Jensen Eldora User manual

8122019-3-kv
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
DANGER!
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut o gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area
immediately.
• After leaving the area, call your
gas supplier or fire department.
Failure to follow these instructions
could result in fire or explosion,
which could cause property damage,
personal injury, or death.
!DANGER !WARNING: FOR OUTDOOR USE ONLY.
Installation and service must be performed by a
qualified installer, service agency, or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
!
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may result
causing property damage, serious injury, or loss of life.
!
WARNING: Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of this
or any other appliance.
An LP gas tank not connected for use shall not be
stored in the vicinity of this or any other appliance.
132LP Eldora Fire Bowl
Owner’s Manual

TABLE OF CONTENTS
Important Safety Information 3
Propane (LP) Gas Dangers and Warnings 5
Parts List 6
Assembly Instructions 7
Pre-Use Instructions 9
Lighting Instructions 10
Care and Cleaning 11
Spider and Insect Warning 12
Tips and Troubleshooting 13
Technical Parts List 14
Warranty and Return Policies 15
SPECIFICATIONS
Product Name
Eldora 42” Fire Bowl
Model No.
132LP
Rated Heat Output
60,000 BTUs/hr
Type of Gas
Propane (LP)
Gas Supply
20 lb LP Gas Tank
2
ATTENTION
Please register your fireplace for recall notifications, proof of ownership
and quality assurance at https://www.realflame.com/registration.

IMPORTANT SAFETY INFORMATION
General Warnings
•Children and adults should be alerted to the hazards of high surface temperatures
and should stay away to avoid burns or clothing ignition.
•Children should be carefully supervised when in the area of the fireplace.
•Clothing or other flammable materials should not be hung from the fireplace or placed
on or near the fireplace.
•Any guard or other protective device removed for servicing the fireplace must be
replaced prior to operating the fireplace.
• Installation and service must be performed by a qualified service agency or gas
supplier. Real Flame recommends using professionals who are certified in the U.S.
by the National Fireplace Institute®(NFI) as NFI Gas Specialists.
• More frequent cleaning may be required as necessary. It is imperative that the
control compartment, burners, and circulating air passageways of the appliance
are kept clean.
• Do not store or use gasoline or other flammable vapors or liquids within 25 feet (7.62 m)
of this fireplace or any other appliance.
• Do not store combustible materials in the fireplace enclosure. This includes LP gas tanks.
If the fireplace is designed to use a hidden LP gas tank, the LP gas tank should be
properly secured in the designated tank holder under the fireplace. Do not store extra
LP gas tanks under the fireplace.
• Be sure to protect the hose and its components from any hot surfaces. It is dangerous
to allow the hose to come into contact with any hot surface.
•The LP gas tank should never be operated or stored on its side or upside down.
• Keep all parts of the fireplace clean including the burner and hose assembly. For more
information on cleaning your fireplace please refer to the “Care and Cleaning” section
of this manual.
• Do not use this fireplace if any part has been under water. Immediately call a qualified
service technician to inspect the fireplace and replace any part of the system that has
been under water.
• Do not use this fireplace for cooking.
• Do not pour water into the fireplace.
• Do not attempt to move or store this fireplace until all parts are cool.
• Always shut o the gas supply at the source and disconnect the hose when the fireplace
is not in use.
•Any alteration of this fireplace that is not specifically directed in the owner’s manual
will void the manufacturer’s warranty. This includes the use of unapproved filler materials.
3

