Jensen JE1913AC2 User manual

English
Français
Veuillez lire attentivement ce manuel avant d'utiliser le téléviseur et
conservez-le en vue d’une référence ultérieure.

1
English
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (includ-
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
-
paratus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. WARNING: To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or
Moisture.
17. The mains plug or appliance coupler shall remain readily operable.
16. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids such as vases,
shall be placed on the apparatus.
18. Use in outdoor: This TV is not designed for outdoors installation. Do not expose the TV to rain, as it may
become damaged.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Safety:
TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLEPARTS ARE INSIDE. REFER TO QUALIFIED
PERSONNEL ONLY.
intended to alert the user to thepresence of uninsulated “dangerous voltage” within the product’s
sk of electric shock to persons.
Instruction: The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and servicing instructions in the literature accompanying the
appliance.
Important Safety Instructions

2
English
Safety Instructions
Important safeguards for you and your new TV
Observing the simple precautions discussed in this booklet will provide you with many years of enjoyment and safe
operation.
This product complies with all applicable U.S.A Federal safety requirements, and those of the Canadian Standards
Association.
1. Read & Follow Instructions
All safety and operating instructions should be read and followed before the TV is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Heed Warnings
All warnings on the TV and in the operating instructions should be adhered to.
4. Cleaning
Unplug the TV from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a soft and
slightly damp cloth for cleaning.
5. Water and Moisture
Do not use this TV near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet base-
ment, or near a swimming pool.
6. Accessories Carts and Stands
Do not place this TV on a slippery or tilted surface, or on an unstable cart, stand, or table. The TV may slide or fall,
causing serious injury to a child or adult, and serious damage to the TV.
7. Transporting the Television
A TV and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause
the TV and cart combination to overturn.
8. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV and to protect
it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by
placing the TV on a bed, sofa, rug, or other similar surface. The TV should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided.
9. Power Sources
This TV should be operated only from the type of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your electronics retailer or local power company.
10. Power-Cord Polarization
This TV is equipped with two pin plug with polarity power code. This is a safety feature. If you unable to insert the plug
into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the ground-
ing-type plug.
11. Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit
from the TV.
12. Lightning
For added protection for the TV during a lightning storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV
from lightning and power-line surges.

3
English
Safety Instructions
13. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the TV be sure the antenna or cable system is grounded so as
to provide some protection against voltage surges and built up static charges. Article 810 of the National Electrical
Code (U.S.A.), ANSI/ NFPA 70 provides information with regard to proper grounding of the mast and supporting struc-
ture, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-
discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
Example of Grounding According to National
Electrical Code Instructions
NEC - National Electrical Code
14. Power Lines
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall on to power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
15. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock. Never spill liquid of any kind on or inside the TV.
17. Servicing
Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service
Unplug from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the TV has been exposed to rain or water.
d. If the TV does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the product to its normal operation.
e. If the TV has been dropped or the cabinet has been damaged.
f. If the TV exhibits a distinct change in performance.
Ground Clamp Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Electric Service
Equipment
Power Service Grounding
Electrode System (NEC
Art 250, Part H)

4
English
Safety Instructions
19. Replacement Parts
When replacement parts are required, be sure that only an authorized service technician has used replacement parts
specified by ASA Electronics or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards and void any warranty.
20. Safety Check
Upon completion of any service or repairs to this TV, ask the service technician to perform safety checks to determine
whether the product is in proper operating condition.
21. Wall Mounting
The TV should be mounted to a wall only by a professional. The TV may slide or fall, causing serious injury to a child
or adult, and serious damage to the product. Warranty shall be voided.
22. Heat
The TV should be situated away from heat sources such as radiators, heat registers, stoves, or other products (includ-
ing amplifiers) that produce heat.
NOTE TO CABLE/TV INSTALLER:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code
(U.S. A). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of the cable entry as practical.
FCC REGULATORY INFORMATION:
This television has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. If installed and used not in accordance with the instructions, this television would radiate radio energy
frequency and may cause harmful interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this television does cause interference to other electronic equipment,
which can be determined by turning the television off and on, then the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and television.
- Connect the equipment into an outlet on a circuit different from that to which the television is connected.
- Consult your dealer or an experienced radio/TV technician for assistance.
Any changes or modifications not expressly approved by the party responsible for compliance may void the user’s
authority to operate the equipment.

