Jenn-Air JF36NXFXDE User manual

W11311783A
Table of Contents/Table des matières/Índice...................................................................................2
INSTALLATION GUIDE
For questions about features, operation/performance, parts, accessories, or service,
call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.ca.
Get the app, connect instructions, terms of use, and privacy policy at www.jennair.com/connect.
GUIDE D’INSTALLATION
Pour des questions à propos des caractéristiques, du fonctionnement/rendement, des pièces, accessoires ou service,
composer le 1800JENNAIR (1800536-6247) ou visiter le www.jennair.com.
Au Canada, composer le 1800JENNAIR (1800536-6247) ou visiter le www.jennair.ca.
Obtenez l’application et les instructions de connexion, les conditions d’utilisation et la politique
de condentialité au www.jennair.com/connect.
GUÍA PARA LA INSTALACIÓN
Si tiene preguntas respecto a las características, funcionamiento/rendimiento, piezas, accesorios o servicio,
llame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio web www.jennair.com.
En Canadá, llame al 1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio web en www.jennair.ca.
Obtenga la aplicación, las instrucciones de conexión, los términos de uso y la política de privacidad en www.jennair.com/connect.
JENNAIR®BOTTOM MOUNT
BUILT-IN REFRIGERATOR
RÉFRIGÉRATEUR ENCASTRÉ AVEC
CONGÉLATEUR EN BAS JENNAIR®
REFRIGERADOR EMPOTRADO DE MONTAJE
ENLA PARTE INFERIOR JENNAIR®

REFRIGERATOR SAFETY..............................................................3
36" SINGLE-DOOR MODELS........................................................4
Accessories..................................................................................4
36" FRENCH DOOR MODELS ......................................................5
Accessories..................................................................................5
42" FRENCH DOOR MODELS ......................................................6
Accessories..................................................................................6
INSTALLATION REQUIREMENTS.................................................7
Tools and Parts.............................................................................7
Location Requirements................................................................8
Electrical Requirements ...............................................................9
Water Supply Requirements ......................................................10
Product Dimensions...................................................................10
Door Swing Dimensions.............................................................12
Cabinet and Panel Installation Options .....................................12
Fully Integrated Grille Installation Requirements.......................13
Standard Integrated Grille Installation Requirements................14
Stainless Steel Panel Kit Installation Requirements..................14
Custom Wood Overlay Panel Requirements.............................15
Custom Wood Overlay Panel Dimensions.................................15
INSTALLATION INSTRUCTIONS.................................................17
Unpack the Refrigerator.............................................................17
Move the Refrigerator into House..............................................17
Install Anti-Tip Boards................................................................17
Secondary Anti-Tip Board .........................................................18
Connect the Water Supply.........................................................19
Plug in Refrigerator ....................................................................20
Install Side Trims ........................................................................21
Move Refrigerator to Final Location ..........................................21
Level and Align Refrigerator.......................................................22
Install Refrigerator and Panels...................................................22
Install Base Grille........................................................................27
Complete Installation .................................................................28
TABLE OF CONTENTS
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR...............................................29
MODÈLES DE PORTE SIMPLE DE 36"......................................30
Accessoires................................................................................30
MODÈLES DE PORTE À DOUBLE BATTANT DE 36" ...............31
Accessoires................................................................................31
MODÈLES DE PORTE À DOUBLE BATTANT DE 42" ...............32
Accessoires................................................................................32
EXIGENCES D’INSTALLATION ...................................................33
Outils et pièces...........................................................................33
Exigences d’emplacement.........................................................34
Spécications électriques..........................................................35
Spécications de l’alimentation en eau.....................................36
Dimensions du produit...............................................................36
Dimensions pour l’ouverture des portes....................................38
Options d’installation de l’armoire etdupanneau.....................38
Exigences d’installation d’une grille entièrement intégrée ........39
Exigences d’installation d’une grille intégrée standard .............40
Exigences d’installation de l’ensemble
depanneaux en acier inoxydable..............................................40
Exigences relatives aux panneaux
de bois personnalisés Overlay...................................................41
Dimensions des panneaux de bois personnalisés Overlay.......41
INSTRUCTIONS D’INSTALLATION.............................................43
Déballage du réfrigérateur..........................................................43
Déplacement du réfrigérateur dansledomicile.........................43
Installation de planches antibasculement .................................43
Planche antibasculement secondaire........................................44
Raccordement à la canalisation d’eau ......................................45
Brancher le réfrigérateur ............................................................46
Installation des garnitures latérales ...........................................47
Déplacement du réfrigérateur àsonemplacement dénitif......47
Réglage de l’aplomb et alignement duréfrigérateur.................48
Installation du réfrigérateur etdespanneaux ............................48
Installation de la grille de la base...............................................54
Terminer l’installation..................................................................54
SEGURIDAD DEL REFRIGERADOR...........................................55
MODELOS DE PUERTA SIMPLE CON CONGELADOR
ENLAPARTE INFERIOR DE 36" (91,4 CM) ...............................56
Accesorios..................................................................................56
MODELOS DE DOS PUERTAS CON CONGELADOR
ENLAPARTE INFERIOR, DE 36" (91,4 CM) ..............................57
Accesorios..................................................................................57
MODELOS DE DOS PUERTAS CON CONGELADOR
ENLAPARTE INFERIOR, DE 42" (106,7CM) ............................58
Accesorios..................................................................................58
REQUISITOS DE INSTALACIÓN.................................................59
Herramientas y piezas................................................................59
Requisitos de ubicación.............................................................60
Requisitos eléctricos..................................................................61
Requisitos del suministro de agua.............................................62
Dimensiones del producto.........................................................62
Medidas de oscilación de las puertas .......................................64
Opciones para la instalación del armario ylos paneles............64
Requisitos para la instalación de rejilla
completamente incorporada......................................................65
Requisitos para la instalación estándar derejilla incorporada..66
Requisitos de instalación del juego depaneles
de acero inoxidable....................................................................66
Requisitos de los paneles de madera recubiertos a la medida ..67
Dimensiones de los paneles de madera recubiertos
a la medida.................................................................................67
INSTRUCCIONES DEINSTALACIÓN.........................................69
Desembale el refrigerador..........................................................69
Cómo hacer entrar el refrigerador enlacasa............................69
Cómo instalar los tableros anti-vuelco ......................................69
Cómo instalar un tablero anti-vuelcosecundario......................70
Conexión del suministro de agua ..............................................71
Cómo enchufar el refrigerador...................................................72
Instalación de las molduras laterales.........................................73
Cómo mover el refrigerador asuubicaciónnal.......................73
Nivelación y alineamiento del refrigerador.................................74
Instalación del refrigerador y los paneles ..................................74
Instalación de la rejilla de la base ..............................................80
Completar la instalación ............................................................80
ÍNDICE