Installation Warnings
•Minimum clearance from the fireplace to combustible materials is 48 inches (121.9 cm) on
all sides. Do not place this fireplace under any overhead structure or vegetation.
•The normal LP inlet pressure for this fireplace is 11.0” W.C. (2.74 kPa). Maximum inlet pressure
is 13.0” W.C. (3.23 kPa). Minimum inlet pressure is 8” W.C. (1.99 kPa).
•Do not remove the feet from this fireplace.
•Do not place the fireplace on anything that blocks or seals the gap between the fireplace and the ground.
•Do not permanently secure the fireplace in any way or to any surfaces.
•Do not bury the hose. You must be able to visually inspect the hose for damage before each use.
•Do not coil or hide the hose under the fireplace. The hose could be damaged if it touches hot surfaces.
Set Up Warnings
•Prior to each operation, check the hose assembly for evidence of excessive abrasion, wear or
damage. Use a handheld mirror, if necessary, to see the hose sections located below the unit.
•If the hose assembly is damaged, cracked, or cut, it must be replaced before using the fireplace.
The hose assembly must be replaced with a hose assembly specified by Real Flame.
Please contact Real Flame Customer Service at 1-800-654-1704 for assistance.
•Place the hose out of the pathways where people may trip over it. Do not place the hose
in areas where it may be accidentally damaged.
•Before each use, examine the burner and its components for dirt and debris. If cleaning is required,
use a pipe cleaning brush and compressed air. Also examine the area around the burner.
Any dirt or foreign material, such as spider webs, nests, leaves, etc., should be removed. If it is
evident that the burner is damaged, the fireplace must not be used, and the burner assembly
must be replaced. Please contact Real Flame Customer Service at 1-800-654-1704 for support.
In-Use Warnings
•NEVER LEAVE this fireplace unattended when in use.
•Do not burn solid fuels, such as charcoal briquettes, lump charcoal, manufactured logs, trash, leaves
paper, cardboard, any type of natural or treated wood, or any other materials in this fireplace.
•The use of alcohol, prescription or non-prescription drugs may impair your ability to safely
operate this fireplace.
•Always use in accordance with all applicable local, state, and national codes. Contact your
local fire department for details on outdoor burning.
•Do not use in windy conditions. Winds above 10 mph (16.09 kph) may cause the flame to extinguish.
•Some surfaces of this fireplace may become hot during use. Be careful and do not touch
surfaces until the unit has cooled.
•Do not attempt to disconnect the gas supply from the fireplace when the unit is in use.
•Do not sit on the fireplace.
4
IMPORTANT SAFETY INFORMATION

PROPANE (LP) GAS DANGERS AND WARNINGS
!WARNING
LP gas is flammable and hazardous if handled improperly. Become aware of its characteristics before
using any LP gas product. Failure to understand and follow these warnings or any directions and
warnings provided by your LP gas supplier may result in property damage, serious injury, or death.
!DANGER
An LP gas tank should never be placed on its side. Doing so may cause liquid propane to leak.
This could cause a fast buildup of LP gas and could lead to property damage, serious injury, or death.
LP Gas Characteristics
•LP gas is flammable, explosive under pressure, heavier than air and settles in pools in low
areas. Pooled gas may ignite causing a fire or explosion which could cause property
damage, serious injury, or death.
•In its natural state, LP gas has no odor. For your safety, a scent has been added.
•Contact with LP gas could burn your skin.
LP Gas Tank Information
•LP gas tanks should be filled only by a certified LP gas dealer.
•Never use an LP gas tank with a damaged body, valve, collar or footing.
•Dented or rusted LP tanks may be hazardous and should be checked by your LP gas supplier.
•The LP gas supply tank must be constructed and marked in accordance with The Specifications
for LP Gas Tanks of The U.S. Department of Transportation (DOT) or The National Standard
of Canada, CAN/CSA-B339, LP Gas Tanks, Spheres and Tubes for The Transportation of
Dangerous Goods; and Commission.
• LP gas tanks must be arranged for vapor withdrawal.
•LP gas tanks must have a listed overfilling prevention device (OPD) and a QCCI or Type I
(CGA810) LP gas tank connection.
•The LP gas tank must contain a shut-o valve as specified in The Standard for
Compressed Gas Cylinder Valve Outlet and Inlet Connection, ANSI/CGA-V-1-1977, CSA B96.
•Never attempt to attach this fireplace to the self-contained LP gas system of a camper,
trailer, motor home or house.
•Hand-turn the manual gas control valve on your LP gas tank. Never use tools. If the valve
will not turn by hand, do not try to repair it. Call a certified gas technician.
• The use of force or any attempt at amateur repair may cause a fire or explosion.
LP Gas Tank Storage and Safety
•LP gas tanks must be stored upright and outdoors in a well-ventilated area out of reach of children.
•Never store an LP gas tank in an enclosed area, such as a shed or garage. Leaking gas could build
up in these areas and may result in an explosion.
•Do not store LP gas tanks near any source of flame or ignition.
•Never store an LP gas tank in direct sunlight or where temperatures can reach 125°F (51.67°C) or higher.
•Never keep a filled LP gas tank in a hot car or car trunk. Heat will cause the gas pressure to
increase, which may open the relief valve and allow gas to escape.
•Place the dust cap on the LP gas tank valve outlet when the LP gas is not in use. Only use
the dust cap that is provided with the LP gas tank. Other types of caps or plugs may
result in leakage of LP gas.
•The LP gas tank should not be dropped or handled roughly.
5

