35 mm) water line at either tube connection. Obtain
a water strainer from your nearest appliance dealer.
5. Plug in refrigerator or reconnect power.
Move the Refrigerator Drawers to
Final Location
1. Place top of cardboard carton or plywood under the
appliance. Remove dolly.
2. Do not remove film or cover.
3. Plug into a grounded 3 prong outlet.
4. Move the refrigerator drawers straight back and evenly in front
of the opening.
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
When MovingYour Refrigerator Drawers:
Your refrigerator drawers are heavy. When moving the
appliance for service, be sure to cover the floor with
cardboard or hardboard to avoid floor damage. Always pull
the appliance straight out when moving it. Do not wiggle or
“walk” the appliance when trying to move it, as floor
damage could occur.
A
B
C
DEF
G
A. Plug
B. Compression nut
C. Pex tubing
A
B
C
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

9
Level the Refrigerator Drawers
IMPORTANT:
■Overlay Model—Be sure to install the custom overlay drawer
panels before leveling the refrigerator drawers. See “Install
Custom Overlay Drawer Panels.”
■Before installing the refrigerator drawers, be sure that the
countertop is level.
■If the countertop is not level, adjust the refrigerator drawers’
leveling legs until the appliance is square with the countertop.
Be sure to maintain ³⁄₈" (9.5 mm) minimum gap between the
top of the drawer and the countertop.
1. Open the top drawer and place the level across the top
drawer as shown. Check the level from left to right.
2. Turn the leveling legs (front and back) until the top drawer
measures level from left to right.
3. Remove the level and close the top drawer. Check the gap
between the top of the drawer and the countertop. If the gap
measures less than ³⁄₈" (9.5 mm) minimum, turn all four
leveling bolts equally to the left to raise the leveling legs (this
will lower the appliance). Recheck the level.
4. Open both drawers less than midway. Place the level on the
side flange beside the drawers as shown. Turn the front
leveling bolts together in order to either raise or lower the
appliance until the sides of the refrigerator drawers are plumb.
5. Remove the level and close the drawers. Recheck the gap
between the top of the drawer and the countertop. If the gap
measures less than ³⁄₈" (9.5 mm), turn all four leveling bolts
equally to raise the leveling legs (this will lower the appliance).
Recheck the level.
NOTE: Be sure to recheck the horizontal level of the top
drawer.
6. Be sure all four levelers are on the floor and supporting the full
weight of the refrigerator drawers.
Install Custom Overlay Panel
IMPORTANT:
■Create a custom overlay panel according to the specifications
in “Custom Overlay Drawer Panels.”
■Jenn-Air is not responsible for the removal or addition of
molding or decorative panels that would not allow access to
the refrigerator for service.
Attach the Overlay Panel
NOTE: If the overlay hooks are not installed, see “Custom Overlay
Drawer Panels” for overlay hook locations.
1. Position the overlay panel ¹⁄₂" (1.27 cm) higher than the door.
Be sure to position the overlay hooks to the pilot holes.
2. Insert the overlay hooks into the top of the holes in the door.
Push against the overlay panel to force the overlay hooks
deeper into the door. Pull the overlay panel straight down to
secure the overlay hooks to the door.
3. Using a Phillips screwdriver, attach the overlay plates to the
bottom of the overlay panel and door as shown.
Complete Installation
1. Remove all boxes, parts packages and packing materials from
the interior of the refrigerator drawers.
2. Remove the film.
3. Clean the refrigerator drawers before use.
4. The controls are preset at the factory to the recommended
settings. Be sure that the compressor is operating properly
and that all the lights are working.
A. Check the level from left to right.
A. Check the level from front to back.
A
A
A. Overlay panel
B. Door
C. Overlay plates (2)
D. Round-head screws (8
ACDB

10
5. If construction will continue after the refrigerator drawers have
been installed, turn the power Off for both Drawers.
To get the most efficient use from your new refrigerator drawers,
read the “Refrigerator Drawers Use” section.
REFRIGERATOR DRAWERS USE
Normal Sounds
Your new refrigerator drawers may make sounds that your old
refrigerator drawers didn’t. Because the sounds are new to you,
you might be concerned about them. Most of the new sounds are
normal. Hard surfaces, such as the floor, walls, and cabinets, can
make the sounds seem louder. The following describes the kinds
of sounds and what may be making them.