3
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

4
36" SINGLE-DOOR MODELS
Custom-Made Panel Design
Features custom-made panels and custom hardware provided by
the cabinetmaker for a seamless appearance designed to blend
with existing kitchen cabinetry.
Base Model Numbers: JB36NXFXLE, JB36NXFXRE
Euro-Style Stainless Design
Features stainless steel wrapped doors and new Euro-style
handles designed to compliment the JennAir®Euro kitchen suite
or enhance any kitchen decor.
Base Model Numbers: JB36NXFXLE, JB36NXFXRE
Kit Model Number: JPK36BNXESS
Pro-Style®Stainless Design
Features stainless steel wrapped doors and Pro-Style®handles
with diamond-etched grip.
Base Model Numbers: JB36NXFXLE, JB36NXFXRE
Kit Model Number: JPK36BNXEPS
Accessories
All factory parts are available through your JennAir dealer or by
calling JennAir at 1-800-JENNAIR (1-800-536-6247). In Canada,
call 1-800-JENNAIR (1-800-536-6247).
Door Handle Kits
For custom wood overlay panels only, handle kits can be ordered.
Follow the kit instructions for installation.
IMPORTANT: These handle kits are not intended for use with
stainless steel door panel kits.
Pro-Style®Stainless Steel—BM—W10250641
Euro-Style Stainless Steel—BM—W10250638
Armoire-Style Door Panel Kit
Refer to the installation instructions that come with the Armoire
kit, for custom wood overlay panel dimensions and installation
details.
36" Model (Black)—W10663562

5
36" FRENCH DOOR MODELS
Custom-Made Panel Design
Features custom-made panels and custom hardware provided by
the cabinetmaker for a seamless appearance designed to blend
with existing kitchen cabinetry.
Base Model Numbers: JF36NXFXDE
Euro-Style Stainless Design
Features stainless steel wrapped doors and new Euro-style
handles designed to compliment the JennAir®Euro kitchen suite
or enhance any kitchen decor.
Base Model Numbers: JF36NXFXDE
Kit Model Number: JPK36FNXESS
Pro-Style®Stainless Design
Features stainless steel wrapped doors and Pro-Style®handles
with diamond-etched grip.
Base Model Numbers: JF36NXFXDE
Kit Model Number: JPK36FNXEPS
Accessories
All factory parts are available through your JennAir dealer or by
calling JennAir at 1-800-JENNAIR (1-800-536-6247). In Canada,
call 1-800-JENNAIR (1-800-536-6247).
Door Handle Kits
For custom wood overlay panels only, handle kits can be ordered.
Follow the kit instructions for installation.
IMPORTANT: These handle kits are not intended for use with
stainless steel door panel kits.
Pro-Style®Stainless Steel FDBM—W10745429
Euro-Style Stainless Steel FDBM—W10745430
Armoire-Style Door Panel Kit
Follow the kit instructions for installation.
36" Model (Black)—W10663562

