Jobsite BT-DA User manual

DATA SHEET
AUDIO, VIDEO, AND RF BALUNS
BALUNS
For Placing Devices
Extended Distances
From Their Source

AUDIO, VIDEO, AND RF BALUNS
BALUNS
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connectors
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth: 20 Hz – 20 kHz
• Transmission Distance:
2000' (CAT-3 UTP)
2500' (CAT-5 UTP)
Warranty Ten year limited
Shipping Weight: 1 lb BT-SA
PART # FG01376
BALUN TRANSFORMER STEREO AUDIO
BT-DA
PART # FG01377
BALUN TRANSFORMER DIGITAL AUDIO
BT-V
PART # FG01378
BALUN TRANSFORMER VIDEO
BT-SV
PART # FG01379
BALUN TRANSFORMER S-VIDEO
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth: 25 MHz – 1 dB
• Transmission Distance:
600' (180 m)
Warranty Ten year limited
Shipping Weight: 1 lb
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated S-Video DIN Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth:
Y: DC to 6 MHz
C: 1MHz to 6 MHz
• Transmission Distance:
500' (150m) (CAT-5 UTP)
Warranty Ten year limited
Shipping Weight: 1 lb
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth: DC to 10 MHz
• Transmission Distance:
Color: 1500' (CAT-3 UTP)
2200' (CAT-5 UTP)
B & W: 2000' (CAT-3 UTP)
2500' (CAT-5 UTP)
Warranty Ten year limited
Shipping Weight: 1 lb
BALUN TRANSFORMER VGA
BT-VGA
PART # FG01380
FEATURES:
• Shielded CAT-5 Connector
• DB-15HD Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth:
0-50 MHz, -3dB at 165’ (50 m)
• Transmission Distance: CAT-5 STP:
640 X 480 pixels, 50 Hz
(15 MHz): 330’ (100 m)
800 X 600 pixels, 60 Hz
(30 MHz): 330’ (100 m)
1024 X 768 pixels, 75 Hz
(60 MHz): 250’ (75 m)
1280 X 1024 pixels, 75 Hz
(100 MHz): 165’ (50 m)
Warranty Ten year limited
Shipping Weight: 1 lb
AUDIO - CAT-5 BALUNS
VIDEO - CAT-5 BALUNS

AUDIO, VIDEO, AND RF BALUNS
BALUNS
BT-HDDA
PART # FG01383
BALUN TRANSFORMER VIDEO + DIGITAL AUDIO
BT-SVSA
PART # FG01382
BALUN TRANSFORMER S-VIDEO STEREO AUDIO
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth:
Video: DC to 10 MHz
Audio: 20 Hz-20kHz
• Transmission Distance:
Color: 1500' (CAT-3 UTP)
2200' (CAT-5 UTP)
B & W: 2000' (CAT-3 UTP)
2500' (CAT-5 UTP)
Warranty Ten year limited
Shipping Weight: 1 lb
BT-VSA
PART # FG01381
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connector
• Gold Plated S-Video DIN Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth:
Y: DC to 6 MHz
C: 1MHz to 6 MHz
• Transmission Distance:
S-Video:500' (150 m)
(CAT-5 UTP)
Warranty Ten year limited
Shipping Weight: 1 lb
BALUN TRANSFORMER CABLE TV/ANTENNA
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth: 5 MHz to 550 Mhz
• Transmission Distance:
Up to 330' (100 m) using CAT-5 UTP
Warranty Ten year limited
Shipping Weight: 1 lb
FEATURES:
• Shielded CAT-5 Connector
• Gold Plated Color Coded RCA Connector
• Universal Mounting Holes
SPECIFICATIONS:
n• Overall dimensions:
4.75" W x .85" H x 2" D
• Bandwidth:
Video: 0-60MHz, -3 dB
Digital Audio: 25 MHz -1 dB
• Transmission Distance:
Video, Color, CAT-5 UTP or STP:
480i/p:1000' (300m)
720p: 500' (150m)
1080i: 500' (300m)
Digital Video: 500' (150 m)
Warranty Ten year limited
Shipping Weight: 1 lb
BT-RF
PART # FG01384
BALUN TRANSFORMER VIDEO STEREO AUDIO
AUDIO & VIDEO - CAT-5 BALUNS
RF - CAT-5 BALUNS
AUDIO & VIDEO - CAT-5 BALUNS

AUDIO, VIDEO, AND RF BALUNS
BALUNS
