JENN-AIR®SIDE BY SIDE BUILT-IN REFRIGERATOR
REFRIGERADOR EMPOTRADO
DE DOS PUERTAS JENN-AIR®
RÉFRIGÉRATEUR ENCASTRÉ CÔTE À CÔTE JENN-AIR®
W10151249B
INSTALLATION GUIDE
For questions about features, operation/performance, parts, accessories, or service, call:
1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call: 1-800-807-6777, or visit our website at www.jennair.ca.
MANUAL DE INSTALACIÓN
Si tiene preguntas respecto a las características, funcionamiento, rendimiento, partes, accesorios o servicio técnico, llame al:
1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.com.
En Canadá, llame al: 1-800-807-6777, o visite nuestro sitio de internet: www.jennair.ca.
GUIDE D’INSTALLATION
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site web à www.jennair.ca.
Table of Contents/Índice/Table des matières ......................................................................................2

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY........................................................................... 3
MODELS....................................................................................................... 4
INSTALLATION REQUIREMENTS ............................................................. 6
Tools and Parts......................................................................................... 6
Location Requirements............................................................................. 6
Electrical Requirements............................................................................ 7
Water Supply Requirements..................................................................... 8
Tipping Radius .......................................................................................... 8
Product Dimensions ................................................................................. 9
Door Swing Dimensions .........................................................................10
Overlay Series Door Panel & Cabinetry Clearance ................................11
Overlay Series Custom Panels and Handle Kits ....................................13
Euro-Style and Pro-Style®Custom Side Panels .................................... 15
Overlay Series Custom Side Panels.......................................................15
INSTALLATION INSTRUCTIONS ............................................................. 16
Unpack the Refrigerator ......................................................................... 16
Reduce Tipping Radius .......................................................................... 16
Move the Refrigerator into House .......................................................... 17
Install Anti-Tip Boards ............................................................................ 17
Connect the Water Supply ..................................................................... 18
Plug in Refrigerator................................................................................. 19
Move Refrigerator to Final Location....................................................... 19
Level and Align Refrigerator ................................................................... 19
Install Overlay Series Custom Panels .................................................... 20
Adjust Doors ........................................................................................... 21
Install Side Panel .................................................................................... 22
Install Base Grille .................................................................................... 22
Complete Installation.............................................................................. 23
Water System Preparation ..................................................................... 23
ÍNDICE
SEGURIDAD DEL REFRIGERADOR........................................................24
MODELOS.................................................................................................. 25
REQUISITOS DE INSTALACIÓN..............................................................27
Piezas y herramientas.............................................................................27
Requisitos de ubicación .........................................................................27
Requisitos eléctricos...............................................................................28
Requisitos del suministro de agua ......................................................... 29
Arco de vuelco ........................................................................................29
Medidas del producto............................................................................. 30
Medidas de oscilación de las puertas....................................................31
Espacio para el panel de la puerta y
para los gabinetes de la serie Overlay ...................................................32
Paneles a la medida y juegos de agarraderas de la serie Overlay ........34
Paneles laterales a la medida para las estilo europeo, y Pro-Style®.....36
Paneles laterales a la medida para la serie Overlay...............................36
INSTRUCCIONES DE INSTALACIÓN...................................................... 37
Desempaque el refrigerador................................................................... 37
Cómo reducir el arco de vuelco ............................................................. 38
Cómo hacer entrar el refrigerador en la casa ........................................ 38
Cómo instalar los tableros antivuelco .................................................... 38
Conexión del suministro de agua........................................................... 39
Cómo enchufar el refrigerador ............................................................... 40
Cómo mover el refrigerador a su ubicación final................................... 40
Nivelación y alineamiento del refrigerador............................................. 41
Cómo instalar los paneles a la medida para la serie Overlay ................ 41
Ajuste las puertas ................................................................................... 43
Cómo instalar el panel lateral ................................................................. 44
Cómo instalar la rejilla de la base........................................................... 44
Cómo terminar la instalación.................................................................. 45
Preparación del sistema de agua........................................................... 45
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ...........................................................46
MODÈLES .................................................................................................. 47
EXIGENCES D’INSTALLATION................................................................49
Outillage et pièces ..................................................................................49
Exigences d’emplacement .....................................................................49
Spécifications électriques ......................................................................50
Spécifications de l’alimentation en eau..................................................51
Rayon de basculement...........................................................................51
Dimensions du produit............................................................................ 52
Dimensions pour le pivotement des portes ...........................................53
Série Overlay - Panneau de porte et placard -
dimensions et espace libre.....................................................................54
Panneaux personnalisés et poignées de la série Overlay......................56
Panneaux latéraux personnalisés des Euro-Syle, et Pro-Style®............58
Panneaux latéraux personnalisés de la Série Overlay ...........................58
INSTRUCTIONS D’INSTALLATION ......................................................... 59
Déballage du réfrigérateur...................................................................... 59
Réduction du rayon de basculement ..................................................... 60
Faire entrer le réfrigérateur dans le domicile.......................................... 60
Installation de planches antibasculement.............................................. 60
Raccordement à la canalisation d'eau................................................... 61
Brancher le réfrigérateur......................................................................... 62
Déplacement du réfrigérateur à l'emplacement final............................. 62
Réglage de l'aplomb et alignement du réfrigérateur.............................. 63
Installation des panneaux personnalisés de la Série Overlay................ 63
Ajustement des portes............................................................................ 65
Installation du panneau latéral................................................................ 66
Installation de la grille de la base ........................................................... 66
Achever l’installation............................................................................... 67
Préparation du système d’eau ............................................................... 67