■Your refrigerator drawers are designed to run more efficiently
to keep your food items at the desired temperatures and to
minimize energy usage. The high efficiency compressor and
fans may cause your refrigerator drawers to run longer than
your old ones. You may also hear a pulsating or high-pitched
sound from the compressor or fans adjusting to optimize
performance.
■You may hear the evaporator fan motor circulating air through
the refrigerator drawers. The fan speed may increase as you
open the drawers or add warm food.
■As each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing through the sealed system tubing.
■Contraction and expansion of the inside walls may cause a
popping noise.
■You may hear air being forced over the condenser by the
condenser fan.
■You may hear water running into the drain pan during the Off
cycle.
Ensuring Proper Air Circulation
In order to ensure proper temperatures, you need to permit airflow
inside the drawers.
Do not block any airflow vents. If the vents are blocked, airflow will
be obstructed and temperature and moisture problems may
occur.
IMPORTANT: To avoid odor transfer and drying out of food, wrap
or cover foods tightly.
Using the Controls
The control panels for both refrigerator drawers are located in the
upper drawer. To view and set the Upper and Lower control panel,
pull out the upper drawer.
IMPORTANT:
■Wait 24 hours after you turn on the refrigerator drawers before
you put food into the drawers. If you add food before the
drawers have cooled completely, your food may spoil.
NOTE: Adjusting the controls to a lower (colder) setting in one
or both drawers will not cool them any faster.
■If the temperature is too warm or too cold in the drawers, first
check the air vents to be sure they are not blocked before
adjusting the controls.
■The preset settings should be correct for normal household
usage. The refrigerator control is set correctly when milk or
juice is as cold as you like.
■The freezer control is set correctly when ice cream is firm.
■The actual temperature may differ from the display when a
drawer is open for an extended period of time.
Turning Drawers On/Off
■Press and hold COOL ON/OFF for 3 seconds to turn on the
drawers. The indicator will light up.
■Press and hold COOL ON/OFF for 3 seconds to turn off the
drawers.
Viewing Celsius Temperatures
■Press the °C touch pad to change the temperature display
information from Fahrenheit to Celsius. The indicator will light
up.
■To redisplay degree Fahrenheit, press °C touch pad again.
Set to Recommended Temperatures
■Press the SET touch pad to reset the set point to the factory
recommended temperature.
■The recommended temperature for the refrigerator drawer is
37°F (3°C). The recommended temperature for the freezer
drawer is 0°F (-18°C).
Adjusting Temperature Set Points
Style 1 - Double Refrigerator Drawers
The refrigerator control adjusts the temperature in both upper and
lower drawers.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

11
Style 2 - Refrigerator/Freezer Drawers
The refrigerator control adjusts the temperature in the upper
drawer. The freezer control adjusts the temperature of the lower
drawer.
Style 3 - Double Freezer Drawers
The freezer control adjusts the temperature in both upper and
lower drawers.
IMPORTANT: Wait at least 24 hours between adjustments.
Recheck the temperatures before other adjustments are made.
To adjust set point temperatures:
■Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature setting is reached.
NOTE: The set point range for the refrigerator drawer is 34°F
(1°C) to 45°F (7°C). The set point range for the freezer drawer
is -5°F (-20.5°C) to 5°F (-15°C).
Max Cool or Max Freeze
The Max Cool or Max Freeze feature assists with periods of heavy
usage, full grocery loads or temporarily warm room temperatures.
Style 1 - Double Refrigerator Drawers
Max Cool will reset the temperature for both drawers to the
coldest setting 34°F (0.5°C) for a 24-hour period.
Style 2 - Refrigerator/Freezer Drawers
Max Cool will reset the temperature for both drawers to the
coldest setting 34°F (0.5°C) in the refrigerator drawer and -5°F
(-20.5°C) in the freezer drawer for 24 hours.
Style 3 - Double Freezer Drawers
Max Freeze will reset the temperatures for both drawers to the
coldest setting -5°F (-20.5°C) for 24 hours.