5
English
Table of Contents
Important Safety Instructions.........................................................................................................................................1
Table of Contents ..........................................................................................................................................................5
Remote Control
Overview .......................................................................................................................................................................6
TV Overview
Front & Side Panel -19”8
Front & Side Panel -26”...............................................................................................................................................
...............................................................................................................................................
9
Front & Side Panel -32”..............................................................................................................................................
Rear Panel -19”
............................................................................................................................................................11
Rear Panel -26”& 32”
.......................................................................................................................................................
12
10
Installation
Connection to Antenna & Cable/Satellite Box .............................................................................................................13
Connection to HDMI Input ...........................................................................................................................................14
Connection to Component YPbPr Input ......................................................................................................................16
Connection to Composite Input ...................................................................................................................................17
Connection to a Personal Computer ...........................................................................................................................18
Connection to a Home Theater System ......................................................................................................................19
TV Setup
Initial Setup Wizard .....................................................................................................................................................20
TV Channel Setup & Channel Auto Scan....................................................................................................................21
Picture Settings
Contrast.......................................................................................................................................................................22
Brightness ...................................................................................................................................................................22
Color............................................................................................................................................................................22
Tint...............................................................................................................................................................................22
Sharpness ...................................................................................................................................................................22
Color Mode ..................................................................................................................................................................22
Audio Settings
Bass ............................................................................................................................................................................23
Treble ..........................................................................................................................................................................23
Balance ........................................................................................................................................................................23
TV Speaker .................................................................................................................................................................23
SPDIF Type.................................................................................................................................................................23
AVC ..........................................................................................................................................................................23
Audio Language ..........................................................................................................................................................23
Date & Time Settings..............................................................................................................................................24
Setup Settings
Menu Languages .......................................................................................................................................................25
Transparency .............................................................................................................................................................25
Zoom Mode ................................................................................................................................................................25
Restore Default ..........................................................................................................................................................25
Noise Reduction ..........................................................................................................................................................25
Closed Captions .......................................................................................................................................................26
Advanced Settings ..................................................................................................................................................27
Parental Control .......................................................................................................................................................28
TV Settings
Channel settings. .........................................................................................................................................................30
Scale Modes ..............................................................................................................................................................31
USB Modes .................................................................................................................................................................32
.......................................................................................................................................................33
.......................................................................................................................................................34
.......................................................................................................................................................35
Troubleshooting ..........................................................................................................................................................36
-19 ”
-26 ”
-32 ”

6
English
Remote Control Overview
TV DVD
POWER
1
++
--
2
5
4
7
0
8
-/--
3
6
9
RETURN
MUTE
SOURCE
EXIT
EPG
MENU
SLEEP SCALE PICTURE
C-LIST
SETUP
ZOOM SUB-T DISP
RPT
TITLE
SOUND
EQ
AUDIO
F-LIST MTS/SAP
CC
T/F
ENTER
INFO
CH VOL
10
12 1413
11
9
65
3
21
4
8
15
16
20
24 25 26 27
30
28 29
31
32 33
34 37
38
39 40
36
35
232221
18 1917
7
TV Activate TV Mode
POWER On / off for TV and DVD
DVD Activate DVD Mode
PREVIOUS
FAST REVERSE
FAST FORWARD
NEXT
EJECT(DVD)
STOP
PLAY/PAUSE
RPT Repeat Selection
T/F
ZOOM(DVD)
SUB-T(DVD)
DISP(DVD) Display Time or chapter information
SET UP(DVD)
AUDIO (DVD)
EQ (DVD)
TITLE (DVD)
C-LIST Press C-LIST button to display the channel list
F-LIST Press this button to display the favourite list
MTS/SAP Press MTS/SAP to select Stereo,SAP or Mono
SOUND Press SOUND to cycle select sound types:Standard/Music/Movie/ Personal
SLEEP Cycles through the LED sleep time::off/5/10/15/30/45/60/90/120/180/240
minutes.
CC Close Caption
SCALE cycles among scale mode:Wide,Zoom,Cinema,Nomal.
PICTURE Press PICTURE to cycle select picture types:Standard/ Dynamic/ Soft/
Personal
MENU Displays the OSD menu on the screen
NAVIGATION Move up, down,left or right
INFO Press INFO to display a variety of information obout current channel
ENTER Press ENTER to confirm your opeartion
EPG Display the program guid
EXIT
CH+/CH- Increase or Decrease channel
SOURCE Displays all inputs
MUTE Press once mutes audio,press again to restore audio
VOL+/VOL- Increase or decrease volume
NUMERIC KEYS
-/-- Digital channel select
RETURE Return to previously viewed channel
①
②
③
④
⑤
⑥
⑦
⑧
⑨
10
12
11
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
32
31
30
33
35
36
38
37
39
40
34
29
Function of remote control buttons