3
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

4
MODELS
Non-Dispensing Refrigerators
Euro-Style Design
Features stainless steel wrapped doors with towel bar handles.
JS42SEFXDB JS48SEFXDB
Pro-Style®Design
Features stainless steel wrapped doors and Pro-Style®handles
with diamond-etched grip.
JS42PPFXDB JS48PPFXDB
Overlay Design
Uses custom-made panels and custom hardware for a seamless
appearance designed to blend with existing kitchen cabinetry.
JS42CXFXDB JS48CXFXDB

5
Dispensing Refrigerators
Euro-Style Design
Features stainless steel wrapped doors with towel bar handles.
JS42SEDUDB JS48SEDUDB
Pro-Style®Design
Features stainless steel wrapped doors and Pro-Style®handles
with diamond-etched grip.
JS42PPDUDB JS48PPDUDB
Overlay Design
Uses custom-made panels and custom hardware for a seamless
appearance designed to blend with existing kitchen cabinetry.
JS42CXDBDB JS42CXDUDB
JS48CXDBDB JS48CXDUDB

6
INSTALLATION REQUIREMENTS
Tools and Parts
IMPORTANT:
■Installer: Leave Installation Instructions with the homeowner.
■Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
PARTS NEEDED:
■Six #8 x 3" (7.6 cm) wood screws (longer screws may be needed)
■One or two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood board(s)
■Overlay Series: Make custom panels, or consult a qualified
cabinetmaker or carpenter to make the panels. See “Overlay
Series Custom Panels” for more information.
Pro-Style®and Euro-Style Series are shipped complete.
■If you are connecting the water line directly to copper tubing
and not to a shutoff valve, you need a ferrule, a union, and a
¹⁄₄" (6.35 mm) compression fitting.
Location Requirements
The refrigerator can be recessed in an opening between cabinets
or installed at the end of a cabinet run using a side panel to
enclose the refrigerator.
IMPORTANT:
■Observe all governing codes and ordinances.
■It is recommended that you do not install the refrigerator near
an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C).
■Floor must support the refrigerator weight, more than 600 lbs
(272 kg), door panels and contents of the refrigerator.
■Ceiling height must allow for side tipping radius. See “Tipping
Radius.”
■Location should permit door to open fully. See “Door Swing
Dimensions.”
■Location must permit top grille removal. See “Opening
Dimensions.”
Opening Dimensions
■To avoid tipping during use, the solid soffit must be within 1"
(2.5 cm) maximum above the refrigerator. If the solid soffit is
higher than 1" (2.5 cm) or one is not available, then the
refrigerator must be braced.
If the anti-tip boards are needed, they must be attached to the
rear wall studs 80" to 90" (203 cm to 229 cm) above the floor.
See “Install Anti-Tip Boards” for more information.
NOTE: A clearance of ¹⁄₂" (1.3 cm) must be maintained above
the top grille in order for the top grille to be removed.
■Cordless drill
■Drill bits
■Two adjustable
wrenches
■Phillips screwdriver
■Small level
■Appliance dolly
■Torx®† T27 screwdriver
■¹¹⁄₃₂" nut driver
■³⁄₈" and ¹⁄₂" open-end wrenches
■⁵⁄₃₂" Allen wrench
■¹⁄₄" and ⁵⁄₁₆" socket drivers
■Tape measure
■Utility knife
†®TORX is a registered trademark of Textron Innovations Inc.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
¹⁄₂"
(1.3 cm)

