JETWAY For Socket 370 User manual

630CF/630CN
USER'S MANUAL
M/B For Socket 370 Pentium

IIIProcessor
N . G03-630CFR3A
Release date: JAN 2001
** Year 2001 compliant **
Trademark:
* Pentium is registered trademark and MMX is a trademark o Intel Corporation,
the other names and brands are the property o their respective owners
* Speci ications and In ormation contained in this documentation are urnished or in ormation use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manu acturer.

USER’S NOTICE.............................................................................1
MANUAL REVISION INFORMATION............................................2
THERMAL SOLUTIONS.....................................................................................2
CHAPTER 1 INTRODUCTION OF 630CF/630CN MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD...............................................................3
1-2 SPECIFICATION...........................................................................................4
1-3 PERFORMANCE LIST.................................................................................5
1-4 LAYOUT DIAGRAM & JUMPER SETTING............................................6
CHAPTER 2 HARDWARE INSTALLATION
2-1 HARDWARE INSTALLATION STEPS......................................................8
2-2 CHECKING MOTHERBOARD'S JUMPER SETTING...........................8
2-3 INSTALL CPU................................................................................................9
2-3-1 ABOUT PENTIUM & CELERON™ 370-PIN CPU...............................9
2-3-2 SETTING CPU BUS CLOCK & MEMORY CLOCK JUMPER.............11
2-3-3 INSTALL CPU..............................................................................................12
2-3-4 OVERCLOCK RUNNING..........................................................................12
2-4 INSTALL MEMORY.....................................................................................13
2-5 EXPANSION CARD.......................................................................................15
2-5-1 PROCEDURE FOR EXPANSION CARD INSTALLATION..................15
2-5-2 ASSIGNING IRQ FOR EXPANSION CARD............................................15
2-5-3 INTERRUPT REQUEST TABLE FOR THIS MOTHERBOARD..........16
2-6 CONNECTORS, HEADERS.........................................................................16
2-6-1 CONNECTORS............................................................................................16
2-6-2 HEADERS.....................................................................................................20
2-7 STARTING UP YOUR COMPUTER..........................................................23
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP.......................................................................................24
3-2 GETTING HELP............................................................................................25
3-3 THE MAIN MENU.........................................................................................25
3-4 STANDARD CMOS FEATURES.................................................................26
3-5 ADVANCED BIOS FEATURES...................................................................28
3-6 ADVANCED CHIPSET FEATURES...........................................................30
3-6-1 ADVANCED DRAM CONTROL...............................................................31
3-7 INTEGRATED PERIPHERALS..................................................................32
3-7-1 ONCHIP IDE FUNCTION..........................................................................33
3-7-2 ONCHIP DEVICE FUNCTION..................................................................34
3-7-3 WINBOND SUPERIO DEVICE..................................................................35
i
TABLE OF CONTENT

3-8 POWER MANAGEMENT SETUP..............................................................36
3-8-1 PM WAKE UP EVENTS..............................................................................37
3-9 PNP/PCI CONFIGURATION SETUP.........................................................38
3-9-1 IRQ RESOURCES........................................................................................39
3-10 PC HEALTH STATUS.................................................................................40
3-11 FREQUENCY/VOLTAGE CONTROL .....................................................40
3-12 LOAD STANDARD/OPTIMIZED DEFAULTS........................................41
3-13 SET SUPERVISOR/USER PASSWORD....................................................42
CHAPTER 4 DRIVER & FREE PROGRAM INSTALLATION
MAGIC INSTALL SUPPORTS WINDOWS 95/98/98SE/NT4.0/2000..............43
4-1 VGA INSTALL SIS 630 VGA DRIVER.............................................44
4-2 PC-HEALTH WINBOND HARDWARE DOCTOR MONITORING
SOFTWARE............................................................................46
4-2-1 HOW TO UTILIZE PC-HEALTH.............................................................47
4-3 LAN (Only or 630CF) INSTALL SIS 00 PCI FAST ETHERNET DRIVER...47
4-4 SOUND INSTALL SIS 7018 AC' 7 AUDIO DRIVER AND
APPLICATION SOFTWARE....................................................48
4-5 PC-CILLIN INSTALL PC-CILLIN 8 ANTI-VIRUS SOFTWARE AND
APPLICATION PROGRAM......................................................50
4-6 HOW TO DISABLE ON-BOARD SOUND.................................................51
4-7 HOW TO UPDATE BIOS..............................................................................51
ii

USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT
MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN
ANY FORM OR BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE
MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE 630CF MOTHER-
BOARD AND WE DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT
WILL CHANGE, CORRECT ANY TIME WITHOUT NOTICE. MANUFACTURER PROVIDES
THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, AND WILL NOT BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE
OF DATA, INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY
NOT BE REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE
COMPANIES, AND THEY ARE USED ONLY FOR IDENTIFICATION OR EXPLANATION
AND TO THE OWNER’S BENEFIT, WITHOUT INTENT TO INFRINGE.
Manual Revision Information
1

Reversion Revision History Date
3.0 Third Edition Jan 2001
Item Checklist
630CF/630CN
Cable for IDE/Floppy
CD for motherboard tilities
□Cable for USB Port 3/4 (Option)
Cable for COM2
630CF/630CN User’s Man al
Intel Processor Family
Thermal Solutions
As processor technology p shes to faster speeds and higher performance, thermal
management becomes increasingly cr cial when b ilding comp ter systems. Maintaining
the proper thermal environment is key to reliable, long-term system operation. The
overall goal in providing the proper thermal environment is keeping the processor
below its specified maxim m case temperat re. Heatsinks ind ce improved processor
heat dissipation thro gh increased s rface area and concentrated airflow from attached
fans. In addition, interface materials allow effective transfers of heat from the
processor to the heatsink. For optim m heat transfer, Intel recommends the se of
thermal grease and mo nting clips to attach the heatsink to the processor.
When selecting a thermal sol tion for yo r system, please refer to the website below
for collection of heatsinks eval ated and recommended by Intel for se with Intel
processors.
Vendor list for heatsink and fan of Pentium® !!! processor, please visit：
http://developer.intel.com/design/Penti miii/components/index.htm
Vendor list for heatsink and fan of Intel®Celeron™ processor, please visit：
http://developer.intel.com/design/celeron/components/index.htm
Chapter 1
2

Introduction of 630CF/630CN Motherboard
1-1 Feature of motherboard
The 630CF/630CN motherboard is design for se Intel’s new generation Penti m
processors, which tilize the Socket 370 design s pports Penti mIII/Celeron FC-
PGA/PPGA processors, and the memory size expandable to 1GB.
This motherboard se the newest SiS 630 chipset provides a high performance/low
cost sol tion for socket 370 series CPUs based system, by integrating a high
performance North Bridge, advanced hardware 2D/3D GUI engine and S per-So th
Bridge. Moreover, by intergrating the Ultra AGP technology and advanced 128-bit
graphic display interface, SiS 630 delivers AGP 4X performance and p to 2GB/s
memory bandwidth, and provides powerf l hardware decoding DVD accelerator to
improve the DVD playback performance. On-board VGA memory can selected from
2Mb to 64Mb.
This motherboard provides 10/10Mb Fast Ethernet interface (Only for 630CF) for
Office req irement and offers AC’97 compliant interface that comprises digital a dio
engine with 3D-hardware accelerator, on-chip sample rate converter. This motherboard
also provides d al USB host controller with fo r USB Ports that deliver better
connectivity and 2x12Mb bandwidth. The b ilt-in Fast PCI IDE controller s pports
Ultra DMA 33/66 f nction p to 66MB/s for data transfer rate. In addition,
630CF/630CN provides hardware monitor f nction that will monitoring and protect
yo r comp ter.
This motherboard provides high performance & meets f t re specification demand. It
is really wise choice for yo r comp ter.
1-2 Specification
Spec Description
3

