JLG R4045 Use and care manual

Operation and Safety Manual
Original Instructions - Keep this manual with the machine at all times.
®
AS/NZS GB
ANSI
Model
R4045
PVC 2010
31215942
September 1, 2020 - Rev A

WARNING
Operating, servicing and maintaining this vehicle or equipment
can expose you to chemicals including engine exhaust, carbon
monoxide, phthalates, and lead, which are known to the State of
California to cause cancer and birth defects or other
reproductive harm. To minimize exposure, avoid breathing
exhaust, do not idle the engine except as necessary, service your
vehicle or equipment in a well-ventilated area and wear gloves
or wash your hands frequently when servicing. For more
information go to www.P65Warnings.ca.gov.

FOREWORD
31215942 a
FOREWORD
The Mobile Elevating Work Platform (MEWP) models covered in this manual are designed and tested to meet or exceed various
compliance standards. Please refer to the manufacturer’s nameplate affixed to the subject MEWP for specific standard compliance
information.
This manual is a very important tool! Keep it with the machine at all times.
The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating proce-
dures essential for the safe and proper machine operation for its intended purpose.
Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior noti-
fication. Contact JLG Industries, Inc. for updated information.
Refer to www.JLG.com for Warranty, Product Registration, and other machine-related documentation.

SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
b31215942
SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
INDICATES AN IMMINENTLY HAZARDOUS SITUATION. IF NOT AVOIDED, WILL
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE A RED BACK-
GROUND.
INDICATES A POTENTIALLY HAZARDOUS SITUATION. IF NOT AVOIDED, COULD
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE AN ORANGE
BACKGROUND.
INDICATES A POTENTIALLY HAZARDOUS SITUATION. IF NOT AVOIDED, MAY
RESULT IN MINOR OR MODERATE INJURY. IT MAY ALSO ALERT AGAINST
UNSAFE PRACTICES. THIS DECAL WILL HAVE A YELLOW BACKGROUND.
NOTICE
INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY
OR INDIRECTLY TO THE SAFETY OF PERSONNEL OR PROTECTION OF PROP-
ERTY.
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO THE POTEN-
TIAL PERSONAL INJURY HAZARDS. OBEY ALL SAFETY MESSAGES THAT FOLLOW
THIS SYMBOL TO AVOID POSSIBLE INJURY OR DEATH.

SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
31215942 c
THIS PRODUCT MUST COMPLY WITH ALL SAFETY RELATED BULLETINS. CON-
TACT JLG INDUSTRIES, INC. OR THE LOCAL AUTHORIZED JLG REPRESENTA-
TIVE FOR INFORMATION REGARDING SAFETY RELATED BULLETINS WHICH
MAY HAVE BEEN ISSUED FOR THIS PRODUCT.
NOTICE
JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER OF
RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT
THE CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE.
NOTICE
JLG INDUSTRIES, INC. MUST BE NOTIFIED IMMEDIATELY IN ALL INSTANCES
WHERE JLG PRODUCTS HAVE BEEN INVOLVED IN AN ACCIDENT INVOLVING
BODILY INJURY OR DEATH OR WHEN SUBSTANTIAL DAMAGE HAS OCCURRED
TO PERSONAL PROPERTY OR THE JLG PRODUCT.
Contact:
Product Safety and Reliability Department
JLG Industries, Inc.
13224 Fountainhead Plaza
Hagerstown, MD 21742
USA
or Your Local JLG Office
(See addresses on manual rear cover)
In USA:
Toll Free: 877-JLG-SAFE (877-554-7233)
Outside USA:
Phone: [phone]
E-mail: [e-mail]
For:
•Accident Reporting
•Product Safety Publica-
tions
•Current Owner Updates
•Questions Regarding
Product Safety
•Standards and Regulations
Compliance Information
•Questions Regarding Special
Product Applications
•Questions Regarding Prod-
uct Modifications

