Jetinno JL24 Series User manual

JL24
Machine Service Manual
Guangzhou Jetinno Intelligent Equipment Co.,Ltd.
www.jetinno.com
(86) 20-32038721
(86) 400-017-9997
Add: 4F, A Building, Creator Park, No.2,Tairui Rd, Science Park, Huangpu District, GZ, GD, PRC.
510663
Read the manual before operation and keep it
carefully

1
Contents
1Preface..............................................................................................................................3
1.1 About this service manual......................................................................................................3
1.2 Important Safety Warnings....................................................................................................4
1.3 Spare parts ...............................................................................................................................5
1.4 Handling packaging materials...............................................................................................5
1.5 Machine scrap..........................................................................................................................5
2About machine ................................................................................................................6
2.1 Technical specification............................................................................................................ 6
2.2 Key parameters........................................................................................................................7
2.3 Machine view........................................................................................................................... 7
2.4 Product interface.....................................................................................................................8
3Transportation and Storage ...........................................................................................8
3.1 Transportation .........................................................................................................................8
3.2 Storage and transportation environment ............................................................................9
4Installation and commissioning .....................................................................................9
4.1 Place machine........................................................................................................................10
4.2 Open door..............................................................................................................................10
4.3 Connect to water supply ...................................................................................................... 11
4.4 Connecting the Power Supply (Start the machine)...........................................................12
4.4.1 Connect to power supply..............................................................................................12
4.5 Turn off machine....................................................................................................................12
5First operation ...............................................................................................................13
5.1 Filling the bean hopper and canisters ................................................................................13
6Commissioning and calibration ...................................................................................13
6.1 grinder coarse and fine adjustment method.....................................................................13
6.2 Grinder Calibration................................................................................................................13
6.3 Instant cartridge calibration.................................................................................................14
6.4 Recipe Management and Testing........................................................................................16
7Set vending mode and drink price ..............................................................................17
7.1 Set vending mode................................................................................................................. 17
7.2 Setting Drink Prices...............................................................................................................18
8Drinks making................................................................................................................18
9Software Upgrade .........................................................................................................19
10 Cleaning ...................................................................................................................19
10.1 Cleaning and cleaning safety...............................................................................................20
10.2 Hygiene....................................................................................................................................20
10.3 Spoiled Food............................................................................................................................20
10.4 Basic Cleaning........................................................................................................................21

2
10.5 Cleaning Guidelines ..............................................................................................................21
10.6 Daily Cleaning........................................................................................................................23
10.6.1 Cleaning Hot Water System..........................................................................................23
10.6.2 Drink Spout Cleaning.....................................................................................................25
10.6.3 Drip Tray and Waste Bin Bucket Cleaning...................................................................25
10.6.4 Mixer Cleaning..............................................................................................................25
10.7 Regular Maintenance............................................................................................................26
10.7.1 Clean the Brewer............................................................................................................ 26
10.8Maintenance Guidelines.......................................................................................................29
10.8.1 Empty boiler....................................................................................................................29
10.8.2 Empty air break ..............................................................................................................29
11 APP Installation .......................................................................................................30
12 Preventive Measures...............................................................................................32
12.1 Cleaner....................................................................................................................................32
12.1.1 Use ...................................................................................................................................32
12.1.2 Storage ............................................................................................................................32
12.1.3 Disposal...........................................................................................................................33
12.2 Health Regulations................................................................................................................33
12.2.1 Water ...............................................................................................................................33
12.2.2 Coffee.............................................................................................................................33
12.2.3 Instant powder..............................................................................................................34
13 Safety and Warranty ...............................................................................................34
14 Frequently asked questions ......................................................................................35
15 Certification ...............................................................................................................36

