JETI model MVario2 User manual

MVario2
®
User Manual
EN
MVario2
ERES limiter
SW for competition flying

MVario2
ERES limiter is a special type of MVARIO2 firmware designed for the
competition category of electrically powered gliders (ERES).
Measurements and height calculations are the same as the
specifications of F5J category. Settings and telemetry are strictly
limited according to the needs of the ERES competition. This special
firmware can be uploaded via JETI Studio to the MVARIO2 sensor by
a USB adapter. The ESC-In port is the input port for connecting the
throttle channel from the receiver. The ESC-Out port is the output
port for connecting the controller.
Telemetry data of the sensor:
● Set switch-off height
● Set switch-off time
● Firmware version
Sensor settings:
● Motor shutdown pulse (default 1.1ms)
● Switch-off height setting (90m by default)
● Switch-off time setting (30s by default)
Data displayed by the sensor:
● Current sensor status (Initialization, Idle, Ready, Running,
Measuring, Done)
● Maximum measured relative height
● 10 relative height values
Mvario2 - ERES limiter
1 Description and function
EN

MVario2
The sensor can only be configured if the ECS-in throttle channel
(pulse) is not connected after connecting the power supply to the
sensor. Once a pulse is connected to the ESC-in, the sensor can no
longer be set until its power supply is reset. Settings can be made by
the Jetibox or DC/DS transmitter (in the "device explorer" menu).
The measured data can be seen if the sensor is in the "Idle" or
"Done" status. The sensor save the data from the last measurement
and can be read again after connecting the power supply. In the
Idle status, you can view the data from the last measurement.
Measurement data means the maximum relative height reached
during motor run and 10s after that and 10 relative altitude values
saved after 1s of motor run.
The sensor can be in the Ready status if a throttle control pulse is
connected to the ESC-in input and the pulse value is less than the
set level for motor shutdown (default setting 1.1ms).
The Sensor will be in the Running status if the throttle control pulse
exceeds the motor shutdown pulse level. After stopping the motor
the sensor goes from the Running status to the Measuring status
and the sensor evaluates the measurement for another 10s.
EN

MVario2
The motor is shutdown if:
● Set height is reached
● Set time is reached
● The throttle lever has been pulled below the set level
The motor will be stopped, whichever occurs first (terms above).
After stopping the motor, the motor cannot be restarted until the
sensor power is disconnected and connected again and the sensor
returns to the Ready status.
To calculate the height is used the sea level pressure
1013,25 hPa - ISA (International Standard Atmosphere)
EN

MVario2
To d i s p l a y t h e t e l e m e t r y
parameters correctly, it is
necessary to reload/reset the
sensor telemetry. In the menu
T i m e r s / S e n s o r s - >
Se n s o rs /L o g gi ng s et up,
select Auto (F1).
EN
2 Settings by the DC/DS transmitter:
Display of telemetry data:
● Set height for motor shutdown
● Set time for motor shutdown
● ERES Firmware version
Sensor display in the menu
"device explorer"

MVario2 EN
Display of ten measured relative
heights.
Main settings.
Sensor display in status "Ready"
To display the ERES limiter in "device explorer", it is necessary to
have the configuration file ERES.bin in the Devices folder in the
transmitter. The sensor have to be connected to the EXT output
of the receiver and the output have to be set as EX BUS.

MVario2
3 S ettings by the JETIBOX
The DC/DS transmitter in the "device explorer" menu or Jetibox
can be used to view 10 measured heights (measured after 1s).
After connecting the power supply (for 3 seconds) the
initialization screen with information about the ERES firmware
version marked "E" as ERES will be displayed on the Jetibox. This
time of 3s is also needed to initialize the relative height of the
sensor. Data cannot be read or set in the "Jetibox" emulator
application in the DC/DS transmitters.
Jetibox menu diagram:
Use the up and down arrows on the Jetibox to switch between
the individual screens. Use the left and right arrows to set up the
values.
EN
3: 92.7 4: 92.2m
5: 91.7 6: 89.7m
7: 86.6 8: 84.9m
9: 85.5 10: 85.2m
Cut-off Altit.
← 90m →
Cut-off Time
← 30s →
Motor Off
← 1.100sm →
Altitude values are only displayed in the sensor
status Idle or Done. If the values of 10 heights are
measured as zero, they are not displayed.
The setting is only displayed until it is detected
throttle deflection pulse on ESC-in.
ERES
Init v.E2.05
Initialization screen
with SW version
ERES Idle 93m
1: 90.7 2: 90.8m

MVario2 EN
Connection with the JETIBOX:
Power supply: 5 - 8,4V
Ext2/ESC Out
Ext1/ESC In
JETIJETI BOX BOXJETI BOX
Made in EU - Czech republic

MVario2
SERVO
Ext2/ESC Out
Ext1/ESC In
MOTOR
speed controller
without BEC
(OPTO)
9 channel receiver
SAT
9
Ext.
BATT
A2
A1
Receiver
Batt.
9 channel receiver
SAT
9
Ext.
BATT
A2
A1
SERVO
Ext2/ESC Out
Ext1/ESC In
Power Batt.
Throttle chanel
MOTOR
speed controller
with BEC
EN
4 Connection options with controllers:
Possibilities of ERES limiter connection in the BEC and OPTO
controller version.
Power Batt.
Throttle chanel

MVario2 EN
5 Technical data:
Dimensions
35 x 16 x 7 mm
Weight with the wires
5 g
Measuring accuracy of relative (absolute) altitude
+/-3 m (+/-9 m)
Resolution of measured height
0,1 m
Measurement range
300 ÷ 1200 hPa
Operating temperature
-10 ÷ 85 °C
Supply voltage
3,5 ÷ 8,4 V
Current consumption
15 mA
Follow the principles of installation and handling of the sensor
according to the instruction manual for MVARIO2.
6 Warranty:
This product is covered by warranty for 24 months after the day of
purchase provided that it has been operated in accordance with
these instructions at the specified voltage and is not mechanically
damaged. When claiming warranty repairs for the product, always
attach a proof of purchase. Warranty and post-warranty service is
provided by your dealer or the manufacturer.
We wish you pleasant RC flying with our products:
JETI model s.r.o., Příbor, www.jetimodel.com