NOTE: The temperature display will remain at the coldest
setting(s) and the indicator light will remain on for a 24-hour
period. The drawer will automatically return to the previous
temperature set point(s) and the indicator light will turn off.
Sabbath Mode
Sabbath Mode is designed for the traveler or for those whose
religious observances require turning off the lights. By selecting
this feature, the temperature set points remain unchanged and the
interior lights will turn off. For most efficient refrigerator drawers
operation, it is recommended to exit the Sabbath Mode when it is
no longer required.
■Press and hold the SABBATH MODE touch pad for 3 seconds
to turn on the feature. The indicator will light up.
■Press and hold the SABBATH MODE touch pad for 3 seconds
to turn off the feature.
Control Lock
The control panel can be locked to avoid unintentional
temperature changes by small children or during cleaning.
■Press and hold the CONTROL LOCK touch pad for 3 seconds
to turn on the feature. The indicator will light up.
■To deactivate the feature, press and hold the CONTROL
LOCK touch pad for 3 seconds.
NOTE: When Control Lockout is activated, the control panel
touch pads will not work. Any attempt to change the settings will
result in a beep which indicates the control panel is locked.
Drawer Open/Alarm Reset
The Drawer Open alarm will sound and the Alarm Reset indicator
will light up when a drawer has been open for longer than
10 minutes.
To temporarily disable the Drawer Open alarm, press and hold the
ALARM RESET touch pad for 3 seconds. Closing the drawer will
stop the audible alarm and reset the 10-minute timer.
Ice Maker and Water Filtration System
(Refrigerator/Freezer Drawers and
Double Freezer Drawers only)
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, fill and discard three full containers of
ice to prepare the water filter for use before using ice.
Turning the Ice Maker On/Off
IMPORTANT: Use the Ice On touch pad on the control panel to
turn the ice maker on or off. Do not adjust the wire arm located on
the ice maker.
■Press and hold the ICE ON/OFF touch pad for 3 seconds to
turn on the ice maker. The indicator will light up.
■Press and hold the ICE ON/OFF touch pad for 3 seconds to
turn off the ice maker.

12
REMEMBER:
■Allow 24 hours to produce the first batch of ice.
■The quality of your ice will only be as good as the quality of the
water supplied to your ice maker.
■Avoid connecting the ice maker to a softened water supply.
Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
■Do not store anything in the ice storage bin.
Water Filtration System
Water Filter Indicator / Reset Filter
The water filter indicator will help you know when to change your
water filter. The indicator will change from dark to yellow when it is
time to order a new filter. The indicator will then change from
yellow to red when it is time to replace the water filter. The
disposable water filter should be replaced at least every 6 months.
After replacing the water filter, reset the water filter indicator.
■Press and hold the RESET FILTER touch pad for 3 seconds.
The indicator light will turn from red to dark.
Changing the Water Filter
The water filter is located through the base grille. You do not have
to remove the base grille in order to change the water filter.
1. Locate the water filter cap in the front base grille. Rotate the
cap counterclockwise to a vertical position and pull the cap
and water filter out through the base grille.
NOTE: There will be water in the filter. Some spilling may
occur.
2. Remove the filter cap by sliding it off the end of the old filter.
The cap will slide to the left or right.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. Take the new water filter out of its packaging and remove the
cover from the O-rings.
4. Slide the filter cap onto the new water filter. See the illustration
in Step 2.
5. With the filter cap in the vertical position, insert the new filter
into the base grille until it stops. Rotate the cartridge cap
clockwise to a horizontal position.
Using the Ice Maker Without the Water Filter
You can run the ice maker without a water filter. Your water will not
be filtered.
1. Slide the filter cap off the end of the water filter. With the filter
cap in the horizontal position, insert the cap into the base
grille until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with a replacement filter.
REFRIGERATOR DRAWERS
CARE
Cleaning
The drawers defrost automatically. However, clean both drawers
about once a month to avoid buildup of odors. Wipe up spills
immediately.
To clean your refrigerator drawers:
1. Hand wash, rinse, and dry interior surfaces thoroughly. Use a
clean sponge or soft cloth and a mild detergent in warm water.
■Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and drawer liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
■To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt [26 g
to 0.95 L] of water).
