JOBO SNAPSCAN 9000 - V1.5 User manual
SnapScan9000
-Patent pending-
User Manual
Version 1.5
November 2010
2
DeclarationofConformity
We declare JOBOInternationalGmbH,
Eintrachtstr.14,
D‐51645Gummersbach
thatthe“SnapScan9000”
complies with the following directives:
EN 55022:2006+A1:2007 Radio interference suppression (ITE).
Limits and methods of measurement
EN 55024:1998/A2:2003 EMC Immunity to Radiated Fields (ITE)
EN61000-3-2:2006 Elektromagnetic Compatibility (EMC-Part 3-2)
EN61000-3-3:2008 Elektromagnetic Compatibility (EMC-Part 3-3)
This declaration of EC conformity shall become null and void when the assembly is
subjected to any modification that has not met with our approval.
Gummersbach,05.September2010 JohannesBockemühl
Geschäftsführer
3
Index
I. Unpack SnapScan9000......................................................4
II. Install film into the film holder....................................6
III. Quick Start..................................................................9
IV. Operation Guide.........................................................14
1. Capture ..................................................................... 14
2. Film Type .................................................................. 32
3. Setting Mode. ............................................................ 35
V. Specification...............................................................38
Waste Management............................................................39
Packaging ...................................................................... 39
Disposal of WEEE (Waste Electrical and Electronic Equipment) 39
Service .............................................................................40
4
I. Unpack SnapScan9000
JOBO SnapScan 9000 Negative Holder User Manual
USB power core USB/Video cable Roll Film Holder Clean brush
2 x Rapid slide feeder
5
Note
We strongly suggest using a clean, dry, non-alcohol
cotton swab to clean the glass surface periodically
to produce a clear image during operation.
Clean dust from Film Scanner back light, to use the
clean brush to wipe the dust.
Dust or dirt from the negative, slide films and cover
trays may affect the scanned image quality, please
make sure the materials are cleaned before inserting
into the scanner.
Please find recommend, processional purger from photo store to clean the dust on
films if any to avoid damaging the only one copy of old films.
6
II. Install film into the film holder
• Insert slides into the rapid slide feeder
1.Putastackofslidesintothefeeder
Aftertheslidesareplacedintotheholder
andtheholderisplacedintotheslotofthe
scanner(referto„QuickStart“)theslides
canbeslideintothescannerbymovingthe
holderbackwardandforward.
Theslidesarepositionedautomatically
insidethescanner.
●Install the Negative Film into holder
1. Open the film holder as illustrated
2. Install film into negative film slot 3. Close the film holder
FilmSlot
7
●Install the Roll Film into holder:
1. Take out the roll film holder from package
2. Insert roll film into film slot 3. Pull out the roll film in another side
8
Note
To avoid mirror image, follow the serial numbers (from left to right) on top of film
when install negative film into holder
If the image is upside down [see fig.2], the image can be corrected by Flip function
in Button of device before capture.
Figure1
Figure2
9
III. Quick Start
Right/+button
FilmSlot
OKbutton
SDcardSlot
Left/‐button
Powerbutton
USBport
TVoutjack
PowerstatusLED
10
1. Put Film onto the film cartridge
2. Insert the film cartridge into JOBO SnapScan 9000
11
3. Connect power USB cable to SnapScan 9000
4. Turn on Device by pressing the power button
12
5. Press OK button to capture the image
6. Follow the menu on display for scanning
13
7. After finished the capture, take out the SD card which stored capture
images
8. Or read picture from PC by MSDC mode
14
IV. Operation Guide
Home: Main menu
•
Capture: capture mode (default)
•
Playback: playback mode
•
Film Type: define the film type which loaded in cartridge
•
USB mode: MSDC (Mass Storage Device Class) mode
•
Setting: TV out and format option
1. Capture
After welcome page, above menu will remains for 5 sec. User can press up/down button
for desired menu. Or system will auto enter Capture mode if there is no action during
this 5 second period.
Capture
Playback
FilmType
USBmode Setting
Capture
15
1.1 Capture: <Up>/<Down> (Button)
•
Press <Up> button to enter Mirror/Flip adjustment (see Chapter 1.2)
•Press <Down> button to enter Brightness/Color adjustment (see Chapter 1.3)
<
U
p
>Right/Up
<Down>
Left/Down
<Up>
<Down>
<OK>GoNext
button
16
1.2 Capture: <Up>/<Down> - Mirror/Flip (Button)
•
Press <Up> button to change image left to right
•
Press <Down> button to upside down image
<
Up>Right/Up
<Down>
Left/Down
<Up>
<Down>
<OK>GoBack
to1.1Capture
button
17
1.3 Capture: <Up>/<Down> - Brightness/Color (Button)
•
Press <Up> button to enter Brightness adjustment (See Chapter 1.4)
•
Press <Down> button to enter Color adjustment (See Chapter 1.5)
<
Up>Right/Up
<Down>
Left/Down
<Up>
<Down>
<OK>GoBack
to1.1Capture
button
18
1.4 Capture: <Up>/<Down> - Brightness (Button)
•
Press <Up> button to increase Brightness with ranges of -3 to 3
•
Press <Down> button to decrease Brightness with ranges of -3 to 3
<
Up>Right/Up
<Down>
Left/Down
<Up>
<Down>
<OK>GoBack
to1.1Capture
button
19
1.5 Capture: <Up>/<Down> - Color Red (Button)
•
Press <Up> button to increase red color with ranges of -3 to 3
•
Press <Down> button to decrease red color with ranges of -3 to 3
<
Up>Right/Up
<Down>
L
e
f
t/
D
o
wn
<Up>
<Down>
<OK>GoNext
toColorGreen
button
20
1.6 Capture: <Up>/<Down> - Color Green (Button)
•
Press <Up> button to increase green color with ranges of -3 to 3
•
Press <Down> button to decrease green color with ranges of -3 to 3
<
Up>Right/Up
<Down>
Left/Down
<Up>
<Down>
<OK>GoNext
toColorBlue
button