7
■A grounded 3 prong electrical outlet should be placed within
4" (10.2 cm) of the right side cabinets or end panel. See
“Electrical Requirements” for more information.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. If the water shutoff valve is not in the cabinets, the
plumbing for the water line can come through the floor or the
back wall. See “Water Supply Requirements” for more
information.
NOTE: Flooring under refrigerator must be at same level as
the room. Face of cabinetry must be plumb.
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only, 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground Fault
Circuit Interrupter) protected outlet, nuisance tripping of the
power supply may occur, resulting in loss of cooling. Food quality
and flavor may be affected. If nuisance tripping has occurred, and
if the condition of the food appears poor, dispose of it.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, remove the top grille and turn the master
power switch to OFF or disconnect power at the circuit breaker
box.
When you are finished, turn ON the master power switch or
reconnect power at the circuit breaker box. Then reset the control
to the desired setting.
Model Width A (as shown above)
42
48 41¹⁄₂" (105.4 cm) to 41³⁄₄" (106.1 cm) 47¹⁄₂" (120.7 cm) to 47³⁄₄" (121.3 cm)
80" - 90"
(203-229 cm) 4"
(10.2 cm)
6"
(15.2 cm)
83¹⁄₂" (212.1 cm) min.
84³⁄₄" (215 cm) max.
to bottom of solid soffit
24"
(60.96 cm) min.
1"
(2.54 cm)
77"
(196 cm)
6"
(15.2 cm)
6"
(15.2 cm)
A
Width
(see chart following)
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

8
Water Supply Requirements
■All installations must meet local plumbing code requirements.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. The right-hand side is recommended. The access hole
through the cabinet must be within ¹⁄₂" (12.7 mm) of the rear
wall.
NOTE: If the water shut off valve is in the back wall behind the
refrigerator, it must be at an angle so that the tube is not
kinked when the refrigerator is pushed into its final position.
■If the water shutoff valve is not in the cabinets, the plumbing
for the water line can come through the floor. A ¹⁄₂" (12.7 mm)
hole for plumbing should be drilled at least 6" (15.2 cm) from
the right or left hand side cabinet or panel. On the floor, the
hole should be no more than 1" (2.54 cm) away from the back
wall. See “Connect the Water Supply.”
■If additional tubing is needed, use copper tubing and check
for leaks. Install the copper tubing only in areas where the
household temperatures will remain above freezing.
■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve
which reduces water flow and clogs more easily.
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper
tubing. Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, call a
licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi
(207 and 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter cartridge, it may further
reduce the water pressure when used in conjunction with a
reverse osmosis system. Remove the water filter cartridge.
If you have questions about your water pressure, call a licensed,
qualified plumber.
Tipping Radius
Be sure there is adequate ceiling height to stand the refrigerator
upright when it is moved into place.
■The dolly wheel height must be added to the tipping radius
when a dolly is used.
■If needed, the tipping radius can be reduced. See “Reduce
Tipping Radius.”
Side Tipping Radius
The side tipping radius varies depending upon the width of the
model. Use the chart provided to determine the side tipping
radius.
NOTE: Tip on side only.
24"
(60.96 cm) min.
1"
(2.54 cm) 6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)
Model Tipping Radius A
42
48 93" (236.2 cm) 96" (243.8 cm)
A

