Johnson Controls RHP14J 184S21 Quick start guide

RHP SERIES
SPLIT-SYSTEM HEAT PUMPS
14.5 SEER – R-410A – 1 PHASE
1.5 THRU 5 NOMINAL TONS
MODELS: RHP14J18 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Standard 10-Years limited compressor warranty.
Extended 10-Years limited parts warranty requires online
registration within 90 days of purchase for replacement or
closing for new home construction.
*Does not apply to R-22 models, 3-Phase models, or internet sales.
See Limited Warranty certificate in User's Information Manual for details.
®
TECHNICAL
GUIDE
TECHNICAL
GUIDE
810754-UTG-C-0214
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The 14.5 SEER Series unit is the outdoor part of a versatile cli-
mate system. It is designed with a matching indoor coil compo-
nent from Johnson Controls Unitary Products. Available for
typical applications this climate system is supported with acces-
sories and documents to serve specific functions.
FEATURES
•Small Footprint - The compact footprint is a perfect fit for
any application.
•Quality Condenser Coils - The coil is constructed of copper
tubing and enhanced aluminum fins for increased perfor-
mance.
•Coil Protection - Coils are protected from damage by a slot-
ted, stamped steel coil guard.
•Protected Compressor - Compressors are protected inter-
nally by a high pressure relief valve and a temperature sen-
sor, and externally by the system high and low pressure
switches. A factory installed liquid line filter-drier further pro-
tects the compressor against moisture and debris. The 5-ton
system utilizes a two-stage compressor.
•Environmentally Friendly Refrigerant - The R-410A refrig-
erant delivers environmentally friendly performance with zero
ozone depletion.
•Durable Finish - An automotive quality finish provides the
ultimate protection from harmful UV rays and rust-creep,
ensuring a long-lasting, high quality apprearance. A powder
paint top coat is applied over a baked on primer using a gal-
vanized, zinc coated steel base material.
•Lower Installed Cost - Installation time and costs are
reduced by easy power and control wiring connections. The
unit is factory charged for a 15-foot lineset. The small base
dimension means less space is required on the ground or
roof.
•Top Discharge - Warm air from the top mounted fan is blown
up, away from the structure and any landscaping. This allows
compact location on multi-unit applications.
•Low Operating Sound Levels - The upward air flow carries
the normal operating noise away from the living area. The
rigid top panel effectively isolates any motor sound. Isolator
mounted compressor and the condenser coil muffle the nor-
mal fan motor and compressor operating sounds.
•Low Maintenance - Long life, permanently lubricated motor-
bearings need no annual servicing.
•Easy Service Access - Fully exposed refrigerant connec-
tions and a single panel covering the electrical controls make
for easy servicing of the unit.
•Secured Service Valves - Secured, re-usable service
valves are provided on both the liquid and vapor sweat con-
nections for ease of evacuating and charging.
•Advanced System Control - These heat pumps feature a
demand-defrost control system to provide optimal comfort
and reliable operation over a wide range of conditions.
•Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.

810754-UTG-C-0214
2Johnson Controls Unitary Products
* Adapter Fitting Required for 1-1/8" Lilneset.
All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of base pan to top of fan guard.
Overall length and width include screw heads.
Physical and Electrical Data
MODEL RHP14J
184S21 RHP14J 244S21 RHP14J 304S21 RHP14J 364S21 RHP14J 424S21 RHP14J 484S21 RHP14J 604S21
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1187 to 252
Minimum Circuit Ampacity 11.9 17.6 17.3 19.7 23.7 28.5 35.3
Max. Overcurrent Device Amps 220 30 30 30 40 50 60
Min. Overcurrent Device Amps 315 20 20 20 25 30 40
Compressor
Amps
Type Scroll Scroll Scroll Recip Scroll Scroll 2-Stage Scroll
Rated Load 9.0 13.4 12.8 14.7 17.9 21.8 35.3
Locked Rotor 48.0 58.3 64.0 74.0 112.0 117.0 118.0
Crankcase Heater No No No Yes No No No
Factory External Discharge Muffler Yes Yes Yes Combined
DM/CV Yes Yes Yes
Factory External Check Valve No No No No No No
HS Kit Required with TXV 4No No No Yes No No No
Fan Diameter Inches 24 22 24 24 24 24 24
Fan Motor
Rated HP 1/10 1/8 1/4 1/4 1/4 1/4 1/4
Rated Load Amps 0.7 0.8 1.3 1.3 1.3 1.3 1.3
Nominal RPM 825 1075 850 850 850 850 850
Nominal CFM 2000 2000 3900 3800 3600 3500 3800
Coil Face Area Sq. Ft. 15.72 19.17 23.58 23.58 23.58 23.58 23.58
Rows Deep 1111122
Fins / Inch 22 22 22 22 22 18 18
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 3/4 3/4 3/4 3/4 7/8 7/8 1-1/8
Unit Charge (Lbs. - Oz.) 56 - 15 7 - 14 9 - 14 10 - 6 11 - 4 13 - 1 14 - 2
Charge Per Foot, Oz. 0.62 0.62 0.62 0.62 0.67 0.67 0.75
Operating Weight Lbs. 145 145 176 193 198 248 290
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. See Hard Start Kit Accessory Installation Manual for Hard Start Kit part number for each model.
5. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-
tract the amount of refrigerant, using the difference in length multiplied by the per foot value.
B
C
A
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A B C Liquid Vapor
18 28-1/4 34 34
3/8
3/4
24 40-1/4 29-1/2 29-1/2
30 40-1/4 34 34
36 40-1/4 34 34
42 40-1/4 34 34 7/8
48 40-1/4 34 34
60 40-1/4 34 34 7/8 *

810754-UTG-C-0214
Johnson Controls Unitary Products 3
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the outdoor unit, the smallest matched indoor unit, and 15 feet of interconnecting line tubing.
2. Verify the TXV or orifice and additional charge required for specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For indoor matches requiring additional charge, the refrigerant needs to be weighed in for specific matched indoor unit and lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + charge adder for matched indoor unit +
charge adder for line set.
System Charge for Various Matched Systems
Outdoor Unit RHP14J184S21 RHP14J244S21 RHP14J304S21 RHP14J364S21 RHP14J424S21 RHP14J484S21 RHP14J604S21
Required Orifice or TXV 1,2 .051/4F1 .059/4G1 .063/4G1 .071/4H1 .075/4J1 4P1 4K1
Indoor Unit 3,4,5 Additional Charge, Oz
RFCX24BE .051 / TXV + 0 .059 / TXV + 0 – – – – –
RFCX30BE .051 / TXV + 0 .059 / TXV + 0 – – – – –
RFCX36CE – – .063 / TXV + 0 .071 / TXV + 0 – – –
RFCX42DE –––.071 / TXV + 5 – – –
RFCX48DE –––.071 / TXV + 25 .075 / TXV + 0 TXV + 0 –
RFCX60DE ––––TXV + 8 TXV + 10 TXV + 0
RFCX24BP .051 / TXV + 0 .059 / TXV + 0 – – – – –
RFCX36BP – – .063 / TXV + 0 .071 / TXV + 0 – – –
RFCX42CP –––.071 / TXV + 5 – – –
RFCX48DP ––––.075 / TXV + 0 TXV + 0 –
RFCX60DP –––––––
FC/MC/PC32 .051 / TXV + 0 .059 / TXV + 0 – – – – –
FC/MC/PC35 .051 / TXV + 0 .059 / TXV + 0 – – – – –
FC/MC/PC37 .051 / TXV + 13 .059 / TXV + 12 .063 / TXV + 0 .071 / TXV + 0 – – –
FC/MC/PC43 .051 / TXV + 13 .059 / TXV + 12 .063 / TXV + 0 .071 / TXV + 0 – – –
FC/MC/PC48 –––.071 / TXV + 5 – – –
FC/MC/PC60 –––.071 / TXV + 25 .075 / TXV + 0 TXV + 0 –
FC/MC62 ––––TXV + 8 TXV + 10 TXV + 0
FC64 –––––TXV + 29 TXV + 8
UC48 –––.071 / TXV + 23 – – –
UC60 –––.071 / TXV + 38 .075 / TXV + 4 – –
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil
only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:
1. For applications requiring a TXV use S1-1TVM*** series kit.
2. Approved orifice(s) shipped with outdoor unit.
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require blower Time Delay Kit S1-2FD06700224.
4. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
5. Refer to Cooling and Heating Performance Data tables for actual performance for specified system matches.

