Jenn-Air JB36NXFXLW01 User manual

JENN-AIR_BOTTOMMOUNTBUILT-INREFRIGERATOR
REFRIGERADOREMPOTRADOCON
CONGEI_DOR ENLAPARTEINFERIORJENN-AII_
CONGI_LATEURENBASJENN-AIR_
USE& CAREGUIDE
For questions about features, operation/performance, parts, accessories, or service, call:
1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call: 1-800-807-6777, or visit our website at www.jennair.ca.
MANUAL DEUSOYCUIDADO
Si tiene preguntas respecto a las caracteristicas, funcionamiento, rendimiento, partes, accesorios o servicio tecnico, Ilame al:
1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.com.
En CanadA, Ilame al: 1-800-807-6777, o visite nuestro sitio de internet: www.jennair.ca.
GUIDED'UTILISATIONETD'ENTRETIEN
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site web &www.jennair.ca.
Table of Contents/[ndice/Table des matieres ...................................................................................... 2
JENN-AIR°
W10303991A

TABLEOF CONTENTS
REFRIGERATOR SAFETY ........................................................................... 3
Proper Disposal of Your Old Refrigerator ................................................. 3
BEFORE USE ............................................................................................... 4
Water Supply Requirements ..................................................................... 4
Water System Preparation ........................................................................ 4
REFRIGERATOR USE ................................................................................. 5
Power On/Off Switch ................................................................................ 5
Using the Controls .................................................................................... 5
Ice Maker and Storage Bin ....................................................................... 7
Water Filtration System ............................................................................ 8
REFRIGERATOR FEATURES ..................................................................... 9
Refrigerator Shelves ................................................................................. 9
Temperature Controlled Dell Drawer ........................................................ 9
FREEZER FEATURES ............................................................................... 10
Freezer Basket ........................................................................................ 10
DOOR FEATURES ..................................................................................... 10
Utility Compartment ................................................................................ 10
Door Bins ................................................................................................ 10
REFRIGERATOR CARE ............................................................................ 11
Cleaning .................................................................................................. 11
Changing the Light Bulbs ....................................................................... 11
Power Interruptions ................................................................................ 12
Vacation Care ......................................................................................... 12
TROUBLESHOOTING ............................................................................... 12
Refrigerator Operation ............................................................................ 12
Temperature and Moisture ..................................................................... 13
Ice and Water .......................................................................................... 13
ASSISTANCE OR SERVICE ...................................................................... 14
ACCESSORIES .......................................................................................... 14
WATER FILTER CERTIFICATIONS .......................................................... 15
PERFORMANCE DATA SHEETS ............................................................. 16
WARRANTY ............................................................................................... 18
/NDICE
SEGURIDAD DEL REFRIGERADOR ........................................................ 19
C6mo deshacerse adecuadamente de su refrigerador viejo ................. 19
ANTES DE USAR ....................................................................................... 20
Requisitos del suministro de agua ......................................................... 20
Preparaci6n del sistema de agua ........................................................... 20
USO DE SU REFRIGERADOR .................................................................. 21
Interruptor de On/Off (Encendido/Apagado) .......................................... 21
Uso de los controles ............................................................................... 21
F&brica de hielo y dep6sito .................................................................... 23
Sistema de filtraci6n de agua ................................................................. 24
CARACTERJSTICAS DEL REFRIGERADOR ........................................... 25
Estantes del refrigerador ........................................................................ 25
Caj6n para carnes frias con temperatura controlada ............................ 25
CARACTERJSTICAS DEL CONGELADOR .............................................. 26
Canastilla del congelador ....................................................................... 26
CARACTERJSTICAS DE LA PUERTA ...................................................... 27
Compartimiento de uso general ............................................................. 27
Recipientes de la puerta ......................................................................... 27
CUlDADO DE SU REFRIGERADOR ........................................................ 27
Limpieza .................................................................................................. 27
C6mo cambiar los focos ........................................................................ 28
Cortes de corriente ................................................................................. 28
Cuidado durante las vacaciones ............................................................ 29
SOLUClON DE PROBLEMAS ................................................................... 29
Funcionamiento del refrigerador ............................................................ 29
Temperatura y humedad ........................................................................ 30
Hielo y agua ............................................................................................ 30
AYUDA O SERVIClO TleCNICO ................................................................ 31
ACCESORIOS ............................................................................................ 31
HOJA DE DATOS DEL RENDIMIENTO ................................................... 32
GARANTIA ................................................................................................. 34
TABLEDESMATIERES
SleCURITle DU RleFRIGleRATEUR ........................................................... 36
Mise au rebut de votre vieux refrig_rateur ............................................. 36
AVANT L'UTILISATION ............................................................................. 37
Specifications de I'alimentation en eau.................................................. 37
Preparation du syst_me d'eau ................................................................ 37
UTILISATION DU RleFRIGleRATEUR ....................................................... 38
Interrupteur d'alimentation On/Off (marche/arr6t) .................................. 38
Utilisation des commandes .................................................................... 38
Machine & glagons et bac d'entreposage .............................................. 40
Syst_me de filtration d'eau ..................................................................... 41
CARACTleRISTIQUES DU RleFRIGleRATEUR ........................................ 42
Tablettes du r6frig6rateur ....................................................................... 42
Bac pour specialit_s alimentaires & temp@ature contr61ee ................... 42
CARACTleRISTIQUES DU CONGleLATEUR ............................................ 43
Panier de cong61ateur ............................................................................. 43
CARACTleRISTIQUES DE LA PORTE ...................................................... 44
Compartiment utilitaire ........................................................................... 44
Balconnets de porte ............................................................................... 44
ENTRETIEN DU RleFRIGleRATEUR ......................................................... 44
Nettoyage ............................................................................................... 44
Remplacement des ampoules d'eclairage ............................................. 45
Pannes de courant .................................................................................. 45
Entretien avant les vacances .................................................................. 45
DlePANNAGE ............................................................................................. 46
Fonctionnement du refrig6rateur ............................................................ 46
Temperature et humidit6 ........................................................................ 47
Glagons et eau ........................................................................................ 47
ASSISTANCE OU SERVICE ...................................................................... 48
ACCESSOI RES .......................................................................................... 48
FEUILLES DE DONNleES SUR LA PERFORMANCE ............................. 49
GARANTIE .................................................................................................. 51
2

REFRIGERATORSAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
[] Disconnect power before servicing.
• Replace all parts and panels before operating.
• Remove doors from your old refrigerator.
• Use nonflammable cleaner.
• Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
• Use two or more people to move and install refrigerator.
• Disconnect power before installing ice maker (on ice maker
kit ready models only).
• Use a sturdy glass when dispensing ice (on some models).
• Do not hit the refrigerator glass doors (on some models).
SAVE THESE INSTRUCTIONS
Proper DisposalofYourOld Refrigerator
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
Before You Throw Away Your Old Refrigerator or Freezer:
• Takeoff the doors.
• Leave the shelves in place so that children may not easily
climb inside.
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous
- even if they will sit for "just a few days." If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.