3
1Preface
Thank you for purchasing JL24 series products! Before using the machine, read the instruction
manual of this coffee machine carefully to ensure the normal operation of the machine.
In order to protect your rights and interests, unpack and inspect the goods, and check in detail
whether the machine is damaged or lacks accessories. In use, if you have any questions, please
contact us, we will do our best to provide services in the shortest time, our contact information is as
follows www.jetinno.com (86) 20-32038721 (86) 400-017-9997。
All parts of this machine, including hardware and software, are owned by Guangzhou Jetinno
Intelligent Equipment Co., Ltd. and cannot be copied, excerpted or translated without the
permission of the company. The product specifications and information mentioned in this user
manual are for reference only, and the content will be updated at any time without prior notice.
Electrical Safety: To avoid serious injury from possible electric shock, unplug the power plug from
the electrical outlet before moving or servicing the machine. If the power cord is damaged, it must
be replaced by a professional from the manufacturer, its repair department or after-sales service to
avoid danger.
Please notify Jetinno about factory settings in advance, such as: service phone number and
company website, company logo, recipe requirements and cup size and other important
information.
1.1 About this service manual
This manual is a guide for authorised technicians to safely transport, install, set up, maintain and
service the machine.
Refer to separate chapters for service, use and daily cleaning instructions.
Below is a description of the risk levels
description
symbol
risk of serious damage
Danger
risk of injury
Caution
Risk of damage to the machine
Attention
Risk of impaired machine function
Important
Advice
Note

4
Caution!
When transporting, installing, setting up and maintaining the machine, if the operation is not
carried out according to the instructions, Jetinno will not be responsible for any personal injury or
damage to the machine;
Any alterations and structural adjustments to the machine are strictly prohibited, and in these
cases Jetinno will not exclude non-cash claims.
Only products and formulas approved by Jetinno can be used in the machine, Jetinno will not be
responsible for any loss caused by this, and the risk lies with the operator;
Always follow the instructions in the technical manual and user manual; pictograms, symbols and
instruction stickers attached to the machine cannot be torn or removed;
The person setting up the machine needs to be a trained technician; no changes to product
specifications are allowed.
1.2 Important Safety Warnings
1) Read this manual carefully before use；
2) Use the correct voltage referring to the nameplate and make sure the power outlet is well
grounded；
3) Do not store or use the machine near heat or air sources；
4) The equipment must be disconnected from the power supply before cleaning or
maintenance；
5) Prevent the machine from being splashed with water；
6) Do not drag the cable when unplugging；
7) Do not put the machine and cables in water
8) If the water hardness is greater than 8°DH, use a filter；
9) When the machine is installed and arranged, do not tilt; do not let children beside the
installation process；
10) If the cable is damaged, contact our company as soon as possible to purchase new spare
parts to replace；
11) Protect the machine from weather (such as water, heat, etc.)；
12) It is strictly forbidden to use the machine outdoors；
13) Maintenance, cleaning and restoration work should be done by professional service
personnel；
14) For your own safety and the longevity of the machine, please use original spare parts；
15) Equipotential sign: If there are other electrical equipments that require equipotential
connection, use appropriate copper conductors with a nominal cross-sectional area of 2.5
square to 10 square meters to reliably connect the equipotential terminal of the machine with
the equipotential terminals of other equipment.
16) Protective grounding.

5
1.3 Spare parts
1) Note that this machine, even with proper cleaning and maintenance, has parts that need to be
replaced due to wear and tear;
2) This mainly applies to mechanical parts and parts of the hot water system, such as hoses, seals,
etc;
3) Defects caused by wearing parts are not covered by warranty;
4) Defects and malfunctions must be resolved by factory-trained technical service personnel,
contact your professional retailer or Jetinno after-sales service center.
1.4 Handling packaging materials
Packaging materials include: cardboard, corrugated cardboard, treated wood, polystyrene
components and plastic film.
After installation, customers should contact their local public cleaning service to dispose of
packaging materials in a recyclable or environmentally friendly manner whenever possible.
1.5 Machine scrap
The scrapped machine cannot be returned to the original factory. The machine contains some
harmful materials to the environment, especially electronic parts, according to the national
standards/regulations to deal with!

