JETWAY MI215 Series User manual

MI215 Series
User’s Manual
NO. G03-MI215-F
Revision: 1.0
Release date: July 4, 2023
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

i
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

ii
ENVIRONMENTAL SAFETY INSTRUCTION............................................................................. iii
USER’S NOTICE...............................................................................................................................iv
MANUAL REVISION INFORMATION...........................................................................................iv
ITEM CHECKLIST............................................................................................................................ iv
CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD.........................................................................................1
1-2 SPECIFICATION.................................................................................................................... 2
1-3 LAYOUT DIAGRAM...............................................................................................................4
CHAPTER 2 HARDWARE INSTALLATION
2-1 JUMPER SETTING................................................................................................................ 10
2-2 CONNECTORS, HEADERS AND WAFERS..................................................................... 14
2-2-1 REAR I/O BACK PANEL CONNECTORS......................................................... 14
2-2-2 MOTHERBOARD INTERNAL CONNECTORS................................................. 17
2-2-3 PIN DEFINITION FOR HEADERS & WAFERS.................................................19
2-3 MAXIMUM VOLTAGE & CURRENT LIMIT....................................................................... 26
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP................................................................................................................ 27
3-2 BIOS MENU SCREEN...........................................................................................................28
3-3 FUNCTION KEYS...................................................................................................................29
3-4 GETTING HELP......................................................................................................................29
3-5 MENU BAR..............................................................................................................................30
3-6 MAIN MENU............................................................................................................................ 30
3-7 ADVANCED MENU................................................................................................................31
3-8 CHIPSET MENU..................................................................................................................... 45
3-9 SECURITY MENU.................................................................................................................. 48
3-10 BOOT MENU...........................................................................................................................50
3-11 SAVE & EXIT MENU..............................................................................................................51
3-12 MEBX........................................................................................................................................52
TABLE OF CONTENT

iii
Environmental Safety Instruction
Avoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
0 to 40 centigrade is the suitable temperature. (The temperature comes from the
request of the chassis and thermal solution)
Generally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
The increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
Attention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.

iv
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
1.0 First Edition July 4, 2023
Item Checklist
Motherboard
Cable(s)
I/O Back panel shield

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
Intel®LGA1700 Socket supports 12th /13th Gen. Core Processor (Max. 65W TDPs
under 180A)
Support 2* DDR5 4800MHz SO-DIMM up to 64GB
Integrated with 2* Intel®2.5GbE PCIe LAN chips
2* HDMI, 2* DP, 1* LVDS/eDP Output
Support 6* COM Serial Ports (2*RS232/422/485 & 4* RS232)
MI215Q6700/R6800 series: total support up to 4* USB3.2 (Gen.2), 2* USB3.2
(Gen.1), 4* USB2.0 ports
MI215H6100 series: total support up to 2* USB3.2 (Gen.2), 1* USB3.2 (Gen.1), 3*
USB2.0 ports
MI215Q6700/R6800 series: 2 * SATAIII (6Gb/s) ports with support for RAID 0, 1
mode & 2* M.2 (M-key) slots; 1* M.2 (E-key) & 1* M.2 (B-key) slot along with SIM
card holder; 1* PCIe Gen.4 x16 slot
MI215H6100 series: 2* SATAIII (6Gb/s) ports & 1* M.2 (M-key) slot; 1* M.2 (E-key) &
1* M.2 (B-key) slot along with SIM card holder; 1* PCIe Gen.4 x16 slot
Support onboard TPM 2.0 (*optional to MI215R6802/Q6702/H6102 Series)
Support wide voltage 12V~36V DC-in
Support Smart FAN function
Supports ACPI S3 Function
Compliance with ErP Standard
Support Watchdog Timer Technology