810754-UTG-C-0214
4Johnson Controls Unitary Products
— = Not applicable.
MA Modular Air Handlers use Coil Only Ratings.
— = Not applicable.
MA Modular Air Handlers use Coil Only Ratings.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL 1
MODEL
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
14.5 SEER HP WITH AIR HANDLERS
RHP14J184S21 RFCX24BE 17.5 – 585 18.0 13.3 14.50 12.00 RFCX30BE 17.5 – 660 18.0 13.1 15.00 12.50
RFCX24BP 17.5 – 675 18.0 13.1 13.00 11.00
RHP14J244S21 RFCX24BE 17.5 – 825 23.0 17.4 15.00 12.50 RFCX30BE 17.5 – 800 23.0 17.4 15.00 12.50
RFCX24BP 17.5 – 740 22.2 16.0 13.25 11.35
RHP14J304S21 RFCX36CE 21.0 – 1000 30.0 21.7 15.00 12.50
RFCX36BP 17.5 – 1060 28.8 22.0 13.25 11.35
RHP14J364S21
RFCX36CE 21.0 – 1275 36.0 27.4 14.50 12.00
RFCX42DE 24.5 – 1275 36.0 26.4 15.00 12.50
RFCX48DE 24.5 – 1195 35.8 26.6 14.50 12.00
RFCX36BP 17.5 – 1245 35.4 26.2 13.00 11.00
RFCX42CP 21.0 – 1230 35.6 26.4 13.35 11.45
RHP14J424S21 RFCX48DE 24.5 – 1125 39.5 27.0 15.00 12.50 RFCX60DE 24.5 – 1350 39.0 28.8 14.50 12.00
RFCX48DP 24.5 – 1320 39.5 28.4 13.25 11.35
RHP14J484S21 RFCX48DE 24.5 – 1295 45.5 30.8 14.00 12.00 RFCX60DE 24.5 – 1310 47.0 31.6 15.00 12.50
RFCX48DP 24.5 – 1320 44.5 30.2 13.25 11.35
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80 °F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95 °F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
STAGE
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
14.5 SEER HP WITH AIR HANDLERS
RHP14J604S21 RFCX60DE 24.5 – 1 1160 46.0 29.8 15.00 12.20
2 1835 57.0 41.0
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80 °F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95 °F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.

810754-UTG-C-0214
Johnson Controls Unitary Products 5
MA Modular Air Handlers use Coil Only Ratings.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(Min.-max.) STAGE
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER1EER
TOTAL SENS.
14.5 SEER HP COIL ONLY RATINGS
RHP14J184S21
FC/MC/PC32 14.5 450 - 750 – 600 18.0 12.6 13.25 11.35
FC/MC/PC35 17.5,21.0 450 - 750 – 600 18.0 12.6 13.20 11.35
FC/MC/PC37 14.5 450 - 750 – 600 18.0 13.2 13.25 11.35
FC/MC/PC43 17.5,21.0 450 - 750 – 600 18.0 13.2 13.25 11.35
RHP14J244S21
FC/MC/PC32 14.5 600 - 1000 – 800 22.2 16.3 13.25 11.35
FC/MC/PC35 17.5,21.0 600 - 1000 – 800 22.4 16.3 13.20 11.35
FC/MC/PC37 14.5 600 - 1000 – 800 22.4 16.6 13.25 11.35
FC/MC/PC43 17.5,21.0 600 - 1000 – 800 22.4 16.6 13.25 11.35
RHP14J304S21 FC/MC/PC37 14.5 800 - 1200 – 1000 28.6 21.6 13.25 11.35
FC/MC/PC43 17.5,21.0 800 - 1200 – 1000 28.4 21.6 13.50 11.35
RHP14J364S21
FC/MC/PC37 14.5 1000 - 1400 – 1200 35.0 25.6 13.00 11.00
FC/MC/PC43 17.5,21.0 1000 - 1400 – 1200 35.0 25.8 13.00 11.00
FC/MC/PC48 21.0,24.5 1000 - 1400 – 1200 35.2 25.8 13.35 11.45
FC/MC/PC60 21.0,24.5 1000 - 1400 – 1200 35.6 26.0 13.35 11.45
UC48 21.0,24.5 1000 - 1400 – 1200 35.0 26.0 13.25 11.35
UC60 21.0,24.5 1000 - 1400 – 1200 35.0 25.6 13.25 11.35
RHP14J424S21 FC/MC/PC60 21.0,24.5 1200 - 1600 – 1200 39.0 27.0 13.25 11.35
FC/MC62 24.5 1200 - 1600 – 1400 38.0 27.8 13.00 11.00
RHP14J484S21 FC/MC/PC60 21.0, 24.5 1400 - 1800 – 1400 45.5 31.6 13.25 11.35 FC/MC62 24.5 1400 - 1800 – 1600 48.0 34.2 14.00 12.00
FC64 24.5 1400 - 1800 – 1400 48.0 32.0 14.00 12.00
RHP14J604S21 FC/MC62 24.5 1150 - 1550 1 1350 48.0 31.8 13.30 11.35
FC/MC62 24.5 1600 - 2000 2 1800 56.5 39.5 13.30 11.35
1. Requires a S1-2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
COOLING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL
FURNACE COIL1
MODEL
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
14.5 SEER HP WITH HIGH EFFICIENCY MOTOR FURNACES2
RHP14J184S21 RGF19*AE10 14.5 FC/MC/PC32A 600 18.0 13.5 14.50 12.50
RGF19*AE10 14.5 FC/MC/PC37A 600 18.0 13.4 13.50 11.35
RHP14J244S21
RGF19*AE10 14.5 FC/MC/PC32A 775 22.2 16.5 13.25 11.35
RGF19*AE10 14.5 FC/MC/PC37A 800 22.4 16.8 13.50 11.35
RGF19*BE12 17.5 FC/MC/PC35B 800 22.4 16.7 13.70 11.35
RGF19*BE12 17.5 FC/MC/PC43B 800 22.6 16.9 14.00 12.00
RGF19*CE16 21.0 FC/MC/PC35C 800 22.4 16.6 13.50 11.35
RGF19*CE16 21.0 FC/MC/PC43C 800 22.6 16.8 13.50 11.35
RGF19*CE20 21.0 FC/MC/PC35C 800 22.6 16.7 14.20 12.00
RGF19*CE20 21.0 FC/MC/PC43C 800 22.8 17.0 14.20 12.00
RHP14J304S21 RGF19*BE12 17.5 FC/MC/PC43B 975 29.0 21.6 15.10 12.50
RGF19*CE16 21.0 FC/MC/PC43C 1000 29.0 21.6 15.10 12.50
For notes see Page 6.

810754-UTG-C-0214
6Johnson Controls Unitary Products
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
RHP14J364S21
RGF19*BE12 17.5 FC/MC/PC43B 1125 35.8 25.4 13.25 11.35
RGF19*CE16 21.0 FC/MC/PC43C 1175 36.0 25.4 13.70 11.35
RGF19*CE16 21.0 FC/MC/PC48C 1150 36.0 25.6 14.50 12.00
RGF19*CE16 21.0 FC/PC60C 1175 35.8 25.4 14.50 12.00
RGF19*CE16 21.0 UC48C 1150 36.0 25.6 14.50 12.00
RGF19*CE16 21.0 UC60C 1175 35.6 25.4 14.20 12.00
RGF19*CE20 21.0 FC/MC/PC43C 1150 36.0 25.6 13.70 11.35
RGF19*CE20 21.0 FC/MC/PC48C 1150 36.0 25.6 14.50 12.00
RGF19*CE20 21.0 FC/PC60C 1150 35.8 25.4 14.50 12.00
RGF19*CE20 21.0 UC48C 1150 36.0 25.6 14.50 12.00
RGF19*CE20 21.0 UC60C 1150 35.6 25.4 14.50 12.00
RGF19*DE20 24.5 FC/MC/PC48D 1175 36.0 25.8 14.50 12.00
RGF19*DE20 24.5 FC/MC/PC60D 1175 36.0 25.4 14.50 12.00
RGF19*DE20 24.5 UC48D 1175 36.0 25.8 14.50 12.00
RGF19*DE20 24.5 UC60D 1175 35.6 25.4 14.50 12.00
RHP14J424S21
RGF19*CE16 21.0 FC/MC62D 1400 38.5 28.0 13.15 11.00
RGF19*CE16 21.0 FC/PC60C 1400 39.5 28.6 13.50 11.35
RGF19*CE20 21.0 FC/MC62D 1350 39.0 28.4 13.70 11.35
RGF19*DE20 24.5 FC/MC/PC60D 1325 40.0 29.0 14.20 12.00
RGF19*DE20 24.5 FC/MC62D 1325 39.0 28.4 13.70 11.35
RGF19*DE20 24.5 UC60D 1325 37.2 27.8 13.25 11.35
RHP14J484S21
RGF19*CE16 21.0 FC/MC62D 1400 47.0 32.2 14.20 12.00
RGF19*CE16 21.0 FC/PC60C 1400 45.0 30.8 13.50 11.35
RGF19*CE16 21.0 FC64D 1400 48.0 32.6 14.50 12.50
RGF19*CE20 21.0 FC/MC62D 1350 47.5 32.4 15.00 12.50
RGF19*CE20 21.0 FC64D 1350 48.0 33.0 15.10 12.50
RGF19*DE20 24.5 FC/MC/PC60D 1325 45.5 31.2 14.20 12.00
RGF19*DE20 24.5 FC/MC62D 1325 47.5 32.4 15.00 12.50
RGF19*DE20 24.5 FC64D 1325 48.0 33.0 15.10 12.50
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. High Efficiency Motor Furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL
FURNACE COIL1
MODEL
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
STAGE
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
14.5 SEER HP WITH HIGH EFFICIENCY MOTOR FURNACES2
2. High Efficiency Motor Furnaces have B.O.D (Blower on Delay) standard.
RHP14J604S21
RGF19*CE20 21.0 FC/MC62D 11085 46.0 29.4 14.20 11.80
21550 55.5 38.0
RGF19*CE20 21.0 FC64D 11085 48.0 30.6 14.50 12.00
21550 57.0 39.0
RGF19*DE20 24.5 FC/MC62D 11085 46.0 29.4 14.20 12.00
21550 56.0 38.0
RGF19*DE20 24.5 FC64D 11070 48.0 30.6 14.50 12.00
2 1525 57.0 39.0
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL
FURNACE COIL1
MODEL
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
14.5 SEER HP WITH HIGH EFFICIENCY MOTOR FURNACES2