REVISION LOG
d31215942
REVISION LOG
Original Issue A - September 1, 2020

TABLE OF CONTENTS
31215942 i
SECTION - 1 - SAFETY PRECAUTIONS
1.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
1.2 PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Operator Training and Knowledge. . . . . . . . . . . . . . . . . . . . . .1-1
Workplace Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Machine Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
1.3 OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Trip and Fall Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Electrocution Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Tipping Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Crushing and Collision Hazards . . . . . . . . . . . . . . . . . . . . . . . . .1-9
1.4 TOWING, LIFTING, AND HAULING. . . . . . . . . . . . . . . . . . . . . . . 1-10
1.5 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Maintenance Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Battery Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
SECTION - 2 - USER RESPONSIBILITIES, MACHINE PREPARATION
AND INSPECTION
2.1 PERSONNEL TRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Operator Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Training Supervision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Operator Responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Machine Familiarization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.2 PREPARATION, INSPECTION, AND MAINTENANCE . . . . . . . . .2-2
Inspection and Maintenance Table . . . . . . . . . . . . . . . . . . . . .2-3
2.3 PRE-START INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
2.4 WALK-AROUND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Inspection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
2.5 FUNCTION CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
SECTION - 3 - MACHINE CONTROLS, INDICATORS AND OPERATION
3.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
3.2 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
3.3 OPERATING CHARACTERISTICS AND LIMITATIONS . . . . . . . .3-2
Placards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
3.4 PLATFORM LOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
3.5 MACHINE CONTROL LOCATIONS . . . . . . . . . . . . . . . . . . . . . . . . .3-3
3.6 BATTERY CHARGING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
3.7 GROUND CONTROL STATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
Ground/Platform/OFF Key Selector Switch . . . . . . . . . . . . . .3-6
Platform Lift/Lower Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Inverter ON/OFF Switch (If Equipped). . . . . . . . . . . . . . . . . . .3-6
Ground Emergency Stop Switch . . . . . . . . . . . . . . . . . . . . . . . .3-7
Hourmeter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
Overload Indicator (LSS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
MDI Indicator (If Equipped). . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
3.8 PLATFORM CONTROL STATION. . . . . . . . . . . . . . . . . . . . . . . . . . .3-9
Platform Emergency Stop Switch . . . . . . . . . . . . . . . . . . . . . 3-10

TABLE OF CONTENTS
ii 31215942
Lift/Drive Select Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10
Forward/Reverse/Lift/Lower Direction Arrow . . . . . . . . . .3-10
Drive/Lift/Steer Joystick Control . . . . . . . . . . . . . . . . . . . . . . .3-11
Steering And Traveling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Traveling Forward and Reverse. . . . . . . . . . . . . . . . . . . . . . . .3-12
Raising And Lowering Platform. . . . . . . . . . . . . . . . . . . . . . . .3-12
Arm Guards (If Equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Overload Indicator (LSS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Tilt Indicator Warning Light and Alarm . . . . . . . . . . . . . . . .3-13
Variable Tilt - Platform Restricted Height Indicator . . . . .3-13
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Battery Charge Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
System Fault Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Indoor/Outdoor Operation Indicator . . . . . . . . . . . . . . . . . .3-14
Indoor/Outdoor Operation Mode Switch . . . . . . . . . . . . . .3-14
Low/High Drive Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
3.9 PLATFORM MANUAL DESCENT CONTROL . . . . . . . . . . . . . . .3-15
3.10 GRADE AND SIDESLOPE DEFINITION. . . . . . . . . . . . . . . . . . . . .3-16
3.11 PLATFORM EXTENSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17
3.12 PLATFORM RAILS FOLD-DOWN PROCEDURE
(IF EQUIPPED) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18
Platform with Dual Rail Extension Deck . . . . . . . . . . . . . . . .3-18
Platform with Rail In Rail Extension Deck. . . . . . . . . . . . . . .3-20
3.13 PARKING AND STOWING MACHINE. . . . . . . . . . . . . . . . . . . . . .3-22
3.14 MACHINE LIFTING AND TIE DOWN . . . . . . . . . . . . . . . . . . . . . .3-23
Lifting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-23
Tie Down. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-24
3.15 TOWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-26
Hydraulic Brake Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-26
SECTION - 4 - EMERGENCY PROCEDURES
4.1 GENERAL INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 EMERGENCY OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Operator Unable to Control Machine . . . . . . . . . . . . . . . . . . . 4-1
Righting of Tipped Machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Platform Caught Overhead. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.3 PLATFORM MANUAL DESCENT. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.4 INCIDENT NOTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
SECTION - 5 - ACCESSORIES
5.1 AVAILABLE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 OPTIONS/ACCESSORIES RELATIONSHIP TABLE . . . . . . . . . . . . 5-2
5.3 DC/AC POWER INVERTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Preparation and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
5.4 QUIKWELDER™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Preparation and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