6
2About machine
2.1 Technical specification
item specification
model
JL24
size
420（W）*720 (H)*535（D)mm
weight
45kg
rated voltage/frequency
Domestic (220V/50Hz/foreign (110V/60Hz) to determine
the local power grid
rated power
3000W
rated current
16A
power supply wire length
>1.5m
Operation temperature/humidity
5℃-35℃/10%RH-90%RH
rated pressure
0.6MPa
communication port
USB;WIFI;4G
displaying screen
14 inch display screen and touch screen
canister volume
3个/2L canister quantity can be adjust
coffee bean volume
1.5Kg
water waste bin volume
1.5L
coffee cake waste bin volume
50 cakes
boiler volume/ power
700CC\2700W
water outlet height
80mm-120mm
cup detection function
yes
coffee bean detection function
yes
IP waterproof IP
IPX1

7
①
②
③
⑤
④
①
①
⑥
⑤
④
③
②
⑥
⑧
⑦
2.2 Key parameters
1) Single instant beverage time: 30~40 seconds 220ml;
2) Single Espresso: ≤45 seconds 30ml) (brewing 35 seconds) (specific Settings affect the taste
and production time);
3) Machine startup time: <2 min;
4) Payment method: wechat/Alipay/banknote device/coin device/customized MDB device;
5) Communication interface: WIFI, optional 4G;
6) Operating system: Android.
2.3 Machine view
①bean container、②14inch touch screen、③beverage outlet、④ water drip tray、⑤ body induction、
⑥foot.
①bean block panel、② grinder、③ brewer ④waste bin、⑤ canister、⑥ mixer、⑦USB port。
⑧boiler empty switch.
Frontal view
Machine inside

8
①
①
⑥
⑤
④
③
②
①nameplate、② ventilation outlet、③ water pump power supply connector and water inlet ④city
water connector、⑤MDB port、⑥ power supply switch.
2.4 Product interface
3Transportation and Storage
3.1 Transportation
Machines are packed in cartons and plastic bags to protect against damage, moisture and dust.
Attention:
To avoid damage please:
Vertical transport of the machine;
Double stacked transport is allowed when the outer packing box is complete;
Avoid machine topple and fall during transportation;
No objects exceeding 5kg should be placed on the top of the machine during use.
Product name
Product choose
button
Time
Page turn button
LOGO
hotline and
machine number
Language switch
Back view
Price

9
3.2 Storage and transportation environment
Attention:
Risk of heat damage!
To prevent machine damage, please note:
It can only be used in temperature range from +5°C to +35°C. Freezing at low temperature
can seriously damage the machine.
Ambient humidity range of 10%RH - 90%RH.
Store the machine in a dust-free and dry environment at a temperature of -10°C to 50°C.
4Installation and commissioning
Attention:
Only trained personnel can install the machine!
Confirm whether the machine is damaged before installation. If the damage is found, contact the
transportation company to make a claim, and inform Jetinno to get after-sales service!
Prepare the transport before installing the machine!
Note :
Confirm the water connection mode of the machine before installation, support external bottled
water and city water mode!
Support for standard bottled water! If the machine is connected directly to city water source,
make sure the water pressure is between 0.5Bar and 6Bar.
Follow the steps for initial use:
Place the machine in the operation place, unpack the machine and open the door with the key;
Check inside the machine;
Remove the fine print paper attached to the powder outlet of the grinder and the material box;
Place buckets or connect machines to drink water directly;
filling material box;
electricity;
Make necessary Settings according to customer requirements;
Note:
The machine is not suitable for outdoor installation, or placed in a strong light environment, can
not be installed in the environment of air jet and water jet, need to be installed in 5°C to 35°C
drying room.
Ensure effective fan ventilation, the machine behind the wall is not less than 50cm, the side
installation space is not less than 30cm; The machine must be placed horizontally before
positioning, and the leaning angle should not exceed 2 degrees.
Pay attention to the installation environment ，should be clean, and please classify packaging
materials!

