SWIVEL BOARD RACK

INSTALLATION GUIDE

IMPORTANT NOTES ON INSTALLING AND USING YOUR NEW RACK

◆ Donottraileryourboatwithwakeboardsintheracks

◆ Wakeboard ropes can catch on wakeboard racks and wakeboards during sharp turns causing

 damagetoboardsandracks.Becarefultopreventtheropefromcatchingonthewakeboardrack

 andwarnalldriversofthispossibility

◆ Donotstandonthewakeboardrackasitcanbendthetubeorforksandabuseisnotcovered

 underwarranty

◆ Failuretotightentherackmountscanresultinalostforkassembly,andisnotcoveredbywarranty.

 Testthisbypullingontherackeachtimebeforeuse.

◆ Notethatthisinstallationguideisonlyaguideline.Eachboatisdifferentandimprovisationis

 neededtomountyourAddictaccessoriesonyourboat.

09-2012

Check WWW.JOBESPORTS.COM for other languages of this manual

Contents of Box

Hardware

INSTALLATION

1.Firstassemblethetwoforks(2)ontheplate(3)with4screws(B).Keepinmindthattheforksshouldpointupand

makesurethelogoisfacingtheoutsideoftheforksandisnotupsidedown.

2.Attachtheclamp(1)onthebackoftheplatewith4screws(A).Donottightenthebolts.

Youmayhavetoswiveltherackaftermountingitonthetowertogettherackhorizontal.

3.Removefourhexheadcapscrews(C)frommountingcollar.

Splitcollarandplaceblackcollarinserts(D)insidemountingcollar.

4.Selectasuitablelocationforyourrack.FortheAddicttower,itisbesttomounttherackabout2/3rdofthewayup

therearlegs.Forothertowers,mountracksononeoftheverticalorhorizontaltubes.

5.Placemountingcollarontowerandreplacehexheadcapscrews(C).Tightenscrewstoatorquesettingof22ft/lbs.

Itisimportanttotightenthescrewsevenlyorcollarmaybind,causingthreaddamage.Asmallgapbetweenmounting

collarhalveswillremainwhentightenedproperly.Notice:Improperbolttorquecouldleadtopoorperformanceorpro-

ductfailure.

6.Swiveltherackinahorizontalposition.Tightenscrews(A)toatorquesettingof22ft/lbs.

Care and Maintenance

I. Besuretocheckandtightenallfastenersandconnectionspriortoeveryuse.

II. Youcanmaintainthenewappearanceofyourboardracksbywipingwithacleandampclothaftereachuse.

 Soapywater,carwaxoracommerciallyavailablemarinewaterspotremovercanbeusedasneeded.

 Avoidabrasivematerialsthatmightscratchthenish.

III. Alwaysrinserackaftercontactwithsalt(brackish)water.

JOBE Addict Rack Warranty

JobeSports Internationalwarrants this product(not includingother 3rd partyaccessories) againstmanufacturers defects. Anodizingand powdercoated surfaces aswell asall

hardwarecorrosionarespecicallyexcludedastheircareandusecannotbecontrolledbyJobeSportsInternational.Anymodicationsorimproperuseshallvoidthiswarranty.

JobeSportsInternationalisnotresponsibleforpersonalinjuryordamagetotheboatcausedbytheuseofthisaccessory.JOBE’sobligationunderthiswarrantyshallnotinclude

anytransportationchargesorcostsofinstallationoranyliabilityfordirect,indirectorconsequentialdamagesresultingfromdelayorimproperinstallation.Nodealer,retaileror

manufactureristheagentofJobeSportsInternationalandmaynotassumeforJobeSportsInternationalanyliabilityinconnectionwiththiswarranty.Thiswarrantyisinlieuofall.
