Johnson & Starley ELJAN 4/SE User manual

Leave these instructions with the User or with the appliance
ELJAN4/SE
GASFIREDWATERHEATERS
USER'SINSTRUCTIONS Publication No. ZZ 601/4
November 1998
IMPORTANT: STATUTE LAW DEFINES THAT ALL GAS APPLIANCES MUST BE INSTALLED AND
MAINTAINED BY COMPETENT PERSONS, (i.e. CORGI REGISTERED INSTALLERS) IN ACCORDANCE
WITH THE GAS SAFETY (INSTALLATION AND USE) REGULATIONS (CURRENT EDITION). FAILURE
TO COMPLY WITH THESE REGULATIONS MAY LEAD TO PROSECUTION.
THISAPPLIANCEHASBEENTESTEDAND CERTIFIED FOR USEWITHNATURALGAS.
1
WARNING:THIS APPLIANCE MUST BE EARTHED.
ELJAN 4/SE is a gas fired appliance which provides domestic hot water and/or space heating when installed in a Johnson and
Starley HI-SPEC J25 or SCS25 MkI air heater. The water temperature is controlled automatically by an integral thermostat in the
appliance. In addition, ELJAN 4/SE can be electrically switched by the air heater time control.
Temperature
control knob
OFF button
START
button
Ignition
button
Pilot
burner
viewing
port

ZZ 601/4
2
Johnson and Starley prides itself on its ability to supply spare parts quickly and efficiently. If your service engineer indicates a
problem in obtaining a spare part, advise him to contact Johnson and Starley Spares Department at the address below.
Telephone: [phone] JOHNSON AND STARLEY Ltd.,
Rhosili Road,
Brackmills,
Fax : [phone] Northampton, NN4 7LZ
1. TOLIGHTYOURAPPLIANCE
WARNING: If the pilot light is extinguished either
intentionally or otherwise, no attempt should be made
to relight the gas until at least 3 minutes have elapsed.
1.1 Remove the air heater front door.
1.2 Check that the system is filled with water.
1.3 Ensure the gas, and where applicable the electrical
supplies to the air heater and water heater are turned on.
1.4 Ensure the Temperature Control Knob is set to ‘OFF’
(fully clockwise).
1.5 Identify the positions of the ‘START’button, ( on the
gas control, marked by a spark symbol,) ‘IGNITION’
button, and the pilot burner viewing port
1.6 Press and hold the ‘START’button fully in and whilst
observing the pilot burner through the viewing port,
repeatedly press and release the ‘IGNITION’ button
until the pilot lights. When the pilot has been lit, keep
the ‘START’button pressed for a further 20 seconds
and then release. The pilot burner should now remain
alight. If it does not, press the ‘OFF’ button and wait
until a minimum of three minutes and then repeat the
ignition sequence, holding the ‘START’ in for a little
longer than before.
NOTE: When lighting the pilot, ensure that the ‘OFF’
button is not touched. Partial depression of the ‘OFF’
button may operate the safety mechanism and prevent
the main burner from lighting.
1.7 With the pilot burner lit, turn the ‘TEMPERATURE
CONTROL KNOB’ fully anticlockwise. The heater
will now operate automatically, controlled by the water
thermostat, providing that any switch (time clock or
manual control) controlling the system is ON.
1.8 Refit the air heater front door
2. OPERATION OFYOURAPPLIANCE
2.1 The Temperature Control Knob will, in its fully anti
clockwise position, control water to the highest
temperature. If a lower temperature is required, turn the
Temperature Control Knob clockwise to the desired
position.
NOTE: If the Temperature Control Knob is removed for
any reason, ensure that it is correctly located when
refitting. DO NOT USE FORCE or damage will occur.
Check the location of the control knob by turning it
fully clockwise; OFF shall be against the red marker on
the gas control.
2.2 The pilot burner must be alight to allow the main
burner to operate under automatic control. Should it
become extinguished, a safety device will shut off all
gas to the appliance.
3. MAINTENANCE
It is recommended that a full maintenance check on your
appliance is made annually, and that a service contract is
taken out on completion of the guarantee period. Your
installer will give you details of arrangements for this
service. If your installer has difficulty in providing this
information, please contact Johnson and Starley Service
Department, who will provide information of suitable
service companies.
4. IF YOUR APPLIANCE IS NOT GIVING THE
SERVICEYOUNEED
4.1 Check that the pilot burner is lit. If not, follow the
ignition procedure. Should the appliance still fail to
function correctly, contact your installer or local gas
service engineer.
4.2 New appliances: Service is supplied under guarantee
by the installer for the first 12 months, thereafter,
should you have difficulty in obtaining service, contact
Johnson and Starley Service Department, who will
provide information of suitable service companies.
4.3 For your appliance to operate safely and efficiently,
it is ESSENTIAL to OBSERVE THE FOLLOWING:
4.3.1 If the appliance has been installed in a cupboard,
DO NOT BLOCK any GRILLES provided in the
cupboard door(s).
4.3.2 DO NOT PLACE anything (clothing, linen, etc.)
in contact with the appliance or its flue pipe.
4.3.3 DO NOT USE the heater compartment for
storage or airing.
2.3 TOSTOPTHE APPLIANCE:
(a) For short periods: Turn the temperature
Control Knob to the ‘OFF’ position and where
applicable turn of the electrical supply to the
water heater. This will leave the pilot burner lit,
but prevent the main burner from lighting.
(b) For longer periods: Press the ‘OFF’ button
and turn the gas supply, and where applicable the
electrical supply, to the water heater OFF.
NOTE: In the interest of economy, the hot water cylinder
and pipes should be efficiently lagged to minimise heat loss,
and water taps should not drip. The water must be drained
out of the appliance if it is to be shut off for long periods,
and frost damage is a possibility.
IF YOU SMELL GAS:
TURN OFF the gas supply
VENTILATE the area
DO NOT operate any electrical switches
CONTACT your installer or local gas service
engineer