Design Micro ATX form factor 4 layers PCB size: 24.5x19.0cm
Chipset SiS 630 Chipset
Clock Generator S pport 66/100/133MHz system B s Clock (CPU B s Clock)
S pport 100/133 MHz system memory clock
S pport 33MHz PCI B s clock
CPU Socket S pport Penti m III 5001GHz processor
S pport Celeron 300733MHz processor
S pport 66, 100 and 133MHz CPU B s clock
Reserves s pport for f t re Intel Penti m III processors
Memory Socket 168-pin DIMM socket x2
PC-100/PC-133 SDRAM
Expandable to 1GB
S pport 3.3V SDRAM DIMM
Expansion Slot 32-bit PCI slot x3, 2.2 Specification Compliant
AMR slot x1
Integrate VGA 3D graphic acceleration
VGA Memory Selectable by BIOS from 2MB to 64MB
Integrate IDE 2 channel of B s Master IDE port s pporting ULTRA DMA
33/66MB/s mode devices
Integrate LAN
(Only or 630CF)
Fast Ethernet Controller 10/100 Mbps
Audio AC’97 Digital A dio controller integrated
AC’97 A dio CODEC on board
A dio driver and tility incl ded
BIOS Award 2MB Flash ROM
Multi I/O PS/2 keyboard and PS/2 mo se connectors
Floppy disk drive connector x1
Parallel port x1
Serial port x2
USB connector x2
USB headers x2 (connecting cable option)
A dio connector (Line-in, Line-o t & Game Port)
1-3 Performance List
The following performance data list is the testing res lt of some pop lar benchmark
testing programs. These data are j st referred by sers, and there is no responsibility
4

for different testing data val es gotten by sers (the different Hardware & Software
config ration will res lt in different benchmark testing res lts.)
CPU: Intel PIII 866MHz FC-PGA package
DRAM: 128M SDRAM x2 (Hy ndai GM 72V66841ET75)
VGA Expansion Card: On Board VGA (Driver V1.05)
Hard Disk Driver: Q ant m Fireball KX20A11
BIOS: Award Optimal defa lt
OS: Win 98SE
Performance Test Report
Share 8M Share 16M Share 32M
3D Mark 99 1908 1918 1912
3D Mark 2000 900 918 916
3D Winbench 99 V1.2 513 525 446
3D Winbench 2000 15.7 20.7 23
Final Reality 5.23 5.25 5.20
Winstone 99 V1.3 29.5 29.5 29.6
Winstone 2000 32.3 33 31.8
Winbench 99 :
CPU Mark 99 67.1 68.1 68.5
FPU Winmark 99 4390 4390 4380
B siness Disk Winmark99 4740 4550 4680
Hi-end Disk Winmark99 17100 16800 16300
B siness Graphic Winmark 217 216 217
Hi-end Graphic Winmark 762 767 767
SYS Mark 2000 : SISMark 2000 Rating ( Internet Content Creation / O ice Productivity )
S ites 156 157 157
Offical 154 155 156
SISOFT Sandra 2000 :
CPU MIPS 2262 2262 2262
FPU MFLOPS 1120 1120 1120
CPU / Memory MB/S 234 236 235
FPU / Memory MB/S 255 257 256
QUAKE3 :
DEMO1 FPS 22.0 22.1 22.2
DEMO2 FPS 21.3 21.6 21.6
1-4 Layout & Jumper Setting
5

Jumpers
Jumper Name Description Page
JP2
JP10, JP11
CPU & SDRAM Freq ency Setting 2x4-pin Block
2x2-pin Block
p.8
JP9 Keyboard Power ON F nction Setting 3-pin Block p.9
JP6 CMOS RAM Clear 3-pin Block p.9
Connectors
Connector Name Description Page
ATX ATX Power Connector 20-pin Block p.16
KB/MOUSE PS/2 Mo se & PS/2 Keyboard 6-pin Female p.16
6

