Jenn-Air JS42NXFXDW00 User manual

JENN-AIR® SIDE BY SIDE BUILT-IN REFRIGERATOR
REFRIGERADOR EMPOTRADO
DE DOS PUERTAS JENN-AIR®
RÉFRIGÉRATEUR ENCASTRÉ CÔTE À CÔTE JENN-AIR®
W10231366A
USE & CARE GUIDE
For questions about features, operation/performance, parts, accessories, or service, call:
1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call: 1-800-807-6777, or visit our website at www.jennair.ca.
MANUAL DE USO Y CUIDADO
Si tiene preguntas respecto a las características, funcionamiento, rendimiento, partes, accesorios o servicio técnico, llame al:
1-800-JENNAIR (1-800-536-6247) o visite nuestro sitio de internet: www.jennair.com.
En Canadá, llame al: 1-800-807-6777, o visite nuestro sitio de internet: www.jennair.ca.
GUIDE D’UTILISATION ET D’ENTRETIEN
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site web à www.jennair.ca.
Table of Contents/Índice/Table des matières ......................................................................................2

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY .............................................................3
Proper Disposal of Your Old Refrigerator....................................3
BEFORE USE..................................................................................4
REFRIGERATOR USE ....................................................................4
Power On/Off ...............................................................................4
Water Supply Requirements........................................................5
Water System Preparation...........................................................5
Using the Controls .......................................................................6
REFRIGERATOR FEATURES ........................................................8
Refrigerator Shelves.....................................................................8
Temperature Controlled Deli Drawer ...........................................8
FREEZER FEATURES ....................................................................9
Freezer Shelf ................................................................................9
Freezer Basket .............................................................................9
DOOR FEATURES........................................................................10
Utility Compartment...................................................................10
Door Bins....................................................................................10
Water and Ice Dispensers ..........................................................10
Water Filtration System..............................................................11
Ice Maker and Storage Bin.........................................................12
REFRIGERATOR CARE ...............................................................13
Cleaning......................................................................................13
Changing the Light Bulbs...........................................................14
Power Interruptions....................................................................14
Vacation Care.............................................................................14
TROUBLESHOOTING ..................................................................15
Refrigerator Operation................................................................15
Temperature and Moisture.........................................................16
Ice and Water .............................................................................16
ASSISTANCE OR SERVICE.........................................................17
ACCESSORIES .............................................................................17
WATER FILTER CERTIFICATIONS.............................................18
PERFORMANCE DATA SHEETS ................................................19
WARRANTY ..................................................................................21
ÍNDICE
SEGURIDAD DEL REFRIGERADOR...........................................23
Cómo deshacerse adecuadamente de su refrigerador viejo....23
ANTES DEL USO..........................................................................24
USO DE SU REFRIGERADOR.....................................................24
Interruptor de On/Off (Encendido/Apagado) .............................24
Requisitos del suministro de agua.............................................25
Preparación del sistema de agua ..............................................25
Uso de los controles ..................................................................26
CARACTERÍSTICAS DEL REFRIGERADOR..............................28
Estantes del refrigerador............................................................28
Cajón para carnes frías con temperatura controlada................29
CARACTERÍSTICAS DEL CONGELADOR.................................30
Estante del congelador ..............................................................30
Canastilla del congelador...........................................................30
CARACTERÍSTICAS DE LA PUERTA.........................................30
Compartimiento de uso general ................................................30
Recipientes de la puerta ............................................................30
Despachadores de agua y hielo.................................................31
Sistema de filtración de agua.....................................................32
Fábrica de hielo y depósito........................................................33
CUIDADO DE SU REFRIGERADOR............................................34
Limpieza .....................................................................................34
Cómo cambiar los focos............................................................35
Cortes de corriente.....................................................................35
Cuidado durante las vacaciones................................................35
SOLUCIÓN DE PROBLEMAS......................................................36
Funcionamiento del refrigerador................................................36
Temperatura y humedad............................................................37
Hielo y agua................................................................................37
AYUDA O SERVICIO TÉCNICO...................................................39
ACCESORIOS ...............................................................................39
HOJA DE DATOS DEL RENDIMIENTO ......................................40
GARANTÍA.....................................................................................42
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ..............................................43
Mise au rebut de votre vieux réfrigérateur.................................43
AVANT UTILISATION ...................................................................44
UTILISATION DU RÉFRIGÉRATEUR..........................................44
Interrupteur d'alimentation On/Off (marche/arrêt).....................44
Spécifications de l’alimentation en eau.....................................45
Préparation du système d’eau...................................................45
Utilisation des commandes........................................................46
CARACTÉRISTIQUES DU RÉFRIGÉRATEUR ...........................48
Tablettes du réfrigérateur...........................................................48
Bac pour spécialités alimentaires à température contrôlée......49
CARACTÉRISTIQUES DU CONGÉLATEUR ..............................50
Tablette de congélateur .............................................................50
Panier de congélateur................................................................50
CARACTÉRISTIQUES DE LA PORTE.........................................51
Compartiment utilitaire...............................................................51
Balconnets de porte...................................................................51
Distributeurs d'eau et de glaçons..............................................51
Système de filtration d'eau ........................................................52
Machine à glaçons et bac d’entreposage .................................54
ENTRETIEN DU RÉFRIGÉRATEUR ............................................55
Nettoyage ...................................................................................55
Remplacement des ampoules d’éclairage ................................55
Pannes de courant .....................................................................56
Entretien avant les vacances .....................................................56
DÉPANNAGE.................................................................................57
Fonctionnement du réfrigérateur ...............................................57
Température et humidité............................................................58
Glaçons et eau ...........................................................................58
ASSISTANCE OU SERVICE.........................................................60
ACCESSOIRES .............................................................................60
FEUILLES DE DONNÉES SUR LA PERFORMANCE.................61
GARANTIE.....................................................................................63

3
REFRIGERATOR SAFETY
Proper Disposal of Your Old Refrigerator
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous
– even if they will sit for “just a few days.” If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not easily
climb inside.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
SAVE THESE INSTRUCTIONS
■Plug into a grounded 3 prong outlet.
■Do not remove ground prong.
■Do not use an adapter.
■Do not use an extension cord.
■Disconnect power before servicing.
■Replace all parts and panels before operating.
■Remove doors from your old refrigerator.
■Use nonflammable cleaner.
■Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■Use two or more people to move and install refrigerator.
■Disconnect power before installing ice maker (on ice maker
kit ready models only).
■Use a sturdy glass when dispensing ice (on some models).
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.

