Johnson Controls SUNLINE MAGNUM DY 036 User manual

INSTALLATION
MANUAL
CAUTION: READ ALL SAFETY GUIDES BEFORE YOU
BEGIN TO INSTALL YOUR UNIT.
SAVE THIS MANUAL
SUNLINE MAGNUM™
GAS/ELECTRIC SINGLE PACKAGE
AIR CONDITIONERS
DY 036, 048 & 060
362254-YIM-D-0109
CONTENTS
GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY CONSIDERATIONS. . . . . . . . . . . . . . . . . 4
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
REFERENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
RENEWAL PARTS . . . . . . . . . . . . . . . . . . . . . . . . . 5
APPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PRODUCT NOMENCLATURE . . . . . . . . . . . . . . . . 6
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
START-UP (COOLING) . . . . . . . . . . . . . . . . . . . . 36
START-UP (GAS HEAT). . . . . . . . . . . . . . . . . . . . 37
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . 40
See the following page for a complete Table of Contents.
NOTES, CAUTIONS AND WARNINGS
The installer should pay particular attention to the words:
NOTE, CAUTION, and WARNING. Notes are intended to
clarify or make the installation easier. Cautions are given
to prevent equipment damage. Warnings are given to alert
installer that personal injury and/or equipment damage
may result if installation procedure is not handled properly.

362254-YIM-D-0109
2Johnson Controls Unitary Products
TABLE OF CONTENTS
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . .4
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
RENEWAL PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
APPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PRODUCT NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . 6
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
INSTALLATION SAFETY INFORMATION: . . . . . . . . . . .7
LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
RIGGING AND HANDLING . . . . . . . . . . . . . . . . . . . . . . .8
CLEARANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DUCTWORK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CONDENSATE DRAIN . . . . . . . . . . . . . . . . . . . . . . . . . . 9
COMPRESSORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
FILTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SERVICE ACCESS . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
THERMOSTAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
POWER AND CONTROL WIRING . . . . . . . . . . . . . . . .12
OPTIONS/ACCESSORIES . . . . . . . . . . . . . . . . . . . . . .12
ELECTRIC HEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
GAS HEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
GAS PIPING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
GAS CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
L.P. UNITS, TANKS AND PIPING . . . . . . . . . . . . . . . . . . 15
VENT AND COMBUSTION AIR HOODS . . . . . . . . . . . . 16
ECONOMIZER/MOTORIZED DAMPER AND
RAIN HOOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
POWER EXHAUST/BAROMETRIC RELIEF DAMPER
AND RAIN HOOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
ECONOMIZER AND POWER EXHAUST DAMPER SET
POINT ADJUSTMENTS AND INFORMATION . . . . . . .17
MINIMUM POSITION ADJUSTMENT . . . . . . . . . . . . . . . 17
ENTHALPY SET POINT ADJUSTMENT . . . . . . . . . . . . 17
POWER EXHAUST DAMPER SETPOINT (WITH OR
WITHOUT POWER EXHAUST) . . . . . . . . . . . . . . . . . . . 17
INDOOR AIR QUALITY . . . . . . . . . . . . . . . . . . . . . . . . . . 17
PHASING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
SUPPLY AIR BLOWERS . . . . . . . . . . . . . . . . . . . . . . . .30
CHECKING SUPPLY AIR CFM . . . . . . . . . . . . . . . . . . .30
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
SEQUENCE OF OPERATIONS OVERVIEW . . . . . . . .31
COOLING SEQUENCE OF OPERATION . . . . . . . . . . .31
CONTINUOUS BLOWER . . . . . . . . . . . . . . . . . . . . . . . . 31
INTERMITTENT BLOWER . . . . . . . . . . . . . . . . . . . . . . . 31
NO OUTDOOR AIR OPTIONS . . . . . . . . . . . . . . . . . . . . 31
ECONOMIZER WITH SINGLE ENTHALPY SENSOR . . 31
ECONOMIZER WITH DUAL ENTHALPY SENSORS . . . 32
ECONOMIZER (SINGLE OR DUAL) WITH POWER
EXHAUST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
MOTORIZED OUTDOOR AIR DAMPERS . . . . . . . . . . . 32
COOLING OPERATION ERRORS . . . . . . . . . . . . . . . .32
HIGH-PRESSURE LIMIT SWITCH . . . . . . . . . . . . . . . . . 32
LOW-PRESSURE LIMIT SWITCH . . . . . . . . . . . . . . . . . 32
FREEZESTAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
LOW AMBIENT COOLING . . . . . . . . . . . . . . . . . . . . . . . 32
SAFETY CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . 32
COMPRESSOR PROTECTION . . . . . . . . . . . . . . . . . . 33
FLASH CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
ELECTRIC HEATING SEQUENCE OF
OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
SAFETY CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . 33
RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
HEAT ANTICIPATOR SETPOINTS . . . . . . . . . . . . . . . 34
GAS HEATING SEQUENCE OF OPERATION . . . . . . 34
TWO STAGE FURNACE ONLY . . . . . . . . . . . . . . . . . . . 35
GAS HEAT OPERATION ERRORS . . . . . . . . . . . . . . . 35
TEMPERATURE LIMITS . . . . . . . . . . . . . . . . . . . . . . . . 35
GAS VALVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
CENTRIFUGAL SWITCH . . . . . . . . . . . . . . . . . . . . . . . . 36
ROLLOUT SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
FLAME SENSE CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . . 36
FLASH CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
RESETS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
HEAT ANTICIPATOR SETPOINTS . . . . . . . . . . . . . . . 36
START-UP (COOLING) . . . . . . . . . . . . . . . . . . . . . . . . . . 36
PRESTART CHECK LIST . . . . . . . . . . . . . . . . . . . . . . . 36
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . 37
POST START CHECK LIST . . . . . . . . . . . . . . . . . . . . . 37
SHUT DOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
START-UP (GAS HEAT) . . . . . . . . . . . . . . . . . . . . . . . . . 37
PRE-START CHECK LIST . . . . . . . . . . . . . . . . . . . . . . 37
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . 37
TO LIGHT PILOT AND MAIN BURNERS: . . . . . . . . . . . 37
TO SHUT DOWN: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
POST-START CHECK LIST (GAS) . . . . . . . . . . . . . . . 37
MANIFOLD GAS PRESSURE ADJUSTMENT . . . . . . . 38
PILOT CHECKOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
BURNER INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . 38
BURNER AIR SHUTTER ADJUSTMENT . . . . . . . . . . . 39
CHECKING GAS INPUT . . . . . . . . . . . . . . . . . . . . . . . . 39
NATURAL GAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ADJUSTMENT OF TEMPERATURE RISE . . . . . . . . . . 40
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
COOLING TROUBLESHOOTING GUIDE . . . . . . . . . . 40
CHARGING THE UNIT . . . . . . . . . . . . . . . . . . . . . . . . . 42
NORMAL OPERATING PRESSURES . . . . . . . . . . . . . 43
GAS HEAT TROUBLESHOOTING GUIDE . . . . . . . . . . 44
FLASH CODE TROUBLESHOOTING . . . . . . . . . . . . . 45
IGNITION CONTROL BOARD . . . . . . . . . . . . . . . . . . . . 45
CENTRIFUGAL SWITCH . . . . . . . . . . . . . . . . . . . . . . . . 45
PILOT FLAME LOCKOUT . . . . . . . . . . . . . . . . . . . . . . . 46
PRIMARY OR AUX TEMPERATURE LIMIT . . . . . . . . . . 46
ROLLOUT SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
UNEXPECTED FLAME PRESENCE . . . . . . . . . . . . . . . 47
GAS VALVE STUCK OFF OR ON . . . . . . . . . . . . . . . . . 47
FLAME SENSE CIRCUIT FAILURE . . . . . . . . . . . . . . . . 47
SYMPTOMATIC TROUBLESHOOTING . . . . . . . . . . . . 47
UNIT FLASH CODES . . . . . . . . . . . . . . . . . . . . . . . . . . 49
FAN ON AND OFF DELAYS . . . . . . . . . . . . . . . . . . . . . 49