Connector
USB USB Port Connector 2x4-pin Connector p.17
LAN
(Only or 630CF)
LAN Port Connector RJ45 Connector p.17
PRINT Parallel Port Connector 25-pin Female p.17
VGA VGA Port Connector 15-pin Female p.18
GAME A dio/Game Connector 3 phone jack + 15-pin Connector p.18
COM1 Serial Port COM1 Connector 9-pin Connector p.18
FDD Floppy Driver Connector 34-pin Block p.18
IDE1 Primary IDE Connector 40-pin Block p.19
IDE2 Secondary IDE Connector 40-pin Block p.19
Headers
Header Name Description Page
COM2 COM2 Headers 10-pin Block p.20
USB2 USB Port Headers 10-pin Block p.20
HDLED IDE activity LED 2-pin Block p.20
TBLED T rbo LED switch 2-pin Block p.20
RST Reset switch lead 2-pin Block p.20
KEYLOCK Keyboard lock switch 2-pin Block p.20
SPKR Speaker connector 4-pin Block p.21
PWR LED Power LED 2-pin Block p.21
PWR Power switch 2-pin Block p.21
WOL Wake On-LAN Headers 3-pin Block p.21
CPUFAN
SYSFAN
FAN Speed Headers 3-pin Block p.21
IR, CIR IR infrared mod le Headers 10-pin Block p.22
CDIN1, CDIN2 CD A dio-In Headers 4-pin Block p.22
AUX-IN AUX-IN A dio Inp t Header 4-pin Block p.22
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket 370 CPU Socket 370-pin FC-PGA/PPGA CPU Socket p.12
DIMM1, DIMM2 DIMM Mod le Socket 168-pin DIMM SDRAM Mod le
Expansion Socket
p.13
PCI1, PCI2, PCI3 PCI Slot 32-bit PCI Local B s Expansion slots p.16
AMR AMR Slot Modem Riser Card slot
Chapter 2
Hardware installation
2-1 Hardware installation Steps
7

Before sing yo r comp ter, yo had better complete the following steps:
1. Check motherboard setting
2. Install CPU
3. Install Memory
4. Install Expansion cards
5. Connect Ribbon cables, Panel wires, and power s pply
6. Set p BIOS
7. Install software driver & tility
2-2 Checking Motherboard’s Jumper Setting
1. CPU & SDRAM Clock Setting : JP2, JP10, JP11
The motherboard’s CPU & SDRAM memory clock adj sted thro gh j mper JP2,
JP10, JP11. Table as below:
CPU/SDRAM (MHz) JP2 JP10 JP11
1-2 3-4 5-6 7-8
AUTO OFF OFF OFF OFF ON ON
66/66 OFF OFF OFF ON OFF OFF
66/100 OFF OFF OFF OFF OFF OFF
100/100 ON OFF OFF OFF OFF OFF
100/133 ON OFF ON OFF OFF OFF
133/100 ON ON OFF OFF OFF OFF
133/133 ON ON ON OFF OFF OFF
2. Keyboard Power On Function Setting (3-pin): JP9
This allows yo to disable the keyboard power on f nction. Set the j mper to
enabled or disabled if yo wish to se yo r keyboard (by pressing < >) to power on
yo r comp ter. This feat re req ires an ATX power s pply that can s pply at least
300mA on the +5VSB lead. The defa lt is set to disable.
8

