JL Audio Stealthbox SB-GM-EQNX/10W1v3 User manual

INSTALLATION GUIDE
for the
SB-GM-EQNX/10W1v3
SKU#94503
2010-2017 Chevrolet Equinox / GMC Terrain
Thank you for choosing a JL Audio Stealthbox®for your automotive sound system. With proper installation, your new vehicle-
specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox®installed by your authorized JL Audio dealer. The installation
professionals employed by your dealer have the necessary tools and experience to disassemble and reassemble your vehicle
properly. Also, keep in mind that your warranty coverage extends to 2 years if your system is installed or approved by your
authorized JL Audio dealer. If you prefer to perform your own installation, please read this installation guide completely
before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox®be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
STEP 1
Empty out the trunk of the vehicle so that you have a clean
area to work in.
Continued on Next Page
STEP 2
Remove the trunk floor, as well as the rear sill panel, by
pulling up on the panel to release the clips.
STEP 3
Lift up on the covers of each tie down hook to expose the
screws, and remove both screws and hooks.
SB-GM-EQNX/10W1v3/BK INSTR_SKU# 011318
INSTALLATION
DIFFICULTY:
25
OUT
OF
ESTIMATED TIME:
1 HOUR

Continued on Next Page
SB-GM-EQNX/10W1v3/BK INSTR_SKU# 011318
STEP 7
Remove the two nuts holding the top of the enclosure in
place. Continue by removing the two nuts holding the
bottom of the enclosure in place. Disconnect the sub wiring
and remove the factory sub enclosure. Retain all four nuts
for the installation of the Stealthbox®.
STEP 6
With the side panel out of the vehicle, the factory sub
enclosure can now be removed.
STEP 5
Pictured is the weatherstripping removed from the side
panel. Starting here, begin unclipping the side panel and
continue toward the rear of the vehicle, and remove the
panel.
STEP 4
Open the rear passenger side door. Pull up the
weatherstripping to allow access to the sill panel and side
panel. Remove the sill panel by pulling up on the panel to
release the clips.
Page 2 • JL Audio, Inc 2017
STEP 9
Attach the two Upper Brackets to the Stealthbox® as shown
using a 1/4” Flat Washer, 1/4” Lock Washer, and 1/4 - 20 x
1” Bolt on each. Hand tighten to allow the brackets to be
adjusted later.
STEP 11
Set the Stealthbox® in place by sliding the bottom of the
enclosure behind the Lower Brackets, and aligning the Upper
Brackets with the upper threaded studs. Hand tighten the
factory nuts on the threaded studs, and mark the location of
the Upper Brackets on the top of the enclosure. Firmly press
the enclosure toward the side of the vehicle, slide the Lower
Brackets into place, and mark the location of the Lower
Brackets on the floor of the vehicle.
Remove the Stealthbox®, align the Upper Brackets with the
marks on the enclosure, and firmly tighten. Align the Lower
Brackets with the marks in the vehicle, and firmly tighten.
STEP 10
Attach the two Lower Brackets to the threaded studs using
the factory nuts, as shown. The smaller, angled bracket goes
on the stud closest to the rear of the vehicle. Hand tighten
to allow the brackets to be adjusted later.
STEP 8
Pictured without the factory sub enclosure are the threaded
studs that held the bottom of the enclosure in place. It is not
necessary to remove the bracket for the foam floor support.

SB-GM-EQNX/10W1v3/BK INSTR_SKU# 011318
STEP 15
Reinstall the side panel, tow hooks, sill panels,
weatherstripping, and floor.
STEP 14
Pictured is the Stealthbox® mounted in place.
STEP 13
Attach the two Lower Brackets to the Stealthbox® as shown
using a 1/4” Flat Washer, 1/4” Lock Washer, and a 1/4 - 20 x 1”
Bolt on each, and firmly tighten.
STEP 12
Attach the speaker wire to the Stealthbox®, set the enclosure
back in place, and firmly tighten the factory nuts on the
upper threaded studs.
Page 3 • JL Audio, Inc 2017
STEP 16
CONGRATULATIONS!
You have completed the installation for this model!
Enjoy your new Stealthbox®!
Please refer to the Power Recommendation section for an
amplifier recommendation and basic set-up help.
Continued on Next Page

SB-GM-EQNX/10W1v3/BK INSTR_SKU# 011318
Page 4• JL Audio, Inc 2017
INCLUDED HARDWARE
(4) 1/4” Flat Washer (4) 1/4 - 20 x 1” Bolt (2) Lower Bracket
(4) 1/4” Lock Washer (2) Upper Bracket
SPECIFICATIONS
Enclosure Type: Acoustic Suspension (sealed)
Driver Type: 10W1v3-2
Nominal Impedance: 2 ohm
Continuous Power Handling: 300 watts
POWER RECOMMENDATION
JL Audio recommends high quality amplifiers such as the XD300/1v2. The diagram below shows the
recommended crossover settings for the XD300/1v2. If another amplifier is being used, please reference this
illustration and use similar settings on that amplifier.
All JL Audio amplifiers are very versatile audio components. Please consult the owner’s manual for even more
detailed information about installing and tuning your amplifier.
CONNECTIONS
Using quality power, signal and speaker wire is essential in ensuring the performance of your Stealthbox®.
JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your Stealthbox® amplifier, other
kits are available should you be using more than one amplifier. Signal wire such as the JL Audio Premium
Audio Interconnect Cables should be used that will provide signal for both channels of the amplifier. JL Audio
recommends using 12AWG speaker wire for subwoofers such as our XC-BCS12-25.
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of you vehicle.
Front Speaker Size / Location: 6-1/2”- Front Doors
Fits JL Audio Models: C1-650, C1-650x, C2-650, C2-650x, C3-650,
C5-650, C5-650x, & C7-650cw
Rear Speaker Size / Location: 6-1/2”- Rear Door
Fits JL Audio Models: C1-650, C1-650x, C2-650, C2-650x, C3-650,
C5-650, C5-650x, & C7-650cw
All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered
trademarks of JL Audio, Inc.“Ahead of the Curve”and its respective logo is a trademark of JL Audio, Inc.
JLA-SKU# 011318 12.15.2017 • Printed in USA • ©2017 JL Audio, Inc.
For more detailed information please visit us online at www.jlaudio.com.