BEFOREUSE
Pinch Hazard
Installation of door panels with less than a 3/8"(0.95 cm) gap
between the door panel and the adjacent cabinet increases
the risk of potential pinching.
Remove the Packaging
Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see "Refrigerator Safety."
• Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside of
your refrigerator before using it. See the cleaning instructions in
"Refrigerator Care."
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
"Troubleshooting" or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
• Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
• Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See "Water Filtration
System."
If you have questions about your water pressure, call a licensed,
qualified plumber.
Please read before using the water system.
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, fill and discard two full containers of
ice to prepare the water filter for use, before using the ice.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
Read all directions before you begin.
IMPC RTANT:
When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see "Connect to Water Line" in the Installation
Instructions. Ifyou have any questions about your water
connection, see "Troubleshooting" or call a licensed, qualified
plumber.
• If you turn the refrigerator on before the water line is
connected, turn the ice maker OFE See "Ice Maker and
Storage Bin."
• All installations must meet local plumbing code requirements.
1= Turn on the ice maker. Slide the ice maker On/Off control,
located on the left-hand side of the ice bin, to the ON (up)
position. Please refer to "Ice Maker and Storage Bin" for
further instructions on the operation of your ice maker.
NOTE: Allow 24 hours to produce the first batch of ice.
A. On/Off control
NOTE: If your model has a base grille water filter, make sure the
water filter is properly installed so that the Eject button is out. See
"Water Filtration System."

REFRIGERATORUSE
Electrical Shock Hazard
Plug into agrounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
Integrated Installation -Full Height Grille
To install the grille panel to the refrigerator:
1. Slide the upper and lower slots in each bracket onto the
mounting pins extending upward from the top of the
refrigerator.
2. Push the grille panel forward to fully engage the spring clips
and fasten the grille panel.
To remove the grille panel from the refrigerator:
1. Open the door(s).
2. Place both hands under the grille panel, grasping the bottom
edge between your fingers and thumbs.
3. Pull the grille panel straight out until the grille stops. Then, lift
up on the grille panel to remove.
Power On or Off Switch
1. Remove the top grille panel.
2. Press power switch to the On or Off position.
3. Replace the top grille panel.
IMPORTANT: Be sure the power switch is set to the On position
after cleaning refrigerator or changing light bulbs.
/A
If you need to turn the power to your refrigerator On or Off, you
must remove the top grille panel to access the power switch. Turn
the power to the refrigerator Off when cleaning your refrigerator or
changing light bulbs.
B A B
A. Top grille
B. Cabinet sides
Standard Installation -Flush Grille
To remove the top grille panel:
1. Open the door(s).
2. Lift the top grille panel straight up, then pull straight out. Place
the panel on a soft surface.
To replace the top grille panel:
1. Hook the panel brackets onto the mounting bolts extending
from the top of the refrigerator.
2. Pull the grille panel down slightly to lock into place.
A. Power switch
IMPORTANT:
• Wait 24 hours after you turn on the refrigerator before you put
food into it. Ifyou add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster.
If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 1Y2hours until the
refrigerator and freezer temperatures are below 48°F (9°C) and
15°F (-9°C), respectively, or until the alarm is turned off. To
turn off the audio alarm and indicator light, see "Master Alarm
Reset."

Turning Refrigerator On/Off and Viewing Set Points
The On/Off touch pad on the control panel shuts down refrigerator
functions such as cooling, some lighting, fans and compressors.
To turn the power off completely, use the power On/Off switch
located behind the top grille. See "Power On/Off Switch."
• Press and hold the ON/OFF touch pad for 3 seconds. The
LED will light up to indicate that cooling is Off. Press the touch
pad again to turn on cooling. The LED will turn off.
Viewing the Celsius Temperatures
Press F/C touch pad. To redisplay degrees Fahrenheit, press
F/C again.
NOTE: If the freezer temperature is below zero, the negative
sign next to the freezer display will light up. This is normal.
Adjusting Controls
IMPORTAN1"."
• The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
NOTE: Wait at least 24 hours between adjustments. Recheck
the temperatures before other adjustments are made.
Press the SET TO RECOMMENDED touch pad to reset the set
points to the factory recommended temperatures.
NOTE: The factory recommended set points are 0°F (-18°C)
for the freezer and 37°F (2°C) for the refrigerator.
The actual temperature may differ from the display when a
door is open for an extended period of time.
To Adjust Set Point Temperatures:
The set point range for the freezer is -5°F to 5°F (-21°C to -15°C).
The set point range for the refrigerator is 33°F to 45°F
(0°C to 7°C).
• Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached.
I-q I-q
F-I ......... [] ............FI
CONDITION/REASON: TEMPERATURE
ADJ USTM ENT:
REFRIGERATOR too cold REFRIGERATOR Control
Not set correctly for conditions 1ohigher
REFRIGERATOR too warm REFRIGERATOR Control
High use or room very warm 1olower
FREEZER too cold FREEZER Control
Not set correctly for conditions 1ohigher
FREEZER too warm/too little ice FREEZER Control
High use or heavy ice use 1olower
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the current
condition that caused the alarm until a new condition occurs or
until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing ON/OFF
twice or by turning the power to the refrigerator off and on again.
See "Power On/Off Switch." After performing a Master Alarm
Reset, the indicator light will reactivate if the condition that caused
the alarm is still present. See "Over Temperature," "Call Service,"
or "Door Alarm."
Door Alarm _
Over Temp Alarm @
Door Alarm
The Door Alarm indicator light will flash, an alarm will sound and
the interior lights will turn off when a door has been open for
longer than 10 minutes. When the door is closed, the audio alarm
will reset and turn off, but the Door Alarm indicator light will
continue to flash until the temperature is equal to or below 45°F
(7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
"Master Alarm Reset."
Over Temperature
IMPORTANT: If the Over Temperature Alarm activates, your food
may spoil. See "Power Interruptions." Minimize door openings
until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or the
freezer temperature rises above 15°F (-9°C) for longer than
11/2hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to flash, until the Alarm is pressed, to let you know that an over
temperature condition has occurred.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 11/2hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: The audio alarm will be disabled for subsequent
occurances of over temperature alarm condition. To enable the
audio alarm, see "Master Alarm Reset."
Call Service
If the Call Service indicator light is flashing, call for service. See
the "Assistance or Service" section for information on calling for
service.
NOTE: The audio alarm will be disabled for subsequent
occurances of the call service alarm condition. To enable the
audio alarm, see "Master Alarm Reset."
Max Cold
The Max Cold feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
• Press MAX COLD to turn on the Max Cold feature. The Max
Cold indicator light will remain on for 24 hours unless manually
turned off.
NOTE: The temperature display will remain at 34°F (1°C) and -5°F
(-21 °C) for the refrigerator and freezer compartments,
respectively, while the Max Cold feature is enabled. After
24 hours, the refrigerator returns to the previous temperature set
points.
6