4
BEFORE USE
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety.”
■Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside
of your refrigerator before using it. See the cleaning instructions
in “Refrigerator Care.”
REFRIGERATOR USE
Power On/Off
If you need to turn the power to your refrigerator On or Off, you
must remove the top grille panel to access the power switch.
Turn the power to the refrigerator Off when cleaning your
refrigerator or changing light bulbs.
Standard Installation - Flush Grille
To remove the top grille panel:
1. Open the door(s).
2. Lift the top grille panel straight up, then pull straight out.
Place the panel on a soft surface.
To replace the top grille panel:
1. Hook the panel brackets onto the mounting bolts extending
from the top of the refrigerator.
2. Pull the grille panel down slightly to lock into place.
Pinch Hazard
Installation of door panels with less than a ³⁄₈" (0.95 cm) gap
between the door panel and the adjacent cabinet increases
the risk of potential pinching.
CAUTION
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
A. Top grille
B. Cabinet sides
B BA

5
Integrated Installation - Full Height Grille
To remove the top grille panel:
1. Open the door(s).
2. Slide your fingers under the bottom of the grille panel until
you can fully grasp the panel, then pull the panel straight out.
Place the grille panel on a soft surface.
To replace the top grille panel:
1. Align the bracket with the mounting posts.
2. Push the grille panel forward until the bracket snaps into
place.
Power On or Off Switch
1. Remove the top grille panel.
2. Press power switch to the On or Off position.
3. Replace the top grille panel.
IMPORTANT: Be sure the power switch is set to the On position
after cleaning refrigerator or changing light bulbs.
Water Supply Requirements
Read all directions before you begin.
IMPORTANT:
■When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see “Connect to Water Line” in the Installation
Instructions. If you have any questions about your water
connection, see “Troubleshooting” or call a licensed, qualified
plumber.
■If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF. See “Ice Maker and
Storage Bin.”
■All installations must meet local plumbing code requirements.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
“Troubleshooting” or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See “Water
Filtration System.”
If you have questions about your water pressure, call a licensed,
qualified plumber.
Water System Preparation
Please read before using the water system.
Immediately after installation, follow the steps below to make
sure that the water system is properly cleaned.
1. Open the freezer door and turn off the ice maker. For Style 1,
lift up the wire shutoff arm as shown. For Style 2, move the
switch to the OFF (right) setting as shown. The On/Off switch
is located on the top right side of the freezer compartment.
Style 1 – Non-Dispenser Models
Style 2 – Dispenser Models
NOTE: If your model has a base grille water filter, make sure the
water filter is properly installed so that the Eject button is out. See
“Water Filtration System.”
A. Power switch
A
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.

6
2. Use a sturdy container to depress and hold the water
dispenser lever for 5 seconds, then release it for 5 seconds.
Repeat until water begins to flow. Once water begins to flow,
continue depressing and releasing the dispenser lever
(5 seconds on, 5 seconds off) for an additional 2 minutes.
This will flush air from the filter and water dispensing system.
Additional flushing may be required in some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
3. Open the freezer door and turn on the ice maker. For Style 1,
lower the wire shutoff arm. For Style 2, move the switch to
the ON (left) position.
■Allow 24 hours to produce the first batch of ice.
■Discard the first three batches of ice produced.
■Depending on your model, you may want to select the
maximum ice feature to increase the production of ice.
Using the Controls
Depending on your model, your refrigerator may have Style 1 or
Style 2 controls. Follow the instructions specific to your model.
IMPORTANT:
■Wait 24 hours after you turn on the refrigerator before you put
food into it. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster.
■If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
■After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 1¹⁄₂ hours until
the refrigerator and freezer temperatures are below 48°F (9°C)
and 15°F (-9°C), respectively, or until the alarm is turned off.
To turn off the audio alarm and indicator light, see “Master
Alarm Reset.
Turning Refrigerator On/Off and Viewing Set Points
The On/Off touch pad on the control panel shuts down
refrigerator functions such as cooling, some lighting, fans and
compressors. To turn the power off completely, use the power
On/Off switch located behind the top grille. See “Power On/Off
Switch.”
■Press the On/Off touch pad.
Viewing the Celsius Temperatures
■Press F/C touch pad. To redisplay degrees Fahrenheit, press
F/C again.
NOTE: If the freezer temperature is below zero, the negative
sign next to the freezer display will light up. This is normal.
Adjusting Controls
IMPORTANT:
■The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
NOTE: Wait at least 24 hours between adjustments. Recheck
the temperatures before other adjustments are made.
■Press the SET TO RECOMMENDED touch pad to reset the
set points to the factory recommended temperatures.
NOTE: The factory recommended set points are 0°F (-18°C)
for the freezer and 37°F (2°C) for the refrigerator.
■The actual temperature may differ from the display when a
door is open for an extended period of time.
To Adjust Set Point Temperatures:
The set point range for the freezer is -5°F to 5°F (-21°C to -15°C).
The set point range for the refrigerator is 33°F to 45°F
(0°C to 7°C).
■Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached
Style1
Style 2
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the
current condition that caused the alarm until a new condition
occurs or until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing ON/OFF
twice or by turning the power to the refrigerator off and on again.
See “Power On/Off Switch.” After performing a Master Alarm
Reset, the indicator light will reactivate if the condition that
caused the alarm is still present. See “Over Temperature,” “Call
Service,” or “Door Alarm.”
Style 1
Style 2
CONDITION/REASON: TEMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold
Not set correctly for conditions
REFRIGERATOR Control
1°higher
REFRIGERATOR too warm
High use or room very warm
REFRIGERATOR Control
1°lower
FREEZER too cold
Not set correctly for conditions
FREEZER Control
1°higher
FREEZER too warm/too little ice
High use or heavy ice use
FREEZER Control
1°lower