6
42" FRENCH DOOR MODELS
Custom-Made Panel Design
Features custom-made panels and custom hardware provided by
the cabinetmaker for a seamless appearance designed to blend
with existing kitchen cabinetry.
Base Model Numbers: JF42NXFXDE
Euro-Style Stainless Design
Features stainless steel wrapped doors and new Euro-style
handles designed to compliment the JennAir®Euro kitchen suite
or enhance any kitchen decor.
Base Model Numbers: JF42NXFXDE
Kit Model Number: JPK42FNXESS
Pro-Style®Stainless Design
Features stainless steel wrapped doors and Pro-Style®handles
with diamond-etched grip.
Base Model Numbers: JF36NXFXDE
Kit Model Number: JPK36FNXEPS
Accessories
All factory parts are available through your JennAir dealer or by
calling JennAir at 1-800-JENNAIR (1-800-536-6247). In Canada,
call 1-800-JENNAIR (1-800-536-6247).
Door Handle Kits
For custom wood overlay panels only, handle kits can be ordered.
Follow the kit instructions for installation.
IMPORTANT: These handle kits are not intended for use with
stainless steel door panel kits.
Pro-Style®Stainless Steel FDBM—W10250642
Euro-Style Stainless Steel FDBM—W10250639
Armoire-Style Door Panel Kit
Follow the kit instructions for installation.
42" Model (Black)—W10663564

7
INSTALLATION REQUIREMENTS
Tools and Parts
IMPORTANT:
■Installer: Leave Installation Instructions with the homeowner.
■Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
Tools Needed:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
■Cordless drill ■3/8" and 1/2" open-end
wrenches
■Drill bits ■5/32" and 3/16" hex key
■Adjustable wrenches (2) ■1/4" and 5/16" socket
drivers
■Phillips screwdriver ■Tape measure
■Small level ■Utility knife
■3/32" hex key
(Panel Kits Only)
■Tape (painters)
■11/32" Nut Driver ■Appliance dolly
Parts Needed:
■#8 x 3" (7.6 cm) wood screws (longer screws may
be needed) (6)
■2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood board(s) (2)
■Custom wood overlay panels - consult a qualied
cabinetmaker or carpenter to make the custom wood panels.
See “Custom Wood Overlay Panels” for more information
OR
Panel kit—See “36" Models or 42" French Door Models” for
panel kit information.
■Flexible, codes-approved water supply tubing, a ferrule, a
union and a 1/4" (6.35 mm) compression tting.
Parts Provided
Slotted Hex-head Screw
W10141645 (21)
Hex-head Pointed Screw
W10141189 (8)
Hex-head Blunt Screw
W10142233 (4)
Shoulder Washer (use with
hex-head pointed screw)
W10471946 (4)
Phillips-head Flat Screw
8281252 (28) Round-head Screw 1163283 (24)
Door Adjustment Pin
(preinstalled)
W10234194 (2) Door Stop Pin W10234202 (2)
Drawer Panel Bracket
W10606815 (2)
Standard Integrated Grille
Bracket
W10182743—Left (1)
W10182741—Right (1)
Fully Integrated Grille Bracket
W10260890—Left (1)
W10260891—Right (1) Filler Board “L” Bracket W10234199 (2)
Panel Top Bracket
W10667450 (2)
Top Grille Lower Trim
W10634858—36" BM (1)
W10606812—42" BM, SxS (1)
RC Hinge Cover Trim
W10648975 - 36" BM (Right)
W10564251 - 36" FDBM Right)
W10606804 - 42" FDBM (Right)
FC Hinge Cover Trim
W10611107 - 36" BM (Left)
W10582015 - 36" FDBM (Left)
W10606808 - 42" FDBM (Left)
Panel Templates
W10222281 - SxS
W10488115 - 36" BM
W10704869 - 36" FDBM
W10488118 - 42" FDBM
W10489178 - Grille
Handle Side Door Trim
W10611106 - BM (Left)
W10648977 - BM (Right)
W10606802 - FDBM (Right)
W10606806 - FDBM (Left)
Installation Block
W10234156
Grille - Bottom / Skirt - Grille
W10189198 / W10188549 -
42" BM
W10189196 /W10188547 -
36" BM

