JK Audio RemoteAmp Blue User manual

JK Audio
RemoteAmp™
User Guide
Stereo Headphone Amplier

ii RemoteAmp Stereo Headphone Amplier
Welcome
Thank You
Thank you for purchasing the
JK Audio RemoteAmp. Please read
this guide for instructions on setting
up and using your new product.
Getting Assistance
If you have any questions,
call us M-F: 8:30am-5:00pm (CT)
In the US & Canada (Toll-Free)
800-552-8346
All other countries dial:
815-786-2929
Email us at:
[email protected]
Or, check out our FAQ section
for answers to common questions.
Limited Warranty
RemoteAmp is covered by a 2 year
warranty to be free from defective
workmanship and materials. To obtain
service, contact JK Audio by phone
or email for return authorization.
Once authorized, you will carefully
pack and ship the faulty product and
all accessories to us. You will pay
for shipping to us and we will pay for
return back to you.
This warranty does not cover damages
due to accident, weather, re, ood,
earthquake, misuse, unauthorized
repairs or modications, or damages
occurred in shipping, only defective
workmanship or materials.
There are no expressed or implied
warranties which extend beyond
the warranty here made.

Contents iii
Safety Precautions
Caution: To prevent possible hearing damage,
avoid listening at high volume levels for long periods.
RemoteAmp contains a headphone amplier that is more powerful
than the typical consumer product.
JK Audio products are designed for the broadcast industry. The
broadcast professional must be able to hear headphone signals over
the ambient noise level. From the cheering crowd at a football game
to trackside at a car race, the program material or cues must be heard
at high volumes without distortion.
Road Safety
Never use headphones while driving or cycling, etc. It can be
dangerous to turn up the volume even while walking. Doing so may
hinder your hearing and can be hazardous on the roadways or at
pedestrian crossings.
Handle with Care
While RemoteAmp was designed to be very rugged and durable,
it is not waterproof and care should be taken to keep the unit dry.

iv RemoteAmp Stereo Headphone Amplier
Overview 1
Setup 2
Operation 4
FAQs 5
Technical Information 7
Welcome

Overview 1
Overview
Compatible with TW (Two-Wire)
Party-Line Intercoms (Listen-Only)
XLR Line level Input Jack
1/8" (3.5mm) Stereo Line Input Jack
Master Level Control
1/4" Stereo Headphone Jack
1/8" (3.5mm) Stereo Headphone Jack
Battery Test Indicator
Stainless Steel Belt Clip
>20 Hours on one 9V Battery
Features
Introducing RemoteAmp
The RemoteAmp is a simple battery-powered personal headphone amplier.
Use the RemoteAmp as an IFB earpiece or headphone amplier, or as an
on-stage monitor headphone amplier. This low-distortion, ½ watt amplier
will cut through the crowd noise without distortion.

2RemoteAmp Stereo Headphone Amplier
Setup
12 3
46
5

Setup 3
Setup
5. 1/8"Stereo Line Input
Connect the headphone output of
any device to this low impedance
unbalanced stereo 1/8" (3.5mm)
Line Input jack.
6. XLR Line Input
The input XLR accepts line level
signals from your mixer, distribution
amplier or phone line hybrid.
The balanced input XLR is wired:
Pin 1 Pin 2 Pin 3
Ground Signal + Signal -
This is a transformer balanced input.
If you are using an unbalanced
source, you must connect your signal
lead to Pin 2 and then connect your
ground to Pins 1 and 3.
1. Level Control
Controls the level of audio from
both the mono XLR and stereo
1/8" (3.5mm) inputs.
2. 1/8"Stereo Headphone Jack
The 1/8" (3.5mm) Stereo
Headphone Jack provides a mix
of the XLR Line input and the
1/8" (3.5mm) Stereo Line Input.
3. 1/4"Stereo Headphone Jack
The 1/4"Stereo Headphone Jack
provides a mix of the XLR Line
input and the 1/8" (3.5mm) Stereo
Line Input.
4. Power Switch
Flip this switch Up to activate the
unit. Flip this switch Down to turn
the unit o󰀨.

4RemoteAmp Stereo Headphone Amplier
Gain Adjustment
Behind the back cover of the
RemoteAmp you will nd two jumpers
on the circuit board — J7 for the
Left channel and J8 for the Right
channel. These jumpers allow you
to adjust the maximum amount of
gain the RemoteAmp delivers. In
the factory default open position you
will receive a maximum of 25 dB
gain. If the jumpers are set to the
optional closed position, a maximum
of 40 dB gain will be delivered.
Operation
Battery
An alkaline battery is strongly
recommended. The battery test
indicator shows the strength of the
battery power remaining. A bright
light indicates plenty of power,
a dim light reminds you to be
prepared with a fresh battery. Once
the LED stops responding to the
test switch, you will begin to hear
signal breakup and distortion as the
battery is drained of its last breath
which may mean minutes or hours
depending on the circumstances.

FAQs 5
Will the RemoteAmp work
with my QuickTap IFB?
Yes. The RemoteAmp will take the
balanced output from the QuickTap
IFB and send it to a 1/4" Stereo
Headphone Jack as well as a 1/8"
(3.5mm) Stereo Headphone Jack.
You can now use headphones, an
earpiece or both.
Can I get more gain out of my
RemoteAmp?
Yes. Take the back o󰀨 of the
RemoteAmp and install both jumpers
(J7,J8). This will give you enough gain
to boost a healthy microphone level
signal to headphone level output.
FAQs

RemoteAmp Stereo Headphone Amplier
Block Diagram
6
JK Audio RemoteAmp
Simplified Block Diagram
May 2, 2018
XLR Line
Input 1/8"(3.5mm)
Headphone
1/4" Headphone
1/8" (3.5mm)
Line Input

Technical Information 7
Line Input
Female XLR: 4k ohms / 100 mV RMS (-18 dBu nom, +4 dBu max)
Max Gain: 46 dB
1/8" (3.5mm) Line In: 50 ohms, -10 dBu nom, +12 dBu max
Headphones
1/4" Stereo Headphone: 8 ohms, 500 mW per channel
1/8" (3.5mm)
Stereo Headphone: 10 ohms, 430 mW per channel
Misc.
Stereo Separation: 46 dB
Frequency Response: 50 Hz - 20 kHz ± 1 dB
Power: One 9 volt Alkaline Battery
Size: 5.1" x 2.7" x 1.3" (13 x 6.9 x 3.3 cm)
Weight: 10 oz. (275 g)
Specications
Technical Information

JK Audio
JK Audio, Inc.
1311 E 6th St.
Sandwich, IL 60548
United States
Telephone: [phone]
Toll Free: 1.800.jkaudio
Fax: [phone]
www.jkaudio.com
© 2018 JK Audio, Inc. All rights reserved.
RemoteAmp™
Stereo Headphone Amplier
User Guide Version 12/17/18