9
Product Dimensions
Side View
■The depth from the front of the top grille to the back of the
refrigerator cabinet is 25³⁄₈" (64.5 cm) for Euro and Pro styles.
The Overlay style depth is 25¹⁄₈" (63.8 cm) without custom
panels.
■The power cord is 84" (213 cm) long.
■The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long.
■Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
Euro-Style and Pro-Style®
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Overlay Style
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Top View
Euro-Style and Pro-Style®
25³⁄₈"
(64.5 cm)
84" (213.4 cm)
Power Cord
*83³⁄₈"
(211.8 cm)
*3¹⁄₂" (8.9 cm)
³⁄₈"
(9.53 mm)
Model A B
42 Euro-Style 41" (104.1 cm) 2¹⁄₈" (5.3 cm)
48 Euro-Style 47" (119.4 cm) 2¹⁄₈" (5.3 cm)
42 Pro-Style®41" (104.1 cm) 2¹¹/₁₆" (6.74 cm)
48 Pro-Style®47" (119.4 cm) 2¹¹/₁₆" (6.74 cm)
25¹⁄₈"
(63.8 cm)
84" (213.4 cm)
Power Cord
*83³⁄₈"
(211.8 cm)
*3¹⁄₂" (8.9 cm)
24¹⁄₈"
(61.3 cm)
23¹⁄₂"
(59.7 cm)
23¹¹⁄₁₆"
(60.3 cm)
A
B

10
Overlay Style
Front View
■Width dimensions were measured from trim edge to trim
edge.
■Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Door Swing Dimensions
The location must permit both doors to open to a minimum of 90°.
Allow 4¹⁄₂" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels, custom handles, or extended handles on a Classic model.
To adjust the door swing, see “Adjust Doors.”
42" (106.7 cm) Models
48" (121.9 cm) Models
Model Width A
42 41" (104.1 cm)
48 47" (119.4 cm)
Model Width A (Trim edge to trim edge)
42 42¹⁄₄" (107.3 cm)
48 48¹⁄₄" (122.6 cm)
23¹¹⁄₁₆"
(60.16 cm)
A
*83³⁄₈"
(211.8 cm)
A
(see chart following)
Model A B
Pro-Style®10³/₄" (27.11 cm) 14¹/₄" (36.11 cm)
Euro-Style 10¹/₄" (25.87 cm) 13³/₄" (34.88 cm)
Model A B
Pro-Style®12³/₁₆" (30.84 cm) 16¹/₄" (41.16 cm)
Euro-Style 11⁵/₈" (29.43 cm) 15¹¹/₁₆" (39.75 cm)
130˚
130˚
90˚
90˚
110˚
110˚
47⁷⁄₈"
(121.6 cm
)
41¹⁄₂"
(105.4 cm)
B
37¹⁄₄"
(94.6 cm)
41³⁄₈"
(
105.1 cm)
A
130˚
130˚
90˚
90˚
110˚
110˚
51³⁄₈"
(130.5 cm)
44"
(111.8 cm)
39"
(99.1 cm)
43⁷⁄₈"
(
111.4 cm)
B
A

11
Overlay Series Door Panel & Cabinetry Clearance
The custom door panels and adjacent cabinetry must be designed so that there is sufficient clearance for the doors to swing open. If
the refrigerator is to be installed close to the wall, see “Door Swing 90°” on next page.
When the doors are closed the refrigerator will extend beyond the face of the adjacent cabinetry to some degree.
NOTE: For Overlay Series models, rout the
hinge side of the custom door panels to a
radius that is equal to at least half the
thickness of the panel if a 130˚ door swing is
desired. See “Adjust Doors.”
Spacer Panel
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
1"
11/4"
11/2"
1"
(2.5 cm)
1
(3.2 cm)
1/4"
1
(3.8 cm)
1/2"
1/2"
Refrigerator
Side Trim
Door
Hinge
Backer Panel
Overlay Panel
Door Swing 110˚
Actual Size
Refrigerator to
Cabinetry Clearance
(2.5 cm)
(3.2 cm)
(3.8 cm)
(1.3 cm)
NOTE: Allow ¹⁄₂"
(1.3 cm) clearance
between overlay
panel and cabinetry.
Cabinetry
3/4"
(1.9 cm)