362254-YIM-D-0109
Johnson Controls Unitary Products 3
LIST OF FIGURES
Fig. # Pg. #
1 RECOMMENDED DRAIN PIPING . . . . . . . . . . . . . . . 9
2 COMPRESSOR RESTRAINING BRACKET . . . . . .9
3 TYPICAL FIELD POWER & CONTROL WIRING .11
4 EXTERNAL SUPPLY CONNECTION EXTERNAL
SHUT-OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5 BOTTOM SUPPLY CONNECTION EXTERNAL
SHUT-OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6 VENT AND COMBUSTION AIR HOOD . . . . . . . .16
7 ENTHALPY SETPOINT ADJUSTMENT . . . . . . . .18
8 ECONOMIZER CONTROL . . . . . . . . . . . . . . . . . .18
9 FOUR AND SIX POINT LOADING . . . . . . . . . . . .19
10 UNIT DIMENSIONS (3 - 5 TON COOLING ONLY/
ELECTRIC HEAT) FRONT VIEW . . . . . . . . . . . . .25
11 UNIT DIMENSIONS (3 - 5 TON COOLING/GAS
HEAT) FRONT VIEW . . . . . . . . . . . . . . . . . . . . . .26
12 UNIT WITH ECONOMIZER RAINHOOD . . . . . . .26
13 UNIT WITH FIXED OUTDOOR AIR/MOTORIZED
DAMPER RAINHOOD . . . . . . . . . . . . . . . . . . . . .27
14 UNIT DIMENSIONS (REAR VIEW) . . . . . . . . . . .27
15 DISCONNECT/BLOWER ACCESS LOCATION . .28
16 PRESSURE DROP ACROSS COIL . . . . . . . . . . .31
17 GAS VALVE PIPING . . . . . . . . . . . . . . . . . . . . . . .35
18 TYPICAL 2 STAGE GAS VALVES . . . . . . . . . . . .38
19 TYPICAL SINGLE STAGE GAS VALVES . . . . . .38
20 PROPER FLAME ADJUSTMENT . . . . . . . . . . . . .38
21 TYPICAL FLAME APPEARANCE . . . . . . . . . . . . .38
22 OPERATING PRESSURES J03DY . . . . . . . . . . .43
23 OPERATING PRESSURES J04DY . . . . . . . . . . .43
24 OPERATING PRESSURES J05DY . . . . . . . . . . .44
25 UNIT CONTROL BOARD . . . . . . . . . . . . . . . . . . .49
LIST OF TABLES
Tbl. # Pg. #
1 UNIT APPLICATION DATA (DY) . . . . . . . . . . . . . . . . 8
2 CONTROL WIRE SIZES . . . . . . . . . . . . . . . . . . . . . 12
3 ELECTRIC HEAT CFM LIMITATIONS . . . . . . . . . . . 13
4 GAS HEAT APPLICATION DATA . . . . . . . . . . . . . . 13
5 GAS PIPE SIZING . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 CENTER OF GRAVITY (ALL MODELS) . . . . . . . . . 19
7 DY 4 AND 6 POINT LOADS WEIGHT
DISTRIBUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8 DY PHYSICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . 20
9 DY OPERATING WEIGHTS (LBS.) . . . . . . . . . . . . . 20
10 ELECTRICAL DATA - DY036, 048 & 060 DIRECT
DRIVE W/O POWERED CONVENIENCE
OUTLET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11 ELECTRICAL DATA - DY036, 048 & 060 DIRECT
DRIVE W/ POWERED CONVENIENCE
OUTLET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
12 ELECTRIC HEAT CORRECTION FACTORS . . . . . 25
13 VOLTAGE LIMITATIONS . . . . . . . . . . . . . . . . . . . . . 25
14 UTILITIES ENTRY . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15 MINIMUM CLEARANCES . . . . . . . . . . . . . . . . . . . . 28
16 SUPPLY AIR BLOWER PERFORMANCE
(DY036, 048, & 060 DIRECT DRIVE) SIDE DUCT
APPLICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
17 SUPPLY AIR BLOWER PERFORMANCE
(DY036, 048, & 060 DIRECT DRIVE) BOTTOM DUCT
APPLICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
18 STATIC RESISTANCES . . . . . . . . . . . . . . . . . . . . . 30
19 ELECTRIC HEAT LIMIT CONTROL SETTING . . . . 34
20 ELECTRIC HEAT ANTICIPATOR SETPOINTS . . . . 34
21 SINGLE STAGE GAS HEAT LIMIT CONTROL
SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
22 2 STAGE GAS HEAT LIMIT CONTROL SETTING. . 36
23 GAS HEAT ANTICIPATOR SETPOINTS . . . . . . . . . 36
24 GAS RATE - CUBIC FEET PER HOUR . . . . . . . . . . 39
25 DY036 COOLING SUPERHEAT
CHARGING TABLE . . . . . . . . . . . . . . . . . . . . . . . . . 42
26 DY048 COOLING SUPERHEAT
CHARGING TABLE . . . . . . . . . . . . . . . . . . . . . . . . . 42
27 UNIT CONTROL BOARD FLASH CODES . . . . . . . 50
28 IGNITION CONTROL BOARD FLASH CODES . . . . 50