7
Door Alarm
The Door Alarm indicator light will flash, an alarm will sound and
the interior lights will turn off when a door has been open for
longer than 10 minutes. When the door is closed, the audio alarm
will reset and turn off, but the Door Open indicator light will
continue to flash until the temperature is equal to or below 45°F
(7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
“Master Alarm Reset.”
Over Temperature
IMPORTANT: If the Over Temperature Alarm activates, your food
may spoil. See the “Power Interruptions.” Minimize door
openings until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or the
freezer temperature rises above 15°F (-9°C) for longer than
1¹⁄₂ hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to flash until the Alarm is pressed to let you know that an over
temperature condition has occurred.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 1¹⁄₂ hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: To deactivate the audio alarm and indicator light, see
“Master Alarm Reset.”
Call Service (on some models)
If the Call Service indicator light is flashing, call for service. See
the “Assistance or Service” section for information on calling for
service.
NOTE: To deactivate the audio alarm and indicator light, see
“Master Alarm Reset.”
Max Cold
The Max Cold feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
■Press MAX COLD to turn on the Max Cold feature. The Max
Cold indicator light will remain on for 24 hours unless
manually turned off.
NOTE: The temperature display will remain at 34°F (1°C) and -5°F
(-21°C) for the refrigerator and freezer compartments,
respectively, while the Max Cool feature is enabled. After
24 hours, the refrigerator returns to the previous temperature set
points.
Rest Mode (on some models)
The Rest Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Deli drawer settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, turn off Rest Mode when it is no longer
required.
■Press REST MODE to turn on this feature.
■Press REST MODE again to turn off this feature.
NOTE: If the Max Cold feature has been selected prior to turning
on the Rest Mode feature, then the set points will remain at 34°F
(1°C) and -5°F (-21°C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times out.
The refrigerator will then return to the previous temperature set
points chosen prior to the selection of the Max Cold feature, but
the lights and ice maker will remain off until Rest Mode is pressed
again.
Sabbath Mode (on some models)
The Sabbath Mode feature is designed for the traveler or for
those whose religious observances require turning off the lights
and ice maker. By selecting this feature, the temperature set
points and Deli drawer settings remain unchanged, the ice maker
will be disabled and the interior lights will turn off. For most
efficient refrigerator operation, turn off Sabbath Mode when it is
no longer required.
■Press SABBATH MODE to turn on this feature.
■Press SABBATH MODE again to turn off this feature.
NOTES:
■If the refrigerator is operating in Sabbath mode and you press
SABBATH MODE to turn off the feature, close the doors to
reset the interior lighting.
■If the Max Cold feature has been selected prior to turning on
the Sabbath Mode feature, then the set points will remain at
34°F (1°C) and -5°F (-21°C) for the refrigerator and freezer
compartments, respectively, until the Max Cold feature times
out. The refrigerator will then return to the previous
temperature set points chosen prior to the selection of the
Max Cold feature, but the lights and ice maker will remain off
until Sabbath Mode is pressed again.
Water Filter Status
Style 1–Reset
The reset filter control allows you to restart the water filter status
tracking feature each time you replace you water filter. See
“Water Filtration System.”
■Press and hold RESET for 3 seconds, until the indicator
display changes to 99%.
Style 2–Reset Filter
The reset filter control allows you to restart the water filter status
tracking feature each time you replace you water filter. See
“Water Filter Indicator” section.
■Press and hold RESET FILTER for 3 seconds, until the Order
or Replace light turns off.

8
REFRIGERATOR FEATURES
Refrigerator Shelves
The shelves in your refrigerator are adjustable to meet your
individual storage needs.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
Shelves
Style 1
To remove and replace a shelf/frame:
1. Remove the shelf/frame by tilting it up at the front and lifting it
out of the shelf supports. Pull shelf straight out.
2. Replace the shelf/frame by guiding the rear shelf hooks into
the shelf supports. Tilt the front of the shelf up until the rear
shelf hooks drop into the shelf supports.
3. Lower the front of the shelf and check to make sure that the
shelf is securely in position.
Style 2
To remove and replace a shelf/frame:
1. Remove the shelf by tilting it up at the front and lifting it out of
the shelf supports. Pull shelf straight out.
2. Reposition the shelf supports in the desired location. Check
that they are level and firmly inserted in the support rails.
3. Place the back of the shelf in the shelf supports.
4. Lower the front of the shelf and make sure that it is in
position.
Temperature Controlled Deli Drawer
The control for the deli drawer adjusts the temperature of the
drawer. Cold air flows into the drawer through the air duct
between the freezer and the refrigerator. Adjusting the control
allows more or less cold air through the air duct.
Adjust the Temperature
There are three temperature settings: Deli, Produce, Meats (Cold
to Coldest) and the Quick Chill setting. Select the appropriate
setting for the food being stored.
1. Choose a setting based on the item to be stored in the
drawer.
2. Push the button that corresponds to that setting.
3. The indicator light for that setting will illuminate to let you
know that the drawer is ready to be loaded.
Quick Chill Setting (on some models)
Each deli drawer has a Quick Chill setting. Selecting Quick Chill
lowers the temperature of the deli drawer for a one-hour period.
NOTE: The deli drawer temperature will be lower than the
freezing point for liquids. Remove items that may freeze, before
setting the drawer to Quick Chill.
Style1
Style 2
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish......................... use same day as purchased
Chicken, ground beef, variety meat (liver, etc.) ................1-2 days
Cold cuts, steaks/roasts ..................................................3-5 days
Cured meats...................................................................7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
A. Deli drawer
B. Crisper
A. Crisper
B. Deli drawer
A
B
B
A
B
A

9
Crisper and Deli Drawers
The larger drawers are the crispers for your larger produce items.
To remove and replace the top cover:
1. Remove food from the top cover. Pull drawer out about 4"
(10.16 cm). Reach under the glass shelf with both hands and
lift gently upward until back of shelf is free. Tilt the shelf at an
angle and remove the shelf from the refrigerator. Do not bump
the glass.
2. Replace the cover by holding the glass shelf firmly with both
hands, tilt the shelf at an angle and position it above the
support rails. Place shelf gently on support rails on side wall.
To remove and replace the crisper and deli drawers:
1. Slide the crisper drawer or deli drawer, straight out to the
stop. Lift the front of the drawer with one hand while
supporting the bottom with the other hand. Slide the drawer
out the rest of the way.
2. To replace the crisper drawer or deli drawer, pull out the
drawer slides until they are fully extended and set the drawer
on the slides. Be sure the small bracket on the side of the
crisper drawer is behind the pin on the side.
3. Push the drawer in toward the back until it is in closed
position. Reopen the crisper drawer or deli drawer to make
sure it has been replaced properly.
FREEZER FEATURES
Freezer Shelf
1. Remove the shelf by lifting it up and pulling it straight out.
2. Replace the shelf by putting it over the supports and lowering
it into place.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of food,
the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Ice crystals inside
a sealed package are normal. This simply means that moisture in
the food and air inside the package have condensed, creating ice
crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 to 3 lbs of food per cubic foot
[907-1,350 g per 28 L] of freezer space). Leave enough space in
the freezer for air to circulate around packages. Be sure to leave
enough room for the door to close tightly.
For more information on preparing food for freezing, check a
freezer guide or reliable cookbook.
Freezer Basket
The freezer basket can be used to store bags of frozen fruits and
vegetables that may slide off freezer shelves.
Remove and Replace the Freezer Basket
1. Pull the basket forward out to the stop.
2. Lift the front of the basket and slide it out the rest of the way.
3. Replace the basket by positioning it on the side wall guide
rails. Lift the basket front slightly while pushing it past the
guide rail stops and slide basket in the rest of the way.
A. Bracket
B. Pin
A
B