12
Allow a minimum of 4¹⁄₂" (11.4 cm) of space between the side of the refrigerator and a corner wall. More clearance may be needed if
thicker custom panels or custom handles are used. Do not overlook baseboards.
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
3/4"
1"
11/4"
11/2"
1/2"
Refrigerator
Side Trim
Door Backer Panel Overlay Panel
Hinge
Door Swing 90˚
Actual Size
Refrigerator to
Cabinetry Clearance
(1.9 cm)
(2.5 cm)
(3.8 cm)
(1.3 cm)
(3.2 cm)
Spacer Panel
Cabinetry
1/2"
3/4"
1"
(1.3 cm)
(1.9 cm)
(2.5 cm)
90˚ Door
Stop Position

13
Overlay Series Custom Panels and Handle Kits
Custom overlay panels allow you to blend the exterior of your
refrigerator into the overall kitchen décor, and to use custom
handles for additional design flexibility.
The custom panels must have backer panels attached in order to
mount them to the refrigerator. It is most common to work with
three panels, as shown in the following graphic: a decorative
overlay panel, a ¹/₈" (3.18 mm) spacer panel or spacer strips and a
¹/₄" (6.35 mm) backer panel.
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimension and placement instructions to be sure that the
custom overlay panels will fit properly.
IMPORTANT:
■The weight of the refrigerator door overlay panel cannot
exceed 50 lbs (23 kg).
■The weight of the freezer door overlay panel cannot exceed
40 lbs (18.1 kg).
■The weight of the top grille overlay panel cannot exceed
10 lbs (4.5 kg).
To minimize panel weight, you may use 2" (5.08 cm) spacer strips
around the perimeter in place of full-sheet solid spacer panels.
The spacer strips must be set in at least 1" (2.54 cm) from the top,
bottom and sides edges of the backer panel. If you use spacer
strips, it is also recommended that you use two 2" (5.08 cm) strips
horizontally centered for added support.
Decorative Overlay Panel
*Represents placement of dispenser frame.
Overlay Panel Spacer Panel
Backer Panel
5/8" to 3/4"
(15.88 to
19.05 mm) 1/8"
(3.18 mm)
1/4"
(6.35 mm)
1" minimum
(2.54 cm)
Door/Grille Trim
Spacer Panel
Offset Dimension
1/8"
(3.18 mm)
Overlay Panel
Backer Panel
Model A B C
42 17¹/₄" (43.82 cm) 23¹/₄" (59.06 cm) 40³/₄" (103.51 cm)
48 19³/₄" (50.17 cm) 26³/₄" (67.95 cm) 46³/₄" (118.75 cm)
14¹⁄₄"
(36.2 cm)
33⁷⁄₈"
(86.0 cm)
B
AA
Freezer
Door Panel
(Non-Dispenser)
Refrigerator
Door Panel
C
7¹⁄₄"
(18.4 cm)
10⁷⁄₈"
(27.6 cm)
Preferred
Radius
¹⁄₂"
(1.27 cm)
72¹⁄₄"
(183.5 cm)
Freezer
Door Panel
(Dispenser)
Dispenser
cut-out is
centered
left-to-right
*

14
Backer Panels
NOTES:
■Dashed lines represent backer panel placement.
■Illustration shows backer panels placed on decorative
overlays.
Dispenser Frame (dispenser models only)
The dispenser frame attaches to the panel with 4 screws.
The dispenser frame overlaps the dispenser cutout by ⁵⁄₁₆"
(0.78 cm) on each side and ¹⁄₂" (1.27 cm) on the top and bottom.
Model D E F
42 16³/₄" (42.55 cm) 22³/₄" (57.79 cm) 39³/₄" (100.97 cm)
48 19¹/₄" (48.90 cm) 26¹/₄" (66.68 cm) 45³/₄" (116.21 cm)
Bottom Offset
¹⁄₈" (3.2 mm)
Bottom Offset
¹⁄₈" (3.2 mm)
D
DED
F
6³⁄₁₆"
(15.7 cm) Side Offset
¹⁄₂" (12.7 mm)
Top Offset
1⁵⁄₈" (4.13 cm)
Bottom Offset
¹⁄₂" (1.27 cm)
22"
(55.9 cm)
33¹⁄₄"
(84.5 cm)
70¹⁄₂"
(179.1 cm)
70¹⁄₂"
(179.1 cm)
Handle-
Side Offset
¹⁄₄"
(6.4 mm)
A. Decorative panel
B. Refrigerator door
C. Dispenser frame
A.
¹⁄₂ " (1.27 cm) Overlap
A
B
C
A A