10
4.1 Place machine
Use forklift or flatbed truck to transport the machine, the machine will be transported to the
designated location; Unwrap the coffee machine and place it on a flat surface.
Important:
Risk of machine failure!
Consider the following tips when choosing a location:
1. The machine shall be placed and operated in a dry and well-ventilated room.
2. Place on a flat surface.
3. Ensure adequate repair, maintenance and cleaning space around the machine.
4. The back of the machine should be no less than 50 cm away from the wall to ensure that the
direct drinking pipe is not bent.
4.2 Open door
Open the door lock and check the inside of the machine if any damage. Take out the foundation
and install it at the bottom of the machine.
Note:
Only professionals can turn on the device!
Jetinno shall not be liable for any damage caused by intentional damage or neglect of these
safety instructions and notes.
Lock hole
Keys inside
Foot

11
4.3 Connect to water supply
There are two ways to connect water sources: bottled water and city water.
Please see below city water connection mode.
Take off the blue buckle, press the elastic surface of the quick connector, pull out the stopper, insert
the direct drinking water pipe into the interface of the quick connector, reinstall the blue buckle,
and open the water inlet valve switch.
Connection mode of barreled water: as shown below.
Important：
Water quality affects health! The water source should meet the GB5479 sanitary standards for
drinking water.
Pay attention to the sanitary condition of water pipes.
Clean related parts.
The water source connected to the machine should be easy to operate.
Direct drinking water should be tightened to avoid water leakage.
Take out the submersible pump inside the
machine, and put the submersible pump
into the bottled water.
The other end of the submersible pump is
connected with the machine water inlet and the
power connector of the submersible pump.

12
Note:
The standard pressure for direct drinking water is 0.5 to 6 Bar.
The water hardness must not exceed 8°DH; otherwise, a water filter is recommended.
4.4 Connecting the Power Supply (Start the machine)
Attention:
The wrong voltage will damage the machine!
Different countries have different voltages!
Make sure the machine is suitable for local electrical network connection.
The supply voltage and frequency can be found on the machine nameplate.
Attention
The voltage change is dangerous to the machine!
The machine should not be connected to unstable or fluctuating voltages.
The power supply socket must be grounded.
The power supply switch is placed in a convenient place to power off, which is convenient to power
off in time when abnormal.
4.4.1 Connect to power supply
Insert the male end of the power cord of the coffee machine into the outlet of the power supply.
Press the power supply switch on the back of the machine; It takes about 2 minutes for the machine
to start.
4.5 Turn off machine
When the machine is shut down for a long time or transported, it is necessary to empty the
water tank and boiler before shutting down. Otherwise there will be water overflow leading to
machine damage; The machine has automatic cleaning, boiler emptying and water tank emptying
procedures, refer to Chapter 10.6.1 and 10.6.2!

13
Caution!
The risk of burns,
When pulling the pipe or joint, pay attention to the hot water that burns the body!
5First operation
5.1 Filling the bean hopper and canisters
Use the key to open the machine door.
Put on a mask and disposable edible gloves.
Turn the powder outlet of the canister upward and remove the canister.
Open the top cover of the canister and add the powder to the canister accordingly; click on the
screen and enter the weight of the added material in the pop-up dialog box【Fill】.
Place the canister back into the machine, rotate the canister layout to facing the middle of the
mixer.
Note:
When the machine is filled with powder for the first time or after cleaning the canister, you need to
click 【Recipe】select 【Mocha】【Start cooking】to make a drink and then discard it,
the purpose is to ensure that the canister outlet is filled and the drink is dispensed according to
the recipe dosage.
Only timely replenishment of powder, the machine can operate normally.
6Commissioning and calibration
6.1 grinder coarse and fine adjustment method
To adjust the coarseness and fineness of the grinder according to the
silkscreen layout.
Without beans, as a benchmark coarseness position (general espresso
coarseness), first screw the knob clockwise to the position of the disc fit
(normal torque until it cannot be screwed), and then rotate the knob
counterclockwise 16 turns, later in the calibration process according to
the coarseness of the powder and then fine-tuning (clockwise direction
is to adjust fine, counterclockwise is to adjust coarse).
6.2 Grinder Calibration
Calibration is a software done for instant cartridges, physical properties of powders, coffee
bean roasting, etc. Before calibration you need to prepare the electronic scale and cups.
Important:
Failure to calibrate will result in abnormal machine output!
Make sure that the canister outlet is filled before calibration, which can be achieved by the
"powder drop test" function, if the outlet is not full, it will lead to inaccurate calibration.