7
English
Remote Control Overview
BUTTON
ENTER OK
MENU
UP
DOWN
LEFT LEFT
RIGHT RIGHT
DOWN
UP
MENU
NEXT
RPT RPT
ZOOM
NEXT
INFO
MUTE MUTE
POWER
RETURN
CH+
VOL+ VOL+
VOL- VOL-
CH-
POWER
TV-FUNCTION DVD-FUNCTION BUTTON TV-FUNCTION DVD-FUNCTION BUTTON TV-FUNCTION DVD-FUNCTION
CH
+
-
VOL
+
-
RETURN
MUTE
POWER
MENU
INFO
ENTER
SOURCE SOURCE
SOURCE
SCALE
SCALE
MTS/SAP
EXIT
EXIT
MTS/SAP
C-LIST
C-LIST
SOUND SOUND
F-LIST
F-LIST
T/F T/F
EJECT
EPG STOP
PLAY-PAUSE
FAST-REVERSE
FAST-FORWARD FAST-FORWARD
FAST-REVERSE
PREVIOUS
PREVIOUS
PLAY-PAUSE
STOP
EPG
1
11
222
333
444
555
666
777
888
999
000
RPT
ZOOM
SUB-T
SUB-T
DISP
DISP
SETUP
SETUP
AUDIO
AUDIO
EQ EQ
TITLE TITLE
CC CC
SLEEP SLEEP
-/--
-/--
NOTE:DVD functions are intended for JENSEN DVD players only.
See your JENSEN DVD manual for more information.

8
English
POWERMENU CH- CH+ VOL+VOL-source
TV Overview
A Blue LED illuminates when the
television is connected to AC power.
IR Receiver
1. Source - After connecting your DVD, cable box, etc. select the appropriate input source to view. Press the
SOURCE button to display the input options.Continue to press/release the Source button to select .
INPUT SOURCE
TV
AV
Component
HDMI 1
HDMI 2
VGA
USB
2. Menu - Press the MENU button to display. Press VOL+ to select from the 6 menu options available. Press
the CH+ / CH- buttons to select a feature from the selected menu then press the VOL+/VOL- buttons to adjust
the volume settings.
3. Channel (CH- / CH+) - Press the CH- / CH+ buttons to select a channel in the TV mode.
4. Volume (VOL- / VOL+) - Press the VOL- / VOL+ buttons to adjust the volume up or down.
5. Power - Press the POWER button to turn the TV ON/ OFF (standby). The screen image will appear within
a few seconds, and the Blue LED will turn off.
Front & Side Panel-19”
nopqr

9
English
POWERMENU CH- CH+ VOL+VOL-
SOURCE
TV Overview
A Blue LED illuminates when the
television is connected to AC power.
IR Receiver
1. Source - After connecting your DVD, cable box, etc. select the appropriate
input source to view. Press the SOURCE button to display the input options.
Press the CH+ / CH- buttons to highlight the input source and press the VOL+
button to select.
INPUT SOURCE
2. Menu - Press the MENU button to display. Press VOL+ to select from the
6 menu options available. Press the CH+ / CH- buttons to select a feature
from the selected menu then press the VOL+/VOL- buttons to adjust the vol-
ume settings.
3. Channel (CH- / CH+) - Press the CH- / CH+ buttons to select a channel
in the TV mode.
4. Volume (VOL- / VOL+) - Press the VOL- / VOL+ buttons to adjust the
volume up or down.
5. Power - Press the POWER button to turn the TV ON/ OFF (standby).
The screen image will appear within a few seconds, and the Blue LED will
turn off.
Front & Side Panel-26”
n
o
p
q
r
TV
AV
Component
HDMI 1
HDMI 2
HDMI3
VGA
USB