15
Euro-Style and Pro-Style®
Custom Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed at the end of a cabinet run. You
may choose an Inset, Flush, or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed panel installation dimensions.
■The side panel should be a minimum of ½" (1.27 cm) thick
to avoid warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ⁷⁄₃₂" (5.6 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ¹⁄₄" (6.35 mm) thick, route the front
edge to allow the side panel to fit into the trim.
Flush Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Attach the support board with a screw or adhesive that is
compatible with aluminum and wood.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Route the front edge of the support board or attach a ¹⁄₄"
(6.35 mm) board to hold the panel in the cabinet side trim.
Overlay Series Custom Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed at the end of a cabinet run. You
may choose an Inset or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed installation dimensions.
■The side panel should be a minimum of ½" (1.27 cm) thick
to avoid warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on rear wall.
Refrigerator
24¹⁄₈"
(61.3 cm)
23¹⁄₂"
(59.7 cm)
23¹¹⁄₁₆"
(60.3 cm)
¹¹⁄₆₄"
(4.5 mm)
¹⁄₄"
(6.35 mm)
³⁄₁₆"
(4.7 mm)
⁷⁄₃₂"
(5.5 mm)
¹³⁄₃₂" (10 mm) ⁵⁄₈"
(15.7 mm)
A
A
A
23¹¹⁄₁₆"
(60.16 cm)
Overlay

16
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ¹⁄₃₂" (0.8 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ³⁄₈" (9.5 mm) thick, route the front
edge to allow the side panel to fit into the trim.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Route the front edge of the support board or attach a ³⁄₈"
(9.5 mm) board to hold the panel in the cabinet side trim.
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
IMPORTANT:
■Do not remove the protective film until the refrigerator is in its
operating position.
■All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
■Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating position.
1. Remove and save the literature package bag taped to the side
of the refrigerator and the parts bag behind the grille. Remove
the four brackets (two on each side) that attach the shipping
base to the refrigerator bottom.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final position.
2. If necessary, reduce the tipping radius. See “Tipping Radius”
for ceiling height requirements or “Reduce Tipping Radius” for
step-by-step instructions. If you do not need to reduce the
tipping radius, proceed to “Move the Refrigerator into House.”
Reduce Tipping Radius
(if required)
Before bringing the refrigerator into the home, be sure there is
adequate ceiling height to stand the refrigerator upright. See
“Tipping Radius” in the “Installation Requirements” section for
more information.
If you do not have adequate ceiling height to stand the refrigerator
upright, the tipping radius can be reduced by removing the top
grille and side trims (see the following chart).
1. Grasp both ends of the top grille.
³⁄₁₆"
(4.5 mm)
³⁄₈"
(9.7 mm)
¹⁄₁₆"
(1.5 mm)
³⁄₃₂"
(2.38 mm)
A
A
Model Reduced Tipping Radius
42 88¹⁄₂" (224.8 cm)
48 89¹⁄₄" (226.7 cm)
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

