JETStream JEC-2000 User manual

Owner's
manual
Owner's
manual
HOME MAGNETIC ELLIPTICAL
ASSEMBLY INSTRUCTION JEC-2000

- 1 -
JEC-2000 ELLIPTICAL ASSEMBLY INSTRUCTION
Step 1. Unpack the box and place all the parts on the floor.
Step 2. Remove the bolts (04), nuts (06) and washers (05) from the front stabilizer and rear
stabilizer (02/03).
Attach the front stabilizer and rear stabilizer (02/03) to the main frame (01). Replace the
bolts, nuts and washers and tighten using the supplied spanner.
Step 3. Take the disc cap (28) off the main from (01).
2
4
1
28
6
5
3
4

- 2 -
Step 4. Remove the screws (24) and washers (05) from the main post (12). Connect the top
tension control cable (13) and bottom tension control cable (14). Then take off the part
(14A).
Next, connect the top computer cable (19) and the bottom computer cable (21). Slide
the main post (12) into the main frame (01) and secure it into place using screws (24)
and washers (05) provided.
Step 5. Remove the nut (35) and the washer (34) from the right arm of disc (9R). Insert the arm
of the disc (9R) into the hole of the right pedal tube (8R) and fix into place by tightening
the nut (35) and the washer (34). Repeat step 4 to install the left disc (9L) on the other
side.
19
29A
21
14
13
14A
7L
19
13
8R
8L
21
5
24 35
34
12
1
14A
19
14
34
35
9

- 3 -
Step 6. Put both discs (09) on the axle (A1) and tighten the lock-nut (10) into place. Place the
lock-nut cap (11) over the lock-nut. (10).
29A 19
11
10
29A
10
11

Step 7. Screw the racing bar (15A) into place by tightening the bolts (31), washers (32) and nuts
(06). Connect the grip pulse wires (29/29A) together. Insert the handlebar (15R/15L) into
the support tube (7R/7L) and fasten the bolts (30) and washers (05).
Step 8. Connect the top computer cable (19) and the bottom hand pulse wire (29A) to the
computer (20). Slide the computer (20) onto the computer holder on top of the handlebar
post (12) and screw (20A) them in.
Step 9. Fit the pedal (22R/22L) onto the pedal tube (08R/08L) using the bolts (33), knobs (18)
and washers (32).
- 4 -
15A 15R
2020A
19
32
6
15L
30
5
31
7R
33
22L
22R
32
18
18
32
7L

- 5 -
EXPLODED VIEW
23
25
17
15R
29
20
17A
15A
25
17 17B
29A
15L
29
30
5
32
31
16
19
20A
30 5
29A
17B
29A
29A
6
12
22R
33
7R
7L
19 13
8L
8R
33
22L
32
18
35
34
21
14
14A
5
24 9
10 11
34
35
2
9
11
10
26
4
27
28
6
5
3
1
36L
36R
4
37

- 6 -
PARTS LIST
GB
JEC2000-040722GB
S/N Descriptions Qty
1 Main frame 1
2 Front stabilizer 1
3 Rear stabilizer 1
4 M8 Bolt x60mm 4
5 M8 Arc washer 12
6 M8 Nut 8
7R Support tube - R 1
7L Support tube - L 1
8R Pedal tube - R 1
8L Pedal tube - L 1
9 Disc 2
10 Lock-nut 2
11 Lock-nut cap 2
12 Main post 1
13 Top tension control cable 1
14 Bottom tension control cable 1
14A Clip 1
15R Handlebar - R 1
15L Handlebar - L 1
15A Racing bar 1
16 Tension control 1
16A Screw 1
17 Foam grip (A) 2
17A Foam grip (B) 1
17B Foam grip (C) 2
18 Knob 4
19 Top computer cable 1
20 Computer 1
20A Screw 2
21 Bottom computer cable 1
22R Pedal - R 1
22L Pedal - L 1
23 Handlebar Cap 2
23A 30 x 60 plug 1
23B 20 x 40 plug 2
24 M8 Screw x 12mm
25 Hand pulse sensor 2
25A Cap 3
26 Foot cap (A) 2
27 Foot cap (B) 2
28 Disc Cap 2
29 Top hand pulse wire 2
29A Bottom hand pulse wire 1
30 M8 bolt x 16mm 4
31 M8 bolt x 40mm 4
32 M8 Washer 8
33 Foot pedal bolt 4
34 Washer 2
35 Nut 2
36R Chain cover - R 1
36L Chain cover - L 1
37 Front chain cover 1