362254-YIM-D-0109
4Johnson Controls Unitary Products
GENERAL
YORK Model DY units are either single package cool-
ing units equipped with optional factory installed elec-
tric heaters, or single package gas-fired central heating
furnaces with cooling unit. Both are designed for out-
door installation on a rooftop or slab.
The units are completely assembled on rigid, perma-
nently attached base rails. All piping, refrigerant
charge, and electrical wiring is factory installed and
tested. The units require electric power, gas connec-
tion, duct connections, installation of combustion air
inlet hood, flue gas outlet hoods and fixed outdoor air
intake damper (units without economizer or motorized
damper option only) at the point of installation.
The supplemental electric heaters have nickel-chrome
elements and utilize single point power connection.
The gas-fired heaters have aluminized-steel (or
optional stainless steel) tubular heat exchangers. The
units have spark ignition with proven pilot. All gas heat-
ers are shipped from the factory equipped for natural
gas use, but can be field converted to L.P./ Propane
with Kit Model # 1NP0440 for single stage and Kit
Model # 1NP0485 for 2 stage.
SAFETY CONSIDERATIONS
Due to system pressure, moving parts and electrical
components, installation and servicing of air condition-
ing equipment can be hazardous. Only qualified,
trained, service personnel should install, repair, main-
tain or service this equipment.
Observe all precautions in the literature, on labels and
tags accompanying the equipment whenever working
on air conditioning equipment. Be sure to follow all
other safety precautions that apply.
Wear safety glasses and work gloves, and follow all
safety codes. Use a quenching cloth and have a fire
extinguisher available for all brazing operations.
INSPECTION
As soon as a unit is received, it should be inspected for
possible damage during transit. If damage is evident,
the extent of the damage should be noted on the car-
rier's freight bill. A separate request for inspection by
the carrier's agent should be made in writing.
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property dam-
age.
- Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas sup-
plier’s instructions.
• If you cannot reach the gas supplier, call
the fire department.
- Installation and service must be performed by
a qualified installer, service agency or the
gas supplier.

362254-YIM-D-0109
Johnson Controls Unitary Products 5
REFERENCE
Additional information is available in the following refer-
ence forms:
• Technical Guide - DY036-060, 343615
• General Installation - DY036-060, 362254
RENEWAL PARTS
Contact your local York®parts distribution center for
authorized replacement parts.
APPROVALS
Design listed by CSA as follows:
• For use as a cooling unit only with or without
optional electric heat.
• For use as a forced air furnace with cooling
unit
• For outdoor installation only.
• For installation on combustible material.
• For use with natural gas or propane gas.
The installer should pay particular attention to the
words: NOTE, CAUTION and WARNING. Notes are
intended to clarify or make the installation easier. Cau-
tions are given to prevent equipment damage. Warn-
ings are given to alert installer that personal injury and/
or equipment damage may result if installation proce-
dure is not handled properly.
This product must be installed in strict compli-
ance with the enclosed installation instructions
and any applicable local, state, and national
codes including, but not limited to, building,
electrical, and mechanical codes.
Improper installation may create a condition
where the operation of the product could cause
personal injury or property damage.

362254-YIM-D-0109
6Johnson Controls Unitary Products
PRODUCT NOMENCLATURE
D Y 048 N04 A 2 A AA 2 0 1 2 4 A
D = A/C, Single Pkg., R-22
Product Category
Airflow
D = Direct Drive/Motorized Damper
B = Direct Drive/Economizer
A = Direct Drive
Product Generation
2 = Second Generation
C00 = Cooling Only. Suitable for Field
Installed Electric Heat
Heat Type and Nominal Heat Capacity
N04 = 40 MBH Output Aluminized Steel, 1 Stage (036)
N06 = 60 MBH Output Aluminized Steel, 1 Stage (048)
N08 = 80 MBH Output Aluminized Steel, 1 Stage
(036, 060)
N10 = 100 MBH Output Aluminized Steel, 1 Stage
(048, 060)
D06 = 60 MBH Output Aluminized Steel, 2 Stage
(036, 048, 060)
D10 = 100 MBH Output Aluminized Steel, 2 Stage
(036*, 048, 060)
S04 = 40 MBH Output Stainless Steel, 1 Stage (036)
S06 = 60 MBH Output Stainless Steel, 1 Stage (048)
S08 = 80 MBH Output Stainless Steel, 1 Stage
(036, 060)
S10 = 100 MBH Output Stainless Steel, 1 Stage
(048, 060)
T06 = 60 MBH Output Stainless Steel, 2 Stage
(036, 048, 060)
T10 = 100 MBH Output Stainless Steel, 2 Stage
(036*, 048, 060)
*(D, T)10 = 92 MBH Output on 036 Models
E05 = 5 KW
E07 = 7 KW
E10 = 10 KW
E15 = 15 KW
E20 = 20 KW
E30 = 30 KW
Gas Heat Options
Electric Heat Options
036 = 3.0 Ton
Nominal Cooling Capacity
048 = 4.0 Ton
060 = 5.0 Ton
Product Identifier
Y = 14.0 SEER
Voltage
1 = 208/230-1-60
2 = 208/230-3-60
4 = 460-3-60
5 = 575-3-60
Product Style
A = Style A
A = No Options Installed
Installation Options
B = Option 1
C = Option 2
D = Options 1 & 2
E = Option 3
F = Option 4
G = Options 1 & 3
H = Options 1 & 4
J = Options 1, 2 & 3
K = Options 1, 2, & 4
L = Options 1,3 & 4
M = Options 1, 2, 3, & 4
N = Options 2 & 3
P = Options 2 & 4
Q = Options 2, 3, & 4
R = Options 3 & 4
S = Option 5
T = Options 1 & 5
U = Options 1, 3, & 5
V = Options 1, 4, & 5
W = Options 1, 3, 4, & 5
X = Options 3 & 5
Y = Options 4 & 5
Z = Options 3, 4 & 5
1 = Disconnect
2 = Non-Pwr'd Conv. Outlet
3 = Smoke Detector S.A.
4 = Smoke Detector R.A.
5 = Pwr'd Conv. Outlet
Options
SS Drain Pan
Configuration Options (not required for all units)
These four digits will not be assigned until a quote is requested, or an order placed.
CPC Controller, DFS, APS
Johnson Controller UNT 1126 (N2 protocol), DFS, APS
Honeywell Controller, DFS, APS
Novar Controller, DFS, APS
Simplicity IntelliComfort Controller
Simplicity IntelliComfort Controller w/ModLinc
2" Pleated filters
BAS Ready Economizer (2-10 V.D.C. Actuator without a Controller)
York Commercial Comfort System (YCCS) Rtu Controller
Any Combination of Additional Options that Don’t Have an Option Code Pre-assigned
AA = None
Standard Cabinet
AB = Phase Monitor
AC = Coil Guard
AD = Dirty Filter Switch
AE = Phase Monitor & Coil Guard
AF = Phase Monitor & Dirty Filter Switch
AG = Coil Guard & Dirty Filter Switch
AH = Phase Monitor, Coil Guard & Dirty Filter Switch
AS = Bottom Drain Connection
RC = Coil Guard & American Flag
TA = Technicoat Condenser Coil
TJ = Technicoat Evaporator Coil
TS = Technicoat Evaporator and Condenser Coil
Additional Options
Hinged Filter Door & Toolless Access Cabinet
3-5 Ton Sunline Magnum™ Model Number Nomenclature
BA = Hinged Filter Door & Toolless Access Panels
BB = Phase Monitor, Hinged Filter Door & Toolless
Access Panels
BC = Coil Guard, Hinged Filter Door & Toolless
Access Panels
BD = Dirty Filter Switch, Hinged Filter Door &
Toolless Access Panels
BE = Phase Monitor & Coil Guard, Hinged Filter
Door & Toolless Access Panels
BF = Phase Monitor & Dirty Filter Switch, Hinged
Filter Door & Toolless Access Panels
BG = Coil Guard & Dirty Filter Switch, Hinged Filter
Door & Toolless Access Panels
BH = Phase Monitor, Coil Guard & Dirty Filter Switch,
Hinged Filter Door & Toolless Access Panels
ZZ = If desired option combination is not listed above, ZZ will be assigned and configuration options will be
located in digits 15-18.