8
Location Requirements
IMPORTANT: This refrigerator is designed for indoor, household
use only.
This appliance is intended to be used in household and similar
applications such as:
■Staff kitchen areas in shops, ofces and other working
environments.
■Farm houses and by clients in hotels, motels and other
residential type environments.
■Bed and breakfast type environments.
■Catering and similar non-retail applications.
■Observe all governing codes and ordinances.
■Floor must support the refrigerator weight, more than 600 lbs
(272 kg), door panels and contents of the refrigerator. Flooring
under refrigerator must be at same level as the room. Face of
cabinetry must be plumb.
■Ceiling height must allow for side tipping radius.
See “Tipping Radius.”
■Location should permit door to open fully.
See “Door Swing Dimensions”.
■Location must permit top grille removal.
See “Opening Dimensions”.
NOTE: The refrigerator is intended for use in a location where
the temperature ranges from a minimum of 55°F (13°C) to a
maximum of 110°F (43°C). The preferred room temperature
range for optimum performance, which reduces electricity
usage and provides superior cooling, is between 60°F (15°C)
and 90°F (32°C). It is recommended that you do not install
the refrigerator near a heat source, such as an oven or
radiator.
Opening Dimensions
IMPORTANT:
■The width of the opening (Width A), from side to side, must
be as specied for your model, for at least 2" (5.08 cm) back
from the face of the cabinet.
NOTE: If your opening does not meet this requirement, you
will need to make modications.
■A solid soft or wall cabinet must be installed 84" (213.4 cm)
above the oor. If the solid soft is higher than 84" (213.4 cm)
or one is not available, then the refrigerator must be braced.
If anti-tip boards are needed, they must be attached to the
rear wall studs so that there is 84" (213.4 cm) from the bottom
of the anti-tip board to the oor. See “Install Anti-Tip Boards”
for more information.
NOTES:
■A clearance of 1/2" (1.3 cm) must be maintained above the
top grille in order for the top grille to be removed.
■Do not remove the foam gasket from the top of the
compressor cover unless removal is necessary to t the
unit under a soft. Removal of the gasket will cause loss in
cooling efciency.
■If installing under a solid soft, after, installation raise the
leveling legs so that the gasket is pressed snugly against
the soft.
■For a fully integrated installation, a minimum of
6" (15.24 cm) of open space above the refrigerator is
required. See “Fully Integrated Installation.” Anti-tip
boards are required. See “Install Anti-Tip Boards” for more
information.
■A grounded 3 prong electrical outlet should be located
within a specied number of inches from the right-hand
side cabinets or end panel. See the chart following the
graphic for the number of inches required for your model.
For more information, see “Electrical Requirements.”
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
B
A
A. Gasket
B. Compressor cover
1/2"
(1.3 cm)

9
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. If the water shutoff valve is not in the cabinets, the
plumbing for the water line can come through the oor. See
“Water Supply Requirements” for more information.
Model Width A
(as shown above) Dimension B (as shown above)
36 36" (91.4 cm) 4" (10.2 cm)
42 42" (106.7 cm) 7¹⁄2" (19.1 cm)
Installation Type Depth C
(as shown above)
Standard Flush (new installation) 25" (63.5 cm) Min.
Retrot Installations 24" (60.9 cm) Min.
Electrical Requirements
Before you move your refrigerator into its nal location, it is
important to make sure you have the proper electrical connection.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similar qualied person. Do
not use a cord that shows cracks or abrasion damage along its
length or at either the plug or connection end.
Recommended Grounding Method
A 115 V, 60 Hz, AC only, 15 or 20 A fused, grounded electrical
supply is required. It is recommended that a separate circuit
serving only your refrigerator be provided. Use an outlet that
cannot be turned off by a switch. Do not use an extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground
Fault Circuit Interrupter) protected outlet, nuisance tripping of the
power supply may occur, resulting in loss of cooling. Food quality
and avor may be affected. If nuisance tripping has occurred, and
if the condition of the food appears poor, dispose of it.
NOTE: Before performing any type of installation or cleaning,
remove the top grille and turn the master power switch to OFF or
disconnect power at the circuit breaker box.
When you are nished, turn ON the master power switch or
reconnect power at the circuit breaker box. Then reset the control
to the desired setting.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
77"
(196 cm)
84" (213.4 cm)
to bottom of solid soffit
A
Width
(see chart following)
B
Dimension
C Depth

10
Water Supply Requirements
IMPORTANT:
■All installations must meet local plumbing If the supply code is
damaged, it must be replaced by the requirements.
■Connect to potable water supply only.
■There is not enough clearance to achieve a ush installation
if a water shutoff valve is located in the wall behind the
refrigerator.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. The water supply line, however, must come up through
the oor in the gray shaded area shown.
■A 1/2" (12.7 mm) hole for plumbing should be drilled on the
oor at least 6" (15.2 cm) from the right- or left-hand side
cabinet and should be no more than 1" (2.54 cm) away from
the back wall. See “Connect the Water Supply.”
■The water supply connection is made at the front of the
refrigerator.
■If additional tubing is needed, use copper tubing and check
for leaks. Install the copper tubing only in areas where the
household temperatures will remain above freezing.
■Do not use a piercing-type or 3/16" (4.76 mm) saddle valve
which reduces water ow and also clogs more easily.
NOTE: Your refrigerator dealer has a kit available with a
1/4" (6.35 mm) saddle-type shutoff valve, a union, and copper
tubing. Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, call a
licensed, qualied plumber.
NOTE: If the water pressure is less than what is required, the ow
of water from the water dispenser could decrease or ice cubes
could be hollow or irregular shaped. If you have questions about
your water pressure, call a licensed, qualied plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of
a reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi
(207 and 827 kPa).
If a reverse osmosis water ltration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■Check to see whether the sediment lter in the reverse
osmosis system is blocked. Replace the lter if necessary.
■Allow the storage tank on the reverse osmosis system to rell
after heavy usage.
■If your refrigerator has a water lter, it may further reduce
the water pressure when used in conjunction with a reverse
osmosis system. Remove the water lter cartridge.
If you have questions about your water pressure, call a licensed,
qualied plumber.
Product Dimensions
IMPORTANT:
■The depth from the front of the top grille to the back of the
refrigerator cabinet is 24" (60.96 cm).
■The power cord is 84" (213 cm) long.
■The water supply connection is made at the bottom front of
the refrigerator.
36" Single Door and 36" French Door Bottom Mount
To p V ie w
F r o n t V i e w
■Width dimensions were measured from hinge edge to clip
edge.
■When leveling legs are fully extended to 1¹⁄4" (3.2 cm) below
rollers, add 1¹⁄4" (3.2 cm) to the height dimension.
Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.
1"
(2.54) cm)
6"
(15.2) cm
353⁄4"
(90.8 cm)
24"
(61.0 cm)
6"
(15.2) cm
6"
(15.2) cm