Sabbath Mode (on some models)
The Sabbath Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Sabbath Mode when it is no longer
required.
• Press SABBATH MODE to turn on this feature.
• Press SABBATH MODE again to turn off this feature.
NOTES:
• If the refrigerator is operating in Sabbath mode and you press
SABBATH MODE to turn off the feature, close the doors and
drawer (on some models) to reset the interior lighting.
If the Max Cold feature has been selected prior to turning on
the Sabbath Mode feature, then the set points will remain at
34°F (1°C) and -5°F (-21 °C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times
out. The refrigerator will then return to the previous
temperature set points chosen prior to the selection of the
Max Cold feature, but the lights and ice maker will remain off
until Sabbath Mode is pressed again.
Energy Saver Feature (42" Bottom Mount Only)
The Energy Saver feature controls the heaters located inside the
hinged seal between the refrigerator doors. The heaters help keep
external moisture from forming on the hinged seal.
• Press ENERGY SAVER to turn on this feature for low humidity
conditions. The ring around the control will be lit when Energy
Saver is on. If moisture begins to collect on the hinged seal
between the doors, press ENERGY SAVER again to turn off
this feature.
Water Filter Status
The Reset Filter control allows you to restart the water filter status
tracking feature each time you replace the water filter. See "Water
Filtration System."
• Press and hold RESET FILTER for 3 seconds, until the Order
or Replace light turns off.
Water Filter Status
_ Good
/_ Order Filter
_ Replace Filter
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, fill and discard two full containers of
ice to prepare the water filter for use, before using the ice.
Turn the Ice Maker On/Off
The ice maker On/Off control is located on the left-hand side of
the ice bin.
1= To turn on the ice maker, slide the ice maker On/Off control to
the ON (up) position.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin. The ice maker
sensors will automatically stop ice production, but the ice
maker control will remain in the ON (up) position.
2. To manually turn off the ice maker, slide the ice maker On/Off
control to the OFF (down) position as shown.
A
A. On/Off control
Ice Storage Bin Care
NOTE: It is normal for ice to stick together in the ice bin. It is
recommended that the ice bin be emptied and cleaned as
needed.
To clean the ice storage bin:
1. Slide the ice bin out of the freezer and lift up and out.
2. Empty the ice bin. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin. This can cause damage to the ice container and the
dispenser mechanism.
3. Wash ice bin with warm water and a mild detergent, rinse well
and dry thoroughly. Do not use harsh or abrasive cleaners or
solvents.
REMEMBER:
• Allow 24 hours to produce the first batch of ice.
• It may take 3 to 4 days for the ice bin to completely fill, if no
ice is used.
The quality of your ice will be only as good as the quality of the
water supplied to your ice maker.
Avoid connecting the ice maker to a softened water supply.
Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
Do not store anything inside the ice bin.

Donotusewithwaterthatismicrobiologicallyunsafeorof
unknownqualitywithoutadequatedisinfectionbeforeor
afterthesystem.
Water Filter Indicator (on some models)
The water filter indicator, located on the control panel, will help
you know when to change the water filter.
A new water filter should display a reading of 99%. The reading in
the display will decrease as the filter life is used. A replacement
water filter should be ordered when "Order Filter" is displayed. It is
recommended that you replace the filter when "Change Filter" is
displayed or when water flow to your water dispenser and/or ice
maker decreases noticeably. See "Changing the Water Filter" later
in this section.
I ................._-._
A. Cover
B.O-rings
4. Remove the covers from the O-rings. Be sure the O-rings are
still in place after the covers are removed.
5. Place the cap (removed in Step 2) on the new filter. Align the
ridge on the cap with the arrow on the filter. Turn the cap
clockwise until it snaps into place.
% Remaining Reset
j#
WATER FILTER INDICATOR
After changing the water filter, press and hold RESET for
2 seconds until the status display changes to 99%.
A
Changing the Water Filter
The water filter is located in the base grille below the freezer
compartment door. It is not necessary to remove the base grille to
remove the filter.
1. Remove the filter by pressing the eject button and pulling
straight out on the filter cap.
NOTES:
Avoid twisting the cap when removing the filter because
this could cause the cap to come off. If this occurs,
replace the cap and pull the filter straight out.
• There will be water in the filter. Some spilling may occur.
A
2.
3.
A. Eject button
B. Filter cap
Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
Align the ridge on the cap with the arrow on the new filter and
turn the cap until it snaps into place.
A. Eject button
B. Arrow on filter
C. Ridge on cap
6. Push the new filter into the opening in the base grille. As the
filter is inserted, the eject button will depress. The eject button
will pop back out when the filter is fully engaged.
7. Pull gently on the cap to check that the filter is securely in
place.
8. Flush the water system. Depending on your model, see
"Water and Ice Dispensers" or "Ice Maker and Storage Bin."
Using the Ice Maker Without a Water Filter
You can operate the ice maker without a water filter. Your ice will
not be filtered.
1. Remove the filter by pressing the eject button and pulling on
the cap. See "Changing the Water Filter" earlier in this section.
2. Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. With the cap in a horizontal position, insert the cap into the
base grille until it stops.
4= Turn the cap counterclockwise until the cap slips into the
attachment slot. Then, turn the cap clockwise until it is in a
horizontal position.
NOTE: The cap will not be even with the base grille.
8

REFRIGERATORFEATURES
Important information to know about glass shelves
an_ covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
The shelves in your refrigerator are adjustable to meet your
individual storage needs.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
Remove and Replace a Shelf/Frame
1. Remove the shelf by tilting it up at the front and lifting it out of
the shelf supports. Pull shelf straight out.
2. Reposition the shelf supports in the desired location. Check
that they are level and firmly inserted in the support rails.
3. Place the back of the shelf in the shelf supports.
4. Lower the front of the shelf and make sure that it is in position.
The control for the deli drawer adjusts the temperature of the
drawer. Cold air flows into the drawer through the air duct
between the freezer and the refrigerator. Adjusting the control
allows more or less cold air through the air duct.
The 42" (106.7 cm) model includes two crisper drawers, two deli
drawers, and a control panel as shown.
The 36" (91.4 cm) model has one crisper and one deli drawer, and
a control panel as shown.
Adjust the Temperature
There are three temperature settings: Deli, Produce, Meats (Cold
to Coldest) and the Quick Chill setting. Select the appropriate
setting for the food being stored.
1. Choose a setting based on the item to be stored in the drawer.
2. Push the button that corresponds to that setting.
3. The indicator light for that setting will illuminate to let you
know that the drawer is ready to be loaded.
Quick Chill Setting
The deli drawer has a Quick Chill setting. Selecting Quick Chill
lowers the temperature of the deli drawer for a 1-hour period.
NOTE: The deli drawer temperature will be lower than the freezing
point for liquids. Remove items that may freeze, before setting the
deli drawer to Quick Chill.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish ......................... use same day as purchased
Chicken, ground beef, variety meat (liver, etc.) ................ 1-2 days
Cold cuts, steaks/roasts .................................................. 3-5 days
Cured meats ................................................................... 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Crisper and Deli Drawers
The larger drawers are the crispers for your larger produce items.
To remove and replace the top cover:
1. Remove food from the top cover. Pull drawer out about 4"
(10.16 cm). Reach under the glass shelf with both hands and
lift gently upward until back of shelf is free. Tilt the shelf at an
angle and remove the shelf from the refrigerator. Do not bump
the glass.
2. Replace the cover by holding the glass shelf firmly with both
hands, tilt the shelf at an angle and position it above the
support rails. Place shelf gently on support rails on side wall.
To remove and replace the crisper and deli drawers:
1. Slide the crisper/deli drawer straight out to the stop. Lift the
front of the drawer with one hand while supporting the bottom
with the other hand. Slide the drawer out the rest of the way.