14
Note:
Because of the density of coffee beans, blending, roasting, bean pressure, the structure of the
grinder and other factors, so each time when replace the bean box, grinder, different brands of
coffee beans, you need to recalibrate. When calibrate the coffee beans, the bean box should be
greater than 500 grams of coffee beans.
After the grinder adjustment is finished, you need to calibrate the amount of coffee powder. Press
and hold the top left corner of the screen, enter the password in the pop-up dialog box,
administrator password: jn9527 or maintenance password: 9527. Then enter the machine
background "coffee machine" interface.
In the Status - Canisters Management - Fill, select the coffee bean box, click , in the pop-up
dialog box [filling] enter the weight of the coffee beans poured into the coffee bean box, click
[save]. Each time you add coffee beans, you need to enter the weight of the additional beans.
in Status - Canisters Management - CAL., Find the coffee bean column, click on the calibration
icon ; in the pop-up dialog box "Dispense Time" (range is 1-10 seconds, generally input 2-3
seconds), click "Start Test" twice, discard the ground coffee powder!
Open the door of the machine, take an empty cup and put it on the electronic scale to clear the
zero, then place it on the grinder outlet and click "Start Test" again.
Weigh the resulting coffee powder, enter the number of grams in the touch screen at the
"Discharge" and "Save".
Put the empty cup on the electronic scale to clear the zero and put it on the grinder outlet, then
do the "Start Test" again, weigh the powder dropped, compare the weight value with the value
at the "Discharge", if the deviation is within ±0.3 grams per second, it is considered Normal, if
the deviation is too large, recalibrate according to the above method until the value is OK. Once
the calibration is complete, there is no need to recalibrate if the same brand of coffee beans is
added again.
6.3 Instant cartridge calibration
Canisters calibration is a software done for the physical properties of the instant canisters and
the physical properties of the powder. Before calibration, you need to prepare the electronic scale
and cups, and the calibration method is the same as the grinder calibration above.

15
Important:
Failure to calibrate will cause the machine to dispense abnormal powder!
Make sure that the canister outlet is filled before calibration, which can be achieved by the
"powder drop test" function, the outlet is not full and will lead to inaccurate calibration.。
Note:
Because each part or powder has different physical properties, each time the canister, motor or
powder is replaced, it needs to be recalibrated with the amount of powder in the canister greater
than 1/3 of the canister volume at the time of calibration.
Use the key to open the machine door; Press and hold the upper left corner of the screen, enter the
password in the pop-up dialog box, administrator password: jn9527 or maintenance password:
9527. Then enter the machine background "coffee machine" interface.
In the Status - Canisters Management - fill, click , in the pop-up dialog box [Fill] enter the
weight of milk powder poured into the canister, click [Save]. The weight of the coffee beans to
be added each time the powder is added.
Remove the mixer under the canister, prepare the cup and electronic scale, and put the cup on
the electronic scale to clear the zero (tare). Place the cup under the canister outlet.
In the Status - Canisters Management –CAL. Find the milk powder column, click the calibration
icon ; in the pop-up dialog box "Discharge Time" (range is 1-10 seconds, usually 2-3 seconds),
click "Start Test", The machine will automatically dispense the powder, confirm that the powder
is finished, pour the powder back to the raw material box, put the cup on the electronic scale to
clear the zero and put it back to the bottom of the material box outlet, click "Start Test" again,
confirm that the powder is finished, then use the electronic scale to weigh; in the touch screen,
"Dispense", enter the number of grams, and then "Save".
Put the empty cup on the electronic scale to clear the zero and then place the powder box
outlet, then do the "start test" again, weigh the fallen powder and compare the weight value
with the value at the "discharge", if the deviation is within ±0.3 grams per second, it is
considered normal. If the deviation is too large, recalibrate according to the above method until
the value is OK.
The remaining two boxes filled with powder weight and calibration methods are the same as
the milk powder.