PARTS LIST
6
1
3
2
4
5
6
ITEM JCo NUMBER QUANTITY
Fire Bowl Body N/A 1
LP Hose and Regulator 96000002 1
Black Lava Rock 100240120J 2
Protective Cover 01320101 1
Key 11110004 1
Tank Seat 95600940 1
1
2
3
4
5
6

7
ASSEMBLY INSTRUCTIONS
1. Place the filler material into the burner pan by hand. To avoid clogging the burner with dust
do not dump the bag into the burner pan. Position the filler across the burner pan to a level
that is 1 inch (2.54 cm) above the burner tube. Make sure you do not block the igniter housing
with the filler material to ensure proper ignition and operation.
If using glass filler, Real Flame suggests first placing a layer of lava rock in the burner pan
to improve airflow.
Filler Material Warning
•Do not overfill the burner area with rock or glass filler; use only the specified amount. The
depth of the filler should not be more than 1 inch (2.54 cm) above the burner tube. Only
Real Flame filler products have been certified and tested for safe use with this Real Flame
fireplace. Using other filler material may result in increased popping and cracking or increased
carbon monoxide emissions.
•Do not light or use this fireplace if the filler is wet. Ensure filler is completely dry before lighting.
Intense heat can cause wet filler to explode and hit someone causing property damage,
serious injury, or death.
•Keep away from the fireplace for at least 20 minutes during initial start-up as filler could
retain moisture from manufacturing and shipping.

8
ASSEMBLY INSTRUCTIONS
2. Place the tank seat on the ground and place a 20 lb LP gas tank into the designated area
in the center. Once the tank is level and steady, tighten down the screw on the side of the
tank seat to secure the tank in place.
3. Connect the LP Gas Tank
Before connection, be sure there is no debris caught in the
collar of the LP gas tank, the regulator valve, the burner
tube, or the burner ports.
Connect the gas line to the tank by turning the connection
knob clockwise. Hand-tighten only.
Disconnect the LP Gas Tank
To disconnect the LP gas tank, make sure the valve on the
LP gas tank is completely closed.
Disconnect the connection knob by turning it counterclockwise
until it is detached from the valve.
!WARNING
Place the LP gas tank 56 inches (142.2 cm) away from the
fireplace and position the hose away from pathways or
places where it could become damaged.
Watch your step while moving between the tank and the
fireplace. Be careful not to trip on the hose.
56”

9
PRE-USE INSTRUCTIONS
!WARNING
Before using this fireplace, make sure you have read, understand, and are following all information
provided in this manual. Failure to follow these instructions could cause property damage,
serious injury, or death.
Checking for Leaks
1. Make a leak check solution by mixing 1 part dishwashing soap with 3 parts water in a spray bottle.
2. Make sure the control knob on the fireplace is in the “OFF” position, then connect your
fireplace to the LP gas tank and turn the tank’s valve on.
3. Spray the leak solution on the valve connections, paying particular attention to the areas
indicated by arrows in the diagrams below.
4. If bubbles appear, turn the LP gas tank o, disconnect the tank, and inspect all connections,
making sure threads are clear of debris. Reconnect the LP gas tank and retest. If you continue
to see bubbles, turn the LP gas tank o. Disconnect the hose and call Real Flame Customer
Service at 1-800-654-1704 for assistance.
5. If no bubbles appear after 1 minute, wipe away excess leak solution and proceed to
“Lighting Instructions.”
Pay close attention to the areas indicated by the arrows.