17
2. Push the top grille straight up; then pull straight out. Lay the
grille on a soft surface.
3. Remove the six screws attaching each cabinet side trim to the
refrigerator and remove the side trims.
Move the Refrigerator into House
1. Place an appliance dolly under the left side of the refrigerator
as shown. Be sure to protect the side trims and handles. Place
the corner posts from the packing materials over the trims and
handles as appropriate. Slowly tighten the strap.
NOTE: Pass the dolly strap under the handles for the
Architect® Series.
2. Place pieces of the shipping carton on the floor when rolling
the dolly and refrigerator into the house. Move the refrigerator
close to the built-in opening.
3. Place top of cardboard carton or plywood under refrigerator.
4. Stand the refrigerator up. First, place the left bottom edge of
the refrigerator on the floor, stand the refrigerator upright and
then lower the right-hand side of the refrigerator to the floor.
5. Do not remove protective film or cover.
6. Reassemble the trim and top grille after the dolly has been
removed from the refrigerator.
Install Anti-Tip Boards
IMPORTANT:
■To avoid tipping during use, the solid soffit must be within 1"
(2.5 cm) maximum above the refrigerator. If the solid soffit is
higher than 1" (2.5 cm) or one is not available, then the
refrigerator must be braced.
■It is recommended that board(s) be installed before the
refrigerator is installed.
■Board(s) must be long enough to fully cover the width of the
compressor cover.
■Locate the board(s) so the bottom surface(s) of the board(s)
is(are) 84" (213 cm) from the floor.
■During installation, raise the refrigerator up so there is ¹⁄₄"
(6.35 mm) maximum between the top of the refrigerator and
the bottom of the anti-tip board(s). Do not crush the
compressor cover when raising the rear leveling legs.
To Install Anti-tip Boards
1. Mark the stud locations on rear wall 80" to 90" (203 cm to
229 cm) above floor.
2. Securely attach one or two 2" x 4" x 32" (5 cm x 10 cm x
81 cm) boards to wall studs behind refrigerator. Use six
#8 x 3" (7.6 cm) (or longer) wood screws. The wood screws
must be screwed into the studs at least 1½" (3.8 cm). The
board(s) must overlap the compressor cover.
A. Top grille
B. Cabinet side trim
B BA
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A. Center board ¹⁄₄ " (6.35 mm) max. above refrigerator
B. Two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) boards
C. Attach to studs with six #8 x 3" (7.6 cm) screws
D. Compressor cover
BA
C
2" (5 cm)
D

18
Connect the Water Supply
Read all directions before you begin.
IMPORTANT: If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
Style 1 - Shutoff Valve Connection
NOTE: If your water line connection does not look like Style 1, see
“Style 2 - Copper Line Connection.”
1. Unplug refrigerator or disconnect power supply.
IMPORTANT: Before attaching the tubing to shutoff valve, flush
the main water supply line to remove particles and air in the water
line. Allow enough flow so that water becomes clear. Flushing the
water line may help avoid filters and/or water valves from
becoming clogged.
2. Remove the shipping tape from the gray, coiled water tubing
on the rear of the refrigerator.
3. Thread the provided nut onto the shutoff valve as shown.
4. Turn shutoff valve ON.
5. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
6. Plug in the refrigerator or reconnect power.
7. Flush the water system. See “Water System Preparation.”
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to completely
fill ice container.
Style 2 - Copper Line Connection
Connecting to Water Line
NOTE: If existing water line meets the “Water System
Requirements,” see “Connecting to Refrigerator.”
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a ½" to 1¹⁄₄" (1.25 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but drill on the top side of the
pipe, not the bottom. This will help keep water away from
the drill and normal sediment from collecting in the valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the lower left rear of refrigerator to the
water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure both
ends of copper tubing are cut square.
5. Using a cordless drill, drill a ¹⁄₄" (6.35 mm) hole in the cold
water pipe you have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" (6.35 mm)
drilled hole in the water pipe and that the washer is under the
pipe clamp. Tighten the packing nut. Tighten the pipe clamp
screws slowly and evenly so washer makes a watertight seal.
Do not overtighten, or you may crush the copper tubing.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten the
clamp or the sleeve. This will crush the copper tubing.
IMPORTANT: Before attaching the tubing to shutoff valve, flush
the main water supply line to remove particles and air in the water
line. Allow enough flow so that water becomes clear. Flushing the
water line may help avoid filters and/or water valves from
becoming clogged.
8. Turn off the shutoff valve on the water pipe. Coil the copper
tubing.
9. Check for leaks around the saddle valve.
Connecting to Refrigerator
1. Unplug the refrigerator or disconnect power.
2. Remove the shipping tape from the gray, coiled water tubing
on the rear of the refrigerator.
3. Remove the short, black plastic tube from the end of the water
line inlet. This tube protects the fitting during shipping only.
4. Measure the distance from the shutoff valve to the opening in
which the refrigerator will be located. Tubing must be
extended from the shutoff valve into the refrigerator opening
following specific guidelines. See “Water Supply
Requirements.”
5. A ¹⁄₄" x ¹⁄₄" (6.35 mm to 6.35 mm) coupling is needed in order
to connect the water tubing to an existing household water
line. Thread the provided nut onto the coupling on the end of
the copper tubing.
A. Bulb
B. Nut
C. Water tubing
A
B
C
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
A. Water tubing
B. Nut
C. Bulb
D. Coupling (purchased)
E. Ferrule (purchased)
F. Nu t (p urchased)
G. Household water line (as
connected in previous section)
A
B
C
DEF
G
A B C D E F G