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

13
2. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners. Dry thoroughly with a soft
cloth. To avoid damage to painted metal exteriors, apply
appliance wax (or auto paste wax) with a clean, soft cloth. Do
not wax plastic parts.
NOTE: To keep your Stainless Steel refrigerator drawers
looking like new and to remove minor scuffs or marks, it is
suggested that you use the manufacturer’s approved
Stainless Steel Cleaner and Polish. To order the cleaner, see
“Accessories.”
IMPORTANT: This cleaner is for Stainless Steel parts only!
Do not allow the Stainless Steel Cleaner and Polish to come
into contact with any plastic parts such as the trim pieces or
drawer gaskets. If unintended contact does occur, clean
plastic part with a sponge and mild detergent in warm water.
Dry thoroughly with a soft cloth.
Power Interruptions
If the power will be out for 24 hours or less, keep both refrigerator
drawers closed to help food stay cold.
If the power will be out for more than 24 hours, do one of the
following:
■Place all perishable food in a food locker or cooler with dry
ice.
■If neither a food locker or cooler is available, consume food if
still cold or throw away perishable food at once.
Vacation Care
Your refrigerator drawers are equipped with the Holiday Mode
feature. By selecting this feature, the temperature set points
remain unchanged and the interior lights will turn off. For most
efficient refrigerator drawers operation, it is recommended to exit
the Holiday Mode when it is no longer required.
If you choose to leave the refrigerator drawers on while
you’re away:
1. Use up any perishables and freeze other items.
2. Press HOLIDAY MODE touch pad.
3. When you return from vacation, press HOLIDAY MODE touch
pad to return to normal operation.
If you choose to turn the refrigerator drawers off before
you leave:
1. Remove all food from the refrigerator drawers.
2. Turn the Control Panel for the Upper and the Lower drawers to
Off. See “Using the Controls.”
3. Clean refrigerator drawers, wipe and dry them well.
4. Tape rubber or wood blocks to the tops of both drawers to
prop them open far enough for air to get in. This stops odor
and mold from building up.
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Your refrigerator drawers will not operate
■Is the power supply cord unplugged? Plug into a grounded
3 prong outlet.
■Has a household fuse blown, or a circuit breaker tripped?
Replace the fuse or reset the circuit breaker. If the problem
continues, call an electrician.
■Are the refrigerator drawers control set in the Off
position? See “Using the Controls.”
■Are the refrigerator drawers not cooling? Turn them off
then on again to reset. See “Using the Controls.” If this does
not correct the problem, call for service.
The motor seems to run too much
■Is the room temperature hotter than normal? The motor will
run longer under warm conditions. At normal room
temperatures, expect your motor to run about 80% of the
time. Under warmer conditions, it will run even more.
■Has a large amount of food just been added to the
refrigerator drawers? Adding a large amount of food warms
the refrigerator drawers. The motor normally will run longer to
cool the refrigerator drawers back down.
■Are the drawers opened often? The motor will run longer
when this occurs. Conserve energy by getting all items out at
one time, keeping food organized, and closing the drawer as
soon as possible.
■Are the controls not set correctly for the surrounding
conditions? See “Using the Controls.”
■Are the drawers not closed completely? Close the drawers
firmly. If they do not close completely, see “The drawers will
not close completely” later in this section.
■Are the drawer gaskets not sealed all the way around?
Contact a technician or other qualified person.
The refrigerator drawers seems to make too much noise
The sounds may be normal for your refrigerator drawers. See
“Normal Sounds.”
The divider between the two compartments is warm
The warmth is probably due to normal operation of the
automatic exterior moisture control. If still concerned, call for
service.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

14
Temperature is too warm
■Are the air vents blocked in either compartment? This
obstructs cold air movement between the compartments.
Remove any objects from in front of the air vents. See
“Ensuring Proper Air Circulation” for the location of air vents.
■Are the drawers opened often? The refrigerator drawers will
warm when this occurs. Keep the refrigerator drawers cool by
getting all items out at one time, keeping food organized, and
closing the door as soon as possible.
■Has a large amount of food just been added to the
refrigerator drawers? Adding a large amount of food warms
the refrigerator drawers. It can take several hours for the
refrigerator drawers to return to the normal temperature.