810754-UTG-C-0214
Johnson Controls Unitary Products 7
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
— = Not Applicable.
MA Modular Air Handlers use Coil Only Ratings.
* Notates “Hot Heat Pump” performance. These ratings are not AHRI Listed.
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
— = Not Applicable.
MA Modular Air Handlers use Coil Only Ratings.
HEATING CAPACITY - With Air Handler Coils
UNIT
MODEL* AIR HANDLER COIL1
MODEL
1. Rated CFM same as for cooling.
HEATING2
2. Heating MBH based on AHRI standards of 70 °F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.
47F17F HSPF
MBH COP KW MBH COP KW STD
14.5 SEER HP WITH AIR HANDLERS
RHP14J184S21 RFCX24BE – 18.0 3.82 1.38 11.0 2.50 1.29 8.20 RFCX30BE – 18.0 3.88 1.36 10.9 2.54 1.26 8.50
RFCX24BP – 18.0 3.56 1.52 11.4 2.34 1.43 7.75
RHP14J244S21 RFCX24BE – 22.2 3.68 1.77 13.7 2.44 1.65 8.50 RFCX30BE – 22.2 3.68 1.77 13.7 2.44 1.65 8.50
RFCX24BP – 22.4 3.42 1.92 13.9 2.30 1.77 7.75
RHP14J304S21 RFCX36CE – 30.0 4.08 2.15 20.4 2.62 2.28 9.00
RFCX36BP – 30.0 3.76 2.42 19.4 2.50 2.27 7.75
RHP14J364S21
RFCX36CE – 34.6 3.80 2.67 20.2 2.80 2.11 8.50
RFCX42DE – 34.6 3.80 2.67 20.2 2.80 2.11 9.00
RFCX48DE – 33.8 3.74 2.65 19.8 2.78 2.09 8.50
RFCX36BP – 35.0 3.52 2.91 20.8 2.58 2.36 8.20
RFCX42CP – 34.8 3.56 2.86 20.8 2.62 2.33 8.20
RHP14J424S21 RFCX48DE – 39.5 3.70 3.13 25.4 2.66 2.80 9.00 RFCX60DE – 39.0 3.78 3.02 25.4 2.68 2.78 8.50
RFCX48DP – 40.5 3.52 3.37 26.4 2.50 3.09 8.50
RHP14J484S21 RFCX48DE – 47.0 3.44 4.00 28.8 2.44 3.46 8.20 RFCX60DE – 47.0 3.72 3.70 30.4 2.62 3.40 9.00
RFCX48DP – 48.0 3.22 4.37 29.6 2.26 3.84 7.80
HEATING CAPACITY - With Air Handler Coils
UNIT
MODEL AIR HANDLER COIL1
MODEL
HEATING2
STAGE RATED
CFM NET MBH HSPF COP @ 47
47 OD 17 OD
14.5 SEER HP WITH AIR HANDLERS
RHP14J604S21 RFCX60DE – 1116043.0– –3.36 2 1835 58.0 40.0 9.00 3.70
2* 1160 55.0 39.5 8.85 3.00
1. Rated CFM same as for cooling.
2. Heating MBH based on AHRI standards of 70 °F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.

810754-UTG-C-0214
8Johnson Controls Unitary Products
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
MA Modular Air Handlers use Coil Only Ratings.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
— = Not Applicable.
* Notates “Hot Heat Pump” performance. These ratings are not AHRI Listed.
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
MA Modular Air Handlers use Coil Only Ratings.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
— = Not Applicable.
HEATING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT
MODEL* COIL1
MODEL
HEATING2
47 F 17 FHSPF
MBH COP KW MBH COP KW STD
14.5 SEER HP COIL ONLY RATINGS
RHP14J184S21
FC/MC/PC32 18.0 3.56 1.52 11.4 2.34 1.43 7.75
FC/MC/PC35 18.0 3.52 1.56 11.3 2.34 1.45 7.70
FC/MC/PC37 18.0 3.62 1.50 11.3 2.40 1.38 7.75
FC/MC/PC43 18.0 3.62 1.50 11.3 2.40 1.38 7.75
RHP14J244S21
FC/MC/PC32 22.83.401.9614.22.261.847.75
FC/MC/PC35 22.63.381.9915.42.261.867.70
FC/MC/PC37 22.83.401.9614.22.261.847.75
FC/MC/PC43 22.83.401.9614.22.261.847.75
RHP14J304S21 FC/MC/PC37 30.03.722.4319.32.482.288.00
FC/MC/PC43 30.03.702.4319.42.582.228.00
RHP14J364S21
FC/MC/PC37 35.03.522.9120.82.582.368.20
FC/MC/PC43 35.03.522.9120.82.582.368.20
FC/MC/PC48 34.83.522.9020.82.602.348.20
FC/MC/PC60 35.43.642.8521.22.662.348.20
UC48 36.03.702.8521.42.662.367.80
UC60 36.03.682.8720.82.602.347.80
RHP14J424S21 FC/MC/PC60 40.53.523.3726.02.523.028.50
FC/MC62 40.03.543.3126.22.523.058.50
RHP14J484S21 FC/MC/PC60 48.03.444.0929.62.383.647.80 FC/MC62 48.03.763.7431.42.583.578.20
FC64 48.03.763.7431.62.603.568.20
1. Rated CFM same as for cooling.
2. Heating MBH based on AHRI standards of 70 °F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.
HEATING CAPACITY - With Upflow, Downflow, & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT
MODEL* COIL1
MODEL
1. Rated CFM same as for cooling.
HEATING2
2. Heating MBH based on AHRI standards of 70° DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.
STAGE RATED
CFM NET MBH HSPF COP @ 47
47 OD 17 OD
14.5 SEER HP COIL ONLY RATINGS
RHP14J604S21 FC/MC62 1 1350 43.5 – – 3.42 2 1800 60 40.5 8.4 3.58
2* 1350 57 40.0 8.6 3.36