TABLE OF CONTENTS
31215942 iii
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
5.5 WORKSTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
5.6 ELECTRICIAN’S TREE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
5.7 PIPE RACKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
5.8 PANEL CARRIER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.9 VISE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
5.10 PLATFORM WORK LIGHTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
5.11 PLATFORM RAIL PADDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5.12 ANTI-VANDALISM PACKAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
5.13 RAIL MOUNTED PLATFORM EXTENSION HANDLES . . . . . . 5-18
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
5.14 FOOTSWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5.15 MAGNETIC GATE LATCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
5.16 JLG™ MOBILE CONTROL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
Document Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
5.17 SKYSENSE™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
Notification Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
SkySense Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
Override Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
SkySense Coverage Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
SECTION - 6 - GENERAL SPECIFICATIONS AND MAINTENANCE
6.1 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Other Publications Available Specific to this Machine . . .6-1
Serial Number Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
6.2 OPERATING SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Platform Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

TABLE OF CONTENTS
iv 31215942
Machine Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Battery Charger Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6.3 LUBRICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Lubrication Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Lubrication Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Hydraulic Oil Operating Temperature Chart. . . . . . . . . . . . . 6-9
6.4 OPERATOR MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Scissor Arm - Safety Props. . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Hydraulic Oil Check Procedure . . . . . . . . . . . . . . . . . . . . . . . .6-11
Delta-Q. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
Green Power (China (GB) Only) . . . . . . . . . . . . . . . . . . . . . . . .6-13
Eagle Performance - Battery Charger . . . . . . . . . . . . . . . . . .6-14
Battery Maintenance and Safety Practices . . . . . . . . . . . . .6-14
Battery Quick-Disconnect (If Equipped). . . . . . . . . . . . . . . .6-15
Tire Wear and Damage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15
Wheel and Tire Replacement . . . . . . . . . . . . . . . . . . . . . . . . . .6-16
Wheel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-16
6.5 SUPPLEMENTAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . .6-17
6.6 DECAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-18
Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-18
Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-19
6.7 DIAGNOSTIC TROUBLE CODES (DTC) . . . . . . . . . . . . . . . . . . . .6-21
SECTION - 7 - INSPECTION AND REPAIR LOG

TABLE OF CONTENTS
31215942 v
LIST OF FIGURES
3-1. Platform with Dual Rail Extension - Fold Down
Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
3-2. Platform with Rail in Rail Extension - Fold Down
Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
3-3. Fork Lift Pockets - Location . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
3-4. Lifting Machine Using Spreader Bar and Lift Lug
Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
3-5. Tie Down and Lift Lug Locations . . . . . . . . . . . . . . . . . . . . 3-25
LIST OF TABLES
1-1 Minimum Approach Distances (M.A.D.). . . . . . . . . . . . . . . 1-6
1-2 Beaufort Scale (For Reference Only) . . . . . . . . . . . . . . . . . . 1-7
2-1 High Drive Cutout Height . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2-2 Tilt Activation Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