3. CMOS RAM Clear (3-pin): JP6
A battery m st be sed to retain the motherboard config ration in CMOS RAM
short 2-3 pins of JP6 to store the CMOS data.
Note: You can clear CM S by shorting 1-2 pin, while the system is off. Then
return to 2-3 pin position. Avoid clearing the CM S while the system is
on, it will damage the motherboard always unplug the power cord from
the wall socket.
2-3 Install CPU
2-3-1 About Pentium III & Celeron™ 370-pin CPU
This motherboard s pports both Penti m III & Celeron 370 pins CPU.
Glossary:
Chipset (or core logic) - two or more integrated circ its which control the interfaces between
the system processor, RAM, I/O devises, and adapter cards.
Processor slot/socket - the slot or socket sed to mo nt the system processor on the
motherboard.
Slot (AGP, PCI, ISA, RAM) - the slots sed to mo nt adapter cards and system RAM.
AGP - Accelerated Graphics Port - a high speed interface for video cards; r ns at 1X
(66MHz), 2X (133MHz), or 4X (266MHz).
PCI - Peripheral Component Interconnect - a high speed interface for video cards, so nd
cards, network interface cards, and modems; r ns at 33MHz.
ISA - Ind stry Standard Architect re - a relatively low speed interface primarily sed for
so nd cards and modems; r ns at approx. 8MHz.
9

Serial Port - a low speed interface typically sed for mo se and external modems.
Parallel Port - a low speed interface typically sed for printers.
PS/2 - a low speed interface sed for mo se and keyboards.
USB - Universal Serial Bs - a medi m speed interface typically sed for mo se, keyboards,
scanners, scanners, and some digital cameras.
Sound (interface) - the interface between the so nd card or integrated so nd connectors and
speakers, mic, game controllers, and MIDI so nd devices.
LAN (interface) - Local Area Network - the interface to yo r local area network.
BIOS (Basic Inp t/Otp t System) - the program logic sed to boot p a comp ter and
establish the relationship between the vario s components.
Driver - software, which defines the characteristics of a device for se by another device or
other software.
Processor - the "central processing nit" (CPU); the principal integrated circ it sed for doing
the "comp ting" in "personal comp ter"
Front Side Bus Frequency
The working freq ency of the motherboard, which is generated by the clock generator for
CPU, DRAM and PCI BUS.
CPU Internal Frequency
The freq ency of CPU, which is also the act al working freq ency of CPU.
Bus Frequency Ratio
The ratio of the working freq ency, m ltiply Front Side B s Freq ency with B s
Freq ency Ratio will form the CPU Internal Freq ency.
CPU L2 Cache
The flash memory inside the CPU, normally Penti m III CPU has 256K or above,
while Celeron CPU will have 128K.
Recognize of CPU
The way to recognize the speci ication o CPU rom the packing Pentium III 370
pins FC-PGA
On the s rface of the CPU as shown on the right pict re, nder the word of
“PENTIUM III” the code is:
RB 80526 P2 866 256
RB : FC–PGA packing
P2 : P2–133MHz front side b s freq ency
PY–100MHz front side b s freq ency
866 : CPU internal freq ency, where here is
866MHz
256 : the size of L2 cache, where here is 256K
10

Celeron FC–PGA
On the s rface of the CPU as shown on the right pict re, nder the word of “Celeron”
the code is:
566/128/66/1.5V
566 : CPU internal freq ency, where here is 566MHz
128 : the size of L2 cache, where here is 128K
66 : front side b s freq ency, where here is 66MHz
1.5V : the voltage for the CPU
2-3-2 Setting CPU Bus Clock & Memory Clock Jumper
Setting the ront side bus requency and SDRAM requency
The motherboard uses jumper JP2 for the front side bus frequency and SDRAM
frequency setting as shown from the tab e be ow:
CPU/SDRAM (MHz) 1-2 3-4 5-6 7-8
66/66 OFF OFF OFF ON
66/100 OFF OFF OFF OFF
100/100 ON OFF OFF OFF
100/133 ON OFF ON OFF
133/100 ON ON OFF OFF
133/133 ON ON ON OFF
Example: Using a Pentium