2= To replace the crisper drawer or deli drawer, pull out the
drawer slides until they are fully extended and set the drawer
on the slides. Be sure the small bracket on the side of the
crisper drawer is behind the pin on the side.
A. Bracket
B. Pin
3. Push the drawer in toward the back until it is in closed
position. Reopen the crisper drawer or deli drawer to make
sure it has been replaced properly.
FREEZERFEATURES
DOOR FEATURES
(os some _:_"ode/s)
Theutility compartment can be placed in any position on the
refrigerator door.
Remove and Replace the Utility Bin
1. Remove utility compartment by grasping both ends and lifting
compartment up and out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Thefreezer basket can be used to store bags of frozen fruits and
vegetablesthat may slide off freezershelves.
Remove and Replace the Freezer Basket
1. Pull the basket forward out to the stop.
2. Lift the front of the basket and slide it out the rest of the way.
3. Replace the basket by positioning it on the side wall guide
rails. Lift the basket front slightly while pushing it past the
guide rail stops and slide basket in the rest of the way.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of food,
the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Ice crystals inside a
sealed package are normal. This simply means that moisture in
the food and air inside the package have condensed, creating ice
crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 to 3 Ibs of food per cubic foot
[907-1,350 g per 28 L] of freezer space). Leave enough space in
the freezer for air to circulate around packages. Be sure to leave
enough room for the door to close tightly.
For more information on preparing food for freezing, check a
freezer guide or reliable cookbook.
Large door bins hold gallon containers and the smaller door bins
hold 2-liter bottles. The door bins are adjustable and removable
for easy cleaning and adjusting.
Gallon Door Bin
NOTE: The gallon door bin can only be placed on the lower
support.
1. Insert the attachment brackets into the adjustment slots on
the door.
2. Push down on the bin to secure tabs.
3. If necessary, adjust interior shelves to allow for milk jugs and
tall beverage containers stored in the gallon door bin.
Door Bins
1=
2. Remove the bin by lifting it up and pulling it out.
Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
10

REFRIGERATORCARE
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
Stainless steel panels: Wash stainless steel with a clean
sponge or soft cloth and a mild detergent in warm water.
To keep your stainless steel refrigerator looking like new
and to remove minor scuffs or marks, it is suggested that
you use the manufacturer's approved Stainless Steel
Cleaner and Polish.
IMPORTANT: This cleaner isfor Stainless Steel parts only!
Do not allow the Stainless Steel Cleaner and Polish to come
into contact with any plastic parts such as the trim pieces,
dispenser covers or door gaskets. If unintentional contact
does occur, clean plastic part with a sponge and mild
detergent in warm water. Dry thoroughly with a soft cloth. To
order the cleaner, see "Accessories."
6. Press the power switch to ON.
7. Replace the top grille. See "Power On/Off Switch."
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to avoid
buildup of odors. Wipe up spills immediately.
To Clean Your Refrigerator:
1. Remove the top grille. See "Power On/Off Switch."
2. Press power switch to OFE
3. Remove all removable parts from inside, such as shelves,
crispers, etc.
4. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
• Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
• To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt
[26 g to 0.95 L] of water).
5. Clean the exterior surfaces.
Broken Glass Hazard
Do not hit refrigerator glass doors.
Protect glass surface and edges during installation or
removal of doors.
Failure to do so can result in serious eye injury or
minor cuts.
Glass door panels: Wash glass door panels with a clean
sponge or soft cloth and a mild detergent in warm water.
NOTE: Do not hit the glass with pots, pans, furniture, toys, or
other objects. Scratching, hitting, jarring or stressing the glass
may weaken its structure, causing an increased likelihood of
breakage at a later date.
the " '
NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to
replace the bulb with one of the same size and shape. The lights
require a 40-watt maximum appliance bulb. Replacement bulbs
are available from your dealer.
Refrigerator Lights
There are three light bulbs located in the top front of the
refrigerator compartment behind a light shield.
1. Remove the top grille. See "Power On/Off Switch."
2. Press power switch to the Off position.
3. Open the light shield. Grasp the light shield by the openings.
Gently push back and pull down, as shown, to access the
light bulbs.
A. Light shield
4. Remove the light bulb and replace it with one of the same
size, shape and wattage.
5. Close the light shield by raising it up into place.
NOTE: If needed, clean the light shield with a damp soft cloth.
6. Press the power switch to the On position.
7. Replace the top grille. See "Power On/Off Switch."
Freezer Lights
There are two light bulbs located in the top of the freezer
compartment. One bulb is over the ice bin, and the other bulb is
over the freezer pan.
1. Slide open the ice bin or freezer pan to access the light bulb.
2. Remove the light bulb and replace it with one of the same
size, shape and wattage.
A
A. Light bulbs
11