810754-UTG-C-0214
Johnson Controls Unitary Products 9
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
— = Not Applicable.
HEATING CAPACITY - With High Efficiency Motor Furnaces
MODEL FURNACE
MODEL COIL1
MODEL
HEATING2
47F17F HSPF
MBH COP KW MBH COP KW STD
14.5 SEER HP WITH HIGH EFFICIENCY MOTOR FURNACES3
RHP14J184S21 RGF19*AE10 FC/MC/PC32A 18.0 3.78 1.40 11.0 2.50 1.29 8.50
RGF19*AE10 FC/MC/PC37A 18.0 3.66 1.47 11.2 2.44 1.34 7.75
RHP14J244S21
RGF19*AE10 FC/MC/PC32A 22.6 3.46 1.91 14.0 2.30 1.78 7.75
RGF19*AE10 FC/MC/PC37A 22.6 3.54 1.87 14.0 2.36 1.74 7.75
RGF19*BE12 FC/MC/PC35B 22.4 3.52 1.86 13.9 2.34 1.74 7.75
RGF19*BE12 FC/MC/PC43B 22.4 3.60 1.82 13.8 2.40 1.68 8.20
RGF19*CE16 FC/MC/PC35C 22.6 3.46 1.91 14.0 2.32 1.77 7.75
RGF19*CE16 FC/MC/PC43C 22.6 3.54 1.87 14.0 2.36 1.74 7.75
RGF19*CE20 FC/MC/PC35C 22.4 3.58 1.83 13.8 2.38 1.70 8.05
RGF19*CE20 FC/MC/PC43C 22.4 3.66 1.79 13.8 2.42 1.67 8.05
RHP14J304S21 RGF19*BE12 FC/MC/PC43B 30.0 3.92 2.26 34.6 5.16 1.96 9.00
RGF19*CE16 FC/MC/PC43C 30.0 3.90 2.27 34.8 5.16 1.98 9.00
RHP14J364S21
RGF19*BE12 FC/MC/PC43B 34.6 3.66 2.77 19.4 2.56 2.22 7.75
RGF19*CE16 FC/MC/PC43C 34.4 3.72 2.71 19.2 2.62 2.15 7.75
RGF19*CE16 FC/MC/PC48C 34.4 3.66 2.75 20.4 2.72 2.20 8.20
RGF19*CE16 FC/PC60C 34.2 3.66 2.74 20.2 2.70 2.19 8.20
RGF19*CE16 UC48C 34.6 3.70 2.74 20.6 2.74 2.20 8.20
RGF19*CE16 UC60C 34.0 3.62 2.75 18.8 2.52 2.19 8.50
RGF19*CE20 FC/MC/PC43C 34.4 3.74 2.69 19.2 2.62 2.15 7.75
RGF19*CE20 FC/MC/PC48C 34.4 3.68 2.74 20.4 2.72 2.20 8.20
RGF19*CE20 FC/PC60C 34.2 3.66 2.74 20.2 2.72 2.18 8.20
RGF19*CE20 UC48C 34.6 3.72 2.73 20.6 2.74 2.20 8.20
RGF19*CE20 UC60C 34.0 3.62 2.75 18.8 2.52 2.19 8.20
RGF19*DE20 FC/MC/PC48D 34.2 3.70 2.71 20.2 2.74 2.16 8.20
RGF19*DE20 FC/MC/PC60D 34.2 3.68 2.72 20.2 2.72 2.18 8.20
RGF19*DE20 UC48D 34.4 3.74 2.69 20.4 2.78 2.15 8.20
RGF19*DE20 UC60D 34.0 3.64 2.74 18.8 2.54 2.17 8.20
RHP14J424S21
RGF19*CE16 FC/MC62D 40.0 3.58 3.27 26.2 2.54 3.02 7.70
RGF19*CE16 FC/PC60C 40.5 3.52 3.37 26.4 2.46 3.14 7.75
RGF19*CE20 FC/MC62D 39.5 3.70 3.13 25.8 2.60 2.91 7.75
RGF19*DE20 FC/MC/PC60D 40.0 3.64 3.22 25.8 2.54 2.98 8.50
RGF19*DE20 FC/MC62D 39.5 3.70 3.13 25.8 2.62 2.89 7.75
RGF19*DE20 UC60D 39.0 3.48 3.28 25.4 2.44 3.05 7.75
RHP14J484S21
RGF19*CE16 FC/MC62D 48.0 3.66 3.88 31.4 2.54 3.62 8.50
RGF19*CE16 FC/PC60C 48.0 3.24 4.39 29.8 2.26 3.86 7.75
RGF19*CE16 FC64D 48.0 3.72 3.94 31.4 2.58 3.57 8.50
RGF19*CE20 FC/MC62D 48.0 3.74 3.76 31.0 2.60 3.49 8.50
RGF19*CE20 FC64D 48.0 3.82 3.80 31.0 2.66 3.41 9.00
RGF19*DE20 FC/MC/PC60D 48.0 3.34 4.21 29.4 2.32 3.71 8.05
RGF19*DE20 FC/MC62D 48.0 3.76 3.74 31.0 2.60 3.49 9.00
RGF19*DE20 FC64D 48.0 3.84 3.78 31.0 2.66 3.41 9.00
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Heating MBH based on AHRI standards of 70 °F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.
3. High Efficiency Motor Furnaces have B.O.D (Blower on Delay) standard.

810754-UTG-C-0214
10 Johnson Controls Unitary Products
* Notates “Hot Heat Pump” performance. These ratings are not AHRI Listed.
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
— = Not Applicable.
ACCESSORIES
Refer to Price Manual for specific model numbers.
Start Assist Kit - Provides increased starting torque for areas
with low voltage. See Hard Start Kit Accessory Installation
Manual for Hard Start Kit part number for each model.
Blower Time Delay - Available to increase efficiency when
installed. Installs on indoor section and maintains blower for
approximately one minute after cooling thermostat has been
satisfied.
Low Temperature Cutout (S1-2LT06700224) - Prevents heat
pump operation below -10°F ambient temperature.
TXV Kits - S1-1TVM series thermal expansion valves precisely
meter refrigerant for optimum performance over a wide range of
conditions. See System Charge table for TXV part number for
each model.
Outdoor Thermostat (S1-2TD06700124) - Provides additional
staging of supplemental electric heat.
Thermostats - Compatible thermostat controls are available
through accessory sourcing. For optimum performance and
installation, refer to the UPGNET “Low Voltage Wiring Diagram”
document to select and apply controls.
SOUND LEVEL - TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
Rated in accordance with ARI Standard 270.
HEATING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL FURNACE
MODEL COIL1
MODEL
HEATING2
STAGE RATED
CFM NET MBH HSPF COP @ 47
47 OD 17 OD
14.5 SEER HP WITH HIGH EFFICIENCY MOTOR FURNACES3
RHP14J604S21
RGF19*CE20 FC/MC62D 1 1085 43.0 – – 3.20
21550 58.0 40.0 8.50 3.50
2* 1085 57.5 38.5 8.45 3.22
RGF19*CE20 FC64D 11085 43.5 – – 3.30 21550 58.0 40.0 8.20 3.60
2* 1085 57.5 39.0 8.15 3.32
RGF19*DE20 FC/MC62D 11085 43.0 – – 3.20 21550 58.0 40.0 8.50 3.50
2* 1085 57.5 38.5 8.45 3.22
RGF19*DE20 FC64D 11070 43.5 – – 3.32
21525 58.0 40.0 8.20 3.60
2* 1070 57.5 38.5 8.15 3.32
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Heating MBH based on AHRI standards of 70 °F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.
3. High Efficiency Motor Furnaces have B.O.D (Blower on Delay) standard.
Size Test Condition 63 125 250 500 1000 2000 4000 8000 dBA SQI
18 Cooling Mode 67 71 67 69 65 59 58 55 70 19.2
Heating Mode 68 70 66 68 67 61 60 57 71 19.2
24 Cooling Mode 69 73 64 67 68 64 61 57 71 19.0
Heating Mode 71 72 65 70 65 64 62 58 73 19.0
30 Cooling Mode 72 70 68 67 67 63 59 55 71 19.0
Heating Mode 74 72 73 68 70 64 61 57 74 19.0
36 Cooling Mode 73 70 72 70 68 63 60 57 73 19.1
Heating Mode 75 73 71 70 70 65 63 61 74 19.1
42 Cooling Mode 71 69 65 68 69 66 63 57 73 19.1
Heating Mode 70 69 68 69 69 65 62 60 73 19.0
48 Cooling Mode 70 73 69 70 70 64 59 57 73 19.1
Heating Mode 70 73 70 71 72 64 62 60 75 19.0
60 Cooling Mode - High Stage 73 70 69 72 75 65 62 59 77 19.1
Heating Mode - High Stage 74 75 72 73 76 68 66 63 79 19.0

810754-UTG-C-0214
Johnson Controls Unitary Products 11
TYPICAL INSTALLATION
TYPICAL FIELD WIRING
60” OVERHEAD
CLEARANCE
MINIMUM 18” SERVICE
ACCESS CLEARANCE
ON ONE SIDE
WEATHERPROOF
DISCONNECT
SWITCH
THERMOSTAT
10” CLEARANCE
AROUND PERIMETER
CONTROL
ACCESS
PANEL
TO INDOOR COIL
NEC CLASS 1 WIRING
NEC CLASS 2 WIRING
TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
NOTES:
ALL OUTDOOR WIRING MUST BE WEATHERPROOF.
MINIMUM 24” UNIT TO UNIT CLEARANCE.
THERMOSTAT INDOOR UNIT
OUTDOOR UNIT
LOW VOLTAGE TERMINAL BLOCK
IN AIR HANDLER WITH ELECTRIC HEAT
DEFROST
CONTROL
FIELD
INSTALLED
JUMPER
DEHUMIDIFICATION CONTROL CONNECTION
(Humidistat* Jumper must be removed)
GND.
SCREW
CONTACTOR
T2 T1
L2 L1
M
R
L or X
Y
O
W
G
T2
E2
RR
YY
O
O
W2 W
CC
X/L
G
W1
BK
GND.
LUG
CIRCUIT
BREAKER***
POWER WIRING
24V CONTROL WIRING
(NEC CLASS 2)
JUMPER TERMINALS E AND W TO HEAT
ON FIRST STAGE DURING EMERGENCY HEAT.
TERMINAL NOT USED ON ALL THERMOSTATS. POWER WIRING
208/230-1-60
230-1-50
CHECK THE LOW VOLTAGE TERMINAL BLOCK ON THE INDOOR UNIT FOR THE ACTUAL ARRANGEMENT OF THE TERMINALS.
CONNECT POWER WIRING TO TERMINAL BLOCK 3TB ON UNITS WITHOUT ELECTRIC HEAT OR CIRCUIT BREAKER.
B or C
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
RED
BLK
YEL
ORG
WHT
PUR
BRN
1
2
3
4
1
3,4
W1/66