III 866 CPU with front side bus frequency of
133MHz and PC-133 SDRAM module, the setting of JP2 are 1-2 closed,
3-4 closed, 5-6 closed for CPU BUS CL CK to be 133MHz and SDRAM
CL CK to be 133MHz.
For experience user looking for over clocking, Please refer to sec 2-3-4
2-3-3 Install CPU
This motherboard Provides a ZIF socket 370. The CPU that comes with the
motherboard sho ld have a cooling FAN attached to prevent overheating. If this is not
the case, then p rchase a correct cooling FAN before yo t rn on yo r system.
WARNING! Be s re that there is s fficient air circ lation across the processor’s
heatsink and CPU cooling FAN is working correctly, otherwise it
11

may ca se the processor and motherboard overheat and damage,
yo may install an a xiliary cooling FAN, if necessary.
To install a CPU, first t rn off yo r system and remove its cover. Locate the ZIF
socket and open it by first p lling the level sideways away from the socket then
pward to a 90-degree angle. Insert the CPU with the correct orientation as shown
below. The notched corner sho ld point toward the end of the level. Beca se the CPU
has a corner pin for two of the fo r corners, the CPU will only fit in the orientation as
shown.
When yo p t the CPU into the ZIF socket. No force req ire to insert of the CPU,
then press the level to Locate position sightly witho t any extra force.
2-3-4 Over clock Running
WARNING! This section is for experienced motherboard installer only. Over
clocking can res lt in system nstability or even shortening life of
the processor.
After setting the J mper JP2 yo can choose overclock r nning by BIOS CMOS
SETUP UTILITY. When yo entered CMOS SETUP UTILITY, choose “Freq ency/
Voltage control” yo will see the screen as below then.
1. Yo can choose the sit ation yo want to try.
CPU/SDRAM (MHz) 1-2 3-4 5-6 7-8
66/66 OFF OFF OFF ON
66/100 OFF OFF OFF OFF
100/100 ON OFF OFF OFF
100/133 ON OFF ON OFF
133/100 ON ON OFF OFF
12

133/133 ON ON ON OFF
CMOS Setup Utility - Copyright (C) 1984-2000 Award Software
requency/Voltage Control
Cyrix III Clock Ratio Default
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Disabled
CPU Host/DRAM Clock Default
CPU Clock Ratio Jumpless x 3.0
Item Help
Menu Level >
:Move Enter:Select +/-/PU/PD:Value 10:Save ESC:Exit 1:General Help
5:Previous Values 6:Optimized Defaults 7:Standard Defaults
NOTE! The BIOS allows yo select B s Freq ency from 66MHz to 133MHz, the
wrong setting will ca se system can not starting, when it happen yo have
to clear CMOS and adj st correct setting for yo r CPU. Again we don’t
s ggest ser r nning overclock.
2-4 Install Memory
This motherboard provides two 168-pin DUAL INLINE MEMORY MODULES
(DIMM) sites for memory expansion available from minim m memory size of 16MB
to maxim m memory size of 1GB SDRAM.
Va id Memory Configurations
Bank 168-Pin DIMM Total Memory
Bank 0, 1
(DIMM1)
SDRAM 32, 64, 128, 256, 512MB X 1 16MB512MB
Bank 2, 3
(DIMM2)
SDRAM 32, 64, 128, 256, 512MB X 1 16MB512MB
Total System Memory (Max. 1GB) 16MB1GB
13
CPU Host/DRAM Clock
Default [ ]
66/66MHz ..... [ ]
66/100MHz ..... [ ]
75/75MHz ..... [ ]
83/83MHz ..... [ ]
95/95MHz ..... [ ]
96/96MHz ..... [ ]
97/97MHz ..... [ ]
100/100MHz ..... [ ]
100/133MHz ..... [ ]
112/112MHz ..... [ ]
133/100MHz ..... [ ]
133/133MHz ..... [ ]
:Move ENTER:Accept ESC:Abort