If the power will be out for 24 hours or less, keep the door or
doors closed (depending on your model) to help food stay cold
and frozen.
If the power will be out for more than 24 hours, do one of the
following:
• Remove all frozen food and store it in a frozen food locker.
• Place 2 Ibs (907 g) of dry ice in the freezer for every cubic foot
(28 L) of freezer space. This will keep the food frozen for 2 to
4 days.
• If neither a food locker nor dry ice is available, consume or can
perishable food at once.
REMEMBER: A full freezer stays cold longer than a partially filled
one. A freezer full of meat stays cold longer than a freezer full of
baked goods. If you see that food contains ice crystals, it may be
refrozen, although the quality and flavor may be affected. If the
condition of the food is poor, dispose of it.
Your refrigerator is equipped with the Sabbath Mode feature,
which is designed for the traveler who wishes to turn off the lights
and ice maker. By selecting this feature, the temperature set
points remain unchanged, the ice maker will be disabled and the
interior lights will turn off. For most efficient refrigerator operation,
it is recommended to exit the Sabbath Mode when it is no longer
required.
If You Choose to Leave the Refrigerator On
While You're Away:
1. Use up any perishables and freeze other items.
2. Press SABBATH MODE pad.
3. If your refrigerator has an automatic ice maker, shut off the
water supply to the ice maker.
4. Empty the ice bin.
5. When you return from vacation, press SABBATH MODE to
return to normal operation.
If You Choose to Turn the Refrigerator Off
Before You Leave:
1. Remove all food from the refrigerator.
2. If your refrigerator has an automatic ice maker:
• Turn off the water supply to the ice maker at least one day
ahead of time.
• When the last load of ice drops, slide the ice maker control
to the OFF (down) position.
3. Depending on your model, turn the Thermostat Control
(or Refrigerator Control) to OFE See "Using the Controls."
4. Clean refrigerator, wipe it, and dry well.
5. Tape rubber or wood blocks to the tops of all doors to prop
them open far enough for air to get in. This stops odor and
mold from building up.
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
The refrigerator will not operate
Electrical Shock Hazard
Plug into agrounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Power cord unplugged? Plug into a grounded 3 prong outlet.
Is outlet working? Plug in a lamp to see if the outlet is
working.
Household fuse blown or circuit breaker tripped? Replace
the fuse or reset the circuit breaker. If the problem continues,
call an electrician.
Are controls on? Make sure the refrigerator controls are on.
See "Using the Controls."
Is refrigerator defrosting? Your refrigerator will regularly run
an automatic defrost cycle. Recheck in 30 minutes to see if it
is operating.
New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
NOTE: Adjusting the temperature controls to coldest setting
will not cool either compartment more quickly.
The motor seems to run too much
Your new refrigerator may run longer than your old one due to its
high-efficiency compressor and fans. The unit may run even
longer if the room is warm, a large food load is added, doors are
opened often, or if the doors have been left open.
The refrigerator is noisy
Refrigerator noise has been reduced over the years. Due to this
reduction, you may hear intermittent noises from your new
refrigerator that you did not notice from your old model. Below are
listed some normal sounds with an explanation.
• Buzzing - heard when the water valve opens to fill the ice
maker
Pulsating - fans/compressor adjusting to optimize
performance
Rattling - flow of refrigerant, water line, or from items placed
on top of the refrigerator
12

Sizzling/Gurgling - water dripping on the heater during
defrost cycle
Popping - contraction/expansion of inside walls, especially
during initial cool-down
Water running - may be heard when water melts during the
defrost cycle and runs into the drain pan
Creaking/Cracking - occurs as ice is being ejected from the
ice maker mold.
There is no audible door open alarm
Has the door been open less thanlO minutes? The door open
alarm will only flash when the door has been open for 10 minutes.
The audible alarm will sound the first time the door is left open for
more than 10 minutes. Subsequent door open alarms will only
flash. You must reset the audible alarm each time. See "Using the
Control(s)."
The doors will not close completely
•Door blocked open? Move food packages away from door.
• Bin or shelf in the way? Push bin or shelf back in the correct
position.
The doors are difficult to open
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
•Are the gaskets dirty or sticky? Clean gaskets with mild
soap and warm water.
The lights do not work
•Is a light bulb loose in the socket or burned out? See
"Changing the Light Bulbs."
•Is the refrigerator in Sabbath Mode? See "Using the
Controls."
•Has the door been open more than 10 minutes? See "Using
the Controls."
Temperature is too warm
New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
Door(s) opened often or left open? Allows warm air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
Large load of food added? Allow several hours for
refrigerator to return to normal temperature.
Controls set correctly for the surrounding conditions?
Adjust the controls a setting colder. Check temperature in
24 hours. See "Using the Controls."
Refrigerator not cooling? For models with digital controls,
turn the refrigerator OFF and then ON to reset. If this does not
correct the problem, call for service.
Air vents blocked? Remove any item from in front of the air
vents.
There is interior moisture buildup
NOTE: Some moisture buildup is normal.
•Humid room? Contributes to moisture buildup.
•Door(s) opened often or left open? Allows humid air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
There is moisture between the refrigerator doors
•Energy Saver on? Turn the Energy Saver feature OFF, if
moisture is collecting between the refrigerator doors. See
"Using the Controls."
The ice maker is not producing ice or not enough ice
•Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
•Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
• Ice maker turned on? Make sure wire shutoff arm or switch
(depending on model) is in the ON position.
• New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
•Large amount of ice recently removed? Allow 24 hours for
ice maker to produce more ice.
•Ice cube jammed in the ice maker ejector arm?
Remove ice from the ejector arm with a plastic utensil.
Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements" in either the Installation
Instruction booklet or the Use & Care Guide.
The ice cubes are hollow or small
NOTE: This is an indication of low water pressure.
•Water shutoff valve not fully open? Turn the water shutoff
valve fully open.
•Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
•Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements."
•Questions remain regarding water pressure? Call a
licensed, qualified plumber.
13

Ice is sticking together in the ice storage bin
• It is normal for frost to be on top of the ice storage bin due to
normal opening and closing of the freezer.
It is normal for ice to stick together when it is not dispensed or
used frequently. It is recommended that the ice storage bin be
emptied and cleaned as needed. See "Ice Maker and Storage
Bin."
Off-taste, odor or gray color in the ice
•New plumbing connections? New plumbing connections
can cause discolored or off-flavored ice.
•Ice stored too long? Discard ice. Wash ice bin. Allow
24 hours for ice maker to make new ice.
Odor transfer from food? Use airtight, moisture-proof
packaging to store food.
Are there minerals (such as sulfur) in the water? A water
filter may need to be installed to remove the minerals.
Is there a water filter installed on the refrigerator? Gray or
dark discoloration in ice indicates that the water filtration
system needs additional flushing.
ASSISTANCEOR SERVICE
If you need assistance or service, first see the "Troubleshooting"
section. Additional help is available. Call us at 1-800-JENNAIR
(1-800-536-6247} from anywhere in the U.S.A., or write:
Jenn-Air Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Information may also be obtained by visiting our website at
www.jennair.com.
In Canada, for assistance, installation or service, call us at
1-800-807-6777, or write:
Jenn-Air Brand Home Appliances
Customer eXperience Centre
200 - 6750 Century Ave.
Mississauga, Ontario L5N 0B7
In Canada, visit www.jennair.ca.
Please include a daytime phone number in your correspondence.
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your appliance to help
you obtain assistance or service if you ever need it. You will need
to know your complete model number and serial number. You can
find this information on the model and serial number label, located
on the inside wall of the refrigerator compartment.
Dealer name
Serial number
Address
Phone number
Model number
Purchase date
ACCESSORIES
To order stainless steel cleaner or replacement filters, call
1-800-688-1100 and ask for the part number listed below or
contact your authorized Jenn-Air dealer. In Canada, call
1-800-807-6777.
Stainless Steel Cleaner and Polish:
Order Part #4396095
Replacement Water Filter:
Order Part #4396841 (T2RFWG2)
14