10
LIGHTING INSTRUCTIONS
Lighting the Fireplace
1. Read and understand all operating instructions before lighting.
2. Before beginning, make sure the key valve is in the “OFF” position.
3. Connect the gas line to the tank by turning the connection knob clockwise. Hand-tighten only.
4. Slowly open the valve on your LP gas tank.
5. Position a burning long match or long burning butane lighter near the side of the burner.
6. Insert the key and slowly turn the key valve counterclockwise toward the “ON” position.
7. Once the burner has been lit, remove the match/lighter. Observe the flame and make sure
that all of the burner ports are lit.
8. Adjust the flame to the desired height using the key valve.
WARNING: If ignition does not occur in 15 seconds, turn the key valve to the “OFF”
position and turn the gas o at its source. Make sure there is no source of ignition around
the fireplace and wait at least 5 minutes until the gas has cleared to repeat the lighting
procedure. Failure to do so could result in a large flashback of collected gas, causing
property damage, serious injury, or death.
Shut-O Instructions
1. Turn the key valve clockwise to the “OFF” position.
2. Once the flame is out, remove the key and close the valve on the LP gas tank to shut o gas flow.
3. Store the key in a safe location. If the key is lost please contact Real Flame Customer Service at
1-800-654-1704 for a replacement.
Flame Height
8-14”
(20.3-35.5 cm)
OFF
ON
KEY VALVE

CARE AND CLEANING
Inspecting Your Fireplace
!WARNING
DO NOT inspect, clean, move or store your fireplace until the flames are COMPLETELY out
and all parts are cool to the touch.
Your fireplace should be inspected regularly to ensure that it is safe to use and to extend the life of its parts.
Inspect your fireplace:
1. Make sure all parts are securely fastened in place. If a part moves when touched, check its
connection points to see if they are loose.
2. Check all connections for leaks using the method described in the “Checking for Leaks” section
of this manual.
3. Visually check all components for any signs of damage, rust, or excessive wear.
4. If damage or leaks of any kind are found. DO NOT operate the fireplace until the proper
repairs have been made.
!WARNING
DO NOT tamper with this fireplace. This is dangerous and will void the warranty.
Repairs and modifications must be approved by Real Flame and completed by a
professional gas technician.
This fireplace has been tested and certified by a third party certification agency based on its
specific and unique parts. Installing any other parts will void both the certification and the warranty.
For approved replacement parts contact Real Flame Customer Service at 1-800-654-1704.
General Care and Cleaning
After repeated use, a slight discoloration or weathering of the fireplace finish may occur. Your
fireplace should be cleaned regularly to ensure safe use and extend its life.
General Cleaning
Make a cleaning solution using a mild soap mixed with water. Use a soft cloth to wipe down
exterior surfaces and rinse with clean water. Never use oven cleaners or abrasive solvents as
these will damage the fireplace.
Burner
The burner should be kept clean to ensure proper operation. Clogged burner ports may be
cleared with a paper clip or pin. Debris in the burner tube can be cleaned using compressed
air or a pipe cleaning brush.
Soot
After use it is possible for soot to develop on some surfaces. This soot deposit will usually
come o with water and mild soap.
Storage
1. Turn the LP gas supply o at the tank. Remove the LP gas tank and store it in a cool, dry
location, outside and away from children.
2. Secure all loose filler material or parts.
3. Cover the fireplace when not in use and do not allow water to pool on the cover surface.
Covering the fireplace will help to protect the internal components from dirt and debris
and prevent the finish from fading.
4. Store the fireplace in a cool, dry location away from children and pets.
11

12
SPIDER AND INSECT WARNING
Spiders or other insects may build webs or nests in your fireplace burner tube which can obstruct
or block the flow of gas.
Some of the gas may back up in the burner tube and cause a flashback (a fire in the burner tube
or underneath the fireplace), which could result in property damage, serious injury, or death.
Check and clean the burner tube periodically using a pipe cleaning brush (shown below) and
compressed air available at any hardware store.
Example of pipe cleaning
brush available at local
hardware store.
Burner Ports
Possible Debris
Possible Debris
Example of a typical burner tube.
Your exact burner tube may vary.