16
6.4 Recipe Management and Testing
Press the upper left corner of the screen, in the pop-up dialog box, enter the password: jn9527; click
[recipe], in the pop-up recipe management interface, select the corresponding product, in the
pop-up recipe parameters interface, you can adjust the product water, material quantity, mixer
speed, delay time, modified [save], click [start cooking] to make drinks.
Recipe management can customize recipe, add recipe, delete recipe, start cooking, save recipe, save
product, import recipe, export recipe, and recipe editing function. Editing of the corresponding
functions can be implemented in the corresponding modules.
Note:
By analogy, the calibration method for sugar and cocoa is the same as that for milk
powder, which needs to be calibrated according to the above method; recalibration is required
when the machine is new or when updating the canisters, motor or different brands of raw
materials; recalibration is not required when replenishing the canisters.

17
7Set vending mode and drink price
7.1 Set vending mode
Free mode selling interface - No product price Payment mode selling interface - with
product prices
1) Long press the upper left corner of the screen and enter the password: jn9527 in the pop-up
dialog box;
2) Click the [Payment Configuration] button to set the payment mode in the pop-up interface.
3) Click [QR code] -> you can choose [WeChat], [Alipay] and other payment methods
4) [Free] switch is enabled, which means free mode is on and no payment is needed.
5) MDB cash, MDB swipe card switch enabled, representing payment mode on, need to pay
successfully before the machine can make products.
6) [Server List] Offline mode should be enabled in free mode; Offline mode should be disabled in
payment mode to ensure normal network.

18
7.2 Setting Drink Prices
The machine backend allows setting different prices for each drink. Enter the password to enter the
background, the background can set the price for each beverage, but also to remove and modify
the product name, change the product picture; discount the price.
Tap [Batch Price Adjustment], select all, reverse select, [OK]to adjust the price of all products; set the
price of a single product, click on the product price can be set individually; tap [Normal], the
drop-down menu can select hot, normal, off the shelf.
Drink management: can add new drinks, batch delete, batch price adjustment, import drinks, export
drinks, edit and delete single drink function.
8Drinks making
Selection of a beverage under the user interface.
Adjust the taste in the touch screen, there are three levels, and then confirm; (this step can be
canceled in the factory settings according to customer needs)
the machine makes drinks directly in free mode; several payment methods will appear in the
machine in payment mode (MDB cash, MDB swipe card, WeChat payment QR code, Alipay
payment QR code)
Discharge nozzle to place the cup, after the payment is successful, the machine automatically
starts making drinks.
A prompt in the touch screen interface after the beverage is made.
Customers can set the language of the user interface according to their needs (Enter machine
background, "status" screen, click [language]).
1、Product list page: Showing all currently
selling drinks
2、Taste adjustment: coffee concentration, can
be freely adjusted, click OK after adjustment

19
9Software Upgrade
Local upgrade: put the software package (APK file) to be upgraded into a USB drive (choose 8G or
less USB drive).
Enter the background to open the machine gate, insert the U disk into the machine gate backplane
USB port; click [More Setting] in the background status page; the following pop-up window will
appear, point [Local Upgrade APP] > select the software package that the U disk needs to be
upgraded, press [OK] to start upgrading the software.
Note: Do not power off the software upgrade process, the software will automatically restart after a
successful upgrade, please wait patiently.
See later chapter 11 for detailed instructions on app installation and upgrade.
10 Cleaning
Thorough cleaning and maintenance is a basic requirement to achieve food hygiene conditions.
Only with regular (twice a week or more frequently depending on the specific use) maintenance,
cleaning and servicing can the machine provide superior tasting drinks and satisfy customers.
Jetinno is designed with all relevant criteria in mind to reduce maintenance costs and improve
operational efficiency.
3、Payment page: MDB cash, MDB swipe
card.
4、Product making page: After payment is
completed, will enter the interface of product
animation.