TABLE OF CONTENTS
vi 31215942

SECTION 1 - SAFETY PRECAUTIONS
31215942 1-1
SECTION 1. SAFETY PRECAUTIONS
1.1 GENERAL
This section outlines the necessary precautions for proper and safe
machine usage and maintenance. In order to promote proper machine
usage, it is mandatory that a daily routine is established based on the
content of this manual. A maintenance program, using the information
provided in this manual and the Service and Maintenance Manual,
must also be established by a qualified person and must be followed to
ensure that the machine is safe to operate.
The owner/user/operator/lessor/lessee of the machine must not accept
operating responsibility until this manual has been read, training is
accomplished, and operation of the machine has been completed
under the supervision of an experienced and qualified operator.
These sections contain the responsibilities of the owner, user, operator,
lessor, and lessee concerning safety, training, inspection, maintenance,
application, and operation.If there are any questions with regard to
safety, training, inspection, maintenance, application, and operation,
please contact JLG Industries, Inc. (“JLG”).
FAILURE TO COMPLY WITH THE SAFETY PRECAUTIONS LISTED IN THIS MANUAL
COULD RESULT IN MACHINE DAMAGE, PROPERTY DAMAGE, PERSONAL INJURY OR
DEATH.
1.2 PRE-OPERATION
Operator Training and Knowledge
•Read, understand, and study the Operation and Safety Manual in
its entirety before operating the machine. For clarification, ques-
tions, or additional information regarding any portions of this
manual, contact JLG Industries, Inc.
•Only personnel who have received proper training regarding the
inspection, application and operation of MEWPs (including recog-
nition and avoiding hazards associated with their operation) shall
be authorized to operate a MEWP.
•Only properly trained personnel who have received unit-specific
familiarization shall operate a MEWP. The user shall determine if
personnel are qualified to operate the MEWP prior to operation.
•Read, understand, and obey all DANGERS, WARNINGS, CAUTIONS,
and operating instructions on the machine and in this manual.
•Ensure that the machine is to be used in a manner which is within
the scope of its intended application as determined by JLG.

SECTION 1 - SAFETY PRECAUTIONS
1-2 31215942
•All operating personnel must have a thorough understanding of
the intended purpose and function of the MEWP controls, includ-
ing platform, ground and emergency descent controls.
•Read, understand, and obey all applicable employer, local, and
governmental regulations as they pertain to your utilization and
application of the machine.
Workplace Inspection
•Precautions to avoid all hazards in the work area must be taken by
the user before and during operation of the machine.
•Do not operate or raise the platform from a position on trucks,
trailers, railway cars, floating vessels, scaffolds or other equipment
unless the application is approved in writing by JLG.
•Before operation, check work area for overhead hazards such as
electric lines, bridge cranes, and other potential overhead obstruc-
tions.
•Check operating surfaces for holes, bumps, drop-offs, obstruc-
tions, debris, concealed holes, and other potential hazards.
•Check the work area for hazardous locations. Do not operate the
machine in hazardous environments unless approved for that pur-
pose by JLG.
•Ensure that the ground conditions are adequate to support the
maximum tire load indicated on the tire load decals located on the
chassis adjacent to each wheel.
•This machine can be operated in nominal ambient temperatures
of 0o F to 104o F (-20o C to 40o C). Consult JLG to optimize opera-
tion outside of this temperature range.
Machine Inspection
•Do not operate this machine until the inspections and functional
checks have been performed as specified in Section 2 of this man-
ual.
•Do not operate this machine until it has been serviced and main-
tained according to the maintenance and inspection require-
ments as specified in the machine’s Service and Maintenance
Manual.
•Ensure all safety devices are operating properly. Modification of
these devices is a safety violation.
MODIFICATION OR ALTERATION OF A MEWP SHALL BE MADE ONLY WITH PRIOR WRIT-
TEN PERMISSION FROM THE MANUFACTURER.
•Do not operate any machine on which the safety or instruction
placards or decals are missing or illegible.
•Check the machine for modifications to original components.
Ensure that any modifications have been approved by JLG.
•Avoid accumulation of debris on platform floor. Keep mud, oil,
grease, and other slippery substances from footwear and platform
floor.