810754-UTG-C-0214
12 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J184S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 400 600 800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 17.2 18.8 18.8 20.5 22.2 19.2 19.9 20.1 21.7 22.9 21.2 20.9 21.3 22.8 23.6
S.C. 16.8 14.9 12.9 12.9 11.0 18.8 17.7 15.2 14.7 11.7 20.8 20.5 17.4 16.5 12.5
KW 0.86 0.89 0.89 0.88 0.88 0.94 0.96 0.96 0.95 0.95 1.02 1.02 1.02 1.02 1.02
75 T.C. 16.4 17.9 17.9 19.7 21.3 18.4 19.1 19.0 20.8 22.1 20.4 20.2 20.2 21.8 22.9
S.C. 16.1 14.5 12.5 12.5 10.5 18.0 17.1 14.8 14.4 11.5 20.0 19.8 17.0 16.3 12.4
KW 0.99 1.02 1.02 1.02 1.02 1.08 1.09 1.09 1.09 1.10 1.17 1.16 1.17 1.17 1.18
85 T.C. 15.7 17.0 17.0 18.9 20.4 17.7 18.3 18.0 19.9 21.3 19.6 19.5 19.1 20.8 22.1
S.C. 15.4 14.1 12.1 12.1 10.1 17.3 16.6 14.3 14.2 11.2 19.2 19.1 16.6 16.2 12.2
KW 1.12 1.14 1.14 1.15 1.17 1.22 1.23 1.22 1.24 1.25 1.31 1.31 1.31 1.32 1.33
95 T.C. 15.0 16.1 16.1 18.1 19.6 16.9 17.4 17.0 19.0 20.4 18.8 18.8 18.0 19.8 21.3
S.C. 14.7 13.7 11.6 11.8 9.7 16.5 16.0 13.9 13.9 10.9 18.4 18.4 16.2 16.0 12.1
KW 1.25 1.26 1.26 1.29 1.31 1.36 1.36 1.36 1.38 1.40 1.46 1.46 1.45 1.46 1.49
105 T.C. 14.0 14.7 14.8 16.7 18.4 15.9 16.2 15.7 17.6 19.2 17.7 17.7 16.6 18.5 20.1
S.C. 13.7 13.1 11.0 11.2 9.2 15.5 15.2 13.3 13.4 10.4 17.3 17.3 15.6 15.6 11.6
KW 1.41 1.42 1.42 1.45 1.48 1.52 1.52 1.51 1.54 1.57 1.63 1.63 1.61 1.63 1.65
115 T.C. 13.1 13.4 13.4 15.4 17.2 14.8 15.0 14.4 16.2 18.0 16.6 16.6 15.3 17.1 18.8
S.C. 12.8 12.5 10.5 10.6 8.7 14.5 14.4 12.7 12.9 9.9 16.2 16.2 15.0 15.1 11.2
KW 1.56 1.57 1.57 1.60 1.65 1.68 1.68 1.67 1.70 1.74 1.80 1.80 1.77 1.80 1.82
125 T.C. 12.2 12.1 12.1 14.0 16.1 13.8 13.8 13.0 14.9 16.8 15.5 15.5 14.0 15.7 17.5
S.C. 11.9 11.9 9.9 10.1 8.2 13.5 13.5 12.1 12.3 9.5 15.1 15.1 14.0 14.6 10.7
KW 1.72 1.72 1.72 1.76 1.82 1.84 1.84 1.82 1.87 1.90 1.97 1.97 1.92 1.97 1.99
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC/PC32 0.96 0.94 1.11
– FC/MC/PC35 0.96 0.94 1.11
– FC/MC/PC37 0.96 0.95 1.11
– FC/MC/PC43 0.96 0.95 1.11
RFCX24BE – 0.98 0.96 1.00
RFCX30BE – 0.98 0.96 1.01
RFCX24BP – 0.96 0.94 1.11
Furnace Coil T.C. S.C. KW
RGF19*AE10 FC/MC/PC32A 0.98 0.97 1.03
RGF19*AE10 FC/MC/PC37A 0.99 0.98 1.03

810754-UTG-C-0214
Johnson Controls Unitary Products 13
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J244S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 21.7 23.6 23.5 25.2 26.6 23.4 24.1 24.3 26.0 27.2 25.1 24.6 25.1 26.9 27.8 S.C. 21.4 19.4 16.6 16.2 13.7 23.1 21.8 18.5 17.9 14.3 24.8 24.3 20.5 19.5 15.0
KW 1.20 1.22 1.22 1.23 1.21 1.28 1.29 1.31 1.29 1.28 1.36 1.35 1.39 1.35 1.35
75 T.C. 20.8 22.3 22.2 24.0 25.7 22.4 23.0 23.0 24.8 26.3 24.1 23.8 23.8 25.7 26.9 S.C. 20.5 18.8 16.0 15.7 13.1 22.1 21.1 18.0 17.5 13.9 23.8 23.5 19.9 19.2 14.6
KW 1.36 1.37 1.37 1.38 1.39 1.45 1.45 1.45 1.46 1.47 1.53 1.53 1.53 1.53 1.54
85 T.C. 19.8 20.9 20.9 22.9 24.8 21.4 21.9 21.6 23.7 25.5 23.1 22.9 22.4 24.5 26.1 S.C. 19.5 18.2 15.4 15.3 12.5 21.2 20.4 17.4 17.1 13.4 22.8 22.6 19.4 18.9 14.3
KW 1.52 1.53 1.53 1.54 1.57 1.61 1.61 1.59 1.62 1.65 1.70 1.70 1.66 1.71 1.73
95 T.C. 18.8 19.5 19.6 21.8 23.9 20.5 20.8 20.3 22.5 24.6 22.1 22.1 21.1 23.2 25.3 S.C. 18.6 17.5 14.8 14.8 11.9 20.2 19.7 16.8 16.7 12.9 21.8 21.8 18.8 18.7 14.0
KW 1.67 1.68 1.68 1.69 1.75 1.77 1.78 1.74 1.79 1.83 1.87 1.87 1.79 1.89 1.92
105 T.C. 17.7 18.0 18.0 20.2 22.4 19.2 19.3 18.7 20.9 23.1 20.7 20.7 19.4 21.6 23.7 S.C. 17.4 16.8 14.1 14.2 11.3 18.9 18.7 16.1 16.1 12.4 20.5 20.5 18.2 18.1 13.5
KW 1.86 1.87 1.87 1.90 1.96 1.97 1.97 1.94 2.00 2.04 2.07 2.07 2.02 2.09 2.12
115 T.C. 16.5 16.4 16.4 18.7 20.9 17.9 17.9 17.0 19.3 21.6 19.4 19.4 17.7 20.0 22.2 S.C. 16.3 16.1 13.4 13.5 10.8 17.7 17.6 15.4 15.5 11.9 19.2 19.2 17.5 17.5 13.0
KW 2.05 2.05 2.05 2.11 2.16 2.16 2.16 2.15 2.21 2.24 2.26 2.26 2.24 2.30 2.32
125 T.C. 15.3 14.8 14.8 17.1 19.4 16.7 16.4 15.4 17.7 20.0 18.1 18.1 16.1 18.3 20.6 S.C. 15.1 14.8 12.7 12.9 10.2 16.5 16.4 14.7 14.9 11.3 17.8 17.8 16.1 16.9 12.5
KW 2.25 2.24 2.24 2.33 2.37 2.35 2.35 2.35 2.42 2.45 2.46 2.46 2.46 2.51 2.52
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC/PC32 0.99 0.98 1.09
– FC/MC/PC35 0.99 0.98 1.09
– FC/MC/PC37 1.00 0.99 1.09
– FC/MC/PC43 1.00 0.99 1.09
RFCX24BE – 1.00 1.01 1.00
RFCX30BE – 1.00 1.01 1.00
RFCX24BP – 0.99 0.96 1.04
Furnace Coil T.C. S.C. KW
RGF19*AE10 FC/MC/PC32A 0.99 0.94 1.00
RGF19*AE10 FC/MC/PC37A 0.99 0.94 1.00
RGF19*BE12 FC/MC/PC35B 1.01 1.01 0.97
RGF19*BE12 FC/MC/PC43B 1.03 1.06 0.97
RGF19*CE16 FC/MC/PC35C 1.01 0.99 0.97
RGF19*CE16 FC/MC/PC43C 1.02 1.02 0.97
RGF19*CE20 FC/MC/PC35C 1.02 1.03 0.99
RGF19*CE20 FC/MC/PC43C 1.02 1.02 0.98