■Are the controls set correctly for the surrounding
conditions? See “Using the Controls.”
■Are the refrigerator drawers not cooling? Turn them off
then on again to reset. See “Using the Controls.” If this does
not correct the problem, call for service.
There is interior moisture buildup
■Are the air vents blocked in the refrigerator drawers?
Remove any objects from in front of the air vents. See
“Ensuring Proper Air Circulation” for the location of air vents.
■Are the drawers opened often? Avoid humidity buildup by
getting all items out at one time, keeping food organized, and
closing the drawer as soon as possible.
■Is the room humid? It is normal for moisture to build up
inside the refrigerator drawers when the room air is humid.
■Is the food packaged correctly? Check that all food is
securely wrapped. Dry damp food containers before placing in
the refrigerator drawers.
■Are the controls set correctly for the surrounding
conditions? See “Using the Controls.”
The drawers will not close completely
■Are food packages blocking the drawer open? Rearrange
containers so that they fit more tightly and take up less space.
The drawers are difficult to open
■Are the gaskets dirty or sticky? Clean gaskets and the
surface that they touch. Rub a thin coat of paraffin wax on the
gaskets following cleaning.
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If you
still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
only use factory specified replacement parts. Factory specified
replacement parts will fit right and work right because they are
made with the same precision used to build every new Jenn-Air
appliance.
To locate factory specified parts in your area, call us or your
nearest designated service center.
In the U.S.A.
Call the Jenn-Air Customer eXperience Center
toll free: 1-800-688-1100.
Our consultants provide assistance with:
■Features and specifications on our full line of appliances.
■Installation information.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).
■Referrals to local dealers, repair parts distributors, and service
companies. Jenn-Air designated service technicians are
trained to fulfill the product warranty and provide after-
warranty service, anywhere in the United States.
To locate the Jenn-Air designated service company in your
area, you can also look in your telephone directory Yellow
Pages.
For further assistance
If you need further assistance, you can write to Jenn-Air with any
questions or concerns at:
Jenn-Air Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

15
In Canada
Call the Jenn-Air Canada Customer eXperience Centre toll free:
1-800-807-6777.
Our consultants provide assistance with:
■Features and specifications on our full line of appliances.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Referrals to local dealers, repair parts distributors, and
services companies. Jenn-Air Canada designated service
technicians are trained to fulfill the product warranty and
provide after-warranty service, anywhere in Canada.
For further assistance
If you need further assistance, you can write to Jenn-Air Canada
with any questions or concerns at:
Jenn-Air Brand Home Appliances
Customer eXperience Centre
200 – 6750 Century Ave.
Mississauga, Ontario L5N 0B7
Please include a daytime phone number in your correspondence.
Accessories
To order accessories, call 1-800-442-9991 and ask for the
appropriate part number listed below or contact your authorized
Jenn-Air dealer. In Canada, call 1-800-807-6777.
Base Grille Water Filter
NOTE: Do not use with water that is microbiologically unsafe
or of unknown quality without adequate disinfection before or
after the system.
Replacement filter
Order Part #4396702 (L200V / NL120V)
WATER FILTER
CERTIFICATIONS

16
PRODUCT DATA SHEETS
Base Grille Water Filtration System
Model WF-L200V Capacity 200 Gallons (757 Liters)
Model WF-NL120V Capacity 120 Gallons (454 Liters))
This system has been tested according to ANSI/NSF 42/53 for the reduction of the substances listed below. The concentration of
the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for
water leaving the system, as specified in ANSI/NSF 42/53.
Test Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.5 gpm (1.9 Lpm). Pressure = 60 psig (413.7 kPa). Temp. = 63°F
(17.2°C).
■It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
■Model WF-L200V: The filter monitor system measures the
amount of water that passes through the filter and alerts you
to replace the filter. When 90% of the filter’s rated life is used,
the filter indicator light changes from green to yellow. When
100% of the filter’s rated life is used, the filter indicator light
changes from yellow to red, and it is recommended that you
replace the filter. Use replacement cartridge L200V / NL120V,
part #4396702. 2010 suggested retail price of $32.99 U.S.A./
$49.99 Canada. Prices are subject to change without notice.
