Jet JWTS-10 Service manual

Operating Instructions and Parts Manual
Table Saw
Model: JWTS-10
WMH TOOL GROUP
2420 Vantage Drive
Elgin, Illinois 60124 Part No. M-708100
Ph.: 800-274-6848 Revision B2 9/06
www.wmhtoolgroup.com Copyright © WMH Tool Group
This Manual is Bookmarked

2
WARRANTY AND SERVICE
WMH Tool Group, Inc., warrants every product it sells. If one of our tools needs service or repair, one of our
Authorized Service Centers located throughout the United States can give you quick service. In most cases, any of
these WMH Tool Group Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or
perform routine maintenance and major repair on your JET® tools. For the name of an Authorized Service Center in
your area call 1-800-274-6848.
MORE INFORMATION
WMH Tool Group is consistently adding new products to the line. For complete, up-to-date product information, check
with your localWMH Tool Group distributor, or visit jettools.com.
WARRANTY
JET products carry a limited warranty which varies in duration based upon the product (MW = Metalworking, WW =
Woodworking).
WHAT IS COVERED?
This warranty covers any defects in workmanship or materials subject to the exceptions stated below. Cutting tools,
abrasives and other consumables are excluded from warranty coverage.
WHO IS COVERED?
This warranty covers only the initial purchaser of the product.
WHAT IS THE PERIOD OF COVERAGE?
The general JET warranty lasts for the time period specified in the product literature of each product.
WHAT IS NOT COVERED?
Five Year Warranties do not cover woodworking (WW) products used for commercial, industrial or educational
purposes. Woodworking products with Five Year Warranties that are used for commercial, industrial or education
purposes revert to a One Year Warranty. This warranty does not cover defects due directly or indirectly to misuse,
abuse, negligence or accidents, normal wear-and-tear, improper repair or alterations, or lack of maintenance.
HOW TO GET SERVICE
The product or part must be returned for examination, postage prepaid, to a location designated by us. For the name
of the location nearest you, please call 1-800-274-6848.
You must provide proof of initial purchase date and an explanation of the complaint must accompany the
merchandise. If our inspection discloses a defect, we will repair or replace the product, or refund the purchase price,
at our option. We will return the repaired product or replacement at our expense unless it is determined by us that
there is no defect, or that the defect resulted from causes not within the scope of our warranty in which case we will,
at your direction, dispose of or return the product. In the event you choose to have the product returned, you will be
responsible for the shipping and handling costs of the return.
HOW STATE LAW APPLIES
This warranty gives you specific legal rights; you may also have other rights which vary from state to state.
LIMITATIONS ON THIS WARRANTY
WMH TOOL GROUP LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR
EACH PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OR MERCHANTABILITY AND
FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG THE IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
WMH TOOL GROUP SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY,
OR FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OF OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
WMH Tool Group sells through distributors only. The specifications in WMH catalogs are given as general information
and are not binding. Members of WMH Tool Group reserve the right to effect at any time, without prior notice, those
alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever.
JET® branded products are not sold in Canada by WMH Tool Group.

3
Table of Contents
Table of Contents....................................................................................................................................3
Warnings.................................................................................................................................................4
Assembly...............................................................................................................................................11
Unpacking and Cleanup.....................................................................................................................11
Stand Assembly.................................................................................................................................11
Assembling the Saw to the Stand.......................................................................................................12
Blade Tilt Pointer................................................................................................................................12
Handwheels.......................................................................................................................................13
Extension Wings ................................................................................................................................13
Rear Guide Rail..................................................................................................................................13
Front Guide Rail.................................................................................................................................14
Support Rod.......................................................................................................................................14
Switch Bracket...................................................................................................................................15
Extension Wing Adjustment................................................................................................................15
Blade Guard and Splitter....................................................................................................................15
Installing/Replacing the Blade.............................................................................................................16
Aligning the Blade Guard and Splitter.................................................................................................16
Table Insert........................................................................................................................................17
Rip Fence ..........................................................................................................................................17
Miter Gauge...........................................................................................................................................18
Grounding Instructions...........................................................................................................................19
Electrical Connections........................................................................................................................19
Extension Cord Recommendations.....................................................................................................19
Blade Raising and Tilt Mechanism......................................................................................................20
Adjusting 45º and 90º Positive Stops..................................................................................................20
Operations.............................................................................................................................................21
Table Saws........................................................................................................................................21
Kickbacks.......................................................................................................................................21
Rip Sawing.....................................................................................................................................22
Resawing........................................................................................................................................23
Crosscutting....................................................................................................................................23
Align-a-rip ..........................................................................................................................................24
Bevel and Miter Operations................................................................................................................24
Safety Devices.......................................................................................................................................25
Feather Board....................................................................................................................................25
Filler Piece.........................................................................................................................................26
Push Stick & Push Block....................................................................................................................26
Maintenance..........................................................................................................................................27
Cleaning.............................................................................................................................................27
Lubrication .........................................................................................................................................27
Miscellaneous ....................................................................................................................................27
Troubleshooting.....................................................................................................................................28
Parts......................................................................................................................................................29
Wiring Diagram......................................................................................................................................37
Ordering Replacement Parts..................................................................................................................38