810754-UTG-C-0214
14 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J304S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 800 1000 1200
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 28.4 30.2 30.1 33.0 34.3 30.2 31.2 31.2 33.5 34.8 32.0 32.2 32.2 34.0 35.3 S.C. 28.4 26.3 22.5 22.3 18.2 30.2 29.6 24.6 23.7 18.7 32.0 32.2 26.8 25.1 19.1
KW 1.49 1.53 1.53 1.55 1.52 1.60 1.63 1.63 1.60 1.59 1.70 1.74 1.74 1.65 1.66
75 T.C. 27.3 28.7 28.7 31.5 33.2 29.0 29.7 29.6 32.1 33.7 30.7 30.6 30.6 32.7 34.2 S.C. 27.3 25.7 21.8 21.6 17.7 29.0 28.4 23.9 23.2 18.2 30.7 30.6 26.1 24.8 18.7
KW 1.67 1.69 1.69 1.72 1.70 1.76 1.78 1.78 1.78 1.77 1.86 1.86 1.86 1.84 1.85
85 T.C. 26.2 27.2 27.2 30.0 32.2 27.8 28.1 28.1 30.7 32.6 29.5 29.0 29.0 31.4 33.1 S.C. 26.2 25.0 21.1 21.0 17.1 27.8 27.3 23.3 22.8 17.7 29.5 29.0 25.4 24.6 18.4
KW 1.84 1.86 1.86 1.88 1.88 1.93 1.92 1.92 1.95 1.96 2.03 1.99 1.99 2.02 2.03
95 T.C. 25.1 25.8 25.8 28.6 31.1 26.7 26.6 26.6 29.3 31.5 28.2 27.3 27.3 30.1 32.0 S.C. 25.1 24.4 20.4 20.4 16.5 26.7 26.1 22.6 22.4 17.3 28.2 27.3 24.7 24.4 18.1
KW 2.01 2.02 2.02 2.05 2.06 2.10 2.07 2.06 2.13 2.14 2.19 2.11 2.11 2.20 2.21
105 T.C. 23.7 23.8 23.9 26.9 29.5 25.2 25.1 24.6 27.6 29.9 26.7 26.3 25.4 28.2 30.3 S.C. 23.7 23.4 19.6 19.7 15.7 25.2 25.1 21.7 21.7 16.6 26.7 26.3 23.9 23.7 17.5
KW 2.22 2.23 2.23 2.27 2.30 2.31 2.29 2.29 2.35 2.37 2.40 2.36 2.36 2.43 2.44
115 T.C. 22.2 21.9 21.9 25.2 27.8 23.7 23.6 22.7 25.8 28.3 25.2 25.2 23.4 26.4 28.7 S.C. 22.2 21.9 18.7 19.0 15.0 23.7 23.6 20.9 21.0 16.0 25.2 25.2 23.1 23.0 17.0
KW 2.44 2.43 2.43 2.50 2.53 2.52 2.52 2.52 2.57 2.60 2.61 2.61 2.61 2.65 2.67
125 T.C. 20.8 19.9 20.0 23.5 26.2 22.2 22.1 20.7 24.0 26.7 23.7 24.2 21.5 24.5 27.1 S.C. 20.8 19.9 17.8 18.3 14.2 22.2 22.1 20.1 20.3 15.3 23.7 24.2 21.5 22.3 16.4
KW 2.65 2.64 2.64 2.72 2.76 2.74 2.75 2.75 2.80 2.83 2.82 2.86 2.85 2.88 2.90
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC/PC37 0.98 0.96 1.10
– FC/MC/PC43 0.98 0.96 1.10
RFCX36CE – 1.00 0.98 1.00
RFCX36BP – 0.98 0.98 1.11
Furnace Coil T.C. S.C. KW
RGF19*BE12 FC/MC/PC43B 0.99 0.98 1.02
RGF19*CE16 FC/MC/PC43C 0.99 0.96 1.02

810754-UTG-C-0214
Johnson Controls Unitary Products 15
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J364S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1000 1200 1400
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 37.2 39.5 39.5 43.2 45.5 39.3 41.1 41.0 44.1 46.4 41.4 42.7 42.5 45.1 47.3
S.C. 36.9 32.5 27.9 27.8 23.2 39.0 36.0 30.2 29.8 24.2 41.0 39.6 32.5 31.8 25.3
KW 2.11 2.18 2.18 2.19 2.19 2.22 2.27 2.26 2.27 2.30 2.32 2.36 2.34 2.35 2.40
75 T.C. 34.9 36.8 36.8 40.6 43.4 37.0 38.1 38.2 41.5 44.2 39.0 39.5 39.5 42.5 44.9
S.C. 34.7 31.3 26.7 26.6 22.0 36.7 34.3 28.9 28.7 23.1 38.7 37.3 31.2 30.7 24.2
KW 2.29 2.34 2.34 2.38 2.41 2.40 2.43 2.43 2.46 2.49 2.51 2.52 2.52 2.55 2.58
85 T.C. 32.7 34.0 34.1 38.0 41.3 34.7 35.2 35.3 39.0 41.9 36.7 36.3 36.4 39.9 42.4
S.C. 32.4 30.0 25.5 25.5 20.8 34.4 32.5 27.7 27.5 21.9 36.4 35.0 29.9 29.5 23.0
KW 2.47 2.50 2.50 2.56 2.62 2.58 2.59 2.60 2.66 2.69 2.70 2.67 2.69 2.75 2.75
95 T.C. 30.5 31.3 31.4 35.4 39.2 32.4 32.2 32.4 36.4 39.6 34.3 33.0 33.4 37.4 40.0
S.C. 30.2 28.8 24.3 24.3 19.6 32.2 30.8 26.4 26.4 20.7 34.1 32.8 28.5 28.4 21.9
KW 2.65 2.67 2.67 2.74 2.83 2.77 2.75 2.77 2.85 2.88 2.89 2.83 2.87 2.95 2.93
105 T.C. 27.5 28.4 28.2 32.2 36.2 29.6 29.7 28.9 33.1 36.8 31.7 31.0 29.5 34.0 37.4
S.C. 27.3 27.1 22.9 23.0 18.4 29.4 28.9 24.9 25.1 19.6 31.5 30.8 27.0 27.1 20.8
KW 2.80 2.81 2.80 2.92 3.01 2.92 2.90 2.91 3.02 3.09 3.03 2.99 3.02 3.13 3.16
115 T.C. 24.6 25.5 25.0 29.0 33.2 26.9 27.3 25.4 29.8 34.0 29.1 29.0 25.7 30.6 34.9
S.C. 24.4 25.3 21.5 21.7 17.3 26.6 27.1 23.5 23.8 18.5 28.9 28.8 25.4 25.8 19.7
KW 2.96 2.95 2.93 3.10 3.20 3.07 3.05 3.04 3.20 3.29 3.18 3.15 3.16 3.30 3.39
125 T.C. 21.7 22.6 21.8 25.8 30.1 24.1 24.8 21.9 26.5 31.2 26.5 27.0 21.9 27.2 32.3
S.C. 21.5 22.6 20.1 20.4 16.1 23.9 24.8 21.9 22.5 17.4 26.3 26.8 21.9 24.5 18.7
KW 3.11 3.09 3.06 3.28 3.38 3.22 3.20 3.18 3.38 3.50 3.33 3.31 3.31 3.48 3.61
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC/PC37 0.98 0.98 1.09
– FC/MC/PC43 0.98 0.98 1.09
– FC/MC/PC48 0.99 0.99 1.10
– FC/MC/PC60 1.00 0.99 1.09
– UC48 1.00 0.99 1.09
– UC60 0.98 0.97 1.09
RFCX36CE – 1.02 1.04 1.01
RFCX42DE – 1.00 1.00 1.00
RFCX48DE – 1.00 1.00 1.00
RFCX36BP – 1.00 0.99 1.10
RFCX42CP – 1.00 1.00 1.08
Furnace Coil T.C. S.C. KW
RGF19*BE12 FC/MC/PC43B 0.99 0.99 1.07
RGF19*CE16 FC/MC/PC43C 0.99 0.97 1.03
RGF19*CE16 FC/MC/PC48C 1.00 0.99 1.04
RGF19*CE16 FC/PC60C 0.99 0.97 1.04
RGF19*CE16 UC48C 1.00 0.99 1.04
RGF19*CE16 UC60C 0.98 0.97 1.04
RGF19*CE20 FC/MC/PC43C 1.00 0.99 1.03
RGF19*CE20 FC/MC/PC48C 1.00 0.99 1.04
RGF19*CE20 FC/PC60C 0.99 0.98 1.04
RGF19*CE20 UC48C 1.00 0.99 1.04
RGF19*CE20 UC60C 0.98 0.98 1.04
RGF19*DE20 FC/MC/PC48D 1.00 0.99 1.03
RGF19*DE20 FC/MC/PC60D 0.99 0.97 1.03
RGF19*DE20 UC48D 1.00 0.99 1.03
RGF19*DE20 UC60D 0.98 0.97 1.03