10
DOOR FEATURES
Utility Compartment
(on some models)
The utility compartment can be placed in any position on the
refrigerator door.
Remove and Replace the Utility Bin
1. Remove utility compartment by grasping both ends and lifting
compartment up and out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Door Bins
Large door bins hold gallon containers and the smaller door bins
hold 2-liter bottles. The door bins are adjustable and removable
for easy cleaning and adjusting.
Gallon Door Bin
NOTE: The gallon door bin can only be placed on the lower
support.
1. Insert the attachment brackets into the adjustment slots on
the door.
2. Push down on the bin to secure tabs.
3. If necessary, adjust interior shelves to allow for milk jugs and
tall beverage containers stored in the gallon door bin.
Door Bins
1. Remove the bin by lifting it up and pulling it out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Water and Ice Dispensers
(on some models)
Depending on your model, your water and ice dispensers may
have one or more of the following features: a water level indicator
in the dispenser tray, a special light that turns on when you use
the dispenser, or a lock option to avoid unintentional dispensing.
NOTES:
■The dispensing system will not operate when the freezer door
is open.
■After connecting the refrigerator to a water source, flush the
water system. Use a sturdy container to depress and hold the
water dispenser lever for 5 seconds, then release it for
5 seconds. Repeat until water begins to flow. Once water
begins to flow, continue depressing and releasing the
dispenser lever (5 seconds on, 5 seconds off) for an
additional 2 minutes. This will flush air from the filter and
water dispensing system. Additional flushing may be required
in some households. As air is cleared from the system, water
may spurt out of the dispenser.
■Allow 24 hours for the refrigerator to cool down and chill
water.
■Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
Water Dispenser
To dispense water:
1. Press a sturdy glass against the water dispenser pad.
NOTES:
■While dispensing water and for 3 seconds after
dispensing has stopped, the digital display will show how
many ounces of water have been dispensed.
■To switch from ounces to cups, press and hold ICE and
LOCK at the same time until the dispenser beeps after
3 seconds. To switch from cups to liters, press and hold
the buttons for another 3 seconds. To switch back to
ounces, repeat the process a third time.
2. Remove the glass to stop dispensing.
NOTE: Water may have an off-flavor if you do not use the
dispenser periodically. Dispense enough water every week to
maintain a fresh supply.
Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when
the dispenser pad is pressed. The dispensing system will not
operate when the freezer door is open. To turn off the ice maker,
see “Ice Maker and Storage Bin.”
Your ice maker can produce both crushed and cubed ice. The
display screen reads “CRUSHED” or “CUBED”, indicating which
type is selected. To change the setting, press the ICE button
before dispensing ice.

11
For crushed ice, cubes are crushed before being dispensed. This
may cause a slight delay when dispensing crushed ice. Noise
from the ice crusher is normal, and pieces of ice may vary in size.
When changing from crushed to cubed, a few ounces of crushed
ice will be dispensed along with the first cubes.
To dispense ice:
1. Press the button to select the desired type of ice.
2. Press a sturdy glass against the ice dispenser pad. Hold the
glass close to the dispenser opening so ice does not fall
outside of the glass.
IMPORTANT: You do not need to apply a lot of pressure to
the pad in order to activate the ice dispenser. Pressing hard
will not make the ice dispense faster or in greater quantities.
3. Remove the glass to stop dispensing.
NOTE: Ice may continue to dispense for up to 10 seconds
after removing the glass from the pad. The dispenser may
continue to make noise for a few seconds after dispensing.
Dispenser Light (on some models)
When you use the dispenser, the light will automatically turn on.
If you want the light to be on continuously, you may choose either
ON or AUTO.
ON: Press LIGHT to turn the dispenser light on.
AUTO: Press LIGHT a second time to select AUTO mode. The
dispenser light will automatically adjust to become brighter as the
room brightens, dimmer as the room darkens.
OFF: Press LIGHT a third time to turn the dispenser light off.
The dispenser lights are LEDs that can not be changed. If it
appears that your dispenser lights are not working, be sure that
the light sensor is not blocked (in AUTO mode). See
“Troubleshooting” for more information.
Dispenser Lock (on some models)
The dispenser can be turned off for easy cleaning or to avoid
unintentional dispensing by small children and pets.
NOTE: The lock feature does not shut off power to the product,
to the ice maker, or to the dispenser light. It simply deactivates
the ice and water dispensers. To turn off the ice maker, see “Ice
Maker and Storage Bin.”
■Press and hold LOCK for 3 seconds to lock the dispenser.
While the dispenser is locking, “LOCKING” will appear on the
display screen and the blue indicator light around the LOCK
button will flash. When the dispenser is locked, the indicator
light will change to red for a few seconds, then turn off.
■Press and hold LOCK a second time to unlock the dispenser.
While the dispenser is unlocking, “UNLOCKING” will appear
on the display screen and the red indicator light around the
LOCK button will flash. When the dispenser is unlocked, the
indicator light will change to blue for a few seconds, then turn
off.
Water Filtration System
Depending on your model, there may be a water filter indicator or
water filter status lights on the control panel. Follow the
instructions specific to your model.
Water Filter Indicator (dispenser models)
The water filter indicator, located on the control panel, will remind
you when it is time to order and replace the water filter.
A new water filter should display a reading of 99%. The reading in
the display will decrease as the filter life is used. A replacement
water filter should be ordered when “Order Filter” is displayed.
When “Change Filter” is displayed, a new water filter should be
installed.
The disposable water filter should be replaced every 6 months
OR earlier if the flow of water to the water dispenser or ice maker
decreases noticeably.
After changing the water filter, press and hold RESET for
2 seconds until the indicator display changes to 99%. See “Using
the Controls.”
Water Filter Status Lights (non-dispenser models)
The water filter status lights will remind you when it is time to
order and replace the water filter. When the Order Filter light is
on, it is almost time to change the water filter. When the Replace
Filter light is on, a new water filter should be installed.
The disposable water filter should be replaced at least every 6
months OR earlier if the flow of water to the ice maker decreases
noticeably.
After replacing the water filter, press and hold RESET FILTER for
3 seconds. The Good light will turn on when the filter tracking
feature is reset. See “Using the Controls.”
Changing the Water Filter
The water filter is located in the base grille below the freezer
compartment door. It is not necessary to remove the base grille
to remove the filter.
1. Remove the filter by pressing the eject button and pulling
straight out on the filter cap.
NOTES:
■Avoid twisting the cap when removing the filter because
this could cause the cap to come off. If this occurs,
replace the cap and pull the filter straight out.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.