11
42" French Door Bottom Mount
To p V ie w
F r o n t V i e w
■Width dimensions were measured from hinge edge to hinge
edge.
■When leveling legs are fully extended to 1¹⁄4" (3.2 cm) below
rollers, add 1¹⁄4" (3.2 cm) to the height dimension.
Tipping Radius
Be sure there is adequate ceiling height to stand the refrigerator
upright when it is moved into place.
■The dolly wheel height must be added to the tipping radius
when a dolly is used.
NOTE: Tip on side only.
Side Tipping Radius—36" (91.4 cm) Models
Side Tipping Radius—42" (106.7 cm) Models
A
A. 887⁄8" (225.7 cm)
A
A. 91³⁄8" (232.1 cm)
413⁄4"
(106.1 cm)
413⁄4"
(106.1 cm)
831⁄8"
(211.1 cm)
831⁄8"
(211.1 cm)
353⁄4"
(90.8 cm)
24"
(61.0 cm)

12
Door Swing Dimensions
■The location must permit both doors to open to a minimum of
90°.
■Allow 4¹⁄2" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using custom
wood overlay panels, custom handles or extended handles.
36" (91.4 cm) Single Door Models
36" (91.4 cm) and 42" (106.6 cm) French Door Models
Model A B C D
36 58³⁄4"
(149.2 cm) 565⁄8" (143.8 cm) 565⁄8" (143.8 cm) 58³⁄4" (149.2 cm)
36 FD 41"
(104 cm) 39³⁄4"
(101 cm) 39³⁄4" (101 cm) 41" (104 cm)
42 FD 44"
(111.8 cm) 42³⁄4"
(108.6 cm) 42³⁄4" (108.6 cm) 44" (111.8 cm)
Cabinet and Panel Installation Options
NOTE: Graphics shown below illustrate installation conguration
options given the specied cabinet depths. All possible
congurations are not shown.
Cabinet Depth—25" (63.5 cm)
Framed Cabinetry
Top View
Inset
Top View
Frameless Cabinetry
Top View
90º
B
A
110º
110˚
90˚
110˚
90˚
BA C
D
E
D
C
F
A B
A. Refrigerator door
B. Door panel
C. Side trim
D. Adjacent cabinet
E. Flush return ller
F. 25" (63.5 cm)
E
D
C
F
A B
A. Refrigerator door
B. Door panel
C. Side trim
D. Adjacent cabinet
E. Flush return ller
F. 25" (63.5 cm)
D
C
A B
E
A. Refrigerator door
B. Door panel
C. Side trim
D. Adjacent cabinet
E. 25" (63.5 cm)

13
Cabinet Depth—24" (60.9 cm)
NOTE: A ush installation is not possible with a 24" (60.9 cm)
deep opening.
Framed Cabinetry
Top View
Frameless Cabinetry
Top View
Fully Integrated Grille
Installation Requirements
The refrigerator can be installed fully integrated if the adjacent
cabinetry meets the airow venting requirements critical to
refrigerator performance. A Fully Integrated Grille installation has
no visible air gap because the grille extends upward to the soft or
upper cabinet.
IMPORTANT:
■A Fully Integrated Grille installation requires a minimum of
6" (15.24 cm) of open space above the refrigerator. This space
must not be blocked in any way, including by softs.
■A Fully Integrated Grille installation can be achieved with either
a 24" (60.9 cm) or 25" (63.5 cm) deep opening.
■A full height grille is used to achieve a Fully Integrated
Grille installation. Use the integrated bracket (provided with
refrigerator) to attach the full height grille.
NOTE: A top grille ller is not required with a full height grille.
Integrated Grille Bracket
Fully Integrated Grille Installation—Side View
*C and D are one piece in the Full-height Door Installation
option.
Fully Integrated Grille Installation Options
Option 1—Open to Ceiling
E
D
C
F
A B
A. Refrigerator door
B. Door panel
C. Side trim
D. Adjacent cabinet
E. Flush return ller
F. 24" (60.9 cm)
D
C
A B
E
A. Refrigerator door
B. Door panel
C. Side trim
D. Adjacent cabinet
E. 24" (60.9 cm)
A
B
C
D
A. False front (optional)
B. Airow
C. Full height grille*
D. Door panel*
6" (15.24 cm)
min.
84"
(213.4 cm)
6" (15.24 cm)
min.
84"
(213.4 cm)

