jobmate YT5452 User manual

3
Know Your Product................................................................................................ 4
Technical Specications........................................................................................ 4
Description of Symbols..........................................................................................5
Contents of Electric Shredder................................................................................6
General Safety Instructions................................................................................... 7
Additional Safety Instructions for Electric Shredder............................................... 9
Assembly Instructions............................................................................................ 9
Operation...............................................................................................................10
Starting.............................................................................................................10
Stopping .......................................................................................................... 10
Tips for Using Your Electric Shredder.............................................................. 10
Maintenance..........................................................................................................12
Warranty ............................................................................................................... 13
CONTENTS

4
1Hopper Locking Knob 2Reset Button
3 Motor 4 Stand Assembly
5Axle 6Hopper
7 Main Body 8Power On/Off Trigger Switch
9Paddle 10 Paddle Holder
11 Wheels (two)
Voltage: 230V/50HZ
Rated power: 2400W
Cutting capacity: 38cm
No-load speed: 3900/min
KNOW YOUR PRODUCT
TECHNICAL SPECIFICATIONS

5
The rating plate on your tool may show symbols. These represent important
information about the product instruction on its use.
Conforms to all relevant European Directives.
Double insulated for additional protection.
DESCRIPTION OF SYMBOLS
Use eye protection.
Use ear protection.
Wear sturdy, non-slip footwear.
Read the user manual.
Do not expose to rain.
Use protective gloves.
Denotes risk of personal injury, loss of life, or damage to the tool in case
of nonobservance.

6
This symbol is known as the ’Crossed-out Wheelie Bin Symbol’. When
this symbol is marked on a product or battery, it means that it should not
be disposed of with your general housed hold waste. Some chemicals
container within electrical/electronic products or batteries can be
harmful to health and the environment. Only dispose of electrical/
electronic/battery items in separate collection schemes, which cater
for the recovery and recycling of materials container within. Your co-
operation is vital to ensure the success of these schemes and for the
protection of the environment.
1*Unit
1*Fast feed hopper
1*Wheel axle
2* Wheels
1*Lower frame
1*Instruction manual
Conforms to relevant standards for electromagnetic compatibility.
DESCRIPTION OF SYMBOLS (CONT.)
CONTENTS OF ELECTRIC SHREDDER
Disconnect from mains power immediately if the power cord becomes
damaged.
Disconnect from power supply when tool needs repairs.

7
WARNING! Read all instructions. Failure to follow all the instructions listed
in all of the warnings listed below refers to your mains operated (corded) power tool
or battery operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1) Work area
• Keep work area clean and well lit. Cluttered or dark areas can lead to accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
dust or fumes.
• Keep children and bystanders away while operating a power tool. Distractions can
cause a loss of control.
2) Electrical safety
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not
matching outlets will reduce risk of electric shock.
• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body
is earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord awayfrom heat, oil, sharp edgesor moving parts. Damaged
or entangled cords increase the risk of electric shock.
• Replacement of the supply cord. If the supply cord is damaged, it must be replaced by
an electrician or a power tool repairer.
• When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
• Have your tool repaired by an electrician or a power tool repairer. This power tool
complies with relevant safety requirements. To avoid danger, electrical appliances
this may result in considerable damage to the user.
3)Personal safety
• Stay alert, watch what you are doing and use common sense when operating a
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
• Use safety equipment. Always wear eye protection. Safety equipment such as a
dust mask, non-skid safety shoes, hard hat, or hearing protection used whenever
conditions require will reduce personal injuries.
• Avoid accidental starting. Ensure the switch is in the ‘off’ position before plugging
GENERAL SAFETY INSTRUCTIONS

8
GENERAL SAFETY INSTRUCTIONS (Cont.)
that have the switch may cause an accident.
• Remove any adjusting key or wrench before turning the power tool on. A wrench
or key left attached to a rotating part of the power tool may result in personal
injury.
• Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
• If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of these devices
can reduce dust related hazards.
4)Power Tool Use and Care
• Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source before making any adjustments,
changing accessories or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
• Maintain power tools. Check for misalignment or sticking of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to stick and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these
instructions, and in the manner intended for the particular type of power tool,
taking into account the working conditions of the work to be performed. Use of the
power tool for operations different from intended use could lead to a hazardous
situation.
5)Service
replacement parts. This will ensure that the safety of the power tool is maintained.