12
■There will be water in the filter. Some spilling may occur.
2. Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. Align the ridge on the cap with the arrow on the new filter and
turn the cap until it snaps into place.
4. Remove the covers from the O-rings. Be sure the O-rings are
still in place after the covers are removed.
5. Place the cap (removed in Step 2) on the new filter. Align the
ridge on the cap with the arrow on the filter. Turn the cap
clockwise until it snaps into place.
6. Push the new filter into the opening in the base grille. As the
filter is inserted, the eject button will depress. The eject
button will pop back out when the filter is fully engaged.
7. Pull gently on the cap to check that the filter is securely in
place.
8. Discard the first three batches of ice produced after replacing
the filter.
Using the Ice Maker Without a Water Filter
You can operate the ice maker without a water filter. Your ice will
not be filtered.
1. Remove the filter by pressing the eject button and pulling on
the cap. See “Changing the Water Filter” earlier in this
section.
2. Remove the cap by turning it counterclockwise until it stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. With the cap in a horizontal position, insert the cap into the
base grille until it stops.
4. Turn the cap counterclockwise until the cap slips into the
attachment slot. Then, turn the cap clockwise until it is in a
horizontal position.
NOTE: The cap will not be even with the base grille.
Ice Maker and Storage Bin
(on some models - Accessory)
Style 1
To Turn the Ice Maker On/Off:
The On/Off switch for the ice maker is a wire shutoff arm located
on the side of the ice maker.
1. To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
2. To manually turn the ice maker off, lift the wire shutoff arm to
the OFF (arm up) position and listen for the click to make sure
the ice maker will not continue to operate.
To Remove and Replace the Ice Bin:
1. Flip up the covering panel.
A. Eject button
B. Filter cap
A. Cover
B. O-rings
A. Eject button
B. Arrow on filter
C. Ridge on cap
A
B
A
B
A
B
C
A. Ice maker cover
A

13
2. Lift the wire shutoff arm so it clicks into the OFF (up)
position. Ice can still be dispensed, but no more can be
made.
3. Lift up the front of the storage bin and pull the ice bin forward.
4. Replace the bin by pushing it in all the way or the dispenser
will not work. Push the wire shutoff arm down to the ON
position to restart ice production. Make sure the door is
closed tightly.
Style 2
To Turn the Ice Maker On/Off:
The On/Off switch is located on the top right side of the freezer
compartment.
1. To turn the ice maker on, slide the control to the ON (left)
position.
NOTE: Your ice maker has an automatic shutoff. The ice
maker sensors will automatically stop ice production, but the
control will remain in the ON (left) position.
2. To manually turn the ice maker off, slide the control to the
OFF (right) position.
To Remove and Replace the Ice Storage Bin:
1. Hold the base of the storage bin with both hands and press
the release button to lift the storage bin up and out.
NOTE: It is not necessary to turn the ice maker control to the
OFF (right) position when removing the storage bin. The
sensor cover (“flipper door”) on the left wall of the freezer
stops the ice maker from producing ice if the door is open or
the storage bin is removed.
2. Replace the storage bin on the door and push down to make
sure it is securely in place.
Clean the Ice Storage Bin
1. Empty the ice container. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin or bucket. This can cause damage to the ice container
and the dispenser mechanism.
2. Wash ice bin with a mild detergent, rinse well and dry
thoroughly. Do not use harsh or abrasive cleaners or solvents.
Remember
■Allow 24 hours to produce the first batch of ice. Allow 3 days
to completely fill ice container.
■Discard the first three batches of ice produced to avoid
impurities that may be flushed out of the system.
■The quality of your ice will be only as good as the quality of
the water supplied to your ice maker.
■Avoid connecting the ice maker to a softened water supply.
Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
■It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
■For Style 1 ice maker, do not force the wire shutoff arm up or
down.
■Do not store anything on top of the ice maker or in the ice
storage bin/bucket.
REFRIGERATOR CARE
Cleaning
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to avoid
buildup of odors. Wipe up spills immediately.
To Clean Your Refrigerator:
1. Remove the top grille. See “Power On/Off Switch.”
2. Press power switch to OFF.
3. Remove all removable parts from inside, such as shelves,
crispers, etc.
4. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
■Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
■To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt
[26 g to 0.95 L] of water).
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