362254-YIM-D-0109
Johnson Controls Unitary Products 7
INSTALLATION
INSTALLATION SAFETY INFORMATION:
Read these instructions before continuing this appli-
ance installation. This is an outdoor combination heat-
ing and cooling unit. The installer must assure that
these instructions are made available to the consumer
and with instructions to retain them for future reference.
1. Refer to the furnace rating plate for the approved
type of gas for this furnace.
2. Install this furnace only in a location and position
as specified on page 8 of these instructions.
3. Never test for gas leaks with an open flame. Use
commercially available soap solution made specifi-
cally for the detection of leaks when checking all
connections.
4. Always install furnace to operate within the furnace's
intended temperature-rise range with the duct sys-
tem and within the allowable external static pressure
range, as specified on the unit name/rating plate.
5. This equipment is not to be used for temporary
heating or cooling of buildings or structures under
construction.
LIMITATIONS
These units must be installed in accordance with the
following national and local safety codes:
In U.S.A.:
• National Electrical Code ANSI/NFPA No. 70.
• National Fuel Gas Code Z223.1.
• Gas-Fired Central Furnace Standard ANSI
Z21.47a.
• Local gas utility requirements.
In Canada:
• Current Canadian Electrical Code C22.1.
• Current Gas Installation Codes CSA-B149.1.
• Local plumbing and waste water codes.
• Other applicable local codes.
Refer to the Unit Application Data Table 1 and to the
Gas Heat Application Data Table 4.
If components are to be added to a unit to meet local
codes, they are to be installed at the dealer's and/or
the customer's expense.
Size of unit for proposed installation should be based
on heat loss/heat gain calculation made according to
the methods of the Air Conditioning Contractors of
America (ACCA).
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly
could result in serious injury, death or property
damage.
Never test for gas leaks with an open flame.
use a commercially available soap solution
made specifically for the detection of leaks to
check all connections. A fire or explosion may
result causing property damage, personal
injury or loss of life.
The Simplicity ® control board used in this
product will effectively operate the cooling sys-
tem down to 0°F when this product is applied
in a comfort cooling application for people. An
economizer is typically included in this type of
application. When applying this product for
process cooling applications (computer rooms,
switchgear, etc.), please reference applica-
tions bulletin AE-011-07 or call the applica-
tions department for Unitary Products @ 1-
877-UPG-SERV for guidance. Additional
accessories may be needed for stable opera-
tion at temperatures below 30° F.

362254-YIM-D-0109
8Johnson Controls Unitary Products
LOCATION
Use the following guidelines to select a suitable loca-
tion for these units.
1. Unit is designed for outdoor installation only.
2. Condenser coils must have an unlimited supply of air.
3. Where a choice of location is possible, position the
unit on either north or east side of building.
4. For ground level installation, use a level concrete
slab with a minimum thickness of 4 inches. The
length and width should be at least 6 inches
greater than the unit base rails. Do not tie slab to
the building foundation.
5. Roof structures must be able to support the weight
of the unit and its options and/or accessories. Unit
must be installed on a solid level roof curb or
appropriate angle iron frame.
6. Maintain level tolerance to 1/2 inch maximum
across the entire length or width of the unit.
If a unit is to be installed on a roof curb or special frame
other than a YORK roof curb, gasketing must be
applied to all surfaces that come in contact with the unit
underside.
RIGGING AND HANDLING
Exercise care when moving the unit. Do not remove
any packaging until the unit is near the place of installa-
tion. Rig the unit by attaching chain or cable slings to
the lifting holes provided in the base rails. Spreader
bars, whose length exceeds the largest dimension
across the unit, MUST BE USED.
Units may also be moved or lifted with a forklift. Slotted
openings in the base rails are provided for this pur-
pose. Fork lengths must be a minimum of 42 inches.
Remove the nesting brackets from the four corners on
the top of the unit. All screws that are removed when
removing the brackets must be replaced on the unit.
Refer to Table 9 for unit weights and to the Figure 9 for
approximate center of gravity.
CLEARANCES
All units require certain clearances for proper operation
and service. Installer must make provisions for ade-
quate combustion and ventilation air in accordance with
Section 5.3, Air for Combustion and Ventilation of the
National Fuel Gas Code, ANSI Z223.1 (in U.S.A.) or
Sections 7.2, 7.3 or 7.4 of Gas Installation Codes CSA-
B149.1 (in Canada) and/or applicable provisions of the
local building codes. Refer to Dimensions and Clear-
ances shown in Figures 10 through 13 and Tables 14
TABLE 1: UNIT APPLICATION DATA (DY)
UNIT MODEL NUMBER 036 048 060
Voltage Variation,
Min. / Max.1
1. Utilization range “A” in accordance with ARI Standard 110.
208/230 187 / 252
460 432 / 504
575 540 / 630
Supply Air CFM, Nom. 1200 1600 2000
Wet Bulb Temperature (ºF) of Air on Evaporator Coil,
Min. / Max 57 / 72
Dry Bulb Temperature (ºF) of Air on Condenser Coil,
Min. / Max. 0 / 125
Excessive exposure of this furnace to contami-
nated combustion air may result in equipment
damage or personal injury. Typical contami-
nates include: permanent wave solutions, chlo-
rinated waxes and cleaners, chlorine based
swimming pool chemicals, water softening
chemicals, carbon tetrachloride, Halogen type
refrigerants, cleaning solvents (e.g. perchloro-
ethylene), printing inks, paint removers, var-
nishes, hydrochloric acid, cements and glues,
antistatic fabric softeners for clothes dryers,
masonry acid washing materials.
Before lifting a unit, make sure that all panels
are in place and that its weight is distributed
equally on all cables so it will lift evenly.