4
Warnings
1. Read and understand the entire owners manual before attempting assembly or operation.
2. Read and understand the warnings posted on the machine and in this manual. Failure to comply with
all of these warnings may cause serious injury.
3. Replace the warning labels if they become obscured or removed.
4. This Table Saw is designed and intended for use by properly trained and experienced personnel only.
If you are not familiar with the proper and safe operation of a Table Saw, do not use until proper
training and knowledge have been obtained.
5. Do not use this Table Saw for other than its intended use. If used for other purposes, WMH Tool
Group disclaims any real or implied warranty and holds itself harmless from any injury that may result
from that use.
6. Always wear approved safety glasses/face shields while using this Table Saw. Everyday eyeglasses
only have impact resistant lenses; they are not safety glasses.
7. Before operating this Table Saw, remove tie, rings, watches and other jewelry, and roll sleeves up
past the elbows. Remove all loose clothing and confine long hair. Non-slip footwear or anti-skid floor
strips are recommended. Do not wear gloves.
8. Always use the blade guard on all ''through-sawing'' operations. A through-sawing operation is one in
which the blade cuts completely through the workpiece.
9. Kickback occurs when the workpiece is thrown towards the operator at a high rate of speed. If you do
not have a clear understanding of kickback and how it occurs, DO NOT operate this table saw!
10. Wear ear protectors (plugs or muffs) during extended periods of operation.
11. Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contain chemicals known to cause cancer, birth defects or other reproductive harm. Some examples
of these chemicals are:
• Lead from lead based paint.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically treated lumber.
12. Your risk of exposure varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals, work in a well-ventilated area and work with approved safety
equipment, such as face or dust masks that are specifically designed to filter out microscopic
particles.
13. Do not operate this machine while tired or under the influence of drugs, alcohol or any medication.
14. Make certain the switch is in the OFF position before connecting the machine to the power supply.
15. Make certain the machine is properly grounded.
16. Make all machine adjustments or maintenance with the machine unplugged from the power source.
17. Remove adjusting keys and wrenches. Form a habit of checking to see that keys and adjusting
wrenches are removed from the machine before turning it on.
18. Keep safety guards in place at all times when the machine is in use. If removed for maintenance
purposes, use extreme caution and replace the guards immediately.
19. Make sure the Table Saw is firmly secured to the floor or bench before use.
20. Check damaged parts. Before further use of the machine, a guard or other part that is damaged
should be carefully checked to determine that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting
and any other conditions that may affect its operation. A guard or other part that is damaged should
be properly repaired or replaced.

5
Error! Objects cannot be created from editing field codes.
21. Provide for adequate space surrounding work area and non-glare, overhead lighting.
22. Keep the floor around the machine clean and free of scrap material, oil and grease.
23. Keep visitors a safe distance from the work area. Keep children away.
24. Make your workshop child proof with padlocks, master switches or by removing starter keys.
25. Give your work undivided attention. Looking around, carrying on a conversation and “horse-play” are
careless acts that can result in serious injury.
26. Maintain a balanced stance at all times so that you do not fall into the blade or other moving parts. Do
not overreach or use excessive force to perform any machine operation.
27. Use the right tool at the correct speed and feed rate. Do not force a tool or attachment to do a job for
which it was not designed. The right tool will do the job better and safer.
28. Use recommended accessories; improper accessories may be hazardous.
29. Maintain tools with care. Keep saw blades sharp and clean for the best and safest performance.
Follow instructions for lubricating and changing accessories.
30. Turn off the machine before cleaning. Use a brush or compressed air to remove chips or debris — do
not use your hands.
31. Do not stand on the machine. Serious injury could occur if the machine tips over.
32. Never leave the machine running unattended. Turn the power off and do not leave the machine until it
comes to a complete stop.
33. Remove loose items and unnecessary work pieces from the area before starting the machine.
Familiarize yourself with the following safety notices used in this manual:
This means that if precautions are not heeded, it may result in minor injury and/or
possible machine damage.
This means that if precautions are not heeded, it may result in serious injury or possibly
even death.