14
5. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners, or cleaners containing
chlorine. Dry thoroughly with a soft cloth.
NOTE: To keep your Stainless Steel refrigerator looking like
new and to remove minor scuffs or marks, it is suggested that
you use the manufacturer’s approved Stainless Steel Cleaner
and Polish.
IMPORTANT: This cleaner is for Stainless Steel parts only!
Do not allow the Stainless Steel Cleaner and Polish to come
into contact with any plastic parts such as the trim pieces,
dispenser covers or door gaskets. If unintentional contact
does occur, clean plastic part with a sponge and mild
detergent in warm water. Dry thoroughly with a soft cloth. To
order the cleaner, see “Accessories.”
6. Press the power switch to ON.
7. Replace the top grille. See “Power On/Off Switch.”
Changing the Light Bulbs
NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to
replace the bulb with one of the same size and shape. All lights
require a 40-watt maximum appliance bulb. Replacement bulbs
are available from your dealer or appliance store.
1. Remove the top grille. See “Power On/Off Switch.”
2. Press the power switch to OFF.
3. Remove light shield when applicable as shown.
NOTE: To clean a light shield, wash it with warm water and a
liquid detergent. Rinse and dry the shield well.
4. Remove light bulb and replace with one of the same size,
shape and wattage.
5. Replace light shield when applicable as shown.
6. Press the power switch ON.
7. Replace the top grille. See “Power On/Off Switch.”
Refrigerator Control Panel Lights
There are two or three light bulbs located in the top front of the
refrigerator compartment behind a light shield.
■Open the light shield. Grasp the light shield by the openings.
Gently push back and pull down, as shown, to access the
light bulbs.
■Remove the light bulb and replace it with one of the same
size, shape and wattage.
■Close the light shield by raising it up into place.
NOTE: If needed, clean the light shield with a damp soft
cloth.
Freezer and Crisper Lights
■Remove the light shield by grasping the sides and squeezing
in toward the center. Once the side hooks of the shield are
free from the freezer or crisper lining, pull down the shield.
■Replace the light shield by squeezing the top and bottom
toward the center and inserting the hooks into the slotted
holes. Once the hooks are in place, snap the front tab into the
slotted hole.
Power Interruptions
If the power will be out for 24 hours or less, keep the door or
doors closed (depending on your model) to help food stay cold
and frozen.
If the power will be out for more than 24 hours, do one of the
following:
■Remove all frozen food and store it in a frozen food locker.
■Place 2 lbs (907 g) of dry ice in the freezer for every cubic foot
(28 L) of freezer space. This will keep the food frozen for 2 to
4days.
■If neither a food locker nor dry ice is available, consume or
can perishable food at once.
REMEMBER: A full freezer stays cold longer than a partially filled
one. A freezer full of meat stays cold longer than a freezer full of
baked goods. If you see that food contains ice crystals, it may be
refrozen, although the quality and flavor may be affected. If the
condition of the food is poor, dispose of it.
Vacation Care
Your refrigerator is equipped with either a Rest Mode or Sabbath
Mode feature, which is designed for the traveler who wishes to
turn off the lights and ice maker. By selecting this feature, the
temperature set points remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, it is recommended to exit Rest Mode or
Sabbath Mode when it is no longer required.
If You Choose to Leave the Refrigerator On While You’re
Away:
1. Use up any perishables and freeze other items.
2. Press REST MODE or SABBATH MODE touch pad.
3. If your refrigerator has an automatic ice maker, shut off water
supply to the ice maker.
4. Empty the ice bin.
5. When you return from vacation, press REST MODE or
SABBATH MODE to return to normal operation.
A. Light shield
A

15
If You Choose to Turn the Refrigerator Off Before You
Leave:
1. Remove all food from the refrigerator.
2. If your refrigerator has an automatic ice maker:
■Turn off the water supply to the ice maker at least one day
ahead of time.
■When the last load of ice drops, raise the wire shutoff arm
to the OFF (up) position.
3. Depending on your model, turn the Thermostat Control
(or Refrigerator Control) to OFF. See “Using Controls.”
4. Clean refrigerator, wipe it, and dry well.
5. Tape rubber or wood blocks to the tops of both doors to prop
them open far enough for air to get in. This stops odor and
mold from building up.
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Refrigerator Operation
The refrigerator will not operate
■Power cord unplugged? Plug into a grounded 3 prong
outlet.
■Is outlet working? Plug in a lamp to see if the outlet is
working.
■Household fuse blown or circuit breaker tripped? Replace
the fuse or reset the circuit breaker. If the problem continues,
call an electrician.
■Are controls on? Make sure the refrigerator controls are on.
See “Using the Controls.”
■Is refrigerator defrosting? Your refrigerator will regularly run
an automatic defrost cycle. Recheck in 30 minutes to see if it
is operating.
■New installation? Allow 24 hours following installation for
the refrigerator to cool completely.
NOTE: Adjusting the temperature controls to coldest setting
will not cool either compartment more quickly.
The motor seems to run too much
Your new refrigerator may run longer than your old one due to its
high-efficiency compressor and fans. The unit may run even
longer if the room is warm, a large food load is added, doors are
opened often, or if the doors have been left open.
The refrigerator is noisy
Refrigerator noise has been reduced over the years. Due to this
reduction, you may hear intermittent noises from your new
refrigerator that you did not notice from your old model. Below
are listed some normal sounds with an explanation.
■Buzzing - heard when the water valve opens to fill the ice
maker
■Pulsating - fans/compressor adjusting to optimize
performance
■Rattling - flow of refrigerant, water line, or from items placed
on top of the refrigerator
■Sizzling/Gurgling - water dripping on the heater during
defrost cycle
■Popping - contraction/expansion of inside walls, especially
during initial cool-down
■Water running - may be heard when water melts during the
defrost cycle and runs into the drain pan
■Creaking/Cracking - occurs as ice is being ejected from the
ice maker mold.
The doors will not close completely
■Door blocked open? Move food packages away from door.
■Bin or shelf in the way? Push bin or shelf back in the correct
position.
The doors are difficult to open
■Are the gaskets dirty or sticky? Clean gaskets with mild
soap and warm water.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