9
1. Remove all parts from package.
2. Check all the parts against the list in the
manual. If any parts are damaged or missing
do not use the wood chipper/shredder until the
part is repaired or replaced.
3.Assemble the wheel axle to the stand
assembly; put the spacer onto the axle; insert
the wheels on the axle, then attach washer
and lock nut to the axle with the supplied
wrench to secure. (Fig. 1 and Fig. 2)
4. Press the wheel covers into the wheels
to cover the ends of the axles. You may use
a hammer to fasten them securely over the
axles. There may be some clearance between
the wheel and the wheel cover, it is not
necessary to press it to the bottom. (Fig. 3 and
Fig. 4)
• Do not use appliance other than for intended use.
• Maintain labels and nameplates on the appliance. These carry important
safety information. If unreadable or missing, contact the point of purchase for a
replacement.
• The warnings, precautions and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which
cannot be built into this product but must be supplied by the operator .
ADDITIONAL SAFETY INSTRUCTIONS FOR
ELECTRIC SHREDDER
ASSEMBLY INSTRUCTIONS
Fig. 1
Fig. 2
Fig. 3
Fig. 4

10
ASSEMBLY INSTRUCTIONS (Cont.)
OPERATION
5. Turn the main body upside down, insert
the two ends of the stand assembly into the
housing, align the holes on the housing and
stand assembly, insert the four washers
onto the screws (A) and install into the stand
assembly. (Fig. 5 and Fig. 6)
Starting (Fig. 7)
Make sure the switch is in the OFF position.
Plug the garden shredder into a suitable outlet
using an approved extension cord if necessary.
Push the ON/OFF switch to “ON” to turn the
garden shredder on.
Stopping (Fig. 7)
Push the ON/OFF switch to “OFF” to turn the
garden shredder off.
CAUTION: The garden shredder will not
operate if the hopper locking knob is loose.
Tips for Using Your Electric Shredder
Overload Protection (Fig.7)
Your garden shredder is designed with overload protection. If the shredder is
clogged during shredding, the overload protection will cut the power automatically to
protect your shredder. Wait at least 1 minute before restarting by rst pressing the
reset button (B) and then the ON/OFF switch.
Hopper Locking Knob (Fig.7)
The garden shredder is tted with a safety interlock switch on the closure between
the hopper and main body. The switch is activated when the hopper is securely
closed and tightened by the hopper locking knob. When the hopper is opened or not
tted well, the shredder will not run. Always tighten the hopper locking knob (D) by
turning it clockwise before operation.
Fig. 5
OFF
ON
REMOVE
TO LOCK
C
I
R
C
U
I
T
B
R
E
A
K
E
R
P
R
E
S
S
T
O
R
E
S
E
T
Fig. 7
(B) Reset
Button
(D) Hopper Locking
Knob
Safety
Switch
OFF
ON
Fig. 6
(A) Screw
washer

11
OPERATION (Cont.)
Safety Switch (Remove To Lock Fig. 7)
As a safety precaution, the safety switch may be removed when you are not
using the shredder to prevent children from starting it accidently (See Fig. 7). The
shredder cannot be started when the safety switch is removed.
Blades
The blades on the rotary plate are reversible. For quality and safety reasons, we
recommend that only identical replacement blades be used should it become
necessary to replace them.
Shredding Material
WARNING! Before starting, ensure that the feed inlet is empty.
WARNING! Always wear ear and eye protection and wear gloves during
operation.
CAUTION! Longer material standing out from the shredder could lash out when
being pulled in by the blades. Keep a safe distance.
CAUTION! When using the garden shredder and feeding branches into the
shredder, sometimes the blades pull the material into the opening. Keep hands at a
safe distance.
CAUTION! The ventilation slots must not be covered.
1. Only insert as much material as to prevent blockage of the feeding funnel. Chop
garden waste that has been stored for a few days and is wilted and damp
alternately with dry branches. This prevents the cutting blades from blocking up.
Widely branched material with leaves must be completely chopped before new
material is fed. Make sure that the chopped material can fall freely from the
ejection slot.
2. Keep hold of branches while feeding them into the garden shredder until they are
automatically drawn in.
3. Keep to the working speed of the garden shredder and do not overload it.
4. To protect the garden shredder from clogging, shred wilted garden waste that has
been left for a few days and shred thin twigs alternately with branches.
5. Before you shred roots, remove any remaining soil and stones from them.
6. Do not shred soft, damp material such as kitchen waste, take it straight to the
compost.
7. Keep a few dry branches for the end, as they will help clean the garden shredder.
8. Only switch the garden shredder off after all of the shredding material has passed
through the discharge chutes. Otherwise, the discharge chutes may jam the next
time the shredder is turned on.