810754-UTG-C-0214
16 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J424S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1155 1355 1555
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 38.5 40.6 41.2 44.8 48.2 40.3 41.9 41.0 45.8 49.3 42.2 43.3 40.7 46.7 50.4 S.C. 38.5 35.5 30.5 30.2 24.7 40.3 39.2 32.0 32.1 25.8 42.2 42.9 33.6 33.9 26.8
KW 2.20 2.21 2.21 2.23 2.36 2.27 2.28 2.28 2.35 2.44 2.34 2.35 2.34 2.47 2.52
75 T.C. 36.9 38.6 39.0 42.8 46.3 38.7 39.7 39.1 43.7 47.3 40.6 40.8 39.2 44.6 48.3 S.C. 36.9 34.8 29.6 29.4 23.8 38.7 37.7 31.3 31.3 24.9 40.6 40.6 33.0 33.2 26.0
KW 2.48 2.49 2.49 2.53 2.62 2.57 2.57 2.57 2.64 2.71 2.65 2.65 2.64 2.74 2.80
85 T.C. 35.3 36.7 36.9 40.8 44.3 37.2 37.5 37.2 41.6 45.3 39.0 38.3 37.6 42.4 46.2 S.C. 35.3 34.0 28.6 28.6 23.0 37.2 36.2 30.5 30.5 24.1 39.0 38.3 32.5 32.4 25.1
KW 2.76 2.78 2.78 2.84 2.88 2.86 2.86 2.86 2.92 2.98 2.96 2.95 2.94 3.01 3.08
95 T.C. 33.7 34.8 34.7 38.8 42.3 35.6 35.3 35.4 39.6 43.2 37.4 35.8 36.1 40.3 44.1 S.C. 33.7 33.3 27.7 27.7 22.2 35.6 34.7 29.8 29.7 23.2 37.4 35.8 31.9 31.6 24.3
KW 3.04 3.06 3.06 3.14 3.14 3.15 3.16 3.15 3.21 3.25 3.26 3.25 3.24 3.29 3.36
105 T.C. 31.7 32.2 31.4 35.9 39.8 33.4 33.3 32.3 36.7 40.5 35.1 34.3 33.1 37.5 41.3 S.C. 31.7 31.6 26.3 26.6 21.1 33.4 33.1 28.5 28.6 22.2 35.1 34.3 30.7 30.6 23.3
KW 3.35 3.36 3.37 3.40 3.47 3.46 3.46 3.46 3.50 3.57 3.58 3.55 3.54 3.60 3.67
115 T.C. 29.7 29.7 28.2 33.0 37.2 31.2 31.2 29.2 33.8 37.8 32.7 32.7 30.2 34.7 38.5 S.C. 29.7 29.7 24.9 25.4 20.1 31.2 31.2 27.2 27.5 21.2 32.7 32.7 29.5 29.6 22.3
KW 3.66 3.67 3.69 3.66 3.80 3.78 3.75 3.76 3.79 3.89 3.89 3.84 3.83 3.92 3.98
125 T.C. 27.6 27.1 25.0 30.1 34.6 29.0 29.2 26.1 31.0 35.1 30.4 31.2 27.2 31.9 35.6 S.C. 27.6 27.1 23.6 24.3 19.1 29.0 29.2 25.9 26.4 20.2 30.4 31.2 27.2 28.6 21.4
KW 3.97 3.97 4.01 3.92 4.13 4.09 4.05 4.07 4.08 4.21 4.21 4.13 4.13 4.23 4.29
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC62 0.97 0.93 1.07
– FC/MC/PC60 1.02 1.00 1.08
RFCX48DE – 1.03 1.00 1.01
RFCX60DE – 1.00 1.00 1.00
RFCX48DP – 1.02 0.98 1.06
Furnace Coil T.C. S.C. KW
RGF19*CE16 FC/MC62D 0.98 0.94 1.07
RGF19*CE16 FC/PC60C 1.01 0.96 1.07
RGF19*CE20 FC/MC62D 1.00 0.97 1.04
RGF19*DE20 FC/MC/PC60D 1.03 1.00 1.03
RGF19*DE20 FC/MC62D 1.00 0.98 1.04
RGF19*DE20 UC60D 0.96 0.96 1.01

810754-UTG-C-0214
Johnson Controls Unitary Products 17
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J484S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1400 1600 1800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 46.3 48.5 48.5 53.1 57.3 48.0 50.1 49.9 53.5 58.0 49.8 51.6 51.4 53.9 58.7
S.C. 46.3 42.2 35.8 35.4 29.2 48.0 45.7 38.1 36.7 29.9 49.8 49.3 40.4 38.0 30.6
KW 2.67 2.73 2.72 2.76 2.74 2.77 2.80 2.80 2.81 2.80 2.87 2.87 2.87 2.86 2.87
75 T.C. 44.4 46.1 46.1 50.7 55.0 46.2 47.4 47.3 51.3 55.8 48.0 48.7 48.5 51.8 56.5
S.C. 44.4 41.2 34.8 34.4 28.2 46.2 44.2 37.0 36.0 29.0 48.0 47.1 39.2 37.5 29.8
KW 3.00 3.04 3.04 3.05 3.09 3.10 3.12 3.12 3.13 3.16 3.20 3.20 3.20 3.21 3.23
85 T.C. 42.4 43.6 43.6 48.3 52.7 44.3 44.7 44.7 49.0 53.5 46.2 45.7 45.7 49.8 54.3
S.C. 42.4 40.2 33.7 33.5 27.1 44.3 42.6 35.8 35.3 28.0 46.2 45.0 38.0 37.0 29.0
KW 3.33 3.35 3.35 3.34 3.44 3.43 3.44 3.44 3.45 3.52 3.54 3.53 3.53 3.56 3.60
95 T.C. 40.5 41.1 41.2 45.9 50.5 42.5 42.0 42.0 46.8 51.3 44.4 42.8 42.8 47.7 52.1
S.C. 40.5 39.2 32.7 32.6 26.0 42.5 41.0 34.7 34.6 27.1 44.4 42.8 36.8 36.5 28.2
KW 3.66 3.66 3.66 3.63 3.80 3.76 3.76 3.76 3.77 3.88 3.87 3.86 3.86 3.91 3.97
105 T.C. 37.9 38.3 37.6 42.7 47.5 39.7 39.5 38.5 43.5 48.2 41.5 40.7 39.3 44.3 48.8
S.C. 37.9 37.4 31.1 31.4 24.8 39.7 39.1 33.2 33.3 25.9 41.5 40.7 35.3 35.3 26.9
KW 4.05 4.05 4.04 4.10 4.22 4.17 4.17 4.13 4.21 4.30 4.29 4.28 4.23 4.33 4.38
115 T.C. 35.2 35.5 34.0 39.5 44.6 36.9 37.1 34.9 40.2 45.1 38.7 38.7 35.8 41.0 45.5
S.C. 35.2 35.5 29.6 30.1 23.6 36.9 37.1 31.7 32.1 24.7 38.7 38.7 33.9 34.1 25.7
KW 4.44 4.44 4.42 4.57 4.64 4.57 4.58 4.51 4.66 4.71 4.70 4.71 4.60 4.75 4.78
125 T.C. 32.6 32.7 30.4 36.3 41.7 34.2 34.7 31.3 37.0 42.0 35.8 36.6 32.2 37.7 42.3
S.C. 32.6 32.7 28.0 28.8 22.4 34.2 34.7 30.2 30.9 23.5 35.8 36.6 32.2 32.9 24.5
KW 4.83 4.83 4.80 5.05 5.06 4.98 4.98 4.88 5.11 5.12 5.12 5.14 4.97 5.17 5.19
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC/PC60 0.96 0.96 1.07
– FC/MC62 0.98 0.98 1.06
– FC64 1.04 0.98 1.07
RFCX48DE – 0.97 0.98 1.01
RFCX60DE – 1.00 1.00 1.00
RFCX48DP – 0.95 0.95 1.06
Furnace Coil T.C. S.C. KW
RGF19*CE16 FC/MC62D 1.03 1.08 1.09
RGF19*CE16 FC/PC60C 0.99 1.04 1.09
RGF19*CE16 FC64D 1.07 1.10 1.09
RGF19*CE20 FC/MC62D 1.05 1.11 1.06
RGF19*CE20 FC64D 1.09 1.13 1.06
RGF19*DE20 FC/MC/PC60D 1.01 1.08 1.06
RGF19*DE20 FC/MC62D 1.05 1.12 1.06
RGF19*DE20 FC64D 1.10 1.14 1.06