SECTION 1 - SAFETY PRECAUTIONS
31215942 1-3
1.3 OPERATION
General
•Machine operation requires your full attention. Bring the machine
to a full stop before using any device, i.e. cell phones, two-way
radios, etc. that will distract your attention from safely operating
the machine.
•Do not use the machine for any purpose other than positioning
personnel, their tools, and equipment.
•Before operation, the user must be familiar with the machine
capabilities and operating characteristics of all functions.
•Never operate a malfunctioning machine. If a malfunction occurs,
shut down the machine. Remove the unit from service and notify
the proper authorities.
•Do not remove, modify, or disable any safety devices.
•Never slam a control switch or lever through neutral to an oppo-
site direction. Always return switch to neutral and stop before
moving the switch to the next function. Operate controls with
slow and even pressure.
•Do not allow personnel to tamper with or operate the machine
from the ground with personnel in the platform, except in an
emergency.
•Do not carry materials directly on platform railing unless approved
by JLG.
•When two or more persons are in the platform, the operator shall
be responsible for all machine operations.
•Always ensure that power tools are properly stowed and never left
hanging by their cord from the platform work area.
•Do not assist a stuck or disabled machine by pushing or pulling
except by pulling at the chassis tie-down lugs.
•Fully lower platform and shut off all power before leaving
machine.
•Remove all rings, watches, and jewelry when operating machine.
Do not wear loose fitting clothing or long hair unrestrained which
may become caught or entangled in equipment.
•Persons under the influence of drugs or alcohol or who are subject
to seizures, dizziness or loss of physical control must not operate
this machine.
•Hydraulic cylinders are subject to thermal expansion and contrac-
tion. This may result in changes to the platform position while the
machine is stationary. Factors affecting thermal movement can
include the length of time the machine will remain stationary,
hydraulic oil temperature, ambient air temperature and platform
position.

SECTION 1 - SAFETY PRECAUTIONS
1-4 31215942
Trip and Fall Hazards
•Prior to operation, ensure all gates and rails are fastened and
secured in their proper position.
•JLG Industries, Inc. recommends that all persons in the platform
wear a full body harness with a lanyard attached to an authorized
lanyard anchorage point while operating this machine. For further
information regarding fall protection requirements on JLG prod-
ucts, contact JLG Industries, Inc.
•Identify the designated lanyard anchorage point(s) at the platform
and securely attach the lanyard. Attach only one (1) lanyard per
lanyard anchorage point.
•Enter and exit only through gate area. Use extreme caution when
entering or leaving platform. Ensure that the platform assembly is
fully lowered. Face the platform when entering or leaving the plat-
form. Always maintain “three point contact” with the machine,
using two hands and one foot or two feet and one hand at all
times during entry and exit.
.
•Keep both feet firmly positioned on the platform floor at all times.
Never position ladders, boxes, steps, planks, or similar items on
unit to provide additional reach for any purpose.
•Never use the scissor arm assembly to gain access to or leave the
platform.
•Keep oil, mud, and slippery substances cleaned from footwear and
the platform floor.

SECTION 1 - SAFETY PRECAUTIONS
31215942 1-5
Electrocution Hazards
•This machine is not insulated and does not provide protection
from contact or proximity to electrical current.
•It is not recommended to use the machine during lightning. To
prevent injury or machine damage if lightning occurs during oper-
ation, lower the boom and shut down the machine in a safe and
secure location.
•Maintain distance from electrical lines, apparatus, or any ener-
gized (exposed or insulated) parts according to the Minimum
Approach Distance (MAD) as shown in Table 1-1.
•Allow for machine movement and electrical line swaying.
•Maintain a clearance of at least 10 ft (3 m) between any part of the
machine and its occupants, their tools, and their equipment from
any electrical line or apparatus carrying up to 50,000 volts. One
foot additional clearance is required for every additional 30,000
volts or less.
•The minimum approach distance may be reduced if insulating
barriers are installed to prevent contact, and the barriers are rated
for the voltage of the line being guarded. These barriers shall not
be part of (or attached to) the machine. The minimum approach
distance shall be reduced to a distance within the designed work-
ing dimensions of the insulating barrier. This determination shall
be made by a qualified person with respect to electrical transmis-
sion and distribution in accordance with the employer, local, or
governmental requirements for work practices near energized
equipment.
DO NOT MANEUVER MACHINE OR PERSONNEL INSIDE PROHIBITED ZONE (MAD).
ASSUME ALL ELECTRICAL PARTS AND WIRING ARE ENERGIZED UNLESS KNOWN OTH-
ERWISE.