14
Option 2—False Front (cabinet face only)
Standard Integrated Grille
Installation Requirements
IMPORTANT:
■A Standard Integrated Grille installation can be achieved with
either a 24" (60.9 cm) or 25" (63.5 cm) deep opening.
■A standard grille is used to achieve a Standard Integrated
Grille installation. Use the standard grille bracket (provided
with refrigerator) to attach the standard grille.
■The grille panel height, shown in the “Standard Integrated
Grille Installation—Side View” graphic, allows for an air gap
critical to refrigerator performance.
Standard Grille Bracket
Standard Integrated Grille Installation—Side View
Standard Integrated Grille Installation—Full Product View
Stainless Steel Panel Kit
Installation Requirements
See the “36" Single Door Models” or the “36" or 42" French Door
Models” section to see the panel kit options available for your
model.
IMPORTANT:
■A panel kit installation can be achieved with either a
24" (60.9 cm) or 25" (63.5 cm) deep opening.
■Refer to the instructions provided with the Stainless Steel Door
Panel Kit to install the door panels and standard grille.
■The grille panel height, shown in the “Panel Kit Installation—
Side View” graphic, allows for an air gap critical to refrigerator
performance.
B
C
D
E
A
A. Top grille ller
B. Soft
C. Airow
D. Grille panel
E. Door panel
C
C. Airow
6" (15.24 cm)
min.
84"
(213.4 cm)

15
Panel Kit Installation—Side View
Panel Kit Installation—Full Product View
Custom Wood Overlay Panel Requirements
Custom wood overlay panels allow you to blend the exterior of
your refrigerator into the overall kitchen decor and to use custom
handles for additional design exibility.
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimension and placement instructions to be sure that the
custom wood overlay panels will t properly.
IMPORTANT:
■For 36" (91.4 cm) Single Door models, the refrigerator door
wood overlay panel cannot exceed 60 lbs (27.2 kg) and the
freezer drawer overlay panel cannot exceed 25 lbs (11.3 kg).
■For 36" French Door models, the refrigerator door wood
overlay panel cannot exceed 38 lbs (17.2 kg) and the freezer
drawer overly panel cannot exceed 25 lbs (11.3 kg).
■For 42" (106.7 cm) French Door models, the refrigerator door
wood overlay panel cannot exceed 38 lbs (17.2 kg) and the
freezer drawer overlay panel cannot exceed 30 lbs (13.6 kg).
■The weight of the top grille wood overlay panel cannot exceed
7 lbs (3.2 kg) for both models.
■The required thickness for all panels is 3/4" (1.91 cm).
■This installation does not require ller or backer panels.
Custom Wood Overlay Panel Dimensions
36" (91.4 cm) Single Door Model—Door and Drawer
Panels
Model 36" Single Door Bottom Mount
Reveal 3/8" 1/8"
A35¹⁄4" (89.54 cm) 35³⁄4" (90.81 cm)
B35¹⁄4" (89.54 cm) 35³⁄4" (90.81 cm)
*For Fully-integrated grille or Standard grille installations.
A
B
C
D
A. Soft
B. Airow
C. Grille panel
D. Door panel
A
B
* 52³⁄8"
(133.03 cm)
20¹⁄2 "
(52.07 cm) FREEZER DRAWER PANEL
Maximum Weight: 25 lbs (11.34 kg)
REFRIGERATOR DOOR PANEL
Maximum Weight: 60 lbs (27.2 kg)
Pinch Hazard
Installation of door panels with less than a ³⁄₈"
(0.95 cm) gap between the door panel and the
adjacent cabinet increases the risk of potential
pinching.
CAUTION
* 52³⁄8"
(133.03 cm)
20¹⁄2"
(52.07 cm)
REFRIGERATOR DOOR PANEL
Maximum Weight: 60 lbs (27.2 kg)
FREEZER DRAWER PANEL
Maximum Weight: 25 lbs (11.34 kg)