WATERFILTERCERTIFICATIONS
Slate of California
Department of Health Services
Water Treatment Device
Certificate Number
05- 1703
Date Issued: April 6, 2005
Date Revised: September 7, 2005
Trademark/Model Designation ....
Whirlpool Deluxe T2WG2
KilchenAi_l l
Manufacturer!
116830 of the
tO Section
Trademarl_Modet Designation
Wh_ripool Deluxe TIWG2
_Vhi_ 1oooI DehlxeTI WG2L
State of California
Deparlmenl of Health Services
Water Treatment Device
Certificate Number
05- 1702
Date Issued: April 6, 2005
Dale Revised: Scp/emN_r 7, 2005
Reolacenlent Elenlent_
Manufacturer: Whirlpool Cor_5or atlon
Rated Service CapaciD': 200 gals Rated Service Flow: 085 gpm
Conditions of Certification:
Do not nse w0h water that is microbiotogically unsale or of unknown quality, withuut adequate disinfection beftJre or
after the system
Rated Service Capacity: 2t/(/gats Rated Service Flow: 05 gpm
Conditions of Certification:
Do not use with water that is microbiologically unsafe or of unknown quality, wittlout adequate disinfection before or
after the system
15

PERFORMANCEDATA SHEETS
Base Grille Water Filtration System
Model T2WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T2WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
@System tested and certified by NSF International against NSF/ANSI
Standard 42 for the reduction of Chlorine Taste and Odor, Particulate
Class I1";and against NSF/ANSI Standard 53 for the reduction of Mercury,
Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSI Standards 42 and 53.
Substance Reduction NSF Reduction Average Influent Challenge Maximum Average Minimum %Average %
Aesthetic Effects Requirements Influent Concentration Effluent Effluent Reduction Reduction
Chlorine Taste/Odor 50% reduction 2.0182 mg/L 2.0 mg/L + 10% 0.06 mg/L ** 0.0536 mg/L 97.03 97.34
Particulate Class I1" 85% reduction 1333333 #/mL At east 10,000 part c es/mL 6600 #/mL 2325 #/mL 99.51 99.83
Contaminant NSF Reduction Average Influent Challenge Maximum Average Minimum % Average %
Reduction Requirements Influent Concentration Effluent Effluent Reduction Reduction
Lead: @ pH 6.5*** 0.010 mg/L 0.1533 mg/L 0.15 mg/L + 10% 0.0005 mg/L 0.0005 mg/L 99.67 99.67
Lead: @ pH 8.5*** 0.010 mg/L 0.1400 mg/L 0.15 mg/L _+10% 0.0007 mg/L 0.0006 mg/L 99.50 99.57
Mercury: @ pH 6.5 0.002 mg/L 0.0058 mg/L 0.006 mg/L + 10% 0.0002 mg/L 0.0002 mg/L 96.54 96.54
Mercury: @ pH 8.5 0.002 mg/L 0.0059 mg/L 0.006 mg/L _+10% 0.0005 mg/L 0.0003 mg/L 91.57 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L _+10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L 1.8 mg/L _+10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L _+10% 0.001 mg/L 0.001 mg/L 93.33 93.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L _+10% 0.0400 mg/L 0.0213 mg/L 51.13 74.00
Test Parameters: pH = 7.5 _+0.5 unless otherwise noted. Flow = 0.85 gpm (3.2 Lpm). Pressure = 60 psig (413.7 kPa).
Temp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
• It is essential that operational, maintenance, and filter •
replacement requirements be carried out for the product to
perform as advertised.
• Use replacement filter T2RFWG2, part #4396841.
2010 suggested retail price of $39.99 U.S.A./S54.95 Canada.
Prices are subject to change without notice.
Model T2WG2L: Style 1 - When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 - When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 - When the water filter status display changes from
"GOOD" to "ORDER," order a new filter. When the filter indicator
reads "REPLACE," it is recommended that you replace the filter.
Style 4 - Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T2WG2: Change the water filter cartridge every 6 months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6 months have passed, replace the water filter
cartridge more often.
These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
• The product is for cold water use only.
• Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
• Refer to the "Warranty" section for the Manufacturer's name,
address and telephone number.
• Refer to the "Warranty" section for the Manufacturer's limited
warranty.
Application Guidelines/Water Supply Parameters
Water Supply City or Well
Water Pressure 30 - 120 psi (207 - 827 kPa)
Water Temperature 33° - 100°F (0.6° - 37.8°C)
Service Flow Rate 0.85 gpm (3.2 Lpm) @60 psi
*Class II particle size: 1 um to <5 um
**Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
***Compliant for Lead reduction requirements under NSF/ANSl Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a registered trademark of NSF International.
16