810754-UTG-C-0214
18 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
HIGH CFM
COOLING PERFORMANCE DATA - HIGH CFM 2-STAGE OPERATION
CONDENSING UNIT MODEL NO. RHP14J604S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1650 1850 2050
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 56.5 60.0 59.6 65.6 70.6 58.5 61.2 60.8 66.7 72.5 60.5 62.3 62.0 67.8 74.4 S.C. 55.7 50.3 42.9 42.5 34.9 57.7 53.1 44.9 44.5 36.0 59.6 55.9 47.0 46.5 37.1
KW 3.43 3.47 3.46 3.53 3.61 3.52 3.56 3.55 3.62 3.70 3.61 3.64 3.64 3.71 3.80
75 T.C. 54.4 57.2 56.8 62.6 67.6 56.3 58.2 57.9 63.6 69.1 58.1 59.2 59.0 64.6 70.6 S.C. 53.6 49.1 41.6 41.3 33.5 55.4 51.9 43.7 43.2 34.6 57.3 54.7 45.7 45.2 35.7
KW 3.81 3.85 3.85 3.92 4.00 3.91 3.94 3.93 4.01 4.09 4.00 4.02 4.02 4.09 4.19
85 T.C. 52.3 54.4 54.0 59.6 64.6 54.0 55.2 55.0 60.5 65.8 55.7 56.1 56.0 61.3 66.9 S.C. 51.5 48.0 40.3 40.1 32.2 53.2 50.7 42.4 42.0 33.2 54.9 53.4 44.4 43.9 34.3
KW 4.20 4.23 4.23 4.31 4.39 4.30 4.32 4.32 4.39 4.48 4.40 4.40 4.40 4.48 4.57
95 T.C. 50.2 51.6 51.2 56.5 61.7 51.8 52.3 52.1 57.3 62.4 53.3 52.9 53.0 58.1 63.2 S.C. 49.5 46.8 39.1 38.9 30.8 51.0 49.5 41.1 40.8 31.8 52.5 52.1 43.1 42.6 32.9
KW 4.59 4.62 4.62 4.70 4.78 4.69 4.70 4.70 4.78 4.87 4.79 4.78 4.79 4.87 4.96
105 T.C. 47.5 48.0 47.8 52.6 57.5 48.8 49.0 48.4 53.3 58.1 50.2 50.0 49.1 54.0 58.8 S.C. 46.8 45.2 37.6 37.4 29.2 48.1 47.3 39.6 39.2 30.2 49.5 49.3 41.5 41.1 31.3
KW 5.11 5.12 5.12 5.20 5.28 5.21 5.21 5.20 5.28 5.37 5.30 5.30 5.28 5.36 5.46
115 T.C. 44.7 44.4 44.4 48.7 53.3 45.9 45.7 44.8 49.3 53.9 47.1 47.1 45.2 49.8 54.4 S.C. 44.1 43.7 36.1 35.8 27.6 45.2 45.0 38.0 37.7 28.6 46.4 46.4 39.9 39.5 29.7
KW 5.63 5.62 5.62 5.70 5.79 5.72 5.72 5.70 5.78 5.88 5.82 5.82 5.78 5.86 5.96
125 T.C. 42.0 40.7 41.0 44.8 49.2 43.0 42.5 41.1 45.3 49.6 44.0 44.2 41.3 45.7 50.0 S.C. 41.4 40.7 34.6 34.3 26.0 42.3 42.5 36.5 36.2 27.0 43.3 43.5 38.4 38.0 28.1
KW 6.15 6.12 6.12 6.20 6.29 6.24 6.23 6.20 6.28 6.38 6.34 6.34 6.27 6.36 6.47
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC62 0.99 0.99 1.01
RFCX60DE – 1.00 1.00 0.98
Furnace Coil T.C. S.C. KW
RGF19*CE20 FC/MC62D+TXV 0.99 1.00 1.00
RGF19*CE20 FC64D+TXV 1.02 1.03 1.01
RGF19*DE20 FC/MC62D+TXV 1.00 1.00 1.00
RGF19*DE20 FC64D+TXV 1.02 1.03 1.00

810754-UTG-C-0214
Johnson Controls Unitary Products 19
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J184S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
450 600 750
MBH COP KW MBH COP KW MBH COP KW
60 60 20.9 4.6 1.34 22.0 5.0 1.30 23.0 5.4 1.25 70 20.3 4.0 1.48 21.3 4.3 1.44 22.3 4.7 1.39
80 19.7 3.5 1.63 20.7 3.8 1.58 21.6 4.2 1.52
47 60 18.4 4.2 1.29 18.9 4.4 1.27 19.5 4.6 1.24 70 17.5 3.6 1.43 18.1 3.9 1.37 18.8 4.2 1.31
80 16.6 3.1 1.57 17.3 3.3 1.54 18.0 3.5 1.50
40 60 16.4 3.8 1.27 17.0 4.0 1.25 17.5 4.2 1.23 70 15.9 3.3 1.40 16.5 3.5 1.38 17.1 3.7 1.36
80 15.4 3.0 1.53 16.0 3.1 1.51 16.6 3.3 1.48
30 60 14.4 3.4 1.23 14.8 3.5 1.23 15.2 3.6 1.22 70 13.9 3.0 1.36 14.3 3.1 1.35 14.6 3.2 1.34
80 13.5 2.7 1.49 13.8 2.7 1.48 14.1 2.8 1.47
17 60 11.4 2.8 1.18 11.7 2.9 1.19 11.9 2.9 1.20 70 10.6 2.4 1.29 10.9 2.5 1.27 11.2 2.6 1.24
80 10.2 2.1 1.42 10.5 2.2 1.39 10.8 2.3 1.35
10 60 9.5 2.5 1.13 9.6 2.5 1.12 9.7 2.6 1.11 70 9.1 2.1 1.26 9.3 2.2 1.24 9.5 2.3 1.22
80 8.6 1.8 1.39 8.9 1.9 1.37 9.3 2.0 1.34
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC/PC32 1.02 0.91 1.11
– FC/MC/PC35 1.02 0.91 1.11
– FC/MC/PC37 1.02 0.93 1.09
– FC/MC/PC43 1.02 0.93 1.09
RFCX24BE – 0.99 0.97 1.02
RFCX30BE – 1.00 0.97 1.02
RFCX24BP – 1.02 0.91 1.11
Furnace Coil MBH COP KW
RGF19*AE10 FC/MC/PC32A 1.00 0.97 1.03
RGF19*AE10 FC/MC/PC37A 1.00 0.98 1.01

810754-UTG-C-0214
20 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J244S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
600 800 1000
MBH COP KW MBH COP KW MBH COP KW
60 60 25.7 4.3 1.74 26.5 4.5 1.72 27.2 4.7 1.70 70 24.0 3.7 1.91 25.1 3.9 1.89 26.1 4.1 1.87
80 22.3 3.1 2.08 23.6 3.4 2.06 25.0 3.6 2.04
47 60 23.7 4.1 1.68 23.9 4.2 1.67 24.2 4.3 1.66 70 21.7 3.5 1.84 22.2 3.7 1.78 22.7 3.9 1.72
80 19.8 2.9 2.00 20.5 3.0 1.99 21.2 3.1 1.98
40 60 19.8 3.6 1.61 20.6 3.7 1.62 21.3 3.8 1.63 70 18.6 3.1 1.78 19.4 3.2 1.79 20.2 3.3 1.79
80 17.3 2.6 1.95 18.2 2.7 1.95 19.1 2.9 1.95
30 60 17.7 3.3 1.57 17.9 3.3 1.59 18.0 3.3 1.62 70 16.6 2.8 1.72 16.9 2.8 1.74 17.2 2.9 1.77
80 15.4 2.4 1.88 15.9 2.5 1.90 16.4 2.5 1.92
17 60 14.6 2.9 1.50 15.0 2.9 1.54 15.3 2.8 1.58 70 13.0 2.3 1.66 13.7 2.4 1.66 14.4 2.5 1.66
80 10.6 1.7 1.80 11.6 1.9 1.80 12.6 2.1 1.80
10 60 13.5 2.7 1.48 13.7 2.7 1.49 13.9 2.7 1.50 70 12.1 2.2 1.64 12.4 2.2 1.64 12.7 2.3 1.64
80 10.7 1.8 1.78 11.1 1.8 1.79 11.4 1.9 1.79
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC/PC32 1.03 0.92 1.10
– FC/MC/PC35 1.03 0.91 1.11
– FC/MC/PC37 1.03 0.94 1.08
– FC/MC/PC43 1.03 0.94 1.08
RFCX24BE – 1.00 0.97 1.02
RFCX30BE – 1.00 0.97 1.02
RFCX24BP – 1.01 0.92 1.08
Furnace Coil MBH COP KW
RGF19*AE10 FC/MC/PC32A 1.01 0.95 1.04
RGF19*AE10 FC/MC/PC37A 1.02 0.98 1.03
RGF19*BE12 FC/MC/PC35B 1.00 1.00 0.99
RGF19*BE12 FC/MC/PC43B 1.00 1.03 0.96
RGF19*CE16 FC/MC/PC35C 1.00 1.00 0.99
RGF19*CE16 FC/MC/PC43C 1.00 1.02 0.97
RGF19*CE20 FC/MC/PC35C 1.00 0.98 1.00
RGF19*CE20 FC/MC/PC43C 1.00 1.01 0.98