16
36" (91.4 cm) and 42" (106.7 cm) French Door
Models—Door and Drawer Panels
Model 36" French Door Bottom Mount
Reveal 3/8" 1/8"
A179⁄16" (44.6 cm) 17¹³⁄16" (45.2 cm)
B35¹⁄4" (89.5 cm) 35³⁄4" (90.8 cm)
Model 42" French Door Bottom Mount
Reveal 3/8" 1/8"
A209⁄16" (52.23 cm) 20¹³⁄16" (52.86 cm)
B41¹⁄4" (104.78 cm) 41³⁄4" (106.05 cm)
*For Fully-integrated grille or Standard grille installations.
Grille Panel
Fully Integrated Grille Installation—Full Height Grille—
Open Soft
Model 36 42
Reveal 3/8" 1/8" 3/8" 1/8"
C 35¹⁄4"
(89.54 cm) 353⁄4" (90.81 cm) 41¹⁄4" (104.78 cm) 413⁄4" (106.05 cm)
Standard Integrated Grille Installation—Open or Closed
Soft
Model 36 42
Reveal 3/8" 1/8" 3/8" 1/8"
D351⁄4"
(89.54 cm) 353⁄4" (90.81 cm) 411⁄4" (104.78 cm) 413⁄4" (106.05 cm)
B351⁄4"
(89.54 cm) 353⁄4" (90.81 cm) 411⁄4" (104.78 cm) 413⁄4" (106.05 cm)
IMPORTANT: The grille panel height, shown in the “Standard
Integrated Grille Installation” graphic, allows for an air gap critical
to refrigerator performance.
Full-Height Door Installation - No Grille - Open Soft
No grille is used in a full-height door installation. Use an Armoire
kit to disguise the cooling system, located on the top of the
refrigerator, which is visible when the doors are opened. See the
instructions, provided with the Armoire kit, for installation details
and custom wood overlay door dimensions.
A
B
* 52³⁄8"
(133.03 cm)
20¹⁄2 "
(52.07 cm) FREEZER DRAWER PANEL
Maximum Weight: 30 lbs (13.6 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
38 lbs (17.2 kg)
A
REFRIGERATOR
DOOR PANEL
Maximum Weight:
38 lbs (17.2 kg)
Pinch Hazard
Installation of door panels with less than a ³⁄₈"
(0.95 cm) gap between the door panel and the
adjacent cabinet increases the risk of potential
pinching.
CAUTION
C
E
D
* 52³⁄8"
(133.03 cm)
65⁄8"
(16.83 cm)
53⁄4"
(14.55 cm)
1" (2.54 cm)
Top Grille Panel
Top Grille Panel
Top Grille Filler
20¹⁄2"
(52.07 cm)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
38 lbs (17.2 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
38 lbs (17.2 kg)
FREEZER DRAWER PANEL
Maximum Weight: 30 lbs (13.6 kg)

17
INSTALLATION
INSTRUCTIONS
Unpack the Refrigerator
IMPORTANT:
■Do not remove the lm covering until the refrigerator is in its
operating location.
■All four leveling legs must contact the oor to support and
stabilize the full weight of the refrigerator.
■Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating location.
1. Remove and save the literature package and hardware kit
located inside the refrigerator. Remove and save the literature,
grille, and trim taped to the outside of the refrigerator.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its nal location.
Move the Refrigerator into House
1. Place an appliance dolly under the left side of the refrigerator
as shown. Place the corner posts from the packing materials
over the trims as appropriate. Slowly tighten the strap.
2. Place pieces of the shipping carton on the oor when rolling
the dolly and refrigerator into the house. Move the refrigerator
close to the built-in opening.
3. Place top of cardboard carton or plywood under refrigerator.
4. Stand the refrigerator up. First, place the left bottom edge of
the refrigerator on the oor, stand the refrigerator upright and
then lower the right-hand side of the refrigerator to the oor.
Install Anti-Tip Boards
IMPORTANT:
■If a solid soft is not available, anti-tip boards must be
installed.
■It is recommended that boards be installed before the
refrigerator is installed.
■Boards must be long enough to fully cover the width of the
compressor cover.
■Place the boards so that the bottom surfaces of the boards are
84" (213 cm) from the oor.
■During installation, raise the refrigerator up until the top of the
refrigerator is making contact with the bottom of the anti-tip
boards. Do not crush the compressor cover when raising the
rear leveling legs.
NOTE: The foam gasket, on top of the compressor cover, will
compress to t under the anti-tip board(s). There is no need to
trim the gasket.
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

18
To Install Anti-tip Boards
1. Mark the stud locations on rear wall.
2. Securely attach two 2" x 4" x 32" (5 cm x 10 cm x 81 cm)
boards to wall studs behind refrigerator. Use six
#8 x 3" (7.6 cm) (or longer) wood screws. The wood screws
must be screwed into the studs at least 1½" (3.8 cm). The
boards must overlap the compressor cover.
Secondary Anti-Tip Board
IMPORTANT:
■For all panel installations, the secondary anti-tip board is
required to be installed prior to door panel installation.
■This anti-tip board is to be secured on the right side of the
cabinet enclosure as per the dimensions shown in illustration.
NOTE: Anti-tip board is required as an addition to the rear
wall anti-tip board (for open to ceiling installation) described in
“Install Anti-Tip Boards” section.
■Secure the secondary anti-tip board so that the bottom
surface of the secondary anti-tip board is 75½" (191.77 cm)
from the oor (right hand side).
■The main anti-tip boards for open to ceiling installation are
secured at 84" (213.36 cm) from the oor (rear side).
■During panel installation, raise the refrigerator up until the top
of the refrigerator is making contact with the bottom of the
secondary anti-tip board.
To Install Secondary Anti-tip Board
1. Mark the stud locations on right hand side cabinet wall.
2. Securely attach one 2" x 4" x 12" (5 cm x 10 cm x 30.4 cm)
board to the cabinet on right hand side cabinet using wood
screws. Use three #8 x 2" (5.08 cm) (or longer) wood screws.
NOTE:
■It is recommended to drive the wood screws from cabinet
wall into the secondary anti-tip board as shown in the
illustration.
■The board must have overlap of 1" (2.54) with the
refrigerator top.
■Leave 4" (10.16 cm) free space at rear as shown in the
illustration.
A
B
CD
A. Two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) boards
B. Attach to studs with six #8 x 3" (7.6 cm) screws.
C. Compressor cover
D. Distance from bottom of anti-tip boards to oor
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Install secondary anti-tip board to ensure product
stability.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A
B
D
C
84"
(213.4 cm)
2" (5 cm)
A. Refrigerator
B. Secondary anti-tip board
C. Kitchen cabinet
D. Wood screws
75½"
(191.77 cm)
4" (10.16 cm)