Base Grille Water Filtration System
Model TIWG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model TIWG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
System tested and certified by NSF International against NSF/ANSI
Standard 42 for the reduction of Chlorine Taste and Odor, Particulate
Class I1"; and against NSF/ANSI Standard 53 for the reduction of
Mercury, Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
This system has been tested according to NSF/ANSI 42/53 for the reduction of the substances listed below. The concentration of the
indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water
leaving the system, as specified in NSF/ANSI 42/53.
Substance Reduction
Aesthetic Effects
Chlorine Taste/Odor
Particulate Class I1"
Contaminant
Reduction
Lead: @ pH 6.5***
Lead: @ pH 8.5***
Mercury: @ pH 6.5
Mercury: @ pH 8.5
Benzene
O-Dichlorobenzene
Toxaphene
Carbofuran
NSF Reduction
Requirements
50% reduction
85% reduction
NSF Reduction
Requirements
0.010 mg/L
0.010 mg/L
0.002 mg/L
0.002 mg/L
0.005 mg/L
0.6 mg/L
0.003 mg/L
0.04 mg/L
Average Influent Challenge Maximum
Influent Concentration Effluent
2.0182 mg/L 2.0 mg/L + 10% 0.06 mg/L **
1333333 #/m L At east 10,000 part c es/m L 6600 #/mL
Average
Influent
0.1533 mg/L
0.1400 mg/L
0.0058 mg/L
0.0059 mg/L
0.0154 mg/L
1.7571 mg/L
0.015 mg/L
0.0819 mg/L
Influent Challenge
Concentration
0.15 mg/L_+ 10%
0.15 mg/L_+ 10%
0.006 mg/L _+10%
0.006 mg/L _+10%
0.015 mg/L_+ 10%
1.8 mg/L _+10%
0.015 mg/L_+ 10%
0.08 mg/L _+10%
Maximum
Effluent
0.0005 mg/L
0.0007 mg/L
0.0002 mg/L
0.0005 mg/L
0.0012 mg/L
0.0250 mg/L
0.001 mg/L
0.0400 mg/L
Average Minimum %
Effluent Reduction
0.0536 mg/L 97.03
2325 #/mL 99.51
Average
Effluent
0.0005 mg/L
0.0006 mg/L
0.0002 mg/L
0.0003 mg/L
0.0006 mg/L
0.0066 mg/L
0.001 mg/L
0.0213 mg/L
Minimum %
Reduction
99.67
99.50
96.54
91.57
92.22
98.58
93.33
51.13
Test Parameters: pH = 7.5 _+0.5 unless otherwise noted. Flow = 0.5 gpm (1.9 Lpm). Pressure = 60 psig (413.7 kPa).
Temp. = 68°F to 71.6°F (2O°C to 22°C). Rated service capacity = 200 gallons (757 liters).
• It is essential that operational, maintenance, and filter •
replacement requirements be carried out for the product to
perform as advertised.
• Use replacement filter T2RFWG2, part #4396841.
2010 suggested retail price of $39.99 U.S.A./S54.95 Canada.
Prices are subject to change without notice.
Model TlWG2L: Style 1 - When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 - When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 - When the water filter status display changes from
"GOOD" to "ORDER," order a new filter. When the filter indicator
reads "REPLACE," it is recommended that you replace the filter.
Style 4 - Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model TlWG2: Change the water filter cartridge every 6 months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6 months have passed, replace the water filter
cartridge more often.
Average %
Reduction
97.34
99.83
Average %
Reduction
99.67
99.57
96.54
94.92
96.34
99.63
93.33
74.00
These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
• The product is for cold water use only.
• Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
• Refer to the "Warranty" section for the Manufacturer's name,
address and telephone number.
• Refer to the "Warranty" section for the Manufacturer's limited
warranty.
Application Guidelines/Water Supply Parameters
Water Supply City or Well
Water Pressure 30 - 120 psi (207 - 827 kPa)
Water Temperature 33 ° - 100°F (0.6 ° - 37.8°C)
Service Flow Rate 0.5 gpm (1.9 Lpm) @ 60 psi
*Class II particle size: 1 um to <5 um
**Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
***Compliant for Lead reduction requirements under NSF/ANSl Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a registered trademark of NSF International.
17

JENN-AII BUILT-INREFRIGERATORWARRANTY
LIMITED WARRANTY
For two years from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or
furnished with the product, Jenn-Air brand of Whirlpool Corporation or Whirlpool Canada LP (hereafter "Jenn-Air") will pay for factory
specified parts and repair labor to correct defects in materials or workmanship that existed when this major appliance was purchased.
Service must be provided by a Jenn-Air designated service company. YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. This limited warranty is valid only in the United States or Canada and
applies only when the major appliance is used in the country in which it was purchased. Proof of original purchase date is required to obtain
service under this limited warranty.
On models with a water filter: 30 day limited warranty on water filter. For 30 days from the date of purchase, when this filter is operated and
maintained according to instructions attached to or furnished with the product, Jenn-Air will pay for a replacement water filter to correct
defects in materials and workmanship.
THIRD THROUGH SIXTH YEAR LIMITED WARRANTY ON SEALED REFRIGERATION SYSTEM PARTS
In the third through sixth years from the date of purchase, when this major appliance is operated and maintained according to instructions
attached to or furnished with the product, Jenn-Air will pay for factory specified parts and repair labor for the following components to
correct defects in materials or workmanship in the sealed refrigeration system that existed when this major appliance was purchased:
compressor, evaporator, condenser, dryer, and connecting tubing.
SEVENTH THROUGH TWELFTH YEAR LIMITED WARRANTY ON SEALED REFRIGERATION SYSTEM
In the seventh through twelfth year from the date of purchase, when this major appliance is operated and maintained according to
instructions attached to or furnished with the product, Jenn-Air will pay for factory specified parts for the following components to correct
defects in materials or workmanship in the sealed refrigeration system that existed when this major appliance was purchased: compressor,
evaporator, condenser, dryer, and connecting tubing.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is used in
a manner that is inconsistent to published user or operator instructions and/or installation instructions.
2. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or repair
house fuses, or to correct house wiring or plumbing.
3. Service calls to repair or replace appliance light bulbs, air filters or water filters. Consumable parts are excluded from warranty coverage.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in accordance
with electrical or plumbing codes, or use of products not approved by Jenn-Air.
5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage results
from defects in materials or workmanship and is reported to Jenn-Air within 30 days from the date of purchase.
6. Any food or medicine loss due to refrigerator or freezer product failures.
7. Pickup and delivery. This major appliance is intended to be repaired in your home.
8. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
9. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an
authorized Jenn-Air servicer is not available.
10. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance with
Jenn-Air's published installation instructions.
11. Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered or cannot be
easily determined.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do not
allow limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply to you. This warranty gives
you specific legal rights, and you also may have other rights that vary from state to state or province to province.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. JENN-
AIR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the exclusion or
limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty gives you specific
legal rights, and you also may have other rights that vary from state to state or province to province.
If outside the 50 United States and Canada, contact your authorized Jenn-Air dealer to determine if another warranty applies.
If you think you need repair service, first see the "Troubleshooting" section of the Use & Care Guide. If you are unable to resolve the problem
after checking "Troubleshooting," additional help can be found by checking the "Assistance or Service" section or by calling Jenn-Air. In the
U.S.A., call 1-800-536-6247. In Canada, call 1-800-807-6777. 6/09
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need it.
You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label located on the product.
Dealer name
Address
Phone number
Model number
Serial number
Purchase date
18