362254-YIM-D-0109
Johnson Controls Unitary Products 9
and 15 for the clearances required for combustible con-
struction, servicing, and proper unit operation.
DUCTWORK
Ductwork should be designed and sized according to
the methods in Manual Q of the Air Conditioning Con-
tractors of America (ACCA).
A closed return duct system shall be used. This shall
not preclude use of economizers or outdoor fresh air
intake. The supply and return air duct connections at
the unit should be made with flexible joints to minimize
noise.
The supply and return air duct systems should be
designed for the CFM and static requirements of the
job. They should NOT be sized to match the dimen-
sions of the duct connections on the unit.
Refer to Figures 10 through 14 for information concern-
ing side and bottom supply and return air duct openings.
NOTE: It is recommended that, in Canada, the outlet
duct be provided with a removable access
panel. It is recommended that this opening be
accessible when the unit is installed in service,
and of a size such that smoke or reflected light
may be observed inside the casing to indicate
the presence of leaks in the heat exchanger.
The cover should be attached in a manner
adequate to prevent leakage.
CONDENSATE DRAIN
Plumbing must conform to local codes. Use a sealing
compound on male pipe threads. Install a condensate
drain line from the 3/4” NPT female connection on the
unit to an open drain.
NOTE: The condensate drain operates in a negative
pressure in the cabinet. The condensate drain
line MUST be trapped to provide proper drain-
age. See Figure 1.
COMPRESSORS
Units are shipped with compressor mountings factory-
adjusted and ready for operation.
Units with scroll compressors have a shipping bracket
which must be removed after the unit is set in place.
See Figure 2.
FILTERS
One-inch or two-inch filters can be supplied with each
unit. Filters must always be installed ahead of the
evaporator coil and must be kept clean or replaced with
same size and type. Dirty filters will reduce the capacity
of the unit and will result in frosted coils or safety shut-
down. Minimum filter area and required sizes are
shown in Physical Data Table 8.
Do not permit overhanging structures or shrubs
to obstruct outdoor air discharge outlet, com-
bustion air inlet or vent outlets.
When fastening ductwork to side duct flanges
on unit, insert screws through duct flanges only.
DO NOT insert screws through casing. Outdoor
ductwork must be insulated and waterproofed.
FIGURE 1 - RECOMMENDED DRAIN PIPING
FIGURE 2 - COMPRESSOR RESTRAINING BRACKET
Do not loosen compressor mounting bolts.
WIRE TIE
(CUT AND
REMOVE)
MOUNTING
BRACKET TOP
(REMOVE)
MOUNTING
BRACKET BASE
REMOVE THESE
SCREWS (2)
COMPRESSOR

362254-YIM-D-0109
10 Johnson Controls Unitary Products
SERVICE ACCESS
The following removable panels provide access to all
serviceable components:
• Compressor compartment
• Electric Heat compartment
• Gas Heat compartment
• Blower compartment
• Main control box
• Filter compartment
Refer to the Dimensions and Clearances shown in Fig-
ures 10, 11, 13 and 14 for location of these access
panels.
Make sure that all screws and panel latches
are replaced and properly positioned on the
unit to maintain an airtight seal.

362254-YIM-D-0109
Johnson Controls Unitary Products 11
TYPICAL POWER WIRING
TYPICAL CONTROL WIRING
FIGURE 3 - TYPICAL FIELD POWER & CONTROL WIRING
REFER TO THE ELECTRICAL DATA
TABLES TO SIZE THE DISCONNECT
SWITCH, OVERCURRENT PROTEC-
TION AND WIRING.
RC
Y
R
Y1
Y2
W1
W
W2
G
C
G
RH
THERMOSTAT
TERMINALS
UNIT TERMINAL
STRIP TB1
24 VOLT
TRANSFORMER
ADD
JUMPER
1
COOLING / HEATING (24 VOLT THERMOSTAT)
24 VOLT THERMOSTAT 2ET07701024. TO CONTROL THE ECONOMIZER ON THE SECOND
STAGE COOLING OR TO HAVE AN ELECTRIC HEAT ACCESSORY WITH TWO STAGES OF
HEAT, USE THERMOSTAT 2TH0471024.
1
RC
Y
R
Y1
Y2
W1
W
W2
G
C
G
RH
THERMOSTAT
TERMINALS
UNIT TERMINAL
STRIP TB1
24 VOLT
TRANSFORMER
ADD
JUMPER
1
COOLING / HEATING (24 VOLT THERMOSTAT)
24 VOLT THERMOSTAT 2ET07701024. TO CONTROL THE ECONOMIZER ON THE SECOND
STAGE COOLING OR TO HAVE AN ELECTRIC HEAT ACCESSORY WITH TWO STAGES OF
HEAT, USE THERMOSTAT 2TH0471024.
1
RC
RH
Y1
Y2
W1
W2
G
LED 1
LED 2
COM
A1
A2
T
T
B
R
Y1
Y2
G
C
X
OCC
W2
W1
THERMOSTAT1
TERMINALS UNIT TERMINAL
STRIP TB1 24 VOLT
TRANSFORMER
TO REMOTE SENSOR
2TH040702224 IF USED
NOT
USED
ADD
JUMPER
ADD
JUMPER
4
4
3
2
1ELECTRONIC PROGRAMMABLE THERMOSTAT 2ET04700224 (INCLUDES SUBBASE).
2SECOND STAGE COOLING IS NOT REQUIRED ON UNITS LESS ECONOMIZER.
3SECOND STAGE HEATING IS ONLY REQUIRED ON UNITS WITH A TWO STAGE
ELECTRIC HEATER OR TWO STAGE GAS HEAT.
4
COOLING / HEATING (ELECTRONIC THERMOSTAT)
MULTI STAGE
REMOVE JUMPER J2 FROM TERMINALS 4 AND 9 ON JUMPER PLUG CONNECTOR
P6 ON UNITS WITH ECONOMIZER. TERMINALS A1 AND A2 PROVIDE A RELAY
OUT-PUT TO CLOSE THE OUTDOOR ECONOMIZER DAMPERS WHEN THE
THERMOSTAT SWITCHES TO THE SET-BACK POSITION.
RH
RC
Y
W
G
R
Y1
W1
C
G
ADD
JUMPER
THERMOSTAT1
TERMINALS UNIT TERMINAL
STRIP TB1
24 VOLT
TRANSFORMER
1
ELECTRONIC PROGRAMMABLE THERMOSTAT 2ET07701024 (INCLUDES SUBBASE).
TO CONTROL THE ECONOMIZER ON SECOND STAGE COOLING, USE THERMOSTAT
2TH04700224.
COOLING / HEATING (ELECTRONIC THERMOSTAT)
SINGLE STAGE