16
The lights do not work
■Is a light bulb loose in the socket or burned out? See
“Changing the Light Bulbs.”
■Is the refrigerator in Sabbath Mode or Rest Mode? See
“Using the Controls.”
■Has the door been open more than 10 minutes? See
“Using the Controls.”
Temperature and Moisture
Temperature is too warm
■New installation? Allow 24 hours following installation for
the refrigerator to cool completely.
■Door(s) opened often or left open? Allows warm air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
■Large load of food added? Allow several hours for
refrigerator to return to normal temperature.
■Controls set correctly for the surrounding conditions?
Adjust the controls a setting colder. Check temperature in
24 hours. See “Using the Controls.”
■Refrigerator not cooling? For models with digital controls,
turn the refrigerator OFF and then ON to reset. If this does not
correct the problem, call for service.
■Air vents blocked? Remove any item from in front of the air
vents.
There is interior moisture buildup
NOTE: Some moisture buildup is normal.
■Humid room? Contributes to moisture buildup.
■Door(s) opened often or left open? Allows humid air to
enter refrigerator. Minimize door openings and keep doors
fully closed.
Ice and Water
The ice maker is not producing ice or not enough ice
■Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
■Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
■Ice maker turned on? Make sure wire shutoff arm or switch
(depending on model) is in the ON position.
■New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
■Large amount of ice recently removed? Allow 24 hours for
ice maker to produce more ice.
■Ice cube jammed in the ice maker ejector arm?
Remove ice from the ejector arm with a plastic utensil.
■Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See “Water Supply Requirements” in either the Installation
Instruction booklet or the Use & Care Guide.
The ice cubes are hollow or small
NOTE: This is an indication of low water pressure.
■Water shutoff valve not fully open? Turn the water shutoff
valve fully open.
■Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
■Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See “Water Supply Requirements.”
■Questions remain regarding water pressure? Call a
licensed, qualified plumber.
Off-taste, odor or gray color in the ice
■New plumbing connections? New plumbing connections
can cause discolored or off-flavored ice.
■Ice stored too long? Discard ice. Wash ice bin. Allow
24 hours for ice maker to make new ice.
■Odor transfer from food? Use airtight, moisture proof
packaging to store food.
■Are there minerals (such as sulfur) in the water? A water
filter may need to be installed to remove the minerals.
■Is there a water filter installed on the refrigerator? Gray or
dark discoloration in ice indicates that the water filtration
system needs additional flushing.
The ice dispenser will not operate properly
■Freezer door closed completely? Close the door firmly. If it
does not close completely, see “The doors will not close
completely.”
■Ice bin installed correctly? Be sure the ice bin is firmly in
position.
■New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
■Ice stuck in the delivery chute? Use a plastic utensil to clear
the delivery chute.
■Has the wrong ice been added to the bin? Use only cubes
produced by the current ice maker.
■Has the ice melted around the auger (metal spiral) in the
ice bin? Empty the ice container. Use warm water to melt the
ice if necessary.
■Is the ice dispenser stalling while dispensing “crushed”
ice? Change the ice button from “crushed” to “cubed.” If
cubed ice dispenses correctly, depress the button for
“crushed” ice and begin dispensing again.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING

17
■Has the dispenser arm been held in too long? Ice will stop
dispensing when the arm is held in too long. Wait 3 minutes
for dispenser motor to reset before using again.
The water dispenser will not operate properly
■Freezer door closed completely? Close the door firmly. If it
does not close completely, see “The doors will not close
completely.”
■Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
■Is the water pressure at least 30 psi (207 kPa)? The water
pressure to the home determines the flow from the dispenser.
See “Water Supply Requirements.”
■Kink in the home water source line? Straighten the water
source line.
■New installation? Flush and fill the water system.
■Water filter installed on the refrigerator? The filter may be
clogged or incorrectly installed.
■Is a reverse osmosis water filtration system connected to
your cold water supply? See “Water Supply Requirements”
in either the Installation Instructions or the Use & Care Guide.
Water is leaking from the dispenser
NOTE: One or two drops of water after dispensing is normal.
■Glass not being held under the dispenser long enough?
Hold the glass under the dispenser 2 to 3 seconds after
releasing the dispenser lever.
■New installation? Flush the water system. See “Prepare the
Water System” or “Water and Ice Dispensers.”
■Recently changed water filter? Flush the water system. See
“Prepare the Water System” or “Water and Ice Dispensers.”
The dispenser water is not cool enough
NOTE: Water from the dispenser is chilled to only 50°F (10°C).
■New installation? Allow 24 hours after installation for the
water supply to cool completely.
■Recently dispensed large amount of water? Allow
24 hours for water supply to cool completely.
■Water not been recently dispensed? The first glass of water
may not be cool. Discard the first glass of water.
■Refrigerator connected to a cold water pipe? Make sure
the refrigerator is connected to a cold water pipe. See “Water
Supply Requirements.”
ASSISTANCE OR SERVICE
If you need assistance or service, first see the “Troubleshooting”
section. Additional help is available. Call us at 1-800-JENNAIR
(1-800-536-6247) from anywhere in the U.S.A., or write:
Jenn-Air Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Information may also be obtained by visiting our website at
www.jennair.com.
In Canada, for assistance, installation or service, call us at
1-800-807-6777, or write:
Jenn-Air Brand Home Appliances
Customer eXperience Centre
1901 Minnesota Court
Mississauga, Ontario L5N 3A7
In Canada, visit www.jennair.ca.
Please include a daytime phone number in your correspondence.
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your appliance to help
you obtain assistance or service if you ever need it. You will need
to know your complete model number and serial number. You can
find this information on the model and serial number label, located
on the inside wall of the refrigerator compartment.
Dealer name____________________________________________________
Serial number __________________________________________________
Address ________________________________________________________
Phone number__________________________________________________
Model number __________________________________________________
Purchase date __________________________________________________
ACCESSORIES
To order stainless steel cleaner or replacement filters, call
1-800-688-1100 and ask for the part number listed below or
contact your authorized Jenn-Air dealer. In Canada, call
1-800-807-6777.
Stainless Steel Cleaner and Polish:
Order Part #4396095
Replacement Water Filter:
Order Part #4396841 (T2RFWG2)