19
Connect the Water Supply
Read all directions before you begin.
IMPORTANT:
■If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
■Connect to potable water supply only.
Connect to Water Line
Parts Needed
■Minimum 7 ft (2.13 m) exible, codes-approved water supply
line
Style 1—Shutoff Valve Connection
NOTE: If your water line connection does not look like Style 1,
see “Style 2—Copper Line Connection.”
1. Unplug refrigerator or disconnect power supply.
IMPORTANT:
■There is not enough clearance to achieve a ush installation
if a water shutoff valve is located in the wall behind the
refrigerator. The water shutoff should be located in the base
cabinet on either side of the refrigerator.
■Before attaching the tubing to shutoff valve, ush the main
water supply line to remove particles and air in the water line.
Allow enough ow so that water becomes clear. Flushing the
water line may help avoid lters and/or water valves from
becoming clogged.
2. Connect the exible, codes-approved water supply line to the
water shutoff valve by threading the provided nut onto the
shutoff valve as shown.
3. Place the end of the tubing into a bucket, and turn shutoff
valve ON.
4. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
Style 2—Copper Line Connection
NOTE: If there is a water supply line that meets the specications
in “Water Supply Requirements,” proceed to “Connecting to
Refrigerator.” If not, use the following instructions to connect to
the household cold water supply.
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a 1/2" to 1¹⁄4" (1.3 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but drill on the top side of the
pipe, not the bottom. This will help keep water away from
the drill and keep normal sediment from collecting in the
valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the refrigerator to the water pipe. Add
7 ft (2.1 m) to allow for cleaning. Use 1/4" (6.35 mm) O.D.
(outside diameter) copper tubing. Be sure both ends of copper
tubing are cut square.
5. Using a cordless drill, drill a 1/4" (6.35 mm) hole in the cold
water pipe you have selected.
Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.
A
B
C
A. Bulb
B. Nut
C. Water tubing
A
B
C
DEF
G
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut

20
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the 1/4" (6.35 mm)
drilled hole in the water pipe and that the washer is under the
pipe clamp. Tighten the packing nut. Tighten the pipe clamp
screws slowly and evenly so washer makes a watertight seal.
Do not overtighten.
IMPORTANT: Before attaching the tubing to shutoff valve, ush
the main water supply line to remove particles and air in the water
line. Allow enough ow so that water becomes clear. Flushing
the water line may help avoid lters and/or water valves from
becoming clogged.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten the
clamp or the sleeve. This will crush the copper tubing.
8. Turn off the shutoff valve on the water pipe. Coil the copper
tubing.
9. Connect the exible, codes-approved water supply line to the
water shutoff valve by threading the provided nut onto the
shutoff valve.
10. Place the end of the tubing into a bucket, and turn shutoff
valve ON.
11. Check for leaks around the saddle valve. Tighten any nuts or
connections (including connections at the valve) that leak.
Connect to Refrigerator
Parts Supplied
■1/4" to 1/4" (6.35 mm to 6.35 mm) male-to-male coupling
NOTE: The exible, codes-approved water supply line should
connect to the supply valve through the oor.
1. Unplug the refrigerator or disconnect power.
2. Connect the 7 ft (2.13 m) exible codes-approved water tube
to the water supply valve.
3. Flush the main water supply line to remove particles and air in
the water line. Allow enough ow so that water becomes clear.
4. Tape the 7 ft (2.13 m) exible codes-approved water supply
line to the oor, 7" (17.78 cm) from the left side of the
refrigerator. Tape along the length of the tubing, which will
allow it to pass beneath the refrigerator without interference.
NOTE: Allow a minimum of 26" (66.04 cm) of exible codes-
approved water supply line to be loose at the front of the
refrigerator for connecting to the refrigerator.
5. Connect the 7 ft (2.13 m) exible codes-approved water supply
line to the refrigerator.
NOTE: If the main water shutoff valve is behind the refrigerator,
a secondary water shutoff valve may be installed in line with
the water supply line at the front of the product.
6. Turn on the water supply valve and check all connections for
leaks.
Plug in Refrigerator
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similar qualied person. Do
not use a cord that shows cracks or abrasion damage along its
length or at either the plug or connection end.
1. Set control switch at top of cabinet to the OFF position.
2. Plug into a grounded 3 prong outlet.
A
B
CD
EFG
A. Household water line
B. Nut (purchased)
C. Ferrule (purchased)
D. Coupling
E. Bulb
F. Nut
G. Refrigerator water tubing
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
6"
(15.2 cm) 6"
(15.2 cm)
1"
(2.54 cm)
7"
(17.78 cm)