362254-YIM-D-0109
12 Johnson Controls Unitary Products
THERMOSTAT
The room thermostat should be located on an inside
wall approximately 56 inches above the floor where it
will not be subject to drafts, sun exposure or heat from
electrical fixtures or appliances. Follow the manufac-
turer's instructions enclosed with the thermostat for
general installation procedure. A minimum of seven
color-coded insulated wires (#18 AWG) should be used
to connect the thermostat to the unit.
POWER AND CONTROL WIRING
Field wiring to the unit must conform to provisions of
the National Electrical Code, ANSI / NFPA No. 70 (in
U.S.A.), current Canadian Electrical Code C22.1 (in
Canada) and/or local ordinances. The unit must be
electrically grounded in accordance with NEC and CEC
(as specified above) and/or local codes. Voltage toler-
ances, which must be maintained at the compressor
terminals, during starting and running conditions, are
indicated on the unit Rating Plate and the Unit Applica-
tion Data table.
The internal wiring harness furnished with this unit is
an integral part of a CSA design certified unit. Field
alteration to comply with electrical codes should not be
required.
A fused disconnect switch should be field provided for
the unit. The switch must be separate from all other cir-
cuits. Wire entry at knockout openings require conduit
fittings to comply with NEC (in U.S.A.), CEC (in Can-
ada) and/or local codes. If any of the wire supplied with
the unit must be replaced, replacement wire must be of
the type shown on the wiring diagram and the same
minimum gauge as the replaced wire.
Use copper conductors properly sized to carry the load.
Each unit must be wired with a separate branch circuit
fed directly from the meter panel and properly fused.
Refer to the Typical Field Wiring Figure 3 and to the
appropriate unit wiring diagram for control circuit and
power wiring information.
OPTIONS/ACCESSORIES
ELECTRIC HEAT
The factory- or field-installed heaters are wired for sin-
gle point power supply. Power supply need only be
brought into the single point terminal block and thermo-
stat wiring to the low voltage terminal strip located in
the upper portion of the unit control box.
These CSA approved heaters are located within the
central compartment of the unit with the heater ele-
ments extending into the supply air chamber. Refer to
Figure 10 for access panel location.
Fuses are supplied, where required, by the factory.
Some KW sizes require fuses and others do not. Refer
to Table 3 for minimum CFM limitations.
208/230-3-60 and 380/415-3-50 units control
transformers are factory wired for 230v and
415v power supply respectively. Change tap
on transformer for 208-3-60 or 380-3-50 oper-
ation. See unit wiring diagram.
When connecting electrical power and control
wiring to the unit, waterproof type connectors
MUST BE USED so that water or moisture
cannot be drawn into the unit during normal
operation. The above waterproofing conditions
will also apply when installing a field-supplied
disconnect switch.
TABLE 2: CONTROL WIRE SIZES
Wire Size Maximum Length1
1. From the unit to the thermostat and back to the unit.
18 AWG 150 Feet

362254-YIM-D-0109
Johnson Controls Unitary Products 13
GAS HEAT
These gas-fired heaters have aluminized-steel or
optional stainless steel, tubular heat exchangers with
spark ignition with proven pilot.
All gas heaters are shipped from the factory equipped
for natural gas use. See Gas Heat Application Data
Table.
For natural gas heating installations in locations requir-
ing low NOx emissions, Accessory model 1LN0406
must be used.
NOTE: Gas Heaters are shipped available for natural gas, but can be converted to L.P. with Kit Model No. 1NP0440 or 1NP0485 (2
Stage). All furnaces meet the latest California seasonal efficiency requirements.
1. Based on 1075 Btu/Ft3.
2. The air flow must be adjusted to obtain a temperature rise within the range shown.
TABLE 3: ELECTRIC HEAT CFM LIMITATIONS
Size
(Tons) Voltage Minimum Supply Air (CFM)
Heater kW
5 7 10 15 20 30
3
208/230-1-60 900 900 900 900 900 -
208/230-3-60 900 900 900 900 900 -
460-3-60 - 900 900 900 900 -
600-3-60 - - 900 900 900 -
4
208/230-1-60 1200 1200 1200 1200 1200 -
208/230-3-60 1200 1200 1200 1200 1200 -
460-3-60 - 1200 1200 1200 1200 -
600-3-60 - - 1200 1200 1200 -
5208/230-3-60 1500 1500 1500 1500 1500 1500 460-3-60 - 1500 1500 1500 1500 1500
600-3-60 - - 1500 1500 1500 1500
TABLE 4: GAS HEAT APPLICATION DATA
GAS HEAT
OPTION
INPUT
CAPACITY
(MBH)
OUTPUT
CAPACITY
(MBH)
AVAILABLE
ON MODELS GAS RATE1
(FT3/HR)
TEMPERATURE RISE °F AT FULL INPUT2
MIN. MAX.
N04 50 40 3 TON 47 15 45
N06 75 60 4 TON 70 25 70
N08 100 80 3/5 TON 93 45/25/25 75/55/55
N10 125 100 4/5 TON 116 45/35/30 75/75/75
D06 75 61 3/4/5 TON 70 35/25/20/15 70/70/55/45
D10 115 92 3 TON 107 55 90
D10 125 101 4/5 TON 116 45/35/30 75/75/75

362254-YIM-D-0109
14 Johnson Controls Unitary Products
GAS PIPING
Proper sizing of gas piping depends on the cubic feet
per hour of gas flow required, specific gravity of the gas
and the length of run. “National Fuel Gas Code” Z223.1
(in U.S.A.) or the current Gas Installation Codes CSA-
B149.1 (in Canada) should be followed in all cases
unless superseded by local codes or gas utility require-
ments. Refer to the Pipe Sizing Table 5.
The heating value of the gas may differ with locality.
The value should be checked with the local gas utility.
NOTE: There may be a local gas utility requirement
specifying a minimum diameter for gas piping.
All units require a 1/2” pipe connection at the
entrance fitting.
GAS CONNECTION
The gas supply line can be routed through the knock-
outs located on the front of the unit or through the
opening provided in the unit's base. Refer to Figure 11
to locate these access openings. Typical supply piping
arrangements are shown in Figures 4 and 5. All
shaded items are field-supplied.
If gas supply line is routed through the unit's base
ensure that the burner assembly can be removed for
maintenance without disturbing the supply line. The sup-
ply piping and fittings must lie below the bottom gas
manifold to avoid interference with the burner assembly.
Two grommets are shipped in the blower compartment
(in parts bag taped to the blower housing) of every unit
with gas heat and should be used in the knockouts
when the gas piping penetrates the front of the unit.
After the gas supply piping has been installed, the bot-
tom opening in the unit should be sealed to prevent
water from leaking into the building.
Gas piping recommendations:
1. A drip leg and a ground joint union must be
installed in the gas piping.
2. When required by local codes, a manual shut-off
valve may have to be installed outside of the unit.
3. Use wrought iron or steel pipe for all gas lines. Pipe
compound should be applied sparingly to male
threads only.
4. All piping should be cleaned of dirt and scale by
hammering on the outside of the pipe and blowing
out the loose dirt and scale. Before initial start-up,
be sure that all of the gas lines external to the unit
have been purged of air.
5. The gas supply should be a separate line and
installed in accordance with all safety codes as
prescribed under “Limitations”. After the gas con-
nections have been completed, open the main
shut-off valve admitting normal gas pressure to the
mains. Check all joints for leaks with soap solution
or other material suitable for the purpose. NEVER
USE A FLAME.
TABLE 5: GAS PIPE SIZING
1/2 in. 3/4 in. 1 in. 1-1/4 in.
10 132 278 520 1,050
20 92 190 350 730
30 73 152 285 590
40 63 130 245 500
50 56 115 215 440
60 50 105 195 400
70 46 96 180 370
80 43 90 170 350
90 40 84 160 320
100 38 79 150 305
NOMINAL IRON PIPE SIZE
LENGTH IN
FEET
Maximum capacity of pipe in cubic feet of gas per hour. (Based upon
a pressure drop of 0.3 inch water column and 0.6 specific gravity gas).
Natural gas may contain some propane. Pro-
pane, being an excellent solvent, will quickly
dissolve white lead or most standard commer-
cial compounds. Therefore, a special pipe
compound must be applied when wrought iron
or steel pipe is used. Shellac base compounds
such as Gaskolac or Stalastic, and compounds
such as Rectorseal #5, Clyde's or John Crane
may be used.