19
6. Turn shutoff valve ON.
7. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
8. Plug in the refrigerator or reconnect power.
9. Flush the water system. See “Water System Preparation.”
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to completely
fill ice container.
Plug in Refrigerator
1. Set control switch at top of cabinet to the OFF position.
2. Plug into a grounded 3 prong outlet.
Move Refrigerator to Final Location
IMPORTANT: To avoid floor damage, make sure levelers are
raised (not touching floor) and refrigerator is on rollers before
moving.
1. Place top of cardboard carton or plywood under refrigerator.
Remove dolly.
2. Do not remove protective film or cover.
3. Move the refrigerator straight back and evenly into the
opening. Be sure that the refrigerator side trims are not
interfering with the door opening. Also, be sure that the water
tubing is not kinked and the power supply cord is on top of the
refrigerator.
Level and Align Refrigerator
IMPORTANT: All four leveling legs must contact the floor to
support and stabilize the full weight of refrigerator. Rollers are for
moving refrigerator and not for permanent support.
After moving the refrigerator to its final location:
1. Use a ⁵⁄₁₆" socket driver to turn the leveling bolts clockwise to
extend the legs to the floor as shown. The rollers should be off
the floor.
2. Adjust the leveling legs to level and align the refrigerator from
left to right and front to back so that the refrigerator is level
and aligned with the cabinetry. The cabinetry surface must be
plumb for the ideal fit of the refrigerator side trim.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A. Rear leveling bolt
B. Front leveling bolt
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A B
A
B

20
3. Continue adjusting all of the leveling legs to raise the
refrigerator until the top is within at least 1" (2.54 cm) of the
top soffit.
NOTE: If an anti-tip board has been used, adjust the leveling
legs until the top of the refrigerator is within ¹⁄₄" (6.35 mm) of
the bottom of the anti-tip board as shown. Do not crush the
compressor cover.
IMPORTANT: Adjust in small increments to keep from
damaging the cabinet trim and causing problems with the
door alignment or top grille fit. To avoid damage to the cabinet
or leveling legs, do not apply more than 50 inch-pounds
(5.65 Nm) of torque to the leveling bolts. The leveling legs can
be extended to a maximum of 1¹⁄₄" (3.18 cm) below the rollers.
4. For Classic and Overlay models, additional adjustments may
be needed after the custom panels are installed.
Install Overlay Series Custom Panels
IMPORTANT:
■Install the custom handles prior to installing the panels on the
refrigerator. For more information on Jenn-Air custom handle
selection, refer to the Jenn-Air Catalog, visit
www.jennair.com, or call 1-800-JENNAIR
(1-800-536-6247). In Canada, visit www.jennair.ca, or call
1-800-807-6777.
■Create custom door overlay panels according to the
specifications in the “Overlay Series Custom Panels” section.
■Jenn-Air not responsible for the removal or addition of
molding or decorative panels that would not allow access to
the refrigerator for service.
Door Panel Installation
1. Remove all tape and door bracing from the refrigerator and
freezer doors.
2. Open the refrigerator and freezer compartment doors.
3. Remove the handle side and top trims.
4. Slide the custom panels into the bottom and hinge side trims
on the refrigerator compartment and freezer compartment
doors, making sure that the backer panel fits into the hinge
side trims.
5. Reinstall the handle-side and top trims.
6. Remove the protective skin from the screw covers. Slide or
snap the screw covers into the handle trim section.
7. Check refrigerator level and alignment. Adjust if needed.
A. Center board ¹⁄₄ " (6.35 mm) max. above refrigerator
B. Two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) boards
C. Attach to studs with six #8 x 3" (7.6 cm) screws
D. Compressor cover
BA
C
2" (5 cm)
D
¹⁄₄" (6 mm)
max.
A. Trims
A. Panels
A
A
A
A