2
1-2 Specification
Spec
Description
Design
Slim Mini-ITX form factor; 10-layers; PCB size: 17.0x17.0cm
Chipset
MI215H6100 Series: Intel®H610E/H610 Chipset (Default: H610)
MI215Q6700 Series: Intel®Q670E Chipset
MI215R6800 Series: Intel®R680E Chipset
CPU Socket
Intel®LGA 1700 Socket supports 12th/13th Gen. Core™ processors (Max.65W
TDPs under 180A)
*Note: for detailed CPU support information please visit our website.
Memory Slot
2* DDR5 SO-DIMM slot
Support 2* DDR5 4800MHz SO-DIMM up to 64GB
Support dual channel function
*Note: MI215R6800 series support ECC.
Expansion
Slot
PCIE1:1* PCIe Gen.4 x16 slot (Max.70W)
M2E1:1* M.2 E-key,type-2230 slot(USB2.0/PCIe x1 interface) supports CNVio
for Wi-Fi
M2B1:1* M.2 B-key, type-3042/3052 slot (USB3.1 /USB2.0/ PCIe x1 interface)
for 4G/5G Module
SIMCARDB1:1* Nano-SIM card slot; co-function with M2B1 slot
Storage
2*SATAIII 6Gb/s port (*SATA1/2)
*Note: MI215Q6700/R6800 series support RAID 0/1 mode.
M2M1: 1* M.2 M-key,type-2280 slot (PCIe Gen.3x4/SATA interface) supports
NVMe
*M2M2:1* M.2 M-Key, type-2242 slot (PCIe Gen.4x4/SATA interface) supports
NVMe
*Note: M2M2 slot is only available to MI215Q6700/R6800 series.
Graphics
Intel®UHD Graphics, shared memory for:
2* DP 1.4a
2* HDMI 2.0b
1* LVDS/eDP
* Note: MI215Q6700/R6800 series support Quad Displays;MI215H6100 series
support Triple Displays
LAN Chips
Integrated with:
MI215R6800 & MI215Q6700:1* Intel i225-LM +1* Intel i225-V 2.5GbE PCIe
LAN chip

3
MI215H6100: 2* Intel i225-V 2.5GbE PCIe LAN chip
Support 10/100/1000/2500Mbps Ethernet data transfer rate
*Note: 2500Mbps high-speed transmission rate is only supported over CAT 5e UTP
cable.
Audio Chip
Realtek HD Audio Codec integrated
Audio driver and utility included
BIOS
AMI 256Mb Flash ROM
Multi I/O
Rear Panel I/O:
MI215Q6700/R6800: 4* USB 3.2 Gen.2 port
MI215H6100: 2* USB 3.2 Gen.2 port & 1* USB 3.2 Gen.1 port + 1* USB 2.0 port
2* 2.5GbE RJ-45 LAN port
2* DP1.4a port
2* HDMI 2.0b port
1* Audio jack (Line-out/MIC combo)
1* 4-Pin 12V~36V Mini-DIN DC-in power jack
Internal I/O Connectors, Headers & Wafers:
1* 12V~36V internal ATX-type power connector (DCIN2)
1 * SATA HDD power-out connector
1* CPUFAN1 connector
1* CMOS battery connector
1* Front panel header
1* Front panel audio header
1* 3W 8Ωamplifier wafer (SPEAK_CON)
2* RS232/422/485 serial port header (COM1/2)
4* RS232 serial port header (COM3/4/5/6)
MI215Q6700/R6800: 2* USB 3.2 (Gen.1) port (FP_USB3)+ 4* USB 2.0 port
(FP_USB1/2)
MI215H6100: 2* USB 2.0 port (FP_USB1)
1* GPIO/80 port header
1* SMBUS header
1* LVDS/EDP wafer (LVDS_EDP) & 1*Inverter wafer(INVERTER1)
TPM 2.0
Optional for MI215R6802, MI215Q6702 &MI215H6102 Series
OS Support
for detailed OS support information please visit our website for latest update

4
1-3 Layout Diagram
Rear IO Diagram
For MI215R6800/ MI215Q6700 Series:
For MI215H6100 Series:
Warning!!
The board has a 12V~36V DC-in power connector (DCIN3) on I/O back panel and an internal
12V~36V power connector (DCIN2). User can only connect one type of compatible power supply
to one of them to power the system.
USB 3.2 (Gen.2)
Ports
2.5GbE RJ-45
LAN Ports
(2.5 GbE)
HDMI Ports
DisplayPorts
Line-Out/MIC Combo
Audio Jack
12V~36V DC-in
Power Jack
USB 3.2 (Gen.2)
Ports
2.5GbE RJ-45
LAN Ports
(2.5 GbE)
HDMI Ports
DisplayPorts
12V~36V DC-in
Power Jack
USB 2.0 Port
USB 3.2 (Gen.1)
Ports
Line-Out/MIC Combo
Audio Jack