Model WF-NL120V: Change the water filter cartridge every 6-
9 months. Use replacement cartridge L200V / NL120V, part
#4396702. 2010 suggested retail price of $32.99 U.S.A./
$49.99 Canada. Prices are subject to change without notice.
■The product is for cold water use only.
■Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
the system.
■Refer to the front cover or “Accessories” section for the
Manufacturer’s name, address and telephone number.
■Refer to the “Warranty” section for the Manufacturer’s limited
warranty.
Application Guidelines/Water Supply Parameters
Substance Reduction
Aesthetic Effects NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % Reduction Average % Reduction
Chlorine Taste/Odor
Particulate Class III*≥50%
≥85% 1.9 mg/L 49,333/mL 2.0 mg/L ± 10% At least 10,000 particles/mL 0.07 mg/L 640 mg/L** 0.06 mg/L 312 mg/L >75.0% 98.7% >75.0% 99%
Contaminant
Reduction NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % Reduction Average % Reduction
Lead: @ pH 6.5
Lead: @ pH 8.5 0.01mg/L 0.01mg/L 0.14 mg/L*** 0.15 mg/L*** 0.15 mg/L ± 10% 0.15 mg/L ± 10% 0.0014 mg/L 0.0069 mg/L 0.0011 mg/L 0.0042 mg/L 99.0% 95.4% 99.21% 97.08%
Mercury: @ pH 6.5
Mercury: @ pH 8.5 0.002 mg/L 0.002 mg/L 0.0059 mg/L 0.0054 mg/L 0.006 mg/L ± 10% 0.006 mg/L ± 10% 0.0009 mg/L 0.0007 mg/L 0.0004 mg/L 0.00043 mg/L 84.74% 87.03% 92.47% 91.93%
Benzene 0.0050 mg/L 0.0157 mg/L 0.015 ± 10% 0.002 mg/L 0.00083 mg/L 87.26% 94.71%
p-dichlorobenzene 0.075 mg/L 0.210 mg/L 0.225 ± 10% 0.0005 mg/L 0.0005 mg/L 99.76% 99.76%
Tested and certified by NSF International against ANSI/NSF Standard
42 for the reduction of Chlorine, Taste and Odor, Particulate Class lll*;
and against ANSI/NSF Standard 53 for the reduction of Lead,
Mercury, Benzene, and p-dichlorobenzene.
Water Supply
Water Pressure
Water Temperature
Service Flow Rate
City or Well
30 - 120 psi (207 - 827 kPa)
33° - 100°F (0.6° - 37.8° C)
0.5 GPM (1.89 L/min.) @ 60 psi.
*
**
***
Class III particle size: >5 to <15 um
Test requirement is at least 10,000 particles/mL of AC Fine Test Dust.
These contaminants are not necessarily in your water supply. Performance may vary based on local water conditions.
® NSF is a registered trademark of NSF International.

17
JENN-AIR®REFRIGERATOR WARRANTY
LIMITED WARRANTY
For one year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or
furnished with the product, Jenn-Air brand of Whirlpool Corporation or Whirlpool Canada LP (hereafter “Jenn-Air”) will pay for factory
specified parts and repair labor to correct defects in materials or workmanship that existed when this major appliance was purchased.
Service must be provided by a Jenn-Air designated service company. YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. This limited warranty is valid only in the United States or Canada
and applies only when the major appliance is used in the country in which it was purchased. Proof of original purchase date is required to
obtain service under this limited warranty.
On models with a water filter: 30 day limited warranty on water filter. For 30 days from the date of purchase, when this filter is operated
and maintained according to instructions attached to or furnished with the product, Jenn-Air will pay for a replacement water filter to
correct defects in materials and workmanship.
SECOND THROUGH FIFTH YEAR LIMITED WARRANTY ON CAVITY LINER AND SEALED REFRIGERATION SYSTEM
In the second through fifth years from the date of purchase, when this major appliance is operated and maintained according to
instructions attached to or furnished with the product, Jenn-Air will pay for replacement or repair of the refrigerator/freezer cavity liner
(including labor costs) if the part cracks due to defective materials or workmanship. Also, in the second through fifth year from the date of
purchase, when this major appliance is operated and maintained according to instructions attached to or furnished with the product,
Jenn-Air will pay for factory specified parts and repair labor for the following components to correct defects in materials or workmanship
in the sealed refrigeration system that existed when this major appliance was purchased: compressor, evaporator, condenser, dryer, and
connecting tubing.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is used
in a manner that is inconsistent to published user or operator instructions and/or installation instructions.
2. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or
repair house fuses, or to correct house wiring or plumbing.
3. Service calls to repair or replace appliance light bulbs, air filters or water filters. Consumable parts are excluded from warranty
coverage.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in
accordance with electrical or plumbing codes, or use of products not approved by Jenn-Air.
5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage
results from defects in materials or workmanship and is reported to Jenn-Air within 30 days from the date of purchase.
6. Any food or medicine loss due to refrigerator or freezer product failures.
7. Pickup and delivery. This major appliance is intended to be repaired in your home.
8. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
9. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an
authorized Jenn-Air servicer is not available.
10. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance with
Jenn-Air's published installation instructions.
11. Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered or cannot
be easily determined.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do
not allow limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply to you. This
warranty gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
JENN-AIR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the
exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty
gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.
If outside the 50 United States and Canada, contact your authorized Jenn-Air dealer to determine if another warranty applies.
If you think you need repair service, first see the “Troubleshooting” section of the Use & Care Guide. If you are unable to resolve the
problem after checking “Troubleshooting,” additional help can be found by checking the “Assistance or Service” section or by calling
Jenn-Air. In the U.S.A., call 1-800-536-6247. In Canada, call 1-800-807-6777.6/09
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need it.
You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label located on the product.
Dealer name____________________________________________________
Address ________________________________________________________
Phone number__________________________________________________
Model number __________________________________________________
Serial number __________________________________________________
Purchase date __________________________________________________

18
SEGURIDAD DE LOS CAJONES REFRIGERADOS
Cómo deshacerse adecuadamente de
su aparato refrigerado viejo
IMPORTANTE: El atrapamiento y asfixia de niños no es un
problema del pasado. Un aparato refrigerado tirado y
abandonado es un peligro, aún si va a quedar ahí “por unos
pocos días”. Si Ud. está por deshacerse de su aparato refrigerado
viejo, por favor siga las instrucciones que se dan a continuación
para prevenir accidentes.
Antes de descartar su aparato refrigerado viejo:
Saque la puerta o el(los) cajón(cajones).
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesión grave.
Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que
puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre
todos los mensajes de seguridad.
ADVERTENCIA
PELIGRO
Este es el símbolo de advertencia de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a
usted y a los demás.
Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra
“PELIGRO” o “ADVERTENCIA”. Estas palabras significan:
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
ADVERTENCIA:
Para reducir el riesgo de incendio, choque eléctrico, o lesiones personales al usar su(s) cajón(cajones)
GUARDE ESTAS INSTRUCCIONES
■ Conecte a un contacto de pared de conexión a tierra de
3 terminales.
■ No quite la terminal de conexión a tierra.
■ No use un adaptador.
■ No use un cable eléctrico de extensión.
■ Desconecte el suministro de energía antes de darle servicio.
■ Vuelva a colocar todos los componentes y paneles antes de
hacerlo funcionar.
■ Remueva la puerta o el(los) cajón(cajones) de su aparato
refrigerado viejo.
■ Use un limpiador no inflamable.
■ Mantenga los materiales y vapores inflamables, tales como
gasolina, alejados del(de los) cajón(cajones) refrigerado(s).
■ Use dos o más personas para mover e instalar el(los)
cajón(cajones) refrigerado(s).
refrigerado(s) siga estas precauciones básicas:
ADVERTENCIA
Peligro de Asfixia
Remueva la puerta o el(los) cajón(cajones) de su
aparato refrigerado viejo.
No seguir esta instrucción puede ocasionar la muerte
o daño al cerebro.

19
ESPECIFICACIONES DE DISEÑO
Modelos de cajón de 24"
Cajón refrigerado doble
Dos cajones refrigerados proveen opciones adicionales de almacenamiento en la cocina u otras áreas del hogar.