13
TIPS AND TROUBLESHOOTING
If the Fireplace Will Not Ignite or Stay Lit
Make sure the gas tank is fully open by twisting the knob counterclockwise and that the
connection between the hose and the tank is correct. Verify that the key valve is not
stripped out and that the valve is opening and closing. Make sure the hose does not have
any kinks or sharp bends.
Other Common Problems
Clogged or Obstructed Burner
It is common for bugs, especially spiders, to make webs or nests inside of burner tubes. If it
seems like you are getting low or no gas flow, visually check all openings in the burner for
signs of clogs. If you see anything clogging the burner using a pipe cleaner or compressed
air to remove the debris.
Out of Gas
Be sure your LP gas tank is not empty. Low tanks can result in lower flames.
Cold Temperatures
Cold temperatures outside may result in lower LP gas tank pressures causing the flames to
be lower. Do not use your fireplace in extreme temperature conditions. Allow the temperature
of your LP gas tank to rise and as the pressure in the LP gas tank increases the flame size will
increase. NEVER heat your LP gas tank; allow it to warm up naturally.
High Winds
Your fireplace is designed to operate in winds up to 10 mph (16.09 kph). High winds may
cause the flame to blow out. Do not operate your fireplace in high wind conditions.
If you continue to have problems with your fireplace please
contact Real Flame Customer Service at 1-800-654-1704.

TECHNICAL PARTS LIST
14
Burner
Kit
Key
11110004
Foot x 4
115010003
Protective Cover
01320101
Lava Rock
100240120J
LP Hose and Regulator
96000002
Tank Seat
95600940

WARRANTY AND RETURN POLICIES
06272019-3
Real Flame®
7800 Northwestern Ave.
Racine, WI 53406
USA
Warranty
Real Flame® Company warrants the body and internal components of this Real Flame gas fireplace to
be free from defects under normal use with a limited 2 year warranty from the date of purchase. The
burner tube and nozzles carry a lifetime warranty. In the event of defects Real Flame will, at its option,
replace the defective product or refund the purchase price. The foregoing is the exclusive remedy and
Real Flame disclaims all other warranties, including any implied warranty of merchantability or fitness
for a particular purpose. In addition, Real Flame will not be responsible for consequential damages in
excess of the purchase price of the product on which such liability is based.
Return Policy
You may return your purchase within 90 days of receipt. No refunds will be issued for incomplete
or unauthorized returns. All returned products must be 100% complete, adequately packaged in
original packaging and in resalable condition. Products that have been assembled or modified will not
be eligible for return. All items must be returned in their entirety, meaning all items included must be
returned together. No returns or exchanges on discontinued items. Please begin the return process
by contacting the store or company where you bought your Real Flame item.
Replacement Parts
In the event that an item has been lost or damaged, either by the manufacturer or in shipping, you
may request a replacement within 30 days of receipt. Replacement parts are not available for all units
and only given at Real Flame’s discretion. We will assess any damage and find a solution, which
could include shipping you a replacement. No replacements are available for discontinued items or
repackaged (open box) products. Please call Real Flame Customer Service at 1-800-654-1704 for replacement
parts before returning the damaged item. Please have the following information (which can be found
in your instruction manual) ready before you call Customer Service:
• Model number of item
• 4-8 digit part number
• Shipping address
• A picture of the damaged item may be requested. Pictures should be sent to custserv@realflame.com.
Incorrect Order Received
If you received something other than what you ordered, please contact Real Flame Customer Service at
1-800-654-1704 within 48 hours of receiving the item.
Refer to www.realflame.com for our complete return guidelines and policies.
Please register your fireplace for recall notifications, proof of ownership and quality assurance at
https://www.realflame.com/registration.
Real Flame Customer Service
USA: 1-800-654-1704
Canada: 1-800-363-6443
custserv@realflame.com
15