18
WATER FILTER CERTIFICATIONS

19
PERFORMANCE DATA SHEETS
Base Grille Water Filtration System
Model T2WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T2WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSI Standards 42 and 53.
Test Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.85 gpm (3.2 Lpm). Pressure = 60 psig (413.7 kPa).
Temp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
■It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
■Use replacement filter T2RFWG2, part #4396841.
2009 suggested retail price of $39.99 U.S.A./$43.99 Canada.
Prices are subject to change without notice.
Model T2WG2L: Style 1 – When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 – When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 – When the water filter status display changes from
“GOOD” to “ORDER,” order a new filter. When the filter indicator
reads “REPLACE,” it is recommended that you replace the filter.
Style 4 – Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T2WG2: Change the water filter cartridge every 6 months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6 months have passed, replace the water filter
cartridge more often.
■These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
■The product is for cold water use only.
■Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
■Refer to the “Warranty” section for the Manufacturer’s name,
address and telephone number.
■Refer to the “Warranty” section for the Manufacturer’s limited
warranty.
Application Guidelines/Water Supply Parameters
System tested and certified by NSF International against NSF/ANSI
Standard 42 for the reduction of Chlorine Taste and Odor, Particulate
Class II*; and against NSF/ANSI Standard 53 for the reduction of Mercury,
Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
Substance Reduction
Aesthetic Effects NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % Reduction Average % Reduction
Chlorine Taste/Odor
Particulate Class II*50% reduction
85% reduction 2.0182 mg/L 1333333 #/mL 2.0 mg/L ± 10% At least 10,000 particles/mL 0.06 mg/L 6600 #/mL** 0.0536 mg/L 2325 #/mL 97.03 99.51 97.34 99.83
Contaminant
Reduction NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % Reduction Average % Reduction
Lead: @ pH 6.5***
Lead: @ pH 8.5*** 0.010 mg/L 0.010 mg/L 0.1533 mg/L 0.1400 mg/L 0.15 mg/L ± 10% 0.15 mg/L ± 10% 0.0005 mg/L 0.0007 mg/L 0.0005 mg/L 0.0006 mg/L 99.67 99.50 99.67 99.57
Mercury: @ pH 6.5
Mercury: @ pH 8.5 0.002 mg/L 0.002 mg/L 0.0058 mg/L 0.0059 mg/L 0.006 mg/L ± 10% 0.006 mg/L ± 10% 0.0002 mg/L 0.0005 mg/L 0.0002 mg/L 0.0003 mg/L 96.54 91.57 96.54 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L ± 10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L 1.8 mg/L ± 10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L ± 10% 0.001 mg/L 0.001 mg/L 93.33 93.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L ± 10% 0.0400 mg/L 0.0213 mg/L 51.13 74.00
Water Supply
Water Pressure
Water Temperature
Service Flow Rate
City or Well
30 - 120 psi (207 - 827 kPa)
33° - 100°F (0.6° - 37.8°C)
0.85 gpm (3.2 Lpm) @ 60 psi
*
**
***
Class II particle size: 1 um to <5 um
Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
Compliant for Lead reduction requirements under NSF/ANSI Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a registered trademark of NSF International.

20
Base Grille Water Filtration System
Model T1WG2L/T2RFWG2 Capacity 200 Gallons (757 Liters)
Model T1WG2/T2RFWG2 Capacity 200 Gallons (757 Liters)
This system has been tested according to NSF/ANSI 42/53 for the reduction of the substances listed below. The concentration of the
indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water
leaving the system, as specified in NSF/ANSI 42/53.
Test Parameters: pH = 7.5 ± 0.5 unless otherwise noted. Flow = 0.5 gpm (1.9 Lpm). Pressure = 60 psig (413.7 kPa).
Temp. = 68°F to 71.6°F (20°C to 22°C). Rated service capacity = 200 gallons (757 liters).
■It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
■Use replacement filter T2RFWG2, part #4396841.
2009 suggested retail price of $39.99 U.S.A./$43.99 Canada.
Prices are subject to change without notice.
Model T1WG2L: Style 1 – When the filter indicator reads 10%,
order a new filter. When the indicator reads 0%, it is
recommended that you replace the filter.
Style 2 – When the filter indicator changes from green to yellow,
order a new filter. When the indicator changes from yellow to red,
it is recommended that you replace the filter.
Style 3 – When the water filter status display changes from
“GOOD” to “ORDER,” order a new filter. When the filter indicator
reads “REPLACE,” it is recommended that you replace the filter.
Style 4 – Press FILTER to check the status of your water filter. If
the filter indicator light is yellow, order a new filter. If the filter
indicator light is red, it is recommended that you replace the filter.
Model T1WG2: Change the water filter cartridge every 6 months.
If the water flow to the water dispenser or ice maker decreases
noticeably before 6 months have passed, replace the water filter
cartridge more often.
■These contaminants are not necessarily in your water supply.
While testing was performed under standard laboratory
conditions, actual performance may vary.
■The product is for cold water use only.
■Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
system.
■Refer to the “Warranty” section for the Manufacturer’s name,
address and telephone number.
■Refer to the “Warranty” section for the Manufacturer’s limited
warranty.
Application Guidelines/Water Supply Parameters
System tested and certified by NSF International against NSF/ANSI
Standard 42 for the reduction of Chlorine Taste and Odor, Particulate
Class II*; and against NSF/ANSI Standard 53 for the reduction of
Mercury, Benzene, Toxaphene, O-dichlorobenzene, and Carbofuran.
Substance Reduction
Aesthetic Effects NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % Reduction Average % Reduction
Chlorine Taste/Odor
Particulate Class II*50% reduction
85% reduction 2.0182 mg/L 1333333 #/mL 2.0 mg/L ± 10% At least 10,000 particles/mL 0.06 mg/L 6600 #/mL** 0.0536 mg/L 2325 #/mL 97.03 99.51 97.34 99.83
Contaminant
Reduction NSF Reduction Requirements Average Influent Influent Challenge Concentration Maximum Effluent Average Effluent Minimum % Reduction Average % Reduction
Lead: @ pH 6.5***
Lead: @ pH 8.5*** 0.010 mg/L 0.010 mg/L 0.1533 mg/L 0.1400 mg/L 0.15 mg/L ± 10% 0.15 mg/L ± 10% 0.0005 mg/L 0.0007 mg/L 0.0005 mg/L 0.0006 mg/L 99.67 99.50 99.67 99.57
Mercury: @ pH 6.5
Mercury: @ pH 8.5 0.002 mg/L 0.002 mg/L 0.0058 mg/L 0.0059 mg/L 0.006 mg/L ± 10% 0.006 mg/L ± 10% 0.0002 mg/L 0.0005 mg/L 0.0002 mg/L 0.0003 mg/L 96.54 91.57 96.54 94.92
Benzene 0.005 mg/L 0.0154 mg/L 0.015 mg/L ± 10% 0.0012 mg/L 0.0006 mg/L 92.22 96.34
O-Dichlorobenzene 0.6 mg/L 1.7571 mg/L 1.8 mg/L ± 10% 0.0250 mg/L 0.0066 mg/L 98.58 99.63
Toxaphene 0.003 mg/L 0.015 mg/L 0.015 mg/L ± 10% 0.001 mg/L 0.001 mg/L 93.33 93.33
Carbofuran 0.04 mg/L 0.0819 mg/L 0.08 mg/L ± 10% 0.0400 mg/L 0.0213 mg/L 51.13 74.00
Water Supply
Water Pressure
Water Temperature
Service Flow Rate
City or Well
30 - 120 psi (207 - 827 kPa)
33° - 100°F (0.6° - 37.8°C)
0.5 gpm (1.9 Lpm) @ 60 psi
*
**
***
Class II particle size: 1 um to <5 um
Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
Compliant for Lead reduction requirements under NSF/ANSI Standard 53 as tested by Pace Analytical Services, Inc.
® NSF is a registered trademark of NSF International.