12
MAINTENANCE
WARNING! Always turn off the garden shredder and unplug the power cord
from the outlet before maintaining the shredder.
WARNING! Always wear gloves when cleaning.
1. Cleaning garden shredder: (See Fig. 8)
a) Unscrew the hopper locking knob (D) counter clockwise and open the hopper.
b) Clean cutting blades and discharge area and remove wood sticks or objects
that may clog the blades.
c) The garden shredder has two blades that are attached to a rotary plate with two
screws, (See Fig. 9). Before any maintenance or cleaning is done on the
blades, always turn the switch off and disconnect the plug from the outlet.
d) Check blades for damage. Use only identical replacement parts if it becomes
necessary to replace them.
e) Return the hopper to its upright position and tighten the knob before operating
the garden shredder.
2. Use only a warm damp cloth and a soft brush to clean your garden shredder.
Always wear safety glasses to protect your eyes during cleaning.
3. Never spray water on the garden shredder or wash it with water. Do not use
detergents or solvents as these could cause irreparable damage to your shredder.
.emitotemitmorfdekcehcebdluohsylbmessadnatsehtfoswercsgninetsafehT.4
Periodically check all nuts, bolts and screws to be sure the shredder is in safe
working condition.
5. Make sure the ventilation slots are always kept clean and are free of debris.
6. To protect the garden shredder from corrosion when storing for a long period,
treat the cutting blade with oil.
7. Cutting blade replacement. (Fig. 8 & 9)
Fig. 9
OFF
ON
REMOVE
TO LOCK
C
I
R
C
U
I
T
B
R
E
A
K
E
R
P
R
E
S
S
T
O
R
E
S
E
T
Fig. 8 (D) Hopper Locking
Knob
(B) Reset
Button
with two screws. Before any maintenance or
cleaning of the blades, always turn the switch off
and disconnect the plug from the outlet.
b) Turn the Hopper Locking Knob (D)
counter clockwise until the housing cover can be
opened.
c) Lift up the housing cover to expose the two
blades.
d) Align the slots on the board, the blade support
and the main body and insert a metal rod like a
screwdriver into the slots to prevent rotating
when removing the blade with the supplied hex key.
e) Remove the old blade. Either reverse the blade
so the sharp edge is in the cutting position or
insert a replacement blade. Use the same
method to replace the other blade.
f) Replace and tighten the two screws to secure
the new blade to the support.

13
WARRANTY POLICY
Congratulations on your purchase of Electric Shredder. In order to get maximum
benefit from your new purchase, please be aware of the warranty provisions
outlined in this document.
2 YEAR [REPLACEMENT/REPAIR] WARRANTY
Your Electric Shredder is guaranteed for a period of 24 months from the original date
of purchase. As the product is intended exclusively for home DIY (Do It Yourself)
use, thus use of this product for professional, industrial or high frequency use will
VOID this warranty. If your product is defective, it will be repaired or replaced in
accordance with the terms of this warranty.
The warranty is provided by Mitre 10 (New Zealand) Limited (“known as Mitre 10”)
Rights & Remedies
We are dedicated to delivering a quality product to all our customers. All of our
products are warranted for two years from date of purchase against defects in
material and workmanship.
If we determine that the product has a manufacturing fault, we will repair or replace
it free of charge to you. The decision to repair or replace is solely at the discretion of
Mitre 10 (New Zealand) Limited.
What do we require?
It is our requirement that all warranty claims are accompanied by a proof of
purchase (sales receipt) to allow verication of the date of purchase. Where proof
of purchase is not provided, Mitre 10 (New Zealand) Limited reserves the right to
charge a service fee and/or charge for parts replaced/repaired. A return freight
charge may apply.
The warranty is ‘return to base’ and not a free in-home service. This means the
customer is responsible for any inwards freight charge to return the product to the

14
Mitre 10 or Mitre 10 MEGA store where the product was purchased from, for the
warranty to be applicable.
Please retain your Proof of Purchase.
Only the original owner is covered by the manufacturer’s warranty and must have
purchased the product from a Mitre 10 or Mitre 10 MEGA store in New Zealand.
What is not covered under warranty?
• Professional, Industrial or high frequency use if the purpose of the tool is stated
as DIY (Do It Yourself) in the instruction manual.
•
If the tool has been operated on a supply voltage other than th
• If the tool has been operated with incorrect oil, fuel or fuel mix.
• If the tool shows signs of damage or defects caused by or resulting from abuse,
accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• General wear and tear.
• Servicing by an unauthorized service agent.
• Any consumable parts.
Exclusions
• Any consequential loss or damage to any person or property directly or indirectly
as a result of using product.
outside of the country of purchase you will be charged fees by the local provider.