8122019-3-kv
RISQUE DE MONOXYDE DE CARBONE
Cet appareil peut produire du monoxyde de carbone qui n'a pas d'odeur.
Son utilisation dans un espace clos peut vous tuer.
Ne jamais utiliser cet appareil dans un espace clos tel qu'une caravane,
une tente, une voiture ou une maison.
DANGER!
!DANGER !AVERTISSEMENT : USAGE EXTÉRIEUR UNIQUEMENT.
!
!
RISQUES D’INCENDIE ET D'EXPLOSION
En cas de présence d’odeur de gaz :
• Couper l'alimentation en gaz vers
l'appareil.
• Éteindre toute flamme nue.
• Si l'odeur persiste, quitter immédi-
atement l’endroit.
• Après avoir quitté les lieux, appeler
votre fournisseur de gaz ou le service
d'incendie. Si ces précautions ne sont
pas respectées, cela pourrait pro-
voquer un incendie ou une explosion,
pouvant causer des dommages
matériels, des blessures ou la mort.
L'installation et l'entretien doivent être eectués par un installa-
teur qualifié, un service d’entretien ou le fournisseur de gaz.
INSTALLATEUR : Laisser ce manuel avec l'appareil.
CONSOMMATEUR : Conserver ce manuel pour référence
future.
AVERTISSEMENT : Si les informations contenues dans
ce manuel ne sont pas suivies à la lettre, un incendie ou
une explosion pourrait survenir et entrainer des
dommages matériels, des blessures graves ou la mort.
AVERTISSEMENT : Ne pas entreposer et ne pas utiliser
d’essence ou d’autres liquides ou vapeurs inflammables à
proximité de cet appareil ou de tout autre appareil.
Un réservoir de GPL non raccordé pour être utilisé ne
doit pas être entreposé à proximité de cet appareil ou
de tout autre appareil.
132LP Eldora Fire Bowl
Owner’s Manual

TABLE DES MATIÈRES
Informations importantes sur la sécurité 3
Dangers et avertissements concernant le gaz propane (GPL) 5
Liste des pièces 6
Instructions d’assemblage 7
Instructions avant l’utilisation 9
Instructions d’allumage 10
Entretien et nettoyage 11
Avertissement concernant les araignées et les insectes 12
Conseils et dépannage 13
Liste des pièces techniques 14
SPÉCIFICATIONS
Nom du produit
Eldora 42” Fire Bowl
N° de modèle
132LP
Puissance
thermique nominale
60,000 BTU/h
Type de gaz
Propane (GPL)
Approvisionnement en gaz
2
ATTENTION
Veuillez enregistrer votre foyer pour recevoir les notifications de
rappel, les preuves de propriété et l’assurance qualité à l’adresse
https://www.realflame.com/registration.
Bonbonne de GPL de 20 lb
Garantie et politiques de retour 15

INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ
Avertissements généraux
3
Les enfants et les adultes doivent être informés des risques de températures de surface élevées
et doivent rester éloignés pour éviter les brûlures ou que leurs vêtements prennent feu.
Les jeunes enfants devraient être soigneusement surveillés autour du foyer.
Les vêtements ou autres matériaux inflammables ne doivent pas être accrochés au foyer
ou placés sur ou à proximité de l’appareil.
Toute protection ou autre dispositif de protection retiré pour l’entretien du foyer doit être
replacé avant d’utiliser l’appareil.
L'installation et l'entretien doivent être eectués par un service d’entretien qualifié ou le
fournisseur de gaz. Real Flame recommande d’utiliser des professionnels certifiés aux
États-Unis par le National Fireplace Institute® (NFI) en tant que Spécialistes NFI du Gaz.
Un nettoyage plus fréquent peut être nécessaire. Il est impératif que le compartiment de
commande, les brûleurs et les passages de circulation d’air de l’appareil soient
maintenus propres.
Ne pas entreposer et ne pas utiliser d’essence ou d’autres liquides ou vapeurs inflammables
à moins de 7,62 m (25 pi) de cet appareil ou de tout autre appareil.
Ne pas ranger as de matériaux combustibles dans le boîtier du foyer. Cela comprend les
bonbonnes de GPL. Si le foyer est conçu pour utiliser une bonbonne de GPL dissimulée, la
bonbonne de GPL doit être correctement fixée dans le porte-bonbonne désigné sous le foyer. Ne
pas entreposer de bonbonnes de GPL supplémentaires sous le foyer.
S’assurer de protéger le tuyau et ses composants de toutes surfaces chaudes. Il est
dangereux de laisser le tuyau entrer en contact avec une surface chaude.
La bonbonne de GPL ne doit jamais être utilisée ou rangée sur le côté ou à l’envers.
Conserver toutes les parties du foyer propres, y compris le brûleur et le tuyau. Pour plus
d’informations sur le nettoyage du foyer, consulter la section Entretien et nettoyage de ce
manuel.
Ne pas utiliser ce foyer si une pièce a été submergée. Appeler immédiatement un technicien de
service qualifié pour inspecter l’appareil et remplacer toute pièce du système qui a été submergée.
Ne pas utiliser ce foyer pour la cuisson.
Ne pas verser d’eau dans le foyer.
Ne pas essayer de déplacer ou de ranger ce foyer jusqu’à ce que toutes les pièces soient
froides.
Toujours couper l’alimentation en gaz à la source et débrancher le tuyau lorsque le foyer n’est
pas utilisé.
Toute modification de ce foyer qui n’est pas spécifiée dans le manuel du propriétaire
annulera la garantie du fabricant. Cela comprend l’utilisation de matériaux de remplissage
non approuvés.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Avertissements d’installation
•
•
•
•
•
•
•
Avertissements de préparation
•
•
•
•
Avertissements lors de l’utilisation
•
•
•
•
•
•
•
•
4
INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ
Distance minimale de l’unité aux matériaux combustibles : 121,9 cm (48 po) de tous les côtés.
Ne pas placer pas ce foyer sous aucune structure suspendue ou végétation.
La pression d’entrée GPL normale pour cet appareil est de 11,0 po W.C. (2,74 kPa). La
pression d’entrée maximale est de 13,0 po W.C. (3,23 kPa). La pression d’entrée minimale est
de 8 po W.C. (1,99 kPa).
Ne pas retirer les pieds du foyer.
Ne pas placer le foyer sur tout ce qui bloque ou scelle l’espace entre le foyer et le sol.
Ne pas fixer en permanence le foyer de quelque manière que ce soit ou à aucune surface.
Ne pas enterrer le tuyau. Il faut pouvoir inspecter visuellement le tuyau avant chaque utilisation.
Ne pas enrouler ou cacher le tuyau sous le foyer. Le tuyau pourrait être endommagé s’il
touche des surfaces chaudes.
Avant chaque fonctionnement, vérifier le tuyau pour s’assurer qu’il n’y a pas d’abrasion,
d’usure ou de dommage. Utiliser un miroir portatif, si nécessaire, pour voir les sections de
tuyau situées sous l’appareil.
Si le tuyau flexible est endommagé, fissuré ou coupé, il doit être remplacé avant d’utiliser le
foyer. Le tuyau doit être remplacé par un tuyau spécifié par Real Flame. Contacter le service
à la clientèle Real Flame au 1-800-654-1704 pour obtenir de l’assistance.
Placer le tuyau hors des sentiers où les gens risquent de trébucher. Ne pas placer le tuyau
dans les endroits où il risque d’être endommagé accidentellement.
Avant chaque utilisation, examiner le brûleur et ses composants pour la présence de saleté et
de débris. Si le nettoyage est nécessaire, utiliser une brosse à tuyau et de l’air comprimé.
Examiner également la zone autour du brûleur. Toutes saletés ou matières étrangères telle que
les toiles d’araignées, les nids, les feuilles, etc., doivent être enlevées. S’il est évident que le
brûleur est endommagé, le foyer ne doit pas être utilisé et le brûleur doit être remplacé.
Contacter le service à la clientèle Real Flame au 1-800-654-1704 pour obtenir de l’assistance.
NE JAMAIS LAISSER ce foyer sans surveillance lorsqu’il est en cours d’utilisation.
Ne pas brûler de combustibles solides, tels que briquettes de charbon de bois, charbon de
bois en bloc, bûches de papier, rebut, feuilles, papier, carton, bois naturel ou traité, ou tout
autre matériau dans ce foyer.
La consommation d’alcool, de médicaments sur ordonnance ou en vente libre peut nuire à la
capacité d’utiliser ce foyer de façon sécuritaire.
Toujours utiliser conformément à tous les codes locaux, provinciaux et nationaux applicables.
Contacter le service d’incendie local pour plus de détails concernant les feux extérieurs.
Ne pas utiliser dans des conditions venteuses. Les vents supérieurs à 16 km/h peuvent
éteindre la flamme.
Certaines surfaces de ce foyer peuvent devenir chaudes pendant l’utilisation. Faire attention
et ne pas toucher les surfaces jusqu’à ce que l’appareil soit refroidi.
Ne pas essayer de débrancher l'alimentation en gaz du foyer lorsque l'appareil est en marche.
Ne pas s'asseoir sur le foyer.

