Jiafu JFMC-SSE331-10 User manual

User Manual
10/100M/1000M Single-mode
Single-fiber-(10KM)
Media Converter

Fiber Media converter
The non-managed media converters, which give you
economic solutions for media conversion between fiber
and copper Ethernet. It provides you SC,FC or ST
connectors for your fiber optic cables and RJ45 for
twisted pair UTP cable connection.The maximum
extension is up to 120km over fiber.
Features
In conformity to IEEE802.3 10base-T, IEEE802.3u
100base-TX/FX,IEEE802.3ab1000base-T,IEEE802.
3z,1000base-SX/LX,IEEE802.1a,IEEE802.1PQ0S,I
EEE802.1d Spanning Tree.
Hot Plug-gable & Wall-Mountable.
Stable performance more than 50thousand hours
with fault-free.
Unique IC solution applied.
Supports 10/100Mbps and 10/100/1000M full/half
duplex, easy upgrades.
Auto MDI/MDI-X.
Auto Negotiation

Support flow control.
Concentrated into EF16-D220(16slot for media
converter cards) or EF14-D220(14slot for media
converter standalone type) 2U rack-mount chassis.
Stable performance more than 50 thousands hours
with fault-free
In conformity with safety code of FCC, CE and
RoHS.
Specifications
Optical
Interfac
e
Connector
1x9 SC/FC/ST
Data Rate
100Mbps, 1000Mbps
Duplex
Mode
Full duplex
Fiber
MM 50/125um,62.5/125um
SM 9/125um
Distance
10/100Mbps:
MM 2km,SM 25/40/60/80/100/120km
10/100/1000Mbps:
MM 550m/2km,SM 20/40/60/80km
Wavelengt
h
MM 850nm,1310nm
SM 1310nm,1550nm
WDM Tx1310/Rx1550nm(A side),Tx1550/Rx1310nm(B
side)
WDM Tx1490/Rx1550nm(A side),Tx1550/Rx1490nm(B
side)
UTP
Interfac
Connector
RJ45
Data Rate
10/100Mbps, 10/100/1000Mbps

e
Duplex
Mode
Half/full duplex
Cable
Cat5,Cat6
Power
Input
Adapter
Type
DC5V
Power
Built-in
Type
AC100~240V
Power Consumption
＜3W
Weight
Adapter
Type
0.39kg
Power
Built-in
Type
0.67kg
Dimensi
ons
Adapter
Type
94*70.5*26.5cm
Power
Built-in
Type
140.5*111*30cm
Temperature
0~50℃Operating; -40~70℃Storage
Humidity
5~95%(no condensing)
MTBF
≥10.0000h
Certification
CE,FCC,RoHS
Application
Extend your Ethernet connection up to 0~120km
away using fiber optics
Creates an economical Ethernet-fiber/copper-fiber
link for connecting remote sub-networks to larger
fiber optic networks/backbones

Converts Ethernet to fiber, fiber to copper/Ethernet,
ensuring optimum network scalability for connecting
two or more Ethernet network nodes (e.g. connecting
two buildings on the same campus)
Designed to provide high-speed bandwidth for
demanding large scale work groups that require
expansion of Gigabit Ethernet Network
System Design
1. For Networking

2. For CCTV Surveillance Security
Product Pictures
10/100M Dual Fiber
10/100M Single Fiber
10/100/1000M Dual Fiber
10/100/1000M Single Fiber