5
Motherboard Internal Diagram-Front
*Note: M2M2 Slot, FP_USB2 & FP_USB3 headers are only available to MI215Q6700/R6800 series.
BATCON
SATAIII Ports
(SATA1/2)
PWROUT
Serial Port Headers
(COM1/2/3/4/5/6)
GPIO
Header
LVDS_EDP
INVERTER1
SMBUS1
Header
Intel LGA1700
CPU Socket
PCIE1: PCIe Gen.4x16 Slot
DDR5 SODIMM Slot x 2
Front Panel
Header
CPUFAN1
Internal ATX-Type
Power Connector
(DCIN2)
SPEAK_CON
Front Panel
Audio Header
M.2 M-Key Slot
(*M2M2)
M.2 M-Key Slot
(M2M1)
USB 3.2(Gen.1)
Header
(*FP_USB3)
M.2 E-Key Slot
(M2E1)
M.2 B-Key Slot
(M2B1)
USB2.0 Headers
(FP_USB1/*FP_USB2)
*Rear IO
Connector
(Refer to Page-4)

6
Motherboard Internal Diagram-Back
*Note: SIM card slot only workable along with M.2 B-key slot.
*SIMCARDB1

7
Motherboard Jumper Position
*Note: The diagrams in the manual are mostly taken from MI215Q6700/R6800 series for illustration
purpose, unless otherwise stated.
JBAT
JP1
COPEN
JP4
JP3
JP5
JAT_ATX

8
Jumper
P/N
Name
Description
Pitch
JBAT
Clear CMOS RAM Settings
3-pin Block
2.0mm
JP1
ME_Features Select
2-pin Block
2.0mm
COPEN
Case Open Message Display Function
2-pin Block
2.0mm
JP3
LVDS_EDP VDD Select
4-pin Block
2.0mm
JP5
INVERTER1 Backlight VCC Select
3-pin Block
2.0mm
JAT_ATX
ATX Mode / AT Mode Select
3-pin Block
2.0mm
JP4
GPIO Header Function Select
2-pin Block
2.0mm
Connectors
P/N
Name
USB1
USB 3.2(Gen.2) Port X2
MI215Q6700/R6800:USB2
USB 3.2(Gen.2) Port X2
MI215H6100:USB2
Top: USB 2.0 Port
Bottom: USB 3.2(Gen.1) Port
LAN1/LAN2
2.5 GbE RJ-45 LAN Port
DP_HDMI1/ DP_HDMI2
Top: DisplayPort (DP1.4a )
Bottom: HDMI Port (HDMI 2.0b)
AUDIO
Line-out/MIC Combo Audio Jack
DCIN3
12V~36V Mini-DIN DC-In Power Jack
DCIN2
Internal 12V~36V ATX-type Power Connector
SATA1/2/3/4
SATAIII Connector
PWROUT
SATA HDD Power-Out Connector
CPUFAN1
CPU Fan Connector
BATCON
CMOS Battery Connector

9
Headers & Wafers
P/N
Name
Description
Pitch
FP
(Front Panel Header)
PWR LED/ HD LED/Power Button /Reset
9-pin Block
2.54mm
FP_AUDIO
Front Panel Audio Header
9-pin Block
2.0mm
SPEAK_CON
3W 8ΩAmplifier Wafer
4-pin Block
2.0mm
COM1/2
RS232/422/485 Serial Port Header
9-pin Block
2.0mm
COM3/4/5/6
RS232 Serial Port Header
9-pin Block
2.0mm
FP_USB1
USB2.0 Port Header
9-pin Block
2.0mm
MI215Q6700/R6800:
FP_USB2
USB2.0 Port Header
9-pin Block
2.0mm
MI215Q6700/R6800:
FP_USB3
USB 3.2 (Gen.1) Port Header
19-pin Block
2.0mm
GPIO
GPIO/80Port Header
10-pin Block
2.0mm
SMBUS1
SMBUS Header
5-pin Block
2.0mm
LVDS_EDP
LVDS/EDP Wafer
30-pin Block
1.25mm
INVERTER1
Inverter Wafer
8-pin Block
2.0mm