Serie Euro
JUD248R*R* Recubierto - Se necesitan paneles y manijas a la medida JUD248R*C*
Cajones refrigerados/congeladores (con fábrica de hielo y filtro de agua)
El cajón refrigerado superior y el cajón congelador inferior proveen opciones adicionales de almacenamiento en la cocina u otras
áreas del hogar. La fábrica de hielo, instalada de fábrica en el cajón inferior, asegura un suministro constante de hielo disponible en
todo momento.
Serie Euro
JUD248C*R* Recubierto - Se necesitan paneles y manijas a la medida JUD248C*C*
Cajones congeladores dobles (con fábrica de hielo y filtro de agua)
Dos cajones congeladores proveen opciones adicionales de almacenamiento en la cocina u otras áreas del hogar. La fábrica de hielo,
instalada de fábrica en el cajón inferior, asegura un suministro constante de hielo disponible en todo momento.
Serie Euro
JUD248F*R* Recubierto - Se necesitan paneles y manijas a la medida JUD248F*C*

20
REQUISITOS DE INSTALACIÓN
Piezas y herramientas
HERRAMIENTAS NECESARIAS:
Reúna las herramientas y piezas necesarias antes de comenzar la
instalación.
Lea y siga las instrucciones provistas con cualquiera de las
herramientas enlistadas aquí.
Herramientas adicionales necesarias
(Estilo 2 - Recubierto únicamente):
PIEZAS NECESARIAS (Estilo 2 - Recubierto únicamente):
PIEZAS SUMINISTRADAS:
Requisitos de ubicación
NOTAS:
■Para que los cajones refrigerados estén alineados con el
frente de los armarios de la base, quite los zócalos o molduras
de la parte posterior de la abertura. Vea “Medidas del
producto” y “Medidas de la abertura (ambos estilos)” más
adelante en esta sección.
■No se recomienda instalar los cajones refrigerados cerca de
un horno, radiador u otra fuente de calor.
■No instale en un lugar donde la temperatura puede ser menor
de 55°F (13°C).
Medidas de la abertura (ambos estilos)
■Las medidas de altura indicadas consideran las patas
niveladoras extendidas a una altura mínima de ¹⁄₄" (6,35 mm)
por debajo de los cajones refrigerados.
NOTA: Si las patas niveladoras están totalmente extendidas
1" (25 mm) por debajo de los cajones refrigerados, agregue
¾" (19,05 mm) a las medidas de altura. Vea “Medidas del
producto”.
■Si el piso de la abertura no está nivelado con el piso de la
cocina, ponga calzas en la abertura para que quede nivelado
con el piso de la cocina.
Requisitos eléctricos
Antes de mover los cajones refrigerados a su ubicación final, es
importante asegurarse que tiene la conexión eléctrica adecuada.
Método de conexión a tierra recomendado
Se requiere una fuente de energía eléctrica de 115 Voltios, 60 Hz.,
CA solamente y con fusibles de 15 ó 20 amperios, conectada a
tierra. Se recomienda que use un circuito separado sólo para sus
cajones refrigerados. Use un tomacorriente que no se pueda
apagar con un interruptor. No use un cable eléctrico de extensión.
■Taladro inalámbrico
■Broca de ¹⁄₈"
■Cinta para medir
■Nivel
■Destornillador Phillips
■Tijeras
■Lápiz
■Punta de trazar
■Paneles de los cajones recubiertos a la medida - Vea
“Paneles de los cajones recubiertos a la medida”.
■Artículos de ferretería
■Ganchos (8)
■Placas del revestimiento (4)
■Tornillos (16)
ADVERTENCIA
Peligro de Explosión
Mantenga los materiales y vapores inflamables,
tales como gasolina, alejados del(de los)
cajón(cajones) refrigerado(s).
No seguir esta instrucción puede ocasionar la muerte,
explosión, o incendio.
Dimensiones fundamentales:
A. Abertura de uso general de 14¾" (37,5 cm)
B. Ancho mínimo de la abertura de 24" (60,96 cm)
¹⁄₂"
(1,3 cm)
14³⁄₄"
(37,5 cm)
24"
(60,96 cm)
min.
24" (60,96 cm) min.
34³⁄₈" (87,3 cm) min.
35" (88,9 cm) max.
A
B
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