6
The most common accidents among table saw users, according to statistics, can
be linked to kickback, the high-speed expulsion of material from the table that can strike the
operator. Kickback can also result in operator’s hands being pulled into the blade.
Kickback Prevention
Tips to avoid the most common causes of
kickback:
• Make sure the blade splitter is always
aligned with the blade. A workpiece can bind
or stop the flow of the cut if the blade splitter
is misaligned and result in kickback.
• Use the blade splitter during every cut. The
blade splitter maintains the kerf in the
workpiece, which will reduce the chance of
kickback.
• Never attempt freehand cuts. The workpiece
must be fed perfectly parallel with the blade,
otherwise kickback will likely occur. Always
use the rip fence or crosscut fence to
support the workpiece.
• Make sure that the rip fence is parallel with
the blade. If not, the chances of kickback are
very high. Take the time to check and adjust
the rip fence.
• Feed cuts through to completion. Anytime
you stop feeding a workpiece that is in the
middle of a cut, the chance of binding,
resulting in kickback, is greatly increased.
Protection Tips from
Kickback
Kickback can happen even if precautions are
taken to prevent it. Listed below are some tips to
protect you if kickback DOES occur:
• Stand to the side of the blade when cutting.
An ejected workpiece usually travels directly
in front of the blade.
• Wear safety glasses or a face shield. Your
eyes and face are the most vulnerable part
of your body.
• Never place your hand behind the blade. If
kickback occurs, your hand will be pulled
into the blade.
• Use a push stick to keep your hands farther
away from the moving blade. If a kickback
occurs, the push stick will most likely take
the damage that your hand would have
received.

7
Features
Specifications
Model Number............................................................................................................................ JWTS-10
Stock Number................................................................................................................................ 708100
Blade Diameter.....................................................................................................................................10"
Arbor Diameter....................................................................................................................................5/8"
Maximum Depth of Cut.....................................................................................................................3-1/8"
Maximum Rip to Right of Blade.............................................................................................................30"
Maximum Rip to Left of Blade...............................................................................................................12"
Maximum Depth of Cut at 45°...........................................................................................................2-1/8"
Table in Front of Blade at Maximum Cut (in) ....................................................................................10-1/2
Maximum Width of Dado..................................................................................................................13/16"
Maximum Diameter of Dado....................................................................................................................8"
Table Height...................................................................................................................................36-1/2"
Table Size (Cast Iron) with Extensions.........................................................................................27" x 44"
Table Size (Cast Iron) without Extensions....................................................................................27" x 20"
Overall Dimensions (D x W x H)....................................................................................40" x 55-1/2" x 42"
Arbor Speed ............................................................................................................................. 3600 RPM
Motor................................................................................ 115/230V, 60Hz, 1Ph, 1-1/2HP, Prewired 115V
Net Weight......................................................................................................................................205 lbs
Gross Weight..................................................................................................................................214 lbs
The specifications in this manual are given as general information and are not binding. WMH Tool Group
reserves the right to effect, at any time and without prior notice, changes or alterations to parts, fittings,
and accessory equipment deemed necessary for any reason whatsoever.