SEGURIDAD DELREFRIGERADOR
Su seguridad y la seguridad de los demos es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodomestico. Lea y obedezca siempre
todos los mensajes de seguridad.
Este es el simbolo de advertencia de seguridad.
Este simbolo le llama la atenci6n sobre peligros potenciales que pueden ocasionar la muerte o una lesi6n a
usted y a los demas.
Todos los mensajes de seguridad iran a continuaci6n del simbolo de advertencia de seguridad y de la palabra
"PELIGRO" o "ADVERTENCIA". Estas palabras significan:
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesibn grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesibn grave.
Todos los mensajes de seguridad le diran el peligro potencial, le diran c6mo reducir las posibilidades de sufrir una lesi6n y Io que
puede suceder si no se siguen las instrucciones.
INSTRUCCIONES (MPORTANTES DE SEGURIDAD
ADVERTENC_A: Para reducir el riesgo de incendio, choque electrico, o lesiones personales al usar su refrigerador siga
estas precauciones basicas:
• Conecte a un contacto de pared de conexi6n a tierra de
3 terminales.
• No use un adaptador.
• No quite la terminal de conexi6n a tierra.
• No use un cable electrico de extensi6n.
• Desconecte el suministro de energia antes de darle servicio.
• Vuelva a colocar todos los componentes y paneles antes de
hacerlo funcionar.
• Remueva las puertas de su refrigerador viejo.
• Use un limpiador no inflamable.
• Mantenga los materiales y vapores inflamables, tales como
gasolina, alejados del refrigerador.
• Use dos o mas personas para mover e instalar el
refrigerador.
• Desconecte el suministro de energia antes de instalar la
fabrica de hielo (en aquellos modelos que incluyen el juego
de instalaci6n de la fabrica de hielo).
• Use un vaso resistente para recibir hielo del despachador
(en algunos modelos).
• No golpee las puertas de vidrio del refrigerador (en algunos
modelos).
CONSERVAR ESTAS (NSTRUCCIONES
C6mo deshacerse adecuadamente de
su refrigerador viejo Antes de tirar su refrigerador viejo o congelador:
• Saque las puertas.
• Deje los estantes en su lugar asi los ni_os no pueden meterse
adentro con facilidad.
Peligro de Asfi×ia
Remueva las puertas de su refrigerador viejo.
No seguir esta instrucci6n puede ocasionar la muerte
o daSo al cerebro.
IMPORTANTE: El atrapamiento y asfixia de ni_os no es un
problema del pasado. Los refrigeradores tirados y abandonados
son un peligro.., aOn si van a quedar ahi "por unos pocos dias". Si
Ud. esta por deshacerse de su refrigerador viejo, por favor siga
las instrucciones que se dan a continuacion para prevenir
accidentes.
19

ANTESDEUSAR
IV:_[e].gJIm7-.1mIe]i
Peligro de pellizcos
Si se instalan los paneles de la puerta con un espacio menor
de 3/8"(0,95 cm) entre el panel de la puerta y el armario
adyacente, aumentara el riesgo de pellizcos potenciales.
Cbmo quitar los materiales de empaque
Quite los residuos de la cinta y goma de las superficies de su
refrigerador antes de ponerlo en marcha. Frote un poco de
detergente liquido para vajilla sobre el adhesivo con los
dedos. Limpie con agua tibia y seque.
No use instrumentos filosos, alcohol para fricciones, liquidos
inflamables o limpiadores abrasivos para eliminar restos de
cinta o goma. Estos productos pueden da_ar la superficie de
su refrigerador. Para mas informacion, vea la seccion
"Seguridad del refrigerador".
• Deshagase de todos los materiales de embalaje o reciclelos.
C6mo limpiar su refrigerador antes de usarlo
Una vez que usted haya quitado todos los materiales de
empaque, limpie el interior de su refrigerador antes de usarlo. Vea
las instrucciones de limpieza en la seccion "Cuidado de su
refrigerador".
Informaci6n importante para saber acerca de los estantes
y tapas de vidrio:
No limpie los estantes y tapas de vidrio con agua caliente
mientras estAn frios. Los estantes y tapas pueden romperse
si se exponen a cambios bruscos de temperatura o impacto,
como seria un golpe brusco. El vidrio templado se ha
dise_ado para hacerse a_icos. Esto es normal. Los estantes
y tapas de vidrio son muy pesados. Use ambas manos al
sacarlos para evitar que se caigan.
us os de st m IhS'I KS
Lea todas las instrucciones antes de comenzar.
IM PORTANTE:
Cuando se instalo su refrigerador, la conexion de agua desde
la fuente de agua debio haber sido conectada a su
refrigerador. Si no se ha conectado el refrigerador a una
fuente de agua, vea "Conexion a la linea de agua" en las
Instrucciones de instalacion. Si tiene preguntas acerca de la
conexion de agua, vea "Solucion de problemas" o Ilame a un
plomero competente autorizado.
• Si enciende el refrigerador antes de conectar la tuberia de
agua, ponga la fabrica de hielo en la posicion OFR Vea
"Fabrica de hielo y deposito".
• Todas las instalaciones deben hacerse de acuerdo a los
requerimientos locales de plomeria.
Presi6n del agua
Se necesita un suministro de agua fria con presion de agua entre
30 y 120 Ibs/pulg 2(207 y 827 kPa) para hacer funcionar el
despachador de agua y la fabrica de hielo. Si usted tiene
preguntas acerca de la presion de agua, vea "Solucion de
problemas" o Ilame a un plomero competente autorizado.
Suministro de agua de 6smosis inversa
IMPORTANTE: La presion del suministro de agua que sale de un
sistema de osmosis inversa y va a la valvula de entrada de agua
del refrigerador necesitarA ser entre 30 y 120 Ibs/pulg 2 (207 y
827 kPa).
Si se conecta un sistema de filtracion de agua de osmosis inversa
al suministro de agua fria, la presion de agua al sistema de
osmosis inversa necesitarA ser de un minimo de 40 Ibs/pulg 2
(276 kPa).
Si la presion del agua al sistema de osmosis inversa es menor de
40 Ibs/pulg 2(276 kPa):
• Fijese si el filtro de sedimentos en elsistema de osmosis
inversa esta bloqueado y reemplacelo si fuera necesario.
• Deje que se vuelva a Ilenar el tanque de almacenaje del
sistema de osmosis inversa despu6s del uso intenso.
Si su refrigerador tiene un filtro de agua, se podrA reducir la
presion de agua aOn mas si se usa en conjunto con un
sistema de osmosis inversa. Quite el filtro de agua; vea
"Sistema de filtracion de agua".
Si tiene preguntas acerca de la presion del agua, Ilame a un
plomero competente autorizado.
$(rvase leer antes de usar el sistema de agua.
IMPORTANTF: Despu6s de conectar el refrigerador a un
suministro de agua o de reemplazar el filtro de agua, Ilene y
deseche dos recipientes Ilenos de hielo para preparar el filtro de
agua para su uso, antes de usar el hielo.
No use con agua que no sea microbiol6gicamente segura o
que sea de calidad desconocida sin desinfectarla
adecuadamente antes o despu6s del sistema.
12. Encienda la fabrica de hielo. Deslice el control de On/Off
(Encendido/Apagado) de la fabrica de hielo, ubicado en el
lado izquierdo del deposito de hielo, hacia la posicion ON
(Encendido - hacia arriba). Vea la seccion "Fabrica de hielo y
deposito" para obtener m_s instrucciones sobre el
funcionamiento de su fabrica de hielo.
• Deje transcurrir 24 horas para la produccion del primer
Iote de hielo.
A. Control de OnlOff (Encendido/Apagado)
NOTA" Si su modelo tiene un filtro de agua para la rejilla de la
base, asegOrese de que el filtro de agua se haya instalado
correctamente, de modo que el boton eyector este hacia fuera.
Vea "Sistema de filtracion de agua".
20