10
Chapter 2
Hardware Installation
2-1 Jumper Setting
JBAT (3-pin): Clear CMOS RAM Settings
1
3
1
3
JBAT → Clear CMOS RAM Settings
1-2 Closed: Normal(default);
2-3 Closed: Clear CMOS.
JP1(2-pin): ME_Features Select
Pin1
JP1 → ME_Features Select
Pin1
1-2 Closed: Disable ME_Features.
1-2 Open: Enable ME_Features(default);
JBAT
JP1

11
COPEN (2-pin): Case Open Message Display Function
COPEN → Case Open Detection
CASE OPEN
GND
Pin1
Pin 1-2 Short:When Case open function pin short to GND, the Case open function was detected.
When Used, needs to enter BIOS and enable ‘Case Open Detect’function. In this case if your
case is removed, next time when you restart your computer, a message will be displayed on
screen to inform you of this.
JP3 (4-pin): LVDS_EDP VDD Select
JP3 → LVDS_EDP VDD Select
6
4
2
3
1
5
6
4
2
1
3
5
6
4
2
1
3
5
2-4 Closed:
VCC=3.3V
(default);
3-4 Closed:
VCC=5V;
4-6 Closed:
VCC= 12V.
**Warning! Wrong voltage setting will result in screen burn out.
COPEN
JP3

12
JP5(3-pin):INVERTER1 Backlight VCC Select
3
1
3
1
JP5 → INVERTER1 Backlight VCC Select
1-2 Closed: VCC=5V(default);
2-3 Closed: VCC=12V.
**Warning! Wrong voltage setting will result in screen burn out.
JAT_ATX (3-pin): AT Mode /ATX Mode Select
3
1
3
1
JAT_ATX → ATX/AT Mode Select
1-2 Closed: ATX Mode Selected(default);
2-3 Closed: AT Mode Selected.
*ATX Mode Selected: Press power button to power on after power input ready;
AT Mode Selected: Directly power on as power input ready.
JP5
JAT_ATX

13
JP4(2-pin): GPIO Header Function Select
Pin1
JP4 → GPIO Function Select
Pin1
1-2 Closed:Function as GPIO Port(default).
1-2 Open: Function as 80 Port;
JP4

14
2-2 Connectors, Headers & Wafers
2-2-1 Rear I/O Back Panel Connectors
*Refer to Page-4 Rear IO Diagram
Icon
Name
Function
USB 3.2 (Gen.2)
Port
To connect USB keyboard, mouse or other devices
compatible with USB 3.2 (Gen.2) specification. Ports
support up to 10Gbps data transfer rate.
Top: USB 2.0 Port
Bottom: USB 3.2 (Gen.1) Port
Top: To connect USB keyboard, mouse or other
devices compatible with USB 2.0 specification.
Bottom: To connect USB keyboard, mouse or other
devices compatible with USB 3.2 (Gen.1)
specification.
Display1.4a Port
Top: To connect display device that support DP1.4a
specification.
HDMI2.0b Port
Bottom: To connect display device that support
HDMI2.0b specification.

15
Line_Out/MIC Combo
Audio Jack
This connector can functions as audio Line-Out jack
and MIC jack with compatible cables & devices.
Mini-DIN
Power Jack
For user to connect compatible power adapter to
provide power supply for the system.
2.5Gbps
RJ-45 LAN Port
This connector is standard RJ-45 LAN jack for
Network connection which
supports10/100/1000/2500 Mbps Ethernet data
transfer rate (*Note:2.5Gbps is only supported with
CAT 5e UTP cable).
(1) 2.5GbE RJ-45 Ethernet Connectors
** There are two LED next to the RJ-45 LAN port. Please refer to the table below for LAN
port LED indications.
2.5Gbps RJ-45 LAN port LED Signals:
Activity/Link
LED
Speed
LED
A
B
*Note: 2.5Gbps high-speed transmission rate is only supported over CAT 5e UTP cable.