SECTION 1 - SAFETY PRECAUTIONS
1-6 31215942
Tipping Hazards
•Ensure that the ground conditions are adequate to support the
maximum tire load indicated on the tire load decals located on the
chassis adjacent to each wheel. Do not travel on unsupported sur-
faces.
•The user must be familiar with the operating surface before driv-
ing. Do not exceed the allowable sideslope and grade while driv-
ing.
•Do not elevate platform or drive with platform elevated while on
or near a sloping, uneven, or soft surface. Ensure machine is posi-
tioned on a smooth, firm surface within the limits of the maximum
operating slope before elevating platform or driving with the plat-
form in the elevated position.
•Before driving on floors, bridges, trucks, and other surfaces, check
allowable capacity of the surfaces.
•Never exceed the maximum platform capacity as specified on the
platform. Keep all loads within the confines of the platform, unless
authorized by JLG.
•Keep the chassis of the machine a minimum of 2 ft (0.6 m) from
holes, bumps, drop-offs, obstructions, debris, concealed holes,
and other potential hazards at the ground level.
•Do not operate the machine when wind conditions exceed specifi-
cations shown in Section 6.2 or as shown on the capacity placard
on the platform billboard. Factors affecting wind speed are; plat-
form elevation, surrounding structures, local weather events, and
approaching storms.
•Wind speed can be significantly greater at height than at ground
level.
•Wind speed can change rapidly. Always consider approaching
weather events, the time required to lower the platform, and
methods to monitor current and potential wind conditions.
•Do not cover or increase surface area of the platform or the load.
Do not carry large surface area items in the platform when operat-
ing outdoors. The addition of such items increases the exposed
wind area of the machine. Increased areas exposed to wind will
decrease stability.
•Do not increase the platform size with unauthorized modifica-
tions, deck extensions, or attachments.
Table 1-1. Minimum Approach Distances (M.A.D.)
VOLTAGE RANGE
(Phase to Phase)
MINIMUM APPROACH DISTANCE
in Feet (Meters)
0 to 50 KV 10 (3)
Over 50KV to 200 KV 15 (5)
Over 200 KV to 350 KV 20 (6)
Over 350 KV to 500 KV 25 (8)
Over 500 KV to 750 KV 35 (11)
Over 750 KV to 1000 KV 45 (14)
NOTE: This requirement shall apply except where employer, local or governmental
regulations are more stringent.

SECTION 1 - SAFETY PRECAUTIONS
31215942 1-7
DO NOT OPERATE THE MACHINE WHEN WIND CONDITIONS EXCEED SPECIFICATIONS
SHOWN IN SECTION 6.2 OR AS SHOWN ON THE CAPACITY PLACARD ON THE PLAT-
FORM BILLBOARD.
Table 1-2. Beaufort Scale (For Reference Only)
BEAUFORT
NUMBER
WIND SPEED DESCRIPTION LAND CONDITIONS
mph m/s
00 0-0.2 Calm Calm. Smoke rises vertically.
11-3 0.3-1.5 Light air Wind motion visible in smoke.
24-7 1.6-3.3 Light breeze Wind felt on exposed skin. Leaves rustle.
38-12 3.4-5.4 Gentle breeze Leaves and smaller twigs in constant motion.
413-18 5.5-7.9 Moderate breeze Dust and loose paper raised. Small branches begin to move.
519-24 8.0-10.7 Fresh breeze Smaller trees sway.
625-31 10.8-13.8 Strong breeze Large branches in motion. Flags waving near horizontal. Umbrella use
becomes difficult.
732-38 13.9-17.1 Near Gale/Moderate Gale Whole trees in motion. Effort needed to walk against the wind.
839-46 17.2-20.7 Fresh Gale Twigs broken from trees. Cars veer on road.
947-54 20.8-24.4 Strong Gale Light structure damage.

SECTION 1 - SAFETY PRECAUTIONS
1-8 31215942
•Never attempt to use the machine as a crane. Do not tie-off
machine to any adjacent structure. Never attach wire, cable, or any
similar items to platform.
•If the scissor arm assembly or platform is caught so that one or
more wheels are off the ground, all persons must be removed
before attempting to free the machine. Use cranes, forklift trucks,
or other appropriate equipment to stabilize machine.