8
Definitions And Terminology
Arbor: Metal shaft that connects the drive
mechanism to the blade.
Bevel Edge Cut: Tilt of the saw arbor and blade
between 0° and 45° to perform an angled cutting
operation.
Blade Guard: Mechanism mounted over the
saw blade to prevent accidental contact with the
cutting edge.
Crosscut: Sawing operation in which the miter
gauge is used to cut across the grain of the
workpiece.
Dado Blade: Blade(s) used for cutting grooves
and rabbets.
Dado Cut: Flat bottomed groove in the face of
the workpiece made with a dado blade.
Featherboard: Device used to keep a board
against the rip fence or table that allows the
operator to keep hands away from the saw
blade.
Kerf: The resulting cut or gap made by a saw
blade.
Kickback: An event in which the workpiece is
lifted up and thrown back toward an operator,
caused when a work piece binds on the saw
blade or between the saw blade and rip fence
(or other fixed object). To minimize or prevent
injury from kickbacks, see the Operating
Instructions section.
Miter Gauge: A component that controls the
workpiece movement while performing a
crosscut of various angles.
Non-Through Cut: A sawing operation that
requires the removal of the blade guard splitter,
resulting in a cut that does not protrude through
the top of the workpiece (includes Dado and
rabbet cuts).
The blade guard and splitter must be re-installed
after performing a non-through cut to avoid
accidental contact with the saw blade during
operation.
Parallel: Position of the rip fence equal in
distance at every point to the side face of the
saw blade.
Perpendicular: 90° (right angle) intersection or
position of the vertical and horizontal planes
such as the position of the saw blade (vertical)
to the table surface (horizontal).
Push Board/Push Stick: An instrument used to
safely push the workpiece through the cutting
operation.
Rabbet: A cutting operation that creates an
L-shaped channel along the edge of the board.
Rip Cut: A cut made along the grain of the
workpiece.
Splitter: Metal plate to which the blade guard is
attached that maintains the kerf opening in the
workpiece when performing a cutting operation.
Standard Kerf: 1/8" gap made with a standard
blade.
Straightedge: A tool used to check that a
surface is flat or parallel.
Through Sawing: A sawing operation in which
the workpiece thickness is completely sawn
through. Proper blade height usually allows a
1/8" of the top of the blade to extend above the
wood stock.
Read and understand the entire contents of this manual before attempting
assembly or operation! Failure to comply may cause serious injury!

9
Shipping Contents
Carton Contents
1 ea Table Saw (not shown)
1 ea Front Rail – Long (A)
1 ea Front Rail – Short (B)
1 ea Extension Wing – Left (C)
1 ea Extension Wing – Right (D)
1 ea Support Rod with mounting screw
and washer (E)
1 ea Rear Rail – Short (F)
1 ea Rear Rail – Long (G)
1 ea Left Leg – Rear (H)
1 ea Left Leg – Front (J)
1 ea Handwheel – Large Mounting Hole (K)
1 ea Handwheel – Small Mounting Hole (L)
2 ea Right Leg (M)
2 ea Top Plate – Short (N)
2 ea Top Plate – Long (O)
2 ea Support Plate – Short (P)
2 ea Support Plate – Long (Q)
1 ea Saw Blade (R)
1 ea Fence (S)
1 ea Table Insert (T)
1 ea Blade Guard Assembly (U)
1 ea Miter (V)
Carton Contents

10
Hardware
The shipping carton includes two hardware bags
with parts for assembling the JWTS-10 Table Saw.
Hardware bag JWTS10-HP contains six packets of
parts and JWTS10-SHP contains three packets of
parts. If either bag is missing the proper number of
packets, contact customer service (phone number
on cover and back pages).
Remove contents from all packets and sort.
Hardware contents can be identified by the
illustration to the right and quantities can be verified
from the list below.
02 3/8”-16 x 2.5” Hex Cap Screw (AA)
02 3/8” Nylon Insert Lock Nut (BB)
18 M8x20 Hex Cap Screw (CC)
24 M8x12 Carriage Bolt (DD)
36 M8 Flat Washer (EE)
40 M8 Hex Nut (FF)
06 M8 Square Head Bolt (GG)
20 M8 Lock Washer (HH)
01 M5x12 Socket Head Cap Screw (JJ)
01 M5 Lock Washer (KK)
04 5/16" Hex Nut (LL)
02 M6x10 Pan Head Screw (MM)
02 M6 Washer (NN)
02 M6 Square Nut (OO)
02 Wheel (RR)
01 Lock Knob for Front Handwheel (SS)
01 Bushing (TT)
02 Foot Pad (UU)
02 Lock Knob for Wheels (VV)
Tools Included for Assembly
2 Arbor/Blade Guard Bracket Wrench
1 Hex Wrench (2.5mm)
1 12-14mm Open End Wrench
Additional Tools Required
1 No. 1 and No. 2 Cross Point Screwdrivers
1 6"– 8" Adjustable Wrench
1 Accurate Straight Edge (approximately 2 ft)
1 4mm Hex Wrench
1 13mm Box Wrench
Note: Use of sockets and ratchets will speed
assembly time but are not required.
Hardware Contents