DANGERS ET AVERTISSEMENTS CONCERNANT LE GAZ PROPANE (GPL)
!AVERTISSEMENT
!DANGER
Caractéristiques du gaz GPL
•
•
•
Informations concernant la bonbonne de GPL
•
•
•
•
•
•
•
•
•
Entreposage et sécurité des bonbonnes GPL
•
•
•
•
•
•
•
5
Le GPL est inflammable et dangereux s’il n’est pas manipulé correctement. Prendre conscience de ses
caractéristiques avant d’utiliser un produit de GPL. Le non-respect de ces avertissements ou de ces
instructions et de ces avertissements fournis par votre fournisseur de GPL peut entraîner des
dommages matériels, des blessures ou la mort.
Une bonbonne de GPL ne doit jamais être placée sur le côté. Cela pourrait provoquer une fuite de
propane liquide. Cela pourrait provoquer une accumulation rapide de gaz propane et pourrait entraîner
des dommages matériels, des blessures ou la mort.
Le GPL est inflammable, explosif sous pression, plus lourd que l’air et se dépose dans les zones
basses. Le gaz accumulé peut s’enflammer en provoquant un incendie ou une explosion qui pourrait
causer des dommages matériels, des blessures ou la mort.
Dans son état naturel, le GPL n’a pas d’odeur. Pour la sécurité, une odeur y a été ajouté.
Le contact avec du propane pourrait brûler la peau.
Les bonbonnes de GPL doivent être remplies uniquement par un distributeur de GPL certifié.
Ne jamais utiliser une bonbonne de GPL avec un corps, une vanne, un collier ou un socle endommagé.
Les bonbonnes de GPL endommagées ou rouillées peuvent être dangereuses et devraient être
vérifiées par votre fournisseur de GPL.
La bonbonne d’alimentation en GPL doit être construite et marquée conformément aux spécifications
pour les bonbonnes de GPL du ministère des Transports des États-Unis (DOT) ou la Norme nationale
du Canada, CAN/CSA-B339, concernant les bonbonnes de GPL, les barriques et les conduites pour le
Transport de Marchandises Dangereuses; et la Commission.
Les bonbonnes de GPL doivent être munies d’une sortie de vapeur.
Les bonbonnes de GPL doivent être munis d’un dispositif anti-débordement (OPD) et d’un raccord de
réservoir de GPL QCCI ou Type I (CGA810).
La bonbonne de GPL doit contenir une vanne d’arrêt conforme à la Norme ANSI/CGA-V-1-1977, CSA
B96, la Norme relative à la sortie de la vanne et aux tuyaux de la bonbonne de gaz comprimé.
Ne jamais essayer d’attacher cet appareil au système de GPL autonome d’un camping-car, d’une
caravane, d’un VR ou d’une maison.
Tourner la vanne de contrôle du gaz à la main. Ne jamais utiliser d’outils. Si la vanne ne tourne pas à
la main, ne pas tenter de la réparer. Appeler un technicien en gaz certifié.
L’usage de la force ou toute autre tentative de réparation peuvent produire un incendie ou une explosion.
Les bonbonnes doivent être entreposées verticalement et à l’extérieur dans un endroit bien ventilé
hors de portée des enfants.
Ne jamais ranger une bonbonne de GPL dans un endroit fermé comme une remise ou un garage. Des
fuites de gaz pourraient s’accumuler dans ces endroits et entraîner une explosion.
Ne pas ranger les bonbonnes de GPL à proximité de toute source de flamme ou d'inflammation.
Ne pas ranger la bonbonne de GPL à la lumière directe du soleil ou des endroits où les températures
peuvent atteindre 52 °C (125 °F) ou plus.
Ne jamais garder une bonbonne de GPL remplie dans une voiture chaude ou un core de voiture. La
chaleur entraînera une augmentation de la pression du gaz, ce qui peut ouvrir la vanne de décharge
et permettre au gaz de s’échapper.
Placer le capuchon protecteur sur la sortie de la vanne lorsque la bonbonne de GPL n’est pas utilisée.
Installer uniquement le type de capuchon protecteur qui est fournie avec la vanne de la bonbonne de
GPL. L’utilisation d’autres types de capuchons ou de bouchons peut entraîner une fuite de GPL.
La bonbonne de GPL ne devrait pas être échappée ou manipulée brutalement.
•