362254-YIM-D-0109
Johnson Controls Unitary Products 15
6. The furnace and its individual manual shut-off
valve must be disconnected from the gas supply
piping system during any pressure testing of that
system at test pressures in excess of 1/2 psig
(3.48kPa).
The furnace must be isolated from the gas supply
piping system by closing its individual manual shut-
off valve during any pressure testing of the gas
supply piping system at test pressures equal to or
less than 1/2 psig (3.48kPa).
7. A 1/8 inch NPT plugged tap, accessible for test
gage connection, must be installed immediately
upstream of the gas supply connection to the fur-
nace.
L.P. UNITS, TANKS AND PIPING
All gas heat units are shipped from the factory
equipped for natural gas use only. The unit may be
converted in the field for use with L.P./propane gas
with accessory kit model number 1NP0440 or
1NP0485 (2 Stage).
All L.P./propane gas equipment must conform to the
safety standards of the National Fire Protection Associ-
ation.
For satisfactory operation, adequate L.P./propane gas
pressure must be provided at the unit manifold under
full load. Maintaining proper gas pressure depends on
three main factors:
1. The vaporization rate depends on (a) the tempera-
ture of the liquid and (b) the “wetted surface” area
of the container or containers.
2. The proper pressure regulation. (Two-stage regula-
tion is recommended from the standpoint of both
cost and efficiency.)
3. The pressure drop in the lines between regulators
and between the second stage regulator and the
appliance. Pipe size required will depend on the
length of the pipe run and the total load of all appli-
ances.
Complete information regarding tank sizing for vapor-
ization, recommended regulator settings, and pipe siz-
ing is available from most regulator manufacturers and
L.P./propane gas suppliers.
L.P./propane gas is an excellent solvent and special
pipe compound must be used when assembling piping
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly
could result in serious injury, death or property
damage.
Never test for gas leaks with an open flame.
use a commercially available soap solution
made specifically for the detection of leaks to
check all connections. A fire or explosion may
result causing property damage, personal
injury or loss of life.
FIGURE 4 - EXTERNAL SUPPLY CONNECTION
EXTERNAL SHUT-OFF
FIGURE 5 - BOTTOM SUPPLY CONNECTION
EXTERNAL SHUT-OFF

362254-YIM-D-0109
16 Johnson Controls Unitary Products
for this gas as it will quickly dissolve white lead or most
standard commercial compounds. Shellac base com-
pounds such as Rectorseal #5 are satisfactory for this
type of gas.
Check all connections for leaks when piping is com-
pleted, using a soap solution. NEVER USE A FLAME.
VENT AND COMBUSTION AIR HOODS
The vent hood and combustion air hood (with screens)
are shipped attached to the blower housing in the
blower compartment. These hoods must be installed to
assure proper unit function. All hoods must be fastened
to the outside of the gas heat access panel with the
screws provided in the bag also attached to the blower
housing.
The screen for the combustion air intake hood is
secured to the inside of the access panel opening with
three fasteners and the screws used for mounting the
hood to the panel. The top flange of this hood slips in
under the top of the access panel opening when install-
ing. Refer to Vent and Combustion Air Hood Figure 6.
The vent hood is installed by inserting the top flange of
the hood into the slotted opening in the access panel
and securing in place.
The products of combustion are discharged horizon-
tally through this screened, hooded vent opening on
the gas heat access panel.
ECONOMIZER/MOTORIZED DAMPER AND RAIN
HOOD
The instruction for the optional economizer/motorized
damper and rain hood can be found in form 035-
07364-000. Use these instructions when field assem-
bling an economizer rain hood onto a unit. The outdoor
and return air dampers, the damper actuator, the
damper linkage, the outdoor and return air divider baf-
fles, and all the control sensors are factory mounted as
part of the “Factory installed” economizer/motorized
damper options.
POWER EXHAUST/BAROMETRIC RELIEF DAMPER
AND RAIN HOOD
The instructions for the power exhaust/barometric relief
damper and rain hood can be found in form 530.18-
N1.10V.
All of the components, including the dampers, hard-
ware, and mounting instructions are shipped in a single
package external from the unit and must be field
assembled and installed.
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly
could result in serious injury, death or property
damage.
Never test for gas leaks with an open flame.
use a commercially available soap solution
made specifically for the detection of leaks to
check all connections. A fire or explosion may
result causing property damage, personal
injury or loss of life.
FIGURE 6 - VENT AND COMBUSTION AIR HOOD
An adhesive backed label is provided over the
outside of the combustion air inlet opening to
prevent moisture from entering the unit, which
could cause damage to electrical components.
Allow this closure label to remain in place until
the combustion air hood is to be installed.

362254-YIM-D-0109
Johnson Controls Unitary Products 17
Power exhaust is only available as a field installed
accessory.
ECONOMIZER AND POWER EXHAUST DAMPER
SET POINT ADJUSTMENTS AND INFORMATION
Remove the economizer access panel from the unit.
Loosen but do not remove the two panel latches.
Locate the economizer control module, where the fol-
lowing adjustments will be made.
Check that the damper blades move smoothly without
binding; carefully turn the Minimum Position Adjusting
screw (found on the damper control module) fully
clockwise and then set the thermostat indoor fan switch
to the on position and then off, or energize and de-
energize terminals “R” to “G”.
MINIMUM POSITION ADJUSTMENT
With thermostat set to indoor fan on position, or termi-
nals “R” to “G” energized, turn the Minimum Position
Adjusting screw (located on the damper control mod-
ule) counterclockwise until the desired minimum
damper position has been attained.
ENTHALPY SET POINT ADJUSTMENT
The enthalpy set point may now be set by selecting the
desired setpoint shown in the Enthalpy Setpoint Adjust-
ment Figure 7. Adjust as follows:
• For a single enthalpy operation carefully turn
the set point adjusting screw (found on the
damper control module) to the “A”, “B”, “C” or
“D” setting corresponding to the lettered curve
of the Enthalpy Setpoint Adjustment Figure 7.
• For a dual enthalpy operation, carefully turn
the set point adjusting screw fully clockwise
past the “D” setting.
POWER EXHAUST DAMPER SETPOINT (WITH OR WITH-
OUT POWER EXHAUST)
• With no power exhaust option, adjust the
Exhaust Air Adjustment Screw fully clockwise.
• With power exhaust option, each building pres-
surization requirement will be different. The
point at which the power exhaust comes on is
determinedby the economizerdamper position
(Percent Open). The Exhaust Air Adjustment
Screw should be set at the Percent Open of
the economizer damper at which the power
exhaust is needed. It can be set from 0 to
100% damper open.
INDOOR AIR QUALITY
Indoor Air quality (indoor sensor input): Terminal AQ
accepts a +2 to +10 Vdc signal with respect to the
(AQ1) terminal. When the signal is below it's setpoint,
the actuator is allowed to modulate normally in accor-
dance with the enthalpy and mixed air sensor inputs.
When the AQ signal exceeds it's setpoint setting and
there is no call for free cooling, the actuator is propor-
tionately modulated from the 2 to 10 Vdc signal, with 2
Vdc corresponding to full closed and 10 Vdc corre-
sponding to full open. When there is no call for free
cooling, the damper position is limited by the IAQ Max
damper position setting. When the signal exceeds it's
setpoint (Demand Control Ventilation Setpoint) setting
and there is a call for free cooling, the actuator modu-
lates from the minimum position to the full open posi-
tion based on the highest call from either the mixed air
sensor input or the AQ voltage input.
• Optional CO2Space Sensor Kit Part #
2AQ04700324
• Optional CO2Unit Sensor Kit Part #
2AQ04700424
Replace the economizer access panel.
Extreme care must be excercised in turning all
setpoint, maximium, and minimum damper
positioning adjustment screws to prevent twist-
ing them off.