Generally, installing SDRAM mod les to yo r motherboard is very easy, yo can
refer to fig re 2-4 to see what a 168-Pin PC100 & PC133 SDRAM mod le looks like.
NOTE! When yo install DIMM mod le f lly into the DIMM socket the eject tab
sho ld be locked into the DIMM mod le very fimly and fit into its
indention on both sides.
WARNING! For the SDRAM CLOCK is set at 133MHz, se only PC133-
compliant DIMMs. When this motherboard operate at 133Mhz,
most system will not even boot if non-compliant mod les are sed
beca se of the strick timing iss es, if yo r DIMM are not PC133-
compliant, set the SDRAM clock to 100MHz to ens re system
stability.
2-5 Expansion Cards
WARNING! T rn off yo r power when adding or removing expansion cards or
other system components. Fail re to do so may ca se severe
damage to both yo r motherboard and expansion cards.
2-5-1 Procedure For Expansion Card Installation
1. Read the doc mentation for yo r expansion card and make any necessary
hardware or software setting for yo r expansion card s ch as j mpers.
2. Remove yo r comp ter’s cover and the bracket plate on the slot yo intend to se.
14
Figure 2-4

3. Align the card’s connectors and press firmly.
4. Sec re the card on the slot with the screen yo remove above.
5. Replace the comp ter system’s cover.
6. Set p the BIOS if necessary.
7. Install the necessary software driver for yo r expansion card.
2-5-2 Assigning IRQs For Expansion Card
Some expansion cards need an IRQ to operate. Generally, an IRQ m st excl sively
assign to one se. In a standard design, there are 16 IRQs available b t most of them
are already in se.
Standard Interrupt Assignments
IRQ Priority Standard unction
0 1 System Timer
1 2 Keyboard Controller
2 N/A Programmable Interr pt
3 * 11 Comm nications Port (COM2)
4 * 12 Comm nications Port (COM1)
5 * 13 So nd Card (sometimes LPT2)
6 14 Floppy Disk Controller
7 * 15 Printer Port (LPT1)
8 3 System CMOS/Real Time Clock
9 * 4 ACPI Mode when enabled
10 * 5 IRQ Holder for PCI Steering
11 * 6 IRQ Holder for PCI Steering
12 * 7 PS/2 Compatible Mo se Port
13 8 N meric Data Processor
14 * 9 Primary IDE Channel
15 * 10 Secondary IDE Channel
* These IRQs are s ally available for ISA or PCI devices.
2-5-3 Interrupt Request Table For This Motherboard
Interrupt request are shared as shown the tab e be ow:
INT A INT B INT C INT D
PCI slot 1 Shared  
PCI slot 2   Shared 
PCI slot 3 Shared
Onboard VGA    
AC97/MC97 Shared  
Onboard USB Shared
Onboard USB 2 Shared
LAN ( or 630CF Only)   Shared 
15

IMPORTANT! If sing PCI cards on shared slots, make s re that the drivers
s pport “Shared IRQ” or that the cards don’t need IRQ assignments.
Conflicts will arise between the two PCI gro ps that will make
the system nstable or cards inoperable.
2-6 Connectors, Headers
2-6-1 Connectors
(1) Power Connector: ATX (20-pin block)
ATX Power S pply connector. This is a new defined 20-pins connector that
s ally comes with ATX case. The ATX Power S pply allows to se soft power
on momentary switch that connect from the front panel switch to 2-pins Power
On j mper pole on the motherboard. When the power switch on the back of the
ATX power s pply t rned on, the f ll power will not come into the system board
ntil the front panel switch is momentarily pressed. Press this switch again will
t rn off the power to the system board.
(2) PS/2 Mouse & PS/2 Keyboard Connector: KB/MOUSE
The connectors for PS/2 keyboard and PS/2 Mo se.
(3) USB Port connector: USB
The connectors are 4-pins connector that connect USB devices to the system board.
16

(4) LAN Port connector: LAN (Only or 630CF)
This connector is standard RJ45 connector for Network connector.
(5) Parallel Port Connector (25-pin emale): PRINT
Parallel Port connector is a 25-pin D-S bminiat re Receptacle connector. The
On-board Parallel Port can be disabled thro gh the BIOS SETUP. Please refer to
Chapter 3 “INTEGRATED PERIPHERALS SETUP” section for more detail
information.
(6) VGA Connector (15-pin emale): VGA
17