362254-YIM-D-0109
18 Johnson Controls Unitary Products
FIGURE 7 - ENTHALPY SETPOINT ADJUSTMENT
40
(4)
70
(21)
50
(10)
55
(13)
60
(16)
65
(18)
35
(2)
45
(7)
75
(24)
80
(27)
35
(2)
40
(4)
45
(7)
50
(10)
55
(13)
60
(16)
65
(18)
70
(21)
75
(24)
80
(27)
85
(29)
85
(29)
90
(32)
90
(32)
105
(41)
110
(43)
100
(38)
95
(35)
95
(35)
100
(38)
105
(41)
110
(43)
APPROXIMATE DRY BULB TEMPERATURE - 0F (0C)
D
D
C
C
B
B
A
A
CONTROL
CURVE
CONTROL POINT
APPROX.
0
F (
0
C)
AT 50% RH
A
D
C
B
63 (17)
73 (23)
70 (21)
67 (19)
FIGURE 8 - HONEYWELL ECONOMIZER CONTROL W7212
N1 N
P1 P
EXH
Set
EXH
Min
Pos
IAQ
Max
IAQ
IAQ
Min
Free
Cool
T
T1
AQ1 AQ
SO+ SO
SR+ SR
A
BC
D
TR TR1
24
Vac
HOT
24
Vac
COM
EF EF1
2
34
5
1
+
Exhaust Air
Adjustment
Screw
Exhaust Air LED
Damper Min.
Position
Screw
Indoor Air Quality
Max. Adjustment
Screw
Indoor Air Quality
LED
Indoor Air Quality
Min. Adjustment
Screw
Free Cooling LED
Economizer Enthalpy
Set Point Adjustment
Screw

362254-YIM-D-0109
Johnson Controls Unitary Products 19
FIGURE 9 - FOUR AND SIX POINT LOADING
TABLE 6: CENTER OF GRAVITY (ALL MODELS)
DIMENSION DY 036-060
X40
Y20
44
7
/
8
82
1
/
4
Y
X
A
B
C
D
CONDENSER COIL
END OF UNIT
FRONT OF UNIT
APPROXIMATE
CENTER OF GRAVITY
BACK OF UNIT
447/8
821/4
Y
X
A
B
C
D
E
F
CONDENSER COIL
END OF UNIT
FRONT OF UNIT
APPROXIMATE
CENTER OF GRAVITY
BACK OF UNIT
TABLE 7: DY 4 AND 6 POINT LOADS WEIGHT DISTRIBUTION
UNIT TOTAL 4-Point Loading (lb) 6-Point Loading (lb)
ABCDABCDEF
DY036 Cooling/ Electric 575 132 125 155 164 89 85 82 102 106 110
DY036N04 615 141 133 166 175 95 91 88 110 114 118
DY036D06 625 143 135 168 178 96 93 89 111 115 120
DY036N08 635 145 138 171 181 98 94 91 113 117 122
DY036D10 645 148 140 174 184 99 96 92 115 119 124
DY048 Cooling/ Electric 585 134 127 158 167 90 87 84 104 108 112
DY048(D,N)06 635 145 138 171 181 98 94 91 113 117 122
DY048(D,N)10 655 150 142 177 187 101 97 94 117 121 125
DY060 Cooling/ Electric 590 135 128 159 168 91 88 84 105 109 113
DY060D06 640 147 139 173 182 99 95 92 114 118 123
DY060N08 650 149 141 175 185 100 97 93 116 120 125
DY060(D,N)10 660 151 143 178 188 102 98 95 118 122 126

362254-YIM-D-0109
20 Johnson Controls Unitary Products
TABLE 8: DY PHYSICAL DATA
MODELS DY
036 048 060
EVAPORATOR
BLOWER Centrifugal Blower (Dia. x Wd. in.) 12 X 10 12 X 10 12 X 10
Fan Motor HP (Direct Drive) 3/4 1 1
EVAPORATOR
COIL
Rows Deep 3 4 4
Fins Per Inch 13 13 13
Face Area (Ft.2) 5.1 5.1 5.1
CONDENSER
FANS
Propeller Dia. (in.) 24 24 24
Fan Motor HP 1/2 1/2 1/2
Nom. CFM 4200 4200 4200
CONDENSER
COILS
Rows Deep 2 2 2
Fins Per Inch 18 18 18
Face Area (Ft.2) 17.117.117.1
COMPRESSOR Quantity 1 1 1
Type Recip. Recip. Scroll
AIR
FILTERS
Quantity Per Unit (15” X 20” X 1” or 2“) 2 2 2
Quantity Per Unit (14” X 25” X 1” or 2“) 1 1 1
Total Face Area (Ft.2) 6.3 6.3 6.3
CHARGE Refrigerant 22 (lbs./oz.) 9/4 9/8 11/8
TABLE 9: DY OPERATING WEIGHTS (LBS.)
MODEL SIZE 3 TON 4 TON 5 TON
BASIC
UNIT
DY (Cooling Only) 575 585 590
DY
(Gas/Electric)
N04 615 - -
N06 - 635 -
N08 635 - 650
N10 - 655 660
D06 625 635 640
D10 645 655 660
OPTIONS
Economizer 50
Motorized Damper 26
Electric Heater 5 - 7 kW 18 10 - 15 kW 23
20 - 30 kW 28
ACCY. Roof Curb 92
Barometric Relief / Fixed Air Damper 10
